Snowblower
Rotary Tiller
Series 25, 45 and 65

SOLID CONSTRUCTION AND HEAVY-DUTY COMPONENTS FOR ALL YOUR TILLING NEEDS
65
C6550 C6560 C6572 C6582
46" 56" 68" 77"
56" 66" 78" 88"
30 - 40 35 - 45 45 - 55 55 - 65
Cat. I, optional t Cat. II
Heavy-duty oil bath (540 RPM)
#100H #100H #100H #100H
196 RPM or 880 ft/min
5" 8" 15" n/a
Slip clutch
⁄" x 3 ¼" ⁄" x 3 ¼" ⁄" x 3 ¼" ⁄" x 3 ¼"
5 anges
6 tines/ange
4 tine opt.
6 anges
6 tines/ange
4 tine opt.
7 anges
6 tines/ange
4 tine opt.
8 anges
6 tines/ange
4 tine opt.
774 lbs 835 lbs 906 lbs 968 lbs
45
C4560 C4572
55" 69"
66" 78"
25 - 40 30 - 45
Cat. I
Heavy-duty oil bath (540 RPM)
#80H #80H
203 RPM or 865 ft/min
6 ¾" 8 ½"
Slip clutch
¼" x 2 ¼" ¼" x 2 ¼"
6 anges
4 tines/ange
8 anges
4 tines/ange
613 lbs 688 lbs
SERIES 25
MODEL C2540 C2548 C2560
Tillage width 36" 45" 54"
Overall width 46 ½" 54 ½" 66 ½"
Tractor HP requirement 12 - 18 14 - 22 18 - 25
3-point hitch* Cat. I
Gearbox Heavy-duty oil bath (540 RPM)
Chain in oil bath #60H #60H #60H
Rotor speed RPM 196 RPM or 880 ft/min
Sideshift 2 ½" 4 ½" 7 ½"
PTO shaft Slip clutch, shear bolt optional
Tine size ¼" x 2 ¼" ¼" x 2 ¼" ¼" x 2 ¼"
Number of tines 4 anges
4 tines/ange
5 anges
4 tines/ange
6 anges
4 tines/ange
Weight 425 lbs 458 lbs 517 lbs
*All models are quick hitch compatible
Get closer to the edge
Getting close to fences, hedges or covering a tire track is easy with
the sideshi feature. e entire unit can be pushed to one side,
while the PTO sha remains in line with the tractor to minimize
stress on the universal joint. e sideshi feature is available on all
Buhler Farm King Rotary Tillers except the C6582.

SOLID CONSTRUCTION AND HEAVY-DUTY COMPONENTS FOR ALL YOUR TILLING NEEDS
The perfect tillers for thorough soil preparation
Buhler Farm King has a collection of rotary tiller models to suit your garden and land-
scaping needs. e tiller attaches to the three-point hitch and is designed to t a variety
of tractors, from 12 hp to 65 hp. Tilling widths range from 36" to 54" in the 25 Series
and from 55" to 69" in the 45 Series. e 65 Series is available in 46" to 77" widths.
Break ground with ease
e tilling sha is equipped with four to eight anges, depending on the model. Flang-
es on all series are available with four tines, and six tines per ange are standard on
the 65 Series. is provides an optimum balance between performance and durability,
even in heavy soils and when breaking untilled soil.
Set the right depth
Standard on all Buhler Farm King Rotary Tillers, the skid shoes are adjustable so it is
easy to set the perfect tilling depth.
Low maintenance :: long life
All models are equipped with an automatic chain tightener that ensures the chain re-
mains tight under the toughest tilling conditions. Housed in a sealed oil bath, the
chain tightener assembly is resistant to heat, dust, debris and moisture, which reduces
maintenance and enhances the longevity of the chain and sprockets.
[2]
[1] [3]
[1] Adjustable skid shoes to set the tillage
depth.
[2] Flange with four tines.
[3] Parking stand (shown in up position).
[4] Automatic chain tightener (shown with
sealed oil bath housing removed).
[4]

301 Mountain Street South
Morden, Manitoba :: Canada R6M 1X7
Ph.: 204.822.4467 :: Fax: [phone]
Toll Free: 888.524.1004
E-mail: [e-mail]
www.buhler.com
TSX:BUI
Equipment shown is subject to change without notice.
©2007 Buhler Manufacturing. Printed in Canada.
Ref: 112007-3000-PG
