BURR KING 760 User manual
BURR KING MFG. CO., INC
1220 Tama a Lane
Wa saw, MO 65355
www.bu king.com
(660)438-8998 • 800-621-2748
Fax (660)438-8991
BURR KING MODEL 760
THREE WHEEL GRINDER
MODEL 760
INSTRUCTION
MANUAL
Model 72110 Shown
BURR KING MFG. CO., INC.
1220 TAMARA LANE
WARSAW MO 65355
WWW.BURRKING.COM
(660) 438-8998
(800) 621-2748
FAX (660) 438-8991
June, 2007
Burr King Manufacturing Company. Inc. warrants the below product to be free in material and workmanship. The period of warranty is 1 year
(90 days for vibratory bowls of 20 quart and lesser volume) from the date of purchase. No warranty is provided for products that have been
modified, abused, handled carelessly, where repairs have been made or attempted by others, or for freight damage. No warranty is provided for three
phase electric motors, controllers, etc. when the motors, controllers are not protected by magnetic starters that were supplied and installed by Burr
King Manufacturing Company. Inc. No other warranty, written or verbal is authorized by Burr King Manufacturing Company, Inc.
During the warranty period Burr King Manufacturing Company, Inc (or its authorized suppliers or agents) will replace or repair the below
product without charge if the product is found by Burr King Manufacturing Company, Inc. to be defective. To receive warranty services you must
contact Burr King Manufacturing Company, Inc. and receive authorization fir warranty service. Unless otherwise authorized by Burr King
Manufacturing Company, Inc. Products (see * below) must be returned to the factory to receive warranty service.
*Motors, speed controllers, and certain other accessories are warranted by their respective manufactures. To receive warranty service on these
items you must contact a brand label service center that supports the product in need of service. Burr King Manufacturing Company; Inc. will assist
you in locating a service center.
For the first thirty days after purchase, and when Burr King Manufacturing Company, Inc. authorizes warranty service, we will pay normal and
necessary surface freight charges both ways (except for items in *). After thirty days the customer is responsible for all freight charges. Where
possible Burr King Manufacturing Company, Inc. may elect to make on site service and/or repairs necessary to return the product to serviceable
condition.
To assure prompt warranty service it is necessary that you complete and return the below warranty information to Burr King Manufacturing
Company, Inc. please FAX or MAIL at your convenience.
Product model: _______________________ Serial number: _______________________
Date Purchased: ______________________ Purchased from: ______________________
Address: ____________________________ City: _______________________State/Prov: _________Postal code________
Your company name: _____________________________________________
Address: _____________________________City: _______________________State/Prov: __________Postal code________
Phone: _______________________________Fax: _______________________Email: _______________________________
Your name: ___________________________Title: _______________________
How did you learn about Burr King products?
Trade show___Web___Industrial Distributor ___Advertisement ___Other __________________________Which one:________________________
What is the intended use of this product? ______________________________________________________________________________________
Please indicate the general work types performed at your company, check all that apply:
Fabrication___Machining___Casting__Molding___Welding___Finishing___Assembly___Research___Other___
Please indicate the primary product focus of your company; check all that apply,
Aircraft/Missile___Automotive___Contract machine___Contract Fabrication___ Agricultural____Maintenance___ Recreational___
Job shop___Foundry___Construction___Arts___Orthopedic___Dental___Medical___Other_________________________________
Please tell us what we can do to improve our products:
________________________________________________________________________________________________________________________
________________________________________________________________________________________________________________________
May we contact you? Yes___No___
Thank you for purchasing Burr King products!
Register online @
www.burrking.com
BURR KING MFG. CO., INC.
1220 TAMARA LANE
WARSAW MO 65355
WWW.BURRKING.CO
M
(660) 438-8998 s (800) 621-2748
FAX (660) 438-8991
February 2005
OPERATOR, and OPERATING AREA SAFETY
Subject equipment includes Grinders, buffers, polishers, and other rotating equipment. Serious injury
or death may occur if minimum safety precautions are not understood, and obeyed by operators and
those other persons who may be in the immediate vicinity of the subject equipment. Persons who
operate, or are in the immediate vicinity of the subject equipment must be properly trained in, and
use, minimum safety precautions and procedures for such machinery.
Minimum safety requirements to operate, or work in the immediate vicinity subject equipment:
1. Read and understand all operating instructions, manuals, labels, and other information provided with the
equipment.
2. Install the equipment according to manufacturer’s instructions.
3. Securely bolt the equipment to a rigid, structurally sound mounting surface.
4. Use and wear proper eye and face protection.
5. Use and wear proper protection for the body, hands, fingers, feet, and legs.
6. Review and understand all machine guards, adjustments, and points of exposure to potential injury.
7. Do not remove, tamper with, or otherwise alter, equipment guards, and other safety features.
8. Insure the machine is adjusted, and remains adjusted according to manufacture’s requirements.
9. Maintain the equipment in good operating condition.
10. Have another person who is knowledgeable in proper and safe operation of the subject equipment
demonstrate proper and safe operation to all operators, and to those persons who might be in the immediate
vicinity of the subject equipment.
11. Use work piece holding devices when ever possible that diminish the possibility that persons will come
in contact with moving machine pieces, or spark/debris output from the machine.
12. Use spark and debris arresting apparatus. Such apparatus should be connected to the machine so as to
contain dust and debris that is generated, and to suppress sparks thereby limiting human inhalation risk, and
the risk of fire or explosion.
13. Use appropriate inhalation apparatus to protect person from ingestion and/or inhalation of sparks, debris,
smoke, particulates, etc.
14. Avoid mixing different metals, alloys, and materials. To mix such materials might create a fire or
explosion hazard.
15. Protect persons from work pieces, particulates, etc. that could be forcibly ejected from the machine. For
example, a buffing wheel or grinding belt can “grab” a work piece while the work piece is being buffed,
polished, ground, or otherwise conditioned, resulting in forcible ejection toward the operator or those in the
vicinity of the machine. The use of leather aprons, gloves, and eye shields are examples of protective gear
that may be effective. In general do not grind, buff, or otherwise engage the traveling belt, wheel, or disc
surface with the work piece pointing into the direction from which the belt, wheel, or disc is traveling.
However, if you choose to do so be aware the work piece may lodge in the traveling belt, wheel, or disc and
be forcibly, and dangerously ejected.
16. Do not operate this machine if the gap (nip point) between a moving belt, wheel or disc and the work
support surface exceeds 1/8 inch.
17. Do not operate this machine if the gap between the moving abrasive belt, disc or wheel and the adjacent
face page 1 continued on next page
Continued from page 1
of the work rest (or table) will permit passage of the work piece through the gap (nip point). Note, however,
that certain alloys such as titanium may create conditions where grinding debris can accumulate in a tight gap
creating a potential fire hazard. When in doubt consult with your safety officer. Failure to observe this
warning may result in the work piece or other item being caught in this gap, and/or being forcibly ejected.
Failure to heed this warning may cause serious bodily harm to the operator and/or bystanders. NEVER USE
THIS EQUIPMENT IF YOU ARE NOT PROPERLY TRAINED IN ITS OPERATION and/or SAFE
USE! IF IN DOUBT STOP and ASK FOR GUIDANCE!
18. Never position the work rest table at an acute angle between the top of the work rest table and the moving
belt or wheel. Doing so will create “nip point” that can cause serious injury should an operator body part
become entangled (pulled into) the nip point created by this acute angle.
19. Do not operate the equipment, or allow others to operate the equipment without proper training in these
and other rotating machinery safety requirements.
20. Do not perform maintenance on the equipment unless you are fully qualified to do so, and understand all
necessary safety and operating requirements.
21. Do not leave the machine unattended while it is running.
22. Correct equipment or safety problems immediately. Do not operate the equipment when it requires
maintenance, or correction.
23. Install and use high quality abrasive belts, wheels, discs, media, etc., as appropriate to your machine.
Understand and follow the operating requirements provided by the manufacturer of these materials.
Rotational Speed Warning, Contact Wheels
Scope: Contact wheels manufactured by Burr King Manufacturing Company, Inc., which have rubber or
urethane tires. Examples include but are not limited to stock codes 202, 302, 402, 502,702, 802, 902, 1002,
1202 and variants. Variants have stock codes that begin with the base number; i.e. 802-S-55 is an 802
variant.
Users are warned not to exceed the below listed revolutions per minute (RPM) on the subject wheels. Failure
to heed this warning may lead to tire de-bonding, fragmentation, or other mechanical failure. Such failures
may cause serious personal injury to operators or bystanders, and/or cause property damage. All Burr King
products are warranted for various time periods to be free of material and/or workmanship defects. Burr King
Manufacturing Companies standard warranty policy is summarized as follows for contact wheels. 1 year
from date of purchase if mounted on a Burr King machine purchased on the same date or 90 days if
purchased as a spare or replacement part. Our warranty does not apply to wheels that are mounted on
products not manufactured by Burr King Manufacturing Company, Inc. Users who mount Burr King
manufactured contact wheels on product not manufactured by Burr King Manufacturing Company, Inc. do so
at their own risk and assume all liability for having so mounted the contact wheel(s).
Remember good safety practice demands guarding to protect operators and bystanders from wheel failure
and/or debris. Never use the subject contact wheels without proper guarding that meets commonly accepted
safe practice. See OSHA, U/L, CSA, CE, ISO and other respected safety standards.
Stock code
Contact Wheel Maximum Safe RPM
202, 302 10000
402, 502, 702 802 4400
902, 1002 2200
1202 1600
Page 2, continued on page 3
Continued from page 2
Occupational Noise Exposure
Burr King products produce levels of noise consistent with their intended purposes. The level and spectral
content of noise produced is dependent on the product type, the degree that the product is maintained in
proper operating condition, the abrasive/media and accessories used, the specific application, and the
surrounding environment. Noise levels produced by various Burr King grinders and polishers, as measured at
the Burr King factory, range from 80 to 93 decibels. Product operators and persons in the immediate product
vicinity should be protected from excessive noise does levels as prescribed in OSHA regulation 29, piece
1910.95 titled “Occupational Noise Exposure”.
ROTATING EQUIPMENT CAN BE DANGEROUS TO OPERATORS AND THOSE WHO MAY BE
IN ITS IMMEDIATE OPERATING VICINITY. IT IS THE ABSOLUTE AND DIRECT
RESPONSIBILITY OF PURCHASERS, MANAGERS, AND OPERATORS OF THIS EQUIPMENT
TO UNDERSTAND AND OBEY THE FOREGOING MINIMUM OPERATING SAFETY
REQUIREMENTS. IF YOU HAVE QUESTIONS OR SAFETY CONCERNS REGARDING
OPERATING THE SUBJECT EQUIPMENT PLEASE CALL YOUR AUTHORIZED BURR KING
DISTRIBUTOR, OR BURR KING MANUFACTURING AT 1-800-621-2748. YOUR SAFETY IS
OUR FOREMOST CONCERN!
Burr King Manufacturing disclaims any and all responsibility for injuries, damage, loss of income, or other
adverse consequence as might be incurred by purchasers, managers, and operators of this equipment.
Page 3 is last page
DOC760OP-99 REV 04/02 1
BURR KING MFG. CO., INC.
1220
TAMARA LANE
WARSAWMO65355
WWW.BURRKING.COM
(660) 438-8998 s (800) 621-2748
FAX (660) 438-8991
April 2002
Operating instructions for the Model 760 belt grinder
The model 760 belt grinder is a three wheel path belt grinder that uses either a 1 1/2 x 60 inch or a 2 x 60
inch continuous loop abrasive belt. When fit with a model 1400, 1401, 1402, 1411 or 1412 internal grinding
attachment (optional) the belt width ranges from 1/2 to 2 inches (depending on the internal grinding
attachment model in use), and the belt length changes to 72 inches. For maximum effectiveness, and operator
safety use abrasive belts manufactured by well respected abrasive manufacturers.
* Use abrasive belts that are the proper size and type for your machine.
* Do not use abrasive belts that are old or excessively worn.
* Do not use abrasive belts that use lap splice joints. Lap spliced belts are prone to separation. They
may also tend to snag your work and create a potential safety hazard by snagging and propelling the
work part in the operator’s direction.
Prior to operating the model 760 please take time to do the following:
1. Insure that you have received all of the items that you ordered. Compare the packing slip with your
purchase order, and of course with the physical items received.
2. Verify that there is no obvious shipping damage. If shipping damage is discovered notify the freight carrier
of your intention to file a freight damage claim. They will assist you.
3. Verify that the AC power that is identified on the machine as received matches the AC power that you
intend to operate the machine with. Do not modify the machine’s wiring without first contacting your
distributor and/or Burr King Manufacturing.
4. Do not modify or defeat any AC wiring safety feature. In example, do not remove the grounding pin on the
AC plug.
5. Verify that you have received a warranty card, parts lists, catalog, and Operator, and Operating Area
Safety Instructions.
6. Complete the warranty card and return it to Burr King Manufacturing.
7. Verify that the various guards for the machine are in place and functional. See the parts list for the
indicated part numbers.
a. The contact wheel guard and backup platen are mounted and adjusted such that the platen lightly
touches the back of the abrasive belt (P/N 703, 704A, 704B).
b. The full safety guard is in place, closed and its door latch is functional such that it will securely
hold the safety door closed (P/N 742A. 742B, 742D, and 742C).
c. If an internal grinding attachment is installed insure that all pinch guards are adjusted so as to
guard the belt wheel entry points. This means that the pinch guards need to very close, but not touching the
abrasive belt (P/N 1429, 2 places, see the internal grinding attachment parts list).
8. Prior to operating the model 760 carefully read the Operator, and Operating Area Safety Instructions.
Insure that all persons who will operate the model 760, or who will work in the vicinity of the model 760
read understand, and comply with these instructions.
9. Insure that the grinder is located in an area that provides clear access to the machine such that operators
have safe and unobstructed access to the machine. The work place should be free from floor obstructions, trip
points, and other faults that may reduce operator safety.
10. Burr King recommends that all three phase installations include a magnetic starter. Magnetic starters
protect motors from “single phasing”, overheating, etc. thereby reducing the risk of damage to the equipment
and/or fire hazard to your facility.
11. Insure that the model 760 AC power source is properly sized, and properly fused. You should consult a
competent electrician, or you may call Burr King Manufacturing for guidance.
DOC760OP-99 REV 04/02 2
Functional operating instructions for the model 760 belt grinder
The model 760 was fully tested and verified to comply with requirements prior to shipping from the factory.
You should perform the following steps:
1. With the machine securely bolted to its table, pedestal, and/or floor point connect the AC power to its
source.
2. Adjust the work support and work support arm (P/N 706, 705) to the desired position. Take care that the
gap between the face of the abrasive belt and the work rest is at most 1/8 inch. WARNING: Be aware
that thin section work pieces can pass through this gap if the gap is not properly adjusted. Ejected
work parts can cause serious personal injury!
3. Insure that the abrasive belt is tensioned properly. To do this, raise the tensioning handle (P/N 737A). You
will hear mechanical clicks as the tensioning ratchet (P/N 736, 737F) moves. Generally, the belt will be
adequately tensioned when you hear three to eight clicks. To reduce or release the belt tension slightly raise
the tensioning handle (P/N 737A) then press the button (P/N 737B) in the center of the tensioning handle.
Move the tensioning handle down slightly to reduce belt tension or all the way down to release belt tension.
4. Engage the motor by placing the ON/OFF switch to ON. The belt should rotate smoothly in a CCW
direction about the machine wheel belt path. If either of these conditions is not met immediately turn the
machine OFF.
a. If the abrasive belt does not remain centered on the contact wheel (P/N 702) while the belt is
moving use the tracking adjustment (P/N 711) on the upper left side of the machine to track the belt. Turning
this control CW to cause the belt to track to the left, conversely turn the control CCW to cause the belt to
move to the right.
b. If the belt runs in reverse ( up from the floor) you must correct this unsafe condition by changing
the main drive motor rotation direction. WARNING: FIRST DISCONNECT THE MACHINE FROM
ITS AC POWER SOURCE. A COMPETENT ELECTRICIAN SHOULD PERFORM ALL
ELECTRICAL WORK ON THE MODEL 760.
1) Reversed the motor direction of a three phase motor by reversing any
two legs of the input power lines.
2) Reverse the motor direction of a single phase motor by reversing leads 5 and 8 found
within the metal wiring box located on the motor, or as otherwise instructed on the actual
motor label.
c. If the abrasive belt tensions, and tracks properly, but has excessive vibration turn the machine OFF
and call the Burr King factory for assistance.
Maintenance for the model 760
WARNING: FIRST DISCONNECT THE MACHINE FROM ITS AC POWER SOURCE.
* Every thirty days apply light machine oil to the rear wheel support (P/N 735) to rear wheel handle (P/N
737G) interface. Two drops of oil is sufficient.
* Every thirty days check the v-belt (P/N 729) tension. If you can hear the belt “slap” the v-belt guard (P/N
728) when the drive motor starts, the v-belt requires re-tensioning. Do this by loosening the four bolts (P/N
2) that secure the motor to the machine base (P/N 731) and slide the motor toward the rear of the machine.
Tighten the four bolts.
* Daily vacuum or otherwise remove dust and debris build-up from the machine and the machine belt track.
There are no other maintenance actions required. All bearings are sealed for life and require no additional
lubrication.
---------------------------------------------------------------------------------------------------------WARNING,
AVOID INJURY: operator safety and the continued effectiveness of your model 760 requires that you:
Do not defeat the safety guards and other safety provisions of the model 760.
Do not operate the model 760 with the safety guard open or the contact wheel guard/platen assembly
(or internal grinding attachment) removed.
Do not reach inside the safety guards while the machine is running. To do so is hazardous.
Do not use fluids in your grinding process unless your model 760 is designed for liquid operation
(NEMA 4, 4X). To do so may create an electrical safety hazard.
DOC760OP-99 REV 04/02 3
Do not use your model 760 to grind/polish explosive materials such unless it is equipped with explosion
proof electrical devices and motor.
Do not mix alloys in your grinding. To do so may create an explosion/fire hazard.
Do not use stone or vitreous wheels on the model 760. To do so will create an operator safety hazard.
Do use eye, hand, face, arm, leg, feet and body protection that is adequate to protect against flying
debris, forcibly ejected work pieces, broken abrasive belts, etc.
Do train operators and others in safe operating practices.
Post these or equivalent instructions such that they are available for ready operator reference.
Please call us for technical assistance and safety advice!
BURR KING MFG. CO., INC.
1220 TAMARA LANE
WARSAW, MO 65355
WWW.BURRKING.COM
(660) 438-8998 s (800) 621-2748
FAX (660) 438-8991
April 2000
Instruction for aligning the idler wheels on model 760 belt grinders
When idler wheels are removed and/or replaced they must be installed such that they are in proper
alignment. Failure to properly align the idler wheels will result in premature failure of the wheels.
Premature failure will be evidenced by outer diameters being excessively worn such that the wheels lose
their factory crown, wear to a truncated form, or become out of balance. Misalignment results in wear that
is analogous to front tire wear when the front steering mechanism of an automobile is miss aligned. The
upper idler equates to the front wheels of the car. If either idler wheel is misaligned to each other or to the
contact wheel excessive, and irregular wear will occur.
The upper and rear idler wheels must operate in the same plane. This means that when they are correctly
aligned a plane passing through the radial center of the upper wheel will exactly pass through the radial
center of the rear wheel. Machines are shipped from the factory with wheels of the same width. In
example, the model 760 prior to mid 1999 was shipped with wheels that are 1.75 inches wide. Currently,
model 760 machines are shipped with wheels that are 2.0 inches wide. The 1.5 and 2.0 inch wheels may
be interchanged and/or mixed; however, if they are mixed their widths must be taking into account when
performing this alignment. The model 760 contact wheel may be 0.5, 1.5, or 2.0 inches wide. Likewise
the width of the contact wheel must be taken into account when performing this alignment.
Never perform maintenance or adjustments as described below on your model 760 without
first disconnecting the machine from its source of electric power. Failure to observe this
warning may lead to serious personal injury.
Procedure: (disconnect electric power and remove the abrasive belt)
1. Install the rear idler such that its inside-bearing surface is approximately 0.06 inches out from the
wheel support P/N 735. Secure the wheel with locking set screw P/N 25.
2. Install the upper wheel such that its inner bearing surface is approximately 0.06 inches out from its
bearing support P/N 714. Secure the wheel with locking set screw P/N 25.
3. Loosen the retaining nut P/N 22 that locks the upper idler wheel adjusting screw P/N 721. Using
screw P/N 721 adjust the upper idler wheel until a straight line representing the plane passing through
the center of the upper idler exactly passes through the center of the contact wheel. This line
represents the center of belt travel. Note: make certain that the bearing support is against the screw
end of P/N 721.
4. Project a line from the upper idler outside rim to the outside rim of the rear idler. Adjust the tracking
control P/N 711 until the wheels are exactly planar. That is their radial centers are aligned.
5. Repeat step 3 and 4 until both conditions are satisfied. That is the upper and rear idlers are aligned to
each other and both wheels are aligned to the contact wheel.
6. Tighten the locking nut on P/N 721.
7. Install a new abrasive belt. Roll the belt manually to assure that it will maintain coarse tracking. If the
belt does not track manually, repeat the prior steps until it does. If after repeating these steps the belt
still will not track the machine requires other maintenance and/or one or both idler wheels require
replacing. The wheels should be replaced in pairs.
8. Apply electric power to the machine and verify that the tracking control P/N 711 will sweep the belt
across the face of the contact wheel. At least ½ inch adjustment in both directions from center should
be possible.
75 73
72
71
74
67
72
70
76
69
68
712
77
78
47
60
61 66 65 64
50 14
54 59
58
63
62
57
49
24
10
48
53
51
55
10
56
24
22
32
52
745
MODEL 760
PARTS LIST
17
16
14
15
24
10
10
18
31
3
29
34
42
42
40
34 42
42
33 40
8
43
44
45
46
39
26
29
3
27
2
13
11
12 10
9
720 21
35
34
19
24 43
5
6
28 25
41
10 23
38
31
37
36
1
30
33
34
35
18
10
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
1220 TAMARA LANE
BURR KING
WARSAW, MO. 65355
54 SCREW, 10-24x1/2 BH, BLK OXIDE9
PARTS LIST
MAIN BODY LIST ITEM 39 LIST - 745/QUICK CHANGE
ITEM 32 LIST - 712/TRACKING ASSEMBLY
MODEL 760
55 739 GUIDE, SPRING
56 738 SPRING, BELT TENSION
57 737G*** ARM, TENSION
58 737F*** PAWL
59 737C*** STRIP, HANDLE
60 737A*** KNOB, REAR TENSION ARM
61 737B-1*** BUTTON
62 27*** SCREW, DRIVE, #8 X 5/8
63 28*** SCREW, DRIVE, #2 x 1/4
64 737E*** NIPPLE, PIPE
65 26*** PIN, 3/32 x 3/8, ROLL PLTED
66 737D*** SPRING, BUTTON
26
150A-3450CS*
1.5 HP MOTOR/120V/1PH/3450RPM
27 730*PULLEY, 3"
28 729-2*BELT, V DRIVE
29 2 BOLT, 5/16-18x1 1/2 HEX HEAD
30 742A-1 GUARD, SAFETY
31 8 SCREW, 10-24 x 1-1/2, BUTTON
32 712 TRACKING ASSY, UPPER IDLER
33 707CSHAFT, BEARING
34 701B BEARING 5/8 x 1 3/8
35 707EX
WHEEL, IDLER - COMES WITH BEARINGS & SHAFT
36 1-0037 BOLT, 3/8-16 x 1-1/4, CARRAGE
37 4-0005 NUT, 3/8-16, JAM, ELASTIC, PLTD
38 711 KNOB ASSY, TRACKING
39 745 BELT TENSIONING ASSEMBLY
40 7 SCREW, 10-24 x 1 1/2 FLAT HD
41 14 NUT, 10-24, KEP
42 701F WHEEL, IDLER CIR-CLIP
43 742B-1 DOOR, SAFETY GUARD
44 742H GROMMET, SAFETY GUARD DOOR
45 742L LATCH, SAFETY GUARD DOOR
46 338-2 SPRING, TRACKING
ITEM # PART # DESCRIPTION
1 700 FRAME, MAIN
2 731 BASE, MACHINE
3 4 WASHER, 5/16 SAE ZINC PLTD
4 1 BOLT, 5/16-18x1, HH, GRD 5, PLTD
5 701 BEARING, CONTACT WHEEL ASSY
6 6 1/4-20 x 1 1/2 FH SOC
7702*CONTACT WHEEL, SMOOTH
8703-3 GUARD, CONTACT WHEEL
9 30 1/4-20x1 SHCS
10 5 WASHER, 1/4 AN
11 704-1B** BRACKET, PLATEN
12 209 SCREW, 1/4-20 X 3/4 ALLEN HEAD
13 704-1A** PLATEN
14 15 WASHER, 5/16 LOCK, SPLIT
15 13 SCREW, 10-24 x 3/4, SOC, HD, CAP
16 705-1 ARM, WORKREST SUPPORT
17 706-1 WORKREST, ANTI-TILT
18 31 1/4-20x1 1/4 SHCS
19 6-0014 PIN, 1/8 X 3/4, ROLL PLTED
20 726 WASHER, SPRING FLANGE
21 727 NUT, 5/8-18 RH, JAM, BRT PLT
22 728A STANDOFF, GUARD
23 728 GUARD, V-BELT, INVERT
24 3 NUT, 1/4-20 JAM, PLTD
25 725*PULLEY, 2.5"
ITEM # PART # DESCRIPTION
47 734 BASE PLATE
48 735 SUPPORT. REAR WHL
49 25 SCREW, SET, 5/16-18 X 3/8, ALLEN
50 736 RACHET
51 34 SCREW, 1/4-20 X 1, FH PHILLIPS
52 20 NUT, NYLOK JAM, 1/2-20
53 21 WASHER, 1/2 ID
ITEM # PART # DESCRIPTION
67 710 BRACKET, PIVOT BLOCK
68 714-1 BODY, TRACKING
69 25 SCREW, SET, 5/16-18 X 3/8, ALLEN
70 716 PIVOT BLOCK MOUNT
71 717 BLOCK, PIVOT
72 16 WASHER, 960-716, AN
73 18 WASHER, 960-516, AN
74 29 SCREW, 10-32 X 1/2 BH
75 19 NUT, 5/16-24, ESNA
76 724 PIN, ROLL, 1/4 x 1
77 5-0035 WASHER, #10, LOCK, HIGH COLLAR
78 13 SCREW, 10-24 x 3/4, SOC, HD, CAP
** CAN BE ORDERED AS ASSEMBLY WITH 704-1A PLATEN AND 704-1B
BRACKET. ORDER PART NUMBER 704-1 FOR ASSEMBLY APRIL 2022
***PARTS CAN BE ORDERED AS ASSEMBLY.
ORDER PART NUMBER 737 FOR HANDLE ASSEMBLY
* NOTICE: BOM PROVIDED IS FOR SKU 70100 - SOME ITEMS MAYBE
DIFFERENT ON YOUR MACHINE. CALL FACTORY WITH YOUR MACHINE
SKU TO VERIFY PART FITMENT
7
5
6
4
3
1
2
8
9
11 10
MAG STARTER
PARTS LIST
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
MAG STARTER
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
MB-4C
BRACKET, MOUNTING, STARTER
1
2
MOTOR
CALL FACTORY FOR PART NUMBER
1
3 4
WASHER, 5/16 SAE ZINC PLTD
4
4 37
BOLT, 5/16-18x3/4 HEX HEAD
4
5 5
WASHER, 1/4 AN
4
6 209
SCREW, 1/4-20 X 3/4 ALLEN HEAD
4
7
4-0013
NUT, KEP, 1/4-20
4
8
MS2A3
MS4A3
MS2B3
MS4B3
3/4HP-1HP, 220V
3/4HP-1HP, 440V
1.5HP-3HP, 220V
1.5HP-3HP, 440V
1
9 775
CONNECTOR, 3/8", STR, LIQ. TIGHT
1
10 776
CONNECTOR, 3/8", 90 DEG, LIQ. TIGHT
1
11 020
CONDUIT 3/8" LIQUID TIGHT
1
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
7
7
6
5
5
6
4
9
4
8
5
3
4
5
6
127
9
4
15
10
13
14
11
16
1.5-3 HP
15
12
10
13
11 14
3/4-1 HP
VARI SPEED
SINGLE PHASE
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
NOTE
FOR 3 PHASE CONTROLLER CALL FACTORY.
CE CERTIFICATION PART NUMBERS
VARI SPEED
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
MB-4C
BRACKET, MOUNTING, STARTER
1
2
941-3
BRACE, MB4 SUPPORT
1
3
5-0032
WASHER, 1/4, LOCK, SPLIT, PLTD
2
4 4
WASHER, 5/16 SAE ZINC PLTD
8
5 209
SCREW, 1/4-20 X 3/4 ALLEN HEAD
10
6 5
WASHER, 1/4 AN
8
7
4-0013
NUT, KEP, 1/4-20
8
8
100B-1725C
150B-1725C
1 HP MOTOR
1.5 HP MOTOR
1
9 37
BOLT, 5/16-18x3/4 HEX HEAD
4
10
015-1
017
120V CORD
220V CORD
1
11 020
CONDUIT 3/8" LIQUIDTIGHT
1
12
864-1
CONT. 115/220V 0.75-1HP
1
13 775
CONNECTOR, 3/8" STR, LIQ. TIGHT
1
14 776
CONNECTOR, 3/8", 90 DEG, LIQ. TIGHT
1
15 643
RELIEF, STRAIN 3/8" 90 DEG
1
16
862-3
CONT. 115/220V 1.5-3HP
1
ADD TO CONTROLLER
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
12
9974-6
LINE FILTER
1
16
9974-5
LINE FILTER
1
CHANGE PART
15 3356
RELIEF, STRAIN
1
10
CE CORD
NO PLUG- CUSTOMER INSTALLED PLUG
1
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
22.25
TOP VIEW
25.50
24
12.25
FRONT VIEW
9.75
7.5
MOUNTING PATTERN
SIDE VIEW
11.25
8.75
.50.50
6.175
.375
(3) PLCS
M760
LINE DRAWING
NOTE:
- ALL DIMENSIONS
ARE IN INCHES
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
Table of contents
Other BURR KING Grinder manuals
