Bulldog Security DELUXE 500 User manual

. .

. .
WARRANTY
Bulldog Warranty Information
All Bulldog models have a Limited Lifetime Warranty on the
main control module.
All parts excluding the control module have a two year
warranty against defects in workmanship, This includes shock
sensors, remote transmitters and sirens. The control module
will be repaired or replaced at our discretion for up to a 2
month period at no charge. After 2 months a $30.00 fee
will be charged for repair or replacement of the control
module.
Removal and reinstallation charges are not the responsibility
of JBS Technologies, LLC the manufacturer of Bulldog Security.
Warranty registration must be completed within 4 days of
the original date of purchase. Registration can be mailed in
or performed on line at www.bulldogsecurity.com. JBS
Technologies makes no warranty against the theft of a vehicle
or its contents. This warranty only extends to the original
system purchaser in the vehicle it was originally installed in.
Limitation of Remedies
The purchasers remedy is limited to the repair or replacement
of the unit and in no event shall exceed the purchase price.
Incidental, consequential and or indirect damages are expressly
disclaimed. No person or entity is authorized to alter or amend
this limited lifetime warranty.
2

. .
3
TABLE OF CONTENTS
Important Notice...................................................................4
A. REMOTE TRANSMITTER OPERATION.....................................5
B. TWO-WAY TRANSEIVER REMOTE CONTRO OPERATION .........6
C. ED DISP AY CHART..........................................................6
D. CHIRP INDICATOR.............................................................6
E. PARKING IGHT INDICATOR DISP AY...................................6
F. A ARM OPERATING CONDITION ..........................................7
G. ACTIVE ARMING................................................................7
H. SI ENT ARMING / DISARMING ............................................8
I. PASSIVE STARTER DISAB E................................................8
J. PASSIVE ARMING ..............................................................8
K. ACTIVE DISARMING...........................................................9
. DISARMING WITHOUT A TRANSMITTER................................9
M. VA ET MODE................................................................9-10
N. CAR FINDER ...................................................................10
O. PANIC MODE...................................................................11
P. SYSTEM STATUS CHECK ...................................................11
Q. DOME IGHT SUPERVISION ..............................................11
R. IGNITION CONTRO ED DOOR OCKS................................11
S. TRUNK RE EASE..............................................................12
T. CHANNE 4 TIMER OUTPUT...............................................12
U. CHANNE 5 TIMER OUTPUT...............................................12
V. CHANNE 6 TIMER OUTPUT ..........................................12-13
A. TO REMOTE START THE VEHIC E .......................................14
B. ENGINE START MEMORIZING FOR MANUA TRANSMISIONS..15
C. OPERATING THE VEHIC E WHI E IN REMOTE START MODE ...15
D. PIT STOP FEATURE ..........................................................16
E. TURBO MODE..................................................................16
F. TIMER/TEMPERATURE START........................................16-18
G. INTERIOR TEMPERATURE MONITOR ...................................18
H. HOW TO TURN OFF THE REMOTE STARTER..........................18
I. SHUT-DOWN INPUTS .......................................................19
J . DISAB ING THE REMOTE STARTER ....................................19
K. BATTERY REP ACEMENT ...................................................20
. REMOTE ICON DESCRIPTION CHART ...........................20-21
M. PROGRAMMING THE REMOTE TRANSMITTER ................21-26
D500OM 6/04

. .
4
WARNINGS:
As with any product that performs automatic functions, there are certain
safety precautions that you must
practice and be aware of.
1. Keep all transmitters out of the reach of children
2. Do not leave anyone in the vehicle while running in remote control mode.
3. otify servicing personnel that the vehicle can be remote started.
4. Do not start the vehicle by remote while the vehicle is in an enclosed
area or garage.
5. Always apply the parking brake and lock the vehicle before exiting.
6. The use and operations of this system is the sole responsibility of the
operator.
7. Some areas may have local ordinances that prohibit leaving a vehicle
running on public streets.
IMPORTANT NOTICE

. .
5
A. REMOTE TRANSMITTER OPERATION:
Transmitter
Button System Function or Feature Remark
Lock Doors & Arm the Security System
Car Locator Works when arme only
(3 sec.) Panic function Press an hol for 3 sec.
+ Silent Arming / Disarming Ign. in the "Off" position.
Unlock Doors & Disarm System
- Two Steps Door Unlock & Disarm System Press twice within 3 sec.
(2 sec.) Trunk elease (Channel 3) Press an hol for 2 sec.
- Passive Arming By-pass While system is isarme .
- - emote Control Entry/Exit Valet Mode While system is isarme ,
Press within 3 secon s
- Activate or Turn Off The emote Start Press twice within 3 sec.
+ Channel # 4 Timer Output
+ Channel # 5 Timer Output
+ Channel # 6 Timer Output
Switching code for 2nd Car Operation For regular remote trans.
OPERATION

. .
6
OPERATION
B. TWO-WAY LCD REMOTE CONTROL TRANSCEIVER OPERATION:
Transceiver
Butt n System Functi n Remark
SET- SET- (C) Systems Status Check Press within 3 sec.
SET- ( ) Monitor Indoor Temperature Press within 3 sec.
SET- ( ) Daily Timer Start Press within 3 sec.
SET (1 sec. LCD screen lamp turns on for 5 seconds. Press and h ld f r 1 sec.
SET-SET- SET Clear the Flash Icon and Melody Sound Press within 3 sec.
on the LCD Screen Transmitter
SET- + Switching code for 2nd/1st Car Operation Press within 3 sec.
(2 sec.
C. LED Status Display Chart: D. Chirp Indicat rs
LED Functi n Chirp Functi n
Off Disarmed 1 chirp Arm
Slow Flash Armed 2 chirps Disarm
Fast Flash Passive Arming 3 chirps Ajar Warning
On (solid Valet Mode 6 chirps Car Locator
E. Parking Light Indicat r Display Chart:
1 Flash Arm
2 Flashes Disarm
12 Flashes Car Locator
Constant On Under Remote Start Operation

. .
7
OPERATION
G. ACTIVE ARMING  LOCK & ARM:
1. Press the button on the transmitter.
2. The siren will chirp once and parking lights will flash once and remain
ON for 10 seconds indicating that the system is now armed. The
vehicles doors will lock upon arming when interfaced with the security
systems keyless entry.
System A m Doo Aja Clea The Flash Icon:
Press the SET button 3 times within
3 seconds will clear the flash icon
on the L D screen transceiver.
F. ALARM OPERATING CONDITION:
Ho n/ Pa king
Si en Light LED Doo s Sta te Dome Light
1. Arming 1 or 3 hirps 1 Flash Slow Flash Locking Disable
2. Disarming 2 or 4 hirps 2 or 3 Flashes Unlocking Turns on for 30 sec.
3. Trigger Alarming Flashes Slow Flash Disable Flashes
4. Passive Fast Flash Disable
Starter
Disable
5. Panic Alarming Flashes Flashes
6. ar-jacking Alarming Flashes Disable Flashes
7. ar Locator 6 hirps 12 Flashes Locking

. .
8
OPERATION
H. SILENT ARMING / DISARMING: Pressing the transmitters and
buttons at the same time will arm or disarm your security system, No chirping
sound will be heard, arm / disarm confirmation will be through the vehicles
parking lights only.
I. PASSIVE STARTER DISABLE:
The purpose of this feature is to protect the vehicle from being stolen at all
times, regardless of whether or not the alarm is armed.
The vehicles starter will be disable 0 seconds after the ignition is turned
off. Once the key is turned off, the LED will flash fast for 0 seconds.
After the 0-second timer has elapsed, the LED will flash slowly (one-half
its normal armed rate) to indicate the passive starter disable is activated
and the system will not respond to any trigger input except the ignition
trigger.
. PASSIVE ARMING
Active arming / disarming is controlled by your security systems remote
transmitter. The security system is equipped with an optional Passive
Arming feature, which allows the security system to arm 30 seconds after
the last door is closed. Operation is as follows.
1. Turn the ignition key to the OFF position and exit the vehicle.
2. After all doors are closed, the security systems LED will flash fast for 30
seconds. If you re-open any door, hood or truck, the security systems
LED will stop flashing. It will begin flashing again once these are closed.
3. After the 30-second timer has elapsed, the security system will automatically
ARM. The siren will chirp [1] time and the parking lights will flash [1]
time and then remain ON for 10 seconds.
PASSIVE ARMING WITH PASSIVE DOOR LOCKING:
The vehicles doors will automatically lock after the passive arming cycle has
been completed.
PASSIVE ARMING BY-PASS: While the system disarmed, Press the
button twice, the security system will respond with [1] chirp and LED will
turn ON. The security system will remain in this temporary state for as
long as you wish. To exit passive by-pass, press the transmitters or
buttons and the system will return to normal status.

. .
9
OPERATION
K. ACTIVE DISARMING  UNLOCK & DISARM:
1. Press the button on the transmitter.
2. The siren will ch rp (2) t mes and park ng l ghts w ll
flash (2) t mes and then remain ON for 30 seconds
indicating that the security system is now disarmed. The
vehicles doors will unlock and dome light will turn ON
for 30 seconds upon disarming when interfaced with the
security system.
System
D sarm
TWO STEPS DOOR UNLOCK: This feature will independently unlock the
drivers door only when disarming the security system. Pressing the
button a second time within 3 seconds will unlock the rema n ng doors.
AUTOMATIC RE-ARM: If this feature is selected the security system will
automatically re-arm itself in 60 seconds after disarming with the remote
transmitter. Automatic rearm will cancel if any door is opened before the
60 second timer has elapsed.
L. DISARMING WITHOUT A TRANSMITTER
OVERRIDES THE ALARM WITHOUT PASSWORD PIN CODE:
The override function may be used if the remote transmitter is lost or
inoperative.
1. Enter the vehicle and turn the ignition switch to ON position. (Alarm
will sound.)
2. Within 10 seconds press and release the valet switch
The alarm will stop sounding and enter the disarm mode. You can now
start and operate the vehicle normally with the ignition key.
M. VALET MODE:
The valet switch allows you to temporarily bypass all alarm functions
eliminating the need to hand your transmitter to parking attendants or
garage mechanics. When the system is in Valet Mode all alarm function
and remote starter functions are bypassed however the remote pan c
feature and remote door locks will remain operational. To use the Valet
Mode the system must first be disarmed either by using your remote
transmitter or by operating the Manual override sequence.

. .
10
OPERATION
Enter Valet Mode:
1. With the unit Disarmed, turn the ignition to ON
position.
2. Press and hold valet/program switch for 2 seconds
until the LED turns ON. he LED wills remain on
as long as the system is in Valet Mode.
Exit Valet Mode:
1. o return to normal operation, turn the ignition
ON.
2. Press and hold the valet/program switch for 2
seconds. he LED will turn OFF indicating the system has exited Valet
Mode.
REMOTE VALET: (S stem in Disarm or Valet mode)
Press and release the
button on the transmitter (3) times within 3
seconds to enter / exit valet mode. (1) parking flash confirms entering
Valet Mode and (2) parking light flashes confirms exiting of valet
mode.
N. CAR FINDER
In armed mode, press the button to active car locator
function. he siren will chirp (6) times. he parking light will
flash (12) times, for you to easily locate your car.
Remote
Door
Unlock
Remote
Door
Lock

. .
11
OPERATION
O. PANIC MODE:
The transmitter can be used as a remote panic switch to
manually trigger the alarm in case emergency.
1. Press and hold the button for 3 second. The alarm will
immediately sound.
2. During Panic Mode, the normal function of this trans-
mitter button will be suspended. The and buttons can be
used to lock and unlock the doors (if the option is installed , however
once the button is pressed, the vehicles starter disable
device, (if installed will be enable allowing the vehicle to start.
3. To stop the Panic Mode, press and hold the
or buttons on the
transmitter again for 3 seconds, if any transmitter button other than the
or button is pressed and released, the Panic Mode will be turned
off immediately.
4. If the button is not pressed, the alarm will automatically stop after 30
seconds.
P. Y TEM TATU CHECK
When you want to check the systems present status through
the LCD screen, Press the transceiver button (2) times,
within 3 seconds press the (SET) button. It responds with
one melody sound, the LCD screen should be illuminated.
Note: If there is no responce then you are out of range.
Q. DOME LIGHT UPERVI ION
The alarm has a unique feature that will turn ON your vehicles dome light
as follows:
1. Upon disarming, the interior dome light will remain ON for 30 seconds.
2. If the vehicle is intruded, the interior dome light will flash for the same
duration as the siren.
Note: Turning on the ignition switch or arming the alarm will turn
off the dome light.
R. IGNITION CONTROLLED DOOR LOCK/UNLOCK.
If the vehicles door locks have been interfaced to the security systems
keyless entry, the system will automatically lock the vehicle's doors when
the ignition is turned ON and will unlock the vehicles doors when the
ignition is turned OFF.

. .
12
OPERATION
S. TRUNK RELEASE (CHANNEL 3) OUTPUT.
Press and hold the button on the transmitter for two sec-
onds to remote control the trunk release or other connected
electronic devices.
T. CHANNEL 4 TIMER CONTROL OUTPUT
Press the transmitters (4) and (4) buttons at the
same time to active the Channel 4 unction. Channel 4 is user-programmable
timer output. You may program the built-in timer to send a ground signal
for any time duration from 1 second to 12 seconds. For instance, this timer
output may be used to turn on the headlights, power windows or sunroof.
(Factory de aults setting at momentary output.)
U. CHANNEL 5 TIMER CONTROL OUTPUT
Press the transmitters (5) and (5) buttons at the same time to active
the Channel 5 unction. Channel 5 is user-programmable timer output.
You may program the built-in timer to send a ground signal for any time
duration from 1 second to 12 seconds. For instance, this timer output may
be used to turn on the headlights, power windows or sunroof. (Factory
de aults setting at momentary output.)
V. CHANNEL 6 TIMER CONTROL OUTPUT
Press the transmitters (6) and (6) buttons at the same time to active
Channel 6 function. Channel 6 is user-programmable timer output. You may
program the built-in timer to send a ground signal for any time duration
from 1 second to 12 seconds. For instance, this timer output may be used
to turn on the headlights, power windows or sunroof. (Factory de aults
setting at momentary output.)

. .
13
OPERATION
For 2-way LCD Remote Control Transceiver:
2nd Car O eration:
1. Press the SET button first, within 3 seconds press and hold
the and buttons together for 2 seconds with two beeping
sounds and the   icon will display on the LCD screen to
indicate the second transcei er pin code has been learned.
2. With the   icon displayed on the LCD screen, you can
remote control and communicate with the second ehicles
security system. It has two short bi sounds while pressing the button
of the LCD screen transcei er.
Back to 1st Car O eration:
1. Press the SET button first, within 3 seconds press and hold
the and buttons together for 2 seconds with one long
beeping sound, the   timer icon will display on the LCD
screen to indicate the system is back to first transcei er pin
code.
2. While the   timer icon is displayed on the LCD screen,
you can remote control and communicate with the first ehicles security
system. It has one short bi sound while pressing the button of the LCD
screen transcei er.

. .
14
OPERATION
A. TO REMOTE START THE VEHICLE:
When you want to Remote Start your vehicle,
1. Press the button twice on the transmitter
2. The parking light will flash to indicate the remote starter
received the signal. A melody sounding from your Remote
LCD transceiver and the  icon will flash on the LCD screen
to confirm the remote starter was activated.)
3. The engine will start in approximately 5 seconds.
4. Once the engine is running, after couple seconds the parking
light will turn on and climate controls will activate and adjust
the vehicles interior temperature to your preset setting.
While the vehicle is running, the   icon and the minutes
digit on the LCD screen will flash and it will indicate a count
down timer based on the 5, 10, 20 or 30 minute run time
you have selected)
5. The vehicle will run for 5 to 30 minutes and automatically
shut down. When the unit shuts off the count down timer
will turn off and the transmitter will play a melody.)
NOTE: The Remote Start Unit will not start the vehicle if any
one of the followingconditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. Move the optional remote start enable toggle switch to OFF position.
If installed)
4. The gear selector is in any gear other then PARK or NEUTRAL
5. The e-brake is not set. for Standard Transmission Vehicle)
SAFE START (C ild safety mode)
Factory defaults setting) press the button twice on the transmitter to
start the vehicle. Programming this feature will eliminate an accidental
remote start, when kids enter this transmitter, it enquires:
The user presses the transmitters and buttons at the same time to
remote start the vehicle.
Activate
Remote
Start
Engine
Running

. .
15
OPERATION
B. ENGINE START MEMORIZING FOR VEHICLES WITH MANUAL
TRANSMISSIONS
The system senses the neutral transmission position automatically and there
is no prior set-up required. The system in the standard transmission vehicle
operates a process that when you exit the vehicle it senses and memorizes
the neutral transmission position. If the vehicle is equipped with a automatic
transmission, this process is omitted.
1. While en ine is runnin with i nition key, set the emer ency brake and
place the transmission in the neutral position.
2. Before turnin off the en ine, press the button twice on the transmitter.
-- The LED indicator will flash 3 times to confirm it is entered.
3. Turn off the I nition Key and remove it from the key cylinder.
-- The en ine will continue runnin until the pre-pro rammed time elapsed
or a shutdown input is received.--
4. Exit the vehicle, close all doors.
-- The en ine should still continue runnin , this is a normal operatin
process.
. Within 1 minute from the time of step 1, press the button on the
transmitter to lock the doors.
6-1. If the en ine shuts down immediately and the system is now ready
for next remote (or pro rammable) en ine starts.
6-2. If the en ine does not shut down immediately, the system has failed
in en ine start memorize set up, repeat above process a ain.
If a door is opened after the above process, the prior memorization for
the next remote or pro rammed en ine start sequence was delete and
the function shall not work until you repeat above process a ain.
Note: If the engine start memorize is set up, the dome light
supervision function will be temporarily by-passed.
C. TO OPERATE THE VEHICLE
WHILE RUNNING IN THE REMOTE START MODE:
To operate the vehicle while runnin in the remote start mode:
Insert the i nition key and turn it to the ON (not the start) position.
Press the brake pedal.
Note: If the brake pedal is pressed before the key is in the ON
position, the engine will shut down.

. .
16
OPERATION
D. PIT-STOP FEATURE:
This feature allows the vehicle to remain running after the key has been
removed from the ignition switch. This feature is useful for occasions when
you wish to exit and lock the vehicle for short periods of time, but would
like to leave the engine running and the climate control on.
1. Before turning off the engine, press the button twice on the transmitter
and the L D indicator will flash 3 times to confirm the program was
entered.
2. Turn the ignition key to the OFF position. (The engine will stay running.)
3. The engine will run until the pre-programmed time elapsed or a shutdown
input is received.
Note: For Standard Transmission Vehic es: Before pressing the
button, set the emergency brake first.
E. TURBO COOL-DOWN TIMER MODE: (See A arm Feature 2 - 5
Programming)
Turbo Cool Down timer mode keeps the engine running after arriving at
your destination for a programmable period of 1, 3 or 5 minutes, This allows
the systems run time to conveniently cool down the turbo after you have
left the vehicle. To activate:
1. While engine is running, place the transmission in the park position and
set the emergency brake.
2. Before turning off the engine, press and release the and buttons
at the same time.
-- The parking light wills turn on to indicate the remote starter has entered
turbo cool down mode. --
3. Turn the ignition key OFF and remove it from the key cylinder.
-- The engine will remain running. --
4. xit and secure(lock) the vehicle.
-- The engine will remain running until the pre-programmed time has
elapsed. 
F. TIMER / TEMPERATURE START:
This unit can be programmed to start and run the engine every 2 or 3
hours or punctually at the same time the next morning, the engine will run
for the programmed running time and then shut down.
IMPORTANT: Timer Start should be used only in open areas, never start
and run the vehicle in an enclosed space such as a garage or carport.

. .
17
OPERATION
2 to 3 hour Timer Start with Temperature-Control OFF: This
feature is design for an extreme cold climate usage. The system will
automatically start the vehicle every 2 or 3 hours, to prevent the engine
from freezing and to prevent a vehicle from being hard to start.
M XIMUM OF SIX CYCLES C N OCCUR.
2 to 3 hour timer tart with Temperature-control:
If you programmed the temperature ON to operate. The system can be
programmed to automatically start the vehicles engine whenever the
temperature inside the vehicle reaches or drops below the preprogrammed
temperature level. The system will monitor the air temperature every 2 to
3 hours and will only start the engine during extreme cold temperatures.
There are (3) three temperature levels to choose from.
Daily Timer Start: This feature is very useful for the driver who wants to
run the vehicle punctually at the same time the next morning. Before setting
up the Daily Timer Start, you should set you time for engine start. (
see Timer Setting / Timer et-up for Daily Timer Start, page 16)
To ENTER:
1. Press the button twice to remote start the vehicle. s soon as the
vehicle is running the parking lights will turn on or start flashing.
2. Immediately depress the button once, within 2 seconds.
3-a. 2 to 3 Hour Timer Start: Rapidly depresses the button. The
parking light will flash (3) times. The siren or horn chirps (3) times. The
vehicle is now programmed to start every 2 to 3 hours.
3-b. Daily Timer Start: Depress the transceiver SET button
first, within 3 seconds press ( ) button. The parking
lights will flash (6) times. The siren chirps (6) times. The
vehicle is now programmed to start at this set time, the
next day. Your set time for the next day, the engine start
flashes for approx. 3 seconds on the LCD screen. fter 3
seconds the icon stays displayed on the LCD screen.
4. Press the brake pedal to shut the engine off.

. .
18
REMOTE START OPERATION
Exit the timer start:
1. Timer start can be exited manually as follows:
Make sure the engine is not running in remote start mode.
2. Turn the ignition key ON. The LED and arking lights will flash (4) times.
The horn chir s (4) times.
Or
1. Press the button twice to remote start the vehicle. As soon as the
vehicle is running and the arking light have turned on or are flashing.
2. Immediately de ress the button, then ress and hold the button
for 2 seconds. The arking lights will flash (4) times. The siren or horn
chir s (4) times. The vehicle is no longer rogrammed to start automatically.
G. INTERIOR TEMPERATURE MONITOR
You can monitor through the LCD screen, the resent interior
tem erature of the assenger com artment before cooling or
heating your vehicle. Press the transceiver SET button first,
within 3 seconds ress the ) button; the interior tem -
erature will be shown on the LCD screen. This reading may be
higher than actual ambient tem erature due to the greenhouse
effect and is relative only the inside vehicle tem erature.
H. TO TURN OFF THE REMOTE START:
When the engine is running (in remote start mode), to shut the
engine off: Press the button twice on the remote transmitter.
Move the o tional remote start enable toggle switch to the
OFF osition. (If installed) Press the brake edal. Release the
emergency brake. (for Standard Transmission Vehicle) The
vehicle will shut down and turn off the arking lights to indicate
engine has sto ed.

. .
19
REMOTE START OPERATION
I. SHUT-DOWN INPUT FOR REMOTE STARTER:
If any of the following conditions exists while the system is operating, the
engine will not start or will shut down immediately:
1. The hood is opened.
2. The brake pedal is pressed.
. The emergency brake is released (for Standard Transmission Vehicle)
4. Engine is over-revved. {Tachometer checking t pe only}
5. The pre-programmed run time (5 /10 / 20 / 0 minutes) has elapsed.
6. Pressing button twice on the remote transmitter.
7. Move the optional remote start enable toggle switch to OFF position.
(If
installed)
8. If the engine does not start with { } attempts.
J. DISABLING THE REMOTE START SYSTEM: (If installed)
This feature allows your systems remote starter to be temporarily disabled
to prevent the vehicle from being remote started accidentally. This feature
is useful if the vehicle is being serviced or stored in an enclosed area. To
disable the remote starter, move the optional remote start enable toggle
switch to the OFF position.
LCD REMOTE TRANSCEIVER:
Note: the s stem ma be interfered with b stronger radio frequenc ,
sources of high voltage electric power lines or obstacles such as tall
buildings, the transmission range ma be shorten due to the s stems
use of a low powered output frequenc .

. .
20
REMOTE START OPERATION
K. BATTERY REPLACEMENT:
A 1.5V type AAA Alkaline battery powers the Remote Transceiver. When the
power of the battery weakens a icon will be displayed on the CD screen.
When the old battery is replaced with a new one, there will be beep sound
that indicates the power is up and the clock on the CD screen returns to
AM12:00 after displaying all the icons. Set the correct time by pressing for
3 seconds before using. (See Timer Setting).
Note : Press the button two times with the batter removed, then
insert the new batter .
L. THE REMOTE LCD ICON DESCRIPTION CHART :
Door Lock Door Unlock
Your vehicle doors are locked. Your vehicle doors are
unlocked.
Armed Mode Valet Mode
Your vehicle is in armed mode. All the functions are
temporarily on hold.
Remote Transmission In-Range Indicator
You are transmitting the signal The system is within the
to the control unit. remote control range.
Door Open Warning Trunk/Hood Trigger
Doors are opened. Trunk or Hood is opened.
(Zone 3) (Zone 2)
Shock Sensor Trigger Warn Awa Trigger
Trigger on Shock Sensor Trigger on Shock Sensor
(Zone 4) (Zone 1)
Engine Starting Engine Running
Your vehicles engine is starting Your vehicles engine is
by remote control. running in remote start mode.
Timer Control Start Temperature Monitor
Engine will automatically start The interior temperature of
at the same time the next day your vehicle.
or every 2 to 3 hours.
ARMED
