Buffalo FB863 User manual

Model • Modèle • Modell • Modello • Modelo • Malli:
FB863 / FE141-E
34L 1800W
Manual Microwave
Instruction manual
FB863_FE141-E_UK_A5_v1_20201103.indb 1FB863_FE141-E_UK_A5_v1_20201103.indb 1 2020/11/3 09:162020/11/3 09:16

2
UK
Safety Tips
To reduce the risk of fire, electric shock, injury to persons or
exposure to excessive microwave oven energy when using your
appliance, follow basic precautions, including the following:
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO MICROWAVE ENERGY
Do not attempt to operate this oven with the door open, since
this can result in harmful exposure to microwave energy. It is
important not to break or tamper with the safety interlocks.
Do not place any object between the oven front face and the
door or allow soil or cleaner residue to accumulate on sealing
surfaces.
Warning: If the door or door seals area damaged, the oven
must not be operated until it has been repaired by a competent
person.
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• Warning: Liquids and other foods must not be heated in
sealed containers since they are liable to explode.
FB863_FE141-E_UK_A5_v1_20201103.indb 2FB863_FE141-E_UK_A5_v1_20201103.indb 2 2020/11/3 09:162020/11/3 09:16

3
UK
• Warning: It is hazardous for anyone other than a competent
person to carry out any service or repair operation that
involves the removal of a cover which gives protection against
exposure to microwave energy.
• Only use utensils suitable for use in microwave ovens.
• The oven should be cleaned regularly and any food deposits
should be removed.
• When heating food in plastic or paper containers, keep an eye
on the oven due to the possibility of ignition.
• If smoke is observed, switch off or unplug the appliance and
keep the door closed in order to stifle any flames.
• Do not overcook food.
• Do not use the oven cavity for storage purposes. Do not store
items, such as bread, cookies, etc. inside the oven.
• Remove wire twist-ties and metal handles from paper or
plastic containers/bags before placing them in the oven.
• Install or locate this oven only in accordance with the
installation instructions provided.
• Eggs in the shell and whole hard-boiled eggs should not be
heated in microwave ovens since they may explode, even after
microwave heating has ended.
• Use this appliance only for its intended uses as described in
manual. Do not use corrosive chemicals or vapours in this
appliance. This oven is especially designed to heat. It is not
designed for industrial or laboratory use.
• Do not store or use this appliance outdoors.
• Do not use this oven near water, in a wet basement or near a
swimming pool.
• The temperature of accessible surfaces may be high when
the appliance is operating. The surfaces are liable to get hot
during use. Keep cord away from heated surface, and do not
cover any vents on the oven.
FB863_FE141-E_UK_A5_v1_20201103.indb 3FB863_FE141-E_UK_A5_v1_20201103.indb 3 2020/11/3 09:162020/11/3 09:16

4
UK
• Do not let cord hang over edge of table or counter.
• Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life
of the appliance and possibly result in a hazardous situation.
• Warning: The contents of feeding bottles baby food jars
shall be stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
• Warning: Microwave heating of beverages result in delayed
eruptive boiling, therefore care must be taken when handling
the container.
• Liquids such as water, coffee and tea can overheat beyond
boiling point without appearing to be boiling.
• Always switch off and disconnect the power supply to the unit
before cleaning or carrying out maintenance.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a
BUFFALO agent or a recommended qualified technician in
order to avoid a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Do not operate the oven when empty.
• The microwave oven shall not be placed in a cabinet unless it
has been tested in a cabinet.
• The appliance is not intended to be operated by means of an
external timer or separate remote-control system.
• Do not use jet/pressure washers to clean the appliance.
FB863_FE141-E_UK_A5_v1_20201103.indb 4FB863_FE141-E_UK_A5_v1_20201103.indb 4 2020/11/3 09:162020/11/3 09:16

5
UK
• Buffalo recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
• Buffalo recommend that this product is connected to a circuit
protected by an appropriate RCD (Residual Current Device).
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your BUFFALO product.
Pack Contents
The following is included:
• Microwave Oven • Instruction manual
BUFFALO prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your BUFFALO dealer immediately.
Installation
1. Remove all packaging materials. Make sure that all protective plastic film and coatings are thoroughly
removed from all surfaces.
Warning: Check for any of the following damage that may have occurred:
• Misaligned or bent door, damaged door seals/sealing surface, broken/loose
door hinges, dents in the oven interior.
• DO NOT operate the oven if any damage is found. Call a BUFFALO agent or
qualified Technician.
2. Position the oven on a flat, stable and heat-
resistant surface. For sufficient ventilation,
allow a minimum of 30cm of space above the
oven, 10cm at the back and sides.
Note: Do not cover or block any
openings on the appliance, or
remove the feet.
3. Place the oven as far away from radios and
TV as possible as operation of the appliance
may cause interference to your radio or TV
reception.
30cm
10cm
10cm
FB863_FE141-E_UK_A5_v1_20201103.indb 5FB863_FE141-E_UK_A5_v1_20201103.indb 5 2020/11/3 09:162020/11/3 09:16

6
UK
Stacking the appliance
Note: To save space, a maximum of 2 appliances can be stacked together. For
details, please follow below instructions.
1. Loosen the screws that fix the mounting plates. Then remove the mounting plates and re-tighten the
screws in place (Step A).
2. Remove the 4 screws as shown in Step B.
3. Locate the mounting plates to the joined parts of the 2 ovens, then fix with the screws just removed
(Step C).
Utensils
See the instructions in this chapter for utensils to use/avoid with microwaving.
If in doubt, please check the manufacturer’s instructions if your utensil is microwave safe or not.
FB863_FE141-E_UK_A5_v1_20201103.indb 6FB863_FE141-E_UK_A5_v1_20201103.indb 6 2020/11/3 09:162020/11/3 09:16

7
UK
Materials you can use in microwave oven
Utensils
(Not included)
Remarks
Browning dish Follow manufacturer’s instructions. The bottom of browning dish must be
placed smoothly on the ceramic board. Incorrect usage may the ceramic board
to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or
chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars are
not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not
use cracked or chipped dishes.
Oven cooking bags Follow manufacturer’s instructions. Do not close with metal tie. Make slits to
allow steam to escape.
Paper plates and cups Use for short-term cooking/warming only. Do not leave oven unattended while
cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for a
short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer’s instructions. Should be labelled
“Microwave Safe”. Some plastic containers soften, as the food inside gets hot.
“Boiling bags” and tightly closed plastic bags should be slit, pierced or vented
as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture. Do
not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers)
Wax Paper Use a cover to prevent splattering and to help retain moisture
Materials to be avoided in microwave oven
Utensils
(Not included)
Remarks
Aluminium tray May cause arcing. Transfer food into microwave-safe dish
Food carton with metal
handle
May cause arcing. Transfer food into microwave-safe dish
Metal or metal-
trimmed utensils
Metal shields the food from microwave energy. Metal trim may cause arcing
Metal twist ties May cause arcing and could cause a fire in the oven
Paper bags May cause a fire in the oven
Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed to high
temperature
Wood Wood will dry out when used in the microwave oven and may split or crack
FB863_FE141-E_UK_A5_v1_20201103.indb 7FB863_FE141-E_UK_A5_v1_20201103.indb 7 2020/11/3 09:162020/11/3 09:16

8
UK
Knowing your appliance
DB
C
E A
A) Control panel
B) Observation window
C) Door assembly
D) Safety interlock system
E) Ceramic board
A) Control panel:
Display Power level knob Time knob
Note:
1. DO NOT press the ceramic board forcibly.
2. Take and put the utensils gently to avoid damage to the
ceramic board.
3. After use, DO NOT touch the ceramic board with hand to
avoid high temperature scalding.
Operation
Note: Before first time use, wipe clean the interior surfaces and let dry well.
Idle mode
1. Connect the appliance to the mains power supply. The display will show “_ _ _ _ _ _ _”.
2. When the display becomes blank, the appliance will enter Idle mode.
3. During idle mode, no knob can be turned.
FB863_FE141-E_UK_A5_v1_20201103.indb 8FB863_FE141-E_UK_A5_v1_20201103.indb 8 2020/11/3 09:162020/11/3 09:16

9
UK
Ready mode
1. While in idle mode, open and then close the door to enter Ready mode.
2. In Ready mode, “READY” is shown.
Start Cooking
1. While in Ready mode, turn the power level knob to desired power level.
Power 100% 90% 70% 50% 30% 20% 0%
Display 100 90 70 50 30 20 0
2. Select the cooking time using the time knob (Maximum time: 60 minutes). After about 2 seconds, the
appliance will start automatically.
3. When cooking time elapses, the appliance will beep and “DONE” will be shown.
4. Soon the display will change to show “READY”, indicating the oven is in Ready mode again.
5. The fan will continue to run for 1 minute to cool the appliance, then stop automatically. The oven is
now in “Idle mode” again.
Note: During cooking, the power level and cooking time can be adjusted at any
time.
Note: During cooking, if the door is opened, the display will become blank and
cooking will be cancelled.
Cleaning, Care & Maintenance
• Switch off and disconnect from the power supply before cleaning.
• Always keep the oven clean!
• Clean the door frame, seal and neighbouring parts carefully with a damp
cloth when dirty.
Cleaning the door and oven front face
• For best performance and to maintain the high degree of safety, the inner door panel and oven front
face should be free of food or grease build-up.
• Wipe these parts with a mild detergent, rinse and wipe dry. Never use abrasive powders or pads.
Cleaning the control panel and plastic parts
• Do not apply a detergent or an alkaline liquid spray to the control panel and plastic parts, as this may
cause damage to these parts.
• Use a dry cloth (not a soaked cloth) to clean these parts.
• Do not allow the control panel to become wet.
FB863_FE141-E_UK_A5_v1_20201103.indb 9FB863_FE141-E_UK_A5_v1_20201103.indb 9 2020/11/3 09:162020/11/3 09:16

10
UK
Cleaning the oven interior
• After use be sure to remove spilled liquids, spattered oil and food debris as quickly as possible.
• If the oven is used when dirty, efficiency will drop and the dirt will get stuck on the oven surface.
This may cause bad odours. Clean the interior with a cloth soaked in luke-warm water with a mild
detergent dissolved in it, then rinse the soap off with a damp cloth.
Remove any odours in the oven interior by microwaving a cup of water with the
juice of 1 lemon for 5 minutes. Wipe the oven clean with a soft dry cloth.
Cleaning the oil baffle
The oven is featured with a removable oil baffle for easy and thorough cleaning. The baffle is located
underneath the interior ceiling of the oven.
• To remove the baffle, press and hold the 2 dents on the baffle front (Step A). Meanwhile push the
whole baffle backward to release. Afterward, remove the baffle from the oven (Step B).
• Clean the baffle with a mild detergent, rinse and wipe dry.
• To install the baffle, hold the baffle and insert the 3 pins on the rear into the holes on the oven back
wall (Step C).
• Press the right dent backward until the right part of the baffle gets buckled. Repeat same operation
to buckle the left part into position (Step D).
FB863_FE141-E_UK_A5_v1_20201103.indb 10FB863_FE141-E_UK_A5_v1_20201103.indb 10 2020/11/3 09:162020/11/3 09:16

11
UK
Cleaning the filter
The oven is featured with a removable filter for easy and thorough cleaning.
• Loosen the fixing nails (Step A), then remove the filter (Step B).
• Clean the filter with a soft brush.
• Locate the filter in place and fix with the nails (Step C).
FB863_FE141-E_UK_A5_v1_20201103.indb 11FB863_FE141-E_UK_A5_v1_20201103.indb 11 2020/11/3 09:162020/11/3 09:16

12
UK
Troubleshooting
If your BUFFALO appliance develops a fault, please check the following table before making a call to the
Helpline or your BUFFALO dealer.
Fault Probable Cause Solution
The unit is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call BUFFALO agent or qualified technician
Fuse in the plug has blown Replace the plug fuse
Power supply Check power supply
Internal wiring fault Call BUFFALO agent or qualified technician
Door is not closed properly Close door securely
Arcing/Sparking Metallic or other inappropriate
materials are being used in food
preparation
Remove metal objects. Use microwave-safe
utensils only
Spilled food remains inside the oven Clean the interior of the oven
The oven is operated when empty Do not operate the oven when empty. It is
very dangerous
Microwave oven
interfering with
TV reception
Radio and TV reception is interfered
when then appliance is operating
It is normal
Steam
accumulating on
door and hot air
out of vents
In cooking, steam may come out of
food. Most will get out of vents but
some may accumulate on cool places
like the oven door
It is normal
Dim oven light In low power microwave cooking, oven
light may become dim
It is normal
Technical Specifications
Model Voltage Power Microwave
Output
Oven
Capacity
Operation
Frequency
Dimensions
h x w x d
(mm)
Weight
(kg)
FB863 230-240V~
50Hz 3000W 1800W 34L 2450MHz 368 x 574 x
528 33.3
FE141-E 230~ 50Hz
FB863_FE141-E_UK_A5_v1_20201103.indb 12FB863_FE141-E_UK_A5_v1_20201103.indb 12 2020/11/3 09:162020/11/3 09:16

13
UK
Electrical Wiring
This appliance is supplied with a 3 pin BS1363 plug and lead.
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible for
waste disposal in your area.
BUFFALO parts have undergone strict product testing in order to comply with
regulatory standards and specifications set by international, independent, and
federal authorities.
BUFFALO products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of BUFFALO.
Every effort is made to ensure all details are correct at the time of going to press, however, BUFFALO reserves the right to
change specifications without notice.
FB863_FE141-E_UK_A5_v1_20201103.indb 13FB863_FE141-E_UK_A5_v1_20201103.indb 13 2020/11/3 09:162020/11/3 09:16

DECLARATION OF CONFORMITY
•Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp •
Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
1.
Manual Commercial Microwave - 34Ltr 1800watt -
UK & IE
2. Manual Commercial Microwave - 34Ltr 1800watt -
EU (not IE)
Model • Modèle • Modell • Modello • Modelo • Malli
1.
FB863
2. FE141-E
Application of Council Directives(s)
Toepassing van Europese Richtlijn(en) • Application de la/des directive(s)
du Conseil • Anwendbare EU-Richtlinie(n) • Applicazione delle Direttive •
Aplicación de la(s) directiva(s) del consejo • Aplicação de directiva(s) do
Conselho
Low Voltage Directive (LVD) 2014/35/EU - recast of
2006/95/EC
EN 60335-1:2012 + A11:2014 +A13:2017
EN 60335-2-90:2006 +A1:2010
EN 62233:2008
Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU - recast of 2004/108/EC
EN 55011:2016 +A1:2017
EN IEC 61000-6-1:2019
EN IEC 61000-3-2:2019
IEC 61000-3-11:2000
Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to Directive
2011/65/EU
Producer Name • Naam fabrikant • Nom du producteur • Name des
Herstellers • Nome del produttore • Nombre del fabricante • Nome do
fabricante
Buffalo
Producer Address • Adres fabrikant • Adresse du producteur • Anschrift
des Herstellers • Indirizzo del produttore • Dirección del fabricante •
Morada do fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
42 North Point Business
Park
New Mallow Road
Cork
Ireland
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und Norm(en)
entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es)
arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es) Directiva(s)
e Norma(s)
Date • Data • Date • Datum • Data • Fecha • Data
7th January 2020
Signature • Handtekening • Signature • Unterschrift
Firma • Firma • Assinatura
Full Name • Volledige naam • Nom et prénom • Vollständiger Name •
Nome completo • Nombre completo • Nome por extenso Ashley Hooper
Position • Functie • Fonction • Position • Qualifica • Posición • Função
Technical & Quality Manager
FB863_FE141-E_UK_A5_v1_20201103.indb 14FB863_FE141-E_UK_A5_v1_20201103.indb 14 2020/11/3 09:162020/11/3 09:16

UK
[phone]
Eire
NL 040 – 2628080
FR 01 60 34 28 80
BE-NL 0800-29129
BE-FR 0800-29229
DE 0800 – 1860806
IT N/A
ES 901-100 133
PT [email protected]
FB863_FE141-E_UK_A5_v1_20201103.indb 15FB863_FE141-E_UK_A5_v1_20201103.indb 15 2020/11/3 09:162020/11/3 09:16

FB863_FE141-E_UK_A5_v1_20201103
http://www.buffalo-appliances.com/
FB863_FE141-E_UK_A5_v1_20201103.indb 16FB863_FE141-E_UK_A5_v1_20201103.indb 16 2020/11/3 09:162020/11/3 09:16
