Bryant QUANTUM PLUS 650A User manual

Form No. PDS 650A.24.6
13 SEER
HEAT PUMP WITH
PURON® REFRIGERANT
650A
Sizes 024 thru 060
The Model 650A 13 SEER heat pump (with efficiencies up to 14.5
SEER) is designed for operation with Puron® refrigerant. Home-
owners will appreciate the 650A because of it’s efficiency, envi-
ronmental soundness, and Puron’s availability for years to come.
Another benefit of the 650A is the durability of the scroll compres-
sor. Model 650A has received certifications from UL (U.S. and
Canada), ARI, and CEC. The 650A is also approved by Energy
Star
®
for energy efficiency.
AVAILABLE OPTIONS
REFRIGERANT
—The environmentally sound refrigerant used
in the 650A is Puron. This advanced refrigerant contains no
chlorine which can contribute to ozone depletion in the atmo-
sphere, so it’s a smart choice for homeowners who are con-
cerned with protecting our environment, now and for future
generations. And it’s a smart choice for anyone interested in
high-efficiency cooling.
BRYANT’S EVOLUTION™ CONTROLS —These industry-
leading controls, when installed with Bryant’s Perfect Humidity™
variable-speed furnaces or fan coils, provide the homeowner
with:
–unparalleled control of temperature, humidity, indoor air quality,
and zoning
–unprecedented ease of use
–simple operation through on-screen, text-based service
reminders
Optional remote access through telephone or Internet is also
available when combined with a remote connectivity kit.
RELIABLE BUILT-IN COMPONENTS —All units include a suc-
tion line accumulator that minimizes the amount of liquid refrig-
erant that reaches the compressor; a high-pressure switch for
high-pressure protection; a low-pressure switch for loss of
charge protection; and a heavy duty, high filtration and moisture
removal liquid-line filter drier specially designed for Puron is
standard with every unit. A crankcase heater is standard on the
048 and 060 sizes.
COMPRESSOR PROTECTION —Each scroll compressor
motor is protected with internal temperature and current-sensi-
tive overloads. For improved serviceability all models are
equipped with a compressor terminal plug.
UNIT DESIGN —Copper tube, enhanced aluminum fin coil is
designed for strong heat transfer. Vertical air discharge carries
sound and hot condenser air up and away from adjacent patio
areas and foliage. Heat pump style base pan is popular for its
easy removal of water, dirt, and leaves.
The
AeroQuiet System (AQS) consists of 4 design features to
achieve ultra-low sound ratings.
Aerocoustic Design featuring the AeroMax™ opening and wire
dome top results in quieter and more efficient operation.
Energy-Efficient Fan and Fan Motor provide a slower fan
operation, thus reducing noise and improving efficiency.
Sound Hood muffles noise from operation.
Discharge Muffler minimizes low frequency sound and pres-
sure pulsation generated by compressor discharge gas.
WEATHER-PROTECTIVE CABINET —The casing steel is galva-
nized and coated with a layer of zinc phosphate. A layer of modified
polyester powder is then applied and baked on, providing each unit
with a durable finish that will last for many years.
All screws on cabinet exterior are coated for a long-lasting, rust-
resistant, quality appearance.
HEAVY DUTY INLET GRILLE —The DuraGuard™ coil protector,
made of a coated steel wire grid with vertical 3/8-in. spacing, is
designed to help protect the coil from inclement weather, vandal-
ism, and incidental damage. It provides protection while not restrict-
ing airflow and maintaining ease of coil inspection and cleaning.
EASY SERVICEABILITY —One access panel provides access
to electrical controls and compressor. Removal of wire dome
gives access to fan motor and removal of the top gives access to
the coil.
WIDE RANGE OF SIZES —Available in 6 nominal sizes from
024 through 060 to meet the needs of residential and light com-
mercial applications.
LIMITED WARRANTY —Standard 5-year limited warranty on all
parts, with 10-year limited warranty on compressor.
TOTALLY ENCLOSED FAN MOTOR —Means greater reliability
under adverse weather conditions and dependable performance
for many years. Permanent split-capacitor-type motors provide
more economical operation.
DEFROST CONTROL BOARD —Incorporates a built-in 5-
minute compressor time-delay relay, defrost relay, defrost timer,
and low-voltage terminal board. The defrost control is a time/tem-
perature initiation/termination control, which includes 4 field-
selectable (DIP switch) time periods of 30, 60, 90, and 120 min-
utes. This control also includes a field-selectable (DIP switch)
Quiet Shift defrost mode which, if selected, maintains extremely
quiet operation during defrost.
APPLICATION VERSATILITY —The 650A can be combined
with a wide variety of evaporator coils and blower packages to
provide quiet, dependable comfort. The 650A can be installed
on a roof or at ground level on a slab.
EXTERNAL SERVICE VALVES —Both service valves are brass,
back seating type with sweat connections. Valves are externally
located so refrigerant tube connections can be made quickly
and easily. Each valve has a service port for ease of checking
operating refrigerant pressures.
THERMOSTATIC EXPANSION VALVE (TXV) —This unit must
be installed with a Puron® refrigerant approved TXV on the
indoor coil. The FX4 and FV4 fan coils and CK5P furnace coil
come factory equipped with Puron-refrigerant TXVs. When
installed with these fan coils, no further change is required.
For any other coil combination, the approved field accessory
Puron-refrigerant TXV must be installed. For applications with
fan coils such as the FC4 and FK4 which have R-22 TXVs, the
R-22 TXV must be replaced with the approved field accessory
Puron-refrigerant TXV.
ELECTRICAL RANGE —All units are offered in 208/230v single
phase only.
TM

—2—
DIMENSIONS
A99088
AIR DISCHARGE
AIR DISCHARGE
AIR IN
AIR IN
AIR IN
3/8"
DIA. TIEDOWN KNOCKOUTS
(2) PLACES
L
K
J
E
D
C
L
NOTES:
1. ALLOW 30" CLEARANCE TO SERVICE SIDE OF UNIT, 48" ABOVE UNIT, 6" ON ONE SIDE, 12" ON REMAINING SIDE, AND 24" BETWEEN UNITS FOR PROPER AIRFLOW. 2. MINIMUM OUTDOOR OPERATING AMBIENT IN COOLING MODE IS 55°F, (UNLESS LOW AMBIENT CONTROL IS USED) MAX. 125°F. 3. MAXIMUM OUTDOOR OPERATING AMBIENT IN HEATING MODE IS 66°F.
4. SERIES DESIGNATION IS THE 14TH POSITION OF THE UNIT MODEL NUMBER. 5. CENTER OF GRAVITY .
ACCESS
PANEL
1 1/4
"
2 1
/2
"
AIR DISCHARGE
1 3/4
"
4 3/16
"
3/8"
DIA. LIQUID
LINE CONN.
H
DIA. VAPOR
LINE CONN.
7/8"
DIA. HOLE
FIELD POWER SUPPLY CONN. 7/8"
DIA.
HOLE WITH 1 1/8"
DIA. KNOCKOUT
AND 1 3/8"
DIA. KNOCKOUT
10 1/2
"
FIELD CONTROL SUPPLY CONN
1 9/16
"
C
F
2 15/16
"
G
A
B
M
DIMENSIONS (IN.)
UNIT
SIZE SERIES
UNIT DIMENSIONS
MINIMUM MOUNTING
PAD DIMENSIONS
ABCD EFGHJK LMSupport Feet Snow Stand
024 D, E 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 5/8 8-3/16 15-7/8 14-3/8 14-1/4 26 x 32 31 x 35 030 D, E 33-13/16 30 33 5-1/16 9-11/16 21-15/16 28-3/8 3/4 8-3/16 14 13-1/8 13-3/4 26 x 32 31 x 35 036 D, E 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 3/4 8-3/16 15-7/8 14-3/8 14-1/4 26 x 32 31 x 35 042 D, E 27-13/16 30 33 5-1/16 9-11/16 15-15/16 22-3/8 7/8 8-3/16 16-1/4 14 13-1/8 26 x 32 31 x 35 048 D, E, F 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 8-3/16 16-1/4 14-1/4 14-1/2 26 x 32 31 x 35 060 D, E 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 8-3/16 16 13-3/4 14 26 x 32 31 x 35

—3—
000 A A AA
Standard Unit
Series
A – Original Series
B – Second Series
Common Unit – U.S.A. Only
Heating Size
RECOMMENDED TUBE DIAMETERS
NOTES: 1.Tube diameters are for lengths up to 50 ft. For tubing lengths greater than 50 ft horizontal and/or 20 ft vertical differential, consult the Application
Guideline and Service Manual for Residential Split-System Air Conditioners and Heat Pumps using Puron Refrigerant.
2. Refrigerant tubes and indoor coils must be evacuated to 500 microns to minimize contamination and moisture in the system.
METERING DEVICE
*TXV must be installed when indoor coil is not equipped with a Puron approved TXV. TXV listed is for any approved coil combination. All TXVs are Puron spe-
cific bi-flow hard shutoff.
A-WTD. SOUND POWER (dBA)
Note: Tested in accordance with ARI Standard 270-95. (Not listed with ARI).
UNIT
SIZE
LIQUID TUBE
DIAMETER (IN.) VAPOR TUBE DIAMETER (IN.)
0 to 50 Ft
Tube Length
0 to 50 Ft
Tube Length
0 to 50 Ft
Alternate
024 3/8 5/8 3/4 ACR
030 3/8 3/4 5/8, 7/8
036 3/8 3/4 5/8, 7/8
042, 048 3/8 7/8 3/4, 7/8
060 3/8 1-1/8 7/8
UNIT SIZE SERIES OUTDOOR PISTON INDOOR TXV*
REQUIRED SUBCOOLING
(°F)
024 D, E 46 KSATX0201PUR 11
030 D, E 52 KSATX0201PUR 9
036 D, E 57 KSATX0301PUR 14
042 D, E 59 KSATX0301PUR 11
048 D, E, F 63 KSATX0401PUR 10
060 D, E 73 KSATX0501PUR 12
UNIT SIZE
SERIES
STANDARD
RATING
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
024-D, E 71 53.0 58.0 62.0 63.5 63.0 56.0 49.0
030-D, E 73 54.0 62.0 64.0 65.0 63.5 60.0 53.0
036-D, E 74 59.5 65.0 67.5 68.0 65.5 61.5 53.5
042-D, E 74 58.0 64.5 67.5 67.0 65.0 60.5 52.5
048-D, E, F 77 60.0 67.5 69.5 68.5 65.0 63.0 55.0
060-D, E 77 59.0 67.5 69.0 70.0 67.5 65.0 59.0
MODEL NUMBER NOMENCLATURE
650A N X 024
Model Number
13 SEER Split-System
Heat Pump
N/A
Electrical Supply
N – 208/230-1-60
Nominal Cooling Capacity
024 – 2 ton 042 – 3.5 ton
030 – 2.5 ton 048 – 4 ton
036 – 3 ton 060 – 5 ton

—4—
SPECIFICATIONS
See notes on page 5.
UNIT SIZE-SERIES 024-D, E 030-D, E 036-D, E
Operating Weight (Lb) 214 205 216
ELECTRICAL
Unit Volts—Hertz—Phase 208/230—60—1
Operating Voltage Range* 187—253
Compressor Rated Load Amps 15.1 14.7 19.3
Compressor Locked Rotor Amps 61.0 72.5 83.0
Condenser Fan Motor—Full Load Amps 0.8 1.1 1.1
Minimum Unit Ampacity for Wire Sizing 19.7 19.5 25.2
Minimum Wire Size (60°C Copper) (AWG)† 14 14 12
Minimum Wire Size (75°C Copper) (AWG)† 14 14 12
Maximum Wire Length (60°C) (Ft)‡ 39 39 50
Maximum Wire Length (75°C) (Ft)‡ 37 37 48
Maximum Branch Circuit Fuse Size** 30 30 35
COMPRESSOR & REFRIGERANT
Compressor Type Scroll
Refrigerant Type Puron
Refrigerant Amount (Lb)†† 7.18 6.63 8.375
OUTDOOR COIL & FAN
Coil Face Area (Sq Ft) 18.18 15.15 18.18
Fins per In.—Rows—Circuits 25—1—2 25—1—3 25—1—4
Fan Motor—HP & RPM 1/8 and 825 1/5 and 825 1/5 and 825
Rated Airflow (CFM) 2400 2800 2800
OPTIONAL EQUIPMENT
Support Feet—4 In. (4) KSASF0101AAA
Snow Stand—18 In. KHASS0206MPK
Time Delay Relay KAATD0101TDR
Ball-Bearing Fan Motor HC38GE231 (RCD)
MotorMaster®—Low-Ambient Controller‡‡ KSALA0401AAA
Outdoor Thermostat KHAOT0301FST
Secondary Outdoor Thermostat KHAOT0201SEC
Crankcase Heater KAACH1201AAA
Start Assist—Capacitor/Relay Type KSAHS1501AAA
Start Assist—PTC Type Standard KAACS0201PTC
Bi-Flow TXV (Hard Shutoff) KSATX0201PUR KSATX0301PUR
Evaporator Freeze Thermostat*** KAAFT0101AAA
Isolation Relay*** KHAIR0101AAA
Liquid-Line Solenoid Valve (LSV) KHALS0401LLS
Low-Ambient Pressure Switch KSALA0301410
Coastal Filter KAACF0801MED
Pressure Guard™ Kit KHAPG0101PGS KHAPG0201PGS
Evolution Controls See chart.
As an ENERGY STAR®
partner, Bryant Heating &
Cooling Systems has
determined that this prod-
uct meets the ENERGY
STAR® guidelines for
energy efficiency.
CERTIFICATION APPLIES ONLY
WHEN THE COMPLETE SYSTEM
IS LISTED WITH ARI.
*
M
A
N
U
F
A
C
T
U
R
E
R
C
E
R
T
I
F
I
E
D
T
O
A
R
I
A
S
C
O
M
P
L
Y
I
N
G
W
I
T
H
A
R
I
S
T
A
N
D
A
R
D
2
4
0
U
N
I
T
A
R
Y
H
E
A
T
P
U
M
P
E
Q
U
I
P
M
E
N
T
®
*Refer to the combination ratings in the Product Data Sheet for system combinations that meet Energy Star® efficiency standards.
REGISTERED
ISO 9001:2000

—5—
SPECIFICATIONS Continued
*Permissible limits of the voltage range at which the unit will operate satisfactorily. Operation outside these limits may result in unit failure.
†If other than uncoated (non-plated), 60°C or 75°C (140° or 167°F) insulation, copper wire (solid wire for 10 AWG and smaller, stranded wire for larger than
10 AWG) is used, consult applicable tables of the NEC (ANSI/NFPA 70).
If wire is applied at ambient greater than 30°C (86°F), consult Table 310-16 of the NEC (ANSI/NFPA 70). The ampacity of nonmetallic-sheathed cable
(NM), trade name ROMEX, shall be that of 60°C (140°F) conductors, per the NEC (ANSI/NFPA 70) Article 336-26.
‡ Length shown is as measured 1 way along the wire path between the unit and the service panel for a voltage drop not to exceed 2 percent.
** Time-delay fuse or circuit breaker.
†† The factory refrigerant charge is for 15 ft of interconnecting tubing. For tubing lengths other than 15 ft, refer to the Residential Split-Systems Long-Line
Application Guideline and Service Manual for Residential Split-System Air Conditioners and Heat Pumps using Puron (R-410A).
‡‡ Install with Ball-Bearing Fan Motor.
*** Use with low-ambient pressure switch.
NOTE: Copper wire must be used from service disconnect to unit. All motors/compressors contain internal overload protection.
UNIT SIZE-SERIES 042-D, E 048-D, E, F 060-D, E
Operating Weight (Lb) 218 266 295
ELECTRICAL
Unit Volts—Hertz—Phase 208/230—60—1
Operating Voltage Range* 187—253
Compressor Rated Load Amps 21.1 20.5/21.8 27.6
Compressor Locked Rotor Amps 104.0 109.0/117.0 158.0
Condenser Fan Motor—Full Load Amps 1.1 1.4 1.4
Minimum Unit Ampacity for Wire Sizing 27.5 27.0/28.6 35.9
Minimum Wire Size (60°C Copper) (AWG)† 10 10 8
Minimum Wire Size (75°C Copper) (AWG)† 10 10 8
Maximum Wire Length (60°C) (Ft)‡ 71 74/69 86
Maximum Wire Length (75°C) (Ft)‡ 68 70/66 82
Maximum Branch Circuit Fuse Size** 40 40 60
COMPRESSOR & REFRIGERANT
Compressor Type Scroll
Refrigerant Type Puron
Refrigerant Amount (Lb)†† 8.63 13.25 13.25
OUTDOOR COIL & FAN
Coil Face Area (Sq Ft) 12.12 18.18 18.18
Fins per In.—Rows—Circuits 20—2—3 20—2—4 20—2—5
Fan Motor—HP & RPM 1/5 and 825 1/4 and 1100 1/4 and 1100
Rated Airflow (CFM) 2800 3300 3300
OPTIONAL EQUIPMENT
Support Feet—4 In. (4) KSASF0101AAA
Snow Stand—18 In. KHASS0206MPK
Time Delay Relay KAATD0101TDR
Ball-Bearing Fan Motor HC38GE231 HC40GE232
MotorMaster®—Low-Ambient Controller‡‡ KSALA0401AAA
Outdoor Thermostat KHAOT0301FST
Secondary Outdoor Thermostat KHAOT0201SEC
Crankcase Heater KAACH1201AAA Standard
Start Assist—Capacitor/Relay Type KSAHS1501AAA KSAHS1601AAA
Start Assist—PTC Type KAACS0201PTC
Bi-Flow TXV (Hard Shutoff) KSATX0301PUR KSATX0401PUR KSATX0501PUR
Evaporator Freeze Thermostatz*** KAAFT0101AAA
Isolation Relay*** KHAIR0101AAA
Liquid-Line Solenoid Valve (LSV) KHALS0401LLS
Low-Ambient Pressure Switch KSALA0301410
Coastal Filter KAACF0801MED
Pressure Guard™ Kit KHAPG0101PGS KHAPG0201PGS
Evolution Controls See chart.

—6—
THERMOSTATS AND ACCESSORIES
* Do not use in zoning heat pump applications.
† This plate is designed to cover surrounding wall area located behind thermostat.
‡ Thermostat conversion kit is a 24-vac accessory that can turn a 4-wire thermostat application into a 5-wire application. This kit can also be used
to replace a broken thermostat wire, or add an extra wire when needed.
** Outdoor air temperature sensor is an accessory for all Bryant electronic thermostats, except the non-programmable air conditioner version and
builder’s thermostats. It allows the temperature at a remote location (outdoors) to be displayed on the thermostat.
The outdoor air temperature sensor must be used with the dual fuel thermostat.
The outdoor air temperature sensor is included with the Thermidistat Control and dual fuel thermostat.
EVOLUTION™* CONTROLS
* When applied with Bryant’s Perfect Humidity™ series 355, 315 and FE4 Indoor Models.
† Must be installed in Dual-Fuel Evolution system applications.
ACCESSORY USAGE GUIDELINE
*For tubing line sets between 50 and 175 ft and/or 20 ft elevation difference between indoor and outdoor units, refer to the Application Guideline
and Service Manual for Residential Split-System Air Conditioners and Heat Pumps using Puron Refrigerant.
† Required for all applications.
Thermidistat™ Control—Non-Programmable/Programmable Thermostat with Humidity
Control (For use in Dual Fuel, AC, HP, and 2S applications. Includes Outdoor Air
Temperature Sensor.) TSTATBBPRH01-B*
Thermostat—Auto Changeover, 7-Day Programmable, °F/°C, Dual Fuel, Includes Outdoor
Sensor (TSTATXXSEN01-B) TSTATBBPDF01-B*
Thermostat—Auto Changeover, 7-Day Programmable, °F/°C, 2-Stage Heat/1-Stage Cool TSTATBBPHP01-B
Thermostat—Auto Changeover, Non-Programmable, °F/°C, 2-Stage Heat/1-Stage Cool TSTATBBNHP01-C
Standard Programmable Thermostat—Manual Changeover, 5-2 Day Programmable, °F/°C,
1-Stage Heat/1-Stage Cool TSTATBBSHP01
Builder’s Thermostat—Manual Changeover, Non-Programmable, °F/°C, 2-Stage Heat/
1-Stage Cool, Heat Pump TSTATBBBHP01*
Outdoor Air Temperature Sensor TSTATXXSEN01-B
Backplate for Non-Programmable Thermostat TSTATXXNBP01†
Backplate for Programmable Thermostat and Thermidistat™ Control TSTATXXPBP01†
Backplate for Builder’s Thermostat TSTATXXBBP01†
Backplate for Standard Programmable Thermostat TSTATXXSBP01
Thermostat Conversion Kit (4 to 5 Wire)—10 Pack TSTATXXCNV10‡
ACCESSORY DESCRIPTION
SYSTXBBUID01
Evolution™* ControlS Deluxe 7-Day Programmable (Wall-mounted system control.)
SYSTXBBUIZ01 Evolution Zone Control Deluxe Zoning 7-Day Programmable (Wall-mounted control for a multi-zone system.)
SYSTXBB4ZC01 Evolution 4-Zone Damper Control Module (Wall-mounted control for a four-zone system.)
SYSTXBBSMS01
Evolution Smart Sensor (Optional wall control used to monitor temperature and/or fan control in an
individual zone.)
SYSTXBBRRS01 Evolution Remote Room Sensor (Monitors temperature in an individual zone.)
SYSTXBBSAM01 Evolution System Access Module (Hardware for wireless access and control via phone or internet.)
SYSTXBBNIM01†
Evolution Network Interface Module (Connects Heat Recovery or Energy Recovery Ventilators or older two-
speed outdoor models to system.)
SYSTXXXBPU01 Back Plate for Evolution Control (Decorative wall plate.)
ACCESSORY
REQUIRED FOR LOW-AMBIENT
APPLICATIONS
(Below 55°F)
REQUIRED FOR LONG-LINE
APPLICATIONS*
(Over 50 Ft)
Crankcase Heater Yes Yes
Evaporator Freeze Thermostat Yes No
Compressor Start Assist—Capacitor and Relay Yes Yes
Puron Low-Ambient Pressure Switch Yes No
Wind Baffle See Low-Ambient
Pressure Switch Instructions No
Support Feet Recommended No
Puron Hard Shutoff TXV Yes† Yes†
Puron Liquid-Line Solenoid Valve for Heating No See Long-Line
Application Guideline
This unit can be used as part of a Perfect Heat / Perfect Humidity System.
This system will remove more moisture per day than a standard system. A
Perfect Heat System will also average warmer air temperature in the heating
mode. A Perfect Heat/Perfect Humidity System requires the use of a Variable-
Speed Fan Coil with Thermidistat Control, Zone Perfect Plus, or Evolution
Control.
Z
O
N
I
N
G

—7—
ACCESSORY DESCRIPTION AND USAGE (Listed Alphabetically)
1. Ball-Bearing Fan Motor
A fan motor with ball bearings which permits speed reduction while maintaining bearing lubrication.
Usage Guideline:
Required on all units when MotorMaster®—Low-Ambient Controller is installed.
2.
Coastal Filter
A mesh screen inserted under the top cover and inside the base pan to protect the condenser coil from salt damage without restricting airflow.
3.
Compressor Start Assist – Capacitor and Relay
Start capacitor and relay gives a "hard" boost to compressor motor at each start up.
Note: Heat pumps with Puron-refrigerant and a reciprocating compressor have capacitor and relay factory supplied.
Usage Guideline:
Required for single-phase reciprocating compressors in the following applications:
Long line
Low ambient cooling
Hard shut off expansion valve on indoor coil
Required for single-phase scroll compressors in the following applications:
Long line
Low ambient cooling
Suggested for all compressors in areas with a history of low voltage problems.
4.
Compressor Start Assist — PTC Type
Solid state electrical device which gives a "soft" boost to the compressor at each start-up.
Usage Guideline:
Suggested in installations with marginal power supply.
5.
Crankcase Heater
An electric resistance heater which mounts to the base of the compressor to keep the lubricant warm during off cycles. Improves compressor lubrication
on restart and minimizes the chance of liquid slugging.
Note: Some heat pumps are factory supplied with a crankcase heater. See accessory list for units that come standard with a crankcase heater. For units
that do not, use the guideline below.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
6.
Evaporator Freeze Thermostat
An SPST temperature-actuated switch that stops unit operation when evaporator reaches freeze-up conditions.
Usage Guideline:
Required when low ambient kit has been added.
7.
Isolation Relay
An SPDT relay which switches the low-ambient controller out of the outdoor fan motor circuit when the heat pump switches to heating mode.
Usage Guideline:
Required in all heat pumps where low ambient kit has been added.
8.
Liquid-Line Solenoid Valve (LLS)
An electrically operated shutoff valve which stops and starts refrigerant liquid flow in response to compressor operation. It is to be installed at the outdoor
unit to control refrigerant off cycle migration in the heating mode.
Usage Guideline:
An LLS is required in all long line heat pump applications to control refrigerant off cycle migration in the heating mode. See Long Line
Application Guideline.
9.
Low-Ambient Pressure Switch
A long life pressure switch which is mounted to outdoor unit service valve. It is designed to cycle the outdoor fan motor in order to maintain head pressure
within normal operating limits (approximately 200 psig to 365 psig). The control will maintain working head pressure at low-ambient temperatures down to
0°F (–17.8°C) when properly installed.
Usage Guideline:
A Low-Ambient Pressure Switch or MotorMaster ®—Low-Ambient Controller must be used when cooling operation is used at outdoor tem-
peratures below 55°F (12.8°C).
10.
MotorMaster®—Low-Ambient Controller
A fan-speed control device activated by a temperature sensor designed to control condenser fan motor speed in response to the saturated, condensing
temperature during operation in cooling mode only. For outdoor temperatures down to –20°F (–28.9°C), it maintains condensing temperature at 100°F ±
10°F (37.8°C ± –12°C).
Usage Guideline:
A MotorMaster ®—Low-Ambient Controller or Low-Ambient Pressure Switch must be used when cooling operation is used at outdoor tem-
peratures below 55°F (12.8°C).
Suggested for all commercial applications
11.
Outdoor Air Temperature Sensor
Designed for use with Bryant Thermostats listed in this publication. This device enables the thermostat to display the outdoor temperature. This device also
is required to enable special thermostat features such as auxiliary heat lock out .
Usage Guideline:
Suggested for all Bryant thermostats listed in this publication.
12.
Outdoor Thermostat
An SPDT temperature-actuated switch which turns on supplemental electric heaters when outdoor air temperature drops below a user-selected set point.
Usage Guideline:
Electric supplemental heat applications in non-variable speed indoor units when electric heat staging is desired.
13.
Pressure Guard Kit
A pressure switch kit that cycles the outdoor fan to limit the heating head pressure below a pre-determined pressure setting.
Usage Guideline:
Some local codes may require limiting the heating head pressure in the vapor line in some applications.
14.
Secondary Outdoor Thermostat
An SPDT temperature-actuated switch which turns on third-stage of supplemental electric heaters when outdoor air temperature drops below the second-
stage set point.
Usage Guideline:
Outdoor thermostat applications where electric heater is capable of 3-stage operation.

—8—
ACCESSORY DESCRIPTION AND USAGE (continued)
15. Sound Hood
Wraparound sound reducing cover for the compressor. Reduces the sound level by about 2 dBA.
Usage Guideline:
Suggested when unit is installed closer than 15 ft to quiet areas—bedrooms, etc.
Suggested when unit is installed between two houses less than 10 ft apart.
16.
Snow Stand
Coated wire rack which supports unit 18 in. above mounting pad to allow for drainage from unit base.
Usage Guideline:
Suggested in the following applications:
Heat pump installations in heavy snowfall areas.
Heat pump installations in snowdrift locations.
Heat pump installations in areas of prolonged subfreezing temperatures.
All commercial installations.
17.
Support Feet
Four stick-on plastic feet that raise the unit 4 in. above the mounting pad. This allows sand, dirt, and other debris to be flushed from the unit base, minimizing
corrosion.
Usage Guideline:
Suggested in the following applications:
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
For improved sound ratings.
18.
Thermostatic Expansion Valve (TXV) Bi-Flow
A modulating flow-control valve which meters refrigerant liquid flow rate into the evaporator in response to the superheat of the refrigerant gas leaving the
evaporator.
Usage Guideline:
Required in all heat pump applications designed with Puron refrigerant.
19.
Time-Delay Relay
An SPST delay relay which briefly continues operation of indoor blower motor to provide additional cooling after the compressor cycles off.
Note: Most indoor unit controls include this feature. For those that do not, use the guideline below.
Usage Guideline:
For improved efficiency ratings for certain combinations of indoor and outdoor units. Refer to ARI Unitary Directory.

—9—
COMBINATION RATINGS
UNIT
SIZE-
SERIES
INDOOR
UNIT CFM††
ARI STANDARD RATINGS*
Cooling Heating
TC
Seasonal Efficiency SEER
EER
High-Temp Low-Temp
HSPF
Factory-
Supplied
Enhance-
ment
Standard
Rating
Field-Supplied
Accessory‡
Puron
TXV
Puron
TXV
& TDR**
TC COP TC COP
024-D, E
*FX4BNF030 25,000 TDR&TXV 13.00 — — — 11.10 25,000 3.30 16,600 2.38 8.0
CC5A/CD5AA036 24,600 NONE — — 12.50 — 11.10 24,800 3.30 16,100 2.30 7.8
CC5A/CD5AW030 23,800 NONE — — 12.00 — 10.80 24,600 3.10 15,900 2.22 7.5
CC5A/CD5AW036 24,600 NONE — — 12.50 — 11.10 25,000 3.30 16,100 2.30 7.8
CE3AA036 23,800 NONE — — 12.60 — 11.05 24,600 3.20 16,600 2.34 7.4
CF5AA036 25,000 NONE — — 12.80 — 11.15 24,800 3.22 16,600 2.34 7.5
CK3BA036 24,200 NONE — — 13.00 — 11.20 24,800 3.34 16,600 2.38 7.5
CK5A/CK5BA036 24,200 NONE — — 13.00 — 11.20 24,800 3.34 16,600 2.38 7.5
CK5A/CK5BT036 24,200 NONE — — 13.00 — 11.20 24,800 3.34 16,600 2.38 7.5
CK5A/CK5BW036 24,200 NONE — — 13.00 — 11.20 24,800 3.34 16,600 2.38 7.5
CK5PA036 24,200 TXV — — — 13.00 11.20 24,800 3.34 16,600 2.38 7.5
CK5PT036 24,200 TXV — — — 13.00 11.20 24,800 3.34 16,600 2.38 7.5
CK5PW036 24,200 TXV — — — 13.00 11.20 24,800 3.34 16,600 2.38 7.5
F(A,B)4BN(F,C)030 23,600 TDR — 12.50 — — 10.95 24,400 3.18 16,500 2.32 7.5
FC4CNF030 24,000 TDR&TXV — 12.50 — — 10.95 24,400 3.18 16,500 2.32 7.5
FE4ANF002 25,200 TDR&TXV 14.20 — — — 12.05 25,200 3.44 16,100 2.48 8.0
FE4ANF003 25,200 TDR&TXV 14.50 — — — 12.35 25,000 3.44 15,900 2.48 8.0
FK4DNF001 24,400 TDR&TXV — 13.80 — — 12.00 23,800 3.30 16,000 2.42 7.8
FK4DNF002 25,200 TDR&TXV — 14.00 — — 12.35 25,000 3.58 16,100 2.54 8.0
FK4DNF003 25,200 TDR&TXV — 14.20 — — 12.60 25,200 3.54 16,000 2.54 8.0
FV4BNF002 25,200 TDR&TXV 14.20 — — — 12.05 25,200 3.44 16,100 2.48 8.0
FV4BNF003 25,200 TDR&TXV 14.50 — — — 12.35 25,000 3.44 15,900 2.48 8.0
COILS + 315(A,J)AV036070 VARIABLE-SPEED FURNACE
CC5A/CD5AA030 24,000 TDR — 13.50 — — 11.85 23,200 3.12 15,000 2.30 7.5
CC5A/CD5AA036 24,000 TDR — 14.00 — — 12.15 24,000 3.34 15,900 2.44 8.0
CC5A/CD5AW030 24,000 TDR — 13.50 — — 11.85 23,200 3.12 15,000 2.30 7.5
CK3BA030 24,000 TDR — 13.50 — — 11.90 23,400 3.28 15,200 2.36 7.8
CK5A/CK5BW030 24,000 TDR — 13.50 — — 11.90 23,400 3.28 15,200 2.36 7.8
CK5PA030 24,000 TDR&TXV 13.50 — — — 11.90 24,000 3.28 15,200 2.36 7.8
CK5PA036 24,200 TDR&TXV 14.00 — — — 12.25 24,800 3.42 15,900 2.46 8.0
CK5PT036 24,200 TDR&TXV 14.00 — — — 12.25 24,800 3.42 15,900 2.46 8.0
CK5PW030 24,000 TDR&TXV 13.50 — — — 11.90 24,000 3.28 15,200 2.36 7.8
CC5A/CD5AW036 24,200 TDR — 14.00 — — 12.10 24,000 3.30 15,200 2.36 7.8
COILS + 335MAV042040 VARIABLE-SPEED FURNACE
CC5A/CD5AW036 24,200 TDR — 14.00 — — 12.10 24,000 3.30 15,200 2.36 7.8
COILS + 355MAV042060 VARIABLE-SPEED FURNACE
CC5A/CD5AA030 23,400 TDR — 13.20 — — 11.75 23,400 3.06 15,000 2.26 7.5
CC5A/CD5AA036 24,200 TDR — 14.00 — — 12.10 24,000 3.28 15,200 2.36 7.8
CC5A/CD5AW030 23,400 TDR — 13.20 — — 11.75 23,200 3.06 15,000 2.26 7.5
CC5A/CD5AW036 24,200 TDR — 14.00 — — 12.15 24,000 3.30 15,200 2.36 7.8
CK3BA036 24,600 TDR — 14.00 — — 12.00 24,400 3.46 16,200 2.48 8.0
CK5A/CK5BA036 24,600 TDR — 14.00 — — 12.00 24,400 3.46 16,200 2.48 8.0
CK5A/CK5BT036 24,600 TDR — 14.00 — — 12.00 24,400 3.46 16,200 2.48 8.0
CK5PA036 24,600 TDR&TXV 14.00 — — — 12.00 24,400 3.46 16,200 2.48 8.0
CK5PT036 24,600 TDR&TXV 14.00 — — — 12.00 24,400 3.46 16,200 2.48 8.0
COILS + 355MAV042080 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 24,200 TDR — 14.00 — — 12.10 24,000 3.30 15,200 2.36 7.8
CC5A/CD5AW030 23,600 TDR — 13.10 — — 11.75 23,200 3.08 15,100 2.26 7.5
CC5A/CD5AW036 24,200 TDR — 14.00 — — 12.10 24,000 3.30 15,200 2.36 7.8
CK5A/CK5BW036 24,600 TDR — 14.00 — — 12.25 24,200 3.50 16,200 2.50 8.0
CK5PW036 24,600 TDR&TXV 14.00 — — — 12.25 24,200 3.50 16,200 2.50 8.0
COILS + 355MAV060080 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 24,200 TDR — 14.00 — — 12.10 24,000 3.30 15,200 2.36 7.8
CC5A/CD5AW030 23,600 TDR — 13.20 — — 11.75 23,200 3.08 15,000 2.26 7.5
CC5A/CD5AW036 24,200 TDR — 14.00 — — 12.15 24,000 3.30 15,200 2.36 7.8
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 24,400 TDR — 14.00 — — 12.15 24,000 3.32 15,200 2.36 7.8
CC5A/CD5AW030 23,600 TDR — 13.20 — — 11.80 23,200 3.08 15,000 2.28 7.5
CC5A/CD5AW036 24,400 TDR — 14.00 — — 12.15 24,000 3.32 15,200 2.36 7.8
CK5A/CK5BW036 25,000 TDR — 14.00 — — 12.10 24,800 3.58 16,500 2.54 8.0
CK5PW036 25,000 TDR&TXV 14.00 — — — 12.10 24,800 3.58 16,500 2.54 8.0
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CC5A/CD5AW036 24,200 TDR — 14.00 — — 12.10 24,000 3.28 15,200 2.36 7.8
030-D, E
*FX4BNF030 29,000 TDR&TXV 13.00 — — — 11.15 30,000 3.56 18,500 2.38 8.0
CE3AA036 28,600 NONE — — 12.70 — 11.15 29,200 3.44 18,500 2.36 7.5
CF5AA036 28,600 NONE — — 12.50 — 10.75 29,400 3.52 18,500 2.36 7.7
CK3BA036 28,800 NONE — — 12.70 — 11.30 29,400 3.56 18,500 2.40 7.7
CK5A/CK5BW036 28,800 NONE — — 12.70 — 11.30 29,400 3.56 18,500 2.40 7.7
CK5PW036 28,800 TXV — — — 12.70 11.30 29,400 3.56 18,500 2.40 7.7
F(A,B)4BN(F,C)030 28,000 TDR — 12.50 — — 11.00 29,400 3.42 18,400 2.34 7.4
F(A,B)4BN(F,C)036 28,400 TDR — 12.20 — — 10.75 29,800 3.42 18,700 2.32 7.4
FC4CNF030 28,000 TDR&TXV — 12.50 — — 11.00 29,400 3.42 18,400 2.34 7.4
FC4CNF036 28,400 TDR&TXV — 12.20 — — 10.75 29,800 3.42 18,700 2.32 7.4
FE4ANF002 29,200 TDR&TXV 14.00 — — — 12.15 29,000 3.68 17,900 2.48 8.1
FE4ANF003 29,400 TDR&TXV 14.50 — — — 12.55 28,600 3.70 17,700 2.52 8.1
FK4DNF001 28,600 TDR&TXV — 13.70 — — 12.10 28,600 3.54 17,800 2.44 7.8
FK4DNF002 28,800 TDR&TXV — 13.70 — — 12.15 29,000 3.68 17,900 2.48 8.0
FK4DNF003 29,000 TDR&TXV — 14.20 — — 12.55 28,600 3.68 17,700 2.50 8.0
FV4BNF002 29,200 TDR&TXV 14.00 — — — 12.15 29,000 3.68 17,900 2.48 8.1
See notes on page 15.

—10—
030-D, E
FV4BNF003 29,400 TDR&TXV 14.50 — — — 12.55 28,600 3.70 17,700 2.52 8.1
FX4BNF036 29,000 TDR&TXV 12.30 — — — 10.85 30,000 3.52 18,800 2.36 8.0
COILS + 315(A,J)AV036070 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 28,600 TDR — 14.00 — — 12.20 28,600 3.52 17,600 2.44 7.8
CK3BA036 28,800 TDR — 14.00 — — 12.25 29,000 3.62 17,800 2.48 8.0
CK5A/CK5BA036 28,800 TDR — 14.00 — — 12.25 29,000 3.62 17,800 2.48 8.0
CK5A/CK5BT036 28,600 TDR — 14.00 — — 12.25 29,000 3.62 17,800 2.48 8.0
CK5PA036 28,800 TDR&TXV 14.00 — — — 12.25 29,000 3.62 17,800 2.48 8.0
CK5PT036 28,800 TDR&TXV 14.00 — — — 12.25 29,000 3.62 17,800 2.48 8.0
COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 28,600 TDR — 14.00 — — 12.40 28,600 3.56 17,500 2.46 7.8
CC5A/CD5AW036 28,600 TDR — 14.00 — — 12.40 28,600 3.56 17,600 2.46 7.8
CK3BA036 28,800 TDR — 14.20 — — 12.45 29,000 3.64 17,700 2.50 8.0
CK5A/CK5BA036 28,800 TDR — 14.20 — — 12.45 29,000 3.64 17,700 2.50 8.0
CK5A/CK5BW036 28,800 TDR — 14.20 — — 12.45 29,000 3.64 17,700 2.50 8.0
CK5PA036 28,800 TDR&TXV 14.20 — — — 12.45 29,000 3.64 17,700 2.50 8.0
CK5PT036 28,800 TDR&TXV 14.20 — — — 12.45 29,000 3.64 17,700 2.50 8.0
CK5PW036 28,800 TDR&TXV 14.20 — — — 12.45 29,000 3.64 17,700 2.50 8.0
COILS + 355MAV042040 VARIABLE-SPEED FURNACE
CC5A/CD5AW036 28,600 TDR — 14.00 — — 12.20 28,800 3.46 17,600 2.42 7.8
COILS + 355MAV042060 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 28,400 TDR — 14.00 — — 12.20 28,600 3.48 17,500 2.42 7.8
CC5A/CD5AW036 28,400 TDR — 14.00 — — 12.25 28,600 3.46 17,200 2.40 7.8
CK3BA036 29,000 TDR — 13.50 — — 11.95 29,000 3.66 18,100 2.48 8.0
CK5A/CK5BA036 29,000 TDR — 13.50 — — 11.95 29,000 3.66 18,100 2.48 8.0
CK5A/CK5BT036 29,000 TDR — 13.50 — — 11.95 29,000 3.66 18,100 2.48 8.0
CK5PA036 29,000 TDR&TXV 13.50 — — — 11.95 29,000 3.66 18,100 2.48 8.0
CK5PT036 29,000 TDR&TXV 13.50 — — — 11.95 29,000 3.66 18,100 2.48 8.0
COILS + 355MAV042080 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 28,600 TDR — 14.00 — — 12.20 28,800 3.48 17,300 2.38 7.8
CC5A/CD5AW036 28,600 TDR — 14.00 — — 12.25 28,800 3.48 17,300 2.40 7.8
CK5A/CK5BW036 29,000 TDR — 13.70 — — 12.10 29,000 3.68 18,100 2.48 8.0
CK5PW036 29,000 TDR&TXV 13.70 — — — 12.10 29,000 3.68 18,100 2.48 8.0
COILS + 355MAV060080 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 28,600 TDR — 14.00 — — 12.20 28,800 3.48 17,200 2.38 7.8
CC5A/CD5AW036 28,400 TDR — 14.00 — — 12.25 28,600 3.48 17,200 2.40 7.8
CK5A/CK5BW036 29,000 TDR — 13.50 — — 11.95 29,000 3.66 18,100 2.46 8.0
CK5PW036 29,000 TDR&TXV 13.50 — — — 11.95 29,000 3.66 18,100 2.46 8.0
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
CC5A/CD5AA036 28,600 TDR — 14.00 — — 12.30 28,600 3.48 17,200 2.40 7.8
CC5A/CD5AW036 28,600 TDR — 14.00 — — 12.30 28,600 3.50 17,200 2.40 7.8
CK5A/CK5BW036 29,200 TDR — 14.00 — — 12.35 28,800 3.74 17,900 2.52 8.0
CK5PW036 29,200 TDR&TXV 14.00 — — — 12.35 28,800 3.74 17,900 2.52 8.0
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CC5A/CD5AW036 28,400 TDR — 14.00 — — 12.30 28,600 3.48 17,100 2.40 7.8
036-D, E
*FX4BNF042 34,400 TDR&TXV 13.00 — — — 10.75 36,800 3.58 23,400 2.56 8.5
CC5A/CD5AA042 34,000 NONE — 12.30 — — 10.40 36,600 3.40 23,400 2.48 8.0
CC5A/CD5AC048 33,400 NONE — — 12.50 — 10.40 36,200 3.30 22,800 2.42 8.0
CC5A/CD5AW042 34,000 NONE — 12.50 — — 10.60 36,400 3.40 23,200 2.50 8.1
CC5A/CD5AW048 33,800 NONE — 12.50 — — 10.50 36,000 3.48 23,400 2.50 8.5
CD5AA048 34,000 NONE — 12.50 — — 10.50 36,600 3.46 23,400 2.50 8.2
CE3AA042 34,000 NONE — 12.50 — — 10.70 36,600 3.50 23,400 2.54 8.3
CE3AA048 34,400 NONE — 13.00 — — 10.90 36,600 3.56 23,200 2.56 8.4
CF5AA048 34,400 NONE — 13.00 — — 10.85 36,000 3.48 23,200 2.54 8.3
CK3BA042 33,800 NONE — 12.50 — — 10.60 34,200 3.26 21,600 2.28 7.4
CK3BA048 34,000 NONE — 13.00 — — 10.70 36,800 3.56 23,400 2.56 8.4
CK5A/CK5BA042 34,000 NONE — 12.50 — — 10.65 36,600 3.50 23,400 2.54 8.3
CK5A/CK5BA048 34,000 NONE — 13.00 — — 10.70 36,800 3.56 23,400 2.56 8.4
CK5A/CK5BE042 33,200 NONE — 12.30 — — 10.70 34,000 3.16 21,600 2.30 7.3
CK5A/CK5BT042 34,000 NONE — 12.30 — — 10.65 36,600 3.50 23,400 2.54 8.3
CK5A/CK5BT048 34,000 NONE — 12.50 — — 10.70 36,800 3.56 23,400 2.56 8.4
CK5A/CK5BW048 34,000 NONE — 13.00 — — 10.70 36,800 3.56 23,400 2.56 8.4
CK5PA042 34,000 TXV — — — 12.50 10.65 36,600 3.50 23,400 2.54 8.3
CK5PA048 34,000 TXV — — — 13.00 10.70 36,800 3.56 23,400 2.56 8.4
CK5PE042 33,200 TXV — — — 12.30 10.70 34,000 3.16 21,600 2.30 7.3
CK5PT042 34,000 TXV — — — 12.30 10.65 36,600 3.50 23,400 2.54 8.3
CK5PT048 34,000 TXV — — — 12.50 10.70 36,800 3.56 23,400 2.56 8.4
CK5PW048 34,000 TXV — — — 13.00 10.70 36,800 3.56 23,400 2.56 8.4
F(A,B)4BN(F,B,C)042 34,000 TDR — — 12.50 — 10.50 36,800 3.46 23,400 2.50 8.2
FC4CN(F,B)042 34,000 TDR&TXV — — 12.50 — 10.50 36,800 3.46 23,400 2.50 8.2
FE4ANF002 33,800 TDR&TXV 13.00 — — — 11.30 33,600 3.32 20,800 2.34 7.6
FE4ANF003 34,000 TDR&TXV 14.00 — — — 11.75 35,200 3.54 22,200 2.62 8.5
FE4ANF005 35,000 TDR&TXV 14.50 — — — 12.25 35,000 3.82 22,400 2.74 9.0
FK4DNF003 34,000 TDR&TXV — — 14.00 — 11.75 35,200 3.54 22,200 2.62 8.5
FK4DNF005 35,000 TDR&TXV — — 14.50 — 12.25 35,000 3.82 22,400 2.74 9.0
FV4BNF002 33,800 TDR&TXV 13.00 — — — 11.30 33,600 3.32 20,800 2.34 7.6
UNIT
SIZE-
SERIES
INDOOR
UNIT CFM††
ARI STANDARD RATINGS*
Cooling Heating
TC
Seasonal Efficiency SEER
EER
High-Temp Low-Temp
HSPF
Factory-
Supplied
Enhance-
ment
Standard
Rating
Field-Supplied
Accessory‡
Puron
TXV
Puron
TXV
& TDR** TC COP TC COP
COMBINATION RATINGS continued
See notes on page 15.
