BRP Lynx REV-XU Series Manual

Original Instructions
619 900 969
REV-XUTM
Series
Read this guide thoroughly.
It contains important safety information.
Minimum recommended operator’s age: 16 years old.
Keep this Operator’s Guide in the vehicle.
Includes
Safety, Vehicle
and Maintenance Information
OPERATOR’S
GUIDE
2019
2019
®™ AND THE BRP LOGO ARE TRADEMARKS OF BOMBARDIER RECREATIONAL PRODUCTS INC. OR ITS AFFILIATES.
©2018 BOMBARDIER RECREATIONAL PRODUCTS INC. ALL RIGHTS RESERVED. PRINTED IN FINLAND.
BEFOREYOU OPERATETHISVEHICLE, READTHIS
OPERATOR’S GUIDE, ALL ON-PRODUCT SAFETY
LABELS ANDWATCHTHE SAFETYVIDEO.
REV-XU Series
619 900 969
OPERATOR’S GUIDE, REV-XU Series/ ENGLISH
GUIDE DU CONDUCTEUR, Série REV-XU / ANGLAIS
FAIT AU / MADE IN CANADA U/M:P.C.

©

OPERATOR'S GUIDE 2019
Commander 600 E-TEC
Commander Limited 600 E-TEC
Commander 800R E-TEC
Commander 900 ACE
Commander GT 900 ACE
Commander GT 1200 4-TEC Comfort
Commander GT 900 ACE Comfort
Commander GT 1200 4-TEC
Commander 600 E-TEC Iceripper 32 mm
Commander 900 ACE Iceripper 32 mm
Commander LTD 900 ACE
69 Ranger 900 ACE
69 Ranger ARMY LTD 800R E-TEC
69 Ranger™ Alpine®1200 4-TEC
69 Ranger SnowCruiser 900 ACE
WARNING
Disregarding any of the safety precautions and instructions contained
in this Operator's Guide and on-product safety labels could cause injury
including the possibility of death!
WARNING
This vehicle may exceed the performance of other vehicles you may have
ridden in the past. Take time to familiarize yourself with your new vehicle.
Lynx products are manufactured by BRP.
The following are trademarks of Bombardier Recreational Products Inc. or its sub-
sidiaries.
ACE®iTCTM ROTAX®
D.E.S.S.™ Lynx®TRA™
HPG™ PPS™ XU™
619900969 en COJT
®™ and the BRP logo are trademarks of Bombardier Recreational Products Inc. or its affiliates.
©2018 Bombardier Recreational Products Inc. and BRP US Inc. All rights reserved.

FOREWORD
Deutsch
Dieses Handbuch ist möglicherweise in Ihrer Landessprache
verfügbar. Bitte wenden Sie sich an Ihren Händler oder besuchen Sie:
www.operatorsguides.brp.com
English This guide may be available in your language. Check with your dealer or
go to: www.operatorsguides.brp.com
Español Es posible que este manual esté disponible en su idioma. Consulte a su
distribuidor o visite: www.operatorsguides.brp.com
Français Ce guide peut être disponible dans votre langue. Vérier avec votre
concessionnaire ou aller à: www.operatorsguides.brp.com
日本語
このガイドは、言語によって翻訳版が用意されています。.
ディーラーに問い合わせるか、次のアドレスでご確認ください：
www.operatorsguides.brp.com
Nederlands Deze handleiding kan beschikbaar zijn in uw taal. Vraag het aan uw dealer
of ga naar: www.operatorsguides.brp.com
Norsk Denne boken kan nnes tilgjengelig på ditt eget språk. Kontakt din
forhandler eller gå til: www.operatorsguides.brp.com
Português Este manual pode estar disponível em seu idioma. Fale com sua
concessionária ou visite o site: www.operatorsguides.brp.com
Suomi Käyttöohjekirja voi olla saatavissa omalla kielelläsi. Tarkista jälleenmyyjältä
tai käy osoitteessa: www.operatorsguides.brp.com
Svenska Denna bok kan nnas tillgänglig på ditt språk. Kontakta din återförsäljare
eller gå till: www.operatorsguides.brp.com
ᵜ᡻޼㜭ᴹᛘⲴ䈝⿽Ⲵ㘫䈁⡸ᵜDŽ䈧㓿䬰୶䰞䈒ˈᡆ㘵ⲫᖅ
www.operatorsguides.brp.com
ѝ᮷ ḕ䈒DŽ
Italiano Questa guida potrebbe essere disponibile nella propria lingua. Contattare
il concessionario o consultare: www.operatorsguide.brp.com
Русский
Воспользуйтесь руководством на вашем языке. Узнайте
о его наличии у дилера или на странице по адресу
www.operatorsguide.brp.com
Congratulations on your purchase of
anewLynx
®snowmobile. Whatever
model you have chosen, it is backed by
the Bombardier Recreational Products
Inc. (BRP) warrantyandanetworkof
authorized Lynx snowmobile dealers
ready to provide the parts, service or
accessories you may require.
Your dealer is committed to your sat-
isfaction. He has taken training to per-
form the initial set-up and inspection
of your snowmobile as well as com-
pleted the final adjustment required to
suit your specific weight and riding en-
vironment before you took possession
_______________ 1

FOREWORD
At delivery, you were informed of the
warranty coverage and signed the
PREDELIVERY CHECK LIST to ensure
your new vehicle was prepared to your
entire satisfaction.
Know Before you Go
To learn how to reduce the risk for you,
your passenger or bystanders being
injured or killed, read the following sec-
tions before you operate the vehicle:
–
SAFETY INFORMATION
– VEHICLE INFORMATION .
Also read all safety labels on your
snowmobile and watch attentively
your
SAFETY VIDEO located at
www.ski-doo.com/safety.
We highly recommend that you take
a safety riding course. Please check
with your dealer or local authorities for
availability in your area.
Failure to follow the warnings con-
tained in this Operator's Guide can
result in SERIOUS INJURY or DEATH.
The proper functioning of a snowmo-
bile depends in part on the surface on
which it is driven.
Drivingonveryhardorsnow-freesur-
faces compromises the cooling of
the engine and the lubrication of rear
suspension components. Avoid pro-
longed driving on such surfaces.
Safety Messages
The types of safety messages, what
they look like and how they are used in
this guide are explained as follows:
Thesafetyalertsymbol indicates a
potential injury hazard.
WARNING
Indicates a potential hazard, if not
avoided, could result in serious in-
jury or death.
CAUTION Indicates a hazard
situation which, if not avoided,
could result in minor or moderate
injury.
NOTICE Indicates an instruction
which, if not followed, could se-
verely damage vehicle components
or other property.
About this Operator's
Guide
This Operator's Guide has been pre-
pared to acquaint the owner/operator
and passenger with this snowmobile
and its various controls, safe riding and
maintenance instructions.
Keep this Operator's Guide in the vehi-
cle as you can refer to it for things such
as maintenance, troubleshooting and
instructing others.
Note that this guide is available in sev-
eral languages. In the event of any dis-
crepancy, the English version shall pre-
vail.
Ifyouwanttoviewand/orprintan
extra copy of your Operator's Guide,
simply visit the following website
www.operatorsguides.brp.com.
The informations contained in this doc-
ument are correct at the time of publi-
cation. BRP, however, maintains a pol-
icy of continuous improvement of its
products without imposing upon itself
any obligation to install them on prod-
ucts previously manufactured. Due
to late changes, some differences be-
tween the manufactured product and
the descriptions and/or specifications
in this guide may occur. BRP reserves
the right at any time to discontinue or
change specifications, designs, fea-
tures, models or equipment without
incurring any obligation upon itself.
2_______________

FOREWORD
This Operator's Guide should remain
with the vehicle when it's sold.
_______________ 3

TABLE OF CONTENTS
FOREWORD .......................................................................... 1
Know Before you Go............................................................. 2
SafetyMessages................................................................. 2
About thisOperator's Guide .................................................... 2
SAFETY INFORMATION
GENERAL PRECAUTIONS......................................................... 10
Avoid Carbon Monoxide Poisoning ............................................ 10
Avoid Gasoline Fires and Other Hazards ...................................... 10
AvoidBurnsfrom Hot Parts .................................................... 10
Accessories and Modifications ................................................ 10
SPECIAL SAFETY MESSAGES ................................................... 11
ACTIVETECHNOLOGIES(iTC)(900ACE AND 12004-TEC) .................. 14
Introduction...................................................................... 14
iTC (intelligent Throttle Control)................................................ 14
RIDINGTHEVEHICLE.............................................................. 15
Pre-Ride Inspection............................................................. 15
Howto Ride ..................................................................... 17
Carrying aPassenger ........................................................... 19
Terrain/Riding Variations........................................................ 20
Environment..................................................................... 24
TRACTIONENHANCINGPRODUCTS ........................................... 26
Manoeuvrability ................................................................. 26
Acceleration ..................................................................... 27
Braking........................................................................... 27
Important Safety Rules ......................................................... 28
EffectsofHavinga StuddedTrackontheLife oftheSnowmobile.......... 28
Installation ofStudsonBRPApproved Tracks................................ 28
Inspection of aStudded Track.................................................. 29
IMPORTANTON-PRODUCTLABELS............................................ 30
HangTag......................................................................... 30
Vehicle Safety Labels ........................................................... 30
TechnicalInformationLabels................................................... 35
VEHICLE INFORMATION
CONTROLS, INSTRUMENTSANDEQUIPMENT .............................. 40
1) Handlebar ..................................................................... 43
2) ThrottleLever................................................................. 43
3) Brake Lever ................................................................... 44
4) Parking Brake Lever.......................................................... 45
5) Engine Cut-OffSwitch ....................................................... 45
6) Emergency EngineStop Switch ............................................ 46
7) MultifunctionSwitch......................................................... 47
4_______________

TABLE OF CONTENTS
CONTROLS, INSTRUMENTS AND EQUIPMENT (cont’d)
8) GearshiftLever ............................................................... 49
9) AdjustableMirrors............................................................ 49
10)Tool Kit ....................................................................... 49
11)Front and RearBumpers ................................................... 50
12)Gauge........................................................................ 50
13)Backrest (If Equipped)...................................................... 61
14)PassengerSeat(1+1) (IfEquipped) ....................................... 61
15)Passengers Handholds(If Equipped)...................................... 62
16)MountainStrap (If Equipped) .............................................. 63
17) Storage Compartment...................................................... 63
18)RearRack.................................................................... 64
19)PassengerHeated Grip and SeatSwitch(IfEquipped) .................. 64
20)12-VoltPower Outlet ....................................................... 65
21)Hitch ......................................................................... 65
22)Adjustable Handlebar (If Equipped)........................................ 66
23)Track ......................................................................... 66
24)Fuses ........................................................................ 66
25)Anchor Points (If Equipped) ................................................ 66
26)Drive BeltGuard............................................................. 67
27)Hood ......................................................................... 68
28)UpperSidePanels .......................................................... 68
29)LowerSidePanels .......................................................... 69
30)RewindStarter Handle(IfEquipped) ...................................... 70
31)Spark PlugStorage.......................................................... 70
32)FuelTankCap................................................................ 70
33)Storage Box(If Equipped) .................................................. 71
34)Shovel(IfEquipped) ........................................................ 71
35)Batterydisplay/Chargingplug (IfEquipped) ............................. 71
36) Electronic Controlled Suspension (ECS²) (If Equipped) .................. 71
37)Seatheater (IfEquipped) ................................................... 72
38)ECO/Standard/Sport ModeSwitch(900ACEand12004-TEC)......... 72
39)HillBrakeSwitches(IfEquipped).......................................... 72
40)HillBrake(IfEquipped) ..................................................... 72
41)AccessoryControlSwitches(If Equipped)................................ 72
42)Lighting Rack(IfEquipped)................................................. 73
43)Brake LightIndicator (IfEquipped)......................................... 73
44)WideningKit(IfEquipped).................................................. 73
FUEL AND OIL....................................................................... 74
Fuel Requirements.............................................................. 74
Recommended Fuel ............................................................ 74
Fueling Procedure............................................................... 74
RecommendedOil.............................................................. 75
InjectionOilLevelVerification.................................................. 75
BREAK-INPERIOD.................................................................. 77
OperationDuringBreak-In...................................................... 77
_______________ 5

TABLE OF CONTENTS
OPERATING MODES (900 ACE AND 1200 4-TEC).............................. 78
ECOMode (FuelEconomyMode)............................................. 78
Standard Mode.................................................................. 78
Sport Mode ...................................................................... 78
Navigating Operating Modes .................................................. 78
Learning Key Modes (Optional) ................................................ 79
OPERATINGINSTRUCTIONS..................................................... 80
EngineStartingProcedure ..................................................... 80
EmergencyStarting............................................................. 80
Vehicle Warm-Up................................................................ 81
GearboxOperation.............................................................. 82
ShifterRodAdjustment......................................................... 83
Shutting Off the Engine......................................................... 83
TowinganAccessory ........................................................... 83
TowingAnotherSnowmobile .................................................. 83
TUNE YOURRIDE .................................................................. 84
RearSuspensionAdjustment.................................................. 86
Front SuspensionAdjustment ................................................. 91
Vehicle Behavior Related toSuspensionAdjustment........................ 92
VEHICLE TRANSPORTATION..................................................... 93
MAINTENANCE
FIRST INSPECTION................................................................. 96
MAINTENANCE SCHEDULE (2-STROKE)....................................... 98
MAINTENANCE SCHEDULE (4-STROKE)..................................... 100
MAINTENANCE PROCEDURES ................................................ 102
AirIntakeSilencerPrefilter................................................... 102
EngineCoolant ................................................................ 102
InjectionOil(600HOE-TEC, 800RE-TEC) .................................. 103
EngineOil(12004-TEC /900ACE)........................................... 103
Engine Oil Replacement (900 ACE).......................................... 104
Engine Oil Replacement (1200 4-TEC) ...................................... 105
EngineOilFilter(900 ACE) ................................................... 107
Oil Filter (12004-TEC)......................................................... 107
ExhaustSystem............................................................... 108
Spark Plugs .................................................................... 109
EngineStopper (E-TEC models) ............................................. 109
Brake Fluid..................................................................... 110
Gearbox Oil .................................................................... 110
Gearbox Oil Replacement .................................................... 111
Drive Belt ...................................................................... 112
Drive Pulley.................................................................... 115
Track............................................................................ 116
Suspension .................................................................... 121
Skis............................................................................. 122
6_______________

TABLE OF CONTENTS
MAINTENANCE PROCEDURES (cont’d)
Fuses and Relays.............................................................. 122
Lights........................................................................... 123
VEHICLE CARE.................................................................... 125
Post-OperationCare .......................................................... 125
Vehicle Cleaningand Protection ............................................. 125
STORAGE.......................................................................... 126
EngineStorage Mode(E-TEC) ............................................... 126
PRESEASON PREPARATION.................................................... 128
TECHNICAL INFORMATION
VEHICLE IDENTIFICATION ...................................................... 132
Vehicle DescriptionDecal .................................................... 132
Identification Numbers ....................................................... 132
NOISE EMISSION AND VIBRATION VALUES ................................ 134
EC-DECLARATIONOFCONFORMITY ......................................... 135
RADIO FREQUENCY DIGITALLY ENCODED SECURITY SYSTEM (RF D.E.S.S.
KEY) ................................................................................ 136
SPECIFICATIONS ................................................................. 137
TROUBLESHOOTING
TROUBLESHOOTINGGUIDELINES ........................................... 152
MONITORINGSYSTEM ......................................................... 155
Pilot Lamps, Messages andBeeper Codes................................. 155
Howto ReadFaultCodes .................................................... 158
WARRANTY
BRP FINLAND OY INTERNATIONAL LIMITED WARRANTY: 2019 LYNX®
SNOWMOBILES .................................................................. 160
MAINTENANCE RECORDS ..................................................... 165
CUSTOMER INFORMATION
CONTACTUS...................................................................... 170
North America................................................................. 170
Europe ......................................................................... 170
Oceania ........................................................................ 170
South America................................................................. 170
Asia............................................................................. 170
CHANGEOFADDRESS/OWNERSHIP......................................... 171
_______________ 7

TABLE OF CONTENTS
8_______________

SAFETY
INFORMATION
________ SAFETY INFORMATION ________ 9

GENERAL PRECAUTIONS
Avoid Carbon Monoxide
Poisoning
All engine exhaust contains carbon
monoxide, a deadly gas. Breathing car-
bon monoxide can cause headaches,
dizziness, drowsiness, nausea, confu-
sion and eventually death.
Carbon monoxide is a colorless, odor-
less, tasteless gas that may be present
even if you do not see or smell any en-
gine exhaust. Deadly levels of carbon
monoxide can collect rapidly, and you
can quickly be overcome and unable
to save yourself. Also, deadly levels of
carbon monoxide can linger for hours
or days in enclosed or poorly ventilated
areas. If you experience any symp-
toms of carbon monoxide poisoning,
leave the area immediately, get fresh
air and seek medical treatment.
To prevent serious injury or death from
carbon monoxide:
– Never run the vehicle in poorly ven-
tilated or partially enclosed areas
such as garages, carports or barns.
Even if you try to ventilate engine
exhaust with fans or open windows
and doors, carbon monoxide can
rapidly reach dangerous levels.
– Never run the vehicle outdoors
where engine exhaust can be drawn
into a building through openings
such as windows and doors.
Avoid Gasoline Fires and
Other Hazards
Gasoline is extremely flammable and
highly explosive. Fuel vapors can
spread and be ignited by a spark or
flame many feet away from the en-
gine. To reduce the risk of fire or explo-
sion, follow these instructions:
– Use only an approved gasoline con-
tainer to store fuel.
– Strictly adhere to instructions in
FU-
ELING PROCEDURE
.
– Never start or operate the engine if
the fuel cap is not properly installed.
Gasoline is poisonous and can cause
injury or death.
– Never siphon gasoline by mouth.
– If you swallow gasoline, get any in
your eye or inhale gasoline vapor,
see your doctor immediately.
If gasoline spills on you, wash with
soap and water and change your
clothes.
Avoid Burns from Hot Parts
The exhaust system and engine be-
come hot during operation. Avoid con-
tact during and shortly after operation
to avoid burns.
Accessories and
Modifications
Do not make unauthorized modifica-
tions, or use attachments or acces-
sories that are not approved by BRP.
Since these changes have not been
tested by BRP, they may increase the
risk of crashes or injuries, and they can
make the vehicle illegal.
See your authorized Lynx dealer for
available accessories for your vehicle.
10 _______ SAFETY INFORMATION ________

SPECIAL SAFETY MESSAGES
SEVERE INJURY OR DEATH can result if you do not follow these instructions:
– Always make a pre-ride inspection BEFORE you start the engine.
– Throttle mechanism should be checked for free movement and return to idle po-
sition before starting engine.
– Always attach tether cord eyelet to clothing before starting the engine.
– Never operate the engine without belt guard and brake disk guard securely in-
stalled or, with hood or side panels opened or removed. Never run the engine
without drive belt installed. Running an unloaded engine such as without drive
belt or with track raised, can be dangerous.
– Always engage parking brake before starting the engine.
– Everyone is a beginner the first time he sits behind the controls of a snowmobile
regardless of previous experience in driving any other type of vehicle. The safe
use of your snowmobile depends on many conditions such as visibility, speed,
weather, environment, traffic, vehicle condition and the condition of the driver.
– Basic training is required for the safe operation of any snowmobile. Study your
Operator's Guide paying particular attention to cautions and warnings. Join
your local snowmobile club: its social activities and trail systems are planned
for both fun and safety. Obtain basic instructions from your snowmobile dealer,
friend, fellow club member or enroll in your state or provincial safety training
program.
– Any new operator must read and understand all safety labels on the snowmo-
bile and the Operator's Guide before operating the snowmobile. Only allow a
new operator to operate the snowmobile in a restricted flat area — at least until
he is completely familiar with its operation. If snowmobile operator training
course is offered in your area, have him enroll.
– The performance of some snowmobiles may significantly exceed that of other
snowmobiles you have operated. Therefore, use by novice or inexperienced
operators is not recommended.
– Snowmobiles are used in many areas and in many snow conditions. Not all
models perform the same in similar conditions. Always consult your snowmo-
bile dealer when selecting the snowmobile model for your particular needs and
uses.
– Injury or death may result to the snowmobile operator, passenger or bystander
if the snowmobile is used in risky conditions which are beyond the driver's, pas-
senger's or snowmobile's capabilities or intended use.
– BRP recommends the operator has at least 16 years old of age.
– It is very important to inform any operator, regardless of his experience, of the
handling characteristics of this snowmobile. The snowmobile configuration,
such as ski stance, ski type, suspension type, track length, width and type vary
from a model to another. The snowmobile handling is greatly influenced by
these characteristics.
– The novice driver should become familiar with the snowmobile through practice
on a level area at slow speeds before venturing far afield.
– Know your local laws. Federal, state, provincial and local government agencies
have enacted laws and regulations pertaining to the safe use and operation of
snowmobiles. It is your responsibility as a snowmobiler to learn and obey these
laws and regulations. Respect and observance will result in safer snowmobiling
for all. Be aware of the liability property damages and insurance laws regarding
your equipment.
________ SAFETY INFORMATION ________ 11

SPECIAL SAFETY MESSAGES
– Speeding can be fatal. In many cases, you cannot react or respond quickly
enough to the unexpected. Always ride at a speed which is suitable to the trail,
weather conditions and your own ability. Know your local rules. Speed limit
may be in effect and meant to be observed.
– Always keep right hand side of the trail.
– Always keep a safe distance from other snowmobiles and bystanders.
– Remember, promotional material may show risky maneuvers performed by
professional riders under ideal and/or controlled conditions. You should never
attempt any such risky maneuvers if they are beyond your level of riding ability.
– Never use this vehicle with alcohol or drugs. They slow reaction time and impair
judgement.
– Your snowmobile is not designed to be operated on public streets, roads or high-
ways.
– Avoid road traveling. If you must do so, and it is permitted, reduce speed. The
snowmobile is not designed to operate or turn on paving. When crossing a road,
make a full stop, then look carefully in both directions before crossing at a 90°
angle. Be wary of parked vehicles.
– Snowmobiling at night can be a delightful experience but because of reduced
visibility, be extra cautious. Avoid unfamiliar terrain and be sure your lights are
working. Always carry a flashlight and spare light bulbs.
– Never remove any original equipment from your snowmobile. Each vehicle
has many built in safety features. Such features include various guards and
consoles, plus reflective materials and safety labels.
– Nature is wonderful but don't let it distract your attention from driving. If you
want to truly appreciate winter's scenery, stop your snowmobile on the side of
the trail so that you don't become a hazard to others.
– Fences represent a very serious threat for both you and your snowmobile. Give
a wide berth to telephone poles or posts.
– Hidden wires unseen from a distance can cause serious accidents.
– Always wear an approved safety helmet, eye protection and a face shield. This
also applies to your passenger.
– Be aware of inherent risks associated with riding off trails, such as avalanche
and other natural or man made hazards or obstacles.
– Tailgating another snowmobile should be avoided. If the snowmobile in front
of you slows for any reason, its driver and passenger could be harmed through
your neglect. Maintain a safe stopping distance between you and the snowmo-
bile in front of you. Depending on the terrain condition, stopping may require
a little more space than you think. Play it safe. Be prepared to use evasive
driving.
– Venturing out alone with your snowmobile could also be hazardous. You could
run out of fuel, have an accident, or damage your snowmobile. Remember, your
snowmobile is capable of traveling further in half an hour than you may be able
to walk in a day. Use the “buddy system”. Always ride with a friend or member
of your snowmobile club. Even then, tell someone where you are going and the
approximate time you plan to return.
12 _______ SAFETY INFORMATION ________

SPECIAL SAFETY MESSAGES
– Meadows sometimes have low areas where water accumulate and freezes
over in winter. This ice is usually glare ice. Attempting to turn or brake on
this surface could cause your vehicle to spin out of control. Never brake or
attempt speeding or turning on glare ice. If you do happen to travel over such a
condition, reduce speed by carefully releasing the throttle.
– Never “jump” with your snowmobile.
– When riding in a group, do not “gun” the throttle. Snow and ice can be thrown
back into the path of a following snowmobile. In addition, when “gunning” the
throttle, the vehicle digs into and leaves an irregular snow surface for others.
– Riding in a group is both fun and enjoyable but don't show off or overtake others
in the group. A less experienced operator might try to do the same as you and
fail. When riding with others, limit your abilities to the experience of others.
– In case of an emergency, press down on the emergency engine stop switch,
then apply brakes.
– Never run the engine in a non-ventilated area and/or if vehicle is left unattended.
– Always engage parking brake before starting the engine.
– Never charge or boost a battery while installed on snowmobile.
– E-TEC engines: Never attempt any fuel system or electrical system main-
tenance or repair. Any maintenance or repair of these systems must by
performed by an authorized Lynx dealer.
– Ensure the path behind is clear of obstacles or bystanders before proceeding in
reverse.
– Always remove the tether cord cap from engine cut-off switch when vehicle is
not in operation in order to prevent accidental engine starting, to avoid unautho-
rized use by children or others or theft.
– NEVER stand behind or near a rotating track. Debris could be projected causing
severe injuries. To remove packed snow or ice, stop engine, tilt and hold vehicle
on its side and use screwdriver from tool kit.
– You may stud the track on this vehicle model. However, you MUST only use the
BRPapprovedtypestudforuseonLynxsnowmobiles. DO NOT EVER use con-
ventional studs, the track thickness is thinner compared to some other tracks.
The stud could tear off track and be projected.
– Never ride as a passenger unless the snowmobile is equipped with a passenger
seat and passenger handholds or holding strap. Sit only on the designated pas-
senger seat.
– Always wear an approved helmet and follow the same dressing guidelines as
those recommended for the operator and described in this guide.
– Make sure that you are able to achieve a stable stance, both feet resting posi-
tively on the footboards of footrests with good grip, and that you are able to hold
on firmly to the handholds.
– Once underway, if you feel uncomfortable or insecure for any reason, don't
wait, tell the driver to slow down or stop.
________ SAFETY INFORMATION ________ 13

ACTIVE TECHNOLOGIES (iTC) (900 ACE AND 1200
4-TEC)
Introduction
NOTE: Some functions or features de-
scribed in this section may not apply to
every model, or may be available as an
option.
The throttle is electronic and provides a
command signal to an electronic mod-
ule whose function is to assure proper
operation of its system within set pa-
rameters.
It is extremely important for opera-
tors to read all information contained
in this operator's guide so as to be-
come familiar with this snowmobile,
its systems, controls, capabilities and
limitations.
iTC (intelligent Throttle
Control)
The system uses an electronic throttle
control (ETC) that provides command
signals to the ECM (Engine Control
Module). With this system, there is no
need for a traditional throttle cable.
The iTC allows the following operating
modes:
–ECOmode
– Standard mode
– Sport mode.
ECO Mode
When ECO mode is selected (fuel
economy mode), vehicle torque and
speed are limited whereby an optimal
cruising speed is maintained in order
to reduce fuel consumption.
Refer to
OPERATING MODES for de-
tailed instructions.
Standard Mode
In standard mode, acceleration is re-
duced when accelerating from a com-
plete stop and when operating in the
low vehicle speed range under certain
conditions.
Sport Mode
In sport mode, maximum engine
power is available throughout the en-
gine operational range.
Refer to
OPERATING MODES for de-
tailed instructions.
Learning Key Modes (Optional)
The LynxTM learning key limits the en-
gine torque and speed of the snow-
mobile therefore enabling first time
users and less experienced operators
to learn how to operate the snowmo-
bile while gaining the necessary confi-
dence and control.
Limitations
The ability of a novice to operate the
snowmobile can be exceeded even
when a learning key is used.
Refer to
OPERATING MODES for de-
tails.
14 _______ SAFETY INFORMATION ________

RIDING THE VEHICLE
Each operator has a responsibility to
ensure the safety of other recreation-
ists or bystanders.
You are responsible for proper opera-
tion of your vehicle as well as training
thosewhomyouallowtorideordrive.
There may be noticeable handling and
performance differences from one
snowmobile to the other.
A snowmobile is relatively simple
to operate but like any other vehicle
or mechanical equipment, it can be
hazardous if you or a passenger are
reckless, thoughtless or inattentive.
We encourage you to have an Annual
Safety Inspection of your snowmo-
bile. Please contact an authorized Lynx
dealer for further details. Though not
required, it is recommended that an
authorized Lynx dealer performs the
preseason preparation of your snow-
mobile. Each visit to your authorized
Lynx dealer is a great opportunity for
your dealer to verify if your snowmo-
bile is included in any safety campaign.
We also urge you to visit your autho-
rized Lynx dealer in a timely manner
if you become aware of any safety re-
lated campaigns.
See an authorized Lynx dealer for avail-
able accessories you may require.
Before venturing on the trails, operate
the snowmobile in a restricted flat area
until you are completely familiar with
its operation and feel comfortable that
you can safely tackle a more demand-
ing task. Have an enjoyable and safe
ride.
Pre-Ride Inspection
WARNING
The pre-operation check is very
important prior to operating the
vehicle. Always check the proper
operation of critical controls,
safety features and mechanical
components before starting.
Before Starting the Engine
1. Remove snow and ice from body in-
cluding lights, seat, footrests, con-
trols and instruments.
2. Verify that air silencer prefilter is free
of snow.
3. Verify that skis and steering operate
freely. Check corresponding action
of skis versus handlebar.
4. Check fuel and oil levels. Replen-
ish if necessary and in case of any
leaks; you should seek service from
an authorized Lynx dealer, repair
shop, or person of your own choos-
ing for maintenance, repair, or re-
placement.
5. All storage compartments must be
properly latched and they must not
contain any heavy or breakable ob-
jects. Hood and side panels must
be also properly latched.
6. Activate the throttle control lever
several times to check that it oper-
ates easily and smoothly. It must re-
turn to idle position when released.
7. Activate the brake lever and make
sure the brake fully applies before
the brake control lever touches the
handlebar grip. It must fully return
when released.
8. Apply parking brake and check if it
operates properly. Leave parking
brake applied.
After Engine is Started
For proper engine starting procedure,
refer to
ENGINE STARTING PROCE-
DURE
in the OPERATING INSTRUC-
TIONS
.
1. Check headlights high beam and
low beam, taillight, stop light and
pilot lamps operation.
NOTE: You may need to detach tether
cord your clothes to check lights. In
such a case, attach cord as soon as you
get back at the controls of the snow-
mobile.
________ SAFETY INFORMATION ________ 15

RIDING THE VEHICLE
2. Check the engine cut-off switch (by
pulling tether cord cap) and emer-
gency engine stop switch opera-
tion.
3. Release parking brake.
4. Refer to the
WARM UP section and
follow instructions.
Pre-Ride Check List
ITEM OPERATION ✔
Body including seat, footrests,
lights, air filter, controls and
instruments
Check condition and remove snow or ice.
Skis and steering Check for free movement and proper action.
Fuel Check for proper level.
Engine/injection oil Check for proper level.
Coolant Check for proper level.
Brake fluid Check for proper level and no leaks.
Storage compartment Check for proper latching and no heavy or
breakable objects.
Throttle lever Check for proper operation.
Track Check condition and remove snow or ice.
Brake lever Check for proper operation.
Parking brake Check for proper operation.
Emergency engine stop switch
and engine cut-off switch
(tether cord cap)
Check for proper action. Tether cord must be
attached to operator clothing eyelet.
Lights Check for proper operation.
Skis and runners Check for proper operation.
Slider shoes Check for proper operation.
Inspect drive belt Check condition for cracks, fraying or abnormal
wear.
16 _______ SAFETY INFORMATION ________

RIDING THE VEHICLE
How to Ride
Riding Gear
Proper snowmobile clothing should
be worn. It should be comfortable
andnottootight. Alwayscheckthe
weather forecast before going on a
ride. Dress for the coldest weather
expected. Thermal underwear next to
theskinalsoprovidesagoodinsula-
tion.
Wear an approved helmet at all times
for safety and comfort. A stocking type
cap, balaclava and face mask should al-
ways be carried or worn. Goggles or a
face shield that attaches to the helmet
are indispensable.
Hands should be protected by a pair
of snowmobile gloves or mitts which
have sufficient insulation and allow use
of thumbs and fingers for operation of
controls.
Rubber bottom boots with either a ny-
lon or a leather top, with removable felt
liners are best suited for snowmobil-
ing.
You should keep yourself as dry as pos-
sible when snowmobiling. When you
come indoors, take your snowmobile
suit and boots off and make certain
they dry properly.
Do not wear long scarfs and loose ap-
parels that could get caught in moving
parts.
Carry colored lens goggles.
What to Bring
Every snowmobiler should carry at
least the following basic parts and
tools that can help him and others in
an emergency:
First aid kit Provided tool kit
Mobile phone Knife
Spare spark plugs Flashlight
Friction tape Trail map
Spare drive belt Snack
Rider Position (Forward Operation)
Your riding position and balance are
the two basic principles of making your
snowmobile go where you want it to.
When turning on the side of a hill, you
and your passenger must be ready to
shift body weight to help it turn in the
desired direction. Driver and passen-
ger(s) must never attempt this ma-
neuvering by placing feet outside of
the vehicle. Experience will teach you
how much lean to put into turns at dif-
ferent speeds and how much you will
have to lean into a slope to maintain
proper balance.
Generally, the riding position for best
balance and control is sitting. How-
ever, the posting, kneeling or standing
positions are also used under certain
conditions.
WARNING
Do not attempt any maneuvers if
they are beyond your abilities.
________ SAFETY INFORMATION ________ 17
