Brunetti Mercury Box User manual

OWNER’S MANUAL
Brunetti Marco & C. S.a.s
Via De’ Bonomini, 25/27
41100 MODENA ITALY
Phone: [phone]
Fax: [phone]
e-mail: [email protected] (commercial info)
e-mail: [e-mail] (technical info)
www.brunetti.it
www.brunetti.it/forum
Mercury
Box
Please, fill out the warranty form you find on
www.brunetti.it
to validate your warranty
-There are no controls and/or useful parts inside the box. Please open
it just to replace the battery.
-TO PROTECT THE BATTERY CONNECTOR WHEN NOT IN USE, IT MUST
BE COVERED WITH THE INCLUDED CAP!
-DO NOT OVERVOLT OVER THE NOMINAL 9V DC (CENTER NEGATIVE):
THE PEDAL COULD BE DAMAGED AND THE WARRANTY INVALIDATED!
-Do not throw water jets directly on the appliance
-Do not use water steams to clean the appliance
-Do not use solvents to clean the appliance, especially on the serigraphy
- The appliance conformity is proved by CE symbol on the sticker near the 9VDC
socket
- The manufacturer declines all responsibility for any kind of damage to persons,
things and/or animals resulting from a wrong use of the appliance
- The manufacturer reserves the right to make any useful and essential change to
the products without compromise the main safety and working features
- Do not use the appliance barefoot
- Do not touch the appliance with wet or moist hands or feet
- Do not allow children or incompetents to use the appliance
- Do not leave inflammable materials near the appliance
- Do not pull up the appliance by control knobs
- Read carefully, compile and deliver the warranty attached to the appliance
- The appliance repair may be done during the warranty period only by us, in our
laboratory, or by authorized staff, in conformity to the national previsions in force
- In case of damage please contact the shop where you bought the appliance
GENERAL INFO AND WARNINGS
By reading this manual you will deeply know the device you bought and will
have the chance to fully experience its potential. Our sets are handmade. This
is why you could find some sound and structural differences. This testifies
the handmade making of the product

D
C
H
FG
B
E
A
I
CONTROLSFEATURES
Mercury Box is the new Brunetti
overdrive/distortion stomp box.
A small metallic box holds together the qualities of
the well-known CustomWork Mercury’s channel 2!
It is endowed with “FET” technology to reproduce tubes
behavior and dynamics as accurately as possible.
Mercury Box is extremely versatile, you can move
from clear and defined crunch sounds to hard rock
“liquid” distortion which is always clean and never
shapeless, very smooth and respectful of your
instrument timbre, even at high gain levels.
Controls are soft and sentive, but effective
at the same time. They indeed interact
thoroughly as in a real tube amplifier.
Mercury Box arises from careful design and
long lasting research of Marco Brunetti, and the
outcome is innovative and technologically unique.
It is not the upgraded clone of a well-know stomp box!
These qualities make Mercury Box different, we
are sure you will be impressed at first note!
A - True-bypass switch to turn the effect on and off: when Mercury Box is off,
it does not alter the original signal
B - Output jack to the amp
C - Input jack from the guitar
D - Standard “BOSS” connector for DC 9V (center pin negative).
DO NOT OVERVOLT THE PEDAL! PROTECT THE BATTERY CONNECTOR
WITH THE INCLUDED CAP WHEN NOT IN USE!
E - VOLUME: effect’s otput level control. It is useful to smooth volumes.To
increase the signal level output, turn it clockwise
F - BASS: low frequencies level control. To heighten bass presence, turn it
clockwise
G - EDGE: medium/high frequencies control. To increase medium frequencies
and make distortion clearer and more aggressive, turn it clockwise
H - GAIN: gain control. To increase distortion level, turn it clockwise
I - Led that indicates the effect is engaged
SPECIFICATIONS
- INPUT Impedance = 500KOhm
- OUTPUT Impedance <= 50KOhm
- Max out level = 600mV
- Weight = about 200g / 0,4lbs
- Dimensions = 100 x 110 x 55 mm
- Current draw = 14mA
- Average 9V (200mA/h) battery life = about 14 hours
- WIMA capacitors, made in Germany
- Metal-film or carbon-film resistors depending on their functions
- SH multiwiper potentiometers, aluminium wiper
