SYSTXBBECW01--A, SYSTXBBECN01--A
& SYSTXBBECC01--A
EvolutionrConnextControl
Owner’s Manual
A12479
NOTE: Read the entire instruction manual before starting the installation.
The features and functions outlined in this Owner’s Manual reflect Version 13
software. See the Downloads section of www.MyEvolutionConnex.Bryant.com for
the latest software release and literature.
US Patents: Carrier U.S. Pat No. 7,243,004, Carrier U.S. Pat No. 7,775,452, pointSETtU.S.
Pat No. 7,415,102

TABLE OF CONTENTS
PAGE
INTRODUCTION 1................................................
HOME SCREEN 1.................................................
Information Displayed 1...........................................
Wi--Fi Connectivity 2.............................................
Information Buttons 4.............................................
MAIN SCREEN 5.................................................
System Mode 5..................................................
Set Day and Time 5..............................................
Adjust Temperature (Temporary Hold) 6..............................
Adjusting Comfort Activities 6.....................................
Adjusting Heating 7..............................................
Adjusting Cooling 7..............................................
Adjust Temperature (Permanent Hold) 7..............................
Adjusting Comfort Profiles 8.......................................
Adjusting Heating 8..............................................
Adjusting Cooling 8..............................................
FEATURES 10....................................................
Adjust Fan Speed 10..............................................
View Current Humidity Level 10....................................
MENU SCREEN 11................................................
COMFORT PROFILES 11.........................................
Home Humidity Control 13........................................

TABLE OF CONTENTS (cont.)
PAGE
Home Fresh Air Control 14........................................
Away Humidity Control 16.........................................
Away Fresh Air Control 17.........................................
Vacation Humidity Control 18......................................
Vacation Fresh Air Control 19......................................
SCHEDULES 20................................................
View or Edit Schedule 20..........................................
Guided Scheduling 21............................................
Upload My Schedule 23...........................................
VACATION 24.................................................
REMINDERS 25................................................
OPERATING STATUS 26.........................................
Accessories Status 26.............................................
Temperature Control Status 27.....................................
DISPLAY 28....................................................
Temperature Units 28.............................................
Backlight Levels 28..............................................
Sound Settings 29................................................
Screen Saver Settings 30..........................................
Touch Screen Calibration 30.......................................

TABLE OF CONTENTS (cont.)
PAGE
ENERGY TRACKING 31.........................................
TIME / DATE 32................................................
Set Time and Date 32.............................................
Manually Adjust Time and Date 32..................................
Setup Daylight Savings Time 33....................................
Setup Time Zone 34..............................................
Enable Time Synchronization 34....................................
SERVICE 35....................................................
Service Information 35............................................
Service Reminder Update 36.......................................
Software Update 36..............................................
Updating Software Using USB 37...................................
Updating Software Using Wi--Fi 39..................................
Model / Serial Numbers 40.........................................
PHOTO UPLOAD 41.............................................
HEATSOURCE (IF APPLICABLE) 42...............................
ZONE NAMES (IF APPLICABLE) 43...............................
Home Automation System Interface (If Applicable) 43...................
SCREEN LOCK 44..............................................
WIRELESS 45..................................................
Wi--Fi Diagnostics 53.............................................

TABLE OF CONTENTS (cont.)
PAGE
WEATHER 54..................................................
UTILITY DEMAND EVENT RESPONSE SETUP 55....................
Utility Event 55.................................................
Price Response 56...............................................
Price Settings 56.................................................
Demand Response 57.............................................
Demand Settings 58..............................................
Response Limits 58..............................................
Restore UE Factory Default Settings 59...............................

1
INTRODUCTION
CONGRATULATIONS! Your decision to choose the EvolutionRConnext
Control puts you in a select group of homeowners who understand the value of
precise comfort control and appreciate the simplicity of an easy--to--use, intuitive,
control.
Your new Evolution Connex Control offers high quality comfort technology. Please
take a few moments to carefully read through this manual. Next set up a comfort
profile and schedule that makes sense for your lifestyle; then relax and enjoy the
new comfort of your home!
HOME SCREEN
Information Displayed
The information displayed on the home screen will appear when there has been no
interaction with the Evolution Connex Control for at least two minutes. The basic
information displayed on the Home Screen consists of the current date and time, the
room temperature (zone temperature if applicable), the outdoor temperature (if
applicable), and current weather condition (Wi--Fi®models only, when properly
configured). Connectivity status to the home Wi--Fi network and the MyEvolution
Server will also be displayed on the Home Screen for compatible Wi--Fi units
(SYSTXBBECW01--A and SYSTXBBECC01--A). Note: You must have Wi--Fi
enabled for the indicator to appear.
If you have uploaded a photo to the control (see Pg. 41), it will be displayed until
you touch the display. You will then be taken to the Home Screen.

2
Wi--Fi Connectivity Status
A150238
With the SYSTXBBECW01--A and SYSTXBBECC01--A Evolution Connex
Wi--Fi®models, connectivity status to the home Wi--Fi network and MyEvolution
Server is displayed in the top right hand corner of the Home Screen.
When the Evolution Connex control is connected to the home Wi--Fi network and
the MyEvolution Server, the signal strength bars will be displayed in white as
depicted in the image above. Connection strength to the home Wi--Fi network will
be indicated by the number of solid white bars displayed.
Strong Connection Limited Connection No Connection
A13259
SPressing on the Connectivity Status bars from the Home Screen will
allow you to view the Remote Access Status screen.

3
A13266
SNOTE: If the Evolution Connex control is connected to the home Wi--
Fi network but loses connection to the MyEvolution Server, the signal
strength bar will be displayed in red as depicted in the image below.
Connection strength to the home Wi--Fi network will continue to be
displayed by the number of solid bars. If this problem persists, please
contact Bryant Customer Relations at 1--800--4284326 for assistance.
Strong Connection Limited Connection No Connection
A13261
SPressing on the Connectivity Status bars from the Home Screen will
allow you to view the Remote Access Status screen.

4
A13267
Information Buttons
On the bottom of some screens will be an information icon. By pressing the
information icon, a text box will display to show what interactions are available on
that particular screen. To close the text box, touch the text box.
A14279

5
MAIN SCREEN
The main screen is where most interactions will take place. Touch anywhere on the
Home screen to arrive at the main screen.
System Mode
SOnce in the main screen,
STo access your system mode touch the MODE label located in the upper
right of the control.
SThe drop--down menu will allow you to choose between AUTO, HEAT,
COOL, FAN ONLY and OFF, depending on the equipment installed in
your system.
SIf OFF is selected your system will not control temperatures, humidity,
or fan.
SIf AUTO is selected, the Evolution Connex Control automatically
switches between heating and cooling to maintain your comfort during
transitional seasons.
NOTE: To save energy, AUTO mode is intended to switch between Heating and
Cooling modes from day to day, not within an hour, for example, time frame. The
Evolution®Zoning System is not designed to satisfy simultaneous Heat and Cool
demands in different zones, in an effort to limit the effect of competing Heat/Cool
zones on excess energy usage.
SIf HEAT is selected then the Evolution Connex Control operates only the
heating system.
SIf COOL is selected then the Evolution Connex Control operates only
the cooling system.
SIf FAN ONLY is selected, then the Evolution Connex Control operates
the indoor fan but heating, cooling, humidification or dehumidification
will not take place.

6
Set Day and Time
STo set the day and time for your home screen enter the main screen by
touching anywhere on the control.
STouch the DAY and TIME label located at the top middle of the screen
or access by going through the menu screen (see Pg. 31).
STo set the HOUR, MINUTE, MONTH, DAY,orYEAR touch the fea-
ture you wish to change.
SUse the Up (Y) and Down (B) buttons to make the appropriate
changes.
SWhen you have completed all of the settings, touch SAVE.
SIf you make a mistake you may touch CANCEL and begin again.
Adjust Temperature (Temporary Hold)
The Evolution Connex Control allows you to temporarily override your
programmed schedule by adjusting the indoor temperature at any time to meet your
needs.
Adjusting Comfort Profiles (See Comfort Profiles on Pg. 11)
STo adjust the comfort activity, enter the main screen by touching any-
where on the control.
STouch the activity/top button under the Touch ’N’ Go®feature on the
left side of the screen; then select the desired activity of HOME, AWAY,
SLEEP,orWAKE.
SUse the Up (Y) and Down (B) buttons to change the time to temporar-
ily hold the desired temperature in 15 minute increments.
SWhen the correct time interval is displayed, touch DONE.
STo return to the scheduled program, touch HOLD UNTIL,andthen
select PER SCHEDULE.

7
Adjusting Heating
STo adjust the heating temperature, enter the main screen by touching
anywhere on the control.
SWith the system in either AUTO or HEAT mode, use the Up (Y)and
Down (B) buttons to set the desired temperature.
SOn the left hand side of the screen, the comfort profile will switch to
manual, and the system will be placed in a temporary hold.
SUse the Up (Y) and Down (B) buttons to change the time to temporar-
ily hold the desired temperature in 15 minute increments.
SWhen the correct time interval is displayed, touch DONE.
STo return to the scheduled program, touch HOLD UNTIL,andthen
select PER SCHEDULE.
Adjusting Cooling
STo adjust the cooling temperature, enter the main screen by touching
anywhere on the control.
SWith the system in either AUTO or COOL mode, use the Up (Y)and
Down (B) buttons to set the desired temperature.
SOn the left hand side of the screen, the comfort profile will switch to
manual, and the system will be placed in a temporary hold.
SUse the Up (Y) and Down (B) buttons to change the time to temporar-
ily hold the desired temperature in 15 minute increments.
SWhen the correct time interval is displayed, touch DONE.
STo return to the scheduled program, touch HOLD UNTIL,andthen
select PER SCHEDULE.
Adjust Temperature (Permanent Hold)
The Evolution Connex Control allows you to permanently override your
programmed schedule by adjusting the indoor temperature at any time to meet your
needs.

8
Adjusting Comfort Profiles (See Comfort Profiles on Pg. 11)
STo adjust the comfort activity, enter the main screen by touching any-
where on the control.
STouch the activity under the Touch ’N’ Gotfeature on the left side of
the screen; then select the desired activity of HOME, AWAY, SLEEP, or
WAKE.
STouch the HOLD UNTIL button, then touch HOLD.
STo return to the scheduled program touch HOLD, and then touch PER
SCHEDULE.
Adjusting Heating
STo adjust the heating temperature, enter the main screen by touching
anywhere on the control.
SWith the system in either AUTO or HEAT mode, use the Up (Y)and
Down (B) buttons to set the desired temperature.
SOn the left hand side of the screen, the comfort profile will switch to
MANUAL.
STouch the HOLD UNTIL button, then touch HOLD.
STo return to the scheduled program, touch HOLD, and then touch PER
SCHEDULE.
Adjusting Cooling
STo adjust the cooling temperature, enter the main screen by touching
anywhere on the control.
SWith the system in either AUTO or COOL mode, use the Up (Y)and
Down (B) buttons to set the desired temperature.
SOn the left hand side of the screen, the comfort profile will switch to
MANUAL.
STouch the HOLD UNTIL button, then touch HOLD.

9
STo return to the scheduled program, touch HOLD, and then touch PER
SCHEDULE.
NOTE: For Multi--Zone Applications (Temporary and Permanent Hold options)
SFor added convenience in a multi--zone application, the Touch ’N’ Got
feature will also allow you select the desired activity of HOME or
AWAY for ALL ZONES.
A14287
SOnce you have selected the desired activity for ALL ZONES, you will
have the option to either permanently (HOLD)ortemporarily(HOLD
UNTIL) override your programmed schedule.
A14288
dSelecting the HOLD option will permanently override your pro-
grammed schedule until you CANCEL ALL ZONES.

10
dSelecting the HOLD UNTIL option will allow you to temporarily
override your programmed schedule.
dOnce selected, use the Up (Y) and Down (B) buttons to change the
time in 15 minute increments.
dWhen the correct time interval is displayed, touch DONE.
FEATURES
Adjust Fan Speed
The Features function of Evolution Connex Control allows you to adjust the fan
speed during continuous fan operation.
STo adjust the fan speed, enter the main screen by touching anywhere on
the control.
STouch FEATURES on the top left of the screen.
SA drop down menu will appear. Touch FAN selection.
SUse the Up (Y) and Down (B) buttons to set the fan to AUTO, LOW,
MEDIUM or HIGH, then touch SAVE. In zoned systems, the activity
settings will apply to the selected zone only.
SFor zoned systems, the selected fan speed will apply to the zone current-
ly displayed in the HOME and MAIN.
View Current Humidity Level
The Features function of Evolution Connex Control allows you to view the current
humidity level within the conditioned space.
SEnter the main screen by touching anywhere on the control.
STouch FEATURES on the top left of the screen.
SIn the drop down menu you will see your measured humidity levels
within the conditioned space.

11
MENU SCREEN
Your menu screen offers more features and control for your Evolution Connex
Control. Touch the menu button at the bottom right of the main screen.
COMFORT PROFILES
You will need to set the comfort profiles before you attempt to program your new
Evolution Connex Control.
SThe COMFORT PROFILES button includes settings for Temperature
and Fan Profiles, Humidity and Fresh Air Profiles, as well as Window
Protection Setup.
A14280
SSet your desired heating and cooling temperatures and your fan setting
using the TEMPERATURE AND FAN PROFILES for each activity.
In zoned systems, the activity settings will apply to the selected zone
only.

12
A14241
dFor example to change your HOME comfort profile, touch the
HOME icon.
dUse the Up (Y) and Down (B) buttons to change the fan settings,
heating and cooling temperatures. When you are done, press the
DONE button on the bottom right.
dDo the same thing to change the WAKE and SLEEP profiles.
dThe AWAY profile provides an extra feature called Advanced
Smart Setback. It allows the EvolutionrSystem to dynamically
determine the away temperature automatically to save the most
amount of money, yet reach your comfort settings when you return
home. Advanced Smart Setback may control the temperature some-
where in between the Away temperature limits. This is normal and
is intended to prevent excessive energy use.
dUse the Up (Y) and Down (B) buttons to change the fan settings
and temperature settings. The temperature settings are the range in
which you choose to keep your home conditioned while you are
away. The Advanced Smart Setback function will maintain your
temperature within this range.
SSet your desired humidity and fresh air (if applicable) using the HU-
MIDITY AND FRESH AIR PROFILES for each activity.

13
A14242
Home Comfort Profile Humidity Control
STouch WHEN AT HOME to set your humidity settings while the home
is occupied to enjoy superior comfort.
A14243
SIf you have a humidifier installed for your system, touch HEATING
HUMIDITY to set the desired humidity level within the home.
dYou will have the option to turn ON or OFF your humidifier from
this screen.

14
A14244
dOnce your Humidifier is turned ON, use the Up (Y) and Down (B)
buttons to set the desired humidity level between 5--45%.
dPress SAVE when finished, or CANCEL to discard any changes.
SNext, select your desired humidity level during cooling by touching
COOLING HUMIDITY.
A14245
dUse the Up (Y) and Down (B) buttons to set the desired dehumidi-
fication level between 46--58%.
dTouch YES or NO for the system to over--cool the conditioned
space by up to 3º F to remove as much humidity out of the air as
possible. The system will not over--cool past 70F.
dPress SAVE when finished, or CANCEL to discard any changes.
