RTXG SERIES
TILLERS
(ROTO HOG)
Published 05/19 Part No. 50075826
OPERATOR’S MANUAL
BUSH HOG®
2501 Griffin Ave.
Selma, AL 36703
334-874-2700
www.bushhog.com
Made in China
RTX85G, RTX92G
This Operator's Manual is an integral part of the safe operation of this machine and must
be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety
and Operation Instructions contained in this manual before operating the equipment. C01-
Cover

To the Owner/Operator/Dealer
All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded
operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has
designed this implement to be used with all its safety equipment properly attached to minimize the chance of
accidents.
BEFORE YOU START! Read the safety messages on the implement and shown in your manual. Observe the rules
of safety and common sense!
For future reference, record your Bush Hog product model number and serial number.
WARRANTY INFORMATION:
Read and understand the complete Warranty Statement found in this Manual. Fill out the Warranty Registration
Form in full and return it to within 30 Days. Make certain the Serial Number of the Machine is recorded on the
Warranty Card and on the Warranty Form that you retain.
Dealer Telephone Model Number
Owner Purchase Date Serial Number

TABLE OF CONTENTS
SAFETY SECTION .............................................................................................................. 1-1
General Safety Instructions and Practices .........................................................................................................1-2
Operator Safety Instructions and Practices .......................................................................................................1-4
Equipment Operation Safety Instructions and Practices ....................................................................................1-5
Transporting Safety Instructions and Practices .................................................................................................1-6
Maintenance and Service Safety Instructions and Practices .............................................................................1-7
Storage and Parking Safety Instructions and Practices ...................................................................................1-10
PARTS INFORMATION ...................................................................................................................................1-11
Concluding Safety Instructions and Practices ..................................................................................................1-11
Decal Location .................................................................................................................................................1-12
Decal Description .............................................................................................................................................1-14
FEDERAL LAWS AND REGULATIONS ..........................................................................................................1-16
INTRODUCTION SECTION ................................................................................................. 2-1
ASSEMBLY SECTION ........................................................................................................ 3-1
DRIVELINE ATTACHMENT ..............................................................................................................................3-4
LUBRICATION ...................................................................................................................................................3-5
OPERATION SECTION ....................................................................................................... 4-1
Standard Equipment and Specifications ............................................................................................................4-3
OPERATOR REQUIREMENTS .........................................................................................................................4-4
TRACTOR REQUIREMENTS ............................................................................................................................4-5
ROPS and Seat Belt ..........................................................................................................................................4-5
Tractor Safety Devices .......................................................................................................................................4-6
Tractor Horsepower ...........................................................................................................................................4-6
3-Point Hitch ......................................................................................................................................................4-6
Front End Weight ..............................................................................................................................................4-7
Power Take Off (PTO) .......................................................................................................................................4-7
GETTING ON AND OFF THE TRACTOR .........................................................................................................4-7
Boarding the Tractor ..........................................................................................................................................4-7
Dismounting the Tractor ....................................................................................................................................4-8
STARTING THE TRACTOR ..............................................................................................................................4-9
CONNECTING THE IMPLEMENT TO THE TRACTOR ....................................................................................4-9
Connecting the Implement ...............................................................................................................................4-10
Setting Implement Height .................................................................................................................................4-11
DRIVELINE ATTACHMENT ............................................................................................................................4-11
Driveline Length Check ....................................................................................................................................4-12
PRE-OPERATION INSPECTION AND SERVICE ...........................................................................................4-13
Tractor Pre-Operation Inspection/Service ........................................................................................................4-14
Implement Pre-Operation Inspection/Service ..................................................................................................4-14
OPERATING THE TRACTOR AND IMPLEMENT ...........................................................................................4-18
Foreign Debris Hazards ...................................................................................................................................4-18
Adjusting the Tiller for work. .............................................................................................................................4-19
Operating the Tiller ..........................................................................................................................................4-19
Bystanders/Passersby Precautions .................................................................................................................4-20
Engaging the Power Take Off (PTO) ...............................................................................................................4-20
PTO RPM and Ground Speed .........................................................................................................................4-21

Shutting Down the Implement ..........................................................................................................................4-21
DISCONNECTING THE IMPLEMENT FROM THE TRACTOR .......................................................................4-22
IMPLEMENT STORAGE .................................................................................................................................4-23
TRANSPORTING THE TRACTOR AND IMPLEMENT ...................................................................................4-23
DRIVING THE TRACTOR AND IMPLEMENT .................................................................................................4-23
Brake and Differential Lock Setting ..................................................................................................................4-25
Transporting on Public Roadways ...................................................................................................................4-26
Hauling the Tractor and Implement ..................................................................................................................4-27
TROUBLESHOOTING GUIDE ........................................................................................................................4-29
MAINTENANCE SECTION .................................................................................................. 5-1
LUBRICATION INFORMATION .........................................................................................................................5-2
OUTBOARD BEARING .....................................................................................................................................5-2
LUBRICATION ...................................................................................................................................................5-2
DRIVESHAFT LUBRICATION ...........................................................................................................................5-4
SLIP CLUTCHES ...............................................................................................................................................5-5
SEASONAL CLUTCH MAINTENANCE .............................................................................................................5-5
GENERAL MAINTENANCE ...............................................................................................................................5-6
Blades ................................................................................................................................................................5-6
Fasteners ...........................................................................................................................................................5-6
Safety Devices ...................................................................................................................................................5-6
STORAGE .........................................................................................................................................................5-6
PROPER TORQUE FOR FASTENERS ............................................................................................................5-6

Safety Section 1-1
SAFETY SECTION

SAFETY
RTXG SERIES TILLER 5/19 Safety Section 1-2
SAFETY
© 2020 Alamo Group Inc.
General Safety Instructions and Practices
A careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to
the owner/operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and
observing certain precautions. The first section of this manual includes a list of Safety Messages that, if
followed, will help protect the operator and bystanders from injury or death. Read and understand these Safety
Messages before assembling, operating or servicing this Implement. This equipment should only be operated
by those persons who have read the manual, who are responsible and trained, and who know how to do so
responsibly.
The Safety Alert Symbol combined with a Signal Word, as seen below, is used throughout this
manual and on decals which are attached to the equipment. The Safety Alert Symbol means:
“ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!” The Symbol and Signal Word
are intended to warn the owner/operator of impending hazards and the degree of possible injury
faced when operating this equipment.
Indicates an imminently hazardous situation that, if not avoided, WILL result in DEATH OR
VERY SERIOUS INJURY.
Indicates an imminently hazardous situation that, if not avoided, COULD result in DEATH
OR SERIOUS INJURY.
Indicates an imminently hazardous situation that, if not avoided, MAY result in MINOR
INJURY.
Identifies special instructions or procedures that, if not strictly observed, could result in
damage to, or destruction of the machine, attachments or the environment.
NOTE: Identifies points of particular interest for more efficient and convenient operation or repair.(SG-1)
Practice all usual and customary safe working precautions and above all---remember safety is
up to YOU. Only YOU can prevent serious injury or death from unsafe practices.
READ, UNDERSTAND, and FOLLOW the following Safety Messages. Serious injury or
death may occur unless care is taken to follow the warnings and instructions stated in the
Safety Messages. Always use good common sense to avoid hazards. (SG-2)
Always maintain the safety signs in good readable condition. If the safety signs are missing,
damaged, or unreadable, obtain and install replacement safety signs immediately. (SG-5)

SAFETY
RTXG SERIES TILLER 5/19 Safety Section 1-3
SAFETY
© 2020 Alamo Group Inc.
Never operate the Tractor or Implement until you have read and
completely understand this Manual, the Tractor Operator’s Manual, and
each of the Safety Messages found in the Manual or on the Tractor and
Implement. Learn how to stop the tractor engine suddenly in an
emergency. Never allow inexperienced or untrained personnel to operate
the Tractor or Implement without supervision. Make sure the operator
has fully read and understood the manuals prior to operation. (SG-4)
Operate this Equipment only with a Tractor equipped with an approved roll-
over-protective system (ROPS). Always wear seat belts. Serious injury or even
death could result from falling off the tractor, particularly during a turnover when
the operator could be pinned under the ROPS. (SG-7)
BEFORE leaving the tractor seat, lower the implement, set the parking
brake and/or set the tractor transmission in parking gear, disengage the
PTO, stop the engine, remove the key, and wait for all moving parts to
stop. Place the tractor shift lever into a low range or parking gear to
prevent the tractor from rolling. Never dismount a Tractor that is moving
or while the engine is running. Operate the Tractor controls from the
tractor seat only. (SG-9)
Never allow children or other persons to ride on the Tractor or Implement.
Falling off can result in serious injury or death. (SG-10)
Never allow children to operate, ride on, or come close to the Tractor or
Implement. Usually, 16-17 year-old children who are mature and
responsible can operate the implement with adult supervision, if they
have read and understand the Operator’s Manuals, been trained in
proper operation of the tractor and Implement, and are physically large
enough to reach and operate the controls easily. (SG-11)
Do not mount or dismount the Tractor while the tractor is moving. Mount
the Tractor only when the Tractor and all moving parts are completely
stopped. (SG-12)
Do not modify or alter this Implement. Do not permit anyone to modify or alter this
Implement, any of its components or any Implement function. (SG-8)

SAFETY
RTXG SERIES TILLER 5/19 Safety Section 1-4
SAFETY
© 2020 Alamo Group Inc.
Operator Safety Instructions and Practices
The operator and all support personnel should wear hard hats, safety
shoes, safety glasses, and proper hearing protection at all times for
protection from injury including injury from items that may be thrown by
the equipment. (SG-16)
PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE
PERMANENT HEARING LOSS! Tractors with or without an Implement
attached can often be noisy enough to cause permanent hearing loss.
We recommend that you always wear hearing protection if the noise in
the Operator’s position exceeds 80db. Noise over 85db over an
extended period of time will cause severe hearing loss. Noise over 90db
adjacent to the Operator over an extended period of time will cause
permanent or total hearing loss. NOTE: Hearing loss from loud noise
[from tractors, chain saws, radios, and other such sources close to the
ear] is cumulative over a lifetime without hope of natural recovery. (SG-I7)
Always read carefully and comply fully with the manufacturer’s
instructions when handling oil, solvents, cleansers, and any other
chemical agent. (SG-22)
KEEP AWAY FROM ROTATING ELEMENTS to prevent entanglement
and possible serious injury or death. (SG-24)
Never allow children to play on or around Tractor or Implement. Children can slip or fall off
the Equipment and be injured or killed. Inadvertent contact with controls can cause the
Implement to shift or fall crushing themselves or others. (SG-25)
Be sure you have adequate knowledge of the property you will be working on. Take time to
make yourself aware of any area underwater or underground lines or cables. Contact with
buried lines or cable could result in serious injury or death. (STL-1)
Do not put hands or feet under implement as it can result in death or
serious injury. Stay away until all motion has stopped and the frames
are securely blocked up. (STL-3)

SAFETY
RTXG SERIES TILLER 5/19 Safety Section 1-5
SAFETY
© 2020 Alamo Group Inc.
Equipment Operation Safety Instructions and Practices
Extreme care should be taken when operating near loose objects such as gravel, rocks,
wire, and other debris. Inspect the area before tilling. Foreign objects should be removed
from the site to prevent machine damage and/or bodily injury or even death. Any objects
that cannot be removed must be clearly marked and carefully avoided by the operator. Stop operating
immediately if blades strike a foreign object. Repair all damage and make certain rotor and blades are in
good condition before resuming operation. (STL-5)
DO NOT use drugs or alcohol immediately before or while operating the
Tractor and Implement. Drugs and alcohol will affect an operator’s
alertness and coordination and therefore affect the operator’s ability to
operate the equipment safely. Before operating the Tractor or Implement,
an operator on prescription or over-the-counter medication must consult
a medical professional regarding any side effects of the medication that
would hinder their ability to operate the Equipment safely. NEVER
knowingly allow anyone to operate this equipment when their alertness or
coordination is impaired. Serious injury or death to the operator or others
could result if the operator is under the influence of drugs or alcohol. (SG-27)
Operate the Tractor and/or Implement controls only while properly seated in the Tractor seat
with the seat belt securely fastened around you. Inadvertent movement of the Tractor or
Implement may cause serious injury or death. (SG-29)
Do not operate the implement while wearing loose fitting clothing. Entanglement of the
clothing with the rotating elements can result in serious injury or even death. Stay clear of
all rotating elements at all times. (SSP-03)
Start tractor only when properly seated in the Tractor seat. Starting a
tractor in gear can result in injury or death. Read the Tractor operators
manual for proper starting instructions. (SG-13)
Never run the Tractor engine in a closed building or without adequate ventilation. The
exhaust fumes can be hazardous to your health. (SG-23)
Do not exceed the rated PTO speed for the Implement. Excessive PTO speeds can cause
Implement driveline or component failures resulting in serious injury or death. (SG-26)

SAFETY
RTXG SERIES TILLER 5/19 Safety Section 1-6
SAFETY
© 2020 Alamo Group Inc.
Transporting Safety Instructions and Practices
Operate the Tractor and/or Implement controls only while properly seated in the Tractor seat
with the seat belt securely fastened around you. Inadvertent movement of the Tractor or
Implement may cause serious injury or death. (SG-29)
There are obvious and hidden potential hazards in the operation of this Implement as in all
power-driven or pulled equipment. REMEMBER! This machine is often operated in rough
terrain conditions that include grass, weeds, gullies, holes, slopes, hidden obstructions and
the like. Serious injury or even death may occur unless care is taken to assure the safety
of the operator and bystanders in the area. Do not operate this machine with anyone in
the immediate area. Stop operating if anyone comes within 25 feet of the equipment. (STL-4)
Many varied objects, such as wire, cable, rope, or chains, can become entangled in the
rotating parts of the Implement. These objects could then swing outside the housing at
great velocity. Such a situation is extremely hazardous and could result in serious injury or
even death. Inspect the area for such objects before working in the area. Remove any such
objects from the site. Never allow the implement to contact such objects. (STL-6)
This Implement may be wider than the Tractor. Be careful when operating or transporting
this equipment to prevent the Implement from running into or striking sign posts, guard rails,
concrete abutments or other solid objects. Such an impact could cause the Implement and
Tractor to pivot violently resulting in loss of steering control, serious injury, or even death.
Never allow the Implement to contact obstacles. (S3PT-12)
Be particularly careful when transporting the Implement with the Tractor. Turn curves or go
up hills only at a low speed and using a gradual steering angle. Rear mounted implements
move the center of gravity to the rear and remove weight from the front wheels. Make
certain, by adding front ballast, that at least 20% of the tractor’s weight is on the front wheels
to prevent rearing up, loss of steering control or Tractor tip-over. Slow down on rough or
uneven surfaces to prevent loss of steering control which could result in property damage
or possible injury. Do not transport unless 3-Point lift lever is fully raised and in the latched
transport position. Dropping implement in transport can cause serious damage to the
tractor and/or Implement and possibly cause the operator or others to be injured or killed.
(S3PT-02)
