Brother PE430 User manual

MODEL: PE430
PE500
NV90E
HE1
PE525
Published: Oct.,2008
Revised: Mar.,2017

MODEL LIST
Model Countries (Added Date)
NV90E IND (May / 2011)
HE1 USA (Jul / 2011)
PE500 USA (Nov / 2011)
NV90E UK&IRE (May / 2012)
NV90E DEU&ITA&CHE (Oct / 2012)
PE430 ARG (Jun / 2014)
PE525 USA (Jul / 2014)

Country Code & Abbreviation of Country Name
Meaning of "R" and "H"

- 1 -
CONTENTS
(1) MAIN FRAME / COVER ························································ 2
(2) UPPER SHAFT / NEEDLE BAR / PRESSER FOOT UNIT············· 4
(3)-1 FEED UNIT (New type) ························································ 6
(3)-2 FEED UNIT (Old type)·························································· 8
(4) THREAD CUTTING UNIT·····················································10
(5) BOBBIN WINDING / NEEDLE THREADING MECHANISM·········12
(6) ELECTRIC PARTS / MAIN MOTOR UNIT ·······························14
(7) EMBROIDERY UNIT ···························································16
(8) ACCESSORY PARTS / USER MANUAL / PACKAGE ···············18
SPARE PARTS··································································20
Note on parts:
We keep performance parts for this sewing machine for at least 8 years after this model is discontinued.
Performance parts are the necessary parts to maintain the function of the sewing machine.

- 2 -
(1) MAIN FRAME / COVER

- 3 -
(1) MAIN FRAME / COVER
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
1 XE5481001 REAR COVER SUB ASSY R 36 XC0508020 RUBBER WASHER
2 XC4517151 BOBBIN PRESSER 1000018473 37 085311016 TAPTITE BIND B M3X10
3 0A4302006 SCREW PAN (S/P WASHER) M3X20 38 XE2941001 BASE PLATE
4 021300106 NUT 1 M3 39 XA1805021 BASE RUBBER A H
5 XA1786053 SPOOL PIN 40 XC3471021 ADJUSTING SCREW
6 XE1394001 SPOOL PIN HOLDER ASSY 41 XC3472021 BASE PLATE RUBBER H
7 XE1490101 THREAD GUIDE SUPPORTING PLATE 42 XD0351051 LEAD WIRE ASSY MAIN BODY FCOMB
8 085311216 TAPTITE BIND B M3X12 43 XE1829001 FERRITE CORE:K1NF-75(N)BK2
9 XE2910001 THREAD GUIDE PLATE ASSY 44 XE2942001 CONNECTOR HOLDER
10 XE2911001 THREAD GUIDE PLATE 45 XD0353051 ES PIN F-A
11 XE2912001 SHAFT 46 XD0945051 ES PIN F-B
12 XE2913001 THREAD GUIDE SPRING 47 XD0967051 SPRING,COMPRESSION
13 X57605051 SPRING 48 XC2514021 FEED BAR SPACER
14 048020343 RETAINING RING E2 1000038911 49 048020343 RETAINING RING E2 1000038911
15 X59642021 SCREW 50 060300516 SCREW BIND M3X5
16 XE5552001 FRONT COVER SUPPLY ASSY:PE430 R 51 XE3145001 CONNECTOR HOLDER COVER
(PE430) 52 X57908021 TAPTITE,BIND S M4X10
XE5553001 FRONT COVER SUPPLY ASSY:NV90E R 53 XD0354251 NEEDLE PLATE B ASSY
(NV90E) 54 XD0355251 NEEDLE PLATE B H
XF1263001 FRONT COVER SUPPLY ASSY:HE1 R 1000026162 55 XC7371022 SLIDE BUTTON
(HE1) 56 XD1666052 CUTTER COVER
XF2297001 FRONT COVER SUPPLY ASSY:PE500 R 1000028353 57 XD1461051 NEEDLE PLATE COVER SPRING
(PE500) 58 X80321021 NT LOWER THREAD CUTTER H
XG1089001 FRONT COVER SUPPLY ASSY:PE525 R 1000028353 59 XD1645021 NEEDLE PLATE COVER SUPPLY ASSY H
(PE525) 60 XE1447201 HANDLE 1000029226
17 XE3096101 SS BUTTON 1000019614 61 XE2953001 HANDLE HOLDER
18 XE2929001 NP BUTTON 62 XE1449001 HANDLE SHAFT
19 XE5274001 SSVR PCB ASSY:CEMB 63 048040343 RETAINING RING E4 1000038911
20 XE2935001 INSULATOR SHEET:CCOM SS 64 137713020 POLYESTER SLIDER
21 XC3751021 MINI CLAMP:UAMS-02 65 XE2954001 BASE FOOT COVER
22 085311016 TAPTITE BIND B M3X10 66 XE5354001 BOTTOM COVER
23 XC6363021 BOARD PRESSER 67 060400816 SCREW BIND M4X8
24 XE2367001 LED LAMP RIGHT SUPPLY ASSY LE1 68 XE2956001 STUD
25 XE3376001 RUBBER 69 087411416 TAPTITE CUP B M4X14
26 XE2937001 FACE PLATE ASSY R 70 085301616 TAPTITE BIND P M3X16
27 X80321021 NT LOWER THREAD CUTTER H 71 XC7568051 SCREW, PAN(S/P WASHER)M4X14
28 XE1435001 FACE PLATE CUTTER HOLDER
29 138433021 TAPTITE,PAN B M3X6
30 XC9604051 NEEDLE THREAD LEVER KNOB
31 XA5825051 NEEDLE THREAD LEVER SHAFT
32 XC3039151 NEEDLE THREAD LEVER
33 138260051 THREAD THROUGH LEVER SPRING
34 XA6320050 SHAFT PRESSER PLATE
35 XA5525051 WASHER,PLAIN

- 4 -
(2) UPPER SHAFT / NEEDLE BAR / PRESSER FOOT UNIT
3
2
4
5
7
32
22
63
41 68 67
69
39
72
73
43
30
31
1
71
12
41
40
65
70
35
46
15
20
19
18
36
5
6
8
56
29
48
47
49
38
13
61
28
55
27
80
60
66
59
16
44
62
21
17 14
79
33
34
76
75
77
78
61
69
9
25
24
64
41
74
50
10
11
73
74
42
37
32
51
52
54
53
4
58
57
45
81
82

- 5 -
(2) UPPER SHAFT / NEEDLE BAR / PRESSER FOOT UNIT
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
UPPER SHAFT MECHANISM 43 XE2976001 LEAD WIRE ASSY ZPM-CCOM
1 XE3707001 UPPER SHAFT SUPPLY ASSY H 44 XE2977001 Z ZIGZAG CAM
2 XC2375051 PULLEY 45 XD1612051 NEEDLE HOLDER GUIDE ASSY
3 012500532 SET SCREW SOCKET (FT) M5X5 46 XC3037021 SCREW3X10
4 132421021 BUSHING PRESSER 47 XE1470101 TAKE-UP SUPPORT SHAFT
5 X57908021 TAPTITE, BIND S M4X10 48 XZ5030001 WASHER, SPRING
6 XE5842001 TIMING BELT 420-5KC-6 H 1000034635 49 048050343 RETAINING RING E5 1000038911
7 XE3581001 TENSION PULLEY ASSEMBLY 50 XC3338021 SCREW3X8
8 138172021 SCREW, PAN (S/P WASHER) M4X10 51 XC8564031 THREAD TAKE-UP LEVER
9 XE3036001 NP PCB ASSY CCOM 52 XC4897020 THREAD TAKE-UP LEVER LINK
10 060400816 SCREW BIND M4X8 53 XC4898021 PRESSER BAR
11 XC3183051 FELT 54 XC4899121 PRESSER BAR CLAMP
NEEDLE BAR / PRESSER FOOT UNIT 55 XC7207021 SCREW STUD M5
12 XE5357001 BASE HOLDER ASSY CE 56 XC4900021 SPRING
13 XE2970001 NEEDLE BAR HOLDER ASSY H 57 XG1343001 SCREW SM3.57-40X8 H 1000052522
14 XC2420020 SHAFT 58 XD0474151 EMBROIDERY PRESSER ASSEMBLY
15 XC8754021 NEEDLE HOLDER SHAFT A 59 XE2982001 PRESSER FOOT LIFTER H
16 014300532 SET SCREW SOCKET (CP) M3X5 60 XE2983001 EMBROIDERY PRESSER STOPPER
17 XC8755020 PLATE 61 060300416 SCREW BIND M3X4
18 060300516 SCREW BIND M3X5 62 XE2984001 T CAM
19 X50476021 SPRING 63 XE2985001 THREAD RELEASE LEVER ASSY
20 XE1463001 HOOK RELEASE PLATE 64 XC4904121 SPRING
21 000020416 SCREW BIND M2X4 1000042428 65 146200021 RETAINING RING, CS4
22 XF2685001 NEEDLE BAR H 1000040787 66 XE2988001 THREAD RELEASER ASSY
23 XE0011101 NEEDLE BAR THREAD GUIDE Q 1000016793 67 137713020 POLYESTER SLIDER
24 X53053052 SCREW SM2.38 68 048020343 RETAINING RING E2 1000038911
25 XC2426020 NEEDLE THREAD PLATE 69 048040343 RETAINING RING E4 1000038911
26 XE0012101 NEEDLE THREAD GUIDE SPRING 1000016793 70 XC8773020 RUBBER
27 XC2427051 NEEDLE BLOCK 1000056100 71 XE1507001 PRESSER SWITCH HOLDER
28 XZ0388251 NEEDLE CLAMP SCREW H 72 XE2991001 PF SWITCH ASSY: CCOM
29 XC2434021 NEEDLE THREAD BLOCK 73 X57908021 TAPTITE, BIND S M4X10
30 XC6562131 NEEDLE BAR CRANK ROD ASSY H 74 X50532021 PRESSER PLATE
31 XE1999001 SCREW, FLAT SM3.57-40X7 L 75 XC2504050 ADJUSTING SCREW
32 012400432 SET SCREW SOCKET (FT) M4X4 76 XZ0380051 SCREW, PAN (WASHER) M3X18
33 XE1464501 THREADER HOOK ASSY H 1000019655 77 XC6056120 PLATE SPRING
34 XD1546051 LINK A ASSY 78 060400816 SCREW BIND M4X8
35 XD1548151 LINK B 79 XE5554101 NEEDLE UNIT SUPPLY ASSY C-EMB 1000029344
36 XE1465001 THREAD GUIDE ASSY 80 XE7727201 N/B THREAD GUIDE SUPPLY ASSY 1000027848
37 XC2429021 SPRING 81 X53330020 WASHER 1000034663
38 X56851021 LOCK NUT 82 048025346 RETAINING RING E2.5 1000032425
39 014401232 SET SCREW SOCKET (CP) M4X12
40 XC8756021 SHAFT BUSHING
41 060300616 SCREW BIND M3X6
42 XE2974001 Z PULSE MOTOR: M35SP-9N CCOM

- 6 -
(3)-1 FEED UNIT (New type)
41
35
44
4
22
38
24
3
10
38
10
27
23
1
9
11
24
22 21
2
27
26
25
23
42
48
43
12
17
14 18
20
19
39
45
40
15
16
13
6
7
5
8
7
36
50
46
47
34
31
32
33
28
29
30
33
49
33
37
*Th
ere are
t
wo
t
ypes
(
new
t
ype
/
o
ld
t
ype
)
o
f
th
e
f
ee
d
un
it
an
d
th
e us
i
ng par
t
s are
diff
eren
t
.
Wh
en or
d
er
i
ng par
t
s, c
h
ec
k
th
e s
h
ape o
f
th
e par
t
s
i
n
di
ca
t
e
d
i
n
blue to order appropriate ones.

- 7 -
(3)-1 FEED UNIT (New type)
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
1 XF7691001 BASE PLATE ASSY 1000039425 45 XC3183051 FELT
2 XE2995001 HORIZONTAL FEED SHAFT 46 XA0286051 WIRE CLIP 1000042697
3 014400432 SET SCREW SOCKET (CP) M4X4 47 060400516 SCREW BIND M4X5
4 060301206 SCREW BIND M3X12 48 XD1856100 PILE H 1000055798
5 XF3569001 OUTER ROTARY HOOK ASSY H 1000047756 49 XE6472001 NEEDLE PLATE HOLDER 1000039425
6 XE1480001 OUTER ROTARY HOOK SHAFT
7 137805022 SPACER 50 XF7720001 FEED UNIT SUPPLY ASSY C-EMB N 1000039425
8 137976021 WASHER 6
9 XZ5092001 SHAFT SUPPORTER 1000039425
10 0A4400806 SCREW,PAN(S/P WASHER)M4X8 1000039425
11 014400632 SET SCREW SOCKET (CP) M4X6
12 XE3650101 INNER ROTARY HOOK BRACKET ASSY H 1000016400
13 XE2998001 PHOTO DIODE SUPPORTER
14 XE2999001 PHOTO DIODE HOLDER ASSY
15 XC7866351 CORD HOLDER 1000012334
16 060260316 SCREW BIND M2.6X3
17 000020416 SCREW BIND M2X4 1000016096
18 0A5300806 SCREW PAN (S/P WASHER) M3X8
19 XE5360001 LOWER SHAFT ASSY
20 XC4943021 TIMING PULLEY D
21 014500532 SET SCREW SOCKET (CP) M5X5
22 X52664020 LOWER SHAFT BUSHING
23 X51383020 WASHER,THRUST
24 048060343 RETAINING RING E6 1000038911
25 XC8798021 SET COLLAR
26 XC4944021 BUSHING PRESSER B
27 085310615 TAPTITE BIND B M3X6
28 XF7693001 NEEDLE PLATE A ASSY H 1000039425
29 XF7694001 NEEDLE PLATE A 1000039425
30 XF2440001 STOPPER PLATE 1000030484
31 XE1488001 NEEDLE PLATE B SUPPORT PLATE
32 XF7695001 F GEAR STOPPER PLATE 1000039425
33 060260316 SCREW BIND M2.6X3 1000039425
34 XE6473001 SCREW NEEDLE PLATE H 1000039425
35 XE3004001 LEAD WIRE GUIDE HOLDER
36 060300416 SCREW BIND M3X4
37 XF5447001 THREAD CUTTER MODULE SUPPORTER 1000039425
38 060400516 SCREW BIND M4X5 1000039425
39 132421021 BUSHING PRESSER
40 X57908021 TAPTITE,BIND S M4X10
41 XD1855551 INNER ROTARY HOOK ASSY R/H 1000055798
42 X52800120 BOBBIN
43 XE1489001 STUD SCREW M4
44 060301206 SCREW BIND M3X12

- 8 -
(3)-2 FEED UNIT (Old type)
44
4
38
47
7
25
40
41
46
27
6
30
26
1
3
14
13
27
25 24
5
30
29
28
26
45
51
12
46
15
20
17 21
23
22
42
48
43
18
19
16
9
10
8
11
10
2
39
41
52
49
50
37
32
34
35
36
31
33
36
*Th
ere are
t
wo
t
ypes
(
new
t
ype
/
o
ld
t
ype
)
o
f
th
e
f
ee
d
un
it
an
d
th
e us
i
ng par
t
s are
diff
eren
t
.
Wh
en or
d
er
i
ng par
t
s, c
h
ec
k
th
e s
h
ape o
f
th
e par
t
s
i
n
di
ca
t
e
d
i
n
blue to order appropriate ones.

- 9 -
(3)-2 FEED UNIT (Old type)
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
1 XE5359001 BASE PLATE ASSY 45 X52800120 BOBBIN
2 XC8782021 NEEDLE PLATE SUPPORTER SHAFT B 46 XE1489001 STUD SCREW M4
3 021300106 NUT 1 M3 47 060301206 SCREW BIND M3X12
4 XE2994001 THREAD CUTTER MODULE SUPPORTER 48 XC3183051 FELT
5 XE2995001 HORIZONTAL FEED SHAFT 49 XA0286051 WIRE CLIP 1000042697
6 014400432 SET SCREW SOCKET (CP) M4X4 50 060400516 SCREW BIND M4X5
7 060301206 SCREW BIND M3X12 51 XD1856000 PILE H 1000019976
8 XC2210021 OUTER ROTARY HOOK ASSY H 1000023473
9 XE1480001 OUTER ROTARY HOOK SHAFT 52 XE5555101 FEED UNIT SUPPLY ASSY C-EMB 1000029406
10 137805022 SPACER
11 137976021 WASHER 6
12 XE1481001 SHAFT SUPPORTER
13 138172021 SCREW,PAN(S/P WASHER)M4X10
14 014400632 SET SCREW SOCKET (CP) M4X6
15 XE3650101 INNER ROTARY HOOK BRACKET ASSY H 1000016400
16 XE2998001 PHOTO DIODE SUPPORTER
17 XE2999001 PHOTO DIODE HOLDER ASSY
18 XC7866351 CORD HOLDER 1000012334
19 060260316 SCREW BIND M2.6X3
20 000020416 SCREW BIND M2X4 1000016096
21 0A5300806 SCREW PAN (S/P WASHER) M3X8
22 XE5360001 LOWER SHAFT ASSY
23 XC4943021 TIMING PULLEY D
24 014500532 SET SCREW SOCKET (CP) M5X5
25 X52664020 LOWER SHAFT BUSHING
26 X51383020 WASHER,THRUST
27 048060343 RETAINING RING E6 1000038911
28 XC8798021 SET COLLAR
29 XC4944021 BUSHING PRESSER B
30 085310615 TAPTITE BIND B M3X6
31 XE5361201 NEEDLE PLATE A ASSY H 1000029406
32 XE5362001 NEEDLE PLATE A
33 XF2440001 STOPPER PLATE 1000030484
34 XE1488001 NEEDLE PLATE B SUPPORT PLATE
35 XD1623251 F GEAR STOPPER PLATE 1000025374
36 060260316 SCREW BIND M2.6X3
37 X50487021 SCREW M4 H
38 XE3004001 LEAD WIRE GUIDE HOLDER
39 060300416 SCREW BIND M3X4
40 XE3005001 THREAD CUTTER MODULE SUPPORTER
41 060400516 SCREW BIND M4X5
42 132421021 BUSHING PRESSER
43 X57908021 TAPTITE,BIND S M4X10
44 XD1855451 INNER ROTARY HOOK ASSY R/H 1000053475

- 10 -
(4) THREAD CUTTING UNIT

- 11 -
(4) THREAD CUTTING UNIT
No. CODE NAME R/H REMARKS
1 XC9733051 THREAD CUTTER FRAME ASSY
2 XC9735050 SPACER
3 XG2930001 CUTTER BLADE ASSY H 1000056778
4 XE4994001 PRESSER PLATE ASSY H
5 060300516 SCREW BIND M3X5
6 XC2598120 SPRING PLATE H
7 XC2587020 RUBBER
8 048030343 RETAINING RING E3 1000038911
9 XC2583121 THREAD HOOK ASSY
10 137713020 POLYESTER SLIDER
11 X56731020 WASHER
12 048040343 RETAINING RING E4 1000038911
13 XC9736050 CUTTER HOLDER
14 XC2581221 THREAD CUTTER LEVER
15 XC2582020 THREAD CUTTER LEVER GEAR
16 0A4300605 SCREW PAN (S/P WASHER) M3X6
17 XC2588321 MOTOR HOLDER ASSY 1000018482
18 XC2592020 IDLE GEAR A
19 XC2593020 IDLE GEAR B
20 X56323021 SPRING
21 048020343 RETAINING RING E2 1000038911
22 XF7723001 C PULSE MOTOR SMJ35-4840-BP 1000040101
23 060300416 SCREW BIND M3X4
24 XC2594121 COLLAR
25 060402016 SCREW BIND M4X20
26 X53169020 BAND
27 137713020 POLYESTER SLIDER
28 XC8407020 WAVE-SHAPE SPRING WASHER
29 XE3186001 PHOTO TRANSISTOR ASSY
30 XC9199051 SENSOR HOLDER
31 0A4300605 SCREW PAN (S/P WASHER) M3X6
32 060400516 SCREW BIND M4X5
33 060300516 SCREW BIND M3X5
34 X53169020 BAND
35 XD0075351 THREAD CUTTER SUPPLY ASSY 1000044631

- 12 -
(5) BOBBIN WINDING / NEEDLE THREADING MECHANISM
11
48
16
43
41
23
21
22
44
25
26
24
28
31
30
29
42
15
9
9
12
6
19
42
42
45
10
14
40
38
33
35
40
34
32
13
8
27
20
20
18
48
37
36
17
47
44
46
39
1
4
2
3
7
5

- 13 -
(5) BOBBIN WINDING / NEEDLE THREADING MECHANISM
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
BOBBIN WINDING MECHANISM NEEDLE THREADING MECHANISM
1 XE3008001 BOBBIN WINDER ASSEMBLY HOLDER 16 XE3011101 THREAD GUARD ASSEMBLY 1000055651
2 XE1495001 BW SHAFT HOLDER ASSEMBLY 17 XA9935050 SPRING TAPE
3 X55238021 RUBBER RING 18 XA0083121 TENSION DISC A H
4 XZ5039001 BOBBIN WINDER SHAFT SPRING 19 XA0084121 TENSION DISC B H
5 048050343 RETAINING RING E5 1000038911 20 XD0573021 WASHER
6 XA2862021 BOBBIN WINDER SHAFT STOPPER 21 XA1388021 TENSION DISC WASHER
7 XZ0070021 BOBBIN WINDER SPRING 22 XE1506001 THREAD RELEASE PLATE
8 XC2614051 SW ADJUST PLATE 1000046449 23 XE3014001 SPRING
9 060300616 SCREW BIND M3X6 24 XE3015001 THREAD TENSION ADJUSTING SCREW
10 XC2612051 SW ASSY:BW-F 25 XE3016001 THREAD TENSION PLATE ASSY
11 XC4672051 BOBBIN BASE ASSY H 26 XE3019001 ADJUSTING SCREW SPRING PLATE
12 XC2616051 BOBBIN BASE 1000034911 27 XE3020101 THREAD TENSION ADJUSTING GEAR 1000033516
13 XA5877021 BOBBIN THREAD CUTTER HOLDER 28 XE3201001 THREAD TENSION DIAL
14 X80321021 NT LOWER THREAD CUTTER H 29 XC9234021 TENSION DIAL SHAFT
15 X57908021 TAPTITE,BIND S M4X10 30 X56839021 NOTCHED SPRING 1000043008
31 062300416 SCREW PAN M3X4
32 XC6957121 THREAD TAKE UP SPRING H
33 XD0377151 THREAD CATCHING SPRING CASE FE H
34 XE5731001 THREAD CUTTING SHUTTER H
35 0A4301806 SCREW, PAN (S/P WASHE) M3X18
36 XE3021001 THREAD SENSOR HOLDER
37 XE3022001 UPTHREAD PCB ASSY CCOM
38 XD0383050 THREAD GUIDE WIRE FE H
39 XA9996051 WASHER,PLAIN
40 XC7564021 SCREW, PAN(S/P WASHER)M3X6
41 XE3025001 PLATE ASSEMBLY
42 060300416 SCREW BIND M3X4
43 XE3028001 THREAD GUARD HOLDER S
44 060300416 SCREW BIND M3X4
45 XE1519101 BOBBIN WINDER GUIDE ASSY
46 XC3037021 SCREW3X10
47 XE3029001 THREAD GUARD COVER H
48 XE1489001 STUD SCREW M4

- 14 -
(6) ELECTRIC PARTS / MAIN MOTOR UNIT

- 15 -
(6) ELECTRIC PARTS / MAIN MOTOR UNIT
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
ELECTRIC PARTS MAIN MOTOR UNIT
1 XE5478201 MAIN PCB SUPPLY ASSY-B R 1000054748 24 XE3180101 MAIN MOTOR SUB ASSY:CCOM V (USA) H 1000056719
2 XE3032001 LCD SUPPORTER XG8099001 MAIN MOTOR SUB ASSY:CCOM-2-V0 H 1000056719
3 XE3033001 LIGHT PLATE ASSY (OTHER)
4 XC2435020 ZIGZAG ADJUSTING NUT 25 XC3803120 MOTOR FAN H 1000033777
5 018301232 BOLT SOCKET M3X12 26 XE3046001 MOTOR HOLDER
6 XD0830151 LCD SUPPLY ASSY (~F1G******) R 1000028578 27 0A5300806 SCREW PAN (S/P WASHER) M3X8
XF2349001 LCD SUPPLY ASSY (G1G******~) R 1000028578 28 XA8474021 UPSET 4X12 DB
7 XE5363003 TOUCH PANEL ASSY (HE1) R 1000026162 29 XC2685051 T BELT494-2GT-6 H
XE5363004 TOUCH PANEL ASSY (PE500) R 1000028353
XE5363001 TOUCH PANEL ASSY (OTHER) R
8 XE3267001 INLET ASSY:CCOM (120V)
XE4205001 INLET ASSY:CCOM EU (230V)
XE3183001 INLET ASSY:CCOM UL (HE1, PE500) 1000026162
9 XE3654001 POWER PCB SUPPLY ASSY 120:CCOM R
(120V)
XE4293001 POWER PCB SUPPLY ASSY 230:CCOM
(230V)
10 XE3039101 INSULATION COVER
11 XE3040101 INSULATION PLATE 1000017054
12 XE3041001 POWER LEAD WIRE ASSY:CCOM
13 085311016 TAPTITE BIND B M3X10 1000024772
14 XE3042001 CARD CONNECT COVER
15 060400516 SCREW BIND M4X5
16 XA0286021 WIRE CLIP
17 XE3043001 CORD GUIDE
18 XE3044001 CORD GUIDE A
19 060400816 SCREW BIND M4X8
20 XE3318001 INSULATE SHEET CCOM BACK
21 XE3045001 SUPPORTER MAIN PWB
22 X53169020 BAND
23 XC6052121 POWER SUPPLY CORD:UL CSA-LF H 1000048404
(USA)
XD0111151 POWER SUPPLY CORD:IRAM (ARG) H
XF0749001 POWER SUPPLY CORD:BRZ (BRA120V) H 1000025696
XE4301001 POWER SUPPLY CORD:BRZ 220V (BRA220V) H
X59354221 POWER SUPPLY CORD BS (UK&IRE) H 1000035202
XA0070121 POWER SUPPLY CORD (OTHER) H

- 16 -
(7) EMBROIDERY UNIT

- 17 -
(7) EMBROIDERY UNIT
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
1 XC3807121 MAIN FRAME ASSEMBLY 1000056645 45 X59853020 RUBBER CUSHION
2 XC4153020 X GEAR 46 XA1899021 SPRING
3 048030343 RETAINING RING E3 1000038911 47 XC3824121 HANDLE
4 XC4154020 X DRIVING GEAR 48 XA5352020 CORD PRESSER
5 X53330020 WASHER 49 XA6281020 Y PRESSER PLATE
6 X58715021 T BELT 40S2M400 H 50 XA6334020 SHUTTER PRESSER PLATE
7 048060343 RETAINING RING E6 1000038911 51 XA6152021 ROLLER ASSY
8 XA5308021 X TENSION PULLEY ASSY 52 XC5001021 LEAD WIRE ASSY, YPM
9 XC3809021 X CARRIAGE GUIDE PLATE ASSY 53 X53169020 BAND
10 XA5314020 CORD GUIDE 54 X52318021 COACHING CLIP CS-2
11 XC3811021 MOTOR,PULSE:Y SMJ35-4823-C 55 085300815 TAPTITE BIND P M3X8
12 XC7564021 SCREW, PAN (S/P WASHER) M3X6 56 XE7628101 EMBROIDERY SUPPLY ASSY EU 1000025686
13 XA5316021 X GUIDE SHAFT XE7511001 EMBROIDERY SUPPLY ASSY (OTHER) 1000016800
14 XA5317120 X SLIDER
15 XA5318120 X BELT PRESSER
16 0A4400806 SCREW PAN (S/P WASHER) M4X8
17 XC5350020 X SHUTTER
18 XE3182101 LEAD WIRE ASSY:EMB UNIT 1000056640
19 085301616 TAPTITE BIND P M3X16
20 XE3176001 XSENS PCB ASSY:CCOM
21 000020416 SCREW BIND M2X4 1000016096
22 XC3815021 MOTOR,PULSE:X SMJ40-4888-A
23 0A4300506 SCREW, PAN (S/P WASHER) M3X5
24 XA5324221 X CARRIAGE ASSY
25 XC4155020 Y GEAR
26 048020343 RETAINING RING E2 1000038911
27 XC4156120 Y DRIVING GEAR
28 XA5330021 T BELT 40S2M316 H
29 XA6151021 Y TENSION PULLEY ASSY
30 XA5338121 Y CARRIAGE 1000022851
31 XC5287121 NOTCHED SPRING
32 XA5340121 Y GUIDE SHAFT
33 103810022 WASHER, WAVE SPRING
34 048040343 RETAINING RING E4 1000038911
35 XA5341120 Y SHUTTER 1000017052
36 XA5342120 Y SLIDER
37 XA8390021 SCREW
38 XE3178001 YSENS PCB ASSY:CCOM
39 XA5346020 CORD HOLDER
40 060300416 SCREW BIND M3X4
41 087411416 TAPTITE CUP B M4X14
42 XC2133025 CARRIAGE COVER R
43 XE3398001 ES COVER U R
44 XE3052001 ES COVER D R
