BulletHD PRO2 User manual

!
!
Welcome!
•Thanks for purchasing this BulletHD PRO2
• Please read this instruction manual to ensure correct use of the
product prior to use.
• Please keep this instruction manual in a safe place.
• Please ensure that the sales store fills out the warranty with the date
of purchase and the name of the store.
• The warranty does not cover any damage that may occur during a
sport activity. It is the users responsibility to secure the action cam
securely to any sport equipment.

Table of Contents
What’s in the box
How to use
BulletHD Overview
Initial Set Up
Charging the battery
Power on/off your BulletHD
Date & Time Setting
MicroSD card Storage Chart
Take a Video
Take Still Pictures
Playback on your computer
On a Mac
LED Status Table
Removing/Installation battery
Repairs
Webcam Function
Technical Specification
Warranty
Warning
Warranty Card
What’s in the box?
1. Camcorder with Sound Cap (water resistant)
2. Camcorder Mount
3. Universal Mount 3pcs
4. Roll Bar Mount
5. Pad Mount
6. Rotating Kit Set
7. Battery 2pcs
8. USB Cable
9. Adhesive Stickers 8pcs
10. Magic Tape 2pcs

11. Hand Safety Strap
12. User Manual
13. Waterproof Cap
14. Rubber O-ring 6pcs
15. Silicon Grease
How to use
1.Camcorder on Front Helmet
2.Camcorder on surfing board or any curved surface
3.Camcorder on top of helmet

4.Camcorder on Vented Helmet
5.Camcorder on Handlebar
6.Camcorder on Non-vented Helmet
Using BulletHD for Water Sports
Remind you to put some silicon grease to the rubber O-ring from time
to time, especially before using underwater. Make sure the rear cap ③
was closed tight.

BulletHD OVERVIEW
①LED ②Power / Shutter ③Rear Cap ④Mode Switch
⑤USB ⑥MicroSD Card Slot ⑦Battery ⑧Microphone
⑨1080P / 720P Mode Switch ⑩Stabilizer / Firmware
INITIAL SET UP
1. Make sure the BulletHD is OFF before adding or removing the memory card!
2. Screw out the rear cap (open) located at the back of the BulletHD ③.
3. Install a micro SD memory card (max up to 32GB) into the rear slot. To insert
the micro SD card, slide the micro SD card into the card slot on the back of
the BulletHD with the card label facing down. The micro SD card will click into
place once it is inserted past flush with the Bullet HD. Use your fingernail to
do this. Then screw in the rear cap till is complete lock.
4. If no micro SD memory is inserted in the BulletHD, the LED on top of the
camera will blink red and blue.
5. When using a micro SD memory card in the BulletHD, there should be no
data from other devices on the card. If you are using a micro SD memory
card for the first time in the BulletHD, first you should format the card in your
computer.

Charging the battery
Screw out the rear cap located at the rear of the camera ③and Plug the USB charger
to the camera. The green light is on while charging, goes off when the battery is fully
charged. On the first use charge the battery 10 hours before use! You can record up to
90 minutes with one charge.
Power on/off your BulletHD
Turn BulletHD
On
Turn on the BulletHD by pressing the Power/Shutter button ②for at
least 3 seconds until the blue LED lights and the red LED flashes
once. The BulletHD will vibrate once, indicating that it is in standby
mode.
Turn BulletHD
Off
Turn the BulletHD off by pressing the Power/Shutter button ②in
standby mode for at least 3 seconds. The BulletHD will vibrate
twice, indicating that it switches off.
Date & Time Setting
Download the “time.txt” file from www.Bullethd.us - Support –Date & Time Quick
Setup for PRO2 1080p
Open the file “time.txt” and change the date & time as follows:
YYYY.MM.DD hh:mm:ss
Y = year h = hour
M = month m = minutes
D = day s = second
Then copy the file to memory card! Now you can take a photo or video to test it!
Remember to insert a micro SD card before you start taking videos or pictures!

Take a Video
To take videos with the BulletHD, make sure that the Video/Photo switch ④is set to
the right for video mode. Turn on the BulletHD by pressing the Power button ②.
Press the Power/Shutter button ②shortly to start a video recording. The red LED will
blink while the video is recording. Press the Power/Shutter button ②again to stop
recording.
Take Still Pictures
To take still pictures with the BulletHD, make sure that the Video/Photo switch ④is set
to the left for photo mode. Turn on the BulletHD by pressing the Power button ②.
Press the Power/Shutter ②button to start taking photos, the red LED will blink. Press
the Power/Shutter button ②again to stop taking photos and to go back to the standby
mode.
In photo mode the BulletHD will take sequentially photos every 3 seconds. It stops
automatically if the battery is empty or if the micro SD card is full.
Playback on your computer
Power off the BulletHD! Screw the rear cap ③, switch ④to right for video mode,
connect with your computer via USB cable from the USB port ⑤,then turn on the
device! The camera will be recognized automatically as USB Device. Or you can take
out the micro SD card and use your own card reader to connect with your computer too.
The device must be power on while connected with computer for data
download. Don’t remove the battery!
When you remove the battery while the video is playing, damage to
your video data could occur!

On a MAC
Simply plug the BulletHD into your MAC with the included USB cable, turn your
BulletHD on, and the MAC OS will recognize the BulletHD as an external hard drive.
IMPORTANT TIP FOR MAC USERS
When deleting files from your MicroSD cards you must empty the trash before
removing it or unplugging the BulletHD. If you do not empty your trash the photos and
videos files will not be completely erased from your cards.
REMARKS:
THE SPECIFICATION IS SUBJECT TO CHANGE WITHOUT NOTICE.
Removing/Installation battery
The battery is designed to have a very tight fix to maximize reliability in high vibration
activities. To remove the battery, pull it out with the battery holder.
It is intentionally not easy to do, but the battery will come out.
Additional batteries and mount packages are available at www.BulletHD.us
Repairs
Since most helmet cameras are used for recording extreme sports or outdoors activity.
Like this and you will probably end up with a broken camera which warranty does not
cover any damage that may occur during a sport activity.
Check with us before giving up on your BulletHD!
http://www.BulletHD.us/repairs/
You might be able to fix your BulletHD even if you think they are broken and beyond
hope. We're the great problem-solvers, and you are able to fix at home whatever is
possible to repair your BulletHD with your hands. We want to help you get the full value
from your camcorder; there are tutorial videos to show you how to repair your cam at
our YouTube channel!, http://www.youtube.com/bulletHDcam
This is easy and simply! We are users too!

Webcam Function
This is not necessary to install the driver to view videos or pictures. The driver is only
necessary to install when using the BulletHD as a webcam which is available for
Windows OS system only.
For details information at www.bullethd.us -Support –Webcam Drivers
Technical Specifications
Optics:
• FISHEYE view @1080p Mode
• SUPER WIDE ANGLE view @720p Mode
• f/2.4, fixed focus glass lens
Video:
• Full HD Resolution Settings: 1080p: 1920x 1080 @ 30fps
• HD Resolution Settings: 720p: 1280x 720 @ 60fps
• Digital Video Motion Stabilization Technology
• Sensor Sensitivity: 960mV/(Lux-sec)
• Video Format: H.264(avc1) / MOV
• Exposure Control: Auto
• White Balance: Auto
Audio:
• Built-in microphone
Photo:
• Resolution: 5296 x 3968
• Camera: 20.0 Mega Pixels
• Format: JPEG
• Capture mode: Auto snapshot every 3 seconds
Storage:
• Memory: Micro SD card, up to 32GB capacity (no included)
(recommended Class 6 or above)
• Avg. Record Time: 10~15min/GB
Product size: 104 x 32 x 32 mm
Weight: 104g
Operating System (for USB drive): Win ME, 2000, XP, Vista, 7; Mac OS X 10.6+

Warranty:
As the warranty is included within this instruction manual, please ensure that the store
name and date of purchase are filled in. Please read the warranty carefully and keep it
in a safe place. This product is covered by a 365 days Limited Warranty on parts and
labor from the date of original purchase, and purchases must be made through an
authorized dealer. The warranty covers defects in workmanship and materials. The
warranty does not apply to units, which have been damaged or abused intentionally or
unintentionally. Purchase from individuals or unauthorized internet sites voids the
warranty. The warranty does not apply to units where the rear cap was incorrect
closed, cosmetic damage, modification of or to any part of the product.
Tampering with or altering the unit will void the warranty. Any unauthorized service will
void the warranty. Original sales receipt must be produced for any warranty service
and a return authorization must be obtained from our customer service points.
The warranty does not cover any damage that may occur during a sport activity. It is
the users responsibility to secure the BulletHD securely to any sport equipment.
WARNING:
The form and functions of BULLETHD, accessories, logos, and all graphics are the
patented, protected property of Silver Creation International Ltd. Any attempt by
anyone other than our authorized dealers to copy or reproduce any of the above
without permission of SCi will be met with legal action. SCi products are available for
purchase only from authorized dealers.

Technical changes and mistakes reserved!
Due to rapid technical development, products are under constant changes / improvements
-please check www.BulletHD.us for current updates.

.

Environmental friendly
Let’s do something for our planet!!
Please download the drivers & software
from our official webpage.
