Bunn HVG User manual

Features ITEM#
PROJECT
DATE
For available variations to some BUNN products,
please contact your BUNN sales representative.
Corporate Offices
1400 Stevenson Drive
Springfield, Illinois 62703
Phone
800-637-8606
217-529-6601
Fax
217-529-6644
Technical Services
800-286-6070
Internet
http://www.bunnomatic.com
Western Regional Office
16431 Carmenita Road,
Cerritos, California 90701
Phone
562-926-0764
Fax
562-926-0858
Canadian Office
280 Industrial Parkway South
Aurora, Ontario, L4G 3T9
Phone
905-841-2866
Fax
905-841-2775
Patents
Apply
1/2000
High Volume Grinder
Model
HVG
High Volume Grinder
• High speed 120 volt grinder.
• Turbo action draws coffee
through grind chamber for
greater grinding efficiency.
• Large 3+lb. hopper; 10 lb.
hopper extension available
upon request.
• Bag lock feature eliminates need
to hold bag.
• Full range of grinds.
• Speed: 120V grinds 3+lbs/minute,
120/240V grinds 6+lbs/minute.
• Patented clean-out lever.
• Bag shaker to prevent ground
coffee overflow.
• Heavy-duty burrs for long life.
Related Products
BUNN® practices continuous product research and improvement. We reserve the right to change specifications and product design without notice.
Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
HVG Hopper Extension
Product No. : 26808.0000
Holds over 10 pounds of whole bean coffee
Dimension: 10
" High
C2.1
Coffee Grinders/Bulk/High Volume 8/99
Precision Burrs
All BUNN grinders use commercial style,
precision cutting burrs to cut (not crush)
coffee beans and to deliver correct
grind distribution.
Model HVG

Dimensions & Specifications
The Mark of Quality in Beverage Equipment Worldwide
All dimensions shown in inches.
Model Product # Volts Amps Capacity Cu. Ft. Shipping Weight
HVG 25750.0000 120 14 5+lbs/min 4.4 101 lbs. (45.9 kg)
HVG 25750.0001 120/240 18 6+lbs/min 4.4 101 lbs. (45.9 kg)
Electrical: Motors are rated: 240 volts,3.0 HP, 120 volts,2.0 HP. Cordset attached.
35.07
25.78
15.46
11.46
10.25
1.02
2.55 REF 9.56
12.11
14.56
ø.875 REF
ELECTRICAL
CONNECTION
LOCATION.
25.83
9.70
9.56
9.50
9.16 8.21
9.10
5.13
.75 1.19
LOCATION OF ELECTRICAL CONNECTION FOR 120VLOCATION OF ELECTRICAL CONNECTION FOR 240V
