Bucher V Series Manual

Bucher Municipal
V Range
ECN - 721264 Print date - 29.04.2021
Information
General Arrangement
Controls
Operation
Optional Equipment
Operator’s Guide
JVM
Routine Maintenance
Conformity Certificates
Vt - Twin Engine Specific to Twin Engine Sweepers.
Vh - Single Engine Specific to Single Engine Hydrostatic Sweepers.
Vm - Mekavac
Specific to Single Engine Semi-
Hydrostatic Sweepers.
Safety
1
3
4
5
6
7
8
9
2
V Range Suction Sweepers
Incorporating:
V50t • V65t • V80t
Twin engine machines
V50h • V65h • V80h
Single engine, Hydrostatic machines
V50m • V65m • V80m
Single engine, Semi-Hydrostatic machines
Part No. 01294-1-GB
Revision Level B


Bucher Municipal
V Range
V50 • V65 •V80 Operator’s Guide
3
Table of Contents
TABLE OF CONTENTS
1 Information 5
Foreword ��������������������������������������������������������������������������������������������������������6
Replacement Parts�����������������������������������������������������������������������������������������7
International Symbols�������������������������������������������������������������������������������������9
2 Safety 11
For Your Safety ��������������������������������������������������������������������������������������������13
Machine Warning Labels������������������������������������������������������������������������������15
3 General Arrangements 17
General Arrangements ���������������������������������������������������������������������������������19
Equipment Access����������������������������������������������������������������������������������������21
4 Controls 23
Cab Mounted Controls ���������������������������������������������������������������������������������25
Warning LED ������������������������������������������������������������������������������������������������27
Information Bar LED�������������������������������������������������������������������������������������29
Centre Console ��������������������������������������������������������������������������������������������33
Soft Keys and Encoder ��������������������������������������������������������������������������������35
Door Controller ���������������������������������������������������������������������������������������������37
Multifunctional Joystick Controls - Trailing Sweepgear�������������������������������� 39
Multifunctional Joystick Controls - Front Facing Sweepgear ����������������������� 41
Multifunction Wireless Pendant��������������������������������������������������������������������43
Powasave Regulator ������������������������������������������������������������������������������������43
Systems Wafer Fuses ����������������������������������������������������������������������������������45
External Controls �����������������������������������������������������������������������������������������47
Front Facing Sweepgear Water Taps ���������������������������������������������������������� 49
5 Operation 51
Vehicle Start Up - Vt���������������������������������������������������������������������������� 53
Commence Sweeping - Vt ������������������������������������������������������������������� 53
Vehicle Start Up - Vh��������������������������������������������������������������������������� 55
Commence Sweeping - Vh ������������������������������������������������������������������ 55
Vehicle Start Up - Vm�������������������������������������������������������������������������� 57
Commence Sweeping - Vm ����������������������������������������������������������������� 57
To Terminate Sweeping����������������������������������������������������������������������� 58
Load Discharge and Auto Body Prop��������������������������������������������������� 59
End of Day Cleaning ��������������������������������������������������������������������������� 60
Cold Weather Precautions������������������������������������������������������������������� 60
Sweeping in Cold Temperatures���������������������������������������������������������� 61
Towing or Craning the Vehicle������������������������������������������������������������� 61
DPF and Aftertreatment����������������������������������������������������������������������� 63

Bucher Municipal
V Range
V50 • V65 •V80 Operator’s Guide
4Table of Contents
6 Optional Equipment 67
Combivac Nozzle��������������������������������������������������������������������������������� 69
Rear Mounted Suction Nozzles ����������������������������������������������������������� 71
Microtrap ��������������������������������������������������������������������������������������������� 73
Varagap Nozzle����������������������������������������������������������������������������������� 73
Variabrush������������������������������������������������������������������������������������������� 73
Rear Mesh Shaker ������������������������������������������������������������������������������ 75
Rotatilt������������������������������������������������������������������������������������������������� 75
Powathrust and Powascrub ����������������������������������������������������������������� 75
Side Sliding Brush������������������������������������������������������������������������������� 77
Supawash ������������������������������������������������������������������������������������������� 79
Hand Lance Detergent Injection ���������������������������������������������������������� 83
Wanderhose and Littasnatch ��������������������������������������������������������������� 85
Wanderhose - Powaboom ������������������������������������������������������������������� 87
Littasnatch������������������������������������������������������������������������������������������� 87
Water Recirculation ����������������������������������������������������������������������������� 89
Easiclean System�������������������������������������������������������������������������������� 91
7 JVM 93
Safety Notice��������������������������������������������������������������������������������������� 95
JVM Date and Time Memory ��������������������������������������������������������������� 95
Description ������������������������������������������������������������������������������������������ 97
Location of J-Plex Components ���������������������������������������������������������� 97
Switching On ��������������������������������������������������������������������������������������� 99
Main Menu ���������������������������������������������������������������������������������������� 101
Menu Navigation ������������������������������������������������������������������������������� 103
Vehicle Logging (Data Capture)��������������������������������������������������������� 109
Reverse Aid Camera ������������������������������������������������������������������������� 113
Display Settings �������������������������������������������������������������������������������� 113
System Faults ����������������������������������������������������������������������������������� 117
Switching Off������������������������������������������������������������������������������������� 119
8 Routine Maintenance 121
Maintenance Schedules �������������������������������������������������������������������� 122
Equipment Adjustment / Maintenance������������������������������������������������ 127
Water System������������������������������������������������������������������������������������ 145
Powapack������������������������������������������������������������������������������������������ 147
Lubrication Diagrams������������������������������������������������������������������������� 155
Autolube Pump ��������������������������������������������������������������������������������� 162
9 Conformity Certificates 165
UK Declaration of Conformity Certificates������������������������������������������ 166
EC Declaration of Conformity Certificates������������������������������������������ 167
PM10 Emission ��������������������������������������������������������������������������������� 168
Noise and Vibration ��������������������������������������������������������������������������� 169

Bucher Municipal
V Range
5
V50 • V65 •V80 Operator’s Guide
1 Information

Bucher Municipal
V Range
6Information
V50 • V65 •V80 Operator’s Guide
The Bucher Municipal V50, V65 and V80 Range of Suction Sweeper represents the highest grade
of craftsmanship and reliability that makes Bucher Municipal probably the world leader in sweeping
technology.
This machine is designed for the removal of spoil on traffic or pedestrian areas, and litter collection
using the Wanderhose [Ref. EN 13019], and should only be driven by trained operatives.
This machine should not be used for sweeping hot or burning substances. In the unlikely event of a
fire, normal powder or foam fire fighting equipment can be used on this product.
An operator should receive training in the follow elements:
1 Safety Observations/Notices
2 Transit driving
3 Correct use of body prop
4 In cab controls
5 External controls
6 Sweeping techniques
7 Load discharge
8 Channel brush setting and changing
9 WSB setting and changing
10 Nozzle setting and Maxigap operation
11 Daily and weekly maintenance items
12 Driving/operation assessment
13 End of day cleaning of body and machine
Bucher Municipal can provide operator training upon request.
We would point out that it is the employers responsibility to carry out his own Risk Assessment on
the equipment in his particular working environment and work application.
This handbook should be carefully studied. In it you will find instructions for the operation and
maintenance of your Bucher Municipal sweeper.
It is vitally important that the operator and maintenance staff have a copy of this book. The life of
the machine will depend upon following these instructions in respect of regular maintenance and
correct operating methods.
It is important that only GENUINE BUCHER MUNICIPAL SPARE PARTS are used when servicing
and maintaining the sweeper. This is especially important for consumables, filters etc, as the use of
non-genuine parts may cause premature failure and invalidation of warranty.
When carrying out maintenance or part replacement, additional explanatory illustrations can be
found in the Parts Manual, which shows and lists hardware, and availability of spares with the
orientation and positions of the various components.
FOREWORD

Bucher Municipal
V Range
M02MS-005a
BA C D
7
Information
V50 • V65 •V80 Operator’s Guide
REPLACEMENT PARTS
It is important that only GENUINE BUCHER MUNICIPAL SPARE PARTS are used when servicing
and maintaining the sweeper. This is especially important for consumables, filters etc. as the use of
non-genuine parts may cause premature failure and invalidation of warranty.
Serial number comprises of:
(A) Model number V65t (example)
(B) EQ number XXXXXX
(C) Year of manufacture XX
(D) Manufacture sequence number XXXX
For the latest parts information please refer to our on-line interactive catalogues which are available
through our E-Shop. To access or to open an account, please follow the instructions on the Bucher
Municipal website: www.buchermunicipal.co.uk
When making enquiries or ordering spare parts the Bucher Municipal Serial Number should
be quoted. The number will be found stamped on a plate attached to the right hand side of the
subframe (see above).

Bucher Municipal
V Range
M02OG-001-5
1a
1a 2
1b
5
ULTRA LOW SULFUR
FUEL ONLY
S≤15 mg/kg
3
4
1b
8Information
V50 • V65 •V80 Operator’s Guide

Bucher Municipal
V Range
9
Information
V50 • V65 •V80 Operator’s Guide
Conforming to ISO 3767
Graphical symbols are used to indicate the water, fuel and hydraulic oil tank filler ports and air
cleaner servicing instructions.
Their location and descriptions are shown below.
(1) Water tank filler ports (1a) = Hose Pipe
(1b) = Hydrant
(2) Hydraulic oil tank filler
(3) Fuel tank filler - Engine requires standard diesel fuel
85kW engine only
(4) Fuel tank filler - Engine requires Ultra Low Sulfur fuel
55kW & 93/97kW engines only
(5) Engine air cleaner instructions, i.e. use only genuine Bucher
Municipal replacement air cleaner elements and refer to Chapter 8
of this guide for servicing instructions
Label Description
CAUTION: Only 55kW & 93/97kW engines require Ultra Low Sulfur fuel.
Standard diesel fuel causes fault to SCR system.
INTERNATIONAL SYMBOLS

Bucher Municipal
V Range
10 Information
V50 • V65 •V80 Operator’s Guide

Bucher Municipal
V Range
11
V50 • V65 •V80 Operator’s Guide
2 Safety

Bucher Municipal
V Range
12 Safety
V50 • V65 •V80 Operator’s Guide
This page is intentionally blank

Bucher Municipal
V Range
13
Safety
V50 • V65 •V80 Operator’s Guide
Meanings of signal words used with safety warnings (ISO 3864)
NOTICE: Indicates a hazardous situation with a risk of damage to equipment
(ANSI Z535.6).
CAUTION: Indicates a hazardous situation with a low level of risk. Indicates a
potentially hazardous situation which if not avoided may result in minor or moderate
injury.
WARNING: Indicates a hazardous situation with a medium level of risk. Indicates
an imminently hazardous situation which if not avoided could result in serious injury
or death.
DANGER: Indicates an imminently hazardous situation with a high level of risk
which if not avoided, will result in serious injury or death.
Basic safety precautions are described in Section 3.
Important operating and safety information is marked with the following SIGNAL words:
NOTICE, CAUTION, WARNING and DANGER.
SIGNAL WORDS AND SYMBOLS ARE SHOWN AS FOLLOWS:-
SIGNAL WORD
Type and source of hazard.
Measures to be taken to protect against the hazard.
The NOTICE signal word does not have the triangle safety alert symbol.
FOR YOUR SAFETY

Bucher Municipal
V Range
M02OG-145-2
Vh only
1
2
5
5
4
3
3
6
2
14 Safety
V50 • V65 •V80 Operator’s Guide

Bucher Municipal
V Range
15
Safety
V50 • V65 •V80 Operator’s Guide
(1)
(2)
(3)
(4)
(5)
(6)
CAUTION
Read Operator’s Guide
To avoid scalding do not release radiator cap when hot
WARNING
Read Operator’s Guide
Keep clear of brushes
Crushing of whole body - force applied from above - ensure body prop
correctly engaged
WARNING
Read Operator’s Guide
Crushing of whole body - force applied from above - Ensure body prop
correctly engaged
Severing of fingers or hand - Impeller blade
Never reach in or drop tools into the fan case
Wear ear defenders when working in this area
DANGER
Vh/Vm only:
Arm entanglement
Never touch rotating shaft
CAUTION
Wear ear defenders when working in this area
Stay at least 1 metre distance from the machine
DANGER
Use safety warning triangle if body is raised on the highway
MACHINE WARNING LABELS
Label Description
NOTICE:
Ensure that all safety labels are always kept clean and visible.
Replace any missing or illegible safety labels.
Ensure any safety labels are affixed to replacement parts as required.
Vt/Vh/Vm

Bucher Municipal
V Range
16 Safety
V50 • V65 •V80 Operator’s Guide

Bucher Municipal
V Range
1717
V50 • V65 •V80 Operator’s Guide
3 General Arrangements

Bucher Municipal
V Range
10
8
9
11
17
15
20
26
28
16
19
21
31
29
29
32
18
22
12
M02OG-002-9
5
6
30
1
2
4
3
29
23
24
4
7
25
13
27
33
33
34
7 34
14
General Arrangements
18
V50 • V65 •V80 Operator’s Guide

Bucher Municipal
V Range
General Arrangements 19
V50 • V65 •V80 Operator’s Guide
GENERAL ARRANGEMENTS
Item Component Page
(1) Hopper/load compartment -
(2) Cowling -
(3) Body (hopper and cowl) prop 59
(4) Auxiliary engine (Vt Only) 118
(5) Fuel tank (Vt/Vh only) 9
(6) Hydraulic oil reservoir 149
(7) Suction fan case 141
(8) Systems locker 45
(9) Channel brush 127
(10) Suction nozzle 131
(11) Wide sweep brush 107, 129
(12) *Wanderhose 85
(13) *Wanderhose extension tubes 85
(14) Cab Mounted Controls 25
(15) Filter screens 143
(16) Wearing plate(s) -
(17) Hopper centre baffle - duals only -
(18) Intake flaps -
(19) Water tank 9
(20) Water tank filler 9
(21) Water tank hydrant filler 9, 81
(22) Water tank drain/flushing valve 89
(23) Rear door screen 89
(24) Rear door drainage tap 89
(25) Water tank flushing ports -
(26) Primary suction filter 145
(27) Secondary suction filter 145
(28) Extended water tank plug -
(29) Water spray jets -
(30) Washdown hose 47
*Wanderhose Water 47
*Littasnatch Water 47
(31) *Supawash hose reel 79, 81
(32) *Easiclean 91
(33) *Rear Suction 71
(34) *Side Sliding Brush 77
Cold Weather Drains
(*) Optional Equipment

Bucher Municipal
V Range
M02OG.139-2
General Arrangements
20
V50 • V65 •V80 Operator’s Guide
This manual suits for next models
9
Table of contents
Popular Blower manuals by other brands

Hitachi
Hitachi RB24E Handling instructions

Makita
Makita maktec MT401 technical information

Scheppach
Scheppach S700 Translation from the original instruction manual

Surtek
Surtek SAG532 User's Manual and Warrantly

Talon Tools
Talon Tools ABA103 user manual

GreenWorks Pro
GreenWorks Pro UltraPower 60X Series Operator's manual
