Steam Combination Oven
Instruction manual
Model •Modèle •Modell •Modello •Modelo •Malli:
DN486

2
UK
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out installation and any repairs if required. Do not
remove any components on this product.
• Consult Local and National Standards to comply with the following:
• Health and Safety at Work Legislation
• BS EN Codes of Practice
• Fire Precautions
• IEE Wiring Regulations
• Building Regulations
• DO NOT immerse the appliance in water.
• Some surfaces become hot during operation - take care when using the appliance.
• Always wear suitable protective clothing when using the oven.
• DO NOT allow anything to come in to contact with the heating elements during use.
• Always switch off and disconnect the power supply to the appliance when not in use.
• Not suitable for outdoor use.
• DO NOT use jet/pressure washers to clean the appliance.
• This appliance must only be used in accordance with these instructions and by persons competent to
do so.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the apliance by a person reponsible for their safety.
• Keep all packaging away from children. Dispose of the packaging in accordance to the regulations of
local authorities.
• If the power cord is damaged, it must be replaced by a BUFFALO agent or a recommended qualified
technician in order to avoid a hazard.
• The total mass of the food for steaming should not exceed 5kg
•
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your BUFFALO product.
Pack Contents
The following is included:
• BUFFALO Steam Combination Oven
• Instruction Manual
BUFFALO prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your BUFFALO dealer immediately.

3
UK
Telephone Helpline: 0845 146 2887 (United Kingdom)
Before using for the first time, the appliance must be cleaned. To clean the appliance:
1. Wash the water box, racks and oven interior with warm soapy water and a damp cloth.
2. Place the rack inside the oven.
3. Close the door.
4. Set the Temperature knob to ‘MAX’, the function knob to Convection Oven (see table) and the Timer
knob to ‘5 minutes’.
5. When the minutes are over turn Off the appliance and disconnect from the power supply.
6. Allow to cool. The appliance is now ready to use.
Note: See ‘Setting the Timer’ for setting times under 20 minutes.
1Handle
2temperatureindicatorlight
3WaterBox
4PowerIndicatorLight
5TimerKnob
6FunctionKnob
7TemperatureKnob
8SteamOutlet
9WaterCollectionTray

4
UK
Operating Instructions
Setting the Timer
The Timer knob also acts as the Power switch. When the Timer is set to
‘0’ the power is Off.
1. Connect the appliance to the mains power supply.
2. Set the Timer knob to the required time (0-120 minutes).
Alternatively select ‘Stay On’ for non-stop use
3. The appliance will begin to heat up to the set temperature (see ‘Setting the Temperature’) and the
Power Indicator light comes on.
4. When the Timer reaches ‘0’ an audible alarm sounds and the appliance turns Off.
Setting the Temperature
1. Turn the Temperature Control Knob to the required temperature
(50°C-200°C).
2. The Temperature Indicator light comes on
Note: Before use ensure that the Water Collection Tray is securley fitted underneath the
unit
Note:This product is classed as a steam-convection oven, an appliance intended for the
cooking of food either by means of direct steam contact or by heated air circulated by
mechanical means within the cooking compartment or by a combination of these two
methods. The pressure within the cooking compartment does not differ significantly from
atmospheric pressure
Note: If the required time is under 20 minutes, the Timer must be turned beyond 20 and
then turned back down to the required setting in order to work.
Note: The Time can be adjusted during cooking if required. Simply adjust the setting as
required using the Timer knob.
Note: When the Oven reaches the set temperature the Temperature Indicator light
turns off.

5
UK
Telephone Helpline: 0845 146 2887 (United Kingdom)
Setting the Function
The oven has four function settings. Rotate knob to select desired function
Convection Oven
1. Place the rack or baking tray in the desired rack position
2. Turn the function knob to the convection oven setting
3. Select the required temperature
4. To switch the oven ON turn the timer control to the required time. It is not necessary to preheat the
oven
Fan Only (Defrost)
1. Place the food to be defrosted on the rack in the middle shelf position. Place a baking tray at the
lowest level and close the oven door
2. Set the function knob to Fan Only setting
3. Set the timer according to the size and quantity of food to be defrosted - the fan will start
Oven is Off
Convection Oven Function
Fan Only Function
(Use for De-frosting)
Combination Function -
(Convecton and Steam)
Steam Only Function

6
UK
Telephone Helpline: 0845 146 2887 (United Kingdom)
Steam Function
1. Fill the water tank to the maximum level
2. Preheat oven to 130C using the Convection Oven setting
3. Place the rack or baking tray in the desired rack position
4. Turn the function knob to the Steam Only setting
5. Select the required temperature
6. Set the timer to the required time - the oven will begin to work
Combination Oven (Steam and Convection)
1. Fill the water tank to the maximum level
2. Preheat oven to the desired temperature using the Convection Oven setting
3. Place the rack or baking tray in the desired rack position
4. Turn the function knob to the Combination Oven setting
5. Select the required temperature
6. Set the timer to the required time - the oven will begin to work
Cleaning, Care & Maintenance
• Always turn Off the appliance and disconnect from the power supply before cleaning.
• Allow the appliance to cool before cleaning.
• Use warm, soapy water and a damp cloth to clean the appliance.
•Drythoroughlyafter cleaning.
• A BUFFALO dealer or qualified technician should carry out repairs if required.

7
UK
Telephone Helpline: 0845 146 2887 (United Kingdom)
Troubleshooting
If your BUFFALO appliance develops a fault, please check the following table before making a call to the
Helpline.
Technical Specifications
Electrical Wiring
This appliance is supplied with a 3 pin, moulded, BS1363 plug and lead, with a 13 amp fuse as standard.
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed, using a dedicated earthing circuit.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Fault Probable Cause Action
The appliance is not working The appliance is not switched on Check the appliance is plugged in correctly
and switched on
Plug and lead are damaged Call BUFFALO agent or qualified technician
Fuse in the plug has blown Replace the plug fuse
Power supply Check power supply
Internal wiring fault Call BUFFALO agent or qualified technician
Appliance does not reach set
temperature
Faulty thermostat Call BUFFALO agent or qualified technician
Faulty element Call BUFFALO agent or qualified technician
Appliance heats up but indicator light
does not come on
Bulb has expired Call BUFFALO agent or qualified technician
Power indicator light comes on but
appliance does not heat up
Faulty element Call BUFFALO agent or qualified technician
Faulty thermostat Call BUFFALO agent or qualified technician
Thermostat set incorrectly Check thermostat
Appliance slow to heat up Cooking surface not clean Clean cooking surface
Faulty element Call BUFFALO agent or qualified technician
No Steam Water Tank Empty Fill Water Tank
Model Voltage Power Current Temperature
Range (°C)
Capacity
(litres)
Dimensions
h x w x d (mm)
Weight
(kg)
DN486 230V 50Hz 2500W 10.9A 50 - 200 30 390 x 550 x 550 19.8

8
UK
Telephone Helpline: 0845 146 2887 (United Kingdom)
Compliance
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible
for waste disposal in your area.
BUFFALO parts have undergone strict product testing in order to comply with
regulatory standards and specifications set by international, independent, and federal
authorities.
BUFFALO products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means,
electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of BUFFALO.
Every effort is made to ensure all details are correct at the time of going to press, however, BUFFALO reserve the
right to change specifications without notice.

9
NL Klantenondersteuning: 050 – 609999 (België)
Veiligheidstips
• Plaatsen op een vlakke en stabiele ondergrond.
• De installatie en eventuele reparaties zijn door een servicetechnicus/vaktechnicus uit te voeren.
Verwijder geen componenten of servicepanelen van dit product.
• Raadpleeg en volg de plaatselijke en nationale regelgeving op m.b.t. tot het volgende:
• Wetgeving van gezondheid en veiligheid op de werkplaats
• Werkregels
• Brandpreventie
• IEE bekabelingsnormen
• Bouwverordeningen
• Dit apparaat NIET in water dompelen.
• Bepaalde oppervlakken worden tijdens gebruik heet - let hierop wanneer u het apparaat gebruikt.
• Gebruik altijd geschikte beschermende kleding gedurende het gebruik van de oven.
• Laat tijdens gebruik NIETS in contact komen met de verwarmingselementen.
• Schakel het apparaat altijd uit en haal de steker uit het stopcontact wanneer u het apparaat niet
gebruikt.
• Niet geschikt voor gebruik buitenshuis.
• Dit apparaat mag uitsluitend in overeenstemming met deze instructies en door competente personen
worden gebruikt.
• Dit apparaat is ongeschikt om door kinderen gebruikt te worden.
• Laat verpakkingsmateriaal niet binnen handbereik van kinderen. Verpakkingsmateriaal in
overeenstemming met de regelgeving van de plaatselijke overheden als afval laten verwerken.
• Indien de stroomkabel beschadigd raakt, dient men deze door een BUFFALO technicus of aanbevolen
vaktechnicus te laten vervangen om gevaarlijke situaties te verhinderen.
• Dit product NIET reinigen met spuit-/drukreinigers.
• Dit apparaat is niet bedoeld voor gebruik door personen (inclusief kinderen) met lichamelijke,
zintuiglijke of mentale beperkingen of door personen met gebrek aan ervaring of kennis, tenzij zij
hierin worden begeleid of zijn opgeleid in het gebruik van het apparaat door een persoon, die
verantwoordelijk is voor hun veiligheid.
• Het totaalgewicht van het te stomen voedsel mag niet meer dan 5 kg zijn
Inleiding
Neem de tijd en lees deze handleiding aandachtig door. Een correct gebruik en onderhoud van deze
machine waarborgt de beste prestatie van uw BUFFALO product.
Verpakkingsinhoud
De verpakking bevat het volgend:
•BUFFALOCombinatie-stoomoven
• Handleiding

10
NL
Klantenondersteuning: 040 – 2628080 (Nederland)
BUFFALO is trots op de haar productkwaliteit en dienstverlening en controleer de inhoud van de
verpakkingen, tijdens de verpakkingsfase, op functionaliteit en schade.
Mocht u product door transport zijn beschadigd, neem dan onmiddellijk contact op met uw BUFFALO dealer.
Werking
Voor het eerste gebruik dient u het apparaat te reinigen. Om het apparaat te reinigen:
1. Was de waterbak, rekken en de ovenbinnenkant met warm zeepwater en een vochtige doek.
2. Plaats het rek in de oven.
3. Sluit de deur.
4. Zet de temperatuurknop op de stand MAX, de functieknop op convectieoven (zie tabel) en de timer-
knop op 5 minuten.
5. Na het verlopen van de ingestelde tijd zet u het apparaat uit en haalt u de stekker uit het stopcontact.
6. Laat het apparaat afkoelen. Het apparaat is nu gebruiksklaar.
Opmerking: Zie "Timer instellen" voor tijdinstellingen onder de 20 minuten.O
1Hendel
2Temperatuurlampje
3Dedoosvanhetwater
4Stroomlampje
5Timerknop
6DeKnopvandefunctie
7Temperatuurregelknop
8DeAfzetvandestoom
9HetDienbladvandeInzamelingvanhetwater
