BSVILLAGE SF 4000 User manual

MANUALE d'USO
Filtro a sabbia
monoblocco SF 4000
www.bsvillage.com

Safety Care for Children
1. Children, especially children younger than five years, are at high risk of drowning. Drowning occurs silently and quickly and can occur in as little as 2 in. (5 cm) of water.
2. Keep children in your direct sight, stay close, and actively supervise them when they are in or near this pool and when you are filling and emptying this pool.
3. When searching for a missing child, check the pool first, even if the child is thought to be in the house.
4. Locate pumps and filters in such a way that children cannot climb on them and gain access to the pool.
5. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times.
Swimming Pool Barriers
Very Important: Swimming pool barriers, which restrict access to the pool by small children, may be required by law. A barrier is necessary to provide protection against
potential drowning and near drowning. Barriers are not a substitute for constant supervision of children. Check state or local laws and codes before setting up pool.
Swimming Pool Equipments
1. The use of artificial pool lighting is at the discretion of the pool owner. Lighting, when installed, should be in accordance with Article 680 of the
National Electrical Code (NEC) or its latest approved edition and in consultation with a licensed electrical professional.
2. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
3. Do not place pool near or under overhead electrical lines.
4. All electrical components installed in and/ or adjacent to an aboveground/onground residential swimming pool shall be installed in accordance with and shall comply
with the requirements of the latest published edition of NFPA 70, National Electrical Code (NEC®) Article 680, Swimming pools, fountains, and similar installations,
and any state or local code.
Filter Pump Awareness
1. WARNING: Risk of Electric Shock. Connect only to a grounding type receptacle. This product is provided with a ground-fault circuit-interrupter. If replacement of
the plug or cord is needed, use only identical replacement parts.
2. WARNING: To reduce the risk of electric shock, replace damaged cord immediately.
3. WARNING: To reduce the risk of electric shock, do not use extension cord to connect unit to electric supply; provide a properly located outlet.
4. CAUTION: To reduce the risk of electric shock the pool must be installed no closer than 6 feet (1.8 m) from any electrical outlet. Do not place portable appliances
closer than 5 feet (1.5 m) from the pool.
5. CAUTION: This pump is for use with storable pools only. Do not use with permanently-installed pools. A storable pool is constructed so that it is capable of being
readily disassembled for storage and reassembled to its original integrity. A permanently-installed pool is constructed in or on the ground or in a building such that it
cannot be readily disassembled for storage.
6. CAUTION: For continued protection against possible electric shock this unit is to be mounted to the base in accordance with the installation instructions.
7. Do not bury cord. Locate cord to minimize abuse from lawn mowers, hedge trimmers, and other equipment.
8. The unit is provided with a ground-fault circuit-interrupter (GFCI). To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button.
Power should be restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the pump without the test button being
pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this pump. Disconnect the pump and have the problem corrected by
a qualified service representative before using.
9. The Filter Pump is to be assembled by an adult; care should be taken in the unpacking and assembly of the Filter Pump, this pool may contain accessible
potentially hazardous sharp edges or sharp points that are a necessary part of the function of the Filter Pump.
10. If a drain or suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration,
or drowning. Repair or replace the drain or suction outlet cover before allowing the pool to be used.. During nighttime pool use, artificial lighting shall be used to
illuminate all safety signs, ladders, steps, deck surfaces and walks.
11. The floor of the pool shall be visible at all times from the outside perimeter of the pool.
12. Post a list of emergency telephone numbers such as the nearest available police, fire, ambulance and/or rescue unit. These numbers are to be kept near the
telephone, which is closest to the pool.
13. Basic lifesaving equipment, including one of the following should be on hand at all times:
• A light, strong, rigid pole (shepherds crook) not less than twelve feet (12’) [366 cm] long.
• A minimum one-fourth inch (1/4”) [6.35 mm] diameter rope as long as one and one half (1-1/2) times the maximum width of the pool or fifty feet (50’) [15.24 meters],
whichever is less, which has been firmly attached to a Coast Guard-approved ring buoy having an outside diameter of approximately fifteen inches (15”) [38.1 cm],
or similarly approved flotation device.
14. Pool shall be located at a minimum distance of 6 ft (1.83 m) from any receptacle, and all 125-volt 15- and 20-ampere receptacles located within 20 ft (6.0 m) of the
pool shall be protected by a ground fault circuit interrupter (GFCI), where distances are by measuring the shortest path the supply cord of an appliance connected
to the receptacle would follow, without piercing a floor, wall, ceiling, doorway with hinged or sliding door, window opening, or other effective permanent barrier, to
the inside wall of the pool.
Circulation Systems
1. Installers shall follow written instructions regarding positioning of all equipment connected to the circulation systems.
2. The installer shall follow written instruction provided for operation of the circulation system components.
3. All circulation system components and pump that require replacement or servicing shall be installed according to the pump’s instruction manual.
4. Circulation equipment shall be installed per manufacturer’s instructions to provide proper mounting and support, to prevent damage from misalignment, settlement,
and vibration, and to minimize the potential for the accumulation of debris and moisture. Please refer to pump’s instruction manual.
Chemicals
For safety sake, ensure the deepest part of the pool is always visible. The user must properly maintain clarify of the pool water at all time. Check the pH and chlorine
levels periodically and make sure they are within the recommended limits. Additional water treatment chemicals might be needed from time to time. Have the water
sample tested by a local pool supply store to determine if additional chemical is needed. Turn on the filter pump system for at least six hours per day. Clean and replace
filter cartridge frequently. Replace only with genuine Polygroup®/ Summer Wave™Brand filter cartridge. Refer to the Filter Pump manual for additional water care
information.
Entrapment Risk
1. Entrapment Avoidance: There shall be no protrusions or other obstruction in the swimming area, which may cause entrapment or entanglement of the user. If
a suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration, or drowning.
Repair or replace the suction outlet cover before allowing the pool to be used.
2. DANGER! TO AVOID SERIOUS INJURY OR DEATH, CLOSE THE POOL OR SPA TO BATHERS IF ANY SUCTION OUTLET COVER/GRATE IS MISSING,
BROKEN OR INOPERATIVE.
3. Never play or swim near drains or suction fittings. Your body or hair may be trapped causing permanent injury or drowning.
4. Never enter the pool or spa if a suction fitting or drain cover is loose, broken, or missing.
5. Immediately notify the pool/spa owner or operator if you find a drain cover loose, broken or missing.
Drowning Risk
1. Keep unsupervised children from accessing the pool by installing fencing or other approved barrier around all sides of pool. State or local laws or codes may require
fencing or other approved barriers. Check state or local laws and codes before setting up pool.
2. Toys, chairs, tables or similar objects that a young child could climb shall be at least four feet (4’) [121.92 cm] from the pool. The pump filter system shall be positioned
so as to prevent it being used as a means of access to the pool by young children. Do not leave toys inside pool when finished using, since toys and similar items
might attract a child to the pool.
3. Position furniture (for example, tables, chairs) away from pool and so that children cannot climb on it to gain access to the pool.
Electrocution Risk
1. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
2. Do not place pool near or under overhead electrical lines.
First Aid
1. Keep a working phone and a list of emergency numbers near the pool.
2. Become certified in cardiopulmonary resuscitation (CPR). In the event of an emergency, immediate use of CPR can make a lifesaving difference.
Special Warning
1. Local building codes may require obtaining a building or electrical permit. Installer shall follow regulations on setback, barriers, devices and other conditions.
2. Safety signs shall comply with requirements of ANSI-Z535 and to use signal wording.
3. DO NOT attempt to assemble this pool in adverse weather conditions, windy conditions or when the temperature is below 60°F.
4. This is a storable filter pump, which should be disassembled and stored when temperatures are expected to fall below 32°F.
Extra Safety Warning
1. Adult supervision is always required.
2. Parents should learn CPR.
3. Keep all electrical radios, speakers and other appliances away from the swimming pool.
4. When you touch the filter, pump, or electrical parts, be sure the ground under your feet is “Bone Dry.”
5. All electrical outlets should have a GFCI and connections should be a minimum of 5 feet (1.52 m) from the outside perimeter of the wall of the pool.
From 5–10 feet (1.52–3.05 m), there should be either a fixed connection (outlet box) or twistlock connection with a GFCI.
6. Connect power cords to a 3-wire grounding-type outlet only.
7. Keep all breakable objects out of the pool area.
8. Alcohol consumption and pool activities do not mix. Never allow anyone to swim, dive or slide under the influence of alcohol or drugs.
9. Severe electrical shock could result if you install your pump or filter on a deck. The pump or filter could fall into the water, causing severe shock or electrocution.
10. Do not install on a deck or other surface at, above, or slightly below the top rail of the pool.
11. Do not use the filter pump during severe weather conditions, i.e. electrical storms, tornadoes, etc.
12. Be aware of overhead power lines when vacuuming your pool or using a telescoping pole.
13. Check regularly for signs of wear or loose bolts that could make the deck unsafe.
14. Please contact pool site dealer or manufacturer for additional safety signs if deemed necessary.
15. For pool service, select a certified pool professional.
For additional safety information, see www.APSP.org.
Consumer Awareness Booklets and Information Source
Contact: U.S. Consumer Product Safety Commission at www.CPSC.gov/cpscpub/pubs/pool/pdf, Pub. #362 “Safety Barrier Guidelines for Home Pools”.
1. The Sensible Way to Enjoy Your Aboveground/Onground Swimming Pool
2. Children Aren’t Waterproof
3. Layers of Protection
4. Pool and Spa Emergency Procedures for Infants and Children
5. Be Safety Aware Copies of the above brochures are available free from the APSP. Go to: www.APSP.org.
Safety Education Programs and Materials Educational programs and materials (i.e., seminars, workshops, brochures, videos, instructional guides) are available from
the APSP, other aquatic safety groups, and by private firms. As a means of communicating useful safety information to pool owners/operators, and users, industry
members are permitted to provide such information to owners/operators and to request or require owners/operators to sign a statement that they have received, read,
and will follow the guidelines.
Other sources of safety information:
• www.cdc.gov
• www.cpsc.gov
• www.drowningpreventionalliance.com
• www.nspf.org
• www.safekids.org
ANSI American National Standards Institute
25 West 43rd Street, New York NY 10036
Contact: 212-642-4900
www.ansi.org
APSP Association of Pool & Spa Professionals
(formerly National Spa and Pool Institute)
2111 Eisenhower Avenue, Alexandria VA 22314
Contact: 703-838-0083
www.apsp.org
ASME American Society of Mechanical Engineers
3 Park Avenue, New York NY 10016
Contact: 212-591-8562
www.asme.org
NSPI National Spa and Pool Institute (ss APSP)
UL Underwriters Laboratories
333 Pfingsten Road,Northbrook IL 60062-2096
Contact: 847272-8800
www.ul.com
NSF NSF International
789 N. Dixboro Rd,
P.O. Box 130140
Ann Arbor MI 48113-0140
734-769-8010
www.nsf.org
ASTM ASTM International (formerly American Society of Testing & Materials)
100 Barr Harbor Drive,West Conshohocken, PA 19428-2959
Contact: 610-832-9585
610-832-9555 (fax)
www.atsm.org
NEC National Electrical Code (see NFPA)
NFPA National Fire Protection Association
1 Batterymarch Park, Quincy MA 02269
Contact: 617-770-3000
www.nfpa.org
Filtration Systems
Any equipment connected to the circulation systems shall be positioned so as to prevent their being used as a means of access to the pool by young children. (See the
latest published edition of ANSI/ APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
Barrier
Barrier is necessary to provide protection against potential drowning and near drowning and that barriers are not a substitute for the constant supervision of children.
(See latest published edition of ANSI/APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.
Risk of Drowning, Entrapment, and Diving Accidents
Publications are available that describe the risk of drowning, entrapment, and diving accidents. Available publications related to pool safety include the Association of
Pool and Spa Professionals’ (APSP) booklets entitled: The Sensible Way to Enjoy Your Aboveground/ Onground Swimming Pool, Children Aren’t Waterproof, Pool and
Spa Emergency Procedures for Infants and Children, Layers of Protection, and the latest published edition of ANSI/APSP-8 Model Barrier Code for Residential
Swimming Pools, Spas, and Hot Tubs.
Installer Responsibilities
All of these components shall be positioned so as to prevent their being used as a means of access to the pool by young children.
(See thZarrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
TABLE OF CONTENTS
Warnings ......................................................................................................................................................... 3 ~ 6
Save These Instructions & Sand Pump Power Information & Part List ........................................................... 7 ~ 8
Setup Instructions & Operation Instruction ........................................................................................................ 9 ~ 13
Important Safety Information ........................................................................................................................... 14
Replacement Instruction .................................................................................................................................. 15
Pool Water Care .............................................................................................................................................. 15
Trouble Shooting Guide ................................................................................................................................... 16
Replacement Parts Ordering Information ........................................................................................................ 17
Sand Filter Pump Disassembly & Storage ...................................................................................................... 17
Asme Compliant Suction Fitting Information ................................................................................................... 18
2

IMPORTANT SAFETY INSTRUCTIONS
When installing and using this electrical equipment, basic safety precautions should always be followed, including the following :
READ AND FOLLOW ALL INSTRUCTIONS
Keep for Future Reference. Failure to follow these warnings and instructions can result in serious injury or death to users, especially children
NOTICE: CUSTOMERS THAT PURCHASE POOLS MAY BE REQUIRED BY LOCAL OR STATE LAW TO INCUR ADDITIONAL EXPENSES WHEN
INSTALLING A POOL, IN ORDER TO COMPLY WITH STATE OR LOCAL LAWS REGARDING FENCING AND OTHER SAFETY REQUIREMENTS.
CUSTOMERS SHOULD CONTACT THEIR LOCAL BUILDING CODE ENFORCEMENT OFFICE FOR FURTHER DETAILS.
DO NOT SIT ON
OR LAY OVER
POOL WALL
AVOID
ENTRAPMENT
You can be permanently
injured.
Stay away from
suction fittings.
You may drown.
WARNING
PREVENT
DROWNING
NO DIVING!
NO JUMPING!
Watch children
at all times.
Observe all Safety Rules.
Shallow Water - You can
be permanently injured.
DANGER
Safety Care for Children
1. Children, especially children younger than five years, are at high risk of drowning. Drowning occurs silently and quickly and can occur in as little as 2 in. (5 cm) of water.
2. Keep children in your direct sight, stay close, and actively supervise them when they are in or near this pool and when you are filling and emptying this pool.
3. When searching for a missing child, check the pool first, even if the child is thought to be in the house.
4. Locate pumps and filters in such a way that children cannot climb on them and gain access to the pool.
5. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times.
Swimming Pool Barriers
Very Important: Swimming pool barriers, which restrict access to the pool by small children, may be required by law. A barrier is necessary to provide protection against
potential drowning and near drowning. Barriers are not a substitute for constant supervision of children. Check state or local laws and codes before setting up pool.
Swimming Pool Equipments
1. The use of artificial pool lighting is at the discretion of the pool owner. Lighting, when installed, should be in accordance with Article 680 of the
National Electrical Code (NEC) or its latest approved edition and in consultation with a licensed electrical professional.
2. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
3. Do not place pool near or under overhead electrical lines.
4. All electrical components installed in and/ or adjacent to an aboveground/onground residential swimming pool shall be installed in accordance with and shall comply
with the requirements of the latest published edition of NFPA 70, National Electrical Code (NEC®) Article 680, Swimming pools, fountains, and similar installations,
and any state or local code.
Filter Pump Awareness
1. WARNING: Risk of Electric Shock. Connect only to a grounding type receptacle. This product is provided with a ground-fault circuit-interrupter. If replacement of
the plug or cord is needed, use only identical replacement parts.
2. WARNING: To reduce the risk of electric shock, replace damaged cord immediately.
3. WARNING: To reduce the risk of electric shock, do not use extension cord to connect unit to electric supply; provide a properly located outlet.
4. CAUTION: To reduce the risk of electric shock the pool must be installed no closer than 6 feet (1.8 m) from any electrical outlet. Do not place portable appliances
closer than 5 feet (1.5 m) from the pool.
5. CAUTION: This pump is for use with storable pools only. Do not use with permanently-installed pools. A storable pool is constructed so that it is capable of being
readily disassembled for storage and reassembled to its original integrity. A permanently-installed pool is constructed in or on the ground or in a building such that it
cannot be readily disassembled for storage.
WARNING
6. CAUTION: For continued protection against possible electric shock this unit is to be mounted to the base in accordance with the installation instructions.
7. Do not bury cord. Locate cord to minimize abuse from lawn mowers, hedge trimmers, and other equipment.
8. The unit is provided with a ground-fault circuit-interrupter (GFCI). To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button.
Power should be restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the pump without the test button being
pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this pump. Disconnect the pump and have the problem corrected by
a qualified service representative before using.
9. The Filter Pump is to be assembled by an adult; care should be taken in the unpacking and assembly of the Filter Pump, this pool may contain accessible
potentially hazardous sharp edges or sharp points that are a necessary part of the function of the Filter Pump.
10. If a drain or suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration,
or drowning. Repair or replace the drain or suction outlet cover before allowing the pool to be used.. During nighttime pool use, artificial lighting shall be used to
illuminate all safety signs, ladders, steps, deck surfaces and walks.
11. The floor of the pool shall be visible at all times from the outside perimeter of the pool.
12. Post a list of emergency telephone numbers such as the nearest available police, fire, ambulance and/or rescue unit. These numbers are to be kept near the
telephone, which is closest to the pool.
13. Basic lifesaving equipment, including one of the following should be on hand at all times:
• A light, strong, rigid pole (shepherds crook) not less than twelve feet (12’) [366 cm] long.
• A minimum one-fourth inch (1/4”) [6.35 mm] diameter rope as long as one and one half (1-1/2) times the maximum width of the pool or fifty feet (50’) [15.24 meters],
whichever is less, which has been firmly attached to a Coast Guard-approved ring buoy having an outside diameter of approximately fifteen inches (15”) [38.1 cm],
or similarly approved flotation device.
14. Pool shall be located at a minimum distance of 6 ft (1.83 m) from any receptacle, and all 125-volt 15- and 20-ampere receptacles located within 20 ft (6.0 m) of the
pool shall be protected by a ground fault circuit interrupter (GFCI), where distances are by measuring the shortest path the supply cord of an appliance connected
to the receptacle would follow, without piercing a floor, wall, ceiling, doorway with hinged or sliding door, window opening, or other effective permanent barrier, to
the inside wall of the pool.
Circulation Systems
1. Installers shall follow written instructions regarding positioning of all equipment connected to the circulation systems.
2. The installer shall follow written instruction provided for operation of the circulation system components.
3. All circulation system components and pump that require replacement or servicing shall be installed according to the pump’s instruction manual.
4. Circulation equipment shall be installed per manufacturer’s instructions to provide proper mounting and support, to prevent damage from misalignment, settlement,
and vibration, and to minimize the potential for the accumulation of debris and moisture. Please refer to pump’s instruction manual.
Chemicals
For safety sake, ensure the deepest part of the pool is always visible. The user must properly maintain clarify of the pool water at all time. Check the pH and chlorine
levels periodically and make sure they are within the recommended limits. Additional water treatment chemicals might be needed from time to time. Have the water
sample tested by a local pool supply store to determine if additional chemical is needed. Turn on the filter pump system for at least six hours per day. Clean and replace
filter cartridge frequently. Replace only with genuine Polygroup®/ Summer Wave™Brand filter cartridge. Refer to the Filter Pump manual for additional water care
information.
Entrapment Risk
1. Entrapment Avoidance: There shall be no protrusions or other obstruction in the swimming area, which may cause entrapment or entanglement of the user. If
a suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration, or drowning.
Repair or replace the suction outlet cover before allowing the pool to be used.
2. DANGER! TO AVOID SERIOUS INJURY OR DEATH, CLOSE THE POOL OR SPA TO BATHERS IF ANY SUCTION OUTLET COVER/GRATE IS MISSING,
BROKEN OR INOPERATIVE.
3. Never play or swim near drains or suction fittings. Your body or hair may be trapped causing permanent injury or drowning.
4. Never enter the pool or spa if a suction fitting or drain cover is loose, broken, or missing.
5. Immediately notify the pool/spa owner or operator if you find a drain cover loose, broken or missing.
Drowning Risk
1. Keep unsupervised children from accessing the pool by installing fencing or other approved barrier around all sides of pool. State or local laws or codes may require
fencing or other approved barriers. Check state or local laws and codes before setting up pool.
2. Toys, chairs, tables or similar objects that a young child could climb shall be at least four feet (4’) [121.92 cm] from the pool. The pump filter system shall be positioned
so as to prevent it being used as a means of access to the pool by young children. Do not leave toys inside pool when finished using, since toys and similar items
might attract a child to the pool.
3. Position furniture (for example, tables, chairs) away from pool and so that children cannot climb on it to gain access to the pool.
Electrocution Risk
1. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
2. Do not place pool near or under overhead electrical lines.
First Aid
1. Keep a working phone and a list of emergency numbers near the pool.
2. Become certified in cardiopulmonary resuscitation (CPR). In the event of an emergency, immediate use of CPR can make a lifesaving difference.
Special Warning
1. Local building codes may require obtaining a building or electrical permit. Installer shall follow regulations on setback, barriers, devices and other conditions.
2. Safety signs shall comply with requirements of ANSI-Z535 and to use signal wording.
3. DO NOT attempt to assemble this pool in adverse weather conditions, windy conditions or when the temperature is below 60°F.
4. This is a storable filter pump, which should be disassembled and stored when temperatures are expected to fall below 32°F.
Extra Safety Warning
1. Adult supervision is always required.
2. Parents should learn CPR.
3. Keep all electrical radios, speakers and other appliances away from the swimming pool.
4. When you touch the filter, pump, or electrical parts, be sure the ground under your feet is “Bone Dry.”
5. All electrical outlets should have a GFCI and connections should be a minimum of 5 feet (1.52 m) from the outside perimeter of the wall of the pool.
From 5–10 feet (1.52–3.05 m), there should be either a fixed connection (outlet box) or twistlock connection with a GFCI.
6. Connect power cords to a 3-wire grounding-type outlet only.
7. Keep all breakable objects out of the pool area.
8. Alcohol consumption and pool activities do not mix. Never allow anyone to swim, dive or slide under the influence of alcohol or drugs.
9. Severe electrical shock could result if you install your pump or filter on a deck. The pump or filter could fall into the water, causing severe shock or electrocution.
10. Do not install on a deck or other surface at, above, or slightly below the top rail of the pool.
11. Do not use the filter pump during severe weather conditions, i.e. electrical storms, tornadoes, etc.
12. Be aware of overhead power lines when vacuuming your pool or using a telescoping pole.
13. Check regularly for signs of wear or loose bolts that could make the deck unsafe.
14. Please contact pool site dealer or manufacturer for additional safety signs if deemed necessary.
15. For pool service, select a certified pool professional.
For additional safety information, see www.APSP.org.
Consumer Awareness Booklets and Information Source
Contact: U.S. Consumer Product Safety Commission at www.CPSC.gov/cpscpub/pubs/pool/pdf, Pub. #362 “Safety Barrier Guidelines for Home Pools”.
1. The Sensible Way to Enjoy Your Aboveground/Onground Swimming Pool
2. Children Aren’t Waterproof
3. Layers of Protection
4. Pool and Spa Emergency Procedures for Infants and Children
5. Be Safety Aware Copies of the above brochures are available free from the APSP. Go to: www.APSP.org.
Safety Education Programs and Materials Educational programs and materials (i.e., seminars, workshops, brochures, videos, instructional guides) are available from
the APSP, other aquatic safety groups, and by private firms. As a means of communicating useful safety information to pool owners/operators, and users, industry
members are permitted to provide such information to owners/operators and to request or require owners/operators to sign a statement that they have received, read,
and will follow the guidelines.
Other sources of safety information:
• www.cdc.gov
• www.cpsc.gov
• www.drowningpreventionalliance.com
• www.nspf.org
• www.safekids.org
ANSI American National Standards Institute
25 West 43rd Street, New York NY 10036
Contact: 212-642-4900
www.ansi.org
APSP Association of Pool & Spa Professionals
(formerly National Spa and Pool Institute)
2111 Eisenhower Avenue, Alexandria VA 22314
Contact: 703-838-0083
www.apsp.org
ASME American Society of Mechanical Engineers
3 Park Avenue, New York NY 10016
Contact: 212-591-8562
www.asme.org
NSPI National Spa and Pool Institute (ss APSP)
UL Underwriters Laboratories
333 Pfingsten Road,Northbrook IL 60062-2096
Contact: 847272-8800
www.ul.com
NSF NSF International
789 N. Dixboro Rd,
P.O. Box 130140
Ann Arbor MI 48113-0140
734-769-8010
www.nsf.org
ASTM ASTM International (formerly American Society of Testing & Materials)
100 Barr Harbor Drive,West Conshohocken, PA 19428-2959
Contact: 610-832-9585
610-832-9555 (fax)
www.atsm.org
NEC National Electrical Code (see NFPA)
NFPA National Fire Protection Association
1 Batterymarch Park, Quincy MA 02269
Contact: 617-770-3000
www.nfpa.org
Filtration Systems
Any equipment connected to the circulation systems shall be positioned so as to prevent their being used as a means of access to the pool by young children. (See the
latest published edition of ANSI/ APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
Barrier
Barrier is necessary to provide protection against potential drowning and near drowning and that barriers are not a substitute for the constant supervision of children.
(See latest published edition of ANSI/APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.
Risk of Drowning, Entrapment, and Diving Accidents
Publications are available that describe the risk of drowning, entrapment, and diving accidents. Available publications related to pool safety include the Association of
Pool and Spa Professionals’ (APSP) booklets entitled: The Sensible Way to Enjoy Your Aboveground/ Onground Swimming Pool, Children Aren’t Waterproof, Pool and
Spa Emergency Procedures for Infants and Children, Layers of Protection, and the latest published edition of ANSI/APSP-8 Model Barrier Code for Residential
Swimming Pools, Spas, and Hot Tubs.
Installer Responsibilities
All of these components shall be positioned so as to prevent their being used as a means of access to the pool by young children.
(See thZarrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
3

Safety Care for Children
1. Children, especially children younger than five years, are at high risk of drowning. Drowning occurs silently and quickly and can occur in as little as 2 in. (5 cm) of water.
2. Keep children in your direct sight, stay close, and actively supervise them when they are in or near this pool and when you are filling and emptying this pool.
3. When searching for a missing child, check the pool first, even if the child is thought to be in the house.
4. Locate pumps and filters in such a way that children cannot climb on them and gain access to the pool.
5. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times.
Swimming Pool Barriers
Very Important: Swimming pool barriers, which restrict access to the pool by small children, may be required by law. A barrier is necessary to provide protection against
potential drowning and near drowning. Barriers are not a substitute for constant supervision of children. Check state or local laws and codes before setting up pool.
Swimming Pool Equipments
1. The use of artificial pool lighting is at the discretion of the pool owner. Lighting, when installed, should be in accordance with Article 680 of the
National Electrical Code (NEC) or its latest approved edition and in consultation with a licensed electrical professional.
2. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
3. Do not place pool near or under overhead electrical lines.
4. All electrical components installed in and/ or adjacent to an aboveground/onground residential swimming pool shall be installed in accordance with and shall comply
with the requirements of the latest published edition of NFPA 70, National Electrical Code (NEC®) Article 680, Swimming pools, fountains, and similar installations,
and any state or local code.
Filter Pump Awareness
1. WARNING: Risk of Electric Shock. Connect only to a grounding type receptacle. This product is provided with a ground-fault circuit-interrupter. If replacement of
the plug or cord is needed, use only identical replacement parts.
2. WARNING: To reduce the risk of electric shock, replace damaged cord immediately.
3. WARNING: To reduce the risk of electric shock, do not use extension cord to connect unit to electric supply; provide a properly located outlet.
4. CAUTION: To reduce the risk of electric shock the pool must be installed no closer than 6 feet (1.8 m) from any electrical outlet. Do not place portable appliances
closer than 5 feet (1.5 m) from the pool.
5. CAUTION: This pump is for use with storable pools only. Do not use with permanently-installed pools. A storable pool is constructed so that it is capable of being
readily disassembled for storage and reassembled to its original integrity. A permanently-installed pool is constructed in or on the ground or in a building such that it
cannot be readily disassembled for storage.
6. CAUTION: For continued protection against possible electric shock this unit is to be mounted to the base in accordance with the installation instructions.
7. Do not bury cord. Locate cord to minimize abuse from lawn mowers, hedge trimmers, and other equipment.
8. The unit is provided with a ground-fault circuit-interrupter (GFCI). To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button.
Power should be restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the pump without the test button being
pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this pump. Disconnect the pump and have the problem corrected by
a qualified service representative before using.
9. The Filter Pump is to be assembled by an adult; care should be taken in the unpacking and assembly of the Filter Pump, this pool may contain accessible
potentially hazardous sharp edges or sharp points that are a necessary part of the function of the Filter Pump.
10. If a drain or suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration,
or drowning. Repair or replace the drain or suction outlet cover before allowing the pool to be used.. During nighttime pool use, artificial lighting shall be used to
illuminate all safety signs, ladders, steps, deck surfaces and walks.
11. The floor of the pool shall be visible at all times from the outside perimeter of the pool.
12. Post a list of emergency telephone numbers such as the nearest available police, fire, ambulance and/or rescue unit. These numbers are to be kept near the
telephone, which is closest to the pool.
13. Basic lifesaving equipment, including one of the following should be on hand at all times:
• A light, strong, rigid pole (shepherds crook) not less than twelve feet (12’) [366 cm] long.
• A minimum one-fourth inch (1/4”) [6.35 mm] diameter rope as long as one and one half (1-1/2) times the maximum width of the pool or fifty feet (50’) [15.24 meters],
whichever is less, which has been firmly attached to a Coast Guard-approved ring buoy having an outside diameter of approximately fifteen inches (15”) [38.1 cm],
or similarly approved flotation device.
14. Pool shall be located at a minimum distance of 6 ft (1.83 m) from any receptacle, and all 125-volt 15- and 20-ampere receptacles located within 20 ft (6.0 m) of the
pool shall be protected by a ground fault circuit interrupter (GFCI), where distances are by measuring the shortest path the supply cord of an appliance connected
to the receptacle would follow, without piercing a floor, wall, ceiling, doorway with hinged or sliding door, window opening, or other effective permanent barrier, to
the inside wall of the pool.
Circulation Systems
1. Installers shall follow written instructions regarding positioning of all equipment connected to the circulation systems.
2. The installer shall follow written instruction provided for operation of the circulation system components.
3. All circulation system components and pump that require replacement or servicing shall be installed according to the pump’s instruction manual.
4. Circulation equipment shall be installed per manufacturer’s instructions to provide proper mounting and support, to prevent damage from misalignment, settlement,
and vibration, and to minimize the potential for the accumulation of debris and moisture. Please refer to pump’s instruction manual.
Chemicals
For safety sake, ensure the deepest part of the pool is always visible. The user must properly maintain clarify of the pool water at all time. Check the pH and chlorine
levels periodically and make sure they are within the recommended limits. Additional water treatment chemicals might be needed from time to time. Have the water
sample tested by a local pool supply store to determine if additional chemical is needed. Turn on the filter pump system for at least six hours per day. Clean and
replace filter cartridge frequently. Replace only with genuine / Summer Wave™Brand filter cartridge. Refer to the Filter Pump manual for additional water care
information.
Entrapment Risk
1. Entrapment Avoidance: There shall be no protrusions or other obstruction in the swimming area, which may cause entrapment or entanglement of the user. If
a suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration, or drowning.
Repair or replace the suction outlet cover before allowing the pool to be used.
2. DANGER! TO AVOID SERIOUS INJURY OR DEATH, CLOSE THE POOL OR SPA TO BATHERS IF ANY SUCTION OUTLET COVER/GRATE IS MISSING,
BROKEN OR INOPERATIVE.
3. Never play or swim near drains or suction fittings. Your body or hair may be trapped causing permanent injury or drowning.
4. Never enter the pool or spa if a suction fitting or drain cover is loose, broken, or missing.
5. Immediately notify the pool/spa owner or operator if you find a drain cover loose, broken or missing.
Drowning Risk
1. Keep unsupervised children from accessing the pool by installing fencing or other approved barrier around all sides of pool. State or local laws or codes may require
fencing or other approved barriers. Check state or local laws and codes before setting up pool.
2. Toys, chairs, tables or similar objects that a young child could climb shall be at least four feet (4’) [121.92 cm] from the pool. The pump filter system shall be positioned
so as to prevent it being used as a means of access to the pool by young children. Do not leave toys inside pool when finished using, since toys and similar items
might attract a child to the pool.
3. Position furniture (for example, tables, chairs) away from pool and so that children cannot climb on it to gain access to the pool.
Electrocution Risk
1. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
2. Do not place pool near or under overhead electrical lines.
First Aid
1. Keep a working phone and a list of emergency numbers near the pool.
2. Become certified in cardiopulmonary resuscitation (CPR). In the event of an emergency, immediate use of CPR can make a lifesaving difference.
Special Warning
1. Local building codes may require obtaining a building or electrical permit. Installer shall follow regulations on setback, barriers, devices and other conditions.
2. Safety signs shall comply with requirements of ANSI-Z535 and to use signal wording.
3. DO NOT attempt to assemble this pool in adverse weather conditions, windy conditions or when the temperature is below 60°F.
4. This is a storable filter pump, which should be disassembled and stored when temperatures are expected to fall below 32°F.
Extra Safety Warning
1. Adult supervision is always required.
2. Parents should learn CPR.
3. Keep all electrical radios, speakers and other appliances away from the swimming pool.
4. When you touch the filter, pump, or electrical parts, be sure the ground under your feet is “Bone Dry.”
5. All electrical outlets should have a GFCI and connections should be a minimum of 5 feet (1.52 m) from the outside perimeter of the wall of the pool.
From 5–10 feet (1.52–3.05 m), there should be either a fixed connection (outlet box) or twistlock connection with a GFCI.
6. Connect power cords to a 3-wire grounding-type outlet only.
7. Keep all breakable objects out of the pool area.
8. Alcohol consumption and pool activities do not mix. Never allow anyone to swim, dive or slide under the influence of alcohol or drugs.
9. Severe electrical shock could result if you install your pump or filter on a deck. The pump or filter could fall into the water, causing severe shock or electrocution.
10. Do not install on a deck or other surface at, above, or slightly below the top rail of the pool.
11. Do not use the filter pump during severe weather conditions, i.e. electrical storms, tornadoes, etc.
12. Be aware of overhead power lines when vacuuming your pool or using a telescoping pole.
13. Check regularly for signs of wear or loose bolts that could make the deck unsafe.
14. Please contact pool site dealer or manufacturer for additional safety signs if deemed necessary.
15. For pool service, select a certified pool professional.
For additional safety information, see www.APSP.org.
Consumer Awareness Booklets and Information Source
Contact: U.S. Consumer Product Safety Commission at www.CPSC.gov/cpscpub/pubs/pool/pdf, Pub. #362 “Safety Barrier Guidelines for Home Pools”.
1. The Sensible Way to Enjoy Your Aboveground/Onground Swimming Pool
2. Children Aren’t Waterproof
3. Layers of Protection
4. Pool and Spa Emergency Procedures for Infants and Children
5. Be Safety Aware Copies of the above brochures are available free from the APSP. Go to: www.APSP.org.
Safety Education Programs and Materials Educational programs and materials (i.e., seminars, workshops, brochures, videos, instructional guides) are available from
the APSP, other aquatic safety groups, and by private firms. As a means of communicating useful safety information to pool owners/operators, and users, industry
members are permitted to provide such information to owners/operators and to request or require owners/operators to sign a statement that they have received, read,
and will follow the guidelines.
Other sources of safety information:
• www.cdc.gov
• www.cpsc.gov
• www.drowningpreventionalliance.com
• www.nspf.org
• www.safekids.org
ANSI American National Standards Institute
25 West 43rd Street, New York NY 10036
Contact: 212-642-4900
www.ansi.org
APSP Association of Pool & Spa Professionals
(formerly National Spa and Pool Institute)
2111 Eisenhower Avenue, Alexandria VA 22314
Contact: 703-838-0083
www.apsp.org
ASME American Society of Mechanical Engineers
3 Park Avenue, New York NY 10016
Contact: 212-591-8562
www.asme.org
NSPI National Spa and Pool Institute (ss APSP)
UL Underwriters Laboratories
333 Pfingsten Road,Northbrook IL 60062-2096
Contact: 847272-8800
www.ul.com
NSF NSF International
789 N. Dixboro Rd,
P.O. Box 130140
Ann Arbor MI 48113-0140
734-769-8010
www.nsf.org
ASTM ASTM International (formerly American Society of Testing & Materials)
100 Barr Harbor Drive,West Conshohocken, PA 19428-2959
Contact: 610-832-9585
610-832-9555 (fax)
www.atsm.org
NEC National Electrical Code (see NFPA)
NFPA National Fire Protection Association
1 Batterymarch Park, Quincy MA 02269
Contact: 617-770-3000
www.nfpa.org
Filtration Systems
Any equipment connected to the circulation systems shall be positioned so as to prevent their being used as a means of access to the pool by young children. (See the
latest published edition of ANSI/ APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
Barrier
Barrier is necessary to provide protection against potential drowning and near drowning and that barriers are not a substitute for the constant supervision of children.
(See latest published edition of ANSI/APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.
Risk of Drowning, Entrapment, and Diving Accidents
Publications are available that describe the risk of drowning, entrapment, and diving accidents. Available publications related to pool safety include the Association of
Pool and Spa Professionals’ (APSP) booklets entitled: The Sensible Way to Enjoy Your Aboveground/ Onground Swimming Pool, Children Aren’t Waterproof, Pool and
Spa Emergency Procedures for Infants and Children, Layers of Protection, and the latest published edition of ANSI/APSP-8 Model Barrier Code for Residential
Swimming Pools, Spas, and Hot Tubs.
Installer Responsibilities
All of these components shall be positioned so as to prevent their being used as a means of access to the pool by young children.
(See thZarrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
4

Safety Care for Children
1. Children, especially children younger than five years, are at high risk of drowning. Drowning occurs silently and quickly and can occur in as little as 2 in. (5 cm) of water.
2. Keep children in your direct sight, stay close, and actively supervise them when they are in or near this pool and when you are filling and emptying this pool.
3. When searching for a missing child, check the pool first, even if the child is thought to be in the house.
4. Locate pumps and filters in such a way that children cannot climb on them and gain access to the pool.
5. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times.
Swimming Pool Barriers
Very Important: Swimming pool barriers, which restrict access to the pool by small children, may be required by law. A barrier is necessary to provide protection against
potential drowning and near drowning. Barriers are not a substitute for constant supervision of children. Check state or local laws and codes before setting up pool.
Swimming Pool Equipments
1. The use of artificial pool lighting is at the discretion of the pool owner. Lighting, when installed, should be in accordance with Article 680 of the
National Electrical Code (NEC) or its latest approved edition and in consultation with a licensed electrical professional.
2. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
3. Do not place pool near or under overhead electrical lines.
4. All electrical components installed in and/ or adjacent to an aboveground/onground residential swimming pool shall be installed in accordance with and shall comply
with the requirements of the latest published edition of NFPA 70, National Electrical Code (NEC®) Article 680, Swimming pools, fountains, and similar installations,
and any state or local code.
Filter Pump Awareness
1. WARNING: Risk of Electric Shock. Connect only to a grounding type receptacle. This product is provided with a ground-fault circuit-interrupter. If replacement of
the plug or cord is needed, use only identical replacement parts.
2. WARNING: To reduce the risk of electric shock, replace damaged cord immediately.
3. WARNING: To reduce the risk of electric shock, do not use extension cord to connect unit to electric supply; provide a properly located outlet.
4. CAUTION: To reduce the risk of electric shock the pool must be installed no closer than 6 feet (1.8 m) from any electrical outlet. Do not place portable appliances
closer than 5 feet (1.5 m) from the pool.
5. CAUTION: This pump is for use with storable pools only. Do not use with permanently-installed pools. A storable pool is constructed so that it is capable of being
readily disassembled for storage and reassembled to its original integrity. A permanently-installed pool is constructed in or on the ground or in a building such that it
cannot be readily disassembled for storage.
6. CAUTION: For continued protection against possible electric shock this unit is to be mounted to the base in accordance with the installation instructions.
7. Do not bury cord. Locate cord to minimize abuse from lawn mowers, hedge trimmers, and other equipment.
8. The unit is provided with a ground-fault circuit-interrupter (GFCI). To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button.
Power should be restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the pump without the test button being
pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this pump. Disconnect the pump and have the problem corrected by
a qualified service representative before using.
9. The Filter Pump is to be assembled by an adult; care should be taken in the unpacking and assembly of the Filter Pump, this pool may contain accessible
potentially hazardous sharp edges or sharp points that are a necessary part of the function of the Filter Pump.
10. If a drain or suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration,
or drowning. Repair or replace the drain or suction outlet cover before allowing the pool to be used.. During nighttime pool use, artificial lighting shall be used to
illuminate all safety signs, ladders, steps, deck surfaces and walks.
11. The floor of the pool shall be visible at all times from the outside perimeter of the pool.
12. Post a list of emergency telephone numbers such as the nearest available police, fire, ambulance and/or rescue unit. These numbers are to be kept near the
telephone, which is closest to the pool.
13. Basic lifesaving equipment, including one of the following should be on hand at all times:
• A light, strong, rigid pole (shepherds crook) not less than twelve feet (12’) [366 cm] long.
• A minimum one-fourth inch (1/4”) [6.35 mm] diameter rope as long as one and one half (1-1/2) times the maximum width of the pool or fifty feet (50’) [15.24 meters],
whichever is less, which has been firmly attached to a Coast Guard-approved ring buoy having an outside diameter of approximately fifteen inches (15”) [38.1 cm],
or similarly approved flotation device.
14. Pool shall be located at a minimum distance of 6 ft (1.83 m) from any receptacle, and all 125-volt 15- and 20-ampere receptacles located within 20 ft (6.0 m) of the
pool shall be protected by a ground fault circuit interrupter (GFCI), where distances are by measuring the shortest path the supply cord of an appliance connected
to the receptacle would follow, without piercing a floor, wall, ceiling, doorway with hinged or sliding door, window opening, or other effective permanent barrier, to
the inside wall of the pool.
Circulation Systems
1. Installers shall follow written instructions regarding positioning of all equipment connected to the circulation systems.
2. The installer shall follow written instruction provided for operation of the circulation system components.
3. All circulation system components and pump that require replacement or servicing shall be installed according to the pump’s instruction manual.
4. Circulation equipment shall be installed per manufacturer’s instructions to provide proper mounting and support, to prevent damage from misalignment, settlement,
and vibration, and to minimize the potential for the accumulation of debris and moisture. Please refer to pump’s instruction manual.
Chemicals
For safety sake, ensure the deepest part of the pool is always visible. The user must properly maintain clarify of the pool water at all time. Check the pH and chlorine
levels periodically and make sure they are within the recommended limits. Additional water treatment chemicals might be needed from time to time. Have the water
sample tested by a local pool supply store to determine if additional chemical is needed. Turn on the filter pump system for at least six hours per day. Clean and replace
filter cartridge frequently. Replace only with genuine Polygroup®/ Summer Wave™Brand filter cartridge. Refer to the Filter Pump manual for additional water care
information.
Entrapment Risk
1. Entrapment Avoidance: There shall be no protrusions or other obstruction in the swimming area, which may cause entrapment or entanglement of the user. If
a suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration, or drowning.
Repair or replace the suction outlet cover before allowing the pool to be used.
2. DANGER! TO AVOID SERIOUS INJURY OR DEATH, CLOSE THE POOL OR SPA TO BATHERS IF ANY SUCTION OUTLET COVER/GRATE IS MISSING,
BROKEN OR INOPERATIVE.
3. Never play or swim near drains or suction fittings. Your body or hair may be trapped causing permanent injury or drowning.
4. Never enter the pool or spa if a suction fitting or drain cover is loose, broken, or missing.
5. Immediately notify the pool/spa owner or operator if you find a drain cover loose, broken or missing.
Drowning Risk
1. Keep unsupervised children from accessing the pool by installing fencing or other approved barrier around all sides of pool. State or local laws or codes may require
fencing or other approved barriers. Check state or local laws and codes before setting up pool.
2. Toys, chairs, tables or similar objects that a young child could climb shall be at least four feet (4’) [121.92 cm] from the pool. The pump filter system shall be positioned
so as to prevent it being used as a means of access to the pool by young children. Do not leave toys inside pool when finished using, since toys and similar items
might attract a child to the pool.
3. Position furniture (for example, tables, chairs) away from pool and so that children cannot climb on it to gain access to the pool.
Electrocution Risk
1. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
2. Do not place pool near or under overhead electrical lines.
First Aid
1. Keep a working phone and a list of emergency numbers near the pool.
2. Become certified in cardiopulmonary resuscitation (CPR). In the event of an emergency, immediate use of CPR can make a lifesaving difference.
Special Warning
1. Local building codes may require obtaining a building or electrical permit. Installer shall follow regulations on setback, barriers, devices and other conditions.
2. Safety signs shall comply with requirements of ANSI-Z535 and to use signal wording.
3. DO NOT attempt to assemble this pool in adverse weather conditions, windy conditions or when the temperature is below 60°F.
4. This is a storable filter pump, which should be disassembled and stored when temperatures are expected to fall below 32°F.
Extra Safety Warning
1. Adult supervision is always required.
2. Parents should learn CPR.
3. Keep all electrical radios, speakers and other appliances away from the swimming pool.
4. When you touch the filter, pump, or electrical parts, be sure the ground under your feet is “Bone Dry.”
5. All electrical outlets should have a GFCI and connections should be a minimum of 5 feet (1.52 m) from the outside perimeter of the wall of the pool.
From 5–10 feet (1.52–3.05 m), there should be either a fixed connection (outlet box) or twistlock connection with a GFCI.
6. Connect power cords to a 3-wire grounding-type outlet only.
7. Keep all breakable objects out of the pool area.
8. Alcohol consumption and pool activities do not mix. Never allow anyone to swim, dive or slide under the influence of alcohol or drugs.
9. Severe electrical shock could result if you install your pump or filter on a deck. The pump or filter could fall into the water, causing severe shock or electrocution.
10. Do not install on a deck or other surface at, above, or slightly below the top rail of the pool.
11. Do not use the filter pump during severe weather conditions, i.e. electrical storms, tornadoes, etc.
12. Be aware of overhead power lines when vacuuming your pool or using a telescoping pole.
13. Check regularly for signs of wear or loose bolts that could make the deck unsafe.
14. Please contact pool site dealer or manufacturer for additional safety signs if deemed necessary.
15. For pool service, select a certified pool professional.
For additional safety information, see www.APSP.org.
Consumer Awareness Booklets and Information Source
Contact: U.S. Consumer Product Safety Commission at www.CPSC.gov/cpscpub/pubs/pool/pdf, Pub. #362 “Safety Barrier Guidelines for Home Pools”.
1. The Sensible Way to Enjoy Your Aboveground/Onground Swimming Pool
2. Children Aren’t Waterproof
3. Layers of Protection
4. Pool and Spa Emergency Procedures for Infants and Children
5. Be Safety Aware Copies of the above brochures are available free from the APSP. Go to: www.APSP.org.
Safety Education Programs and Materials Educational programs and materials (i.e., seminars, workshops, brochures, videos, instructional guides) are available from
the APSP, other aquatic safety groups, and by private firms. As a means of communicating useful safety information to pool owners/operators, and users, industry
members are permitted to provide such information to owners/operators and to request or require owners/operators to sign a statement that they have received, read,
and will follow the guidelines.
Other sources of safety information:
• www.cdc.gov
• www.cpsc.gov
• www.drowningpreventionalliance.com
• www.nspf.org
• www.safekids.org
ANSI American National Standards Institute
25 West 43rd Street, New York NY 10036
Contact: 212-642-4900
www.ansi.org
APSP Association of Pool & Spa Professionals
(formerly National Spa and Pool Institute)
2111 Eisenhower Avenue, Alexandria VA 22314
Contact: 703-838-0083
www.apsp.org
ASME American Society of Mechanical Engineers
3 Park Avenue, New York NY 10016
Contact: 212-591-8562
www.asme.org
NSPI National Spa and Pool Institute (ss APSP)
UL Underwriters Laboratories
333 Pfingsten Road,Northbrook IL 60062-2096
Contact: 847272-8800
www.ul.com
NSF NSF International
789 N. Dixboro Rd,
P.O. Box 130140
Ann Arbor MI 48113-0140
734-769-8010
www.nsf.org
ASTM ASTM International (formerly American Society of Testing & Materials)
100 Barr Harbor Drive,West Conshohocken, PA 19428-2959
Contact: 610-832-9585
610-832-9555 (fax)
www.atsm.org
NEC National Electrical Code (see NFPA)
NFPA National Fire Protection Association
1 Batterymarch Park, Quincy MA 02269
Contact: 617-770-3000
www.nfpa.org
Filtration Systems
Any equipment connected to the circulation systems shall be positioned so as to prevent their being used as a means of access to the pool by young children. (See the
latest published edition of ANSI/ APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
Barrier
Barrier is necessary to provide protection against potential drowning and near drowning and that barriers are not a substitute for the constant supervision of children.
(See latest published edition of ANSI/APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.
Risk of Drowning, Entrapment, and Diving Accidents
Publications are available that describe the risk of drowning, entrapment, and diving accidents. Available publications related to pool safety include the Association of
Pool and Spa Professionals’ (APSP) booklets entitled: The Sensible Way to Enjoy Your Aboveground/ Onground Swimming Pool, Children Aren’t Waterproof, Pool and
Spa Emergency Procedures for Infants and Children, Layers of Protection, and the latest published edition of ANSI/APSP-8 Model Barrier Code for Residential
Swimming Pools, Spas, and Hot Tubs.
Installer Responsibilities
All of these components shall be positioned so as to prevent their being used as a means of access to the pool by young children.
(See thZarrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
5

Safety Care for Children
1. Children, especially children younger than five years, are at high risk of drowning. Drowning occurs silently and quickly and can occur in as little as 2 in. (5 cm) of water.
2. Keep children in your direct sight, stay close, and actively supervise them when they are in or near this pool and when you are filling and emptying this pool.
3. When searching for a missing child, check the pool first, even if the child is thought to be in the house.
4. Locate pumps and filters in such a way that children cannot climb on them and gain access to the pool.
5. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times.
Swimming Pool Barriers
Very Important: Swimming pool barriers, which restrict access to the pool by small children, may be required by law. A barrier is necessary to provide protection against
potential drowning and near drowning. Barriers are not a substitute for constant supervision of children. Check state or local laws and codes before setting up pool.
Swimming Pool Equipments
1. The use of artificial pool lighting is at the discretion of the pool owner. Lighting, when installed, should be in accordance with Article 680 of the
National Electrical Code (NEC) or its latest approved edition and in consultation with a licensed electrical professional.
2. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
3. Do not place pool near or under overhead electrical lines.
4. All electrical components installed in and/ or adjacent to an aboveground/onground residential swimming pool shall be installed in accordance with and shall comply
with the requirements of the latest published edition of NFPA 70, National Electrical Code (NEC®) Article 680, Swimming pools, fountains, and similar installations,
and any state or local code.
Filter Pump Awareness
1. WARNING: Risk of Electric Shock. Connect only to a grounding type receptacle. This product is provided with a ground-fault circuit-interrupter. If replacement of
the plug or cord is needed, use only identical replacement parts.
2. WARNING: To reduce the risk of electric shock, replace damaged cord immediately.
3. WARNING: To reduce the risk of electric shock, do not use extension cord to connect unit to electric supply; provide a properly located outlet.
4. CAUTION: To reduce the risk of electric shock the pool must be installed no closer than 6 feet (1.8 m) from any electrical outlet. Do not place portable appliances
closer than 5 feet (1.5 m) from the pool.
5. CAUTION: This pump is for use with storable pools only. Do not use with permanently-installed pools. A storable pool is constructed so that it is capable of being
readily disassembled for storage and reassembled to its original integrity. A permanently-installed pool is constructed in or on the ground or in a building such that it
cannot be readily disassembled for storage.
6. CAUTION: For continued protection against possible electric shock this unit is to be mounted to the base in accordance with the installation instructions.
7. Do not bury cord. Locate cord to minimize abuse from lawn mowers, hedge trimmers, and other equipment.
8. The unit is provided with a ground-fault circuit-interrupter (GFCI). To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button.
Power should be restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the pump without the test button being
pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this pump. Disconnect the pump and have the problem corrected by
a qualified service representative before using.
9. The Filter Pump is to be assembled by an adult; care should be taken in the unpacking and assembly of the Filter Pump, this pool may contain accessible
potentially hazardous sharp edges or sharp points that are a necessary part of the function of the Filter Pump.
10. If a drain or suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration,
or drowning. Repair or replace the drain or suction outlet cover before allowing the pool to be used.. During nighttime pool use, artificial lighting shall be used to
illuminate all safety signs, ladders, steps, deck surfaces and walks.
11. The floor of the pool shall be visible at all times from the outside perimeter of the pool.
12. Post a list of emergency telephone numbers such as the nearest available police, fire, ambulance and/or rescue unit. These numbers are to be kept near the
telephone, which is closest to the pool.
13. Basic lifesaving equipment, including one of the following should be on hand at all times:
• A light, strong, rigid pole (shepherds crook) not less than twelve feet (12’) [366 cm] long.
• A minimum one-fourth inch (1/4”) [6.35 mm] diameter rope as long as one and one half (1-1/2) times the maximum width of the pool or fifty feet (50’) [15.24 meters],
whichever is less, which has been firmly attached to a Coast Guard-approved ring buoy having an outside diameter of approximately fifteen inches (15”) [38.1 cm],
or similarly approved flotation device.
14. Pool shall be located at a minimum distance of 6 ft (1.83 m) from any receptacle, and all 125-volt 15- and 20-ampere receptacles located within 20 ft (6.0 m) of the
pool shall be protected by a ground fault circuit interrupter (GFCI), where distances are by measuring the shortest path the supply cord of an appliance connected
to the receptacle would follow, without piercing a floor, wall, ceiling, doorway with hinged or sliding door, window opening, or other effective permanent barrier, to
the inside wall of the pool.
Circulation Systems
1. Installers shall follow written instructions regarding positioning of all equipment connected to the circulation systems.
2. The installer shall follow written instruction provided for operation of the circulation system components.
3. All circulation system components and pump that require replacement or servicing shall be installed according to the pump’s instruction manual.
4. Circulation equipment shall be installed per manufacturer’s instructions to provide proper mounting and support, to prevent damage from misalignment, settlement,
and vibration, and to minimize the potential for the accumulation of debris and moisture. Please refer to pump’s instruction manual.
Chemicals
For safety sake, ensure the deepest part of the pool is always visible. The user must properly maintain clarify of the pool water at all time. Check the pH and chlorine
levels periodically and make sure they are within the recommended limits. Additional water treatment chemicals might be needed from time to time. Have the water
sample tested by a local pool supply store to determine if additional chemical is needed. Turn on the filter pump system for at least six hours per day. Clean and replace
filter cartridge frequently. Replace only with genuine Polygroup®/ Summer Wave™Brand filter cartridge. Refer to the Filter Pump manual for additional water care
information.
Entrapment Risk
1. Entrapment Avoidance: There shall be no protrusions or other obstruction in the swimming area, which may cause entrapment or entanglement of the user. If
a suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration, or drowning.
Repair or replace the suction outlet cover before allowing the pool to be used.
2. DANGER! TO AVOID SERIOUS INJURY OR DEATH, CLOSE THE POOL OR SPA TO BATHERS IF ANY SUCTION OUTLET COVER/GRATE IS MISSING,
BROKEN OR INOPERATIVE.
3. Never play or swim near drains or suction fittings. Your body or hair may be trapped causing permanent injury or drowning.
4. Never enter the pool or spa if a suction fitting or drain cover is loose, broken, or missing.
5. Immediately notify the pool/spa owner or operator if you find a drain cover loose, broken or missing.
Drowning Risk
1. Keep unsupervised children from accessing the pool by installing fencing or other approved barrier around all sides of pool. State or local laws or codes may require
fencing or other approved barriers. Check state or local laws and codes before setting up pool.
2. Toys, chairs, tables or similar objects that a young child could climb shall be at least four feet (4’) [121.92 cm] from the pool. The pump filter system shall be positioned
so as to prevent it being used as a means of access to the pool by young children. Do not leave toys inside pool when finished using, since toys and similar items
might attract a child to the pool.
3. Position furniture (for example, tables, chairs) away from pool and so that children cannot climb on it to gain access to the pool.
Electrocution Risk
1. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
2. Do not place pool near or under overhead electrical lines.
First Aid
1. Keep a working phone and a list of emergency numbers near the pool.
2. Become certified in cardiopulmonary resuscitation (CPR). In the event of an emergency, immediate use of CPR can make a lifesaving difference.
Special Warning
1. Local building codes may require obtaining a building or electrical permit. Installer shall follow regulations on setback, barriers, devices and other conditions.
2. Safety signs shall comply with requirements of ANSI-Z535 and to use signal wording.
3. DO NOT attempt to assemble this pool in adverse weather conditions, windy conditions or when the temperature is below 60°F.
4. This is a storable filter pump, which should be disassembled and stored when temperatures are expected to fall below 32°F.
Extra Safety Warning
1. Adult supervision is always required.
2. Parents should learn CPR.
3. Keep all electrical radios, speakers and other appliances away from the swimming pool.
4. When you touch the filter, pump, or electrical parts, be sure the ground under your feet is “Bone Dry.”
5. All electrical outlets should have a GFCI and connections should be a minimum of 5 feet (1.52 m) from the outside perimeter of the wall of the pool.
From 5–10 feet (1.52–3.05 m), there should be either a fixed connection (outlet box) or twistlock connection with a GFCI.
6. Connect power cords to a 3-wire grounding-type outlet only.
7. Keep all breakable objects out of the pool area.
8. Alcohol consumption and pool activities do not mix. Never allow anyone to swim, dive or slide under the influence of alcohol or drugs.
9. Severe electrical shock could result if you install your pump or filter on a deck. The pump or filter could fall into the water, causing severe shock or electrocution.
10. Do not install on a deck or other surface at, above, or slightly below the top rail of the pool.
11. Do not use the filter pump during severe weather conditions, i.e. electrical storms, tornadoes, etc.
12. Be aware of overhead power lines when vacuuming your pool or using a telescoping pole.
13. Check regularly for signs of wear or loose bolts that could make the deck unsafe.
14. Please contact pool site dealer or manufacturer for additional safety signs if deemed necessary.
15. For pool service, select a certified pool professional.
For additional safety information, see www.APSP.org.
Consumer Awareness Booklets and Information Source
Contact: U.S. Consumer Product Safety Commission at www.CPSC.gov/cpscpub/pubs/pool/pdf, Pub. #362 “Safety Barrier Guidelines for Home Pools”.
1. The Sensible Way to Enjoy Your Aboveground/Onground Swimming Pool
2. Children Aren’t Waterproof
3. Layers of Protection
4. Pool and Spa Emergency Procedures for Infants and Children
5. Be Safety Aware Copies of the above brochures are available free from the APSP. Go to: www.APSP.org.
Safety Education Programs and Materials Educational programs and materials (i.e., seminars, workshops, brochures, videos, instructional guides) are available from
the APSP, other aquatic safety groups, and by private firms. As a means of communicating useful safety information to pool owners/operators, and users, industry
members are permitted to provide such information to owners/operators and to request or require owners/operators to sign a statement that they have received, read,
and will follow the guidelines.
Other sources of safety information:
• www.cdc.gov
• www.cpsc.gov
• www.drowningpreventionalliance.com
• www.nspf.org
• www.safekids.org
ANSI American National Standards Institute
25 West 43rd Street, New York NY 10036
Contact: 212-642-4900
www.ansi.org
APSP Association of Pool & Spa Professionals
(formerly National Spa and Pool Institute)
2111 Eisenhower Avenue, Alexandria VA 22314
Contact: 703-838-0083
www.apsp.org
ASME American Society of Mechanical Engineers
3 Park Avenue, New York NY 10016
Contact: 212-591-8562
www.asme.org
NSPI National Spa and Pool Institute (ss APSP)
UL Underwriters Laboratories
333 Pfingsten Road,Northbrook IL 60062-2096
Contact: 847272-8800
www.ul.com
NSF NSF International
789 N. Dixboro Rd,
P.O. Box 130140
Ann Arbor MI 48113-0140
734-769-8010
www.nsf.org
ASTM ASTM International (formerly American Society of Testing & Materials)
100 Barr Harbor Drive,West Conshohocken, PA 19428-2959
Contact: 610-832-9585
610-832-9555 (fax)
www.atsm.org
NEC National Electrical Code (see NFPA)
NFPA National Fire Protection Association
1 Batterymarch Park, Quincy MA 02269
Contact: 617-770-3000
www.nfpa.org
Filtration Systems
Any equipment connected to the circulation systems shall be positioned so as to prevent their being used as a means of access to the pool by young children. (See the
latest published edition of ANSI/ APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
Barrier
Barrier is necessary to provide protection against potential drowning and near drowning and that barriers are not a substitute for the constant supervision of children.
(See latest published edition of ANSI/APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.
Risk of Drowning, Entrapment, and Diving Accidents
Publications are available that describe the risk of drowning, entrapment, and diving accidents. Available publications related to pool safety include the Association of
Pool and Spa Professionals’ (APSP) booklets entitled: The Sensible Way to Enjoy Your Aboveground/ Onground Swimming Pool, Children Aren’t Waterproof, Pool and
Spa Emergency Procedures for Infants and Children, Layers of Protection, and the latest published edition of ANSI/APSP-8 Model Barrier Code for Residential
Swimming Pools, Spas, and Hot Tubs.
Installer Responsibilities
All of these components shall be positioned so as to prevent their being used as a means of access to the pool by young children.
(See thZarrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
6

SAND PUMP POWER INFORMATION
PARTS LIST
Preliminary Steps:
1. READ ALL INSTRUCTIONS CAREFULLY and get a thorough understanding of what is required to assemble your ST series Filter Pump.
2. Before you begin to assemble the pool, identify, count, and check all parts needed for assembly.
3. It is recommended that you have some PETROLEUM JELLY on hand for lubricating the gaskets.
4. Installer shall follow written instructions provided for operation of the filter pump systems.
5. All electrical components shall be installed in accordance with Article 680 of the National Electrical Code (NEC) “Swimming Pools, Fountains and
Similar Installations” or its latest approved edition.
6. The Pump are manufactured by and ETL control number 4000608 and 4006317 - double insulated and grounded - 120V. A.C. - 60 Hz. (ALL Units
must have a minimum of 105 V.A.C. to start and run properly.)
Sand Specifications:
Fill the tank with #20 silica sand. You can purchase the sand from your local home improvement or building material store.
SAVE THESE INSTRUCTIONS
12” SAND FILTER (WITH CP2000 PUMP)
SAND PUMP MODEL
10” SAND FILTER (WITH CP2000 PUMP)
350 watts
350 watts
WATTAGE AMPERAGE
3.0amps
3.0amps
Safety Care for Children
1. Children, especially children younger than five years, are at high risk of drowning. Drowning occurs silently and quickly and can occur in as little as 2 in. (5 cm) of water.
2. Keep children in your direct sight, stay close, and actively supervise them when they are in or near this pool and when you are filling and emptying this pool.
3. When searching for a missing child, check the pool first, even if the child is thought to be in the house.
4. Locate pumps and filters in such a way that children cannot climb on them and gain access to the pool.
5. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times.
Swimming Pool Barriers
Very Important: Swimming pool barriers, which restrict access to the pool by small children, may be required by law. A barrier is necessary to provide protection against
potential drowning and near drowning. Barriers are not a substitute for constant supervision of children. Check state or local laws and codes before setting up pool.
Swimming Pool Equipments
1. The use of artificial pool lighting is at the discretion of the pool owner. Lighting, when installed, should be in accordance with Article 680 of the
National Electrical Code (NEC) or its latest approved edition and in consultation with a licensed electrical professional.
2. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
3. Do not place pool near or under overhead electrical lines.
4. All electrical components installed in and/ or adjacent to an aboveground/onground residential swimming pool shall be installed in accordance with and shall comply
with the requirements of the latest published edition of NFPA 70, National Electrical Code (NEC®) Article 680, Swimming pools, fountains, and similar installations,
and any state or local code.
Filter Pump Awareness
1. WARNING: Risk of Electric Shock. Connect only to a grounding type receptacle. This product is provided with a ground-fault circuit-interrupter. If replacement of
the plug or cord is needed, use only identical replacement parts.
2. WARNING: To reduce the risk of electric shock, replace damaged cord immediately.
3. WARNING: To reduce the risk of electric shock, do not use extension cord to connect unit to electric supply; provide a properly located outlet.
4. CAUTION: To reduce the risk of electric shock the pool must be installed no closer than 6 feet (1.8 m) from any electrical outlet. Do not place portable appliances
closer than 5 feet (1.5 m) from the pool.
5. CAUTION: This pump is for use with storable pools only. Do not use with permanently-installed pools. A storable pool is constructed so that it is capable of being
readily disassembled for storage and reassembled to its original integrity. A permanently-installed pool is constructed in or on the ground or in a building such that it
cannot be readily disassembled for storage.
6. CAUTION: For continued protection against possible electric shock this unit is to be mounted to the base in accordance with the installation instructions.
7. Do not bury cord. Locate cord to minimize abuse from lawn mowers, hedge trimmers, and other equipment.
8. The unit is provided with a ground-fault circuit-interrupter (GFCI). To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button.
Power should be restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the pump without the test button being
pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this pump. Disconnect the pump and have the problem corrected by
a qualified service representative before using.
9. The Filter Pump is to be assembled by an adult; care should be taken in the unpacking and assembly of the Filter Pump, this pool may contain accessible
potentially hazardous sharp edges or sharp points that are a necessary part of the function of the Filter Pump.
10. If a drain or suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration,
or drowning. Repair or replace the drain or suction outlet cover before allowing the pool to be used.. During nighttime pool use, artificial lighting shall be used to
illuminate all safety signs, ladders, steps, deck surfaces and walks.
11. The floor of the pool shall be visible at all times from the outside perimeter of the pool.
12. Post a list of emergency telephone numbers such as the nearest available police, fire, ambulance and/or rescue unit. These numbers are to be kept near the
telephone, which is closest to the pool.
13. Basic lifesaving equipment, including one of the following should be on hand at all times:
• A light, strong, rigid pole (shepherds crook) not less than twelve feet (12’) [366 cm] long.
• A minimum one-fourth inch (1/4”) [6.35 mm] diameter rope as long as one and one half (1-1/2) times the maximum width of the pool or fifty feet (50’) [15.24 meters],
whichever is less, which has been firmly attached to a Coast Guard-approved ring buoy having an outside diameter of approximately fifteen inches (15”) [38.1 cm],
or similarly approved flotation device.
14. Pool shall be located at a minimum distance of 6 ft (1.83 m) from any receptacle, and all 125-volt 15- and 20-ampere receptacles located within 20 ft (6.0 m) of the
pool shall be protected by a ground fault circuit interrupter (GFCI), where distances are by measuring the shortest path the supply cord of an appliance connected
to the receptacle would follow, without piercing a floor, wall, ceiling, doorway with hinged or sliding door, window opening, or other effective permanent barrier, to
the inside wall of the pool.
Circulation Systems
1. Installers shall follow written instructions regarding positioning of all equipment connected to the circulation systems.
2. The installer shall follow written instruction provided for operation of the circulation system components.
3. All circulation system components and pump that require replacement or servicing shall be installed according to the pump’s instruction manual.
4. Circulation equipment shall be installed per manufacturer’s instructions to provide proper mounting and support, to prevent damage from misalignment, settlement,
and vibration, and to minimize the potential for the accumulation of debris and moisture. Please refer to pump’s instruction manual.
Chemicals
For safety sake, ensure the deepest part of the pool is always visible. The user must properly maintain clarify of the pool water at all time. Check the pH and chlorine
levels periodically and make sure they are within the recommended limits. Additional water treatment chemicals might be needed from time to time. Have the water
sample tested by a local pool supply store to determine if additional chemical is needed. Turn on the filter pump system for at least six hours per day. Clean and replace
filter cartridge frequently. Replace only with genuine Polygroup®/ Summer Wave™Brand filter cartridge. Refer to the Filter Pump manual for additional water care
information.
Entrapment Risk
1. Entrapment Avoidance: There shall be no protrusions or other obstruction in the swimming area, which may cause entrapment or entanglement of the user. If
a suction outlet cover is missing or broken, do not use the pool. Suction can cause body part entrapment, hair and jewelry entanglement, evisceration, or drowning.
Repair or replace the suction outlet cover before allowing the pool to be used.
2. DANGER! TO AVOID SERIOUS INJURY OR DEATH, CLOSE THE POOL OR SPA TO BATHERS IF ANY SUCTION OUTLET COVER/GRATE IS MISSING,
BROKEN OR INOPERATIVE.
3. Never play or swim near drains or suction fittings. Your body or hair may be trapped causing permanent injury or drowning.
4. Never enter the pool or spa if a suction fitting or drain cover is loose, broken, or missing.
5. Immediately notify the pool/spa owner or operator if you find a drain cover loose, broken or missing.
Drowning Risk
1. Keep unsupervised children from accessing the pool by installing fencing or other approved barrier around all sides of pool. State or local laws or codes may require
fencing or other approved barriers. Check state or local laws and codes before setting up pool.
2. Toys, chairs, tables or similar objects that a young child could climb shall be at least four feet (4’) [121.92 cm] from the pool. The pump filter system shall be positioned
so as to prevent it being used as a means of access to the pool by young children. Do not leave toys inside pool when finished using, since toys and similar items
might attract a child to the pool.
3. Position furniture (for example, tables, chairs) away from pool and so that children cannot climb on it to gain access to the pool.
Electrocution Risk
1. Keep all electrical lines, radios, speakers and other electrical appliances away from the pool.
2. Do not place pool near or under overhead electrical lines.
First Aid
1. Keep a working phone and a list of emergency numbers near the pool.
2. Become certified in cardiopulmonary resuscitation (CPR). In the event of an emergency, immediate use of CPR can make a lifesaving difference.
Special Warning
1. Local building codes may require obtaining a building or electrical permit. Installer shall follow regulations on setback, barriers, devices and other conditions.
2. Safety signs shall comply with requirements of ANSI-Z535 and to use signal wording.
3. DO NOT attempt to assemble this pool in adverse weather conditions, windy conditions or when the temperature is below 60°F.
4. This is a storable filter pump, which should be disassembled and stored when temperatures are expected to fall below 32°F.
Extra Safety Warning
1. Adult supervision is always required.
2. Parents should learn CPR.
3. Keep all electrical radios, speakers and other appliances away from the swimming pool.
4. When you touch the filter, pump, or electrical parts, be sure the ground under your feet is “Bone Dry.”
5. All electrical outlets should have a GFCI and connections should be a minimum of 5 feet (1.52 m) from the outside perimeter of the wall of the pool.
From 5–10 feet (1.52–3.05 m), there should be either a fixed connection (outlet box) or twistlock connection with a GFCI.
6. Connect power cords to a 3-wire grounding-type outlet only.
7. Keep all breakable objects out of the pool area.
8. Alcohol consumption and pool activities do not mix. Never allow anyone to swim, dive or slide under the influence of alcohol or drugs.
9. Severe electrical shock could result if you install your pump or filter on a deck. The pump or filter could fall into the water, causing severe shock or electrocution.
10. Do not install on a deck or other surface at, above, or slightly below the top rail of the pool.
11. Do not use the filter pump during severe weather conditions, i.e. electrical storms, tornadoes, etc.
12. Be aware of overhead power lines when vacuuming your pool or using a telescoping pole.
13. Check regularly for signs of wear or loose bolts that could make the deck unsafe.
14. Please contact pool site dealer or manufacturer for additional safety signs if deemed necessary.
15. For pool service, select a certified pool professional.
For additional safety information, see www.APSP.org.
Consumer Awareness Booklets and Information Source
Contact: U.S. Consumer Product Safety Commission at www.CPSC.gov/cpscpub/pubs/pool/pdf, Pub. #362 “Safety Barrier Guidelines for Home Pools”.
1. The Sensible Way to Enjoy Your Aboveground/Onground Swimming Pool
2. Children Aren’t Waterproof
3. Layers of Protection
4. Pool and Spa Emergency Procedures for Infants and Children
5. Be Safety Aware Copies of the above brochures are available free from the APSP. Go to: www.APSP.org.
Safety Education Programs and Materials Educational programs and materials (i.e., seminars, workshops, brochures, videos, instructional guides) are available from
the APSP, other aquatic safety groups, and by private firms. As a means of communicating useful safety information to pool owners/operators, and users, industry
members are permitted to provide such information to owners/operators and to request or require owners/operators to sign a statement that they have received, read,
and will follow the guidelines.
Other sources of safety information:
• www.cdc.gov
• www.cpsc.gov
• www.drowningpreventionalliance.com
• www.nspf.org
• www.safekids.org
ANSI American National Standards Institute
25 West 43rd Street, New York NY 10036
Contact: 212-642-4900
www.ansi.org
APSP Association of Pool & Spa Professionals
(formerly National Spa and Pool Institute)
2111 Eisenhower Avenue, Alexandria VA 22314
Contact: 703-838-0083
www.apsp.org
ASME American Society of Mechanical Engineers
3 Park Avenue, New York NY 10016
Contact: 212-591-8562
www.asme.org
NSPI National Spa and Pool Institute (ss APSP)
UL Underwriters Laboratories
333 Pfingsten Road,Northbrook IL 60062-2096
Contact: 847272-8800
www.ul.com
NSF NSF International
789 N. Dixboro Rd,
P.O. Box 130140
Ann Arbor MI 48113-0140
734-769-8010
www.nsf.org
ASTM ASTM International (formerly American Society of Testing & Materials)
100 Barr Harbor Drive,West Conshohocken, PA 19428-2959
Contact: 610-832-9585
610-832-9555 (fax)
www.atsm.org
NEC National Electrical Code (see NFPA)
NFPA National Fire Protection Association
1 Batterymarch Park, Quincy MA 02269
Contact: 617-770-3000
www.nfpa.org
Filtration Systems
Any equipment connected to the circulation systems shall be positioned so as to prevent their being used as a means of access to the pool by young children. (See the
latest published edition of ANSI/ APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
Barrier
Barrier is necessary to provide protection against potential drowning and near drowning and that barriers are not a substitute for the constant supervision of children.
(See latest published edition of ANSI/APSP-8 Model Barrier Code for Residential Swimming Pools, Spas, and Hot Tubs.
Risk of Drowning, Entrapment, and Diving Accidents
Publications are available that describe the risk of drowning, entrapment, and diving accidents. Available publications related to pool safety include the Association of
Pool and Spa Professionals’ (APSP) booklets entitled: The Sensible Way to Enjoy Your Aboveground/ Onground Swimming Pool, Children Aren’t Waterproof, Pool and
Spa Emergency Procedures for Infants and Children, Layers of Protection, and the latest published edition of ANSI/APSP-8 Model Barrier Code for Residential
Swimming Pools, Spas, and Hot Tubs.
Installer Responsibilities
All of these components shall be positioned so as to prevent their being used as a means of access to the pool by young children.
(See thZarrier Code for Residential Swimming Pools, Spas, and Hot Tubs.)
PARTS NAME QTY. PARTS NAME QTY.
Drain Valve Cap
Drain Valve O-Ring
Sand Guard
Clamp
CAM-SHAFT Bolt Cap
6-Port Valve O-Ring
6-Port Valve
1
1
2
1
6
2
1
5
1
1
1
1
1
1
1
1
1
1
1
1
1
6-Port Valve Drain Outlet Cap
Pressure Gauge
Long Hose
Hose Clamp
Locking Pin
Pump
1.5” Fitting O-Ring
6-Port Valve Drain Outlet Window
6-Port Valve Handle
GFCI Power Cord Set
ITEMS ITEMS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Sand Tank Base
Sand Tank
Center Pipe
A) ST1100
B) ST1600
A) ST1100
B) ST1600
A) ST1100
B) ST1600
A) ST1100 12”Hose
B) ST1600 10”Hose
Short Hose
7

Press
"RESET"
Button
To Start
Pump
Operation
How to use the GFCI plug
*Do not connect
to a timer device
10
20
11
10
19
9
78
6
2
4
3
1
5
18
18
13
13
15
15
16
15
15
14
17
18
18
18
16
21
21
8

3. Insert and push the Locking Pins all the way down to
secure the Pump with the Sand Tank Base
1
16
17
2. Snap the Pump on to the Sand Tank Base
17 1
1. Set up the pool by following all instructions comes with the
pool. Do not fill water until the Filter Pump is properly
installed. Locate the Outlet and Inlet openings on the pool wall.
4. With the Drain Valve of the Sand Tank pointing outward.
Place the Sand Tank on the Sand Tank Base .
2
2 1
SETUP INSTRUCTIONS
17
1
2
1
ALIGN
Drain Valve
Inlet
Outlet
16
17
1
PUSH
WARNING: POSITION THIS PRODUCT AWAY FROM THE POOL, SO AS TO PREVENT CHILDREN FROM CLIMBING ON IT AND ACCESSING THE POOL.
Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts.
9

5. Put the Center Pipe inside the Sand Tank . Let the
Center Pipe seats at the center of the Sand Tank .
2
25
5
7. Fill the tank with #20 silica sand. You can purchase the sand from your local home improvement or building material store.
Slowly pour sand into the Sand Tank until the sand level is between the Min and Max marks on the Center Pipe .
2 5
6. Attach the Sand Guard to the top opening of the Center
Pipe .
6
5
5
2
6
5
5
2
Sand
10

10
2
7
7
PUSH
2
10
12
5ALIGN
10
9
2
5
8. Remove the Sand Guard and save for future use.
6
10. Apply the Clamp to the flange of the 6-Port Valve
and Sand Tank .
7
2
10 11. Close the Clamp push the 2 jaws as close together as possible.
7
6
9. Place the 6-Port Valve to the Sand Tank . Make sure the 6-Port
Valve O-Ring is present at the bottom flange of the 6-Port Valve
. Make sure the center tube extending from the valve fits securely
with the Center Pipe . Rotate the 6-Port Valve so that the
Pressure Gauge is facing the same direction as the Drain Valve.
10
10
10
12
5
9
2
11

8
CAM-HANDLE
CAM-BOLT
CAM-HANDLE
12. Turn the CAM-HANDLE so that the CAM-BOLT is inserted
into the slot on the other jaw.
13. Hold the CAM-HANDLE with one hand and start turning in
clockwise direction.
15. Insert the CAM-SHAFT Bolt Cap to the end of the CAM-BOLT.
8
14. Continue to turn the CAM-HANDLE to tighten the jaw until no
more turns can be made. Align the CAM-HANDLE with the
Clamp and push the CAM-HANDLE toward the Sand
Tank .
7
2
CAM-HANDLE
2
7
12

16. Connect the Short hose between the Pump Outlet
and the 6-Port Valve Inlet. Tighten the Hose Clamp
with a flat blade screwdriver.
14
15
17. The sand filter pump is now fully assembled. Connect the sand filter
pump to the pool with the Long Hoses supplied with the pump.
Connect the pool Outlet to the Pump Inlet. And tighten the Hose
Clamp with a flat blade screwdriver. Connect the 6-Valve Port
Outlet to the pool Inlet Port. Tighten the Hose Clamp with a flat
blade screwdriver.
15
15
13
FUNCTIONS OF THE 6-PORT VALVE
FUNCTION WATER FLOW DIRECTION
Normal filtration and regular vacuuming of pool. Pool > Pump > Sand (Forward) > Pool
Pool > Pump > Sand (Backward) > Drain Outlet
Pool > Pump > Sand (Forward) > Drain Outlet
Pool > Pump > Drain Outlet
Sand by-passed
Pool > Pump > Pool
Sand by-passed
Reverses water flow to clean the sand bed.
For initial startup cleaning of the sand, and
leveling the sand bed after backwashing.
For vacuuming directly to the drain outlet,
lowering pool level or to drain the pool.
For circulating water back to pool without going filtering.
Shuts off all flow to filter and pool.
Never turn on the pump at this “CLOSED” position.
VALVE POSITION
FILTER
BACKWASH
RINSE
WASTE
RECIRCULATE
CLOSED No flow.
Never turn on the pump at this “CLOSED” position.
OPERATING INSTRUCTION
15
14
15
6-Port Valve Inlet
Pump Outlet
15
15
13
13
15
15
Outlet Port
Inlet Port
6-Port Valve Outlet
Pump intlet
13

WASTECLOSEDBACKWASH
FILTER RINSE RECIRCULATE
POWER SWITCH
Outlet port
Inlet port
11
12
IMPORTANT SAFETY INFORMATION
1. Make sure all the Hoses are secured to the fittings on the pump and pool.
2. Always press down the 6-port Valve Handle before switching position.
3. Always turn off the pump power when switching position.
4. It is critical to the backwash the sand before using the pump to clean the pool water. This will
prevent fine sand to flow into the pool and also wash off any dirt or debris within the sand.
5. Make sure the power switch is at the “OFF” position. Plug the GFCI Power Cord Set to
a grounded power outlet.
6. IMPORTANT: To stand the filter pump, press the RESET button on the GFCI Power Cord Set .
7. Fill the pool until the water level reaches the pool fill line.
8. Follow the following steps to BACKWASH the sand before first use:
• Remove the 6-Port Valve Drain Outlet Cap from the 6-Port Valve . (Optionally, a
1.5” [38mm] hose can be connected to the drain port to direct the waste water to a nearby drain.)
• Press down the 6-Port Valve Handle and turn to the “BACKWASH” position.
• Turn on the power of the Pump .
• Pool water is now circulating backward through the sand bed
to the drain outlet. Continue BACKWASH until the drain water
becomes clean and clear.
• Turn off the Pump and switch the handle to the “RINSE” position.
Turn on the Pump for ONE minute, this will clean up and
level out the sand bed. Turn off the Pump when done.
9. To start filtering the pool, turn the 6-Port Valve Handle to the “FILTER”
position and then switch on the Pump . Record down the sand tank pressure
ready from the Pressure Gauge . This reading indicates the initial tank pressure
when the sand bed is clean.
10. BACKWASH the tank when the pressure is 1-1.5 bar (14.5 - 21.8 Psi) above the
initial pressure. Or, BACKWASH the sand filter once every TWO weeks to
maintain water cleaniness.
13
11 10
17
17
17
17
17
12
14
20
21
20
20
21
Press
"RESET"
Button
To Start
Pump
Operation
How to use the GFCI plug
*Do not connect
to a timer device
21
14

PUMP MOTOR PROTECTION
IMPORTANT! Your filter pump is protected by a thermal switch. The switch senses the temperature of the filter pump. If it gets too hot, the switch will stop the pump from
running until it cools off. It will automatically turn back on when the filter pump has cooled down. This is a safety device to prevent pump damage and prolong service
life. If your pump is automatically turning off, it is because of high pool water temperature and/or low water flow through the pump. If this happens you need to check the
water flow and correct it if needed, as this filter pump uses the water flow for cooling. You may also want to run the pump at night when the temperature is lower.
POOL MAINTENANCE
1. BACKWASH the sand bed when the pressure reading is 1-1.5 bar (14.5 - 21.8 Psi) above the nitial presssure; or, BACK WASH the sand bed at least once TWO weeks.
2. Discard all the sand at the end of the season, wash the pump components, sand tank and 6-port valve thoroughly with freash water before storage. Fill up with new
sand at the beginning of the swimming season.
3. Check and adjust pH and chlorine levels daily using required chemicals. See below Section of “POOL WATER CARE”.
4. Check filter pump output daily. If flow is reduced, see below Section of “TROUBLE SHOOTING GUIDE”.
5. Check filter pump, hoses, fitting for leaks. If a leak is found, see below Section of “TROUBLE SHOOTING GUIDE”.
6. Check seams in pool periodically. Minor repairs may be made with the repair patch kit (supplied with pool). Additional patches are available from or your local pool
supply store.
POOL WATER CARE
1. The following items are required and readily available from your local pool supply store:
• TEST KIT - Used to check chlorine and pH levels.
• 1” CHLORINE TABLETS - Used to disinfect pool water and help control the growth of algae.
• pH CONTROL CHEMICALS - Used to adjust pH levels Up (Soda Ash) or Down (Acid).
• ALGAECIDES - Used to eliminate algae.
• SUPERCHLORINATOR - Used to destroy combined chlorine, ammonia, nitrogen, and organic compounds.
• LEAF NET with handle - Used to remove leaves, trash, insects, etc. from pool.
• CHLORINE DISPENSER (available in most pool supply store).
2. Use test kit daily to check pH and chlorine levels. Adjust accordingly using the required chemicals.
NOTE: Excessive levels of chlorine or low pH levels will damage pool liner.
3. The pool can be cleaned using a garden hose powered vacuum from or a pool supply store.
4. Using a foot bath near the pool to wash off your feet prior to entering the pool will assist in keeping the pool clean.
5. Well water often presents special problems with water chemistry. If you must use well water, take a sample to
your local pool chemical supplier for analysis before adding ANY chemicals.
6. Refer to the POOL’s USER MANUEL for the capacity of your pool. You will need this information to determine
the amount of chemicals you will need to correct the pool water.
NOTE: It is recommended to use a 5 gallon bucket of water to mix and dissolve your chemicals and then applying directly to the pool water. Follow manufacturers
label directions on all chemicals.
• Most pool supply stores will test your pool water for free and advise you of what chemicals you need, and the correct amount to use for your pool. You will need to
tell them the pool capacity in gallons.
7. IMPORTANT: We cannot over-stress the importance of proper and adequate daily chemical treatment. Chlorine and pH levels must be properly maintained at all
times. PUMP AND FILTER ALONE WILL NOT PREVENT ALGAE FROM GROWING IN POOL WATER; THIS CAN ONLY BE DONE BY MAINTAINING PROPER
CHLORINE AND pH LEVELS AT ALL TIMES.
• Maintain pH level between 7.3 and 7.8.
• Maintain chlorine level between 1.0 and 1.6 ppm (parts per million).
• Superchlorinate your pool at least every other week.
NOTE:
1. Hot weather/heavy use may require pH and chlorine levels to be maintained on the upper side of the scale and superchlorination of the pool every week.
2. Using a pool cover and/or solar cover will assist in maintaining your pH and chlorine levels by reducing the amount of evaporation from your pool.
CAUTION: Concentrated chlorine levels and low pH levels will damage pool. You must follow the instructions for the pool chemicals you use, as to quantity and
recommended usage. NEVER drop lumps or pellets of chemicals in pool; this may present a hazard to swimmers and/or damage your liner.
Chlorine Tablets
15

TROUBLESHOOTING GUIDE
PROBLEM CAUSE SOLUTION
1 Pump motor
fails to start
2 Sand filter
doesn't
clean pool
3 Sand filter
doesn't pump
water or flow
is very slow
4 Pump
doesn't
Work
5 6-way valve/
cover leaking
6 Hose leaking
7 Pressure gauge
doesn't Work
8 Sand is
flowing back
into the pool
A The motor is not plugged in.
Or GFCI not activated A GFCI power cord must be plugged into a grounded power outlet.
B Check the line voltage, it must be in the range of 105 to 125V.B Low voltage
B Load with filter sand, see "sand loading instructions”.B No filtering media in tank.
A Improper chlorine or pH levels
C Reset the GFCI plug and/or circuit breaker. If problem persists,
have the circuit checked by a qualified electrician.
C GFCI plug and/or circuit
breaker tripped
A Adjust the chlorine and pH level. Consult your local swimming
pool supply stores.
A Clear any obstructions in the pool oulet fitting and oump intake hose.A Clogged inlet or discharge.
C Set valve to “FILTER” position.C Wrong 6-way valve setting position.
D Operate the filter for longer periods.D Excessively dirty pool.
E Clean the strainer at the pool outlet fitting
E Obstructed pool outlet fitting is
restricting the water flow
B Tighten hose clamps, check hoses for damage and check pool water level.B An air leak on the intake line.
C Backwash the sand bed more frequently.C Sand media clogged with dirt.
B Clean strainer screens at pool inlet.B Strainer screen clogged up.
A Remove 6-way valve and ensure the o-ring is in present.A Sand tank o-ring missing.
A Tighten/reinstall hoses clamp.A Hose clamps not securely tight.
B Clean sand tank o-ring with garden hose water.B Sand tank o-ring diry.
C Tighten the hose clamps.C Hose clamps not tight.
C Ensure o-ring is in place and not damaged.B Hose connection fitting o-ring missing.
A Clear any obstructions in the intake by unscrewing it from the 6-port valve.A Clogged inlet of the pressure gauge.
B Contact Customer Service.B Pressure gauge damage.
B Discard all the used sand and replace with new sand.B Sand bed is calcified.
D Contact Customer Service.D 6-port valve damage.
C Tighten hose clamps, check hose for damage.C An air leak on the intake hose.
D Contact Customer Service.
A Fill pool to correct water level.A Low water level.
D Replace about 1" (25mm) of sand. Replace all the sand if problem persists.
D Let the motor cool down and restart again.
C Motor too hot and overload
protection is shut off.
D Crusting or caking on the
filtering sand surface.
E Remove any pool vacuuming device attached to the system line.
E Pool vacuuming device
attached to the system.
D Faulty motor or the
impeller is jammed.
A Use only No.20 silica sand with particle sizi range 0.45 to 0.85mm
(0.018 to 0.033 inches)and a Uniformity Coefficient less than 1.75.
A Sand is too small.
WARNING: UNPLUG THE POWER CORD BEFORE TROUBLESHOOTING THE FILTER PUMP.
16

SAND FILTER PUMP DISASSEMBLY & STORAGE
REPLACEMENT PARTS ORDERING INFO
1. First, unplug the GFCI Power Cord of the system.
2. Loosen all Hose Clamps . Remove the Hose and allow water to drain out.
3. Remove Drain Valve Cap from the Sand Tank and allow water to drain out, and the tighter back the Drain Valve Cap onto the
drain valve on the Sand Tank .
4. Clear and lubricate all Fitting O-Rings with petroleum jelly and then place the sand filter pump in a safe place.
21
15
3 3
2
2
13
18
14
ST1600
Key#
ST1100
PART # PART #
Description
Sand Tank Base
Sand Tank
Drain Valve Cap
Drain Valve O-Ring
Center Pipe
Sand Guard
Clamp
CAM-SHAFT Bolt Cap
6-Port Valve O-Ring
6-Port Valve
6-Port Valve Drain Outlet Cap
Pressure Gauge
59” Hose
ST1100 12” Hose
ST1600 10” Hose
Hose Clamp
Locking Pin
Pump
1.5” Fitting O-Ring
6-Port valve Drain Outlet Window
6-Port Valve Handle
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
P58PP1782E09
P58000000W05
P58PF0800W05
P58PF1731K01
P586402000W1
P58PF8891P01
P58897023E09
P58PP2021K01
P58135001K01
P58PF8880E09
P58PF8910E09
P58340000000
P584150006W1
P5842504500A
P58PP1759E09
P530C200S8W5
P58037000K01
P58PF8960C01
P58PF8950E09
P58PP2884A09
P58000001W05
P58PF0800W05
P58PF1731K01
P586402001W1
P58PF8891P01
P58897023E09
P58PP2021K01
P58135001K01
P58PF8880E09
P58PF8910E09
P58340000000
P584150006W1
P584150012W1
P5842504500A
P58PP1759E09
P530C200S8W5
P58037000K01
P58PF8960C01
P58PF8950E09
P584150010W1
17

ASME COMPLIANT SUCTION FITTING INFORMATION
9. The suction outlet PSF-100A or PSF-100B is to be replace every 5 years.
10. No tool is required for installation.
11. Service and Winterizing Instructions
CAUTION! DO NOT EXCEED THE MAXIMUM ALLOWABLE FLOW RATE:
1. 45 Gallon per minute (2,700 Gallon per hour).
2. Carefully observe and inspect the suction outlet for damage and tampering before each use of the pool.
3. Missing, broken or cracked suction outlet must be replaced before using the pool.
4. Loose suction fitting should be reattached or replaced before using the pool.
5. Remove and store Suction Outlet assembly if temperatures are expected to fall below 32° F.
1. PSF-100A and PSF-100B Suction Outlets are certified by IAPMO in accordance with the ASME/ANSI A112.19.8b-2009 Suction Fitting for use in Swimming Pools,
Wading Pools, Spas, and Hot Tubs.
2. This is a submerged suction outlet for use with above ground swimming pool.
3. For single drain only. Use only ONE outlet for each pump.
4. Do not locate this suction outlet on sitting areas or on the backrest for such seating area.
5. Install this outlet at location recommended by the pool manufacturer.
6. The maximum allowable flow rate of this suction outlet is 45 gallon per minute (2,700 gallonper hour).
7. Connection Hose:
• Model PSF-100-A is to be connected with 1 1/4” (31.8mm) diameter hose.
• Model PSF-100-B is to be connected with 1 1/2” (38.1mm) diameter hose.
8. The suction outlet is to be mounted at the suction outlet opening as specified by the manufacturer of the above ground pool. The diameter of this opening should be
within the range of 1.77” to 1.85” (45.0mm to 47.0mm). Refer to the following diagram for detail assembly instructions:
PSF-100A AND PSF-100B SUCTION OUTLET
(FOR ABOVE GROUND POOL)
Swimming Pool
Water Hose
Hose Clamp
Lock Nut, To Be Tightened By Hand
Rubber Gasket
Water Cap, To Be Installed
Only During Pump Maintenance
Or Filter Change
Suction Fitting, PSF-100A
Or PSF-100B
Flat Washer
18

www.bsvillage.com
[email protected]
0522 15 36 417
0522 18 40 494
www.bsvillage.com
BUSINESS SHOP S.r.l. a Socio Unico
Via della Repubblica n. 19/1 - 42123 Reggio Emilia (RE)
P.Iva e C.F. 02458850357 - Cap. soc. 60.000,00 € i.v.
