Buderus Logano G215 WS User manual

Please read thoroughly before use.
6302 6959 – 02/2006 GB For the user
Operating instructions
Logano G215 WS
Oil and gas-fired boilers

2Operating instructions Logano G115 WS oil/gas-fired special boilers • Issue 02/2006
We reserve the right to make any changes due to technical modifications.
Overview
Regulations and directives
Installation:
90/396/EEC gas appliance directive
92/42/EEC boiler efficiency directive
73/23/EEC low voltage directive
89/336/EEC EMC directive
97/23/EC pressure equipment directive
current Gas safety (Installation and Use) Regulations
The Building Regulations
Building Standards (Scotland)
IEE Wiring Regulations BS 7671
National and ByLaws of the local water undertaking
Corgi registered required to work on the appliance (Competent Persons)
Oftec registered required to work on the appliance (Competent Persons)
Codes of practice:
BS 6880 Code of practice for low temperature hot water heating systems for output greater than 45kW
BS 6644 Specification for Installation of gas-fired hot water boilers of rated inputs between 70kW (net) and
1.8 MW (net) (2nd and 3rd family gases)
CP 342.2 centralised hot water supply
BS 5449 Forced circulation hot water systems
BS 5546 Installation of gas hot water supplies for domestic purpose (2nd. Family Gases)
BS 6891 Low pressure installation pipes
BS 5410 Code of practice for Oil firing Part 2
BS 5854 & IM/11 Codes of Pracitice for flues (as appropriate)
BS 7074 Application Selection & Installation of Expansion vessels & ancillary for sealed water systems Part 2
IGE/UP/1 Soundness testing & purging of industrial & commercial installations
IGE/UP/2 Gas installation pipework and compressors on industrial and commercial premises
IGE/UP/7 Gas installations in Timber framed buildings
IGE/UP/10 Installation of gas appliances in industrial and commercial premises, part 1: flued appliances
CISBE Guide
Management of Health and & Safety at work regulations 1992 - Guidance note PM5
Health & Safety at work act 1974
Manual Handling Regulations 1992
The Electricity at Work Regulations, 1989

3
We reserve the right to make any changes due to technical modifications.
Operating instructions Logano G215 WS oil/gas-fired special boilers • Issue 02/2006
Index
1 For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.1 About this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.2 Correct use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.3 Key to symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.4 Please observe these notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2 Product description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3 Operation of the heating system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.1 Switching on the heating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.2 Switching off the heating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.3 Emergency measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.4 Check the operating pressure, if necessary top up with heating water and vent the system. . .7
3.4.1 When should you check the operating pressure? . . . . . . . . . . . . . . . . . . . . . . . . .7
3.4.2 Operating pressure, checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3.4.3 Filling the heating system and checking for leaks . . . . . . . . . . . . . . . . . . . . . . . . .7
3.4.4Filling the heating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3.5 Operating tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3.6 Why is regular maintenance important? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4 Trouble shooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

4Operating instructions Logano G215 WS oil/gas-fired special boilers • Issue 02/2006
We reserve the right to make any changes due to technical modifications.
For your safety1
1 For your safety
1.1 About this manual
These installation and maintenance instructions contain
important information for the safe and correct
installation, initial start-up and maintenance of this
boiler.
In the following text, the Logano G215 WS oil and gas-
fired boilers will generally be described as „the boiler“.
1.2 Correct use
The boiler is designed for generating heating water and
domestic hot water (DHW) when used with hot water
cylinder, for example, in detached homes or in
apartment buildings or smaller commercial properties.
1.3 Key to symbols
In these instructions, the following symbols are used:
ÎCross-references
Cross-references to a specific point or another
document are identified by an arrow Î.
1.4 Please observe these notes
You will learn how to use your heating system by
–letting your installer instruct you when the system is
handed over and
–reading these operating instructions carefully.
Do not carry out any work on the boiler that is not
described in these operating instructions.
1.4.1 If you notice a smell of gas
1.4.2 Tips regarding the installation room
WARNING!
RISK TO LIFE
Identifies possible risks which may lead to
serious injury or death if appropriate care is
not taken.
CAUTION!
RISK OF INJURY/
SYSTEM DAMAGE
Identifies potentially dangerous situations
which might lead to medium or slight
injuries or to material losses.
PLEASE NOTE
User tip for the optimum utilisation and
setting of the control(s) plus useful
information.
WARNING!
RISK TO LIFE
by unqualified personnel.
zInstallation, commissioning and
maintenance must only be carried out
by a specialist installer. Work on
electrical and fuel-bearing components
in particular must only be carried out by
suitably qualified personnel.
WARNING!
RISK TO LIFE
through the explosion of volatile gases.
There is a risk of explosion if you can smell
gas.
zKeep naked flames away. Do not
smoke. Do not use lighters.
zAvoid sparks!
Do not operate electrical switches,
including telephones, plugs or door-
bells.
zClose the main gas shut-off valve.
zOpen windows and doors.
zWarn all occupants, but do not use
doorbells.
zLeave the building.
zCall your gas supplier and your local
heating engineer from outside the
building.
zIf necessary, notify police or fire
brigade!
zImmediately leave the danger zone if
you hear gas escaping.
WARNING!
RISK TO LIFE
through poisoning.
Insufficient ventilation can lead to
dangerous flue gas leaks.
zNever close or obstruct air ducts and
vent apertures or reduce their size.
zThe boiler must not be operated, until
the obstruction has been removed.
WARNING!
RISK OF FIRE
through flammable material or liquids.
zNever store flammable materials or
liquids in the immediate vicinity of the
boiler.

Product description 2
5
We reserve the right to make any changes due to technical modifications.
Operating instructions Logano G215 WS oil/gas-fired special boilers • Issue 02/2006
2 Product description
This boiler is a low temperature boiler for oil or gas
combustion with modulating boiler water temperature
control.
Your specialist heating company has equipped the
boiler with a suitable burner.
The boiler comprises:
–Control device
–Boiler casing
–Boiler block with thermal insulation
The control device monitors and controls all electrical
boiler components.
The boiler casing prevents energy losses and acts as
sound insulation.
The boiler block transfers the heat generated by the
burner to the heating water. The thermal insulation
prevents energy losses. Fig. 1 Boiler without burner
1Control device
2Boiler casing
3Boiler block with thermal insulation
4Burner door casing
1
2
3
4
This product meets all basic requirements
of relevant standards and directives.

6Operating instructions Logano G215 WS oil/gas-fired special boilers • Issue 02/2006
We reserve the right to make any changes due to technical modifications.
Operation of the heating system3
3 Operation of the heating system
3.1 Switching on the heating system
Before switching the system on, check
–that the operating pressure is high enough,
–that the fuel supply at the main shut-off valve is open
and
–that the heating system emergency stop switch is
switched on.
zSwitch the boiler water thermostat to "AUT"
(Automatic).
zSwitch the ON/OFF switch to ON (position "I"). This
switches on the entire heating system.
3.2 Switching off the heating system
zSwitch the ON/OFF switch on the control to OFF
(position "0"). This switches the boiler and all its
components OFF (for example the burner).
zClose the main fuel shut-off valve.
3.3 Emergency measures
In the event of an emergency, e. g. a fire, proceed as
follows:
zClose the main fuel shut-off valve.
zIsolate the heating system from the mains power
supply via the heating system emergency stop switch
or a corresponding domestic fuse.
Fig. 2 Switching on the heating system (Logamatic 2000)
1Set the boiler water thermostat
2ON/OFF switch
Fig. 3 Switching on the heating system (Logamatic 4000)
1Set the boiler thermostat
2ON/OFF switch
I0
1
2
12
PLEASE NOTE
Operating instructions, e. g. how to set the
temperature, can be found in the Îcontrol
unit documentation.
CAUTION!
SYSTEM DAMAGE
through frost.
The heating system can freeze up, if it has
been shut down.
zLeave the heating system switched ON
as long as possible.
zProtect your heating system against
freezing by draining the heating
system and DHW pipework at the
lowest possible point.

Operation of the heating system 3
7
We reserve the right to make any changes due to technical modifications.
Operating instructions Logano G215 WS oil/gas-fired special boilers • Issue 02/2006
3.4 Check the operating pressure, if necessary top up with heating water and vent the
system
3.4.1 When should you check the operating
pressure?
Recently topped-up heating water loses much of its
volume in the first few days because it releases gases.
This causes air pockets, and the heating system will
start to rumble.
zAfter installing a new heating system, check the
operating pressure daily for the first few days. If
necessary top up with heating water and bleed the
radiators.
zAfter a while the operating pressure will only need to
be checked monthly. If necessary top up with heating
water and bleed the radiators.
3.4.2 Operating pressure, checking
The installer will have set the red needle on the pressure
gauge to the required operating pressure (at least 1 bar
pressure).
zCheck that the pressure gauge needle is within the
green range.
zTop up with heating water if the pressure gauge
needle is below the green range.
3.4.3 Filling the heating system and checking for
leaks
Before commissioning the heating system, check for
leaks to prevent problems during operation. Pressurise
the heating system to 1.3x permissible operating
pressure (observe the safety pressure of the safety
valve).
zShut off the pressure expansion vessel from the
system by closing the cap valve.
zCheck the connections and pipework for leaks.
zOpening the mixing and shut-off valves on the hot
water (primary) side.
zFill the system via an approved filling link.
Fig. 4 Pressure gauge for sealed systems
1Red needle
2Pressure gauge needle
3Green marking
3
1
2
CAUTION!
SYSTEM DAMAGE
over pressure during leak testing.
Pressure, control and safety equipment
may be damaged through excessive
pressure.
zWhen you carry out a leak test, make
sure that no pressure, control or safety
equipment is fitted which cannot be
isolated from the boiler water chamber.

8Operating instructions Logano G215 WS oil/gas-fired special boilers • Issue 02/2006
We reserve the right to make any changes due to technical modifications.
Operation of the heating system3
3.4.4 Filling the heating system
Filling and refilling of the heating circuit must been
carried out by a method that has been approved by the
Water Regulation Advisory Scheme (WRAS), for the
type of heating appliances, i.e. Domestic (in-house)
Fluid Category 3. Non-Domestic (other than in-house)
Fluid Category 4. Depending on the Fluid Category the
approved method should comprise of the following:
1. Requirements Fluid Category 3 systems (fig see
below)
zControl valve (stop valve) including a double check
valve on the mains cold water supply pipe
zTemporary connection to e removed after filling
(filling loop)
zControl valve (stop valve) on the heating system
pipework
2. Requirements Fluid Category 4 systems (fig see
below)
zControl valve (stop valve) on the mains cold water
supply pipe
zStrainer
zVerifiable Backflow Prevention Device with reduced
pressure Zone(RPZ valve assembly) incorporating a
Type BA air gap
zTundish
zControl valve (stop valve) on the heating system
pipework
zShut off the pressure expansion vessel from the
system by closing the cap valve.
zSlowly fill the heating system. Observe the pressure
gauge whilst filling.
zClose the water tap and the boiler fill & drain valve
once the required operating pressure has been
reached.
Fig. 5 Requirements Fluid Category 3 systems
Fig. 6 Requirements Fluid Category 4 systems

Operation of the heating system 3
9
We reserve the right to make any changes due to technical modifications.
Operating instructions Logano G215 WS oil/gas-fired special boilers • Issue 02/2006
3.5 Operating tips
Correct fuel
This heating system requires fuel of the correct type and
grade to ensure its proper operation.
Follow the advice of your installer if you want to convert
your heating system to another type of fuel or use fuel
with a different specification.
Location
3.6 Why is regular maintenance important?
Heating systems should be regularly maintained for the
following reasons:
–to achieve a high level of efficiency and to operate
the system economically (low fuel consumption),
–to achieve a high level of operational reliability,
–to maintain the highest level of environmentally
responsible combustion.
Use the following fuel only:
Company stamp/date/signature
CAUTION!
SYSTEM DAMAGE
through incorrect fuel.
zOnly use the fuel specified.
CAUTION!
BOILER DAMAGE
through contaminated drawn into the boiler
air.
zNever use chlorinated cleaning agents
or halogenated hydrocarbons (as, for
example, contained in spray cans,
solvents or cleaning agents, paints and
adhesives).
zAvoid very dusty atmospheres.
CAUTION!
SYSTEM DAMAGE
through a lack of, or unsatisfactory,
cleaning and maintenance.
zHave your system inspected, cleaned
and maintained annually by your
installer or a service engineer.
zWe recommend you enter into a
contract covering an annual inspection,
and maintenance as required.

10 Operating instructions Logano G215 WS oil/gas-fired special boilers • Issue 02/2006
We reserve the right to make any changes due to technical modifications.
Trouble shooting4
4 Trouble shooting
We differentiate between two types of faults
–Burner faults and
–Control unit and heating system faults.
A fault lamp on the burner illuminates if the burner
develops a fault. Generally, such faults can be reset by
pressing the reset button on the burner.
Control device and heating system faults are indicated
on the control device display, subject to the control
device being equipped with a display. For further
information see Îcontrol device documentation.
Correcting burner faults
zPress the burner reset button (Îburner
documentation).
Fig. 7 Resetting the burner
1Burner
1
CAUTION!
SYSTEM DAMAGE
through frost.
The heating system can freeze up, if it has
been switched OFF through a fault
shutdown.
zTry to remedy the fault.
zContact your installer immediately if
this is not possible.

11
We reserve the right to make any changes due to technical modifications.
Operating instructions Logano G215 WS oil/gas-fired special boilers • Issue 02/2006
Notes

.
Your installer:
Buderus
Cotswold Way, Warndon, Worcester WR4 9SW
Tel.: [phone], Fax: [phone]
www.buderus-commercial.co.uk
In the UK, Buderus is a trading name of
BBT Thermotechnology Ltd.
BBT Thermotechnik GmbH
D-35573 Wetzlar
www.heiztechnik.buderus.de
[email protected]
