Brother XM2701 User manual

Operation Manual
Product Code: 885-X06/X08/X09/X16/X18/X19/X26/X28/X29
888-X06/X08/X09/X16/X18/X19/X26/X28/X29
Sewing Machine
Manual de instrucciones
Código de producto: 885-X06/X08/X09/X16/X18/X19/X26/X28/X29
888-X06/X08/X09/X16/X18/X19/X26/X28/X29
Máquina de coser
Visítenos en http://solutions.brother.com donde hallará consejos para la solución
de problemas así como la lista de preguntas y respuestas más frecuentes.
Please visit us at http://solutions.brother.com where you can get product
support and answers to frequently asked questions (FAQs).
ENGLISH
ESPAÑOL

———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
—
—
—
1
IMPORTANT SAFETY
INSTRUCTIONS
Please read these safety instructions
before attempting to use the machine.
DANGER - To
reduce the risk of electric shock:
1 Alwaysunplug the machine from
the electrical outlet immediately after
using, when cleaning, when making
any user servicing adjustments
mentioned in thismanual, or if you are
leaving the machine unattended.
WARNING - To
reduce the risk of burns, fire, electric
shock, or injury to persons.
2 Alwaysunplug the machine from
the electrical outlet when making any
adjustmentsmentioned in the
instruction manual:
To unplug the machine, switch the
machine to the symbol “O” position
to turn it off, then grasp the plug and
pull it out of the electrical outlet. Do
not pull on the cord.
Plug the machine directly into the
electrical outlet. Do not use an
extension cord.
Alwaysunplug your machine if the
power iscut.
3 Never operate thismachine if it has
a damaged cord or plug, if it isnot
working properly, if it hasbeen
dropped or damaged, or water isspilled
on the unit. Return the machine to the
nearest authorized dealer or service
center for examination, repair,
electrical or mechanical adjustment.
While the machine isstored or in use if
you notice anythingunusual, such asan
odor,heat, discoloration or deformation,
stop usingthemachineand immediately
unplug the power cord.
When transporting the machine, be
sure to carry it by itshandle. Lifting
the machine by any other part may
damage the machine or result in the
machine falling, which could cause
injuries.
When lifting the machine, be careful
not to make any sudden or careless
movements, otherwise you may
injure your back or knees.
4 Alwayskeep your work area clear:
Never operate the machine with any
air openingsblocked. Keep
ventilation openingsof the machine
and foot control free from the build
up of lint, dust, and loose cloth.
Do not store objectson the foot
controller.
Do not use extension cords. Plug the
machine directly into the electrical
outlet.
Never drop or insert any object into
any opening.
Do not operate where aerosol (spray)
products are being used or where
oxygen isbeing administered.
Do not use the machine near a heat
source, such asa stove or iron;
otherwise, the machine, power cord
or garment being sewn may ignite,
resulting in fire or an electric shock.
Do not place thismachine on an
unstable surface, such asan unsteady
or slanted table, otherwise the
machine may fall, resulting in
injuries.
5 Special careisrequired when sewing:
Alwayspay close attention to the
needle. Do not use bent or damaged
needles.
Keep fingersaway from all moving
parts. Special care isrequired around
the machine needle.

2
—
—
—
—
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
Do not turn on the machine while
pressing down the foot controller.
The machine may start unexpectedly
and cause personal injury or damage
to the machine.
Switch themachineto thesymbol “O”
position toturn it off when makingany
adjustmentsin the needle area.
Do not use a damaged or incorrect
needle plate, asit could cause the
needle to break.
Do not push or pull the fabric when
sewing, and follow careful instruction
when freehand stitching so that you
do not deflect the needle and causeit
to break.
6 Thismachine is not a toy:
Your close attention isnecessary when
themachineisused by or near children.
Theplastic bag that thismachinewas
supplied in should be kept out of the
reach of children or disposed of.
Never allow children to play with the
bag due to the danger of suffocation.
Do not use outdoors.
7 For a longer service life:
When storing thismachine, avoid
direct sunlight and high humidity
locations. Do not use or store the
machine near a space heater, iron,
halogen lamp, or other hot objects.
Use only neutral soapsor detergents
to clean the case. Benzene, thinner,
and scouring powderscan damage
the case and machine, and should
never be used.
Alwaysconsult theoperation manual
when replacing or installing any
assemblies, the presser feet, needle, or
other partsto assurecorrect installation.
8 For repair or adjustment:
If the Light unit (light-emitting diode)
isdamaged, it must be replaced by
authorized dealer.
In the event a malfunction occursor
adjustment isrequired, first follow the
troubleshooting table in the back of
the operation manual to inspect and
adjust the machine yourself. If the
problem persists, please consult your
local authorized Brother dealer.
Use thismachine only for itsintended
use asdescribed in thismanual.
Use accessoriesrecommended by the
manufacturer ascontained in thismanual.
The contentsof thismanual and
specificationsof thisproduct are
subject to change without notice.
For additional product information,
visit our web site at www.brother.com
SAVETHESE
INSTRUCTIONS
Thismachine isintended
for household use.
Thisapplianceisnot intended for useby
persons(including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unlessthey havebeen given
supervision or instruction concerning
useof the appliance by a person
responsible for their safety.
Children should besupervised to ensure
that they do not play with theappliance.
Thisappliance can be used by
children aged from 8 yearsand
aboveand personswith reduced
physical, sensory or mental
capabilitiesor lack of
experience and knowledge if
they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazardsinvolved. Children
shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.

———————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
—
—
—
3
FORUSERSIN THEUK, EIRE,
MALTA AND CYPRUSONLY
IMPORTANT
In the event of replacing the plug fuse, use a fuse
approved by ASTA to BS1362, i.e. carryingthe
mark, rating asmarked on plug.
Always replace the fuse cover. Never use plugswith
the fuse cover omitted.
If the available electrical outlet is not suitable for the
plug supplied with thisequipment, you should
contact your authorized dealer to obtain the correct
lead.
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS...........1
1. KNOWING YOURSEWING
MACHINE..................................4
ACCESSORIES .................................................4
Optional accessories .......................................... 4
THEMAIN PARTS ...........................................5
Flat bed attachment ............................................ 5
USING YOURSEWING MACHINE ................6
Connecting plugs ............................................... 6
Main power and sewing light switch .................. 7
Foot controller .................................................... 7
Checking the needle ........................................... 7
Replacing the needle .......................................... 7
Changing the presser foot ................................... 8
THECONTROLS .............................................9
Pattern selection dial .......................................... 9
Stretch stitching .................................................. 9
Patternsand stitch names ................................. 10
Stitch length dial .............................................. 14
Stitch width dial ............................................... 14
Reverse sewing lever ........................................ 14
THREADING THEMACHINE .......................15
Winding the bobbin ......................................... 15
Lower threading ............................................... 17
Lower threading (for modelsequipped with a
quick-set bobbin) ............................................. 18
Upper threading ............................................... 19
Using the needle threader (for models equipped
with a needle threader) ..................................... 21
Drawing up the lower thread ............................ 22
FABRIC, THREAD, AND NEEDLE
COMBINATIONS .........................................24
2. SEWING BASICS ......................25
Please read before sewing ................................ 25
Starting sewing ................................................. 25
Trial sewing ...................................................... 26
Changing the sewing direction ......................... 26
Sewing thick fabrics ......................................... 26
Sewing thin fabrics ........................................... 27
Sewing stretch fabrics ....................................... 27
Stitching cylindrical pieces ............................... 27
Sewing with a twin needle (Option) ................. 27
Thread tension ................................................. 29
3. BUILT-IN STITCHES ................. 30
Straight stitching ...............................................30
Zigzag stitching .................................................30
Blind hem stitching ...........................................30
Shell tuck stitching ............................................32
Elastic stitching .................................................32
Double action stitching .....................................33
Fagoting ............................................................33
Overedge stitching ............................................34
Feather stitching ................................................34
Triple zigzag stretch stitching ............................35
Decorative stitching ..........................................35
4. SEWING BUTTONHOLESAND
BUTTONS ............................... 36
Making a buttonhole
(1-step automatic buttonhole) ...........................36
Adjusting buttonholes .......................................38
Sewing buttons .................................................39
5. USING ATTACHMENTSAND
APPLICATIONS ....................... 40
Zipper insertion ................................................40
Gathering ..........................................................41
Darning ............................................................41
Appliqués .........................................................41
OPTIONAL ACCESSORIES ........................... 42
Using the walking foot ......................................42
Using the quilting guide ....................................43
Using the quilting foot ......................................43
Using the 1/4-inch quilting foot ........................44
Using the narrow hemmer foot .........................44
Using the blind stitch foot .................................46
6. APPENDIX ................................ 47
MAINTENANCE ........................................... 47
Restrictionson oiling ........................................47
Precautions on storing the machine ..................47
Cleaning ...........................................................47
TROUBLESHOOTING .................................. 49
INDEX .......................................................... 52

4
—
—
—
—
—
——————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
1
1 KNOWING YOUR SEWING MACHINE
ACCESSORIES
We have designed these accessoriesto help you easily perform most sewing tasks.
Note
●The included accessoriesvary depending on the machine model.
Optional accessories
The following are available asoptional accessoriesto be purchased separately. Depending on the model you
purchased, thefollowing accessory may be included with your machine.
1. 2. 3. 4. 5.
6. 7. 8. 9.
No. Part Name Part Code
Americas Others
1Zigzag foot “J”
(on machine) XC4901-121
2 Buttonhole foot “A” XD1792-031
3 Zipper foot “I” XE9369-001
4 Darning Plate XC6063-021
5 Button sewing foot “M” XE2137-001
6Bobbin
(One is on machine) SA156 SFB: XA5539-151
7Needle set
(90/14 needle) 3-piece set: XE5328-001 2-piece set: XE7064-001
8 Oval screwdriver XE5241-001
9 Foot controller See page 5
No. Part Name Part Code
Americas Others
1. 2. 3. 4. 5.
6. 7. 8.
No. Part Name Part Code
Americas Others
1 Extra spool pin XE2241-001
2Twin needle
(2.0/75 needle) X57521-021
3 Walking Foot SA107 F034N:
XC2165-002
4 Quilting Foot SA129 F005N:
XC1948-052
5 1/4-inch Quilting Foot SA125 F001N:
XC1944-052
6 Narrow Hemmer Foot SA127 F003N:
XC1945-052
7 Blind Stitch Foot SA134 F018N:
XC1976-052
8 Quilting guide SA132 F016N:
XC2215-052
No. Part Name Part Code
Americas Others

KNOWING YOURSEWING MACHINE—————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
—
—
—
5
THE MAIN PARTS
1Bobbin winder (Page 15)
Thiswindsthe thread onto thebobbin for useasthe
lower thread.
2Stitch length dial (Page 14)
Rotate the dial to control the stitch length.
3Spool pin (Page 15, 19)
Thisholds the spool of thread.
4Stitch width dial (Page 14)
Rotate the dial to control the stitch width.
5Upper tension-control dial (Page 29)
Thiscontrols the tension of the upper thread.
6Thread guide (Page 15, 19)
Thisisused when winding the thread onto the
bobbin and then threading the machine.
7Thread take-up lever (Page 20)
8Thread cutter (Page 26)
Passthe threadsthrough the thread cutter to cut
them.
9Needle threader (Page 21)
(This isonly available on certain models.)
0Quick-set bobbin (Page 18)
(This isonly available on certain models.)
AFlat bed attachment with accessory compartment
(Page 5)
BPresser foot (Page 8)
CReverse sewing lever (Page 14)
Push thislever to stitch in the reverse direction.
DPattern selection dial (Page 9)
Rotate the dial in either direction to choose the
stitch you want.
EHandwheel
Used to manually raise and lower the needle.
FButtonhole fine-adjustment screw (Page 38)
GMain power and sewing light switch (Page 7)
You can turn the main power and sewing light
switch on and off.
HFoot controller jack / socket (Page 6)
Plug in the foot controller plug and connect the
machine to the power supply.
IPresser foot lever (Page19)
Used to raise and lower the presser foot.
J Buttonholelever (1-Step automatic buttonhole)
( Page 36 )
Lower the buttonhole lever when sewing
buttonholes.
KFoot controller (Page 7)
You can usethisto control thesewingspeed, and to
start and stop sewing.
Foot Controller:
Model KD-1902 for 110-120V area
KD-1902 for 110-127V area (Brazil only)
Model KD-2902 for 220-240V area
The foot controller part code differsdepending on the
country or region. Contact your dealer or thenearest
authorized service center.
Flat bed attachment
The accessoriescan be stored in a compartment inside
the flat bed attachment.
1
Slide the flat bed attachment to the left to
open it.
1Flat bed attachment
2Storage compartment
1
32
4
5
6
7
8
9
0
A
B
C
D
G
F
H
I
K
E
J
1
2

6
—
—
—
—
—
——————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
1
USING YOUR SEWING MACHINE
WARNING
CAUTION
Connecting plugs
1
Connect the foot controller plug to the
machine.
2
Connect the power supply plug to a wall
outlet.
Note
●If a power outage occurs while the sewing
machine isbeingoperated, turn off themain
power and unplug the power supply cord.
When restarting thesewingmachine, follow
thenecessary procedureto correctly operate
the machine.
(For U.S.A. only)
●Thisappliance has a polarized plug (one
blade wider than the other). To reduce the
risk of electric shock, thisplugisintended to
fit in a polarized outlet only one way. If the
plug doesnot fit fully in the outlet, reverse
the plug.
If it still doesnot fit, contact a qualified
electrician to install the proper outlet. Do
not modify the plug in any way.
● Use only regular household electricity for the power source. Using other power sourcesmay
result in fire, electric shock, or damage to the machine.
● Make sure that the plugson the power cord are firmly inserted into the electrical outlet and
the power supply jack on the machine.
● Do not insert the plug on the power cord into an electrical outlet that isin poor condition.
● Turn off the main power and remove the plug in the following circumstances:
When you are away from the machine
After using the machine
When the power failsduring use
When the machine does not operate correctly due to a bad connection or a disconnection
During electrical storms
● Use only the power cord included with thismachine.
● Do not use extension cordsor multi-plug adapterswith many other appliancesplugged in to
them. Fire or electric shock may result.
● Do not touch the plug with wet hands. Electric shock may result.
● When unpluggingthemachine, alwaysturn off themain power first. Alwaysgrasp theplugto
removeit from theoutlet. Pullingon the cord may damagethecord, or lead to fireor electric
shock.
● Do not allow the power cord to be cut, damaged, modified, forcefully bent, pulled, twisted,
or bundled. Do not place heavy objectson the cord. Do not subject the cord to heat. These
thingsmay damage the cord and cause fire or electric shock. If the cord or plug isdamaged,
take the machine to your authorized dealer for repairsbefore continuing use.
● Unplug the power cord if the machine isnot to be used for a long period of time. Otherwise
a fire may result.
a
b

KNOWING YOURSEWING MACHINE—————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
—
—
—
7
Main power and sewing
light switch
Thisswitch turnsthe main power and sewing light on or off.
1Turn on (toward the‘I’ mark)
2Turn off (toward the‘O’ mark)
CAUTION
Foot controller
When you pressthe foot controller down lightly, the
machinewill run atalow speed. When you pressharder,
the machine’sspeed will increase. When you take your
foot off thefoot controller, the machine will stop.
1Slower
2Faster
You should make sure that nothingisplaced on the foot
controller when the machine isnot in use.
CAUTION
Note
(For U.S.A. only)
● Foot Controller: Model KD-1902
Thisfoot controller can be used on themachine
with product code885-X06, 885-X08, 885-X09,
885-X26, 885-X28, 888-X06, 888-X08, 888-X09,
888-X16, 888-X18, 888-X26 and 888-X28.
Theproduct codeismentioned on themachine
ratingplate.
Checking the needle
The sewing needle must always be straight and sharp
for smooth sewing.
■Checking the needle correctly
Put the flat side of the needle on a flat surface.
Check the needle from the top and the sides.
Dispose of any bent needlessafely.
1Parallel space
2Level surface (bobbin cover, glass, etc.)
Replacing the needle
CAUTION
1
Turn off the machine.
2
Raise the needle by turning the
handwheel toward you
(counterclockwise) so that the mark on
the wheel points up.
3
Lower the presser foot lever.
1Presser foot lever
● Do not turn on themachinewhilepressing
down the foot controller. The machine
may start unexpectedly and cause
personal injury or damage to the machine.
● Do not allow piecesof cloth and dust to
build up on the foot controller. Doing so
could cause a fire or an electric shock.
2
1
1
2
● Alwaysturn off the machine before you
changethe needle. Otherwise, injuries
may occur if the foot controller is
accidentally pressed and the machine
startssewing.
● Only use sewing machine needlesfor
home use. Other needlesmay bend or
break and cause injury.
● Never sew with a bent needle. A bent
needlewill easily break and cause injury.
1
2
1

8
—
—
—
—
—
——————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
1
CAUTION
4
Hold the needlewith your left hand, and
then use an oval screwdriver to turn the
needle clamp screw counterclockwise to
remove the needle.
1Use an oval screwdriver
2Needle clamp screw
Do not use excessive force when loosening
or tightening the needle clamp screw,
otherwise certain partsof the sewing
machine may be damaged.
5
With the flat side of the needle toward the
back of the machine, insert the needle
until it touchesthe needle stopper. Next,
tighten the needle clamp using an oval
screwdriver.
Install the twin needle in the same way.
CAUTION
Changing the presser foot
CAUTION
You will have to change the presser foot depending on
what you want to sew and how.
1
Turn off the machine.
Raise the presser foot lever.
2
Raise the needle by turning the
handwheel toward you
(counterclockwise) so that the mark on
the wheel pointsup.
3
Press the black button at the back of the
presser foot holder to release the presser
foot.
4
Put a different presser foot on the needle
plate so that the bar on the presser foot is
in line with the slot on the shank.
● Before replacing the needle, place fabric
or paper under the presser foot to
prevent the needle from falling into the
hole in the needle plate.
1Use an oval
screwdriver
2Needle stopper
3Needle
2 1
2
3
1
● Make sure you insert the needle until it
touchesthestopper, and securely tighten
the needle clamp screw with an oval
screwdriver, otherwise the needle may
break or the machine may be damaged.
● Alwaysturn off the machine before you
change the presser foot. If you leave the
power on and step on the controller, the
machine will start and you may be
injured.
● Alwaysuse the correct presser foot for
the stitch pattern you have chosen. If
you use the wrong presser foot, the
needle may strike the presser foot and
bend or break, and may cause injury.
● Only use presser feet that have been
designed to be used with thismachine.
Using any other presser foot may cause
accident or injury.
1Black button
2Presser foot holder
3Presser foot
1
2
3

KNOWING YOURSEWING MACHINE—————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
—
—
—
9
5
Lower the presser foot lever and fix the
presser foot onto the shank. If the presser
foot isin the correct place, the bar should
snap in.
1Shank
2Bar
■ Presser foot installation orientation
CAUTION
THE CONTROLS
Pattern selection dial
CAUTION
To choosea stitch, simply turn thepattern selection dial
in either direction. The next section shows
recommended stitch lengthsand widths.
1Pattern selection dial
2Chosen pattern number
Stretch stitching
Raise the needle by turning the handwheel toward you
(counterclockwise)so that themark on thewheel points
up.
■ 53 Stitches
Setting the stitch length dial to “ ” changesthe
selected pattern to a stretch stitch.
* To set the dial to “SS2”, set it to “SS1”, and then turn the
dial further to the left (direction of the arrow).
■ 27/37 Stitches
Setting the stitch length dial to “ ” changesthe
selected pattern to a stretch stitch.
12
● If thepresser foot isnot installed with
the correct orientation, the needle may
strike the presser foot, which may bend
or break the needle and cause injury.
● When you use the pattern selection dial
to choose a pattern, raise the needle by
turning the handwheel toward you
(counterclockwise) so that the mark on
the wheel pointsup. If the needle isin
the down position when you turn the
pattern selection dial, theneedle, presser
foot or fabric may be damaged.
2
1
1

10
—
—
—
—
—
——————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
1
Patterns and stitch names
■ 53 Stitches(only available on certain models)
■ 37 Stitches(only availableon certain models)
■ 27 Stitches
Pattern Stitch Name Recommended
Width
(mm (inch))
Recommended
Length
(mm (inch))
Reference
Page
53 37 27
1-STEP AUTOMATIC
BUTTONHOLE 3-5 (1/8 – 3/16) F-1.5 (1/64-1/16) 36
STRAIGHT STITCH 0-5 (0-3/16) (Changesneedle
position) 1-4
(1/16-3/16) 30, 40, 41, 42, 43, 44, 46
ZIGZAG STITCH 0-5
(0-3/16) F-4 (1/64-3/16) 30, 39, 41, 42, 46
BLIND HEM STITCH 3-5
(1/8-3/16) F-2 (1/64-1/16) 30, 46
SHELL TUCK STITCH 3-5
(1/8-3/16) F-3 (1/64-1/8) 32
ELASTIC STITCH 3-5
(1/8-3/16) F-2.5 (1/64-3/32) 32
1 2
3
4 5 6
7
8 9 10 11 12 13 14
15 16 17 18 19
1
2
0
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35
36
37
3
8
39 40 41 42 43 44 45 46 47 48 49 50 51 52 53
1
2
3
4 5 6
7
8 9 10 11 12 13 14 15 16 17 18 19
20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35
36
37
1
2
3
4 5 6
7
8 9 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25
26 27
1
1
1
2
2
2
3
3
3
4
4
4
5
5
5
6
6
6

KNOWING YOURSEWING MACHINE—————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
—
—
—
11
STRETCH BLIND HEM STITCH 3-5
(1/8-3/16) F-1.5 (1/64-1/16) 30
SCALLOPSTITCH 3-5
(1/8-3/16) F-1.5 (1/64-1/16) 35
DOUBLEACTION STITCH 3-5
(1/8-3/16) F-3 (1/64-1/8) 33
BRIDGING STITCH 3-5
(1/8-3/16) F-3 (1/64-1/8) 33
RAMPART STITCH 3-5
(1/8-3/16) F-3 (1/64-1/8) 33
ELASTIC SHELL TUCK STITCH 3-5
(1/8-3/16) F-3 (1/64-1/8) 34
BEAD STITCH 3-5
(1/8-3/16) F-1.5 (1/64-1/16) 35
ARROWHEAD STITCH 3-5
(1/8-3/16) F-1.5 (1/64-1/16) 35
— PARALLELOGRAM STITCH 3-5
(1/8-3/16) F-1.5 (1/64-1/16) 35
— SCALLOPSTITCH 3-5
(1/8-3/16) F-1.5 (1/64-1/16) 35
— LIGHTNING STITCH 5
(3/16) F-1.5 (1/64-1/16) 35
— SQUARESTITCH 5
(3/16) F-1.5 (1/64-1/16) 35
— DECORATIVESTITCH 5
(3/16) F-1.5 (1/64-1/16) 35
TRIPLESTRETCH STITCH 0-5 (0-3/16) (Changesneedle
position) / Fixed
2.5 (3/32) 30
TRIPLEZIGZAG STRETCH
STITCH 3-5 (1/8-3/16) / Fixed
2.5 (3/32) 35
ELASTIC OVERLOCK STITCH 3-5
(1/8-3/16) / Fixed
2.5 (3/32) 34
ELASTIC OVERLOCK STITCH 3-5
(1/8-3/16) / Fixed
2.5 (3/32) 34
FEATHERSTITCH 3-5
(1/8-3/16) / Fixed
2.5 (3/32) 34
Pattern Stitch Name Recommended
Width
(mm (inch))
Recommended
Length
(mm (inch))
Reference
Page
53 37 27
7
7
7
8 8 8
9
9
9
1
0
1
0
1
0
1
1
1
1
11
1
2
1
2
12
1
3
1
3
1
3
14
1
4
14
1
5
1
5
1
6
1
6
1
7
1
7
1
8
1
8
1
9
1
9
2
0
2
0
15 1
2
1
2
1
1
6
1
2
2
2
2
17 1
2
3
2
3
18 1
2
4
2
4
1
9
1

12
—
—
—
—
—
——————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
1
COMB STITCH 3-5
(1/8-3/16) / Fixed
2.5 (3/32) 34
DECORATIVESTITCH 3-5
(1/8-3/16) / Fixed
2.5 (3/32) 35
FAGOTING STITCH 3-5
(1/8-3/16) / Fixed
2.5 (3/32) 33
DECORATIVESTITCH 3-5
(1/8-3/16) / Fixed
2.5 (3/32) 33
DECORATIVEHEM STITCH 3-5
(1/8-3/16) / Fixed
2.5 (3/32) 33
DECORATIVESTITCH 5
(3/16) / Fixed
2.5 (3/32) 35
DECORATIVESTITCH 5
(3/16) / Fixed
2.5 (3/32) 35
DECORATIVESTITCH 5
(3/16) / Fixed
2.5 (3/32) 35
— DECORATIVESTITCH 5
(3/16) / Fixed
2.5 (3/32) 35
— DECORATIVESTITCH 5
(3/16) / Fixed
2.5 (3/32) 35
— LINK STITCH 5
(3/16) / Fixed
2.5 (3/32) 35
— DECORATIVESTITCH 3-5
(1/8-3/16) / Fixed
2.5 (3/32) 35
— DECORATIVESTITCH 5
(3/16) / Fixed
2.5 (3/32) 35
— — STRETCH OVERLOCK STITCH 3-5
(1/8-3/16) Fixed
2.5 (3/32) 35
— — STRETCH OVERLOCK STITCH 3-5
(1/8-3/16) Fixed
2.5 (3/32) 35
— — SMOCKING STITCH 3-5
(1/8-3/16) Fixed
2.5 (3/32) 35
— — DECORATIVESTITCH 5
(3/16) Fixed
2.5 (3/32) 35
— — DECORATIVESTITCH 5
(3/16) Fixed
2.5 (3/32) 35
Pattern Stitch Name Recommended
Width
(mm (inch))
Recommended
Length
(mm (inch))
Reference
Page
53 37 27
25 25 20 1
26 26 21 1
27 27 22 1
28 28 23 1
29 29 24 1
30 30 25 1
31 31
26
1
32 32
27
1
33 33 1
34 34 1
35 35 1
36 36
1
37 37 1
38
39
40
41
42

KNOWING YOURSEWING MACHINE—————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
—
—
—
13
— — LEAFSTITCH 3-5
(1/8-3/16) Fixed
2.5 (3/32) 35
— — TREESTITCH 3-5
(1/8-3/16) Fixed
2.5 (3/32) 35
— — LEGSSTITCH 3-5
(1/8-3/16) Fixed
2.5 (3/32) 35
— — DECORATIVESTITCH 3-5
(1/8-3/16) Fixed
2.5 (3/32) 35
— — DECORATIVESTITCH 5
(3/16) Fixed
2.5 (3/32) 35
— — DECORATIVESTITCH 5
(3/16) Fixed
2.5 (3/32) 35
— — DECORATIVESTITCH 5
(3/16) Fixed
2.5 (3/32) 35
— — DECORATIVESTITCH 5
(3/16) Fixed
2.5 (3/32) 35
— — DECORATIVESTITCH 5
(3/16) Fixed
2.5 (3/32) 35
— — DECORATIVESTITCH 5
(3/16) Fixed
2.5 (3/32) 35
— — DECORATIVESTITCH 5
(3/16) Fixed
2.5 (3/32) 35
Pattern Stitch Name Recommended
Width
(mm (inch))
Recommended
Length
(mm (inch))
Reference
Page
53 37 27
4
3
4
4
4
5
4
6
4
7
4
8
4
9
5
0
5
1
5
2
5
3

14
—
—
—
—
—
——————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
1
Stitch length dial
Depending on the selected stitch, you may need to
adjust the stitch length for best results.
The numbersmarked on the stitch length dial represent
the stitch length in millimeters(mm)(1/25 inch).
THEHIGHERTHENUMBER, THELONGERTHE
STITCH. With the “0” setting, material isnot fed. Thisis
used when sewing a button.
The “F”-“1” range isfor making a satin stitch (closed
zigzag stitch), which isused for making buttonholes
and decorativestitches. Theposition needed for making
the satin stitch variesaccording to the material and
thread being used. To determinetheexact dial position,
first test thestitch and length settingson ascrap pieceof
fabric to observe the feeding of the material.
1Stitch length dial
2Shorter
3Longer
CAUTION
Stitch width dial
Raise the needle by turning the handwheel toward you
(counterclockwise)so that themark on thewheel points
up. Thenumbersmarked on thedial represent thestitch
width.
1Stitch width dial
When theStraight or Triple Stretch Stitch isselected, the
needle position can be changed from left to right by
adjusting thestitch width dial.
CAUTION
Reverse sewing lever
You can use reverse sewing for back tacking and
reinforcing seams.
To sew in reverse, push the reverse sewing lever in as
far aspossible and hold it in that position while you
lightly push the foot controller. To sew forward, release
the reverse sewing lever. The machine will then sew
forward.
1Reverse sewing lever
● If the stitches are bunched together,
lengthen the stitch length and continue
sewing. Do not continue sewing without
lengthening the stitch length, otherwise
the needle may break and cause injury.
1231
1
● After adjusting the stitch width, slowly
turn the handwheel toward you
(counterclockwise) and check that the
needledoesnot touch the presser foot. If
the needle hitsthe presser foot, the
needle may bend or break.
● If the stitchesare bunched together,
increase the stitch length. Continuing to
sew with the stitchesbunched together
may result in the needle bending or
breaking.
1

KNOWING YOURSEWING MACHINE—————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
—
—
—
15
THREADING THE MACHINE
Winding the bobbin
CAUTION
1
Pull up the spool pin and put a spool of
thread on thispin.
2
While holding the thread from the spool
with your right hand, passthe thread
toward you, in the groove on the thread
guide. Then, passthe thread around the
pre-tension disk and pull the thread in
completely.
1Pre-tension disk
CAUTION
● We designed the bobbin that comeswith thismachine. If you usebobbinsfrom other models,
the machine will not work properly. Only use the bobbin that comeswith thismachine or
bobbinsof the same type (part code: SA156, SFB: XA5539-151). Using other bobbinsmay
cause damage to the machine.
Actual size
11.5 mm
(7/16 inch)
Thismodel Other models
1Pre-tension disk 2Bobbin winder shaft 3Bobbin
1
3
2
1Pull the thread
in completely.
● If the spool of thread isin the wrong
place, or isset incorrectly, the thread
may tangle on the spool pin.
1

16
—
—
—
—
—
——————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
1
3
Passthe end of the thread through the
hole on the bobbin from the inside of the
bobbin.
4
Put the bobbin onto the bobbin winder
shaft and slide the bobbin winder shaft to
the right. Turn the bobbin clockwise, by
hand, until the spring on the shaft slides
into the notch of the bobbin.
Makesureto pull out 7 to 10 cm (3-4 inches)
of thread from the hole on the bobbin.
1Spring on the shaft
2Notch
37-10 cm (3-4 inches)
CAUTION
5
Turn on the machine.
CAUTION
6
While holding the end of the thread,
gently pressthe foot controller to wind
the thread around thebobbin a few times.
Then stop the machine.
7
Trim the excessthread above the bobbin.
11 cm (1/2 inch)
CAUTION
8
Press the foot controller to start.
9
When thebobbin seemsfull and begins
spinning slowly, take your foot off the foot
controller.
0
Cut the thread, slide the bobbin winder
shaft to the left and remove the bobbin.
Note
● When thesewingmachineisstarted or the
handwheel isturned after winding the thread
around the bobbin, themachine will make a
clickingsound; thisisnot amalfunction.
● Theneedlebar doesnot movewhen you slide
thebobbin winder shaft to theright.
● Pull the thread taut and hold the end of
thethread straight up. If thethreadistoo
short, not pulled taut or held at an angle,
injuriesmay occur when the thread is
wound around the bobbin.
● Do not turn on the machine while
pressing down the foot controller. The
machine may start unexpectedly and
cause personal injury or damage to the
machine.
312
● Make sure you follow the instructions
carefully. If you do not cut the excess
thread completely before winding the
bobbin, when the thread runslow it may
tangle around the bobbin and cause the
needle to break.
1

KNOWING YOURSEWING MACHINE—————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
—
—
—
17
CAUTION
Lower threading
Install the bobbin wound with thread.
For more detailson using the quick-set
bobbin, see page 18.
CAUTION
1
Prepare the bobbin wound properly
before threading the lower thread.
See page 15 for the details about bobbin
winding.
2
Raise the needle by turning the
handwheel toward you
(counterclockwise) and raise the presser
foot lever.
3
Remove the bobbin cover by slidingit and
lift toward you.
1Bobbin cover
4
Put thebobbin in so the thread comesout
in the direction shown by the arrow.
CAUTION
5
Hold the end of the thread, push the
bobbin down with your finger, and then
passthe thread through the slit, asshown.
If the thread isnot correctly inserted through
the tension-adjusting spring of the bobbin
case, it may cause incorrect thread tension.
1Tension-adjusting spring
● Not winding the bobbin properly may
cause the thread tension to loosen, and
may break the needle.
1Wound evenly
2Wound poorly
● Make sure you turn off the machine
while threading. If you accidentally step
on the foot controller and the machine
startsto sew, you could be injured.
1
2
1
● Make sure you set the bobbin so the
thread unrollsin the right direction. If
the thread unrolls in the wrong
direction, it may cause the thread
tension to be incorrect or break the
needle.
1

18
—
—
—
—
—
——————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
1
6
Replace the bobbin cover. Put the
projection into the race retainer groove
and push closed.
1Groove
2Projection
Make sure that the end of the thread comes
out from the cover toward the rear of the
machine (as shown in the illustration).
Draw up the lower thread before starting
sewing. Refer to “Drawing up the lower
thread” on page 22 after threading the upper
thread.
Lower threading (for
models equipped with a
quick-set bobbin)
Install the bobbin wound with thread.
This feature isonly available on certain models.
1
Follow steps 1 to 4 from “Lower
threading” on page 17.
2
While lightly holding down the bobbin
with your right hand asshown, guide the
thread through the slit ( 1 and 2 ). Then,
pull the thread toward you to cut it with
the cutter ( 3 ).
At thistime, check that the bobbin easily
rotatescounterclockwise.
1Slit
2Cutter (Cut the thread with the cutter.)
Note
● If the thread isnot correctly inserted through
the tension-adjusting spring of the bobbin
case, it may cause incorrect thread tension.
1Tension-adjusting spring
3
Replace the bobbin cover. Put the
projection into the race retainer groove
and push closed.
1Groove
2Projection
Start sewing after threading the lower and
upper thread. When sewing gathersor darts,
you can draw up thelower thread by hand so
that somethread will be left over. Refer to the
stepsin “Drawing up the lower thread”
(page 22).
12
1
2
2
31
1
12

KNOWING YOURSEWING MACHINE—————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
—
—
—
—
19
Upper threading
1Spool pin
2Thread guide (back)
3Thread guide (front)
4Thread take-up lever
5Mark on the handwheel
CAUTION
1
Turn off the machine.
2
Raise the presser foot lever.
1Presser foot lever
3
Raisetheneedleby turningthehandwheel
toward you (counterclockwise) so that the
mark on the wheel points up.
If the needle is not correctly raised, the
sewing machine can not be threaded.
1Mark on the wheel
4
Pull up the spool pin and put a spool of
thread on thispin.
CAUTION
● When threading the upper thread, carefully follow the instructions. If the upper threading is
not correct, the thread may become tangled or the needle may bend or break.
● Never use a thread weight of 20 or lower.
● Use the needle and the thread in the correct combination. For detailson the correct
combination of needlesand threads, refer to “FABRIC, THREAD, AND NEEDLE
COMBINATIONS” on page 24.
4
3
2
21
5
1
1
● If the spool of thread isin the wrong
place, or isset incorrectly, the thread
may tangle on the spool pin and cause
the needle to break.
