bto 17CL48 User manual

I
Introduction (English)
This Concise User’s Guide introduces the main features
of your computer. The English version of this guide be-
gins on page 1. The expanded User’s Manual is on the
Device Drivers & Utilities + User’s Manual disc.
Einführung (Deutsch)
Dieses Ausführliche Benutzerhandbuch führt Sie in die
Hauptfunktionen des Computers ein. Die deutsche Ver-
sion des Handbuchs beginnt auf Seite 25. Das erweiterte
Benutzerhandbuch finden Sie auf der Disc für die Gerä-
tetreiber und Hilfsprogramme (Disc Device Drivers &
Utilities + User's Manual).
Présentation (Français)
Ce Guide Utilisateur Concis présente les fonctionnalités
principales de votre ordinateur. La version française de
ce guide commence à la page 49. Le Manuel de l'Utilisa-
teur étendu se trouve sur le disque de Pilotes & Utili-
taires + Manuel de l'Utilisateur (disque Device Drivers
& Utilities + User's Manual).
Introducción (Español)
Esta Guía del Usuario Concisa le presenta las caracterís-
ticas principales de su ordenador. La versión española de
esta guía comienza en la página 73. El Manual del usua-
rio completo se encuentra en el disco de Controladores
del dispositivo y Utilidades + Manual del usuario (disco
Device Drivers & Utilities + User's Manual).
Introduzione (Italiano)
La presente Guida Rapida per l'Utente introduce le carat-
teristiche principali del computer. La versione italiana di
questa guida inizia da pagina 97. Il Manuale utente com-
pleto si trova nel disco contenente driver e utilità + Ma-
nuale utente (disco Device Drivers & Utilities + User's
Manual).

II
Contents
About this Concise User Guide .........................................................1
System Startup ..................................................................................3
RAID Setup .......................................................................................4
System Map: Front View with LCD Panel Open .............................6
LED Indicators ..................................................................................7
Hot Key Buttons & Keyboard ...........................................................8
Control Center .................................................................................10
System Map: Front, Left, Right & Rear Views ..............................14
System Map: Bottom View .............................................................15
Video Features ................................................................................16
Audio Features ................................................................................18
Driver Installation ...........................................................................19
Troubleshooting ..............................................................................20
Specifications ..................................................................................21
Inhalt
Über das Ausführliche Benutzerhandbuch .....................................25
Schnellstart ......................................................................................27
RAID Setup .....................................................................................28
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm ............................................................................30
LED-Anzeigen ................................................................................31
Hot-Key-Tasten & Tastatur ............................................................32
Control Center (Steuerzentrum) ......................................................34
Systemübersicht: Ansicht von vorne, links, rechts und hinten .......38
Systemübersicht: Ansicht von unten ...............................................39
Grafikfunktionen .............................................................................40
Audiofunktionen ..............................................................................42
Installation der Treiber ....................................................................43
Fehlerbehebung ...............................................................................44
Technische Daten ............................................................................45
Sommaire
A propos de ce Guide Utilisateur Concis ........................................49
Guide de démarrage rapide .............................................................51
Configuration RAID ........................................................................52
Carte du système: Vue de face avec l’écran LCD ouvert ...............54
lndicateurs LED ...............................................................................55
Boutons Hot-Key & Clavier ............................................................56
Control Center (Centre de contrôle) ................................................58
Carte du système: Vues de face, gauche, droite & arrière ..............62
Carte du système: Vue d’en dessous ...............................................63
Caractéristiques vidéo .....................................................................64
Caractéristiques audio .....................................................................66
Installation du pilote ........................................................................67
Dépannage .......................................................................................68
Spécifications ..................................................................................69

III
Contenidos
Acerca de esta Guía del Usuario Concisa .......................................73
Guía rápida para empezar ...............................................................75
Configuración RAID .......................................................................76
Mapa del sistema: Vista frontal con panel LCD abierto ................78
Indicadores LED .............................................................................79
Botones Hot-Key & Teclado ..........................................................80
Control Center (Centro de control) .................................................82
Mapa del sistema: Vistas frontal, izquierda, derecha y posterior ...86
Mapa del sistema: Vista inferior .....................................................87
Características de audio ..................................................................88
Parámetros de vídeo ........................................................................89
Instalación de controladores ...........................................................91
Solución de problemas ....................................................................92
Especificaciones ..............................................................................93
Sommario
Informazioni su questa guida rapida ...............................................97
Guida di avvio rapido ......................................................................99
Configurazione RAID ...................................................................100
Descrizione del sistema: Vista anteriore con pannello
LCD aperto ....................................................................................102
Indicatori LED ..............................................................................103
Pulsanti Hot-Key & Tastiera .........................................................104
Control Center (Centro di controllo) .............................................106
Descrizione del sistema: Vista anteriore, sinistra, destra e
posteriore .......................................................................................110
Descrizione del sistema: Vista inferiore ........................................111
Funzioni video ...............................................................................112
Funzionalità audio .........................................................................113
Installazione driver ........................................................................115
Risoluzione dei problemi ..............................................................116
Specifiche tecniche ........................................................................117

IV

1
English
About this Concise User Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for the
expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’sManual
disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper operation of
the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information contained in the expanded User’s Man-
ual on the Device Drivers & Utilities + User’s Manual disc.
© June 2012
Trademarks
Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.

FCC Statement
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2.This device must accept any
interference received, includ-
ing interference that may
cause undesired operation.

2
English
Instructions for Care and Operation
The computer is quite rugged, but it can be damaged. To prevent
this, follow these suggestions:
•Don’t drop it, or exposeit to shock. If the computer falls, the case and the
components could be damaged.
•Keep it dry, and don’t overheat it. Keep the computer and power supply
away from any kind of heating element. This is an electrical appliance. If
water or any other liquid gets into it, the computer could be badly dam-
aged.
•Avoid interference. Keep the computer away from high capacity trans-
formers, electric motors, and other strong magnetic fields. These can hin-
der proper performance and damage your data.
•Follow the proper working procedures for the computer. Shut the com-
puter down properly and don’t forget to save your work. Remember to
periodically save your data as data may be lost.
Servicing
Do not attempt to service the computer yourself. Doing so may vio-
late your warranty and expose you and the computer to electric
shock. Refer all servicing to authorized service personnel. Unplug
the computer from the power supply. Then refer servicing to quali-
fied service personnel under any of the following conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the operating
instructions.
• If the computer has been dropped or damaged (do not touch the poisonous
liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.
Safety Information
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual. Do not dis-
pose of batteries in a fire. They may explode. Check with local codes for
possible special disposal instructions.
• Do not continue to use a battery that has been dropped, or that appears
damaged (e.g. bent or twisted) in any way. Even if the computer continues
to work with a damaged battery in place, it may cause circuit damage,
which may possibly result in fire.
• Make sure that your computer is completely powered off before putting it
into a travel bag (or any such container).
• Before cleaning the computer, make sure it is disconnected from any exter-
nal power supplies, peripherals and cables (including telephone lines). It is
advisable to also remove your battery in order to prevent accidentally turn-
ing the machine on.
• Use a soft clean cloth to clean the computer, but do not apply cleaner
directly to the computer. Do not use volatile (petroleum distillates) or abra-
sive cleaners on any part of the computer.
• Do not try to repair a battery pack. Refer any battery pack repair or replace-
ment to your service representative or qualified service personnel.
Polymer Battery Precautions
Note the following information which is specific to polymer batter-
ies only, and where applicable, this overrides the general battery pre-
caution information.
• Polymer batteries may experience a slight expansion or swelling, however
this is part of the battery’s safety mechanism and is not a cause for concern.
• Use proper handling procedures when using polymer batteries. Do not use
polymer batteries in high ambient temperature environments, and do not
store unused batteries for extended periods.

Battery Disposal & Caution
The product that you have purchased contains a rechargeable
battery. The battery is recyclable. At the end of its useful life, un-
der various state and local laws, it may be illegal to dispose of
this battery into the municipal waste stream. Check with your lo-
cal solid waste officials for details in your area for recycling op-
tions or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the
manufacturer. Discard used battery according to the manufac-
turer’s instructions.

3
English
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and make sure it is locked in position.
4. Securely attach any peripherals you want to use with the
computer (e.g. keyboard and mouse) to their ports.
5. Attach the AC/DC adapter to the DC-In jack at the rear of the
computer, then plug the AC power cord into an outlet, and
connect the AC power cord to the AC/DC adapter.
6. Use one hand to raise the
lid/LCD to a comfortable viewing
angle
(do not exceed 135 degrees) ; use the other hand (as
illustrated in Figure 1) to support the base of the computer
(Note: Never lift the computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
System Software
Your computer may already come with system software
pre-installed. Where this is not the case, or where you are
re-configuring your computer for a different system, you
will find this manual refers to Microsoft Windows 7.
Model Differences
This notebook series includes two different models (see
Specifications on page 21 for details).
Figure 1
Opening the Lid/LCD/Computer with AC/DC Adapter
Plugged-In

Shut Down
Note that you should
always shut your com-
puter down by choos-
ing Shut Down from
the Start Menu.
This will help prevent
hard disk or system
problems.
135 ﾟ

4
English
RAID Setup
You may use your hard disks in combination with Striping
(RAID 0), Mirroring (RAID 1), or Recovery for either
fault tolerance or performance.
Table 1 - RAID Description
Prepare the following before setting up your serial ATA
hard disks in RAID mode:
•TheMicrosoft Windows 7 OS disc.
•TheDevice Drivers & Utilities + User’s Manual disc.
Note: All hard disks in a RAID should be identical (the
same size and brand) in order to prevent unexpected sys-
tem behavior.
RAID Setup Procedure
Part I: BIOS
1. Start-up your computer and press F2 to enter the BIOS.
2. Go to the Advanced menu, select SATA Mode and press
Enter.
3. Select RAID Mode.
4. Press Esc and go to the Boot menu.
5. Set the CD/DVD-ROM Drive (make sure the Microsoft
Windows OS disc is inserted) as the first device in the boot
order from the Boot menu.
6. Select Save Changes and Reset from the Exit menu (or
press F4) and press Enter to exit the BIOS and reboot the
computer.
RAID Level Description
RAID 0
(at lease two
hard disks
needed)
Identical drives reading and writing data in paral-
lel to increase performance. RAID 0 imple-
ments a striped disk array and the data is broken
into blocks and each block is written to a sepa-
rate disk drive.
RAID 0 (a striped array) is not fault-tolerant. The
failure of one drive will result in the loss of all
data in the array.
RAID 1
(at lease two
hard disks
needed)
Identical drives in a mirrored configuration used
to protect data. Should a drive that is part of a
mirrored array fail, the mirrored drive (which
contains identical data) will handle all the data.
When a new replacement drive is installed, data
to the new drive is rebuilt from the mirrored drive
to restore fault tolerance.
RAID 1 (mirrored array) provides full data pro-
tection, as data can simply be copied from a
healthy disk to a replacement for any failed disk.
Recovery
(at lease two
hard disks
needed)
Two identical drives copying data between a
master and a recovery disk. This provides more
control over how data is copied between the
master and recovery drives, fast volume
updates and the ability to view the data in Win-
dows Explorer.

5
English
Part II: Intel Matrix
1. Press Ctrl + i to enter RAID configuration menu.
2. Select 1.Create RAID Volume and press Enter.
3. Type the RAID volume name and then press Tab or Enter to
advance to the next field.
4. Specify (use the up and down arrow keys) the RAID level
(RAID 0 or RAID 1 or Recovery - see Table 1) and then
press Tab or Enter to advance to the next field.
5. Press Enter and the system will select the physical disks to
use.
6. Press Enter and select (if applicable) the Strip Size (best set
to default).
7. Press Enter and select the Capacity size (best set to default).
8. Press Enter to select Create Volume.
9. Press Enter to create the volume, and confirm the selection by
pressing Y.
10. This will now return to the main menu.
11. Select 6.Exit and press Enter, then press Y to exit the RAID
configuration menu.
12. Make sure the Windows 7 OS DVD is in the DVD drive and
as the computer starts up it will automatically boot from the
Windows 7 OS DVD (you will be prompted to press a key to
boot from the DVD).
13. Press Enter to continue installing the operating system as
normal (see your Windows documentation if you need help
on installing the Windows OS).
Figure 2
RAID
Created

RAM Module Speeds
Use either 1333MHz OR 1600MHz DDR3 modules of the
same brand. Do not mix DRAM speeds/brands in order to
prevent unexpected system behavior.
RAID Hard Disks
All hard disks in a RAID should be identical (the same
size and brand) in order to prevent unexpected system
behavior.

6
English
System Map: Front View with LCD Panel Open
2
1
9
8
6
7
4
53
10
Note that the Touchpad and
Buttons valid operational
area is that indicated within
the red dotted lines above.
Figure 3
Front ViewwithLCDPanel
Open
1. PC Camera (Optional)
2. LCD
3. GPU Button
4. LED Indicators
5. Power Button
6. Hot Key Buttons
7. Speakers
8. Keyboard
9. Built-In Microphone
10. Touchpad & Buttons

Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft
is usually prohibited.
Make sure the wire-
less modules are OFF
if you are using the
computer aboard air-
craft.
Use the key combina-
tions to toggle power to
the WLAN/Bluetooth
modules, and check the
LED indicator/visual in-
dicator to see if the
modules are powered
on or not (see Table 5
on page 9).
7
10

7
English
LED Indicators
The LED indicators on the computer display helpful infor-
mation about the current status of the computer.
Table 2 - Front Left LED Indicators
Table 3 - Top Case LED Indicators
Icon Color Description
Orange The AC/DC Adapter is Plugged
In
Green The Computer is On
Blinking Green The Computer is in Sleep Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking Orange The Battery Has Reached Criti-
cally Low Power Status
Green Number Lock Activated
Green Caps Lock Activated
Green Scroll Lock Activated
Icon Color Description
White The Computer is On
Green UMA Mode Activated
Orange Optimus Mode Activated
Green Intel Integrated GPU (iGPU) Activated
Orange NVIDIA Discrete GPU (dGPU) Activated
White Hard Disk Activity
Green The Wireless LAN Module is Powered On
Orange The Bluetooth Module is On

8
English
Hot Key Buttons & Keyboard
Press the Hot Key buttons on the computer to toggle the
appropriate function on/off.
Table 4 - Hot Key Buttons
The keyboard has a numeric keypad for easy numeric data
input. Pressing NumLk turns on/off the numeric keypad.
It also features function keys to allow you to change oper-
ational features instantly.
Figure 4 - Keyboard
Icon Description
PC Camera Power Toggle
Mute Toggle
WLAN Module Power Toggle
Function Keys NumLk &
ScrLk
Numeric
Keypad
Fn Key

Special Characters
Some software applications allow the number-keys to be
used with Alt to produce special characters. These special
characters can only be produced by using the numeric key-
pad. Regular number keys (in the upper row of the key-
board) will not work. Make sure that the numeric keypad is
on.

9
English
Function Keys
The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the
basic function key combinations, visual indicators are available when the hot key driver is installed.
Keys Function/Visual Indicators Keys Function/Visual Indicators
Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F10
() PC Camera Power
Toggle
Fn + F1 Touchpad Toggle Fn + F11
() WLAN Module Power
Toggle
Fn + F2 Turn LCD Backlight Off
(Press a key to or use TouchPad to turn on) Fn + F12 Bluetooth Module Power Toggle
Fn + F3
() Mute Toggle NumLk Number Lock Toggle
Fn + F4 Sleep Toggle Fn + ScrLk Scroll Lock Toggle
Fn + F5/F6 Volume Decrease/
Increase Caps Lock Caps Lock Toggle
Fn + F7 Display Toggle Fn + Esc Control Center Toggle (see page 10)
Fn + F8/F9 Brightness Decrease/
Increase Table 5 - Function Keys & Visual Indicators

10
English
Control Center
Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the
Control Center on/off. The Control Center gives quick access to frequently used controls, and enables you to quickly
turn modules on/off.
Figure 5 - Control Center
Click on any button to turn any of the modules (e.g. TouchPad, Camera) on/off. Click on Power Conservation Modes
to switch between Performance, Balanced or Energy Star modes. To remove the Power Conservation Modes screen
just click in a blank area of the icon or press a key on the keyboard. Click on the buttons (or just click and hold the mouse
button) to adjust the slider for Brightness/Volume. Click on Display Switch/Time Zone/ Desktop Background to
bring up the appropriate Windows control panel. Click on the Sleep button to put the computer into Hibernate or Sleep
modes.
Wireless & Bluetooth
Modules are Off

11
English
Power Modes
You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will
affect the power status of modules (e.g. WLAN or Camera), screen brightness, Touchpad power and Silent Mode. You
can click a Control Center icon to set an overall power mode and then click individual icons in the Control Center to
power on/off any modules etc.
Table 6 illustrates the basic settings for each power mode. If you choose User Defined the settings will correspond to
your selected system settings.
Table 6 - Power Modes
Modes Power Saving Flight Entertainment Quiet Performance User Defined
Icon
Power Plan Power Saver Balanced Power Saver Power Saver High Perfor-
mance
User Defined
Power Conservation Mode Energy Star BIOS Default Energy Star Energy Star Performance
Brightness 14 42 100 42 100
WLAN OFF OFF ON ON ON
PC Camera OFF OFF OFF ON ON
Touchpad ON ON OFF ON ON

12
English
Power Status
The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged
in to a working power outlet. The power status bar will show the current battery charge state.
Brightness
The Brightness icon will show the current screen brightness level. You can use the slider to adjust the screen brightness
or the Fn + F8/F9 key combinations, or use the Fn + F2 key combination to turn off the LED backlight (press any key
to turn it on again). Note that screen brightness is also effected by the Power Mode selected.
Volume
The Volume icon will show the current volume level. You can use the slider to adjust the Volume or the Fn + F5/F6
key combinations, or use the Fn + F3 key combination to mute the volume.
Power Conservation
This system supports Energy Star power management features that place computers (CPU, hard drive, etc.) into a low-
power sleep modes after a designated period of inactivity. Click either the Performance, Balanced or Energy Star
button. Click in a blank area of the icon or press a key on the keyboard to exit Power Conservation Mode without
making any changes.
Sleep
Click the Sleep button to bring up the Hibernate or Sleep buttons, and click either button to havethe computer
enter the appropriate power-saving mode. Click in a blank area of the icon or press a key on the keyboard to exit Power
Conservation Mode without making any changes.

13
English
Display Switch
Click the Display Switch button to access the menu (or use the + P key combination) and select the appropriate
attached display mode.
Time Zone
Clicking the Time Zone button will access the Date and Time Windows control panel.
Desktop Background
Clicking the Desktop Background button will allow you to change the desktop background picture.
Touchpad/PC Camera/Wireless LAN Module /Bluetooth Module
Click any of these buttons to toggle the Touchpad or module’s power status. A crossed out icon will appear over the top
left of the icon when it is off. Note that the power status of a module, and Touchpad power, is also effected by the
Power Mode selected.
Caps Lock/Scroll Lock/ Number Lock
Click the button to toggle the appropriate lock mode.

14
English
System Map: Front, Left, Right & Rear Views
1Front
10 13
12
11
14
Right
Rear
25
4
38
67
Left
9
15

USB
The USB 3.0 ports are colored blue. USB 3.0 will transfer data much faster than USB 2.0,
and is backwards-compatible with USB 2.0.
10
Figure 6
Front, Left, Right & Rear
Views
1. LED Indicators
2. Security Lock Slot
3. USB 2.0 Port
4. Headphone-Out Jack
5. Microphone-In Jack
6. S/PDIF-Out Jack
7. Optical Device Drive Bay
8. Emergency Eject Hole
9. Multi-in-1 Card Reader
10. USB 3.0 Ports
11. Combined eSATA/USB
3.0 Port
12. HDMI-Out Port
13. RJ-45 LAN Jack
14. External Monitor Port
15. DC-In Jack
16. Vent
10
16
