BTC Task FF432 User manual

Task
Instruction Manual
Table & Floor Light
MADE IN BRITAIN
ORIGINALBTC.COM
[phone]
UNIT 21 / 22 AVENUE ONE, STATION LANE, WITNEY, OX28 4XZ, ENGLAND
Ceramic Table
FT431
Table
FT378
Solo Table
FT427
Small Table
FT402
Established in 1990, Original BTC manufactures relaxed, familiar lighting for traditional and
contemporary homes.
All products are hand-assembled in Oxford from high quality components, produced in the UK.
Ceramic Floor
FF432
Floor
FF379
Overreach
FF393
FF432/379/393 - FT402/378/431/427
v1.1-10.18

Task Table & Floor Light
FT402 Small Table
FT378 Table
FT431 Ceramic Table
FT427 Solo Table
230V ac 50Hz Adjusting FittingIP20
(a) FF432/379, FT402/378/431/427
(b) FF393
* Warm white (2700k) low energy lamps recommended.
** Wattage value provided as a guide to suitable lamps. Lower wattage than stated may be used.
Safety Instructions
Cleaning and Maintenance
These instructions are provided for your safety in order to prevent the risk of Fire, Electric shock or
Injury. Please retain for future reference. When fitting is in operation, some parts will become hot;
take care when using/handling.
- Ensure the lamp type and max wattage is followed- do not exceed. Take care not to overtighten
lamp.
- Do not touch the lamp (bulb) or lamp holder while in operation, as both become very hot.
- Turn off and unplug fitting, leaving lamp to cool before changing lamp. Dispose of old lamps
carefully.
- Adjust light fitting only when power to the fitting is off and has been left to cool.
- Never leave a fitting without a lamp in position.
- Keep light fitting away from combustible materials such as soft furnishings.
- Ensure children do not play with the light fitting.
- Ensure the light is positioned on a solid, level and non-slip surface and make sure the position of
the cable does not pose a trip hazard.
- If the electrical flex or electrical components become damaged at any point, the fitting must be
unplugged from the power supply immediately and not operated until the damaged parts are
fixed/replaced.
- For use in a dry, indoor environment only. Ensure the fitting does not come into contact with any
liquids.
Metal finishes should only be cleaned with a soft, dry cloth. Do not use polishes or abrasives. Bone
china can be cleaned by hand, using a soft damp cloth with a diluted mild detergent (nonabrasive) if
necessary. Switch off power to the fitting before cleaning.
The Task Table and Floor lights, can be moved, angled or adjusted bringing greater flexibility and
creative scope, while focussing a high level of illumination directly where it is needed. Shades can
be angled and swivelled, to throw either a concentrated pool or illuminate a larger area.
E27 GLS BALL
LAMP GUIDANCE
TYPE* WATTAGE** BASE SHAPE




INCANDESCENT
CFL
ECO-HALOGEN
LED
60W MAX (a)
15W
42W
10W
Adjusting Position of Arm
1
2
3
Loosen the handle of the clamp, by gently turning clamp by one
quarter-turn in an anti-clockwise direction.
Position arm into desired position, then secure by tightening
handle of clamp firmly. Do not overtighten.
The arm may be rotated, when held in the clamp by gently
twisting the arm while holding the clamp in position.
Adjusting Height of Arm
1
2
Loosen the handle of the clamp, by gently turning clamp almost one
full turn in an anti-clockwise direction.
While supporting both clamp and arm, position arm at desired height,
then secure by tightening handle of clamp firmly. Do not overtighten.
Adjusting Shade
1
2
The swivel joint allows great flexibility of movement, allowing the
shade to be tilted or rotated into position as desired.
Adjust angle of shade by gently pivoting shade on swivel joint (4)-
tilting up/down up to 90˚ or rotating up to 180˚ in either direction.
2
1
3
1
2
4
When adjusting the clamp, ensure it is supported with
other hand and take care not to loosen the handle too far,
as this can cause the handle to detach from the clamp
body and fall from the fitting, causing damage/injury.
FF432 Ceramic Floor
FF379 Floor
FF393 Overreach
Adjusting Angle of Arm (Task Solo ONLY)
1Loosen the handle of the clamp, by gently turning clamp almost one
full turn in an anti-clockwise direction.
Secure position by tightening handle of clamp firmly.
2
1
100W MAX (b)
20W
70W
18W
