USE & CARE INSTRUCTIONS for BrewWISESM System
(Includes G92T DBC Grinder and DUAL SH DBC Brewer with Smart Funnel™)
STEP 1 STEP 2 STEP 3 STEP 4
34481.0000A 01/03 ©2003 Bunn-O-Matic Corporation 34481 011403
Select the desired batch
size and coffee flavor on
the grinder. It is not nec-
essary to select a size on
the brewer.
Discard the grounds and
filterwhenbrewingiscom-
pleted.
Momentarily press and re-
lease the BREW button.
Place an empty server un-
der the funnel.
Slide funnel into the fun-
nel rails. The brewer reads
the batch size and flavor
ground through a chip in
the funnel handle and will
automatically select the
correct settings to brew.
Grind the proper amount
of fresh coffee into the
Smart Funnel™ using the
G92-HD with Smart Fun-
nel™ operation.
Insert a BUNN®filter into
the funnel.
A batch size must be cho-
sen at the brewer when
grounds are not obtained
from a Smart Funnel™
compatible grinder.
STEP 5
STEP 6 STEP 7 STEP 8 STEP 9 STEP 10
Level grounds by gently
shaking.
Press the ON/OFF button
to ON.
STEP 2 STEP 4
Clean mineral deposits and
rinse. Using a paper clip,
make sure all holes are
open. Replace sprayhead.
STEP 1
Remove the sprayhead.
STEP 5
Use a clean damp cloth
rinsed in nonabrasive,
mild detergent to clean all
surfaces.
Remove the lid of the
server.
STEP 3
Reinstall the sprayhead.
CLEANING
BUNN
®
COFFEE BREWING

34481 011403
STEP 6 STEP 8STEP 7 STEP 9 STEP 10
STEP 12 STEP 14STEP 11 STEP 15
Unscrew the inlet cap.
Pull out lid assembly. Clean inlet tube with the
medium sized brush (BOM
#00675.0000) and clean-
ing product solution.
Rinse well. Reassemble
the lid making sure to re-
place the retainer cap.
Clean the sight gauge with
the large brush (BOM
#00674.0000) and reas-
semble.
Remove the glass tube.
Make sure reservoir is
empty and unscrew the
sight gauge cap.
Use a clean damp cloth
rinsed in nonabrasive,
mild detergent to clean all
surfaces.
Thoroughly rinse entire
inside of the server. DO
NOT immerse server in
water.
STEP 13
Reinstall glass tube and
the sight gauge cap.
Use a small brush (BOM
#00674.0000) to thor-
oughly scrub the faucet
shank.
Allow the parts to soak in a
sanitizer solution for a mini-
mum of ten minutes. Re-
move the faucet parts from
the sanitizer solution and
rinse thoroughly. Allow
parts to air dry over night.
Transfer these parts to a
three compartment sink
for cleaning. Fill the first
sink with a soap solution
using a mild detergent, the
second sink with a sani-
tizer solution (75°F warm
chlorine solution of at least
50-100 ppm) and the third
sink is used for clean rinse.
STEP 16 STEP 17 STEP 18 STEP 19 STEP 20
Turn the faucet wing nut
in a clockwise direction
and remove the faucet
from the dispenser. Un-
screw the faucet cap from
the faucet body and dis-
assemble all faucet parts.
Use a small brush (BOM
#00674.0000) to thor-
oughly scrub the faucet
body.
CLEANING (Continued)
USE & CARE INSTRUCTIONS for BrewWISESM System
(Includes G92T DBC Grinder and DUAL SH DBC Brewer with Smart Funnel™)
