Table of Contents
2 / 20 0870159870_MV1202A_A0001_IM_en
Table of Contents
1 Safety........................................................................................................................... 3
2 Product Description ..................................................................................................... 4
2.1 Operating Principle............................................................................................... 4
2.2 Application ........................................................................................................... 5
2.3 Standard Features................................................................................................. 5
2.3.1 Vacuum Relief Valve..................................................................................5
2.4 Optional Accessories............................................................................................. 5
2.4.1 Inlet Filter ..................................................................................................5
3 Transport ..................................................................................................................... 5
4 Storage......................................................................................................................... 6
5 Installation................................................................................................................... 6
5.1 Installation Conditions ..........................................................................................6
5.2 Connecting Lines / Pipes ......................................................................................7
5.2.1 Suction Connection....................................................................................7
5.2.2 Discharge Connection................................................................................7
5.3 Filling Oil..............................................................................................................7
5.4 Electrical Connection ............................................................................................8
5.4.1 Wiring Diagram Three-Phase Motor ..........................................................8
6 Commissioning............................................................................................................ 10
6.1 Conveying Condensable Vapours ......................................................................... 10
7 Maintenance................................................................................................................ 11
7.1 Maintenance Schedule.......................................................................................... 11
7.2 Oil Level Inspection .............................................................................................. 11
7.3 Cleaning from Dust and Dirt................................................................................. 12
7.4 Oil Change...........................................................................................................13
8 Overhaul...................................................................................................................... 14
9 Decommissioning ........................................................................................................ 14
9.1 Dismantling and Disposal...................................................................................... 14
10 Spare Parts................................................................................................................... 15
11 Troubleshooting........................................................................................................... 16
12 Technical Data ............................................................................................................. 18
13 Oil ............................................................................................................................... 18
14 EU Declaration of Conformity ...................................................................................... 19
