BOMBARDIER ski-doo All Summit Series Reference manual

Printed in Canada (mbs2000-002a.fmMD)
®*Trademarks of Bombardier Inc.
©1999 Bombardier Inc. All rights reserved.
2000-2 Page 1 of 3
THESE MODIFICATIONS MUST BE PERFORMED ON ABOVE MENTIONED
SNOWMOBILES FOR SEA LEVEL RIDING
The present
 supplies all informations pertaining to parts required to modify above mentioned
models for sea level riding.
For 1999 and previous model years, refer to “High Altitude and Sea Level Data” booklet, (P/N 484 300 003).
CAUTION: The following modifications and adjustments apply only for altitudes from and below
1800 m (6000 ft).
Failure to comply with these requirements may cause serious engine damage.
No. 2000-2
Date: September 3, 1999 SUBJECT: Sea Level Specifications
YEAR MODEL MODEL NUMBER SERIAL NUMBER
2000 All Summit* Series All Summit* Series All Summit* Series
FOR APPROVAL ONLY
Summit 700
Summit 600

Page 2 of 3 2000-2
SUMMIT 600
DRIVE PULLEY
DRIVEN PULLEY
Additional Information: Use a 23 teeth sprocket (P/N
504 085 400) at sea level to obtain a chain case ratio of
23/43.
CAUTION: These adjustments are guidelines
only. Specific adjustments vary with temperature,
altitude and snow conditions. Always observe spark
plug condition for proper jetting.
CARBURATION
MAIN JET CHART
NOTE: Arrows in the charts indicate that the preced-
ing information is repeated.
NOTE: Shaded columns give factory settings.
Sea
Level
600 m
2000 ft
1200 m
4000 ft
1800 m
6000 ft
2400 m
8000 ft
3000 m
10000 ft
Spring çççç
Green/Blue
414 768 200 ç
Ramp çççç
417 005 294 ç
Calibration
screw position 453456
Pin çQty 3 x 1
417 004 308 çç
Qty 3 x 1
417 004 309 ç
Engagement
RPM ± 100 ç4000 çç 4200 ç
Maximum
RPM ± 100 çççç
8000 ç
Sea
Level
600 m
2000 ft
1200 m
4000 ft
1800 m
6000 ft
2000 m
8000 ft
3000 m
10000 ft
Spring çççç Beige
414 558 900 ç
Spring
tension
Kg ± 0.7
lb ± 1.5 çççç 7.0
15.4 ç
Cam
angle ° (degrees) çççç 47°
417 126 337 ç
Clutching
Altitude
Clutching
Altitude
Sea
Level
600 m
2000 ft
1200 m
4000 ft
1800 m
6000 ft
2400 m
8000 ft
3000 m
10000 ft
Main jet çççç 280 ç
Jet needle çççç 7DFY1 ç
Needle position çççç 3ç
Slide cut-away çççç 2.5 ç
Pilot jet çççç 37.5 ç
Air screw çççç 1.0 ç
Valve seat çççç 1.5 (V) ç
Needle jet çççç
Z-9 (224) ç
Float level mm çççç 22.9 ç
Idle RPM
± 200 çççç 1600 ç
Idle throttle
valve position mm çççç 1.7 ç
Sea
Level
600 m
2000 ft
1200 m
4000 ft
1800 m
6000 ft
2400 m
8000 ft
3000 m
10000 ft
Qty
- 40°C
- 40°Fçççç
300 çPTO
MAG
- 30°C
- 20°Fçççç
290 çPTO
MAG
- 20°C
- 4°Fçççç
280 çPTO
MAG
- 10°C
14°Fçççç
280 çPTO
MAG
0°C
32°Fçççç
280 çPTO
MAG
10°C
50°Fçççç
280 çPTO
MAG
20°C
70°Fçççç
280 çPTO
MAG
Calibration
Altitude
Tempera tu re
Altitude

2000-2 Page 3 of 3
SUMMIT 700/700 H.M.
DRIVE PULLEY
DRIVEN PULLEY
CAUTION: These adjustments are guidelines only.
Specific adjustments vary with temperature, alti-
tude and snow conditions. Always observe spark
plug condition for proper jetting.
CARBURATION
MAIN JET CHART
NOTE: Arrows in the charts indicate that the preced-
ing information is repeated.
NOTE: Shaded columns give factory settings.
Sea
Level
600 m
2000 ft
1200 m
4000 ft
1800 m
6000 ft
2400 m
8000 ft
3000 m
10000 ft
Spring çççç
Violet/Yellow
415 015 300 ç
Ramp çççç
417 005 293X ç
Calibration
screw position 3423 45
Pin çQty 3 x 1
417 004 308 ççQty 3 x 1
417 004 309 ç
Engagement
RPM ± 100 çççç
3800 ç
Maximum
RPM ± 100 çççç
8000 ç
Sea
Level
600 m
2000 ft
1200 m
4000 ft
1800 m
6000 ft
2000 m
8000 ft
3000 m
10000 ft
Spring çççç Beige
414 558 900 ç
Spring
tension
Kg ± 0.7
lb ± 1.5 çççç 7.0
15.4 ç
Cam
angle ° (degrees) çççç 50°/47°
417 126 339 ç
Clutching
Altitude
Clutching
Altitude
Sea
Level
600 m
2000 ft
1200 m
4000 ft
1800 m
6000 ft
2400 m
8000 ft
3000 m
10000 ft
Main jet çççç 280 ç
Jet needle çççç 7DHY6 ç
Needle position çççç 3ç
Slide cut-away çççç 2.5 ç
Pilot jet çççç 45 ç
Air screw çççç 1.0 ç
Valve seat çççç 1.5 ç
Needle jet çççç
Z-7 (224) ç
Float level mm çççç 22.9 ç
Idle RPM
± 200 çççç 1600 ç
Idle throttle
valve position mm 1.5 1.6 1.7 1.8 1.9 2.2
Sea
Level
600 m
2000 ft
1200 m
4000 ft
1800 m
6000 ft
2400 m
8000 ft
3000 m
10000 ft
Qty
- 40°C
- 40°Fçççç
300 çPTO
MAG
- 30°C
- 20°Fçççç
290 çPTO
MAG
- 20°C
- 4°Fçççç
280 çPTO
MAG
- 10°C
14°Fçççç
280 çPTO
MAG
0°C
32°Fçççç
280 çPTO
MAG
10°C
50°Fçççç
280 çPTO
MAG
20°C
70°Fçççç
280 çPTO
MAG
Calibration
Altitude
Altitude
Temperature

Printed in Canada (mbs2000-003a.fmMD)
®*Trademarks of Bombardier Inc. and/or its subsidiaries.
©1999 Bombardier Inc. All rights reserved.
2000-4 Page 1 of 11
This bulletin is divided into 2 main sections.
Section 1: Spring Applications
It is a quick reference chart which provides autho-
rized spring application for each Ski-Doo model. It
contains the standard spring part number (in gray
shading) as installed at the factory, as well as 1 softer
spring and 1 harder spring recommendation.
Section 2: Spring Specifications
Refers to spring specifications.
The informations in this bulletin supersede all in-
formations previously published.
Please update your
Shop Manual by indicating the
number of this bulletin in the proper section of the
manual.
COIL SPRINGS
(compression)
NOTE: Read color when spring is upright and
stripes are down.
Type R
(straight on both ends)
(Single Rate Spring)
1. Color code stripes
2. Wire diameter
3. Free length
Type S
(barrel shape on one end)
(Single Rate Spring)
1. Color code stripes
2. Wire diameter
3. Free length
Type T
(barrel shape on both ends)
(Single Rate Spring)
1. Color code stripes
2. Wire diameter
3. Free length
No. 2000-4
Date: September 24, 1999 SUBJECT: Spring Chart
YEAR MODEL NAME MODEL NUMBER SERIAL NUMBER
2000 All (except utility models) All All
A00F0PA
1
2
23
1
3
A00F19A
2
A06F02A
1
2
33
FOR APPROVAL ONLYFOR

Page 2 of 11 2000-4
Type U
(barrel shape on one end with
positioning tab at the other end)
(Single Rate Spring)
1. Color code stripes
2. Wire diameter
3. Free length
4. Positioning tab
Type 2
(barrel shape on both ends)
(Dual Rate Spring)
1. Color code stripes
2. Wire diameter
3. Free length
Type 4
(barrel shape on both ends with
positioning tab at the color code coils end)
(Dual Rate Spring)
1. Color code stripes
2. Wire diameter
3. Free length
4. Positioning tab
TORSION SPRINGS
1. Color code stripes
2. Wire diameter
3. Opening angle (°)
4. Left hand (LH)
5. Right hand (RH)
1
3
A00F12A
24
3
A00F20A
2 1
3
A00F21A
1
4
2
A00F0SA
2
3
4
5
1

2000-4 Page 3 of 11
SECTION 1
SPRING APPLICATIONS
.
2000 FRONT SPRINGS 2000
MODEL (P/N) SOFTER SPRING (P/N) STANDARD (P/N) HARDER SPRING
MACH Z 414 956 300 415 075 900 415 039 700
MACH Z MILLENNIUM 414 956 300 505 070 473 415 039 700
MACH 1 414 956 300 414 976 100 415 039 700
FORMULA III 800 Not Applicable 505 070 153 505 070 298
FORMULA III 700 Not Applicable 505 070 153 505 070 298
FORMULA Z 700 Not Applicable 505 070 393 Not Applicable
FORMULA Z 600 Not Applicable 505 070 393 Not Applicable
FORMULA DE LUXE 700 Not Applicable 505 070 392 Not Applicable
FORMULA DE LUXE 600 Not Applicable 505 070 392 Not Applicable
FORMULA DE LUXE 500 414 956 300 415 035 900 415 039 700
FORMULA 500 LC 414 956 300 415 075 900 415 039 700
FORMULA DE LUXE 380 414 956 300 415 035 900 415 039 700
FORMULA DE LUXE 503 414 956 300 415 035 900 415 039 700
FORMULA S 414 956 300 415 075 900 415 039 700
MX Z 700 Not Applicable 505 070 181 Not Applicable
MX Z 700 MILLENNIUM Not Applicable 505 070 474 Not Applicable
MX Z 600 Not Applicable 505 070 181 Not Applicable
MX Z 500 Not Applicable 505 070 393 Not Applicable
MX Z 440 F 414 956 300 415 035 900 415 039 700
SUMMIT 700 Not Applicable 505 070 020 505 070 305
SUMMIT 700
MILLENNIUM Not Applicable 505 070 475 505 070 305
SUMMIT 700 HM Not Applicable 505 070 020 505 070 305
SUMMIT 600 Not Applicable 505 070 020 505 070 305
GRAND TOURING SE Not Applicable 505 070 092 505 070 298
GRAND TOURING SE
MILLENNIUM Not Applicable 505 070 391 505 070 298
GRAND TOURING 700 Not Applicable 505 070 391 505 070 298
GRAND TOURING 600 Not Applicable 505 070 392 Not Applicable
TOURING 500 414 956 300 415 035 900 415 039 700
TOURING SLE 414 956 300 415 035 900 415 039 700
TOURING LE 414 956 300 415 035 900 415 039 700
TOURING E 414 956 300 415 035 900 415 039 700
SKANDIC 500 414 859 300 414 955 800 414 968 600
SKANDIC 380 414 859 300 414 955 800 414 968 600
TUNDRA R Not Applicable 505 070 130 Not Applicable

Page 4 of 11 2000-4
2000 CENTER SPRINGS 2000
MODEL (P/N) SOFTER SPRING (P/N) STANDARD (P/N) HARDER SPRING
MACH Z 415 070 400 415 090 500
415 090 600 415 103 600
MACH Z MILLENNIUM 415 070 400 415 090 500
415 090 600 415 103 600
MACH 1 415 070 400 415 090 500
415 090 600 415 103 600
FORMULA III 800 415 070 400 415 103 600 415 057 500
FORMULA III 700 415 070 400 415 103 600 415 057 500
FORMULA Z 700 415 070 500 503 189 325 Not Applicable
FORMULA Z 600 415 070 500 503 189 325 Not Applicable
FORMULA DE LUXE 700 415 070 500 503 189 325 Not Applicable
FORMULA DE LUXE 600 415 070 500 503 189 325 Not Applicable
FORMULA 500 LC 414 974 400 415 070 400 415 103 600
FORMULA DE LUXE 500 414 974 400 415 070 400 415 103 600
FORMULA DE LUXE 380 414 974 400 415 069 900 414 771 300
FORMULA S 414 974 400 415 069 900 414 771 300
FORMULA DE LUXE 503 414 974 400 415 069 900 414 771 300
MX Z 700 415 070 500 503 189 325 Not Applicable
MX Z 600 415 070 500 503 189 325 Not Applicable
MX Z 500 415 070 500 503 189 325 Not Applicable
MX Z 440 F 414 859 300 415 070 100 415 070 500
SUMMIT 700 414 859 300 415 070 100 415 070 500
SUMMIT 700 HM 414 859 300 415 070 100 415 070 500
SUMMIT 600 414 859 300 415 070 100 415 070 500
GRAND TOURING SE 415 057 500 415 057 600 415 070 700
GRAND TOURING 700 415 057 500 415 057 600 415 070 700
GRAND TOURING 600 415 035 900 415 057 500 415 057 600
TOURING 500 415 035 900 415 070 600 415 057 600
TOURING SLE 415 070 400 415 103 600 415 057 500
TOURING LE 414 974 400 415 069 900 414 771 300
TOURING E 414 974 400 415 069 900 414 771 300
SKANDIC 500 414 974 400 503 189 000 414 771 300
SKANDIC 380 414 974 400 503 189 000 414 771 300
TUNDRA R Not Applicable Not Applicable Not Applicable

2000-4 Page 5 of 11
2000 REAR SPRINGS 2000
MODEL (P/N) SOFTER SPRING (P/N) STANDARD (P/N) HARDER SPRING
MACH Z 503 189 335 LH
503 189 334 RH
503 188 200 LH
503 188 100 RH
503 189 339 LH
503 189 338 RH
MACH Z MILLENNIUM 503 189 335 LH
503 189 334 RH
503 188 200 LH
503 188 100 RH
503 189 339 LH
503 189 338 RH
MACH 1 503 189 335 LH
503 189 334 RH
503 188 200 LH
503 188 100 RH
503 189 339 LH
503 189 338 RH
FORMULA III 800 503 189 343 LH
503 189 342 RH
503 189 339 LH
503 189 338 RH
503 189 359 LH
503 189 358 RH
FORMULA III 700 503 189 343 LH
503 189 342 RH
503 189 339 LH
503 189 338 RH
503 189 359 LH
503 189 358 RH
FORMULA Z 700 503 189 343 LH
503 189 342 RH
503 189 445 LH
503 189 443 RH
503 189 339 LH
503 189 338 RH
FORMULA Z 600 503 189 343 LH
503 189 342 RH
503 189 445 LH
503 189 443 RH
503 189 339 LH
503 189 338 RH
FORMULA DE LUXE 700 503 189 343 LH
503 189 342 RH
503 189 445 LH
503 189 443 RH
503 189 339 LH
503 189 338 RH
FORMULA DE LUXE 600 503 189 343 LH
503 189 342 RH
503 189 445 LH
503 189 443 RH
503 189 339 LH
503 189 338 RH
FORMULA DE LUXE 500 503 189 355 LH
503 189 354 RH
503 189 343 LH
503 189 342 RH
503 189 445 LH
503 189 443 RH
FORMULA 500 LC 503 189 355 LH
503 189 354 RH
503 189 343 LH
503 189 342 RH
503 189 445 LH
503 189 443 RH
FORMULA DE LUXE 503 Not Applicable 503 189 347 LH
503 189 346 RH
503 189 355 LH
503 189 354 RH
FORMULA DE LUXE 380 Not Applicable 503 189 347 LH
503 189 346 RH
503 189 355 LH
503 189 354 RH
FORMULA S Not Applicable 503 189 347 LH
503 189 346 RH
503 189 355 LH
503 189 354 RH
MX Z 700 503 189 343 LH
503 189 342 RH
503 189 445 LH
503 189 443 RH
503 189 339 LH
503 189 338 RH
MX Z 600 503 189 343 LH
503 189 342 RH
503 189 445 LH
503 189 443 RH
503 189 339 LH
503 189 338 RH
MX Z 500 503 189 343 LH
503 189 342 RH
503 189 445 LH
503 189 443 RH
503 189 339 LH
503 189 338 RH
MX Z 440 LC To be determined To be determined To be determined
MX Z 440 F 503 189 347 LH
503 189 346 RH
503 189 355 LH
503 189 354 RH
503 189 343 LH
503 189 342 RH
SUMMIT 700 503 189 347 LH
503 189 346 RH
503 189 355 LH
503 189 354 RH
503 189 343 LH
503 189 342 RH
LH = Left Hand RH = Right Hand

Page 6 of 11 2000-4
SUMMIT 600 503 189 347 LH
503 189 346 RH
503 189 355 LH
503 189 354 RH
503 189 343 LH
503 189 342 RH
SUMMIT 700 HM 503 189 347 LH
503 189 346 RH
503 189 355 LH
503 189 354 RH
503 189 343 LH
503 189 342 RH
GRAND TOURING SE 503 189 355 LH
503 189 354 RH
503 189 343 LH
503 189 342 RH
503 189 445 LH
503 189 443 RH
GRAND TOURING 700 503 189 339 LH
503 189 338 RH
503 189 359 LH
503 189 358 RH
503 189 329 LH
503 189 327 RH
GRAND TOURING 600 503 189 343 LH
503 189 342 RH
503 189 339 LH
503 189 338 RH
503 189 359 LH
503 189 358 RH
TOURING 500 503 189 343 LH
503 189 342 RH
503 189 339 LH
503 189 338 RH
503 189 359 LH
503 189 358 RH
TOURING SLE 503 189 343 LH
503 189 342 RH
503 189 339 LH
503 189 338 RH
503 189 359 LH
503 189 358 RH
TOURING LE 503 189 343 LH
503 189 342 RH
503 189 339 LH
503 189 338 RH
503 189 359 LH
503 189 358 RH
TOURING E 503 189 343 LH
503 189 342 RH
503 189 339 LH
503 189 338 RH
503 189 359 LH
503 189 358 RH
SKANDIC 500 503 189 343 LH
503 189 342 RH
503 189 339 LH
503 189 338 RH
503 189 359 LH
503 189 358 RH
SKANDIC 380 503 189 343 LH
503 189 342 RH
503 189 339 LH
503 189 338 RH
503 189 359 LH
503 189 358 RH
TUNDRA R Not Applicable 414 880 200 LH
414 880 300 RH
503 189 252 LH
503 189 251 RH
2000 REAR SPRINGS 2000
MODEL (P/N) SOFTER SPRING (P/N) STANDARD (P/N) HARDER SPRING
LH = Left Hand RH = Right Hand

2000-4 Page 7 of 11
SECTION 2
SPRING SPECIFICATIONS
Coil Springs Specifications
P/N TYPE
SPRING
RATE
(lbs/in) ± 10
FREE
LENGTH
(mm) ± 3
WIRE
DIAMETER
(mm) ± .05
COLOR
CODE
STRIPES
COLOR OF
SPRING
291 000 794 R 100 215 6.65 PI/WH BLACK
414 771 300 R135 272.5 8.41 BK/BK SAFARI RED
414 782 300 R225 165 8.41 BK SAFARI RED
414 788 200 R150 272.5 8.41 BK/YL SAFARI RED
414 789 400 R135 272.5 8.41 BK/BK AQUA BLUE
414 797 700 R135 272.5 8.41 BK/BK FLAME RED
414 797 800 R135 272.5 8.41 BK/BK PEARL BLUE
414 797 900 R135 272.5 8.41 BK/BK VIOLET
414 803 000 R65 408 6.17 BL/OR BLACK
414 808 800 R 120 272.5 7.77 BK/OR SAFARI RED
414 809 300 R 160 213.1 7.77 WH BLACK
414 809 500 R 150 ± 5 256.8 7.92 BK YELLOW
414 810 100 R 125 ± 5 256.8 7.49 WH YELLOW
414 859 300 R 90 ± 7 239 7.14 BK/WH YELLOW
414 861 600 R 135 272.5 8.41 BK/BK YELLOW
414 869 000 R 125 ± 5 256.8 7.49 WH SAFARI RED
414 871 600 R 150 ± 5 256.8 7.92 WH VIOLET
414 877 800 R 160 ± 7 223.1 7.92 WH/WH BLACK
414 891 000 R 100 ± 7 260 7.14 WH/BK SAFARI RED
414 893 800 R 185 ± 7 213 8.41 GN/GN YELLOW
414 895 100 R 100 255 7.14 PI/GD BLACK
414 916 800 R 90 ± 7 239 7.14 RD FIREFLY GREEN
414 928 100 R 110 256.8 7.77 GD/BK SAFARI RED
414 928 600 R 100 ± 7 260 7.14 GD RASPBERRY
414 929 300 R 110 256.8 7.77 BK/RD PEARL BLUE
414 929 500 R 100 ± 7 260 7.14 RD/YL PEARL BLUE
414 940 200 R 140 ± 7 223 7.77 WH/GN BLACK
414 955 800 R 100 239 7.14 RD/GN/GN BLACK
414 955 900 R 125 ± 5 256.8 7.49 BK/RD NEON GREEN
414 956 000 R 125 ± 5 256.8 7.49 BL/RD BLACK
414 956 100 R 125 ± 5 256.8 7.49 BL/BL/BL VIPER RED
414 956 200 R 115 242 7.77 PI/BL BLACK
414 956 300 R 100 265 7.14 PI/WH/BL YELLOW
414 956 400 R 100 ± 7 260 7.14 RD/YL/BL ROYAL VIOLET
SPRING COLOR CODES
BK = BLACK BL = BLUE GD = GOLD GN = GREEN OR = ORANGE PI = PINK RD = RED
SI = SILVER WH = WHITE YL = YELLOW

Page 8 of 11 2000-4
414 956 500 R 100 ± 7 260 7.14 BL/YL/GN VIPER RED
414 956 800 R 100 ± 7 260 7.14 RD/YL NEON GREEN
414 968 600 R 125 235 7.49 RD NEON GREEN
414 974 400 R 90 265 7.14 GN/OR BLACK
414 974 500 R 115 265 7.49 OR/WH BLACK
414 976 000 R 135 242 8.25 PI/GN BLACK
414 976 100 R 125 262 7.92 PI/YL VIPER RED
415 012 900 R 115 260 7.92 PI/YL BLACK
415 016 700 R 200 230 8.71 PI/OR/YL BLACK
415 013 800 R 150 264 7.77 BK/PI/WH NEON GREEN
415 013 900 R 150 264 7.77 PI/WH/YL ROYAL VIOLET
415 014 200 R 150 264 7.77 GN/OR/BL PEARL BLUE
415 014 500 R 150 264 7.77 BK/WH/OR VIPER RED
415 020 600 R 125 203.2 7.77 4 Green lines BLACK
415 020 700 R 150 203.2 7.92 4 Red lines BLACK
415 020 800 R 70 152 5.73 4 Blue lines BLACK
415 020 900 R 150 190.5 8.29 4 Pink lines BLACK
415 035 500 R 125 262 7.92 SI/GN YELLOW
415 035 600 R 125 235 7.49 OR FRENCH BLUE
415 035 700 R 125 262 7.92 SI/OR JAY BLUE
415 035 800 R 125 262 7.92 SI/PI FIR GREEN
415 035 900 R 125 262 7.92 YL BLACK
415 038 500 R 100 265 7.14 SI/GD VIPER RED
415 039 600 R 150 235 8.41 GN BLACK
415 039 700 R 150 258 8.71 PI BLACK
415 039 800 R 140 257 8.71 SI BLACK
415 039 900 R 150 238 8.71 SI/WH BLACK
415 040 000 R 130 250 8.25 SI/SI BLACK
415 040 100 R 215 218 9.19 OR/PI BLACK
415 057 500 R 160 264 8.71 RD/GD BLACK
415 058 200 R 115 270 7.92 GN/GD BLACK
415 069 600 R 300 170 9.50 YL/BK/YL BLACK
415 075 800 R 125 262 7.92 PI/RD/BK FRENCH BLUE
415 075 900 R 125 262 7.92 BL/RD/BK YELLOW
415 076 000 R 100 265 7.14 RD/RD/BK YELLOW
415 083 700 R 125 235 7.49 OR/RD/BK YELLOW
415 090 300 R 376 76 8.25 GD/RD/YL BLACK
415 090 500 R 293 45 6.17 YL/BL/YL BLACK
415 095 200 R 75 408 6.17 BL/BL/YL BLACK
SPRING COLOR CODES
BK = BLACK BL = BLUE GD = GOLD GN = GREEN OR = ORANGE PI = PINK RD = RED
SI = SILVER WH = WHITE YL = YELLOW
P/N TYPE
SPRING
RATE
(lbs/in) ± 10
FREE
LENGTH
(mm) ± 3
WIRE
DIAMETER
(mm) ± .05
COLOR
CODE
STRIPES
COLOR OF
SPRING

2000-4 Page 9 of 11
503 100 700 R 65 290 6.35 BL/YL BLACK
505 070 089 R 125 262 7.92 GN/BK/BK GOLDEN
WHEAT
505 070 130 R 75 408 6.17 YL/PI/YL BLACK
505 070 473 R 125 262 7.92 BK/YL/RD SILVER
REFLECTION
415 090 400 S 359 215 10.60 WH/RD/YL BLACK
415 090 600 S 220 210 9.19 RD/BL/YL BLACK
415 110 400 S 400 215 11.10 YL/OR/YL BLACK
414 809 100 T 125 ± 5 274 7.92 GD YELLOW
414 815 500 T 135 259 7.77 BK/WH VIOLET
414 852 800 T 100 ± 7 279 7.92 RD YELLOW
414 871 300 T 125 ± 5 274 7.92 GD SAFARI RED
414 871 500 T 125 ± 5 274 7.92 GD VIOLET
414 894 100 T 112 ± 7 279.4 8.41 BK/GN YELLOW
414 916 900 T 100 ± 7 279 7.92 BK/WH FIREFLY GREEN
414 925 400 T 100 ± 7 279 7.92 WH/BK SAFARI RED
414 926 000 T 100 ± 7 279 7.49 BK RASPBERRY
414 926 900 T 110 279.4 7.77 GN/YL SAFARI RED
414 927 100 T 110 279.4 7.77 BK/YL PEARL BLUE
414 927 500 T 100 ± 7 279 7.92 RD/WH PEARL BLUE
414 988 600 T 100 ± 7 279 7.49 PI/PI BLACK
414 998 600 T 100 ± 7 279 7.49 BK/PI SAFARI RED
415 006 900 T 150 ± 7 272.5 8.41 BK/YL FIREFLY GREEN
415 007 000 T 135 ± 7 272.5 8.41 BK/BK FIREFLY GREEN
415 014 300 T 150 264 7.77 GN/OR/PI CAN-AM RED
415 057 500 T 160 264 8.71 RD/GD BLACK
415 057 600 T 180 260 9.52 BL/GD BLACK
415 069 900 T 115 265 7.49 SI/YL/YL BLACK
415 070 000 T 135 242 8.25 WH/YL/YL BLACK
415 070 100 T 115 242 7.92 GD/YL/YL BLACK
415 070 200 T 115 270 7.92 PI/YL/YL BLACK
415 070 300 T 100 264 7.49 OR/YL/YL BLACK
415 070 400 T 115 270 8.25 GN/YL/YL BLACK
415 070 500 T 135 242 8.41 BL/YL/YL BLACK
415 070 600 T 160 264 9.19 RD/YL/YL BLACK
415 070 700 T 200 263 9.52 YL/YL/YL BLACK
415 071 000 T 150 242 8.71 SI/RD/YL BLACK
415 079 300 T 85 290 7.77 RD/BL/BK YELLOW
415 079 400 T 85 315 8.25 RD/GN/BK YELLOW
SPRING COLOR CODES
BK = BLACK BL = BLUE GD = GOLD GN = GREEN OR = ORANGE PI = PINK RD = RED
SI = SILVER WH = WHITE YL = YELLOW
P/N TYPE
SPRING
RATE
(lbs/in) ± 10
FREE
LENGTH
(mm) ± 3
WIRE
DIAMETER
(mm) ± .05
COLOR
CODE
STRIPES
COLOR OF
SPRING

Page 10 of 11 2000-4
415 079 500 T 85 290 7.77 GN/RD/YL VIPER RED
415 079 600 T 85 315 8.25 OR/RD/YL FRENCH BLUE
415 079 700 T 85 315 8.25 PI/YL/RD PLATINUM
415 103 600 T 135 264 8.25 GN/GN/YL BLACK
503 127 200 T 170 258 8.71 BL/GN BLACK
503 135 400 T 250 300 10.31 RD/OR BLACK
503 189 000 T 115 265 7.92 YL/GD/YL BLACK
503 189 325 T 150 242 8.25 YL/SI/YL BLACK
505 070 020 T 90 250 7.77 BK/OR/BK YELLOW
505 070 093 T 85 290 7.77 BK/GN/BK GRAND
CANYON RED
505 070 144 T 100 290 8.25 RD/BK/RD YELLOW
505 070 146 T 100 315 8.71 RD/RD/RD YELLOW
505 070 240 T 90 265 7.49 RD/PI/BK YELLOW
505 070 305 T 105 250 8.25 RD/OR/BK YELLOW
505 070 475 T 90 250 7.77 BK/YL/GN SILVER
REFLECTION
415 108 100 U 125 260 8.25 BK/RD/BK YELLOW
505 070 233 U 125 262 7.92 PI/BL/BK YELLOW
505 070 300 U 150 258 8.71 GN/PI/BK YELLOW
505 070 302 U 100 265 7.14 OR/PI/BK YELLOW
505 070 091 2 65 - 95 340 8.25 BK/BL/BK GOLDEN
WHEAT
505 070 092 2 65 - 95 340 8.25 BK/YL/BK GRAND
CANYON RED
505 070 153 2 65 - 95 340 8.25 GN/GN/BK YELLOW
505 070 298 2 70 - 100 340 8.25 BL/PI/BK YELLOW
505 070 391 2 65 - 95 340 8.25 YL/BK/BK SILVER
REFLECTION
505 070 392 2 55 - 85 320 7.77 RD/GD/YL BLACK
505 070 393 2 55 - 85 320 7.77 RD/BL/RD YELLOW
505 070 181 4 55 - 85 320 7.77 PI/BK/BK YELLOW
505 070 474 4 55 - 85 320 7.77 BK/YL/BL SILVER
REFLECTION
SPRING COLOR CODES
BK = BLACK BL = BLUE GD = GOLD GN = GREEN OR = ORANGE PI = PINK RD = RED
SI = SILVER WH = WHITE YL = YELLOW
P/N TYPE
SPRING
RATE
(lbs/in) ± 10
FREE
LENGTH
(mm) ± 3
WIRE
DIAMETER
(mm) ± .05
COLOR
CODE
STRIPES
COLOR OF
SPRING

2000-4 Page 11 of 11
Torsion Springs Specification
P/N
WIRE
DIAMETER
(mm)
OPENING
ANGLE
±7°
COLOR
CODE
COLOR
OF SPRING
414 866 300 LH
414 866 200 RH 10.3 85° YL BLACK
414 880 200 LH
414 880 300 RH 9.5 100° Not Applicable BLACK
414 880 500 LH
414 880 400 RH 10.3 12° Not Applicable BLACK
414 943 600 LH
414 943 500 RH 10.6 90° WH BLACK
414 944 300 LH
414 944 200 RH 11.11 90° GN BLACK
415 010 600 LH
415 010 500 RH 10.6 80° RD BLACK
415 060 800 LH
415 060 700 RH 11.11 80° BL BLACK
415 069 400 LH
415 069 300 RH 11.11 100° OR BLACK
486 071 200 LH
486 071 100 RH 10.3 135° YL/YL BLACK
486 071 400 LH
486 071 300 RH 10.3 150° WH/WH BLACK
503 188 200 LH
503 188 100 RH 11.11 100° BL/YL BLACK
503 189 083 LH
503 189 080 RH 11.5 100° GD BLACK
503 189 242 LH
503 189 241 RH 11.11 105° OR/YL BLACK
503 189 252 LH
503 189 251 RH 10.3 95° RD/RD BLACK
503 189 329 LH
503 189 327 RH 11.89 100° SI BLACK
503 189 335 LH
503 189 334 RH 11.11 105° YL/GD BLACK
503 189 339 LH
503 189 338 RH 11.11 90° GN/GN BLACK
503 189 343 LH
503 189 342 RH 10.6 80° RD/RD/RD BLACK
503 189 347 LH
503 189 346 RH 10.3 85° YL/YL/YL BLACK
503 189 355 LH
503 189 354 RH 10.6 90° WH/WH/WH BLACK
503 189 359 LH
503 189 358 RH 11.11 80° BL/BL BLACK
503 189 445 LH
503 189 443 RH 11.11 95° GN/GN/GN BLACK
LH = Left Hand RH = Right Hand
SPRING COLOR CODES
BK = BLACK BL = BLUE GD = GOLD GN = GREEN OR = ORANGE PI = PINK RD = RED
SI = SILVER WH = WHITE YL = YELLOW

Printed in Canada (mbs2000-004a.fm MD)
®*Trademarks of Bombardier Inc. and/or its subsidiaries.
©1999 Bombardier Inc. All rights reserved.
2000-3 Page 1 of 21
The following tables are intended to annex suspension decal on snowmobiles. These tables describe
additional settings for optimum comfort according to load.
NOTE: The A.C.M. (Accelerator and Control Modulator) nut must be fully tightened when performing
suspension adjustments (see
Operator‘s Guide ). Following table gives a quick access to proper page 
No. 2000-3
Date: September 24, 1999 SUBJECT: Spring Reference According to
Load
YEAR MODEL MODEL NUMBER SERIAL NUMBER
2000 All
(except utility models) All All
MODEL NAME PAGE MODEL NAME PAGE
Formula 500 LC (Can/U.S.) 10 Mach Z 12
Formula 500 LC (Europe) 11 MX Z 440 F 7
Formula III 700 19 MX Z 500 (Can/U.S.) 15
Formula III 800 19 MX Z 500 (Europe) 16
Formula Deluxe 380 4 MX Z 600 (Can/U.S.) 15
Formula Deluxe 500 4 MX Z 600 (Europe) 16
Formula Deluxe 500 LC 10 MX Z 700 (Can/U.S.) 15
Formula Deluxe 600 15 MX Z 700 (Europe) 16
Formula Deluxe 700 (Can/U.S.) 15 Skandic 380 3
Formula Deluxe 700 (Europe) 17 Skandic 500 3
Formula S (Can/U.S.) 4 Summit 600 8
Formula S (Europe) 5 Summit 700 8
Formula Z 600 15 Summit 700 HM 8
Formula Z 700 15 Touring 500 LC (Can/U.S.) 13
Grand Touring 600 (Can/U.S.) 20 Touring 500 LC (Europe) 14
Grand Touring 600 (Europe) 21 Touring E 2
Grand Touring 700 18 Touring LE 2
Grand Touring SE 9 Touring SLE 6
Mach 1 12
FOR APPROVAL ONLYFOR

Page 2 of 21 2000-3
TOURING LE, TOURING E
REAR SPRING CENTER SPRING
RIGHT
P/N
LEFT
P/N
CAM
POSITION
COLOR
CODE
P/N
CAM
POSITION
COLOR
CODE
COLOR
STANDARD
Up to 200 lb 503 189 338 503 189 339 1 GN/GN 415 069 900 N.A. SI/YL/YL BLACK
200 lb to 280 lb 503 189 338 503 189 339 2 GN/GN 415 069 900 N.A. SI/YL/YL BLACK
280 lb to 320 lb 503 189 338 503 189 339 3 GN/GN 415 069 900 N.A. SI/YL/YL BLACK
320 lb to 350 lb 503 189 338 503 189 339 4 GN/GN 415 069 900 N.A. SI/YL/YL BLACK
OPTION 1
Up to 250 lb 503 189 358 503 189 359 1 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
250 lb to 330 lb 503 189 358 503 189 359 2 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
330 lb to 370 lb 503 189 358 503 189 359 3 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
370 lb to 400 lb 503 189 358 503 189 359 4 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
SPRING COLOR CODES
BK = BLACK BL = BLUE GD = GOLD GN = GREEN OR = ORANGE PI = PINK RD = RED SI = SILVER
WH=WHITE YL=YELLOW

2000-3 Page 3 of 21
SKANDIC 380, SKANDIC 500
REAR SPRING CENTER SPRING
RIGHT
P/N
LEFT
P/N
CAM
POSITION
COLOR
CODE
P/N
CAM
POSITION
COLOR
CODE
COLOR
STANDARD
Up to 200 lb 503 189 338 503 189 339 1 GN/GN 503 189 000 N.A. YL/GD/YL BLACK
200 lb to 280 lb 503 189 338 503 189 339 2 GN/GN 503 189 000 N.A. YL/GD/YL BLACK
280 lb to 320 lb 503 189 338 503 189 339 3 GN/GN 503 189 000 N.A. YL/GD/YL BLACK
320 lb to 350 lb 503 189 338 503 189 339 4 GN/GN 503 189 000 N.A. YL/GD/YL BLACK
OPTION 1
Up to 250 lb 503 189 358 503 189 359 1 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
250 lb to 330 lb 503 189 358 503 189 359 2 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
330 lb to 370 lb 503 189 358 503 189 359 3 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
370 lb to 400 lb 503 189 358 503 189 359 4 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
SPRING COLOR CODES
BK = BLACK BL = BLUE GD = GOLD GN = GREEN OR = ORANGE PI = PINK RD = RED SI = SILVER
WH = WHITE YL = YELLOW

Page 4 of 21 2000-3
FORMULA S (CAN/U.S.), FORMULA DLX 500/380
REAR SPRING CENTER SPRING
RIGHT
P/N
LEFT
P/N
CAM
POSITION
COLOR
CODE
P/N
CAM
POSITION
COLOR
CODE
COLOR
STANDARD
Up to 125 lb 503 189 346 503 189 347 1 YL/YL/YL 415 069 900 N.A. SI/YL/YL BLACK
125 lb to 150 lb 503 189 346 503 189 347 2 YL/YL/YL 415 069 900 N.A. SI/YL/YL BLACK
150 lb to 175 lb 503 189 346 503 189 347 3 YL/YL/YL 415 069 900 N.A. SI/YL/YL BLACK
175 lb to 200 lb 503 189 346 503 189 347 4 YL/YL/YL 415 069 900 N.A. SI/YL/YL BLACK
OPTION 1
Up to 175 lb 503 189 354 503 189 355 1 WH/WH/WH 414 771 300 N.A. BK/BK SAFARI RED
175 lb to 200 lb 503 189 354 503 189 355 2 WH/WH/WH 414 771 300 N.A. BK/BK SAFARI RED
200 lb to 225 lb 503 189 354 503 189 355 3 WH/WH/WH 414 771 300 N.A. BK/BK SAFARI RED
225 lb to 250 lb 503 189 354 503 189 355 4 WH/WH/WH 414 771 300 N.A. BK/BK SAFARI RED
OPTION 2
Up to 225 lb 503 189 342 503 189 343 1 RD/RD/RD 414 771 300 N.A. BK/BK SAFARI RED
225 lb to 250 lb 503 189 342 503 189 343 2 RD/RD/RD 414 771 300 N.A. BK/BK SAFARI RED
250 lb to 275 lb 503 189 342 503 189 343 3 RD/RD/RD 414 771 300 N.A. BK/BK SAFARI RED
275 lb to 300 lb 503 189 342 503 189 343 4 RD/RD/RD 414 771 300 N.A. BK/BK SAFARI RED
OPTION 3
Up to 275 lb 503 189 338 503 189 339 1 GN/GN 414 771 300 N.A. BK/BK SAFARI RED
275 lb to 300 lb 503 189 338 503 189 339 2 GN/GN 414 771 300 N.A. BK/BK SAFARI RED
300 lb to 325 lb 503 189 338 503 189 339 3 GN/GN 414 771 300 N.A. BK/BK SAFARI RED
325 lb to 350 lb 503 189 338 503 189 339 4 GN/GN 414 771 300 N.A. BK/BK SAFARI RED
OPTION 4
Up to 325 lb 503 189 358 503 189 359 1 BL/BL 414 771 300 N.A. BK/BK SAFARI RED
325 lb to 350 lb 503 189 358 503 189 359 2 BL/BL 414 771 300 N.A. BK/BK SAFARI RED
350 lb to 375 lb 503 189 358 503 189 359 3 BL/BL 414 771 300 N.A. BK/BK SAFARI RED
375 lb to 400 lb 503 189 358 503 189 359 4 BL/BL 414 771 300 N.A. BK/BK SAFARI RED
SPRING COLOR CODES
BK = BLACK BL = BLUE GD = GOLD GN = GREEN OR = ORANGE PI = PINK RD = RED SI = SILVER
WH=WHITE YL=YELLOW

2000-3 Page 5 of 21
FORMULA S (EUROPE)
REAR SPRING CENTER SPRING
RIGHT
P/N
LEFT
P/N
CAM
POSITION
COLOR
CODE
P/N
CAM
POSITION
COLOR
CODE
COLOR
STANDARD
Up to 225 lb 503 189 342 503 189 343 1 RD/RD/RD 415 069 900 N.A. SI/YL/YL BLACK
225 lb to 250 lb 503 189 342 503 189 343 2 RD/RD/RD 415 069 900 N.A. SI/YL/YL BLACK
250 lb to 275 lb 503 189 342 503 189 343 3 RD/RD/RD 415 069 900 N.A. SI/YL/YL BLACK
275 lb to 300 lb 503 189 342 503 189 343 4 RD/RD/RD 415 069 900 N.A. SI/YL/YL BLACK
OPTION 1
Up to 275 lb 503 189 338 503 189 339 1 GN/GN 414 771 300 N.A. BK/BK SAFARI
RED
275 lb to 300 lb 503 189 338 503 189 339 2 GN/GN 414 771 300 N.A. BK/BK SAFARI
RED
300 lb to 325 lb 503 189 338 503 189 339 3 GN/GN 414 771 300 N.A. BK/BK SAFARI
RED
325 lb to 350 lb 503 189 338 503 189 339 4 GN/GN 414 771 300 N.A. BK/BK SAFARI
RED
OPTION 2
Up to 325 lb 503 189 358 503 189 359 1 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
325 lb to 350 lb 503 189 358 503 189 359 2 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
350 lb to 375 lb 503 189 358 503 189 359 3 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
375 lb to 400 lb 503 189 358 503 189 359 4 BL/BL 414 771 300 N.A. BK/BK SAFARI
RED
SPRING COLOR CODES
BK = BLACK BL = BLUE GD = GOLD GN = GREEN OR = ORANGE PI = PINK RD = RED SI = SILVER
WH = WHITE YL = YELLOW

Page 6 of 21 2000-3
TOURING SLE
REAR SPRING CENTER SPRING
RIGHT
P/N
LEFT
P/N
CAM
POSITION
COLOR
CODE
P/N
CAM
POSITION
COLOR
CODE
COLOR
STANDARD
Up to 200 lb 503 189 338 503 189 339 1 GN/GN 415 103 600 1 GN/GN/YL BLACK
200 lb to 250 lb 503 189 338 503 189 339 2 GN/GN 415 103 600 1 GN/GN/YL BLACK
250 lb to 300 lb 503 189 338 503 189 339 3 GN/GN 415 103 600 2 GN/GN/YL BLACK
300 lb to 350 lb 503 189 338 503 189 339 4 GN/GN 415 103 600 3 GN/GN/YL BLACK
350 lb to 375 lb 503 189 338 503 189 339 4 GN/GN 415 103 600 4 GN/GN/YL BLACK
375 lb to 400 lb 503 189 338 503 189 339 4 GN/GN 415 103 600 5 GN/GN/YL BLACK
OPTION 1
Up to 250 lb 503 189 358 503 189 359 1 BL/BL 415 071 000 1 SI/RD/YL BLACK
250 lb to 300 lb 503 189 358 503 189 359 2 BL/BL 415 071 000 1 SI/RD/YL BLACK
300 lb to 350 lb 503 189 358 503 189 359 3 BL/BL 415 071 000 2 SI/RD/YL BLACK
350 lb to 400 lb 503 189 358 503 189 359 4 BL/BL 415 071 000 3 SI/RD/YL BLACK
400 lb to 425 lb 503 189 358 503 189 359 4 BL/BL 415 071 000 4 SI/RD/YL BLACK
425 lb to 450 lb 503 189 358 503 189 359 4 BL/BL 415 071 000 5 SI/RD/YL BLACK
SPRING COLOR CODES
BK = BLACK BL = BLUE GD = GOLD GN = GREEN OR = ORANGE PI = PINK RD = RED SI = SILVER
WH=WHITE YL=YELLOW
