Enclave vs. the Competition

BOLD denotes a Buick advantage.

2010 Buick 2010 Lexus 2010 Mazda

Enclave RX350 CX9

CX AWD AWD GT AWD

Performance Specifications

Base Engine 3.6L V6 3.5L V6 3.7L V6

Horsepower @ rpm 288 @ 6,300 275 @ 6,200 273 @ 6,250

Torque (lb.-ft.) 270 @ 3,400 257 @ 4,700 270 @ 4,250

Std. Transmission 6-speed auto.6-speed auto. 6-speed auto.

Drivetrain FWD / AWD AWD FWD / AWD

Suspension, f/r Ind./Ind. Ind./Ind. Ind./Ind.

Steering Type Variable assist Variable assist Variable assist

rack-and-pinion rack-and-pinion rack-and-pinion

Turning radius 6.16/20.2 5.9/19.4 6.2/20.3

GVWR 2,930/6460 2,560/5644 2,733/6025

Towing capacity 2,041/4500 1,587/3500 1,588/3500

Fuel tank 83.3/18.3 72.5/15.9 76/16.7

City/hwy2(L/100km) 13.5/9.0 11.6/8.2 14.0/9.6

City/hwy2(mpg) 21/32 24/34 20/29

Recommended fuel Regular Premium Regular

Dimensions and Interior Volume in mm/inches unless otherwise indicated

Wheelbase 3,020/118.9 2,740/107.9 2,875/113.2

Curb weight 2,261/4985 1,970/4343 2,062/4546

Exterior length 5,126/201.8 4,770/187.8 5,101/200.8

Exterior body width 2,007/79.0 1,885/74.2 1,936/76.2

Exterior height 1,834/72.2 1,720/67.7 1,728/68.0

Front tread 1,709/67.3 1,630/64.2 1,654/65.1

Rear tread 1,709/67.3 1,620/63.8 1,644/64.7

Front legroom 1,050/41.3 842/33.1 1,038/40.9

Rear legroom 934/36.8 680/26.8 1,010/39.8

Third row legroom 843/33.2 NA 824/32.4

Front headroom 1,026/40.4 992/39.1 975/38.4

Rear headroom 1,006/39.6 958/37.7 990/39.0

Third row headroom 975/38.4 NA 899/35.4

Front hiproom 1,458/57.4 NA 1,435/56.5

Rear hiproom 1,448/57.0 NA 1,422/56.0

Third row hiproom 1,227/48.3 NA 1,111/43.7

Front shoulder room 1,576/62.0 1,473/58.0 1,510/59.4

Rear shoulder room 1,551/61.1 1,462/57.6 1,490/58.7

Third row shoulder room 1,468/57.8 NA 1,444/56.9

Luggage volume 535/18.9 1,133/40.0 487/17.2

Luggage volume (max) 3,290/116.2 2,274/80.3 2,851/100.7

Seating capacity 7/85 7

Vehicle Features

Smart Slide 2nd-row seat S NA NA

2 Row bucket seats SNA NA

OnStar®with Turn-by-Turn Nav. S NA NA

Remote Vehicle Start O NA NA

Power liftgate S O O

HID headlamps S O S

Rear seat audio controls ONA NA

Driver Information Centre S S NA

Engine block heater ONA NA

New vehicle warranty (mths/km) 4/80,000 3/60,000 3/60,000

Powertrain warranty (mths/km) 5/160,000 5/100,000 5/100,000

1. When properly equipped. Maximum trailer ratings are calculated assuming a properly equipped base vehicle, plus

driver.

2. Energuide-estimated fuel economy ratings at time of printing. Based on AWD models .

Key Messages

Style

– Waterfall black chrome grille

– Portholes

– Classically styled analog clock with quartz movement

– Genuine mahogany-accented steering wheel

– Camphor burl wood appliqués

Luxury

Technology

– Available articulating headlamps

– Available USB port

– Bluetooth®for Phone

– Available DVD Player with Dolby 5.1 surround sound Bose system

QuietTuning

– Triple door seals

– Laminated windshield and front side glass

– Laminated steel intake plenum

Comfort

– Available heated/cooled front seats

– Smart SlideTM 2nd-row seat with fore and aft seat adjustment

– Adjustable 1st-row centre console armrest

Quality

– High-end premium materials

– Excellent fit and finish

Confidence

Vehicle Dynamics

– 3.6-litre VVT DI engine with 288 hp and 270 lb.-ft. of torque

– 6 speed automatic transmission

– Active intelligent all-wheel drive

– 4-wheel independent suspension

Safety

– Before: StabiliTrak with rollover mitigation, “Intelligent” AWD, Traction

Control, antilock brakes, OnStar Turn-by-Turn Navigation, articulating

headlamps (available) and rear backup camera (available)

– During: Solid body structure with crush zones, 6 air bags including

roof rail air bags for all 3 rows, driver and front passenger safety belt

pretensioners for front and rear impacts3

– After: OnStar4

Spaciousness and Functionality

– 3 rows of seating for up to 8 people

– Available sunroof and auxiliary skylight allows a greater feeling of

openness

– SmartSlide Seat for 3rd-row access

– 2nd- and 3rd-row seats fold flat for 3,290 litres (116.2 cu.ft.) behind

1st row

– 2,041 kg (4,500-lb.) maximum towing capability

Reputation and Warranty

– 4-year/80,000-km New Vehicle Limited Warranty

– 5-year/160,000-km GM Powertrain Component Warranty with

Roadside Assistance and Courtesy Transportation

– 2010 Buick Enclave achieved highest possible U.S. Government crash

test rating (NHTSA) and is a Top Safety Pick by IIHS

– 2010 Buick Enclave was named a Consumer’s Digest Best Buy

3 Always use safety belts and proper restraints, even with air bags. Children are safer when properly secured in a rear

seat. See the Owner Manual for more safety information.

4 OnStar®system includes one-year Directions & Connections service agreement.

Go to www.onstar.ca for system limitations and details.

2010 Enclave

Quick Facts

• Walkaround Summary

• Competitive Comparison

• Key Messages

Additional copies can be obtained by printing PDF file from GM InfoNET.

All information contained in this pocket piece is based on the latest information available as of

11/2009. Buick and General Motors of Canada reserve the right to discontinue or change at any time,

without notice, any prices, colours, parts, materials, standard equipment, optional equipment, Mar-

keting Option Packages, special equipment, specifications and/or body types and models. This ma-

terial is not legally approved for use in any advertising. It is intended for use by dealership employees

Produced by GMPRO for VSSM Product Training.

The comparator data is provided under license from Autodata Solutions Company (Autodata). This information is provided for information purposes only for personal use and may not be used for any commercial purpose whatsoever without the prior written consent of Autodata.

Up Front

•Model lineup includes CX with premium cloth interior and

CXL1 and CXL2 with perforated leather interior. All available in

FWD or AWD

•Standard High Intensity Discharge headlamps provide excep-

tional illumination for safety

•Fog lamps are standard for visibility

•Daytime Running Lamps enhance visibility to oncoming traffic

•Automatic lamp control activates lights automatically

•Articulating headlamps rotate for enhanced visibility while

turning. Standard on CXL2

•Waterfall black chrome grille and chrome fender portholes

add unique style to the front of Enclave

Under the Hood

•3.6L DOHC VVT V6 engine delivers 288 hp and 270 lb.-ft. of

torque. Direct injection helps produce more horsepower while

delivering fuel consumption of 12.7/8.4 L/100km (22/34 mpg)

•6-speed electronically controlled automatic transmission

provides smooth shifts and enhanced fuel efficiency

•Performance Algorithm Shifting downshifts during high lateral

acceleration manoeuvers for maximum vehicle performance

•Auto-grade braking automatically shifts into lower gear while

braking on a downgrade to reduce brake use

Passenger Side

•Long 3,023 mm (118.9”) wheelbase enables a stable, com-

fortable ride

•Body Frame Integral construction is used for exceptional ride

and handling, roominess and occupant protection

•Outside rearview mirrors are power-adjustable with heat for

convenience and signal feature for safety. Power folding mir-

rors with memory are standard on CXL1. CXL2 adds driver’s

auto-dimming feature

•19-inch aluminum wheels standard on all models, chrome clad

standard on CXL2, available on CXL1.

•20-inch chromed-aluminum wheels available on CXL2

•Tire pressure monitoring system alerts driver to low tire pres-

sure for safety

•Oversized sunroof with rear skylight – Tilt and slide in the

front with 900x1200 mm (3x4’) skylight and roller shade at the

rear. Available on CX/CXL

•Chrome luggage rack rails can accept available crossbars and

accessories

•QuietTuning includes laminated glass, laminated steel fresh air

plenum, flat blade windshield wipers, triple door seals, acoustic

foam and numerous other features that REDUCE noise at the

source, BLOCK noise from entering the cabin and ABSORB any

remaining noise

At the Rear

•Power liftgate raises and lowers at the touch of a button and

includes pinch protection for safety. Standard

•Ultrasonic Rear Park Assist provides audio alerts to objects

when backing up at low speeds. Available on CX, standard on

CXL

•Rearview camera helps driver see objects behind the vehicle

when backing up with the screen integrated into the rearview

mirror. Standard on CXL and available CX

•Large cargo capacity of 3, 259 litres (115 cu. ft.) with flat load

floor for convenience. Rear cargo hooks and underfloor storage

bins help secure and organize cargo

•2,041 kg (4500-lb.) towing capacity with available towing

package 907 kg (2000 lb. is standard). Package includes a hitch

receiver, selectable transmission Tow/Haul mode control, trans-

mission cooler and wiring

•Cargo shade and net keep cargo concealed and secured. Avail-

able on CX, standard on CXL

•Dual exhaust chrome tips are a stylish performance cue

Driver Side

•StabiliTrak electronic stability control system with Rollover

Mitigation uses brake intervention to help reduce oversteer and

understeer, especially on slippery surfaces.

•Active intelligent all-wheel drive transfers power automati-

cally, providing optimum traction in all conditions. Requires no

driver intervention. Available on CX and CXL

•Variable-assist power rack-and-pinion steering for car-like re-

sponsiveness and ease of low-speed manoeuvers

•Four-wheel independent suspension allows each wheel to

react independently. T

•Remote Vehicle Start System can also heat or cool the cabin

and activate available heated seats, heated mirrors and rear de-

froster. Available on CX, standard on CXL

•4-wheel antilock disc brakes have large, vented rotors and Dy-

namic Rear Proportioning for safety

Interior

•Chrome and wood interior accents add an upscale appearance

•Analog clock provides a luxury appearance and convenience

•360-degree air bag sensing system1includes front, side, rear

and rollover sensing for comprehensive safety

•Dual-stage driver and front-passenger air bags1provide

added protection in the event of certain frontal collisions.

•Head-curtain side air bags1offer a level of head protection

during side-impact crashes for outboard passengers in all three

rows. They stay inflated longer during rollovers

•Front seat-mounted thorax protection air bags1provide an ad-

ditional level of protection to the thoracic region for the driver

and front-seat passenger during side-impact crashes

•Cloth front bucket seats with 6-way power driver and 2-way

power passenger adjustments are standard on CX

•Perforated leather heated front seats with driver’s memory,

8-way power driver and 4-way power passenger adjustments

are standard on CXL models.

•Heated/cooled front seats provide comfort in hot and cold

weather. Standard on CXL2

•Smart SlideTM 2nd-row Captain’s Chairs are standard on all

models; slide forward with one-handed operation for 3rd-row

access. Folds flat into the floor. Four inches of fore/aft travel for

comfort. 60/40 (3-passenger) bench seat with Smart Slide is

available on CX/CXL1 and CXL2

•2nd-row centre console includes armrest, cupholders, storage

and 12-volt power outlet. Available with 2nd-row Captain’s

Chairs

•3rd-row 60/40 seat comfortably seats 3 adults and is standard.

Folds flat into load floor

•AM/FM/CD player includes MP3 playback capability, auxiliary

input jack, RDS and 6 speakers

•Bose Premium Audio System includes 10 speakers, sub-

woofer, rear audio controls and USB port. Available on

CX/CXL1, standard on CXL2

•Rear-seat DVD entertainment system includes 8-inch screen

and premium Bose 5.1 Surround Sound. Available on CXL

•Standard XM Satellite Radio provides digital-quality sound

•Bluetooth®for Phone allows the driver to make hands-free cell

phone calls within the vehicle

•DVD touch-screen navigation system with voice recognition is

available on CXL models

•Tri-zone climate control with rear air conditioning is standard

•Driver Information Centre includes vehicle status messages

and personalization features

•Tilt and telescoping steering column adjusts for comfort.

Power tilt/telescoping standard on CXL2

•Mahogany and leather-trimmed steering wheel has audio

controls that allow the driver to keep their hands on the wheel

•OnStar®system2includes Automatic Crash Response and

one-year Directions & Connections plan with Turn-by-Turn

Navigation

•Ambient lighting highlights the centre stack and console

•Integrated multi-functional centre console includes sliding

armrest, dual-bin storage, cupholders and 3 power outlets

•115-volt power outlet can power devices such as laptop com-

puters and video game systems. Available CXL1, standard CXL2

•Standard Universal Home Remote controls up to three remote

devices

•Power windows with express up/down for driver and express

down for passenger with rear disable add convenience

•Electronic immobilizer and content theft systems standard

1 Always use safety belts and proper child restraints, even with air bags. Children are safer when

properly secured in a rear seat.

2 Optional OnStar® system includes one-year Directions & Connections Plan.

Go to www.onstar.ca for system limitations and details.

Buick LaCrosse vs. the Competition

BOLD denotes a Buick advantage.

2010 Buick 2009 Lexus

LaCrosse ES 350

Performance Specifications

Engine 3.0L VVT SIDI V6 3.5L V6

Horsepower 255 272

Torque (lb.-ft.) 217 254

Engine (A) 3.6L VVT —

SIDI V6 (CXS)

Horsepower 280 —

Torque (lb.-ft.) 259 —

Fuel Consumption (FWD), 11.1/7.4 (3.0L); 10.9/7.2

city/hwy, L/100km 11.8/8.3 (3.6L)

Fuel Consumption, (FWD) 26/38 (3.0L) 26/39

city/hwy, (mpg) 24/34 (3.6L)

Fuel capacity L (gal.) 68 (15) 70 (15.4)

Recommended fuel Regular Premium

Transmission 6-speed auto. 6-speed auto. w

tap-up/tap-down sequential shift

Front suspension Ind. Ind.

MacPherson MacPherson

strut strut

Rear suspension Ind. (CX, CXS) Ind.

H-arm (CXL,CXS; dual-link

Touring Package)

Performance Suspension (A) Continuously Variable —

Real-time Damping

Drivetrain FWD; AWD FWD

CXL eLSD (A)

Steering Power rack-and- Speed

pinion (CX); sensing power

Magnetic variable power rack-and-

effort (CXL, CXS) pinion

4-wheel disc ABS brakes S S

Wheels 17", 18", (19") 17"

Wheelbase, mm/in. 2,837/111.7 2,776/109.3

Track, front, mm/in. 1,567/61.7 1,575/62.0

Track, rear, mm/in. 1,575/62.0 1,565/61.6

Luxurious Interior, Personal Technologies

Leather-appointed seats A A

Heated/ventilated front seats A A

Rear seat 60/40 split- Pass-through

folding w/ only

pass-through

Remote Vehicle Starter System A —

Heated steering wheel A —

Satellite radio A A

Standard audio 7 speakers 8 speakers,

single CD, 6-disc CD,

MP3, aux. jack MP3,

(CX, CXL) aux. jack

USB A —

Premium audio A (CX, CXL); 300-watt

S (384-watt 14-speaker

11-speaker Mark

harman/kardon Levinson

CXS)

Buick LaCrosse vs. the Competition

2010 Buick 2009 Lexus

LaCrosse ES 350

Luxurious Interior, Personal Technologies (continued)

Flash memory A —

DVD entertainment system A (Dual display) —

Voice-activated touch-screen

navigation A A

Hard Drive Device A —

Bluetooth interface S A

Driver Information Centre S S

Head-Up Display A —

Rearview camera A A

Rear park assist A —

Keyless access/start A S

Power rear sunshade A A

Oversized power sunroof A A

Dimensions (in mm (inches) unless otherwise indicated)

Max. seating capacity 5 5

Head room, 1st 960/37.8 950/37.4

Head room, 2nd 945/37.2 935/36.8

Leg room, 1st 1,059/41.7 1,072/42.2

Leg room, 2nd 991/39.0 912/35.9

Shoulder room, 1st 1,450/57.1 1,455/57.3

Shoulder room, 2nd 1,422/56.0 1,430/56.3

Hip room, 1st 1,341/52.8 1,420/55.9

Hip room, 2nd 1,420/55.9 1,321/52.0

Trunk volume L (cu. ft.) 377/13.3 (CX, CXL); 416/14.7

362/12.8 (CXS)

Quality, Reliability, Durability, Warranties (years/km)

New vehicle limited warranty 4/80,000 4/80,000

Powertrain warranty 5/160,000 6/110,000

Standard roadside assistance 5/160,000 4/unlimited

Standard courtesy transportation 5/160,000 (Dealer discretion)

Rust-through warranty 6/unlimited 6/unlimited

QuietTuning/equivalent S Added NVH measures

Safety: Before, During & After

Telematics OnStar (S) —

Advanced headlamps A (Xenon A (Xenon

HID Adaptive) HID Adaptive)

Fog lamps S (CXL, CXS) S

Dual-stage frontal air bags S S

Front-seat knee air bags — S

Seat-mounted side-impact air bags S S

Head-curtain side-impact air bags S S

Rear-seat thorax air bags A A

Stability Control S S

Traction control S S

Brake Assist S S

Tire Pressure Monitor S S

Immobilizer S S

Side Blind Zone Alert A —

20 0 LaCrosse

Quick Facts

• Walkaround Summary

• Competitive Comparison

Additional copies can be obtained by printing PDF file from Global Connect or LMS

All information contained in this pocket piece is based on the latest information available as of

06/2009. Buick and General Motors reserve the right to discontinue or change at any time, without

notice, any prices, colours, parts, materials, standard equipment, optional equipment, Marketing Op-

tion Packages, special equipment, specifications and/or body types and models. This material is not

legally approved for use in any advertising. It is intended for use by dealership employees only and

duced by GMPRO for VSSM Product Training.

Up Front

•Models include CX, CXL and CXS.

•C rome waterfall grille with deep tri-shield badge adds a

sophisticated appearance.

•Port oles–an iconic Buick design element–distinguish

LaCrosse from everything else on the road.

•Distinctive lig ting includes jewel-like front headlamps.

Standard fog lamps on CXL and CXS. Available Xenon High-

Intensity Discharge headlamps with Adaptive Forward Lighting

pivot and turn as LaCrosse turns.*

•Daytime Running Lamps with Twilight Sentinel provide safety

and convenience.

•4-year/80,000-km new ve icle limited warranty and 5-

year/160,000-km GM Powertrain Component Warranty with

Roadside Assistance and Courtesy Transportation provide

peace of mind.

Under the Hood

•Two powerful V6 engines. 255 hp 3.0L DOHC VVT SIDI V6

(CX, CXL); 280 hp 3.6L DOHC VVT SIDI V6 (CXS).

•Spark Ignition Direct Injection (SIDI) is standard and enhances

fuel efficiency and reduces emissions.

•A fuel-saving 6-speed automatic transmission include tap-

up/tap-down clutchless shifting capabilities.

•Long-life fluids and components contribute to hassle-free

ownership.

•Buick’s impressive quality helped Buick top the J.D. Power &

Associates 2009 Vehicle Dependability Study, tying for the

#1 spot and surpassing Lexus and Toyota.

•LaCrosse is manufactured at GM’s Fairfax, KS facility, the

home of two consecutive North American Car of the Year win-

ners, Malibu and Aura.

Passenger Side

• Power, eated exterior mirrors are designed to be the quietest

in GM history with extensive wind tunnel testing. CXL and CXS

mirrors add puddle lamps and integrated turn signals.

•W eels–17" (CX), 18" (CXL, CXS) and 19" (CXS with Touring

Package).

•Global Midsize Platform offers a high degree of rigidity and

stiffness for enhanced ride and handling, helping LaCrosse feel

connected to the road.

At the Rear

•LED taillamps have a more precise lighting pattern, a faster

response time and last 20 times longer than conventional

designs.

•Standard dual ex aust. On CX and CXL exhaust tips are tucked

behind the rear lower fascia. On CXS they’re nested within the

fascia and have bright tips.

•360-Degree Field of Vision advanced visibility aids enhance

the driver’s rear views and include available Ultrasonic Rear

Parking Assist and a rearview camera.

Driver Side

•Assertive stance and coupe-like profile provide a confident,

sporty appearance.

•Dramatic sweep spear and taut sculpted lines contribute to

sophistication. LaCrosse stands out in a segment filled with

vehicles that look the same.

•360-Degree Field of Vision advanced visibility aids enhance

the driver’s side blind zone views and include the available Side

Blind Zone Alert System.*

•Available Remote Ve icle Start System allows LaCrosse to be

started from about 45 metres (150-ft.) away. It can also auto-

matically pre-heat/pre-cool the cabin and activate the available

heated and ventilated seats.

•Confident control features include standard StabiliTrak Stability

Control, Traction Control, 4-wheel disc ABS with brake assist

and electronic brakeforce distribution.

•Four-w eel independent suspension features European in-

spired driving dynamics. CX and CXS rear suspensions have

a 4-link design. CXL and CXS with Touring Package feature a

sophisticated H-arm rear suspension.

•All-w eel drive wit electronic Limited Slip Differential

(eLSD) is offered exclusively on CXL. It is fully automatic and

optimizes handling and traction independently and simultane-

ously. Up to 85% of available torque can be transferred to any

of the wheels.

•Steering systems provide crisp, precise response. CXL and

CXS add variable effort power steering.

•Continuously Variable Real-Time Damping is included with

the CXS Touring Package and provides sport-oriented handling.

•Sport Mode Selectivity provides more dynamic handling on

CXS equipped with the Touring Package. It adjusts suspension

calibration and increases steering efforts for more assertive

handling.

•Standard Tire Pressure Monitoring System informs the driver

of a low tire for peace of mind.

Inside

•

Meticulously crafted, premium materials include French seam

and deck-seam stitching, smoked chrome accents and Dark

Poplar woodgrain appliqués.

•Ice Blue ambient lig ting further distinguishes LaCrosse

creating an inviting, harmonious environment.

•T e low and away instrument panel adds a feeling of enhanced

cabin space.

•Available eated and ventilated front seats ensure comfort.

LaCrosse is the only vehicle in its segment to offer both.

•Impressive appointments enhance comfort and convenience.

Standard driver 8-way power seat, automatic climate control,

front armrest with 2-tier centre console, an intuitive centre stack,

leather-wrapped steering wheel with audio/cruise controls,

manual rake/telescoping steering column, a Driver Information

Centre and OnStar.

•En anced luxury and convenience features include an available

premium oversized sunroof, E-Z Key and Keyless Start, Universal

Home Remote, driver seat/mirror memory feature, Head-Up Dis-

play* and a segment-exclusive heated woodgrain steering wheel.

•Seat trim includes cloth on CX, available leather-appointed seat-

ing on CXL and perforated leather-appointed seating on CXS

(available on CXL).

•Exceptional rear seat comfort. First-class comfort with impres-

sive leg room, a centre armrest, theatre seating and a 60/40 split-

folding rear seat with pass-through. An available rear seat

entertainment system with seatback dual DVD displays and

power rear sunshade make the ride even more enjoyable.

•Available connectivity features include Bluetooth for phone,

voice-activated touch-screen navigation with 40GB Hard Drive

Device, voice-recognition capability, USB port, 2GB flash drive,

Time-Shift record capability, 120V power outlet, XM Satellite

Radio, and OnStar eNav, Destination Download and Turn-by-Turn

Navigation.

•Audio system c oices include a standard 7-speaker AM/FM/

CD/MP3 system on CX and CXL, and an available 384-watt

harman/kardon 11-speaker system (standard on CXS).

•LaCrosse as a Library Quiet interior. QuietTuning is an exclu-

sive Buick engineering process to reduce, block and absorb inte-

rior cabin noise.

•Electronic ve icle immobilizer is standard and prevents

LaCrosse from starting without the correct key.

•Air bags include six standard air bags and available rear seat

thorax side-impact air bags.

* Available later this year.

Buick Lucerne vs. the Competition

BOLD denotes a Lucerne advantage.

2010 Buick 2010 2010 Toyota

Lucerne Chrysler 300 Camry SE

CX Touring V6 (A6)

Performance Specifications

Base Engine 3.9L OHV V6 3.5L SOHC V6 3.5L DOHC V6

Horsepower @ rpm 227 @ 5,700 250 @ 6,400 268 @ 6,200

Torque (lb.-ft.) @ rpm

237 @ 3,200 250 @ 3,800 248 @ 4,700

Transmission 4-speed auto. 4-speed auto. 6-speed auto.

Drivetrain

FWD RWD FWD

Suspension, f/r Ind./ind. Ind./ind. Ind./ind.

Power Steering Type Rack- Rack- Speed sensitive

and-pinion and-pinion rack-and-pinion

Turning radius (m/ft.) 6.45/21.2 5.95/19.5 5.5/18.0

Fuel tank (L/gal.) 70/15.3 68/15 70/15.3

City/Hwy (L/100km)112.1/7.3 12.5/8.1 10.7/7.0

City/Hwy (mpg)123/39 23/35 26/40

Recommended fuel Regular Regular Premium

Dimensions and Interior Volume in mm/inches unless otherwise indicated

Wheelbase 2,936/115.6 3,048/120.0 2,775/109.3

Curb weight 1,726/3,805 1,683/3,710 1,580/3,483

Exterior length 5,161/203.2 4,999/196.8 4,805/189.2

Exterior body width 1,874/73.8 1,882/74.1 1,820/71.7

Exterior height 1,473/58.0 1,483/58.4 1,460/57.5

Front tread 1,601/63.0 1,600/63.0 1,575/62.0

Rear tread 1,587/62.5 1,602/63.1 1,565/61.6

Front headroom 1,004/39.5 983/38.7 986/38.8

Rear headroom 957/37.7 965/38.0 959/37.8

Front legroom 1,079/42.5 1,061/41.8 1,057/41.6

Rear legroom 1,051/41.4 1,021/40.2 974/38.3

Front hiproom 1,424/56.1 1,450/57.1 1,387/54.6

Rear hiproom 1,445/56.9 1,419/55.9 1,369/53.9

Front shoulder room 1,473/58.0 1,508/59.4 1,469/57.8

Rear shoulder room 1,453/57.2 1,465/57.7 1,441/56.7

Luggage volume 481/17.0 442/15.6 411/14.5

Seating Capacity 5/65 5

Vehicle Features

Factory Remote Vehicle Start Opt. NA Opt.

Bluetooth interface Std. Opt. NA

Steering wheel audio controls Std. NA Std.

RainsenseTM wipers Opt. NA NA

OnStar Std.2NA NA

Cornering lamps Std. NA NA

Rear Parking Assist Opt. NA Opt.

6-passenger seating Opt. NA NA

Laminated side glass Std. NA NA

Passenger (f) power seat controls 6-way NA 2-way

Passenger (f) express down window Std. Opt. NA

Driver Information Centre Std. NA NA

Automatic rear load leveling Std. NA NA

Powertrain Warranty 60/160,000 60/100,000 60/100,000

1. Energuide-estimated fuel at time of printing.

2. OnStar®system includes one-year Safe & Sound service agreement.

Go to www.onstar.ca for system limitations and details.

5 Keys to Learning

Luxury Features

– QuietTuningTM features reduce, block and absorb noise

– Available touch-screen navigation system

– Available Remote Vehicle Starter System

– Available heated and cooled front seats

– Jewel-like, woodgrain and chrome accents

– Available harman kardon sound system

– Available Bluetooth phone interface

– Available Ultrasonic Rear Parking Assist

Power and Performance

– Refined 3.9L VVT V6 engine on CX and CXL

– 292-hp premium V8 engine on Super

– 4-speed electronically controlled transmission

Ride and Handling

– 4-wheel independent suspension

– Available magnetic variable-assist power steering

– Available Magnetic Ride Control, a Buick first

– Standard 17-inch and available 18-inch aluminum wheels

Quality, Reliability and Durability

– 4-year/80,000-km new vehicle limited warranty

– 5-year/160,000-km powertrain limited warranty

– Premium materials, fits and finishes throughout

– Buick is the highest-ranked company (tied with Lexus) in the

2007 J.D. Power and Associates Vehicle Dependability Study3

Safety

– 5-star front crash test rating (NHTSA)

– Available Lane Departure Warning system

– Available Side Blind Zone Alert

– 4-wheel antilock disc brakes with Dynamic Rear Proportioning

– Available StabiliTrak with Brake Assist

– Front passenger dual-depth air bag4

– Front seat and side curtain air bags4

– Electronic immobilizer and available content theft-deterrent

systems

– Tire Pressure Monitoring System

– OnStar with 1-year Directions & Connections service, Turn-by-

Turn Navigation and Advanced Automatic Crash Notification2

3. Please note that J.D. Power Consumer Centre ratings may not include all information used to determine J.D. Power and

Associates awards

4. Always use safety belts and proper restraints, even with air bags. Children are safer when properly secured in a rear

seat. See the Owner Manual for more safety information.

2010 Lucerne

Quick Facts

• Walkaround Summary

• Competitive Comparison

• 5 Keys to Learning

Additional copies can be obtained by printing PDF file from GM InfoNET

All information contained in this pocket piece is based on the latest information available as of

11/2009. Buick and General Motors of Canada reserve the right to discontinue or change at any time,

without notice, any prices, colours, parts, materials, standard equipment, optional equipment, Mar-

keting Option Packages, special equipment, specifications and/or body types and models. This ma-

terial is not legally approved for use in any advertising. It is intended for use by dealership employees

Produced by GMPRO for VSSM Product Training.

Up Front

•Signature Buick waterfall chrome grille adds to appearance.

Standard on all models

•Jeweled headlamps have clear lenses with styled chrome ele-

ments for a quality appearance

•Integrated cornering lamps illuminate the curb when the turn

signal is activated

•Daytime Running Lamps with Twilight Sentinel provide safety

and convenience

•Projector fog lamps add sporty styling and help visibility in

inclement weather. Standard on all model

•Tight panel fits show quality and attention to detail. Hood-to

fascia gaps are 4mm, many other gaps are 3mm or less

•Structureless wipers reduce wind noise and perform well, es-

pecially at higher speeds

•4-year/80,000-km new vehicle warranty and 5-year/160,000-

km powertrain component warranty provide peace of mind

•Five-star frontal NHTSA crash test rating provides safety and

peace of mind

Under the Hood

•3.9-litre VVT V6 engine, with 227 hp at 5700 rpm and 237 lb.-

ft. of torque at 3200 rpm, combines power and efficiency. Ener-

guide estimated fuel ratings of 12.0/7.4 L/100km (24/38 mpg)

city/highway. Variable Valve Timing (VVT) optimizes power and

efficiency at all engine speeds (standard CX and CXL)

•FlexFuel capability on the V6 engine allows Lucerne to run on

varying blends of ethanol and gasoline (from 100% gasoline to

a maximum of 85% ethanol)

•4.6-litre DOHC V8 engine produces 292 hp at 6300 rpm and

288 lb.-ft. of torque at 4800 rpm. Energuide-estimated fuel

economy of 13.8/8.8 L/100km (20/32 mpg) city/highway1Pre-

mium fuel recommended (standard Super)

•Regular unleaded fuel can be used with both engines

•4-speed automatic transmission provides smooth shifts and

proven durability

•Full-function traction control helps reduce wheelspin on slick

surfaces

•Oil life system indicates when to change oil

Passenger Side

•Chrome portholes are a classic Buick design cue. 3 per side

with V6 models, 4 per side with V8

•Bright beltline and window trim provide a refined appearance

•Mirrors have standard manual folding and power adjustment

and available heated, driver’s auto dimming and turn-signal in-

dicators

•Chrome full-grip door handles provide easy operation

•17-inch (CX, CXL) and 18-inch (Super) aluminum wheels pro-

vide an appealing style with each trim level.

At the Rear

•Jeweled taillamps have translucent red lenses with crafted

chrome assemblies underneath for appearance

• Chrome decklid trim on Super adds a touch of luxury

• Dual Chrome exhaust tips add a sporty appearance on Super.

Single chrome tip on CX and CXL

• Ultrasonic Rear Parking Assist helps provide audio and visual

warnings to certain objects when backing up at low speeds

(available CX and CXL, standard Super)

• 481 litres (17 cu.ft.) trunk with wide opening and low liftover

adds convenience. Includes rear armrest pass-through

Driver Side

•

Lane Departure Warning alert helps drivers to avoid uninten-

tional lane changes for control and safety. A camera sensor de-

tects unintentional lane departures and alerts the driver with a

display in the right cluster binnacle (available CXL and Super)

•Side Blind Zone Alert is designed to help drivers detect vehicles

in their side blind spot. Provides a visual alert in the outside

rearview mirror when a vehicle is in the side blind zone (available

CXL and Super; requires Lane Departure Warning)

•Four-wheel independent suspension provides a smooth ride.

CX and CXL have Ride and Handling; Super has Sport Tuned

•Magnetic Ride Control uses real-time damping to provide crisp

handling and a premium, refined ride (standard Super)

•StabiliTrak electronic stability control with Brake Assist senses

where drivers steer and helps them stay on course. If emergency

braking is sensed, Brake Assist optimizes braking at each wheel

(available CX/CXL, standard Super)

•4-wheel disc antilock brakes with Electronic Brakeforce Distri-

bution provide performance and safety

•Remote Vehicle Start System provides convenient starting from

up to 60 metres (196’) away. Activates HVAC, rear defogger and

heated seats as required (available CX/CXL, standard Super)

•Electronic immobilizer provides vehicle anti-theft protection

•Tire Pressure Monitoring System alerts driver to a low tire

pressure for safety and peace of mind

Interior

•QuietTuningTM provides a remarkably quiet interior. Includes

laminated front and rear side glass, laminated steel dash panel,

sound-damping dash mats, double-isolated powertrain mounts,

composite baffles, melt-on floor pan sound deadeners, thick

carpet and composite wheel-housing liners

•6 standard air bags2include driver dual-stage, front-passenger

dual-depth, side-curtain head and side-impact thorax air bags

for comprehensive occupant protection

•Memory package recalls the seat and outside mirror settings

for 2 drivers (standard CXL and Super)

•Automatic dual-zone climate control provides convenient op-

eration and includes rear-seat cooling outlets and outside tem-

perature (available CX, standard CXL and Super)

•5-passenger seating with front bucket seats is standard

•6-passenger seating with 40/20/40 split front seat includes

armrest and storage (available CX/CXL)

•6-way power driver’s seat is standard. 6-way power passenger

and 8-way power front seats are available

•Heated leather appointed front seats provide comfort in cold

weather (standard CXL)

•Heated and cooled perforated leather-appointed front seats

provide comfort in cold or hot weather (available CXL, standard

on Super)

•Leather-wrapped steering wheel with audio and cruise

controls on CX adds convenience. Heated leather-wrapped

standard on CXL. Heated wood wheel is available on CXL; stan-

dard on Super

•Tilt steering column adds convenience (CX/CXL). Power

tilt/telescoping steering column standard on Super

•Universal Home Remote learns the codes of up to three com-

patible devices (available CX, standard CXL and Super)

•Sound systems choices include CD/MP3 player, 6-disc CD

changer and touch screen-navigation system

•Harman Kardon 9-speaker premium audio system with 280

watts delivers rich, pleasing sound (available)

•XM Satellite Radio,3with a wide variety of programming, has

something to excite any driver (available CX, standard CXL and

Super)

•OnStar4includes 1-year Directions & Connections service,

Turn-by-Turn Navigation and Advanced Automatic Crash Notifi-

cation for safety and convenience5

•Bluetooth phone interface allows the driver to make hands-free

cell phone calls within the vehicle. Requires Bluetooth-enabled

phone. Available CX, standard on CXL and Super

•Comfort and Convenience Package includes a cargo conven-

ience net, Universal Home Remote and automatic dual zone cli-

mate control. Bluetooth cellphone connectivity and 16”

Compact Steel Spare. Available on CX

•Driver Confidence Package includes StabiliTrak, ultrasonic rear

parking assist, content theft alarm and remote start system.

Available on CXL-1SA

•Premium model (CXL-1SB) combines Driver Confidence Pack-

age with Sunroof, Premium audio system, Lane Departure

Warning and Side Blind Zone Alert plus 17” chrome finish

wheels

1. Energuide-estimated fuel economy at time of printing.

2. Always use safety belts and proper child restraints, even with air bags. Children are

safer when properly secured in a rear seat. See the Owner Manual for more information.

3 Includes three trial months beyond which service fees apply.Only available in 10 Cana-

dian provinces and contiguous 48 states.

4 One-year OnStar Safe & Sound service is included. Visit onstar.ca for system limitations

and details.

CTS Sedan vs. the Competition

BOLD denotes a Cadillac advantage.

2010 Cadillac 2010 BMW 2010 Mercedes

CTS RWD 1SA 328i RWD Benz C300 RWD

Performance Specifications

Engine 3.0L VVT V-6 SFI 3.0L VVT Inline-6 3.0L V-6

Horsepower (@ rpm) 270 @ 7,000 230 @ 6,500 228 @ 6,000

Torque (@ rpm) 223 @ 5,700 200 @ 2,750 221 @ 2,500

Transmission 6-speed man. 6-speed man. 6-speed man.

Opt Engine 3.6L VVT V-6 DI 1SB NA NA

Opt horsepower (@ rpm) 304 @ 6,400 NA NA

Opt torque (@ rpm) 273 @ 5,200 NA NA

Opt. Transmission 6-speed auto. 6-speed auto. 7-speed man.

Drivetrain RWD RWD RWD

Opt. drivetrain AWD AWD xi only AWD4MATIC

Front Suspension Ind. SLA Ind. Double-Pivot Ind. Strut

Rear Suspension Ind. Multilink Ind. 5 Link Ind. Multilink

Power Steering Type Hydraulic speed Hydraulic speed Hydraulic speed

proportional proportional proportional

Turning circle (m/ft.) 10.4 / 35 11.8/38.7 11/36

Fuel tank (L/gal.) 68/14.9 61/13.4 66/14.5

Recommended fuel Regular Premium Premium

L/100km (city/hwy) Auto. Trans 11.3/7.2 11.3/6.9 11.7/7.8

mpg (city/hwy) Auto. Trans 25/39 25/41 24/36

Dimensions and Interior Volume in mm/inches unless otherwise indicated

Wheelbase 2,880/113.4 2,760/108.7 2,760/108.6

Exterior length 4,866/191.6 4,541/178.8 4,630/182.3

Exterior body width 1,842/72.5 1,817/71.5 1,770/69.7

Exterior height 1,472/58.0 1,421/55.9 1,444/56.9

Front tread 1,570/61.8 1,500/59.1 1,541/60.7

Rear tread 1,575/62.0 1,529/60.2 1,544/60.8

Front legroom 1,077/42.4 1,054/41.5 1,059/41.7

Rear legroom 913/36.0 878/34.6 848/33.4

Front headroom 988/38.9 978/38.5 942/37.1

Rear headroom 937/36.9 953/37.5 942/37.1

Front hip room 1,400/55.1 N/A/N/A 1,338/52.7

Rear hip room 1,375/54.1 N/A/N/A 1,381/54.4

Front shoulder room 1,441/56.7 1,408/55.4 1,390/54.7

Rear shoulder room 1,390/54.7 1,399/55.1 1,398/55.0

Luggage volume (L/cu.ft.) 385/13.6 460/16.2 354/12.5

Vehicle Features

Wheel size choice 17”/18” 17” 17”

Remote Vehicle Start ONA NA

Leather seat trim SNA NA

Ventilated Front Seats ONA NA

Homelink SNA NA

Compass SO O

Power tilt mirrors SOpt. O

Rear seat armrest/passthrough SNA NA

Voltage/Oil Pressure Gauges SNA NA

Telematics OnStar® 2 BMW Assist) TeleAid

Tire Pressure Monitor Direct Indirect Indirect

Warranty (months/km)

New Vehicle 48/80,000 48/80,000 48/80,000

Powertrain 60/160,000 48/80,000 72/110,000

Roadside Assistance 60/160,000 48/unlimited 48/unlimited

No Charge Maintenance 48/80,000 48/80,000 NA/NA

Keys to Learning

Power and Performance

• 3.0L Direct Injection V6 with 270 hp (1SA).

• 3.6L Direct Injection V6 with 304 hp (standard on 1SB).

• 6-speed manual (standard) or 6-speed automatic transmission

(standard on Sport Wagon; available on Sedan).

Ride and Handling

• Exclusive performance-oriented RWD architecture.

• Available AWD.

• 4-wheel independent suspension.

• Available 19" Wheel Package with Summer Only tires.

• 4-mode StabiliTrak for performance driving.

• ZF speed-sensitive variable-assist steering.

Comfort and Convenience

• Sport seats with leatherette or available leather seating

surfaces.

• Available Sapele wood trim.

• Available heated and ventilated front seats.

• Available DVD navigation system

• Bose®5.1 Surround Sound system with CD/DVD Player, 10

speakers, 40GB Hard Drive with USB and audio input jack con-

nectivity.1

• Available Rear Vision Camera (Sport Wagon only).

• Available UltraView Sunroof.

• Available LED ambient interior accent lighting.

• Standard Bluetooth®hands-free phone interface.

Safety and Security

• OnStar®with Turn-by-Turn Navigation3.

• Six air bags including dual-stage, dual-depth front air bags4.

• Available Xenon HID headlamps with LED light pipes and

Adaptive Forward Lighting System.

• Tire Pressure Monitoring System.

• LED tail lamps and full-width LED CHMSL.

Quality, Reliability and Durability

–

Hand cut-and-sewn instrument panel top pad, seats and door

inserts

–

5-year/160,000-km Powertrain Component Warranty

–

Oil life monitoring system

2010 CTS Portfolio

Quick Facts

• Walkaround Summary

• Competitive Comparison

• Keys to Learning

Additional copies can be obtained by printing PDF file from LMS or Global Connect

All information contained in this pocket piece is based on the latest information available as of

01/2010. Cadillac and General Motors of Canada reserve the right to discontinue or change at any

time, without notice, any prices, colours, parts, materials, standard equipment, optional equipment,

Marketing Option Packages, special equipment, specifications and/or body types and models. This

material is not legally approved for use in any advertising. It is intended for use by dealership em-

Motors. Produced by GMPRO for VSSM Product Training.

Up Front

•Bold, dramatic exterior styling with upper and lower mesh

grilles and front fender chrome air extractors creates a unique

road presence totally different from competitive vehicles.

•Tungsten halogen headlamps with wiper activation provide

powerful illumination.

•Twilight Sentinel®headlamp control automatically activates

headlamps and tail lamps when needed.

•Xenon High Intensity Discharge (HID) headlamps help

contribute to nighttime driving vision (available).

•LED front light pipes, included with HID headlamps, provide a

distinct appearance.

•Adaptive Forward Lighting System, included with HID head-

lamps, pivots the headlamps while turning for enhanced visibility.

•Fog lamps for additional lighting in inclement weather (avail-

able). Brakes ducts on models without fog lamps.

Under the Hood

•3.0L Direct Injection V6 with Direct Injection and Variable

Valve Timing (VVT) delivers 270 hp and 221 lb.-ft. torque..

•3.6L Direct Injection V6 Direct Injection and Variable Valve

Timing (VVT) delivers 304 hp and 273 lb.-ft. torque.

•Fuel Consumption ratings

•Direct Injection on both engines produces more power while

maintaining lower fuel consumption and reduced emissions.

Both engines also operate with regular unleaded fuel.

•6-speed manual transmission meets expectations of perform-

ance-minded drivers with precise shift feel (standard on Sedan;

not available on Sport Wagon).

•6-speed electronically controlled automatic transmission

with Driver Shift Control for tap-up/tap-down shifting. Includes

Downgrade Detection with Brake Assist, Performance Algo-

rithm Liftfoot (PAL) and Performance Algorithm Shifting (PAS)

are included for responsive performance (standard on Sport

Wagon, available on Sedan).

Passenger Side

•17" aluminum wheels and P235/55R17 H-rated All-season

tires contribute to handling and performance.

•18" aluminum wheels with multi-coat painted finish and

P235/50R18 V-rated all-season tires handle higher sustained

speeds. Included in available Performance Package with 18" All-

Season tires . Standard on 3.6L Sedan.

•18" high-polished aluminum wheels optional on CTS Sedan

and CTS Wagon with Performance Package.

•Sport Package includes 19" high-polished aluminum wheels

with P245/45ZR19 Y-rated Summer-Only performance tires.

Available with 3.6L models.

•Power, heated outside rearview mirrors help defrost mirrors

in cold weather.

At the Rear

•LED tail lamps with light pipes provide distinctive appearance,

long bulb life. 26 LED light pipes on Sport Wagon.

•Ultrasonic Rear Parking Assist provides warning of objects be-

hind vehicle when backing up (available).

•Sedan cargo capacity of 385 litre (13.6 cu. ft.) trunk with a low

lift-over height and rear-seat pass-through (Sedan).

•Limited-slip rear differential helps reduce wheel slip. Included

with available Performance Package.

At the Rear (Sport Wagon)

•Sport Wagon cargo capacity of 736 litres (26 cu. ft.) with seats

up and 1,642 litres (58 cu. ft.) with seats down

•3-tier rear cargo storage includes carpeted primary cargo area,

covered secondary cargo area and third cargo area below it

adjacent to air inflator.

•Retractable privacy shade (available).

•Pet guard/cargo restraint net (available).

•Memory Power Liftgate with three programmable height

settings.

Driver Side

•Independent short/long arm (SLA) front and 5-link independ-

ent rear suspension provides precise suspension control.

Available Sport suspension (FE2) and Performance suspension

(FE3) provide enhanced handling.

•Rear-wheel drive helps provide balanced handling with near

50/50 weight distribution.

•All-wheel drive contributes to excellent traction and handling

on a variety of surfaces and conditions. Delivers 25% front /

75% rear torque on dry roads and up to 100% torque to the

front wheels when needed. Available with automatic transmis-

sion.

•Variable-effort, variable-ratio ZF power rack-and-pinion

steering provides more assist during low-speed driving and

less assist during highway cruising.

•4-wheel ABS vented disc brakes provide firm, positive braking

and reduced brake fade.

•Performance Braking System with larger rotors included with

available Performance Package.

•EZ Key passive entry system operates up to 60 metres (200')

away and applies driver personalization settings for cabin tem-

perature, defogger and heated/ventilated seats (available).

•StabiliTrak stability control system helps maintain stability

when system detects oversteer/understeer to help keep vehicle

on intended path.

Interior

•Bose®8-speaker sound system (standard).

•Bose®5.1 Surround Sound system with CD/DVD player,

10 speakers, 40GB hard drive with USB and audio connectivity

(available)1.

•In-dash 6-disc CD changer (available).

•Navigation system includes pop-up touch screen, voice and/or

text guidance and 40GB Hard Drive Device. (available)2.

•Back-up camera displays certain objects behind vehicle in

pop-up navigation display (Sport Wagon only).

•LED ambient interior accent lighting casts clean white light on

key areas throughout the cabin (available).

•Bluetooth®phone interface enables driver to make handsfree

cell phone calls within vehicle. Requires Bluetooth compatible

phone and initial setup.

•Hand cut-and-sewn stitching on seats, instrument panel and

doors adds premium tailored appearance.

•Nuance leather seating surfaces include 8-way power front

seats with 2-way power lumbarand driver memory.

•Heated front seats are standard, heated and ventilated front

seats are available.

•60/40 split flat-folding rear seat (standard on Sport Wagon,

available on Sedan).

•UltraView Sunroof includes two large glass panels for

panoramic open-air driving (available).

•OnStar®includes one-year Directions & Connections service

with Turn-by-Turn Navigation.3

•Genuine Sapele wood trim on the instrument panel, centre

console steering wheel, gearshift knob and door trim (avail-

able).

•Dual-zone automatic climate control with separate tempera-

ture controls/displays for driver and front passenger.

•Power tilt/telescopic steering column (available). Manual

tilt/telescopic steering column is standard.

•Six air bags include driver’s side dual-stage and front passen-

ger side dual-depth air bags. Seat-mounted side-impact air

bags and head-curtain side-impact air bags are also standard.4

•PASS-Key III anti-theft system detects tampering with ignition

lock, shuts down vehicle ignition to help prevent vehicle theft.

•Universal Home Remote (standard).

1. Navigation screen will display DVD Video only when vehicle is in Park

2. At Time of Print, detailed Map Coverage is available for most major urban areas of the United States and for certain

Metropolitan areas of Canada (Vancouver, Calgary, Edmonton, Winnipeg, Windsor, London, Toronto, Ottawa, Mon-

treal, Quebec City and Halifax). Coverage is limited outside these areas.

3 OnStar uses existing emergency service providers and wireless and satellite technologies. Visit www.onstar.ca for

system limitations and details.

4 Always use safety belts and proper child restraints, even in vehicles with airbags. Children are safer when properly

secured in a rear seat. See the Owner Manual for more safety information.

CITY/HWY RWD AWD

SEDAN L/100KM MPG L/1OOKM MPG

3.0L 11.3/7.2 25/39 11.9/7.7 24/37

3.6L A6 11.4/6.9 25/41 11.7/7.4 24/38

3.6L M6 13.0/7.9 22/36

WAGON

3.6L A6 11.8/7.5 24/38 11.7/7.4 24/38

Cadillac DTS vs. the Competition

Bold denotes a Cadillac advantage

2010 Cadillac 2010 BMW 2010 Lincoln

DTS 528 i MKS

Performance Specifications

Base Engine 4.6 L V-8 3.0 L I-6 3.7 L V-6

Horsepower @ rpm 275 @ 6,000 230 @ 6,500 273 @ 6,250

Torque (lb.-ft.) @ rpm

295 @ 4,400 200 @ 2,750 270 @ 4,250

Opt. Engine 4.6L V8 – –

Horsepower @ rpm 292 @ 6300 – –

Torque (lb.-ft.) @ rpm

288 @ 4500 – –

Transmission 4-speed auto. 6-speed man. 6-speed auto.

Drivetrain

Front-wheel drive Rear-wheel drive Front-wheel drive

Suspension, f/r Ind./ind. Ind./ind. Ind./ind.

Speed sensitive steering Magnasteer Servotronic N/A

Fuel tank 68/13.2 70/15.4 76/16.7

Turning radius 6.5/21.3 5.7/18.7 6.05/19.8

L/100km (city/hwy) 13.8/8.7 11.4/7.3 12.5/8.4

mpg (city/hwy) 20/32 25/39 23/34

Dimensions and Interior Volume in mm/inches unless otherwise indicated

Wheelbase 2,936/115.6 2,888/113.7 2,868/112.9

Curb weight 1,818/4,008 1,590/3,505 1,872/4,127

Exterior length 5,273/207.6 4,854/191.1 5,184/204.1

Exterior body width 1,900/74.8 1,846/72.7 1,928/75.9

Exterior height 1,463/57.6 1,468/57.8 1,565/61.6

Front tread 1,588/62.5 1,558/61.3 1,651/65.0

Rear tread 1,567/61.7 1,581/62.2 1,661/65.4

Front legroom 1,080/42.5 1,054/41.5 1,064/41.9

Rear legroom 1,057/41.6 914/36.0 980/38.6

Front headroom 996/39.2 993/39.1 963/37.9

Rear headroom 980/38.6 967/38.1 980/38.6

Front hiproom 1,455/57.3 NA/NA 1,405/55.3

Rear hiproom 1,440/56.7 NA/NA 1,405/55.3

Front shoulder room 1,524/60.0 1,456/57.3 1,488/58.6

Rear shoulder room 1,504/59.2 1,452/57.2 1,458/57.4

Luggage volume (max) 532/18.8 520/18.4 521/18.4

Passenger volume 2,987/105.5 2,806/99.1 2,990/105.6

Seating Capacity 5/6 5 5

Vehicle Features

Magnetic Ride Control Opt. NA NA

IntelliBeam Opt. NA NA

Cornering lights Std. NA NA

Adaptive Remote Start system Std. NA NA

Adaptive Cruise Control Opt. NA Opt.

Heated steering wheel Opt. NA NA

Massaging front seats Opt. NA NA

In-Vehicle Communications OnStar BMW Assist NA

Laminated side glass Std. NA NA

DVD Entertainment system Opt. NA Opt.

Lane departure warning Opt. NA NA

Blind spot sensor Opt. NA NA

Powertrain limited Warranty 60/160,000 48/110,000 72/110,000

1 Always use safety belts and proper restraints, even with airbags. Children are safer when prop-

erly secured in a rear seat. See the Owner Manual for more safety information.

DTS Key Messages

Design

– The Cadillac’s signature egg crate design grille features a bold,

centre-mounted Wreath and Crest badge

– Available Platinum Edition (1SE) with unique exterior and

interior appointments

– HID Xenon headlamps and state-of-the-art LED taillamps and

CHMSL

– Chrome accents create a sophisticated appearance

– Low and forward-positioned instrument panel

– Dual-firmness pillow-top seats with high-performing heated

and cooled seats for outstanding comfort

– Integrated centre stack designed for a seamless appearance

Performance

– 275-hp NorthstarTM 4.6L V8 on Luxury Editions (1SA, 1SC, 1SD)

– 292-hp NorthstarTM High Output 4.6L V8 on 1SE

– Magnetic Ride Control suspension on Platinum Edition for out-

standing performance and ride comfort

– Enhanced structural integrity for refined ride and handling

– Brake assist, which boosts brake pressure for improved stop-

ping response as needed, is integrated with StabiliTrakTM

– Large disc brakes with dual-piston front calipers

Technology

– Available Lane Departure Warning and Side Blind Zone Alert

– 6 standard airbags including a new dual-depth passenger-side

frontal airbag and roof-rail-mounted side curtain airbags

– Theft-deterrent, noise-damping laminated glass

– Ultrasonic Front and Rear Park Assist standard except 1SA

– Available IntelliBeamTM headlamps automatically activate your

high/low beams, maximizing lighting area for greater visibility.

– Bluetooth for phone

– Available Adaptive Cruise Control

– Entertainment system includes 8-speakers, MP3 player, auxil-

iary input jack and XM Satellite RadioTM

– Available in-dash 6-disc CD changer and Bose®speaker

system and touch-screen DVD navigation

Craftsmanship

– Genuine materials such as natural walnut wood, three grades

of available premium leathers and aluminum sill plates

– Noise, vibration and harshness (NVH) improvements that in-

clude laminated side glass, structureless windshield wiper

blades and laminated steel front-of-dash

– World-class quality is achieved through the use of leading

global manufacturing processes that empower each skilled

craftsperson to own and continuously improve their craft

2010 DTS

Quick Facts

• Walkaround Summary

• Competitive Comparison

• DTS Key Messages

Additional copies can be obtained by printing PDF file from LMS or Global Connect

All information contained in this pocket piece is based on the latest information available as of

11/2009. Cadillac and General Motors of Canada reserve the right to discontinue or change at any

time, without notice, any prices, colours, parts, materials, standard equipment, optional equipment,

Marketing Option Packages, special equipment, specifications and/or body types and models. This

material is not legally approved for use in any advertising. It is intended for use by dealership em-

Motors. Produced by GMPRO for VSSM Product Training.

Up Front

• Signature Cadillac egg-crate grille features prominent Cadillac

crest. Body-colour grille is available

• Available Platinum Edition (1SE) includes unique 18-inch

wheels, chrome grille, exterior trim and leather-wrapped interior

• Adaptive Cruise Control uses a receiver mounted in the grille

to automatically adjust speed and maintain distance from vehi-

cles ahead (available)

• Xenon High Intensity Discharge (HID) headlamps provide

bright, uniform illumination

• IntelliBeam automatically controls high-beam actuation using a

camera mounted in the inside rearview mirror (available)

• Cornering lamps illuminate when the turn signal is activated

•

Daytime Running Lamps with Twilight Sentinel for convenience

• Front Parking Assist provides audio and visual warnings to cer-

tain objects when approaching them at low speeds. Standard

except 1SA

• Structureless wiper blades offer low wind noise and great

performance, especially at higher speeds

• Sculpted aluminum hood is lightweight for efficiency

Under the Hood

• 4.6-litre DOHC V8 engine (LD8) produces 275 hp and 295 lb.-

ft. of torque. Provides quick launch and part-throttle response.

Energuide ratings are 13.8/8.7 L/100 km (20/32 mpg) city/hwy.

Standard on 1SA, 1SC and 1SD

• 4.6-litre DOHC V8 engine (L37) produces 292 hp and 288 lb.-

ft. of torque and is a more responsive, higher revving version

with more peak horsepower (1SE)

• Regular unleaded fuel can be used with both engines. Pre-

mium is recommended

• 4T80-E 4-speed automatic transmission provides smooth

shifts and proven durability

• Noise-reducing features include laminated steel dash panel,

acoustic engine cover, hydraulic engine mounts, rubber dash

damping mats and hood blanket and seals

• Oil life monitor indicates when to change oil

• New Mobil 1 synthetic oil provides long oil life1

Passenger Side

• Laminated theft-deterrent side glass helps reduce interior

noise and helps keep shattered glass together to prevent

snatch-and-grab theft attempts

• 17- and 18-inch aluminum wheels provide a total of 4 wheel

choices for appearance

• Tire Pressure Monitor warns of an improperly inflated tire

• Mirrors have standard manual folding, power adjustment, turn

signal and heated features. Driver’s side auto-dimming and

power folding features are available

• Robust structure for crashworthiness ratings, quality ride,

quietness and craftsmanship

At the Rear

• LED taillamps, CHMSL and backup lights illuminate 4 times

faster and last longer than conventional bulbs for safety

• Rear Parking Assist helps provide audio and visual warnings to

certain objects when backing up at low speeds. Standard on all

except 1SA

• Chrome dual exhaust tips add a sporty appearance

• 532 litre (18.8 cu.ft.) trunk with wide opening and low liftover

adds convenience. Includes rear armrest pass-through

• Trunk Convenience Package includes net, mat and tie-down

Driver Side

• Lane Departure Warning is designed to help prevent

unintentional lane changes for control and safety (available

1SD, standard on 1SE))

• Side Blind Zone Alert is designed to help drivers detect

vehicles in their side blind spot when changing lanes and

making turns (available 1SD, satndard on 1SE)

• Four-wheel independent suspension provides a smooth ride

• Magnetic Ride Control, the world’s fast-reacting suspension,

doesn’t make you choose between provides for performance

and ride comfort (1SE)

• Automatic rear load-leveling keeps DTS level under various

load conditions

• Magnasteer variable-assist power steering provides greater

assist at low speeds for manoeuverability, less assist at high

speeds for steering feel

• StabiliTrak helps prevent understeer and oversteer using

individual wheel braking and throttle intervention

•

Brake Assist, which boosts brake pressure for improved stop-

ping response as needed; integrated with StabiliTrak

• Traction control uses brake and throttle intervention to help re-

duce wheelspin

• 4-wheel disc antilock brakes have larger brake discs

• Dynamic Rear Proportioning regulates hydraulic pressure

individually to each of the rear brakes, optimizing braking

control by determining which wheel is on the outside of a curve

and adjusts brake pressure to enhance cornering control

• Adaptive Remote Start has a range

up to 60 metres (200’).

Activates

climate control, heated seats and defogger if required

• Vehicle theft deterrent electronic immobilizer and content

theft deterrent systems add security

1 Maintenance needs vary with different uses and driving conditions. See Owner Manual for more

information.

2 Always use safety belts and proper child restraints, even with airbags. Children are safer when

properly secured in a rear seat. See the Owner Manual for more information.

Interior

• Available Platinum Edition includes numerous unique interior

appointments. Tuscany full-leather seats; Light Ash wood trim

with decorative inlays; leather-wrapped console and instrument

panel top pad; synthetic suede headliner and pillar trim; rear

well lighting; and illuminated sill plates

• 6 standard airbags2include driver dual-level, front passenger

dual-depth, side-curtain head and side-impact thorax airbags

for comprehensive occupant protection.

• Passenger Occupant Detection System2will suppress airbag

deployment if a child or small person is sensed, averting poten-

tial injury from high-pressure airbag inflation

• Analogue clock adds a stylish appearance

• Technical grain trim is standard. Genuine dark Burled Walnut

trim is available

• 3 leather seat offerings include standard Nuance, available

semi-aniline Tuscany and premium automotive aniline Tehama

• 5-passenger seating includes front bucket seats and floor

console (standard)

• 6-passenger seating includes front 40/20/40 split bench seat

with 8-way power driver and passenger seats (available)

• 8-way power front seats with power lumbar adjusters standard

• 4-way power front lumbar adjusters with massagers add

comfort (available)

• Heated and cooled perforated front seats and heated rear

seats are available on 1SA, otherwise standard.

• Steering wheel options include wood accents, heated rim and

power tilt/telescope

• Automatic tri-zone climate control includes enhanced rear-seat

outlets/controls and cabin air filtration. Dual zone automatic

climate control is standard on 1SA.

• Sunroof is electric sliding, express open with tinted glass roof

Panel. Standard except 1SA

• Universal Home Remote learns the codes of up to three

compatible devices. Standard except 1SA

•

Sound systems choices include standard CD/MP3 player, plus

6-disc in-dash CD changer/MP3 playback and DVD navigation

system. All systems include auto tone, speed controlled volume,

Radio Data System and auxiliary audio input jack

•

Bose speaker system provides rich, pleasing sound (available)

• XM Radio,2with a wide variety of programming, has something

to excite any driver. Enhanced display for 2009

• OnStar3provides a number of safety and convenience services

including Turn-by-turn navigation with 1 year of the Directions

and Connections Plan.

• Bluetooth®phone interface allows the driver to make hands-

free cell phone calls within the vehicle

3 Includes 3 free trial months beyond which service fees apply

4 One-year OnStar Directions & Connections service is included. Visit onstar.ca for system limita-

tions and details.

Escalade EXT

2010

Cadillac

Escalade EXT

Performance Specifications

Base Engine 6.2L VVT V8

Horsepower @ rpm 403 @ 5700

Torque (lb.-ft.) 417 @ 4300

Transmission 6-speed auto.

Drivetrain Front engine/AWD w/open transfer case

Suspension, front Ind. short-long arm coil-over-shock

Suspension, front Non.-ind. 5-link coil springs, load-leveling

Steering Type Power rack-and-pinion

GVWRmax. (kg/lb.) 3,266/7,200

Payloadmax. (kg/lb.) 618/280

Towing capacity max.1(kg/lb.) 3,447/7,600

Fuel tank (L/gal.) 117.3/25.8

Turning radius (m/ft.) 6.55/21.5

Dimensions and Interior Volume in mm/inches unless otherwise indicated

Wheelbase 3,302/130.0

Curb weight (kg/lb.) 2,648/104.3

Exterior length 5,649/222.4

Exterior body width 2,009/79.1

Exterior height 1,956/77.0

Front tread 1,732/68.2

Rear tread 1,702/67.0

Front headroom 1,024/40.3

Rear headroom 963/37.9

Front legroom 1,049/41.3

Rear legroom 993/39.1

Front hiproom 1,636/64.4

Rear hiproom 1,582/62.3

Front shoulder room 1,659/65.3

Rear shoulder room 1,659/65.3

Cargo Volume max..(L/cu.ft.) 2,860/101.03

Seating Capacity 5

Vehicle Features

Active fuel management®Std.

Flex Fuel Capability Std.

Stabilitrak®Std.

Road-Sensing Suspension Std.

Foldable Midgate Std.

Utility Enhancement System Std.

Remote Vehicle Starter Std.

OnStar®Std.

Touch screen DVD naviation system Std.

Bluetooth Std.

USB Port Std.

Wheel/tire sizes 18”/22”

Heated windshield washer fluid Std.

HID headlamps Std.

Rear Park Assist Std.

Rearview camera Std.

Heated/cooled front seats Std.

Powertrain limited warranty (mths/km) 60 /160,000

No charge scheduled Maintenance 48/80,000

Maximum trailering weight includes driver and one passenger in tow vehicle and all required equipment.

See Owner Manual for more details.

5 Keys to Learning

Comfort and Convenience

– IntelliBeam, heated steering wheel and 22-inch 7-spoke

chromed aluminum wheels included on Luxury and Premium

– Heated/cooled front seats

– Utility Enhancement System with folding Midgate and lockable

top-box storage bins

– 14-way power front seats with power lumbar adjusters and

driver’s seat position memory

– High Intensity Discharge headlamps with Twilight Sentinel

– Remote Vehicle Starter System

– Navigation system with rearview camera, premium Bose®5.1

digital surround sound system, DVD/CD/MP3/6-disc CD

changer and XM Satellite Radio

– Available rear-seat DVD entertainment system

– Power tilt steering wheel

– Express up/down front windows

Power and Performance

– 403-hp 6.2L VVT V8 engine with Active Fuel ManagementTM and

FlexFuel

– 6-speed automatic transmission with Driver Shift Control

– Automatic all-wheel drive

Ride and Handling

– Road-sensing suspension and 18-inch wheels on Base

– Magnetic Ride Control and 22-inch wheels on Luxury and Pre-

mium

Quality, Reliability and Durability

– 4-year/80,000-km new vehicle limited warranty

– 5-year/160,000-km powertrain warranty

Safety and Security

– OnStar®includes one-year Directions & Connections service

and downloads to the navigation system2

– Dual-stage frontal air bags with Passenger Sensing System,

front seat side-impact thorax air bags and head curtain side im-

pact air bags with rollover sensor3

– StabiliTrak with Roll-Over Mitigation

– 5-star frontal and side safety rating

– PASS-Key III+ theft-deterrent system

2. TBT availability impacted by some geographic/cellular limitations, advisor assisted routing available)

3. Always use safety belts and proper child restraints, even with air bags. Children are safer when properly

secured in a rear seat. See Owner Manual for more safety information.

2010 Escalade EXT

Quick Facts

• Walkaround Summary

• Competitive Comparison

• 5 Keys to Learning

Additional copies can be obtained by printing PDF file from LMS or Global Connect

All information contained in this pocket piece is based on the latest information available as of

12/2009. Cadillac and General Motors of Canada reserve the right to discontinue or change at any

time, without notice, any prices, colours, parts, materials, standard equipment, optional equipment,

Marketing Option Packages, special equipment, specifications and/or body types and models. This

material is not legally approved for use in any advertising. It is intended for use by dealership em-

Motors. Produced by GMPRO for VSSM Product Training.

Up Front

•Bold, powerful front end styling provides a distinct Cadillac

appearance

•Body-mounted full wrap front fascia eliminates visual gaps for

quality

•Exceptional fit and finish and gap reduction with 4.0 mm

gaps on most panels provide a quality appearance

•High Intensity Discharge headlamps provide a bright, intense

beam of white light

•Twilight Sentinel®automatically turns on/off headlamps and

taillamps

•IntelliBeam automatically switches the headlamps from high

beam to low beam and back again when taillamps or oncoming

headlamps are detected. Available

•Flat blade wipers offer low wind noise and great performance,

especially at higher speeds

Under the Hood

•Vortec 6.2L V8 with VVT has 403 hp and 417 lb.-ft. of torque

•Variable Valve Timing (VVT) optimizes power and efficiency at

all engine speeds

•Active Fuel Management®switches from 8- to 4-cylinder oper-

ation when appropriate, providing better fuel efficiency

•FlexFuel capability allows the use of ethanol/gasoline blends

•Tow/Haul mode provides enhanced trailering performance

•All-wheel drive is always fully engaged. Provides superior low-

speed drivability and fuel economy

•Hydraulic engine mounts absorb vibration and noise

•Extended-life components1help reduce maintenance. Include

spark plugs, ignition system, transmission fluid and coolant

•Warranty includes 4-year/80,000-km bumper-to-bumper cover-

age and 5-year/160,000-km powertrain coverage

Passenger Side

•Fully boxed frame offers additional crush space for safety and

accommodates new suspension

•Chrome fender portholes are a bold styling cue

•18-inch, 7-spoke aluminum wheels provide a substantial ap-

pearance. Chromed version is available

•22-inch, 7-spoke chromed aluminum wheels provide a bolder

appearance. Available

•Tire Pressure Monitoring System displays individual tire pres-

sures in the Driver Information Centre for safety

•Roof-mounted luggage rack with chrome accents increases

cargo-carrying capacity. Side rails. Includes centre cross bars

•Chrome accent assist steps facilitate entry/exit. Power

retractable assist steps are available

At the Rear

•Utility Enhancement System provides unmatched cargo carry-

ing flexibility. Includes the unique Midgate that may be folded

into the cab, opening up an 2.5 metre (8-foot) long cargo bed

that can be either covered or open

•Rigid 3-piece cargo cover can be stowed in the cargo bed

sides with strap system. Each piece supports up to 113 kg

(250 lb.)

•Top-Box storage housed between reinforcement in bed and

fender. 48 litres (1.7 cu. ft.) of storage on each side

•Removable rubber cargo mat helps keep items from shifting

•Lighting in storage area is built into the bed wall. Illuminates

the driver’s side top-box storage area and the cargo bed

•Ultrasonic Rear Parking Assist provides audible warnings to

help identify objects behind Escalade EXT when reversing.

•Rearview camera allows the driver to view objects behind the

vehicle on the navigation screen. Standard

•Heavy-duty trailering equipment tows up to 3,402 kg (7,500 lb.)2

Driver Side

•StabiliTrak®with Roll-Over Mitigation helps maintain stability

when system detects understeer or oversteer. Roll-Over

Mitigation determines whether rollover is imminent and

engages StabiliTrak

•Short- and long-arm independent front suspension uses new

coil-over-shock design for the smoothest ride in the segment

•5-link coil spring rear suspension features standard rear load-

leveling

•Road-Sensing computer-controlled suspension adjusts shock

valving to provide a smooth, controlled ride

•Magnetic Ride Control uses magnetic damper fluid. Real-time

damping produces exceptional ride and handling. Available.

•Locking rear differential provides maximum traction

•Four-wheel antilock disc brakes with dynamic brake propor-

tioning have large rotors, stiff iron calipers for braking perform-

ance and safety

•Remote Vehicle Starter allows the vehicle to be started and ac-

tivates climate control from up to 60 metres (200 feet) away

•Mirrors have heated, power adjust, power folding, driver’s auto-

dimming, turn signal indicators, ground illumination, memory

and programmable curb tilt features for safety and convenience

Interior

•Dual-zone automatic climate control provides comfort for all

passengers

•Premium interior materials provide an exceptionally luxurious

driving environment. Includes real wood, Nuance leather,

brushed aluminum trim and bright chrome trim rings

•Dual-stage frontal air bags3with Passenger Sensing System

provide occupant protection

•Seat-mounted side-impact air bags3, driver and right front

passenger for thorax and pelvic protection

•Head curtain side-impact air bags3with rollover sensors are

designed to protect the head of outboard occupants of both

rows in certain side collisions and rollovers

•Bose 5.1 digital surround sound system includes 8 speakers,

DVD/CD/MP3 playback, 6-disc in-dash CD changer and rear

audio controls

•Touch screen DVD navigation system4with 8-inch screen and

dedicated map DVD and 6-disc DVD/CD/MP3 slots for

convenience. Standard

•USB port in centre console can connect, charge and control

certain iPodsTM. Can connect MP3 players and memory sticks

(but cannot control using the radio controls)

•XM Satellite Radio, with a wide variety of programming, has

something to excite any driver

•Rear-seat DVD entertainment system includes 8-inch screen

and wireless headphones (available)

•Sunroof features express open and close for convenience.

Available

•14-way power front bucket seats including 4-way power lum-

bar, memory for 2 drivers and independent heated seat

cushions and seatbacks

•Heated and cooled front seats deliver conditioned air through

perforated surfaces in the bottom and back. Standard

•2nd-row 60/40 seats fold flat to accommodate cargo or the

fold-down Midgate

•Heated steering wheel provides comfort in cold weather.

Available

•Power adjustable pedals feature adjustable brake and

accelerator pedals with memory.

•Centre console with two-tier storage and power outlet

•Ultra Luxury Collection includes IntelliBeam headlamp control,

heated steering wheel, power sunroof, suspension package,

Magnetic Ride Control and 22” wheel and tire package

•OnStar includes 1-year Directions & Connections service, auto-

matic air bag deployment notification and Turn-by-Turn Naviga-

tion5

1. Maintenance needs vary with different uses and driving conditions. See Owner Manual for more

information.

2. Maximum trailering weight includes driver and one passenger in tow vehicle and all required

trailering equipment. See Owner Manual for more information.

3. Always use safety belts and proper child restraints, even with air bags. Children are safer when

properly secured in a rear seat. See Owner Manual for more safety information.

4. At Time of Print, detailed Map Coverage is available for most major urban areas of the United

States and for certain Metropolitan areas of Canada (Vancouver, Calgary, Edmonton, Winnipeg,

Windsor, London, Toronto, Ottawa, Montreal, Quebec City and Halifax). Coverage is limited out-

side these areas

5. OnStar®requires subscription. One-year Directions & Connection Service Agreement provided.

Go to www.onstar.ca for system limitations and details.

Escalade hybrid vs. the Competition

BOLD denotes an XLR advantage.

2010 Cadillac 2010 Lexus

Escalade 4x4 RX 450h AWD

Hybrid Hybrid

Performance Specifications

Base Engine 6.0L V8 3.5L V6

Horsepower @ rpm 332 @ 5100 245 @ 6000

Torque (lb.-ft.) @ rpm 367 @ 4100 234 @ 4800

Std. Transmission Two-mode 6-speed

4-speed auto. CVT

Drivetrain 4WD AWD

Suspension, front Ind. short-long-arm Independent,

struts coil-over-shock

Suspension, rear 5-link rigid axle, Ind. double

coil spring wishbone

Steering Type Electric-assist Electric-assist

rack and pinion rack and pinion

Towing Capacity (kg/lb.)13,357/7,500 907/2,000

Fuel tank 98/21.6 65/14.3

Turning radius 5.95/19.5 5.7/18.7

Seating capacity 85

Dimensions and Interior Volume in mm/inches unless otherwise indicated

Wheelbase 2,946/116.0 2,740/107.9

Curb weight 2,795/6,161 2,110/4,651

Exterior length 5,144/202.5 4,770/187.8

Exterior body width 2,007/79.0 1,885/74.2

Exterior height 1,887/74.3 1,720/67.7

Front tread 1,732/68.2 1,630/64.2

Rear tread 1,702/67.0 1,620/63.8

Front legroom 1,049/41.3 1,096/43.1

Rear legroom 991/39.0 942/37.1

Third row legroom 650/25.6 NA

Front headroom 1,024/40.3 992/39.1

Rear headroom 996/39.2 958/37.7

Third row headroom 963/37.9 NA

Front hiproom 1,636/64.4 1,412/55.6

Rear hiproom 1,539/60.6 1,384/54.5

Third row hiproom 1,539/60.6 NA

Front shoulder room 1,659/65.3 1,472/58.0

Rear shoulder room 1,656/65.2 1,462/57.6

Third row shoulder room 1,567/61.7 NA

Luggage volume 479/16.9 1,133/40.0

Luggage volume (max) 3,084/108.3 2,274/80.3

Passenger volume 4,871/172.0 2,823/99.7

Vehicle Features

Active Fuel Management Std. NA

Adaptive suspension Std. NA

Limited slip differential Locking NA

Remote vehicle start Std. NA

Navigation system Std. Opt.

OnStar®Std. NA

Power liftgate Std. NA

Side Blind Zone Alert Std. NA

Rearview camera Std. Std

Heated rear seats Std. NA

Standard wheels 22-inch 18-inch

Surround sound audio Std. NA

Rear audio controls Std. NA

Battery rundown protection Std. NA

Powertrain warranty (yrs/km) 60/160,000 72/110,000

Hybrid component warranty 96/160,000 96/160,000

1. When properly equipped.

5 Keys to Learning

Comfort and Convenience

– Standard 12-way power adjustable heated and cooled front

seats with driver memory

–IntelliBeam

– Bose 5.1 Digital Surround Sound System

– XM Satellite Radio

– Available DVD rear-seat entertainment system

– Remote Vehicle Starter System

– Standard Bluetooth®hands-free phone interface

– Power liftgate

Power and Performance

–Two-mode Hybrid system is a patented hybrid technology with

two modes optimized for city and highway driving

First mode: At low speed and light loads, the vehicle can oper-

ate by electric power or engine power, or any combination

Second mode: Primarily for highway speeds and heavy loads,

providing electric assist or full V8 power when needed.

–300-volt Energy Storage System works with electric motors in

the transmission to produce electric power

–Regenerative braking captures some of the energy lost during

vehicle braking and coasting and returns it to the battery for

future use

– Hybrid status information is displayed on the navigation

screen

–Standard all-wheel drive

–Towing up to 2,540 kg (5,600 lb.)1

Ride and Handling

– Magnetic Ride Control suspension

– Automatic rear load leveling

–Standard 22-inch chrome wheels

Quality, Durability and Reliability

– 4-year/80,000-km New Vehicle Limited warranty

– 5-year/160,000-km powertrain component warranty

–8-year/160,000-km hybrid-specific component warranty

Safety and Security

– Dual-stage frontal air bags, front seat side-impact thorax air

bags and head curtain side-impact air bags for all rows with

rollover sensors2

– Side Blind Zone Alert

– StabiliTrak with Proactive Roll Avoidance

2. Always use safety belts and proper child restraints, even with air bags. Children are safer when

properly secured in a rear seat. See Owner Manual for more safety information.

2010 Escalade

Hybrid

Quick Facts

• Walkaround Summary

• Competitive Comparison

• 5 Keys to Learning

Additional copies can be obtained by printing PDF file from LMS or Global Connect

All information contained in this pocket piece is based on the latest information available as of

12/2009. Cadillac and General Motors of Canada reserve the right to discontinue or change at any

time, without notice, any prices, colours, parts, materials, standard equipment, optional equipment,

Marketing Option Packages, special equipment, specifications and/or body types and models. This

material is not legally approved for use in any advertising. It is intended for use by dealership em-

Motors. Produced by GMPRO for VSSM Product Training.

Escalade Hybrid Presentation Tips

Hybrid-Specific Noises

• Hybrids have normal, unique sounds (whirring, blowing, hum-

ming) based on the various operating system components and

conditions

— Electric traction motors in transmission

— Electric air conditioning compressor

— Electro-hydraulic brake pump (recharges the accumulator

pressure)

— Electric cooling fans

Hybrid Unique Driving Characteristics

• When starting the vehicle, if a driver shifts the transmission be-

fore the vehicle start-up sequence is completed, the engine may

not actually start.

• Transition from electric only to engine start may feel like a

transmission downshift.

• To avoid discharging the 12-volt system, recommend starting

the ignition and leaving the key in the On position for operating

accessory features for extended periods of time (radio, DVD,

tailgating situations, etc.).

Overview

•Escalade Hybrid is the world’s first full-size hybrid luxury SUV,

offering fuel consumption ratings of up to 20 city and 21 high-

way on the RWD model

•Two-Mode Hybrid system is designed to increase fuel effi-

ciency in both city and highway driving. The competition only

improves city fuel economy

The first mode: Used for low speeds and stop and go traffic,

may use electric power only to propel the Escalade Hybrid up to

30 mph. Depending on vehicle demands, the Escalade Hybrid

may also run on engine power only or a combination of engine

power and electric power simultaneously

The second mode: Used during highway driving and for higher

powertrain loads. The vehicle may operate using both engine

and electric power simultaneously or when conditions warrant

— trailering, passing, etc. - it may run on engine power only. In

addition, if engine loads are light Active Fuel Management will

be used to increase fuel economy by reducing fuel consump-

tion

How it Works

•Auto Stop: At stop signs and red lights the engine will shut off

conserving fuel and emitting no emissions

•Electric Mode: During city driving and stop-and-go traffic the

Escalade Hybrid may be powered by just electricity from the hy-

brid electric motors and the 300-volt battery

•Gas Mode: If vehicle demands are high enough, the Escalade

Hybrid may be powered by just the gas engine

•Gas Mode with AFM: During highway driving if vehicle loads

are light, the Escalade will engage AFM and run on just four o

the eight cylinders to reduce fuel consumption

•Hybrid/Blended Mode: The Escalade Hybrid may use both elec-

tricity from the hybrid motors and 300-volt battery simultane-

ously with the gas engine

•Regenerative Braking Mode: The Escalade Hybrid will use re-

generative braking to capture some energy naturally lost during

braking and coasting and store it in the 300-volt battery for fu-

ture use. This stored energy will be used to propel the vehicle in

city driving and the hybrid/blended mode.

Up Front

•High Intensity Discharge headlamps with Twilight Sentinel

provide outstanding road illumination and safety

•Standard IntelliBeam automatically switches the headlamps

from high beam to low beam and back again when taillamps or

oncoming headlamps are detected

Under the Hood

•Electric accessories reduce draw on the engine for efficiency.

Includes electric air conditioning, heater coolant pump and vari-

able-effort power steering

•6.0L Vortec V8 engine with LIVC (Late Intake Valve Closing),

Variable Valve Timing and Active Fuel Management®for

power and efficiency. Produces 332 horsepower at 5100 rpm

and 367 lb.-ft. of torque at 4100 rpm.

•5-year/160,000-km Powertrain Component Warranty includes

Roadside Assistance and Courtesy Transportation for peace of

mind

•8-year/160,000-km hybrid-specific component warranty for

peace of mind

Passenger Side

•22-inch, 7-spoke chromed aluminum wheels provide a bold

appearance

•Magnetic Ride Control uses magnetic damper fluid. Real-time

damping produces exceptional ride and handling

At the Rear

•Rearview camera allows the driver to view objects behind the

vehicle on the navigation screen

•Locking rear differential provides maximum traction

Driver Side

•Electric power steering runs off its own intermediate-voltage

continuous 42-volt power source. Variable-effort and a rack-

mounted motor provide precise feel and easy manoeuverability

•Side Blind Zone Alert is designed to help provide drivers more

time to react to obstacles that may be difficult to see in the side

mirror. Standard

Interior

•300-volt Nickel Metal Hydride Energy Storage System is

housed under the 2nd-row seats and does not interfere with

3rd-row access, the flat load floor or cargo room. The battery

pack starts the vehicle and powers the electric motors and

several accessories. Depowers if tampered with, for safety

•Navigation system with rearview camera, Bose 5.1 Cabin

Surround Sound System and Hybrid Power Flow Diagram

shows hybrid operation

•XM Satellite Radio, with a wide variety of programming, has

something to excite any driver

•USB port in center console can connect, charge and control

iPods. MP3 players and memory sticks plug in (but cannot be

controlled using the radio buttons)

•Bluetooth phone interface allows the driver to make hands-free

cell phone calls within the vehicle

•Available rear-seat DVD entertainment system includes 8-

inch screen and 2 wireless headphones

•Standard sunroof features express open and close

•12-way power front bucket seats include 4-way power lumbar,

memory for 2 drivers and independent heated seat cushions

and seatbacks

•Standard heated and cooled front seats deliver conditioned air

through perforated surfaces in the bottom and back

•2nd-row 40/20/40 split-folding bench seats hold 3 passengers

and have heated outboard cushions

•3rd-row 50/50 bench seats hold 3 passengers and can be tum-

bled, folded or removed

•Power tilt steering wheel provides precise adjustment at the

touch of a button

•OnStar®includes 1-year Directions & Connections service and

Turn-by-Turn Navigation. OnStar can send navigation destina-

tions to the navigation system for entry on-the-go3

•Patinum Edition Package includes unique front fascia and

grille, interior accents and trim Includes LED Headlights, heated

and cooled cup holders, Dual DVD Head Restraints and power-

retractable assist steps

1. Maximum trailering weight includes driver and one passenger in tow vehicle and all required

trailering equipment. See Owner Manual for more information.

2. Always use safety belts and proper child restraints, even with air bags. Children are safer when

properly secured in a rear seat. See Owner Manual for more safety information.

3. Go to www.onstar.ca for system limitations and details..

Escalade vs. the Competition

BOLD denotes a Cadillac advantage.

2010 Cadillac 2010 2010

Escalade Lincoln Mercedes

Navigator 4WD GL450 AWD

Performance Specifications

Base Engine 6.2L V-8 5.4L V-8 4.6L V-8

Horsepower @ rpm 403 @ 5,700 310 @ 5100 335 @ 6000

Torque (lb.-ft.) 417 @ 4,300 365 @ 3600 339 @ 2 700

Std. Transmission 6-spd. auto 6-spd. auto 7-spd. auto

Drivetrain Front engine/ Front engine/ Front engine/

AWD w/open 4WD/active AWD/active

transfer case transfer case transfer case

Suspension, front Short & long arm, Short & long arm, Double wishbone

torsion bar air air

Suspension, rear 5-link coils multi-link, 5-link coils

stabilizer bar stabilizer bar stabilizer bar

Steering Type Power Speed-sensitive Speed-sensitive

recirculating ball rack & pinion rack & pinion

GVWR (kg/lb.) 3,221/7,101 3,538/7,800 3,150/6,945

Payload (kg/lb.)1612/1,349 783/1,726 576/1,270

Towing capacity2(kg/lb.) 3,674/8,100 3,765/8,300 3,402/7,500

Turning radius (m/ft.) 5.95/19.5 6.2,20.3 6.05,19.8

Fuel tank (L//gal.) 98/21.6 106/23.3 100/21.9

Drag coefficient 0.36 0.41 0.38

Dimensions and Interior Volume in mm/inches unless otherwise indicated

Wheelbase 2,946/116.0 3,023/119.0 3,075/121.1

Curb weight (kg/lb.) 2,609/5,752 2,723/6,003 2,395/5,280

Exterior length 5,144/202.5 5,293/208.4 5,088/200.3

Exterior body width 2,007/79.0 2,002/78.8 1,920/75.6

Exterior height 1,887/74.3 1,989/78.3 1,840/72.4

Front tread 1,732/68.2 1,702/67.0 1,651/65.0

Rear tread 1,702/67.0 1,707/67.2 1,654/65.1

Front legroom 1,049/41.3 1,044/41.1 1,024/40.3

Rear legroom 991/39.0 993/39.1 1,003/39.5

Third row legroom 650/25.6 958/37.7 869/34.2

Front headroom 1,024/40.3 1,003/39.5 1,019/40.1

Rear headroom 996/39.2 1,008/39.7 1,031/40.6

Third row headroom 963/37.9 953/37.5 970/38.2

Front hiproom 1,636/64.4 1,529/60.2 1,419/55.9

Rear hiproom 1,539/60.6 1,521/59.9 1,424/56.0

Third row hiproom 1,539/60.6 1,273/50.1 NA/NA

Front shoulder room 1,659/65.3 1,608/63.3 1,482/58.3

Rear shoulder room 1,656/65.2 1,618/63.7 1,495/58.9

Third row shoulder room 1,567/61.7 1,318/51.9 1,282/50.5

Luggage volume (L/cu.ft.) 479/16.9 518/18.3 200/81

Luggage volume max. (L/cu.ft.) 3,084/108.9 2,925/103.3 2,300/81.0

Passenger volume 4,871/172.0 4,465/158 4,049/158

Seating Capacity 7/8 7/8 7

Vehicle Features

In-Vehicle Communications OnStar NA Tele Aid

Remote vehicle start Std. NA NA

Locking/limited slip differential Std. NA Opt.

Driver Shift Control Std. NA Std.

Adaptive Suspension

Std. NA Opt.

Ride Control Opt. NA Opt.

Heated 2nd row seats Std. Std. Opt.

Blind spot sensor Opt. NA NA

Navigation sytem3Std. Opt. Std.

Power Pedals Std. Std. NA

Wheel size choices 18”/22” 20” 20”

Power liftgate Std. Std. Opt.

Power tilt down mirrors S NA NA

Heavy Duty Battery S NA NA

Powertrain limited Warranty 60/160,000 72/110,000 48/80,000

1 When properly equipped.

2 When properly equipped. Maximum trailer ratings are calculated assuming a properly equipped base vehicle, plus driver.

5 Keys to Learning

Comfort and Convenience

– Available IntelliBeam headlamps

– Available power release 2nd-row seat

– Standard Touch screen DVD-integrated navigation

– Aluminum, wood and leather-trimmed interior

– Tri-zone automatic climate control system

– Bose 5.1 Digital Surround Sound System

– XM Satellite Radio

– Available DVD rear-seat entertainment system

– Remote Vehicle Starter System

– 2nd-row bucket seats or available split bench seat

– 3rd-row 3-passenger removable seat

– Standard heated/cooled front seats, heated 2nd row seats

– Available heated steering wheel

– Rear Parking Assist

– Standard Bluetooth®for phone

– Standard USB port

Power and Performance

–

403-hp 6.2L VVT V8 engine with Active Fuel ManagementTM and

FlexFuel

– 6-speed automatic transmission with Driver Shift Control

– All-wheel drive standard

Ride and Handling

– Road-Sensing suspension

– Automatic rear load leveling

– Available Magnetic Ride Control

– Standard 18-inch and available 22-inch wheels

Quality, Reliability and Durability

– Interior has low gloss surfaces, tight component fits, damped

features and premium materials

– 4-year/80,000-km new vehicle limited warranty

– 5-year/160,000-km powertrain warranty

– Oil life monitor

Safety and Security

– Seat-mounted side-impact, driver and right front passenger

for thorax and pelvic protection and head curtain side-impact

air bags for all rows with rollover sensors3

– Available Side Blind Zone Alert

– StabiliTrak®with Proactive Roll Avoidance

– Electronic immobilizer and content theft-deterrent systems

– High Intensity Discharge headlamps with Twilight Sentinel

– Ladder-type frame

– 5-star frontal and side impact crash test rating (NHTSA U.S.)

Always use safety belts and proper child restraints, even with airbags. Children are safer when properly secured in a

rear seat. Front-seat side-impact airbags help reduce the risk of certain injuries to front-seat occupants in side im-

pacts. See Owner Manual for more safety information.

2010 Escalade

Quick Facts

• Walkaround Summary

• Competitive Comparison

• 5 Keys to Learning

Additional copies can be obtained by printing PDF file from LMS or Global Connect

All information contained in this pocket piece is based on the latest information available as of 12/2009

Cadillac and General Motors of Canada reserve the right to discontinue or change at any time, without

notice, any prices, colours, parts, materials, standard equipment, optional equipment, Marketing Op-

tion Packages, special equipment, specifications and/or body types and models. This material is not

legally approved for use in any advertising. It is intended for use by dealership employees only and

duced by GMPRO for VSSM Product Training.

Up Front

• Bold, powerful front end with chrome grille provides a

distinctive Cadillac appearance

• High Intensity Discharge headlamps provide outstanding road

illumination

• Twilight Sentinel provides automatic headlamp activation with

adjustable delay

• Available IntelliBeam automatically switches the headlamps

from high beam to low beam and back again when taillamps or

oncoming headlamps are detected.

• 5-star driver and front-passenger front and side NCAP safety

ratings by NHTSA are the highest ratings possible

Under the Hood

• Vortec 6.2L V8 Flex Fuel engine with VVT has 403 hp and 417

lb.-ft. of torque

• Active Fuel Management®switches from 8- to 4-cylinder oper-

ation when appropriate, providing better fuel efficiency

• Variable Valve Timing (VVT) optimizes power and efficiency

at all engine speeds

• FlexFuel capability allows the use of ethanol/gasoline blends

• Heavy-duty 6L80-E 6-speed automatic transmission reliably

handles high power output for demanding conditions.

Driver Shift Control with tap up/tap down shifting adds

control and performance. Automatic grade braking downshifts

when the driver applies the brake on steep grades to provide

engine braking. Tow/Haul mode provides enhanced trailering

performance

• All-wheel drive is always engaged providing superior low-

speed drivability and fuel efficiency

• 2010 Fuel consumption ratings are 15.3/10.1L/100km (18/28

mpg) city/highway

• 5-year/160,000-km powertrain warranty with Premium Road-

side Assistance provides peace of mind

Passenger Side

• Chrome fender portholes are a bold styling cue

• 18-inch, 7-spoke polished aluminum wheels provide a

striking appearance.

• Available 22-inch, 7-spoke chromed aluminum wheels are

the largest in the segment.

• Tire Pressure Monitoring System displays individual tire pres-

sures in the Driver Information Centre for safety

• Assist steps with chrome accent facilitate entry/exit. Power-

Retractable assist steps are available.

• Chrome luggage rack with chrome accent for cargo carrying

1. Maximum trailering weight includes driver and one passenger in tow vehicle and all required trailering equipment.

See Owner Manual for more information.

At the Rear

• LED taillamps and side markers provide a distinct appearance

and illuminate quicker than bulbs for safety

• Power liftgate with liftglass works at the touch of a button for

convenience. Includes pinch protection for safety. Electronic

touchpad liftgate/liftglass controls ease operation. Defogger

and wiper/washer help improve visibility

• Ultrasonic Rear Parking Assist provides visual and audio

warnings to help identify objects behind Escalade

• Rearview camera allows the driver to view objects behind the

vehicle on the navigation screen while reversing. Available

• Heavy-duty trailering equipment tows up to 3674 (8100 lb.)

on Escalade. Escalade ESV tows up to 3,538 kg (7,800 lb.).

Cover conceals receiver hitch when not in use

• Locking rear differential provides maximum traction

• Up to 3,084 litres (108.9 cu. ft) of cargo volume on Escalade

Driver Side

• StabiliTrak®with Roll-Over Mitigation helps maintain stability

when system detects understeer or oversteer. Roll-Over

Mitigation determines whether rollover is imminent and

engages StabiliTrak

• Short- and long-arm independent front suspension uses coil-

over-shock design a smooth ride

• 5-link coil spring rear suspension features standard rear air

load-leveling

• Road-Sensing computer-controlled suspension adjusts shock

valving to provide a smooth, controlled ride

• Available Magnetic Ride Control uses magnetic damper fluid.

Real-time damping produces exceptional ride and handling

• Four-wheel antilock disc brakes with dynamic brake propor-

tioning, large rotors and stiff calipers contribute to braking per-

formance and safety

• Remote Vehicle Starter System allows the vehicle to be started

and activate climate controls from up to 60 metres (200 ft.)

• Outside mirrors feature power folding, power adjustable,

heated, driver’s side auto-dimming, turn signal indicators,

ground illumination and curb-tilt

• Available Side Blind Zone Alert is designed to help provide

drivers more time to react to obstacles that may be difficult to

see in the side mirror. Uses a visual alert in the sideview mirror

Interior

• Platinum Edition provides a host of premium luxury features

including unique exterior and interior accents, heated and

cooled cup holders, rear seat entertainment system, power-re-

tractable assist steps, 22” chromed aluminum Wheels, Side

Blind Zone Alert, IntelliBeam, heated steering wheel, Power re-

lease 2nd row seat, Power Sunroof and Magnetic Ride Control

• Tri-zone automatic climate control provides comfort for all

passengers

• Dual-stage frontal air bags with Passenger Sensing System

and 360-degree sensing, head curtain side air bags with

rollover sensor and front seat-mounted side-impact thorax air

bags2protect occupants in certain side collisions

• Touch-screen DVD navigation system with 8-inch screen for

convenience. Rear audio controls and auxiliary input jack are

also standard

• Bose 5.1 digital surround sound system iincludes 10 speakers

including subwoofer

• XM Satellite Radio, with a wide variety of programming, has

something to excite any driver

• Bluetooth phone interface allows the driver to make hands-free

cell phone calls within the vehicle. Requires compatible phone

• USB port in centre console can connect, charge and control

iPods using the radio. Can connect other MP3 players and

memory sticks (but cannot control through the radio controls)

• Available rear-seat DVD entertainment system includes 8-

inch screen and 2 wireless headphones. ESV includes two

screens and 4 wireless headphones

• Available sunroof features express open and close

• 14-way power front bucket seats include 4-way power lumbar,

memory for 2 drivers, and independent heated seat cushions

and seatbacks

• Standard Heated and cooled front seats deliver conditioned air

through perforated surfaces in the bottom and back. 2nd row

seats are heated only

• Heated and cooled cupholders keep beverages at their desired

temperature (Platinum Edition only)

• 2nd-row heated bucket seats recline, fold and have folding

armrests for comfort. Available 40/20/40 split-folding bench

seats hold 3 passengers and has heated outboard cushions

• Available Power release 2nd-row seats fold down and tumble

seats at the touch of a button. Seats must be put up manually.

• 3rd-row 50/50 bench seats hold 3 passengers and can be tum-

bled, folded or removed.

• Power tilt steering wheel provides precise adjustment at the

touch of a button

• Available heated steering wheel is available for comfort in

cold weather.

• Power pedals feature adjustable brake and accelerator pedals

with memory. Standard

• OnStar®includes 1-year Directions & Connections service

and Turn-by-Turn Navigation. OnStar can send navigation

destinations to the navigation system for entry on-the-go4

2. Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in

a rear seat. See Owner Manual for more safety information.

3. Required XM Radio monthly subscriptions sold separately after trial period.

4. OnStar® subscription. 1-year Premium Service Agreement provided. Go to www.onstar.ca for system limitations

and details.

SRX vs. the Competition

BOLD denotes an SRX advantage.

2010 Cadillac 2010 Lexus

SRX AWD RX 3 0 AWD

Pe fo mance Specifications

Engine 3.0L DOHC V6 3.5L DOHC V6

Horsepower @ rpm 26 @ 69 0 275 @ 6200

Torque (lb.-ft.) @ rpm 223 @ 5100 257 @ 4700

Engine (A) 2. L DOHC Turbo V6 —

Horsepower @ rpm 300 @ 5500

Torque (lb.-ft.) @ rpm 295 @ 1 50

Fuel requirement Regular Premium

Transmission 6-speed auto. 6-speed auto

Limited-slip rear differential A (eLSD) —

Fuel consumption, city/hwy

L/100km 11. /8.0 11.6/ .2

mpg 2 /3 24/34

Drivetrain FWD; AWD (A) AWD

Front suspension Strut-type MacPherson strut

Rear suspension Linked H-arm Double-wishbone

Brakes, front/rear 4-wheel vented Front vented disc/

disc w/ ABS rear solid disc

Panic Brake Asist w/ ABS, BA

Wheels 1 ", 20" 1 ", 19

Towing Capacity (kg/lb.) 1,5 /3,500 1,5 /3500

Turning circle (m/ft.) 12.2/40.3 11.4/37.4

Dimensions and Inte io Volume in mm/inches unless otherwise indicated

Wheelbase 2,807/110. 2,740/107.9

Length 4, 34/190.3 4,770/1 7.

Width 1,910/75.2 1, 5/74.2

Height 1,669/65.7 1,720/67.7

Track, front 1,617/63.7 1,630/64.2

Track, rear 1,610/63.4 1,620/63.

Curb weight, (kg/lbs.) 1,907/4204 1,970/4510

Head room, front/ 1,009/39.7 992/39.1

Head room, rear 976/38.4 95 /37.7

Leg room, front 1,047/41.2 1,096/43.1

Leg room, rear 929/36.6 934/36.

Shoulder room, front 1,481/ 8.3 1,473/57.9

Shoulder room, rear 1,430/56.2 1,462/57.5

Hip room, front 1,40 /55.4 1,412/55.6

Hip room, rear 1,391/ 4.7 1,3 4/54.5

Cargo capacity, . (L/cu. ft.) 39/29.6 1,132/40.0

Cargo capacity, max(L/cu. ft.) 1,733/61.2 2,273/ 0.3

Vehicle Featu es

Climate controls Dual-zone; Tri-zone (A) Dual-zone

Remote Vehicle Starter System A —

Satellite radio S S

Premium audio S S

Navigation system S ; A (In-dash)

(OnStar Directions & Connections)

A (In-dash — pop-up)

Bluetooth S S

USB port S A

Adaptive Forward Lighting A A

Memory personlization (seat/mirrors) S A

Heated front seats S A

Auto-dimming Outside Rearview mirrors S A

Power liftgate A A

Power-adjustable pedals A —

Ultrasonic Front & Rear Parking Assist A A

Rearview camera A A

Powertrain limited warranty 60/160,000 72/110,000

S = Standard A = Available — = Not available

5 Keys to Lea ning

POWER AND PERFORMANCE

• 3.0L VVT DOHC V6 DI (Direct Injection)

• 2. L SFI V6 Turbocharged (available)

• 6-speed transmissions with Driver Shift Control

• 4-wheel vented disc brakes with ABS, Ready Brake Alert and

Panic Brake Assist

• Advanced AWD with eLSD (Electronic Limited Slip Differential)

RIDE AND HANDLING

• 4-wheel independent suspension, MacPherson strut in the

front and linked H-arm in the rear

• Continuously variable real-time damping suspension (available)

• ZF Premium variable-effort steering gear (available)

COMFORT AND CONVENIENCE

• Cut, sewn and wrapped interior surfaces

• Premium Sapele wood trim

• Full-colour Driver Information Centre (DIC)

• Tri-zone HVAC (available)

• Pop-up ” touch-screen navigation (available)

• 40GB hard drive (available); 10GB available for music

• Adaptive Remote Start (available)

• -way power front-driver seat

• AM/FM/CD/MP3 audio with voice recognition

• Bose -speaker Centerpoint surround sound system

• USB port

• Rear Vision Camera (available)

• Keyless Access (available)

• Tire Pressure Monitoring System

SAFETY AND SECURITY

• Dual-stage frontal air bags

• Driver and front passenger seat-mounted side-impact air bags

• StabiliTrak Stability Control System

• Roll-Over Mitigation

• Head-curtain side air bags

• OnStar Directions & Connections

• Rear safety belt reminder

QUALITY, RELIABILITY AND DURABILITY

• Library quiet with damping materials and acoustically

laminated windshield and front side glass

• Extensive use of high-strength steel

• Direct Injection V6 increases power and improves fuel

efficiency

2010 SRX

Quick Facts

• Walkaround Summary

• Competitive Comparison

• 5 Keys to Learning

Additional copies can be obtained by printing PDF file from LMS or Global Connect

All information contained in this pocket piece is based on the latest information available as of

07/2009. Cadillac and General Motors of Canada reserve the right to discontinue or change at any

time, without notice, any prices, colours, parts, materials, standard equipment, optional equipment,

Marketing Option Packages, special equipment, specifications and/or body types and models.

This material is not legally approved for use in any advertising. It is intended for use by dealership

General Motors. Produced by GMPRO for VSSM Product Training.

Up F ont

•Dramatic presence provides a striking, bold look for this mid-

size luxury crossover.

•Fog lamps for added vision and appearance. (Available)

•Vertical headlamps with light pipe technology have a jewel-

like appearance.

•HID headlamps with washers provide optimum night time visi-

bility. (Available)

•Adaptive Forward Lighting swivels the headlamps in sync with

vehicle steering and speed and automatically levels the head-

lamps to maximize effectiveness. (Available)

Unde the Hood

•3.0L VVT DOHC V6 SIDI engine produces 265 hp and 223 lb.-

ft. of torque.

•2.8L SFI V6 Turbocharged engine produces 300 hp and 295

lb.-ft. of torque (available).

•Hydra-Matic 6T70 6-speed transmission standard on 3.0L V6.

•Aisin Warner AF40 6-speed transmission standard on 2. L

turbo V6.

•Driver Shift Control with tap-up/tap-down is standard on both

engines and offers a clutchless manual shift mode for a more

engaged driving experience.

•Direct Injection on the 3.0L V6 introduces fuel directly into

the cylinder where it mixes with air versus the intake port on

typical engines. The result is higher horsepower and better

fuel efficiency.

•ECO Mode standard on the 2. L engine alters transmission

shift points to maximize fuel economy. Push the ECO button to

turn it on or off.

•Long-life components including spark plugs, engine coolant,

exhaust system and transmission fluid, help reduce the need

for maintenance.

Passenge Side

• All-new luxury crossover architecture provides a Body Frame

Integral (BFI) design with extensive use of high strength steel

for cabin safety and improved vehicle dynamics. This provides

confident, inspiring and predictable body motion with precise

steering and smooth confortable feel on the road.

•18" painted cast aluminum wheels are standard with bright

machined finish available.

•20" wheels either Sterling Silver premium painted or Chrome-

Tech are available.

•Chrome fender treatment with a side marker lamp.

•UltraView Sunroof covers more than 70% of vehicle’s roof

area. (Available)

At the Rea

•Integrated spoiler on the rear edge of the roof extends the line

by approximately 100 mm (4") and improves aerodynamics.

•Vertical tail lamps extend past the liftgate surface giving the

SRX the look of contemporary tail fins.

•Power Liftgate with Memory Height can be raised or lowered

by a simple push of a button. The liftgate can be programmed

to open to any height making it adaptable to the size constraints

of any garage or the height of the person. (Available)

•Pass-through exhaust rear fascia gives the SRX a more

finished look.

•Up to 1, 88 kg (3 00-lb.) towing capacity (available).

•SRX can be flat-towed (dinghy or dolly).

D ive Side

•StabiliTrak Stability Control System helps driver maintain con-

trol during evasive manoeuvers.

•Roll-Over Mitigation senses potential for vehicle rollover and

applies brake pressure to outside front wheel to manage lateral

pressure and reduce tendency for vehicle rollover.

•FE2 Touring suspension is standard on all FWD and AWD

Luxury Collection.

•FE3 Sport suspension is included on AWD configurations of

the Performance and Premium Collections.

•Continuously variable real-time damping suspension, stan-

dard on FE3, calms vehicle body movement, reduces roll, pitch

and vertical motion.

•Advanced All-Wheel Drive delivers power to the front wheels

during normal driving conditions and to the rear as well when

slippage is detected (available).

•Electronic Limited-Slip Differential (eLSD) is standard on the

AWD system and can transfer up to 5% torque side-to-side

along the rear axle which helps in slippery conditions and in de-

manding performance manoeuvers.

•4-wheel vented disc brakes with ABS, Ready Brake Alert, Panic

Brake Assist and Hill Start Assist.

Inte io

•Available Keyless Access lets you unlock and enter the vehicle

with a personalized fob close-by.

•Push-Button Start is standard and allows starting and stopping

of the engine with a press of an ignition button.

•Adaptive Remote Start allows you to start SRX from nearly

100 metres (330') away and heat or cool the interior.

•Dual-stage frontal air bags deploy at one of two inflation levels

depending on the severity of a crash.

•Driver and front passenger seat-mounted side-impact air

bags help protect occupants.

•Head-curtain side-impact air bags help protect outboard occu-

pants from certain side collisions and prevents passenger ejec-

tion in the event of a rollover.

•Centre Stack is designed with an attractive layout and a metal-

lic finish surround keeping the IP lower, sweeping forward and

away from front occupants.

•Hand-cut, sewn and wrapped surfaces provide a three-dimen-

sional low gloss look with French seam stitching throughout.

•Unique Driver Information Centre (DIC) is a 2-1/2" round high-

resolution colour graphic display placed in the centre of the

instrument cluster providing warnings and messages while

serving as an additional screen for the vehicle’s navigation

system, OnStar Turn-by-Turn and XM NavTraffic.

•8" high-resolution pop-up touch-screen navigation can

operate by voice recognition and provides comprehensive

guidance (available).

•8-speaker Bose Centerpoint surround sound system is

standard.

•10-speaker Bose .1 surround sound system is available.

•Auxiliary audio input and USB port for MP3 playback from

iPod (standard).

•40GB hard drive allows you to load a larger library of music

(10GB) and also stores all navigation map data (available).

•Timeshift is available on uplevel radios and allows the user to

pause, rewind and play AM, FM and XM radio programming.

•Dual-zone HVAC controls standard and tri-zone available.

•Power-adjustable pedals adjust to drivers of different statures

(available).

•OnStar with one year of Directions & Connections provides ac-

cess to emergency and convenience services. Includes Turn-

by-Turn Navigation, eNav and Destination Download (standard).

Avalanche vs. the Competition

BOLD denotes a Chevrolet advantage.

2010 2010 2010

Avalanche LT Ford F-150 Dodge Ram 1500

1500 4WD Super Cab 4WD Crew Cab 4WD

Performance Specifications

Base Engine 5.3L V8 5.4L V8 5.7L V-8

Horsepower @ rpm 320 @ 5400 320 @ 5,200 390 @ 5,600

Torque (lb.-ft.) @ rpm 335 @ 4000 390 @ 3,500 407 @ 4,000

Available Engine 6.2L V8

Horsepower @ rpm 395 @ 5600

Torque (lb.-ft.) @ rpm 417 @ 4300

Std. Transmission 6-speed auto. 6-speed auto. 5-speed auto.

Drivetrain Front engine/ Front engine/ Front engine/

Auto 4WD 4WD 4WD (auto. opt.)

Suspension, front Ind. SLA Dbl. Wishbone Ind. SLA

Suspension, rear 5-link coil leaf Multileaf

GVWR (kg/lb.)13,266/7,200 3,266/7,200 3,084/6,700

Payload (kg/lb.)2606/1,336 685/1,510 526/1,160

Towing capacity (kg/lb.)33,674/8,100 4,354/9,600 2,812/6,200

Turning radius (m/ft.) 6.55/21.5 7.16/23.5 6.85/22.5

Ground clearance 230.7/9.1 229/9.0 206/8.1

Fuel tank (L/gal.) 117/25.8 136/29.9 98/21.5

L/100km (city/hwy) 14.4/9.6 15.6/11.2 16.2/10.8

mpg (city/hwy) 20/29 18/25 17/26

Dimensions and Interior Volume in mm/inches unless otherwise indicated

Wheelbase 3,302/130.0 3,683/145.0 3,556/140.0

Base curb weight (kg/lb.) 2,569/5,664 2,511/5,536 2,546/5,613

Exterior length 5,621/221.3 5,885/231.7 5,779/227.5

Exterior body width 2,009/79.1 2,004/78.9 2,017/79.4

Exterior height 1,946/76.6 1,941/76.4 1,900/74.8

Front tread 1,732/68.2 1,702/67.0 1,730/68.1

Rear tread 1,702/67.0 1,702/67.0 1,715/67.5

Front legroom 1,049/41.3 1,052/41.4 1,041/41.0

Rear legroom 993/39.1 1,105/43.5 1,001/39.4

Front headroom 1,044/41.1 1,041/41.0 1,041/41.0

Rear headroom 1,016/40.0 1,024/40.3 1,013/39.9

Front hiproom 1,636/64.4 1,537/60.5 1,615/63.6

Rear hiproom 1,582/62.3 1,641/64.6 1,669/65.7

Front shoulder room 1,659/65.3 1,674/65.9 1,676/66.0

Rear shoulder room 1,656/65.2 1,666/65.6 1,669/65.7

Exterior box length41,608/63.3 1,676/66.0 1,928/75.9

Pickup box minimum width 1,270/50.0 1,270/50.0 1,295/51.0

Pickup box depth 572/22.5 569/22.4 508/20.0

Luggage volume max. (L/cu.ft.) 2,859/10141,631/57.6 1,427/50.3

Seating capacity 5/6 5/6 6/5

Vehicle Features

MidgateTM Design Std. NA NA

OnStar Std. NA NA

Rear differential Locking Std. Ltd. Slip Std. Ltd. Slip Opt.

Ride Control Opt. NA NA

Electronic stability control Stabilitrak Std. Std.

Automatic level control Opt. NA NA

Lockable Top Box Storage Std. NA NA

Rigid 3-piece cargo cover Std. NA NA

Remote Vehicle Starter Std. NA Std.

Roof rack Opt. NA NA

Rear seat audio controls Std. NA NA

12V DC Outlets 53 3

Powertrain Warranty (yr/km) 5/160,000 5/100,000 5/100,000

Roadside Assistance (yr/km) 5/160,000 5/100,000 5/100,000

1. Gross Vehicle Weight Rating. When properly equipped; includes weight of vehicle, passengers, cargo and equipment.

2. Payload capacity includes weight of driver, passengers, optional equipment and cargo.

3. Maximum trailer ratings assume a properly equipped base vehicle, plus driver. See Owner Manual.

4. With Midgate up/down.

5. Excludes other GM products.

5 Keys to Learning

Design and Styling

– Available Z71 Off-Road Package

– Available 17-, 18- or 20-inch wheels

Performance and Handling

– Engines range from 320 hp to 395 hp

– 6-speed automatic transmission with Tow/Haul mode

– Available Autoride suspension is a segment exclusive

– Towing up to 3,674 kg (8,100 lb)3

– Available integrated brake controller

– Active Fuel ManagementTM on 5.3L engine helps save fuel

– FlexFuel capability on both engines accepts E85 ethanol

– Available AutoTrac 4WD system

Comfort and Convenience

– Full-feature bucket seats on LTZ have leather seating surfaces,

heated/cooled surfaces and 12-way power with power lumbar

– GM-exclusive Midgate™ makes Avalanche the only vehicle that

can reconfigure from 6-passenger seating to a vehicle with 3-

passenger seating and an 2.48 metre (8’2”) bed with a secure,

protected cargo box5

– Composite cargo area and Midgate are durable and scratch

and ding-resistant, and they cannot corrode

– Unsurpassed cargo box versatility5

– Standard MP3 playback capability, USB port, XM Satellite

Radio and auxiliary input jack

– Available Bose, DVD navigation with voice prompt and DVD

rear seat entertainment systems

– Remote Vehicle Starter System. Standard

– Bluetooth phone connectivity. Standard

Quality, Reliability and Durability

– 5-year/160,000-km powertrain warranty

– Oil Life Monitoring System and long-life fluids

Safety and Security

– Five-star U.S. government frontal crash test rating

– StabiliTrak with Proactive Roll Avoidance

– Standard OnStar®is not available on any competitor

– Standard side curtain air bags with rollover sensors

– Standard front seat-mounted side impact air bags

2010 Avalanche

Quick Facts

• Walkaround Summary

• Competitive Comparison

• 5 Keys to Learning

Additional copies can be obtained by printing PDF file from GMtraining.com

All information contained in this pocket piece is based on the latest information available as of

11/2009. Chevrolet and General Motors of Canada reserve the right to discontinue or change at any

time, without notice, any prices, colours, parts, materials, standard equipment, optional equipment,

Marketing Option Packages, special equipment, specifications and/or body types and models. This

material is not legally approved for use in any advertising. It is intended for use by dealership em-

Motors. Produced by GMPRO for VSSM Product Training.

LARIAT LARAMIE

Up Front

•5-star frontal crash test ratings by the National Highway Traffic

Safety Administration (U.S.) — the highest ratings possible

•Daytime Running Lamps with Automatic Lamp Control provide

safety and convenience

•Front recovery hooks provide a secure attachment for freeing

stuck vehicles. Standard

•Aerodynamic shape contributes to low wind noise and high fuel

efficiency

•Flat blade wipers offer low wind noise and great performance,

especially at higher speeds and in winter conditions

Under the Hood

•Active Fuel ManagementTM switches from 8- to 4-cylinder opera-

tion when appropriate, saving fuel on 5.3L engine

•Vortec 5.3L V8 has 315 hp and 338 lb.-ft. of torque . Energuide

estimated city/highway fuel consumption rating is 14.4/9.6 L/100

km (20/29 mpg).

•Vortec 6.2L V8 has 395 hp and 417 lb.-ft. of torque and Variable

Valve Timing (VVT) for performance. Available on 2WD or 4WD

LT (1SC/1SD) and 4WD LTZ

•E85 capability on both engines allows the use of ethanol/gasoline

blends

•6-speed automatic transmission with Tow/Haul mode provides

efficiency, smooth shifts and durability

•Autotrac transfer case on 4WD models is a convenient, on-de-

mand automatic 4WD system. Includes Auto 4WD mode and

Neutral mode for dinghy-towing. Included with 6.2L engine.

•Oil Life Monitoring System informs driver when to change the

engine oil

•5-year/160,000-km Limited Powertrain Warranty includes

Roadside Assistance and Courtesy Transportation.

Passenger Side

•Z71 Off-Road Package includes specially tuned shocks and

springs, skid plate package, 18-inch wheels with on/off-road

tires, large wheel flares, skid plate package, tubular assist steps,

AutoTrac (4WD) and numerous exterior/interior design enhance-

ments. Available

•Fully boxed frame offers strength and durability

•Standard 17-inch, available 18-inch (Z71 only) and available

20-inch wheels add to appearance. Polished aluminum standard

on LTZ availableLT, 20-inch chrome-clad wheels available LTZ

At the Rear

•The Midgate™ is an integral part of the Ultimate Utility Bed,

made of durable PRO-TEC®composite material.

–

Separates the rear seat from the cargo box and may be lowered

into the cabin when more cargo room is needed.

–

When needed, lowering the Midgate allows use of Avalanche’s

full 2.4 metre (8 ft.) cargo box length.

–

Owners can transport items like 1.2x2.4 metre (4- x 8-ft.) sheets

of building material with the tailgate closed and cargo safely

secured

•Locking tailgate helps to deter theft. When lowered, it adds

60cm (25 inches) to the load floor length

•Rigid, 3-piece cargo cover adds to adaptability and security. The

cover can be removed and stowed on board

•Water Management System is designed to move water away

from cargo

•Cargo bed provides a high side-wall height and includes

–

two-tier loading, allowing two layers of cargo to be transported

while fully encased and weather-protected,

–

cargo bed divider pockets that prevent cargo from sliding back

and forth, and

–

lockable top-box storage units with driver-side lamp for secure

storage

•Removable rubber cargo mat protects items from marring and

scratching

•Ultrasonic Rear Parking Assist helps the driver park the vehicle

when in Reverse (available)

•Rearview camera provides a view to the rear when backing up

(available; required with the navigation system)

•Locking rear differential maintains wheel traction in low-speed

situations. Standard

•Standard trailering equipment package1permits towing large

trailers

•Heavy Duty Cooling Package provides increased trailering capa-

bilities. Includes transmission oil cooler and engine oil coolers.

Requires 5.3L engine. Up to 3,674 kg (8,100 lb.) on 2WD and up

to 3,538 kg (7,800 lb.) on 4WD1

Driver Side

•StabiliTrak with Proactive Roll Avoidance helps maintain stabil-

ity when system detects oversteer or understeer. Proactive Roll

Avoidance determines whether rollover is imminent and engages

stability control system

•Short- and long-arm independent front suspension uses coil-

over- shock design with monotube dampers for a smooth ride

•5-link coil spring rear suspension provides a smooth ride

•Autoride suspension is a semi-active, two-position damping con-

trol system that responds in real time to road conditions. In-

cludes rear load-leveling. Available LT (1SC/1SD); standard LTZ

•Four-wheel antilock disc brakes with dynamic rear proportioning

have large, vented rotors for confident braking

•Tire Pressure Monitoring System informs the driver of a low tire

•Remote Vehicle Starter System allows the vehicle to be started

from up to 60 metres (200 ft) away

•Available mirror features include heated power glass, power

fold, memory and turn signal indicators

Interior

•LTZ enhancements include new bodyside mouldings, embossed

door sill plates, Centre Channel Bose Sound System and

heated/cooled seats with Perforated Leather seating surfaces

•Z71 Off-Road Package includes metallic interior accents and

badging (available)

•Dual-zone manual and available automatic climate control

systems provide comfort and convenience

•Dual-stage driver and passenger front air bags with Passenger

Sensing System2provide occupant protection

•Seat-mounted side-impact front air bags2for thorax and pelvic

protection

•Head curtain side-impact air bags with rollover sensors2are

designed to help protect the head of outboard occupants in both

rows during certain side collisions and rollovers

•Standard audio features include single CD with MP3 capability,

USB port (for iPodTM/MP3) XM Radio3and auxiliary input jack

•Available audio features include DVD navigation system with

voice prompts and OnStar Destination Download; Bose Center-

point Surround Sound 10-speaker system and rear seat controls

•Rear seat DVD entertainment system includes 203mm (8”)

screen and 2 wireless headphones (available)

•40/20/40 split-bench cloth front seat on LS (available 1LT) in-

cludes folding storage armrest, 6-way power driver’s seat and

lockable bottom cushion storage with power outlet

•Bucket seats on LT include 6-way power driver and passenger

seat and a large centre console

•Full-feature bucket seats on LTZ have leather seating surfaces,

heated/cooled surfaces, and 12-way power with power lumbar

(available)

•60/40 split-folding rear seat accommodates people, cargo or

both

•Driver Information Centre provides warning messages and per-

sonalisation features. Includes outside temperature and compass

display.

•Power adjustable pedals provide comfort for drivers of different

statures (available)

•OnStar4includes one year of Safe & Sound service on LS. In-

cludes one year of Directiions and Connections Plan with Turn-

by-Turn Navigation LT and LTZ

•Integrated trailer brake controller provides maximum trailer-

braking control with full vehicle integration. Available

•Bluetooth for Phone allows hands-free communication with com-

patible phones. Standard

1. Maximum trailer ratings are calculated assuming a properly equipped base vehicle, plus driver. See the Avalanche

Owner Manual for details.

2. Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a

rear seat. See Owner Manual for more information.

3. Available XM Radio is available only in 10 Canadian provinces and the 48 contiguous United states.

4. Visit www.onstar.ca for system limitations and details. Turn-By-Turn Navigation availability impacted by some geo-

graphic/cellar limitations, advisor assisted routing available.

Other manuals for 2010 Enclave

This manual suits for next models

Table of contents

Other Buick Automobile manuals

Buick

Buick Verano User manual

Buick

Buick 2010 Lucerne User manual

Buick

Buick 1997 Skylark User manual

Buick

Buick 2010 Enclave User manual

Buick

Buick 2010 Lacrosse User manual

Buick

Buick Enclave 2012 User manual

Buick

Buick 1994 Century User manual

Buick

Buick 1998 Skylark User manual

Buick

Buick 2005 LeSabre User manual

Buick

Buick 2011 Lucerne User manual

Buick

Buick 2014 Encore Car User manual

Buick

Buick 2005 Terraza User manual

Buick

Buick 1997 Regal Assembly instructions

Buick

Buick 2002 Rendezvous User manual

Buick

Buick Rainer 2007 Assembly instructions

Buick

Buick 2005 LeSabre Parts list manual

Buick

Buick 2010 Lacrosse User manual

Buick

Buick 2003 LeSabre User manual

Buick

Buick Envision 2017 User manual

Buick

Buick ENCORE 2019 Assembly instructions

Buick

Buick Encore 2013 User manual

Buick

Buick PARKAVE GTK 2004 Assembly instructions

Buick

Buick 1993 Century User manual

Buick

Buick 2014 Regal Infotainment System User manual

Popular Automobile manuals by other brands

Scion

Scion 2010 xB Warranty & maintenance guide

Chevrolet

Chevrolet 2013 Impala owner's manual

GMC

GMC 2002 Safari owner's manual

Mercury

Mercury 2003 Mountaineer owner's guide

Mahindra

Mahindra THAR CRDe 2015 owner's manual

GMC

GMC SAVANA - BROCHURE 2010 brochure

Vaz

Vaz Lada Niva 1600 Driver manual

Porsche

Porsche BOXTER - Technical manual

Toyota

Toyota Land Cruiser Prado owner's manual

Datsun

Datsun 1977 280Z Service manual

Mazda

Mazda mx-5 2016 Shop Manual

Fiat

Fiat 2015 500 Abarth user guide

Jeep

Jeep Cherokee 1988 quick start guide

Ferrari

Ferrari 2003 Challenge Stradale owner's manual

TATA Motors

TATA Motors Indigo Marina Owner's manual & service book

Toyota

Toyota RAV4 EV 2013 manual

Kia

Kia Cadenza owner's manual

Chevrolet

Chevrolet 2013 Spark owner's manual

Buick 2010 Enclave Operator's manual

Popular Automobile manuals by other brands
