Bush B102 User manual

Instruction Manual
B102
Bluetooth Adaptor

CONTENTS
1
ACCESSORIES
Micro USB power adaptor
3.5mm-3.5mm cable
3.5mm-2x RCA cable
User manual
Note:
Place the unit on a dry stable surface away from heat and
damp and where is unlikely to fall or be knocked over.
Safety information
Panels instruction...........................................................
Get started.....................................................................
Cable connection operation.............................................
NFC operation................................................................
Bluetooth operation.........................................................
Specification..................................................................
Disposal of old electrical appliances.................................
Contact details...............................................................
Guarantee.....................................................................
.......................................................... 2
5
6
7
8
9
10
10
11
12

2
SAFETY INFORMATION
CAUTION!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within this unit.
1. Read these instructions. Keep these instructions.
2. Heed all warnings. Follow all instructions.
3. Do not use this apparatus near water.
4. Clean only with a slightly damp cloth.
5. Do not block any ventilation openings.
6. Install in accordance with the manufacturer’s instructions.
7. Do not install or operate near any heat sources such as
radiators, stoves, or other apparatus that produce heat.
8. Unplug this apparatus during lightning storms or when
unused for long periods of time.
9. Refer all servicing to qualified service personnel.
10. Servicing is required when the unit has been damaged in
any way, such as the power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the unit,
the unit has been exposed to rain or moisture, does not
operate normally, or has been dropped.

1
23
11. To reduce the risk of fire or electrical shock, do not expose
this product to rain or moisture.
12. The unit must not be exposed to dripping and splashing
and no object filled with liquids such as a vase of flowers
should be placed on the product.
13. No naked fame sources such as candles should be placed
on the product.
14. Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate this
device.
15. Usage of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous exposure.
ELECTRICAL INFORMATION
Use only power supplies listed in the user instructions.
MAINS SUPPLY
1. The mains operating voltage of this unit is marked on a
rating plate on the back of the unit.
2. The means of disconnecting this appliance from the mains
supply is the mains plug. This should be unobstructed and
readily operable at all times.
3. The direct plug-in adapter (if included) is used as disconnect
device, the disconnect device shall remain readily operable.
4. Plug the adapter with the product power supply interface
firmly before connecting to power.
SAFETY INFORMATION

4
SAFETY INFORMATION
We apologize for any inconvenience caused by any minor
inconsistencies in these instructions, which may occur as a
result of product improvements and development.
CARE AND MAINTENANCE
1. Do not use harsh or abrasive cleaning agents or solvents.
2. Polish the product with soft cloth.
3. Do not attempt to disassemble you product.
4. Do not paint your product.
5. Do not drop, throw or try to bend your product.
6. Only use the power supply that same with product. Use an
unauthorized power supply will damage the product.
7. All care and cleaning operations should be carried out with
the unit unplugged from the mains power.
8. Occasionally wipe the unit with a lint free duster. Never
clean the unit with liquids or solvents.
9. After using the machine, power off at the mains and unplug
it if you are leaving it unattended for a long period.
AVOID HEARING DAMAGE
Listen at moderate volumes to avoid hearing damage. If you
hear no sound during playing, do not turn up volume as the
music suddenly begin at high volume. Excessive sound
pressure from speakers can cause hearing damage and loss.
To avoid damaging your ears, adjust the volume to the lowest
level before playing, and turn up to the desired level when
playback has started.

5
PANELS INSTRUCTION
12
OPTICAL
LINE OUT
1. Bluetooth button/ NFC sensor
2. Indicator light
3. Line out
4. Optical output
5. Micro USB power input
345

GET STARTED
1
26
1. Connect the Micro USB plug of the Power Input on the back
of the unit.
2. Connect the USB plug of the Power Cable to the USB port
on the Power Adaptor.
3. Connect the Power Adapter to a wall outlet.

7
LINE OUT OPERATION- RCA/AUX:
1. Connect the plug of the 3.5 mm cable to the LINE OUT jack
on the back of the unit.
2a. Connect the other end of RCA plugs to the audio input of
your audio device (e.g. amplifier).
2b. Connect the other end of 3.5mm plugs to the 3.5 mm input
of your audio unit (e.g. speakers)..
OPTICAL OPERATION - Optical:
1. Connect the plug of an optical audio cable (not supplied) to
the optical output the back of the unit.
2. Connect the other end to the optical input of your audio unit
(e.g. DVD player).
CABLE CONNECTION OPERATION

NFC OPERATION
1
28
1. Place the back of your phone (with NFC function) on the
NFC SENSOR for 3 seconds. The Bluetooth function of the
phone is activated automatically.
2. The units are paired when the indicator light solid blue.
3. Your audio device provides the best control of the playback.
4. To disconnect the NFC connection, place the back of the
phone on the NFC SENSOR again for 3 seconds. The units
are disconnected and you will hear a sound.
Note:
1. Some devices with Android system 4.0 or below need to
install the ‘NFC.apk’ to activate the NFC function.
2. Some devices have a weak compatibility with NFC function
that may be related to the NFC software.

9
BLUETOOTH OPERATION
1. To enjoy music wirelessly from audio devices (e.g. phone),
start the Bluetooth function on your device.
2. Press the BLUETOOTH button to enter the Bluetooth mode.
The INDICATOR flashes blue.
3. Let your phone search for Bluetooth units, and select ‘B102’
from the list of discovered devices.
(If necessary, enter ‘0000’ as passkey.)
4. After a successful Bluetooth connection, the INDICATOR
lights solid blue.
5. Your audio device provides the best control of the playback.
6. Double click the BLUETOOTH button will un-pair the unit
from your phone.
Note:
When you receive an incoming call on your mobile phone, the
unit will automatically mute. When the call ends, it depends on
your phone whether the track will resume playback.

10
SPECIFICATIONS
Power supply: 220-240 V / 50 Hz
Bluetooth range: 10 m
Dimensions: 86 x 86 x 25 mm
This appliance complies with the following EU
directives: 2006/95/EC Low voltage directive,
2004/108/EC EMC directive, 2002/96/EC WEEE
directive.
DISPOSAL OF OLD ELECTRICAL APPLIANCES
The symbol on the product or its packaging indicates
that this product may not be treated as household
waste. Instead it should be handed over to the
applicable collection point for the recycling of
electrical and electronic equipment.
By ensuring this product is disposed of correctly, you wi ll help
prevent potential negative consequences for the environment
and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more
information about recycling this product , please contact your
local council office, your household waste disposal service or
the shop where the product was purchased.

1
211
CONTACT DETAILS
In the unlikely event of difficulties with your appliance, please
contact the retailer if the machine is still under guarantee.
Customer help-line: 0870 600 3030

GUARANTEE
1
212
This product is guaranteed againstmanufacturing defects for a period of
PRODUCT GUARANTEE
Year.
This product is guaranteed for twelve months from the date of original purchase.
Any defect that arises due to faulty materials or workmanship will either be
replaced, refunded or repaired free of charge where possible during this period
by the dealer from whom you purchased the unit.
The guarantee is subject to the following provisions:
The guarantee does not cover accidental damage, misuse, cabinet parts,
knobs or consumable items.
The product must be correctly installed and operated in accordance with the
instructions contained in this manual.
It must be used solely for domestic purpose.
The guarantee will be rendered invalided if the product is re-sold or has been
damaged by inexpert repair.
Specifications are subject to change without notice.
The manufacturer disclaims any liability for the incidental or consequential
damages.
The guarantee is in addition to, and does not diminish your statutory or legal
rights.
Guarantor: Argos Ltd.
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
