Broadrack KSR Series User manual

KSR Series
Single Rail LCD Console with CAT5 KVM Switch
User Manual
Rev 1.0

KSR Series User Manual
I
Packing List
The complete KSR-11508-C5 / 11516-C5 / 11532-C5 / 11708-C5 / 11716-C5 /
11732-C5 / 11708HD-C5 / 11716HD-C5 / 11732HD-C5 / 11908-C5 / 11916-C5 /
11932-C5 package consist of:
1 x 1U 19” rack mount console
2 x rails with front and rear bracket
2 x long brackets. (Needed for rack depth 828 ~ 1000mm)
1 x power cord
1 x T-Dongle
1 x user manual CD
1 x quick installation guide
2 x key
6 x flat screws. (for rail mount to console body)
6 x screws. (for replace long bracket)
The complete KSR-12008-C5 / 12016-C5 / 12032-C5 package consist of:
1 x 1U 19” rack mount console
2 x rails with front and rear bracket
1 x power cord
1 x T-Dongle
1 x user manual CD
1 x quick installation guide
2 x key
6 x flat screws. (for rail mount to console body)
Check to make sure that the unit was not damaged in shipping. If you encounter a
problem, contact your dealer.
Please read this manual thoroughly, and follow the installation and operation
procedures carefully to prevent any damage to the product, and/or any of the devices
that connect to it.

KSR Series User Manual
II
Safety Instructions
1. Please read these safety instructions carefully.
2. Please keep this User’s Manual for later reference.
3. Please disconnect this equipment from AC outlet before cleaning. Don’t use
liquid or sprayed detergent for cleaning. Use moisture sheet or clothe for
cleaning.
4. For pluggable equipment, the socked-outlet shall be installed near the
equipment and shall be easily accessible.
5. Please keep this equipment from humidity.
6. Lay this equipment on a reliable surface when install. A drop or fall could cause
injury.
7. Do not leave this equipment in an environment unconditioned, storage
temperature above 600C, it may damage the equipment.
8. The opening on the enclosure is for air convection hence the equipment from
overheating. DO NOT COVER THE OPENING.
9. Make sure the voltage of the power source connect the equipment to the power
outlet.
10.Please keep the power cord such a way that people cannot step on it. Do not
place anything over power cord. The power cord must rate for the voltage and
current marked on the product’s electrical ratings label. The voltage and current
rating of the cord should be greater than the voltage and the current rating
marked on the product.
11.All cautions and warning on the equipment should be noted.
12.If the equipment is not in use for long time, disconnect the equipment from mains
to avoid being damaged by transient over-voltage.
13.Never pour any liquid into ventilation openings; this could cause fire or electrical
shock.
14.Never open the equipment. For safety reason, qualified service personnel
should only open the equipment.
15.If one of the following situations arises, get the equipment checked by service
personnel.
The Power Cord or plug is damaged.
Liquid has penetrated into the equipment.

KSR Series User Manual
III
The equipment has been exposed to moisture.
The equipment has not worked well or you cannot get it work according to
User’s Manual.
The equipment has dropped and damaged.
If the equipment has obvious signs or breakage.

KSR Series User Manual
IV
Index of Contents
Packing List..........................................................................................................I
Safety Instructions...............................................................................................II
Index of Contents..............................................................................................IV
1. General Information......................................................................................6
1.1 Overview...............................................................................................6
1.2 Product Specification............................................................................2
1.2.1 KSR-11508-C5 / 11516-C5 / 11532-C5 Specification.................2
1.2.2 KSR-11708-C5 / 11716-C5 / 11732-C5 Specification.................6
1.2.3 KSR-11708HD-C5 / 11716HD-C5 / 11732HD-C5 Specification10
1.2.3 KSR-11908-C5 / 11916-C5 / 11932-C5 Specification...............14
1.2.4 KSR-12008-C5 / 12016-C5 / 12032-C5 Specification...............18
2. Panel Controls and OSD Function..............................................................22
2.1 Auto Tune...........................................................................................23
2.2 Input Source .......................................................................................23
2.3 Brightness...........................................................................................23
2.4 Contrast..............................................................................................24
2.5 Color...................................................................................................24
2.6 Position...............................................................................................25
2.7 Language............................................................................................26
2.8 Recall..................................................................................................27
2.9 Exit......................................................................................................27
2.10 Power Indicator.................................................................................27
3. Installation ..................................................................................................28
3.1 Install KSR-11508-C5 / 11516-C5 / 11532-C5 / 11708-C5 / 11716-C5 /
11732-C5 / 11708HD-C5 / 11716HD -C5 / 11732HD-C5 / 11908-C5 /
11916-C5 / 11932-C5 into Cabinet..............................................................28
3.1.1 Notes ........................................................................................28
3.1.2 Hardware Kits Contents............................................................28
3.1.3 Installation Steps.......................................................................29
3.1.4 Replace Longer Bracket Steps (For rack depth 828~1000mm) 31
3.1.5 Unload Steps ............................................................................31
3.2 Install KSR-12008-C5 / 12016-C5 / 12032-C5 Console into Cabinet..33
3.2.1 Notes ........................................................................................33
3.2.2 Hardware Kits Contents............................................................33

KSR Series User Manual
V
3.2.3 Install Console Steps................................................................34
3.3 Installing the Video Card and Video Driver.........................................36
3.3.1 Configuring the Display Settings...............................................36
4. KVM SWITCH.............................................................................................37
4.1 Introduction.........................................................................................37
4.2 Feature ...............................................................................................37
4.3 Technical Specifications .....................................................................39
4.4 System Requirements.........................................................................41
4.5 Cable Diagrams..................................................................................42
4.6 Product Details ...................................................................................43
4.7 Hardware Installation.......................................................................45
4.7.1 Computer / Server Installation....................................................45
4.7.2 Optional Remote Console Installation........................................47
4.7.2.1 IP Module.........................................................................47
4.7.2.2 CAT5 Module...................................................................48
4.7.3 When video signal is foggy or unclear .......................................48
4.7.4 Daisy Chain Connection ............................................................49
4.7.5 Turning on the Console..............................................................49
4.7.6 Testing the Console...................................................................50
4.8 Hotkey.................................................................................................51
4.9 OSD (On Screen Display)...................................................................53
4.9.1 Login Window ............................................................................54
4.9.2 Port Name..................................................................................55
4.9.3 Main Menu.................................................................................56
4.9.3.1 LANGUAGE.....................................................................56
4.9.3.2 PORT NAME EDIT ..........................................................57
4.9.3.3 PORT SEARCH...............................................................58
4.9.3.4 USER SECURITY............................................................58
4.9.3.5 ACCESS LIST..................................................................59
4.9.3.6 HOTKEY..........................................................................60
4.9.3.7 TIME SETTINGS .............................................................61
4.9.3.8 OSD MOUSE...................................................................61

KSR Series User Manual
VI
1
.
General Information
1.1 Overview
The KVM console is an ideal solution for network administration with multiple
servers / platforms. Their 15 / 17 / 17.3 / 19 / 20.1-inch large size TFT LCD color
display and ultra-low-profile compact industrial keyboard / touchpad provide the
user-friendliest and most reliable environment for network administrators. All these
functions are integrated in a 19-inch 1U space with rugged construction design to
achieve ultra space saving and high reliability for high quality industrial network
applications.
The KVM console provide superior picture quality and state-of-the-art features
mounted in an industrial grade, rack mount console. The console forms a rugged
enclosure that protects the panel from industrial hazards and permits easy
access to panel controls.
The KVM console panels provide flicker-free color images at optimal
resolutions. The panels’ 0.297 x 0.297 mm pixel pitch – 15 inch (0.264 x 0.264 mm
pixel pitch – 17 inch, 0.1989 x 0.1989 mm pixel pitch – 17.3 inch, 0.098 x 0.294 mm
pixel pitch – 19 inch, 0.255 x 0.255mm pixel pitch – 20.1 inch) ensures crisp images
with clear definition, even at high resolutions. The KVM console panels are
intelligent, microprocessor-based, and have an ergonomically designed display.
The KVM console panels employ the latest in active matrix thin film transistor
(TFT) technology, providing crisp screen images and wide viewing angles.
Unlike CRT panels, LCD panels are inherently immune to the magnetic fields
commonly found on the plant floor or communications centers. LCDs are also
typically brighter than conventional CRT technology, making them ideal for the
high ambient lighting conditions found in many of today's factory environments.
On-screen menus allow for display adjustments. In addition, the panels'
Plug-n-Play+ features support Dos, Unix, Linux, OSX, Windows, while a
universal power supply ensures global applicability.
The KVM console panels are compatible with most analog RGB (red, green, blue)
display standards, including PS/2, optional for Sun Micro System, Apple Macintosh
Centris, Quadra, and Macintosh II family signals. The LCD panel is capable of
displaying crisp and vibrant color graphics with VGA, SXGA, XGA (non-interlaced),
SXGA, UXGA, and most Macintosh compatible color video cards.

KSR Series User Manual
2
1.2 Product Specification
1.2.1 KSR-11508-C5 / 11516-C5 / 11532-C5 Specification
Model name
KSR-11508-C5
Number of ports
8
Dimension
590.8 x 482.0 x 44.0 mm / 23.3 x 19.0 x 1.7 inches
Package Dimension
788 x 564 x 206 mm / 31.0 x 22.2 x 8.1 inches
Net Weight
12.0 Kg / 26.5 lbs
Gross Weight
18.5 Kg / 40.8 lbs
Display Size
15 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1024 x 768 (XGA)
Pixel Pitch
Supports 0.297 mm x 0.297 mm
Viewing Angle (CR>10) Right-Left View 130°(Typ)
Up-Down View 100°(Typ)
Contrast Ratio
550:1
Brightness
White 250 cd/m² (Center 1 point Typ)
Back Light
Dual Lamps for Back Light
Supported Colors
16M Colors (6-bit with FRC)
Response Time
Rising Time 2 ms, Decay Time 6 ms
Operating System
Dos, Microsoft Windows, Netware, Unix, Linux, MAC, SUN
Connectors
PC Port Connectors
8 x RJ-45
Daisy Chain Connector
1 x HDDB 15-pin
Power Connector
1 x AC Inlet
Signal Cable
CAT5 / 5E / 6 cable with T-Dongle
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
10.12W for Panel
Temperature Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language US, UK, German, French, Spanish, Italian, Portuguese, Dutch,
Swiss, Belgium, Swedish, Hebrew, Norwegian, Danish, Japanese,
Mandarin, Russian, Arabic
Table 1-1. KSR-11508-C5 Specification

KSR Series User Manual
3
Model name
KSR-11516-C5
Number of ports
16
Dimension
590.8 x 482.0 x 44.0 mm / 23.3 x 19.0 x 1.7 inches
Package Dimension
788 x 564 x 206 mm / 31.0 x 22.2 x 8.1 inches
Net Weight
12.0 Kg / 26.5 lbs
Gross Weight
18.5 Kg / 40.8 lbs
Display Size
15 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1024 x 768 (XGA)
Pixel Pitch
Supports 0.297 mm x 0.297 mm
Viewing Angle (CR>10) Right-Left View 130°(Typ)
Up-Down View 100°(Typ)
Contrast Ratio
550:1
Brightness
White 250 cd/m² (Center 1 point Typ)
Back Light
Dual Lamps for Back Light
Supported Colors
16M Colors (6-bit with FRC)
Response Time
Rising Time 2 ms, Decay Time 6 ms
Operating System
Dos, Microsoft Windows, Netware, Unix, Linux, MAC, SUN
Connectors
PC Port Connectors
16 x RJ-45
Daisy Chain Connector
1 x HDDB 15-pin
Power Connector
1 x AC Inlet
Signal Cable
CAT5 / 5E / 6 cable with T-Dongle
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
10.12W for Panel
Temperature Operate 0 ~ 50°C / 32 ~122°F
Storage -20 ~ 60°C / -4 ~140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language US, UK, German, French, Spanish, Italian, Portuguese, Dutch,
Swiss, Belgium, Swedish, Hebrew, Norwegian, Danish, Japanese,
Mandarin, Russian, Arabic
Table 1-2. KSR-11516-C5 Specification

KSR Series User Manual
4
Model name
KSR-11532-C5
Number of ports
32
Dimension
590.8 x 482.0 x 44.0 mm / 23.3 x 19.0 x 1.7 inches
Package Dimension
788 x 564 x 206 mm / 31.0 x 22.2 x 8.1 inches
Net Weight
12.0 Kg / 26.5 lbs
Gross Weight
18.5 Kg / 40.8 lbs
Display Size
15 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1024 x 768 (XGA)
Pixel Pitch
Supports 0.297 mm x 0.297 mm
Viewing Angle (CR>10) Right-Left View 130°(Typ)
Up-Down View 100°(Typ)
Contrast Ratio
550:1
Brightness
White 250 cd/m² (Center 1 point Typ)
Back Light
Dual Lamps for Back Light
Supported Colors
16M Colors (6-bit with FRC)
Response Time
Rising Time 2 ms, Decay Time 6 ms
Operating System
Dos, Microsoft Windows, Netware, Unix, Linux, MAC, SUN
Connectors
PC Port Connectors
32 x RJ-45
Daisy Chain Connector
1 x HDDB 15-pin
Power Connector
1 x AC Inlet
Signal Cable
CAT5 / 5E / 6 cable with T-Dongle
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
10.12W for Panel
Temperature Operate 0 ~ 50°C / 32 ~122°F
Storage -20 ~ 60°C / -4 ~140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language US, UK, German, French, Spanish, Italian, Portuguese, Dutch,
Swiss, Belgium, Swedish, Hebrew, Norwegian, Danish, Japanese,
Mandarin, Russian, Arabic
Table 1-3. KSR-11532-C5 Specification

KSR Series User Manual
5
Figure 1-1. KSR-11508-C5 Dimension
Figure 1-2. KSR-11516-C5 Dimension
Figure 1-3. KSR-11532-C5 Dimension

KSR Series User Manual
6
1.2.2 KSR-11708-C5 / 11716-C5 / 11732-C5 Specification
Model name
KSR-11708-C5
Number of ports
8
Dimension
590.8 x 482.0 x 44.0 mm / 23.3 x 19.0 x 1.7 inches
Package Dimension
788 x 564 x 206 mm / 31.0 x 22.2 x 8.1 inches
Net Weight
13.0 Kg / 28.7 lbs
Gross Weight
20.5 Kg / 45.2 lbs
Display Size
17 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1280 x 1024 (SXGA)
Pixel Pitch
Supports 0.264 mm x 0.264 mm
Viewing Angle (CR>10) Right-Left View 170°(Typ)
Up-Down View 160°(Typ)
Contrast Ratio
1000:1
Brightness
White 250 cd/m² (Center 1 point Typ)
Back Light
Dual Lamps for Back Light
Supported Colors
16.7M Colors (6-bit with FRC)
Response Time
Rising Time 3.8 ms, Decay Time 1.2 ms
Operating System Dos, Microsoft Windows, Netware, Unix, Linux, MAC, SUN
Connectors
PC Port Connectors
8 x RJ-45
Daisy Chain Connector
1 x HDDB 15-pin
Power Connector
1 x AC Inlet
Signal Cable
CAT5 / 5E / 6 cable with T-Dongle
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
9.91W for Panel
Temperature Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language US, UK, German, French, Spanish, Italian, Portuguese, Dutch,
Swiss, Belgium, Swedish, Hebrew, Norwegian, Danish, Japanese,
Mandarin, Russian, Arabic
Table 1-4. KSR-11708-C5 Specification

KSR Series User Manual
7
Model name
KSR-11716-C5
Number of ports
16
Dimension
590.8 x 482.0 x 44.0 mm / 23.3 x 19.0 x 1.7 inches
Package Dimension
788 x 564 x 206 mm / 31.0 x 22.2 x 8.1 inches
Net Weight
13.0 Kg / 28.7 lbs
Gross Weight
20.5 Kg / 45.2 lbs
Display Size
17 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1280 x 1024 (SXGA)
Pixel Pitch
Supports 0.264 mm x 0.264 mm
Viewing Angle (CR>10) Right-Left View 170°(Typ)
Up-Down View 160°(Typ)
Contrast Ratio
1000:1
Brightness
White 250 cd/m² (Center 1 point Typ)
Back Light
Dual Lamps for Back Light
Supported Colors
16.7M Colors (6-bit with FRC)
Response Time
Rising Time 3.8 ms, Decay Time 1.2 ms
Operating System
Dos, Microsoft Windows, Netware, Unix, Linux, MAC, SUN
Connectors
PC Port Connectors
16 x RJ-45
Daisy Chain Connector
1 x HDDB 15-pin
Power Connector
1 x AC Inlet
Signal Cable
CAT5 / 5E / 6 cable with T-Dongle
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
9.91W for Panel
Temperature Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language US, UK, German, French, Spanish, Italian, Portuguese, Dutch,
Swiss, Belgium, Swedish, Hebrew, Norwegian, Danish, Japanese,
Mandarin, Russian, Arabic
Table 1-5. KSR-11716-C5 Specification

KSR Series User Manual
8
Model name
KSR-11732-C5
Number of ports
32
Dimension
590.8 x 482.0 x 44.0 mm / 23.3 x 19.0 x 1.7 inches
Package Dimension
788 x 564 x 206 mm / 31.0 x 22.2 x 8.1 inches
Net Weight
13.0 Kg / 28.7 lbs
Gross Weight
20.5 Kg / 45.2 lbs
Display Size
17 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1280 x 1024 (SXGA)
Pixel Pitch
Supports 0.264 mm x 0.264 mm
Viewing Angle (CR>10) Right-Left View 170°(Typ)
Up-Down View 160°(Typ)
Contrast Ratio
1000:1
Brightness
White 250 cd/m² (Center 1 point Typ)
Back Light
Dual Lamps for Back Light
Supported Colors
16.7M Colors (6-bit with FRC)
Response Time
Rising Time 3.8 ms, Decay Time 1.2 ms
Operating System
Dos, Microsoft Windows, Netware, Unix, Linux, MAC, SUN
Connectors
PC Port Connectors
32 x RJ-45
Daisy Chain Connector
1 x HDDB 15-pin
Power Connector
1 x AC Inlet
Signal Cable
CAT5 / 5E / 6 cable with T-Dongle
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
9.91W for Panel
Temperature Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language US, UK, German, French, Spanish, Italian, Portuguese, Dutch,
Swiss, Belgium, Swedish, Hebrew, Norwegian, Danish, Japanese,
Mandarin, Russian, Arabic
Table 1-6. KSR-11732-C5 Specification

KSR Series User Manual
9
Figure 1-4. KSR-11708-C5 Dimension
Figure 1-5. KSR-11716-C5 Dimension
Figure 1-6. KSR-11732-C5 Dimension

KSR Series User Manual
10
1.2.3 KSR-11708HD-C5 / 11716HD-C5 / 11732HD-C5 Specification
Model name
KSR-11708HD-C5
Number of ports
8
Dimension
590.8 x 482.0 x 44.0 mm / 23.3 x 19.0 x 1.7 inches
Package Dimension
788 x 564 x 206 mm / 31.0 x 22.2 x 8.1 inches
Net Weight
13.0 Kg / 28.7 lbs
Gross Weight
20.5 Kg / 45.2 lbs
Display Size
17.3 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1920 x 1080 (Full HD)
Pixel Pitch
Supports 0.1989 mm x 0.264 mm
Viewing Angle (CR>10) Right-Left View 140°(Typ)
Up-Down View 120°(Typ)
Contrast Ratio
650:1
Brightness
White 300 cd/m² (Center 1 point Typ)
Back Light
Dual Lamps for Back Light
Supported Colors
16.7M Colors (6-bit with FRC)
Response Time
Rising Time 2 ms, Decay Time 6 ms
Operating System Dos, Microsoft Windows, Netware, Unix, Linux, MAC, SUN
Connectors
PC Port Connectors
8 x RJ-45
Daisy Chain Connector
1 x HDDB 15-pin
Power Connector
1 x AC Inlet
Signal Cable
CAT5 / 5E / 6 cable with T-Dongle
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
8.3W for Panel
Temperature Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language US, UK, German, French, Spanish, Italian, Portuguese, Dutch,
Swiss, Belgium, Swedish, Hebrew, Norwegian, Danish, Japanese,
Mandarin, Russian, Arabic
Table 1-7. KSR-11708HD-C5 Specification

KSR Series User Manual
11
Model name
KSR-11716HD-C5
Number of ports
16
Dimension
590.8 x 482.0 x 44.0 mm / 23.3 x 19.0 x 1.7 inches
Package Dimension
788 x 564 x 206 mm / 31.0 x 22.2 x 8.1 inches
Net Weight
13.0 Kg / 28.7 lbs
Gross Weight
20.5 Kg / 45.2 lbs
Display Size
17 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1920 x 1080 (Full HD)
Pixel Pitch
Supports 0.1989 mm x 0.1989 mm
Viewing Angle (CR>10) Right-Left View 140°(Typ)
Up-Down View 120°(Typ)
Contrast Ratio
650:1
Brightness
White 300 cd/m² (Center 1 point Typ)
Back Light
Dual Lamps for Back Light
Supported Colors
16.7M Colors (6-bit with FRC)
Response Time
Rising Time 2 ms, Decay Time 6 ms
Operating System
Dos, Microsoft Windows, Netware, Unix, Linux, MAC, SUN
Connectors
PC Port Connectors
16 x RJ-45
Daisy Chain Connector
1 x HDDB 15-pin
Power Connector
1 x AC Inlet
Signal Cable
CAT5 / 5E / 6 cable with T-Dongle
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
8.3W for Panel
Temperature Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language US, UK, German, French, Spanish, Italian, Portuguese, Dutch,
Swiss, Belgium, Swedish, Hebrew, Norwegian, Danish, Japanese,
Mandarin, Russian, Arabic
Table 1-5. KSR-11716HD-C5 Specification

KSR Series User Manual
12
Model name
KSR-11732HD-C5
Number of ports
32
Dimension
590.8 x 482.0 x 44.0 mm / 23.3 x 19.0 x 1.7 inches
Package Dimension
788 x 564 x 206 mm / 31.0 x 22.2 x 8.1 inches
Net Weight
13.0 Kg / 28.7 lbs
Gross Weight
20.5 Kg / 45.2 lbs
Display Size
17.3 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1920 x 1080 (Full HD)
Pixel Pitch
Supports 0.1989 mm x 0.1989 mm
Viewing Angle (CR>10) Right-Left View 140°(Typ)
Up-Down View 120°(Typ)
Contrast Ratio
650:1
Brightness
White 300 cd/m² (Center 1 point Typ)
Back Light
Dual Lamps for Back Light
Supported Colors
16.7M Colors (6-bit with FRC)
Response Time
Rising Time 2 ms, Decay Time 6 ms
Operating System
Dos, Microsoft Windows, Netware, Unix, Linux, MAC, SUN
Connectors
PC Port Connectors
32 x RJ-45
Daisy Chain Connector
1 x HDDB 15-pin
Power Connector
1 x AC Inlet
Signal Cable
CAT5 / 5E / 6 cable with T-Dongle
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
8.3W for Panel
Temperature Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language US, UK, German, French, Spanish, Italian, Portuguese, Dutch,
Swiss, Belgium, Swedish, Hebrew, Norwegian, Danish, Japanese,
Mandarin, Russian, Arabic
Table 1-6. KSR-11732HD-C5 Specification

KSR Series User Manual
13
Figure 1-4. KSR-11708HD-C5 Dimension
Figure 1-5. KSR-11716HD-C5 Dimension
Figure 1-6. KSR-11732HD-C5 Dimension

KSR Series User Manual
14
1.2.3 KSR-11908-C5 / 11916-C5 / 11932-C5 Specification
Model name
KSR-11908-C5
Number of ports
8
Dimension
640.8 x 482.0 x 44.0 mm / 25.2 x 19.0 x 1.7 inches
Package Dimension
827 x 564 x 206 mm / 32.6 x 22.2 x 8.1 inches
Net Weight
14.0 Kg / 30.9 lbs
Gross Weight
21.5 Kg / 47.4 lbs
Display Size
19 inches
Panel Type
Active Matrix TFT LCD
Resolution Capabilities
Maximum Resolution up to 1280 x 1024 (SXGA)
Pixel Pitch
Supports 0.098 mm x 0.294 mm
Viewing Angle (CR>10) Right-Left View 170°(Typ)
Up-Down View 160°(Typ)
Contrast Ratio
1000:1
Brightness
White 250 cd/m² (Center 1 point Typ)
Back Light
Dual Lamps for Back Light
Supported Colors
16.7M Colors (6-bit with FRC)
Response Time
Rising Time 3.6 ms, Decay Time 1.4 ms
Operating System Dos, Microsoft Windows, Netware, Unix, Linux, MAC, SUN
Connectors
PC Port Connectors
8 x RJ-45
Daisy Chain Connector
1 x HDDB 15-pin
Power Connector
1 x AC Inlet
Signal Cable
CAT5 / 5E / 6 cable with T-Dongle
Keyboard Mouse
106 key PS/2 keyboard with touch pad
Sync
45 ~ 80 KHz
Power Source
100 ~ 240 VAC input
Power Consumption
11.03W for Panel
Temperature Operate 0 ~ 50°C / 32 ~ 122°F
Storage -20 ~ 60°C / -4 ~ 140°F
Humidity
10% ~ 90% RH
Chassis Construction
Heavy duty steel materials
Keyboard Language US, UK, German, French, Spanish, Italian, Portuguese, Dutch,
Swiss, Belgium, Swedish, Hebrew, Norwegian, Danish, Japanese,
Mandarin, Russian, Arabic
Table 1-7. KSR-11908-C5 Specification
