Broage NBOOK User manual

BROAGE NBOOK
Achelous I515
Quick Guide

Date of purchase: 2020.AUG.01
Place of purchase: Suzhou,China
ENVIRONMENT
Temperature:
－Operating:5°c to 35°c
－Non-operating:-20°c to 65°c
Humidity(non-condensing):
－Operating: 20% to 80%
－Non-operating: 20% to 80%

First things first
We would like to thank you for making an notebook your choice for meeting your
mobile computing needs.
Your guides
To help you use your notebook, we have designed the quick guide:
First off, the Quick Guide introduces you to the basic features and functions of
your new computer.
It covers basic topics such as using the keyboard and audio, etc. This guide
contains detailed information on such subjects as system utilities, data recovery,
expansion options and troubleshooting. In addition it contains warranty
information and the general regulations and safety notices for your notebook.
Software installation
The first time you turn on your computer, it will automatically install software and
set up for use. This may take some time, please do not turn off your computer; wait
until the installation has finished.
Recovery
You should create recovery backups as soon as you can. The pc Recovery
Management program allows you to create recovery backups and then to restore
or reinstall applications and drivers provided by your pc.
Having trouble?
This pc provides several options to support your purchase.
PC support

Make sure you write down your computer serial number, date and place of
purchase and model name on the area provided in this guide; save your proof of
purchase.
Before you call us, please write down any error message that accompanies the
problem, and have the computer in front of you and switched on if possible.
Having these items to hand when contacting us will ensure better and quicker
service.
Pc website
Remember to visit www.juncoelec.com and refer to the support section for
up-to-date information, help, drivers and downloads.
Warranty and contact information
You can find information about the warranty for your computer and how to
contact technical support in your computer's Warranty.

Your notebook tour
After setting up your computer, let us show you around your new computer.
Screen view
# Item Description
1 Webcam Web camera for video communication.
A light next to the webcam indicates that the
webcam is active.
2 Screen Displays computer output.

Whole machine view
# Item Description
1 Charger connector Connects to an AC adapter.
2 USB 3.0 port Connects to USB devices.
3 HDMI connector Supports high-definition digital video
connections.
4 Display panel Displays computer output.
5 Touchpad Touch-sensitive pointing device.
The touchpad and selection buttons form a single
surface.
6 Touchpad buttons Press down firmly on the touchpad surface to
perform a left click.
Press down firmly on the lower right corner to
perform a right click
7 Keyboard For entering data into your computer.

8 USB 3.0 port Connects to USB devices.
9 Headphone jack Connects to an external microphone for recording
audio.
10 Micro-SD card slot Accepts one Secure Digital(TF/MINI SD)card.
Only one card can operate at a time.
11 Power Turns the computer on and off.
12 RJ-45 Ethernet cable insertion port
Information on USB 3.0
·USB 3.0 compatible ports are blue.
·Compatible with USB 3.0 and earlier devices.
·For optimal performance, use USB 3.0-certified devices.
·Defined by the USB 3.0 specification (SuperSpeed USB).
Base view

Using the keyboard
The keyboard has full-sized keys and separate cursor, lock, Windows, function and
special keys.
Hotkeys
The computer employs hotkeys or key combinations to access most of the
computer's controls like screen brightness and volume output.
To activate hotkeys, press and hold the <Fn> key before pressing the other key in
the hotkey combination.
Hotkey Function Description
＜Fn>+<Esc> Touchpad toggle Turns the built-in touchpad on and
off.
＜Fn>+<F2> Speaker toggle Turns the speakers on and off.
＜Fn>+<F4> Volume up Increases the sound volume.
＜Fn>+<F3> Volume down Decreases the sound volume.
<Fn>+<F5> Keyboard light
control
Keyboard light switch and brightness
adjustment
<Fn>+<F6> Screen brightness
-
The screen is dimmed
<Fn>+<F7> Screen brightness
+
The screen brightness is adjusted up
＜Fn>+＜F8> Previous Return to the previous media file.
＜Fn>+<F9> Next Jump to the next media file.
＜Fn>+＜F12> Insert A mode used to switch text input in a
word processor.

Room 1602-2, Building 1, Xingyao City,
No. 2028 Jiangling Road,
Xixing Street, Binjiang District,
Hangzhou City, Zhejiang Provinc
Tel. [phone]
www.juncoelec.com
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:(1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Product: Notebook Computer
Trade Name: Broage
Name of Responsible Party: Hangzhou ALL IN E-Commerce Co., Ltd.
Address of Responsible Party: Room 1602-2, Building 1, Xingyao City, No. 2028
Jiangling Road, Xixing Street, Binjiang District, Hangzhou City, Zhejiang Provinc
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:

(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
SAR Information Statement
Your broage NBOOK is a radio transmitter and receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal
Communications Commission of the U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general population. The guidelines
are based on standards that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health. The exposure
standard for broage NBOOKs employs a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the
broage NBOOK transmitting at its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR level of the
broage NBOOK while operating can be well below the maximum value. This is because the
broage NBOOK is designed to operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to a wireless base station antenna,
the lower the power output. Before a broage NBOOK model is available for sale to the public, it
must be tested and certified to the FCC that it does not exceed the limit established by the
government adopted requirement for safe exposure. The tests are performed in positions and
locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The
highest SAR value for this model when worn on the body, as described in this user guide, is
0.298W/Kg(Body-worn measurements differ among broage NBOOK models, depending upon
available accessories and FCC requirements). While there may be differences between the SAR
levels of various broage NBOOKs and at various positions, they all meet the government
requirement for safe exposure. The FCC has granted an Equipment Authorization for this model
broage NBOOK with all reported SAR levels evaluated as in compliance with the FCC RFexposure
guidelines. SAR information on this model broage NBOOK is on file with the FCC and can be
found under the Display Grant section of http://www.fcc.gov/ oet/fccid after searching on
FCC ID: 2AWGQI515Additional information on Specific Absorption Rates (SAR) can be found on the
Cellular Telecommunications Industry Asso-ciation (CTIA) web-site at
http://www.wow-com.com. * In the United States and Canada, the SAR limit for broage NBOOKs
used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard

incorporates a sub-stantial margin of safety to give additional protection for the public and to
account for any variations in measurements.
Body-worn Operation
This device was tested for typical body-worn operations. To comply with RF exposure
requirements, a minimum separation distance
of 0mm must be maintained between the user’s body and the handset, including the antenna.
Third-party belt-clips, holsters,
and similar accessories used by this device should not contain any metallic components.
Body-worn accessories that do not meet these requirements may not comply with RF exposure
requirements and should be avoided. Use only the supplied or an approved antenna.
