Bush DLED43UHDHDRSB User manual

Instruction manual
DLED43UHDHDRSB

1 Safety information
SOME DO’S AND DON’TS ON THE SAFE USE OF
THE TV 4
Markings on the Product 8
2 Getting to know your TV
Ready? Let’s begin... 10
Accessories Included 10
Features 10
Ultra HD (UHD) 10
High Dynamic Range (HDR) / Hybrid Log-
Gamma (HLG) 10
Dolby Vision 10
Licence Notification 11
Antenna Connection 11
Inserting the Batteries into the Remote 11
Power Connection 12
Switching On/Off 12
Remote Control 13
3 Connections
Connections 16
First Time Installation 17
4 Standard features
TV Control Button & Operation 20
Using Main TV Menu 20
Standby Notifications 21
Using the Channel List 22
5 Advanced features
Media Playback via USB Input 24
Custom Boot Up Logo 24
FollowMe TV 24
CEC 25
System Audio Control 25
E-Manual 25
To Program Your SKY Remote For Your TV 25
Configuring Parental Settings 25
Electronic Programme Guide 26
Software Upgrade 27
Software upgrade search via user interface 27
Settings Menu Contents 28
Connectivity 35
Apps 38
Freeview Play Platform 38
Integrated Catch-Up Services 38
Accessing Freeview Play catch-up TV services38
Internet Browser 39
HBBTV System 39
Smart Centre 40
Alexa Ready 41
6 Other information
Environmental Information 46
Specification 47
Product fiche 47
PC Input Typical Display Modes 49
AV and HDMI Signal Compatibility 50
Supported Video File Formats for USB Mode 51
Supported Picture File Formats for USB Mode 51
Supported Audio File Formats for USB Mode 52
Supported Subtitle File Formats for USB Mode52
Supported DVI Resolutions 53
DVB-T functionality information 53
Quick UI Launcher functionality information 53
7 Product support
Troubleshooting & Tips 56
Help and assistance 57
Disposal information 58
Your Bush Guarantee 59
Important Data Protection Information 59
Contents
1

Safety information
1

Don’t operate your TV in extreme
ambient conditions as this may cause
damage to your TV.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Note: Follow the on screen instructions for operating the
related features.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sucient magnitude
to constitute a risk of electric shock of persons.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the TV.
Preparation
Place the TV on a solid even surface. For ventilation, leave
a free space of at least 10 cm all around the TV. To prevent
any fault and unsafe situations, do not place any objects
on top of the TV. Use this TV in moderate climates.
Operation temperature and operation humidity:
0°C up to 40° C, 85% rel. humidity max. (not blocking
ventilation openings).
Intended Use
This TV is used to receive and display TV programmes.
The dierent connection options make an additional
expansion of the reception and display sources possible
(various external devices). This TV is only suitable for dry
interior use. This TV is intended solely for private domestic
use and may not be used for industrial and commercial
purposes. We exclude liability in principle, if the TV is not
used as intended, or unauthorised modifications have
been made. To operate your TV in extreme ambient
conditions may cause damage to your TV.
This TV is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instructions
concerning use of the TV by a person responsible for
their safety. Children should be supervised to ensure
that they do not play with the TV.
Children may not recognise dangers. The swallowing
of batteries can be fatal. Keep batteries always out of
reach of small children. If a battery is swallowed, seek
immediate medical attention. Keep the packaging films
out of reach of children, there is a risk of suocation.
Use this TV at an altitude of less than 2000 metres above
the sea level, in dry locations and in regions with moderate
or tropical climates.
To avoid danger of suocation, keep plastic bags out of
the reach of babies, children and domestic animals.
Carefully attach the stand to the TV. If the stand is provided
with screws, tighten the screws firmly to prevent the TV
from tilting. Do not over-tighten the screws and mount
the stand rubbers properly.
SOME DO’S AND DON’TS ON THE SAFE
USE OF THE TV
Please read the following recommended safety
precautions carefully for your safety.
This TV has been designed and manufactured to meet
international safety standards but, like any electrical
equipment, care must be taken if you are to obtain the
best results and safety is to be assured.
DO read the operating instructions before you attempt
to use the TV.
DO ensure that all electrical connections (including
the mains plug, extension leads and inter-connections
between the pieces of TV) are properly made and in
accordance with the manufacturer’s instructions. Switch
off and withdraw the mains plug before making or
changing connections.
DO consult your dealer if you are ever in doubt about the
installation, operation or safety of your TV.
DO be careful with glass panels or doors on the TV.
DO route the power cord so that it is not likely to be
walked on, crushed, chafed, or subjected to excessive
wear and tear or heat.
DON’T remove any fixed cover as this may expose
dangerous voltages.
Safety information
Important - Please read these instructions fully before
installing or operating
Safety information
4
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.

DON’T obstruct the ventilation openings of the TV with
items such as newspapers, tablecloths, curtains, etc.
Overheating will cause damage and shorten the life of
the TV.
DON’T allow electrical equipment to be exposed to
dripping or splashing, or objects filled with liquids, such
as vases, to be placed on the TV.
DON’T place hot objects or naked flame sources such as
lighted candles or nightlights on, or close to the TV. High
temperatures can melt plastic and lead to fires.
DON’T use makeshift stands and NEVER fix legs with
wood screws - to ensure complete safety always fit the
manufacturer’s approved stand or legs with the fixings
provided according to the instructions.
DON’T listen to headphones at high volume, as such use
can permanently damage your hearing.
DON’T leave the TV switched on when it is unattended
unless it is specifically stated that it is designed for
unattended operation or has a standby mode. Switch
o using the switch, on the TV and make sure that your
family know how to do this. Special arrangements may
need to be made for infirm or handicapped people.
DON’T continue to operate the TV if you are in any doubt
about it working normally, or if it is damaged in any way
- switch o, withdraw the mains plug and consult your
dealer.
ABOVE ALL
NEVER let anyone especially children push
anything into holes, slots or any other opening
in the TV - this could result in a fatal electrical
shock.
NEVER guess or take chances with electrical
equipment of any kind.
It is better to be safe than sorry!
Power source
•The TV should be operated only from a 220-240 V AC,
50 Hz outlet.
WARNING: Do not leave your TV in standby or
operating mode when you leave your house.
Positioning the TV
•For ventilation, please leave a clear space of at least
10cm all around the TV.
•Do not block the ventilation openings.
•Do not place the TV on sloping or unstable surfaces,
the TV may tip over.
•To prevent damage to the TV, do not place any objects
on top of the TV.
Power cord and plug
•Do not place the set, a piece of furniture, etc. on the
power cord (mains lead) or pinch the cord. Handle
the power cord by the plug. Do not pull the plug by
holding its neck, as this could result in damage to the
plug. Do not unplug the TV by pulling from the power
cord and never touch the power cord with wet hands as
this could cause a short circuit or electric shock. Never
make a knot in the cord or tie it with other cords. The
power cords should be placed in such a way that they
are not likely to be stepped on. A damaged power cord
can cause fire or give you an electric shock. When it is
damaged and needs to be replaced, it should be done
by qualified personnel.
•This TV receiver is supplied with a moulded mains plug.
The mains plug must not be cut o, as it may contain
a special radio interference filter, the removal of which
could lead to impaired performance. If you wish to
extend the lead, obtain an appropriate safety approved
extension lead or consult your dealer.
•Observe the manufacturers instructions when
connecting extension leads to the set. Check the fuse
rating on the new plug; this should be fitted with a 5
Amp fuse which conforms to either ASTA or BSI (BS1362)
approvals, these are easily identifiable by either the ASA
or symbols. If you are in any doubt about the
installation of an extension lead, please consult a
competent electrician.
Safety information
Important - Please read these instructions fully before
installing or operating
Safety information
5
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.

Moisture and Water
•Do not use this TV in a humid or damp place (avoid
bathrooms, the sink in the kitchen, and near the washing
machine).
•Do not expose this TV to rain or water.
•Do not place objects filled with liquids, such as flower
vases, on top of the TV. Avoid from dripping or splashing.
•If any solid object or liquid falls into the cabinet, unplug
the TV and have it checked by qualified personnel before
operating it any further.
Ventilation
•The slots and openings on the TV set are intended for
ventilation and to ensure reliable operation.
•To prevent overheating, these openings must not be
blocked or covered in anyway.
Heat sources and Flames
•Do not expose the TV to direct sunlight or other heat
sources.
•The TV should not be placed near to open flames and
sources of intense heat such as an electric heater.
•Ensure that no open flame sources, such as lit
candles, are placed on top of the TV.
Headphone Volume
•Excessive sound pressure from earphones and
headphones can cause hearing loss, please
take care.
Wall Mounting (optional)
•To prevent injury, this TV must be securely attached to the
wall in accordance with the installation instructions (if the
option is available).
LCD Screen
•Occasionally, a few non-active pixels may appear on
the screen as a fixed blue, green or red point. Please
note that this does not aect the performance of your
product.
•Take care not to scratch the screen with fingernails or
other hard objects.
Cleaning
•Before cleaning, unplug the TV from the wall socket.
•Do not use liquid or aerosol cleaners. Only use a soft,
dry cloth.
Batteries
WARNING: Incorrect installation of batteries may
cause battery leakage and corrosion, resulting in damage
to the remote control.
•Do not mix old and new batteries, or batteries of dierent
types.
•Do not dispose of batteries in a fire.
•Do not dispose of batteries with normal
household waste, take to a local recycling
centre.
CAUTION: Insert the batteries / rechargeable
batteries in the correct polarity. Don´t try to recharge
non rechargeable batteries and under no circumstances
throw them into fire. Danger of explosion. Do not use
unequal batteries (old and new, Alkaline and carbon,
etc.) simultaneously. If you will not use the TV for a long
time, remove the batteries and store the TV in a dry and
dust free place. Improper use of batteries may cause an
explosion or leakage. If the batteries have leaked, use
gloves and clean the remote control thoroughly with a
dry cloth! Batteries should not be exposed to heat, such
as sunshine, fire or the like.
Replacement Parts
When replacement parts are required, make sure that
the service technician has used replacement parts,
which are specified by the manufacturer or have the
same specifications as the original one. Unauthorised
substitutions may result in fire, electrical shock or other
hazards.
Taking out of service and storing
Unplug the TV from the mains and pack the TV in an
appropriate cardboard box. Remove the batteries from
the remote control and pack the remote control with
the TV set.
NOTE: The TV set should be stored in a dry and dust-
free room.
Connection to a Television Distribution
System (Cable TV etc.) from Tuner
Device connected to the protective earthing of the
building installation through the mains connection or
through other apparatus with a connection to protective
earthing-and to a television distribution system using
coaxial cable, may in some circumstances create a fire
hazard.
Connection to a cable distribution system has therefore to
be provided through a device providing electrical isolation
Safety information
Important - Please read these instructions fully before
installing or operating
Safety information
6
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.

below a certain frequency range (galvanic isolator, see
EN 60728-11).
CAUTION
Do not put your fingers in the middle between the TV
and stand, especially when you carry the TV, as they may
be injured.
WARNING
Do not ingest the battery, Chemical Burn Hazard.
This product or the accessories supplied with the
product may contain a coin/button cell battery. If the
coin/button cell battery is swallowed, it can cause
severe internal burns in just 2 hours and can lead to
death.Keep new and used batteries away from children.
If the battery compartment does not close securely,
stop using the product and keep it away from children.
If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate
medical attention.
A television may fall, causing serious personal injury
or death. Many injuries, particuIarly to children, can be
avoided by taking simple precautions such as:
•ALWAYS use cabinets or stands or mounting methods
recommended by the manufacturer of the television set.
•ALWAYS use furniture that can safely support the
television set.
•ALWAYS ensure the television set is not overhanging the
edge of the supporting furniture.
•ALWAYS educate children about the dangers of climbing
on furniture to reach the television set or its controls.
•ALWAYS route cords and cables connected to your
television so they cannot be tripped over, pulled or
grabbed.
•NEVER place a television set in an unstable location.
•NEVER place the television set on tall furniture (for
example, cupboards or bookcases) without anchoring
both the furniture and the television set to a suitable
support.
•NEVER place the television set on cloth or other
materials that may be located between the television
set and supporting furniture.
•NEVER place items that might tempt children to climb,
such as toys and remote controls, on the top of the
television or furniture on which the television is placed.
•The TV is only suitable for mounting at heights ≤2 m.
If the existing television set is going to be retained and
relocated, the same considerations as above should be
applied.
WALL MOUNTING WARNINGS
•Read the instructions before mounting your TV on
the wall.
•The wall mount kit is optional. You can obtain from
your local dealer, if not supplied with your TV.
•Do not install the TV on a ceiling or on an inclined wall.
•Use the specified wall mounting screws and other
accessories.
•Tighten the wall mounting screws firmly to prevent
the TV from falling. Do not over-tighten the screws.
WARNING
Apparatus connected to the protective earthing of the
building installation through the MAINS connection or
through other apparatus with a connection to protective
earthing – and to a television distribution system using
coaxial cable, may in some circumstances create a fire
hazard. Connection to a television distribution system
has therefore to be provided through a device providing
electrical isolation below a certain frequency range
(galvanic isolator).
Symbols in this Instruction Manual
The following symbols are used in the Instruction Manual
as a marker for restrictions and precautions and safety
instructions. Note such information for security reasons.
WARNING
If you do not pay attention to such a marked warning, it
can cause serious injury or death. Note these warnings
strictly, in order to ensure a safe operation.
CAUTION
Such a precaution is marked, you should take up or
note, to avoid injury or property damage. Note these
instructions strictly, in order to ensure a safe operation.
IMPORTANT
Warnings on the TV and restrictions are displayed like
this. Read this information strictly in order to operate the
system correctly and avoid damage.
NOTE
Information about the operation and additional
explanations are marked like this. To be aware of such
information is recommended to ensure that the functions
can be used optimally.
Safety information
Important - Please read these instructions fully before
installing or operating
Safety information
7
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.

Markings on the Product
The following symbols are used on the product as a
marker for restrictions and precautions and safety
instructions. Each explanation shall be considered where
the product bears related marking only. Note such
information for security reasons.
Class II Equipment: This TV is designed in such a
way that it does not require a safety connection to
electrical earth.
Hazardous Live Terminal: The marked terminal(s)
is/are hazardous live under normal operating
conditions.
iCaution, See Operating Instructions: The marked
area(s) contain(s) user replaceable coin or button
cell batteries.
CLASS 1
LASER PRODUCT
Class 1 Laser Product: This product
contains Class 1 laser source that is safe
under reasonably foreseeable
conditions of operation.
The illustrations and the OSD in this instruction manual
are for explanation purposes and may vary slightly from
the actual operations. TV design and specifications may
be changed without notice.
Hereby, VESTEL Elektronik Sanayi ve Ticaret A.Ş., declares
that the radio equipment type TFT IDTV is in compliance
with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following
internet address: doc.vosshub.com
Safety information
Important - Please read these instructions fully before
installing or operating
Safety information
8
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.

Getting to know your TV
2

Ready? Let’s begin...
Please read these instructions carefully. They contain
important information which will help you get the best
from your TV and ensure safe and correct installation
and operation.
If you require any further assistance, our technical experts
are happy to help. For full details, refer to the product
support section at the end of these instructions.
Accessories Included
•Remote Control
•Batteries: 2 x AAA
•Instruction Manual
•Quick Start Guide
Features
•Remote controlled colour TV
•Fully integrated digital terrestrial TV (DVB-T-T2)
•HDMI inputs to connect other devices with HDMI
sockets
•USB input
•OSD menu system
•Stereo sound system
•Teletext
•Headphone connection
•Automatic programming system
•Manual tuning
•Automatic power down after up to eight hours.
•Sleep timer
•Child lock
•Automatic sound mute when no transmission.
•NTSC playback
•AVL (Automatic Volume Limiting)
•PLL (Frequency Search)
•PC input
•Game Mode (Optional)
•Picture o function
•Ethernet (LAN) for Internet connectivity and service
•802.11 a/b/g/n built in WLAN Support
•Audio Video Sharing
Ultra HD (UHD)
TV supports Ultra HD (Ultra High Definition - also known
as 4K) which provides resolution of 3840 x 2160 (4K:2K).
It equals 4 times the resolution of Full HD TV by doubling
the pixel count of the Full HD TV both horizontally and
vertically. Ultra HD content is supported from HDMI, USB
inputs and over DVB-T2 and DVB-S2 broadcasts.
High Dynamic Range (HDR) / Hybrid
Log-Gamma (HLG)
Using this feature the TV can reproduce greater dynamic
range of luminosity by capturing and then combining
several dierent exposures. HDR/HLG promises better
picture quality thanks to brighter, more realistic highlights,
more realistic colour and other improvements. It delivers
the look that filmmakers intended to achieve, showing
the hidden areas of dark shadows and sunlight with full
clarity, colour and detail. HDR/HLG content is supported
via native and market applications, HDMI, USB inputs and
over DVB-S broadcasts. Set the related HDMI source
input as Enhanced from the Sources option in the
Settings>System menu in order to watch HDR/HLG
content, if the HDR/HLG content is received through an
HDMI input. The source device should also be at least
HDMI 2.0a compatible in this case.
Dolby Vision
Dolby Vision™ delivers a dramatic visual experience,
astonishing brightness, exceptional contrast, and vivid
colour, that brings entertainment to life. It achieves this
stunning image quality by combining HDR and wide
colour gamut imaging technologies. By increasing
the brightness of the original signal and using a higher
dynamic colour and contrast range, Dolby Vision presents
amazing true-to-life images with stunning detail that
other post-processing technologies in the TV aren’t
able to produce. Dolby Vision is supported via native
and market applications, HDMI and USB inputs. Set
the related HDMI source input as Enhanced from the
Sources option in the Settings>System menu in order to
watch Dolby Vision content, if the Dolby Vision content
is received through an HDMI input. The source device
should also be at least HDMI 2.0a compatible in this case.
In the Settings>Picture>Mode menu two predefined
picture modes will be available if Dolby Vision content is
detected: Dolby Vision Bright and Dolby Vision Dark.
Both allow the user to experience the content in the way
the creator originally intended with dierent ambient
lighting conditions.
Getting to know your TV
You’ll be up and running in no time
Getting to know your TV
10
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.

Licence Notification
The terms HDMI, HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc.
Dolby, Dolby Vision, Dolby Audio, and the double-D
symbol are trademarks of Dolby Laboratories Licensing
Corporation. Manufactured under licence from Dolby
Laboratories. Confidential unpublished works. Copyright
© 1992-2020 Dolby Laboratories. All rights reserved.
YouTube and the YouTube logo are trademarks of Google
Inc.
For DTS patents, see http://patents.dts.com. Manufactured
under licence from DTS Licencing Limited. DTS, the
Symbol, & DTS and the Symbol together are registered
trademarks, and DTS TruSurround is a trademark of DTS,
Inc.©DTS, Inc. All Rights Reserved.
For DTS patents, see http://patents.dts.com. Manufactured
under licence from DTS Licencing Limited. DTS, DTS-HD,
the Symbol, & DTS or DTS-HD and the Symbol together
are registered trademarks of DTS, Inc.©DTS, Inc. All Rights
Reserved.
DVB is a registered trademark of the DVB Project.
[1] EIA/CEA-861-D compliance covers the transmission
of uncompressed digital video with high-bandwidth
digital content protection, which is being standardized for
reception of high-definition video signals. Because this is
an evolving technology, it is possible that some devices
may not operate properly with the television.
This product contains technology subject to certain
intellectual property rights of Microsoft. Use or distribution
of this technology outside of this product is prohibited
without the appropriate licence(s) from Microsoft.
Content owners use Microsoft PlayReady™ content
access technology to protect their intellectual property,
including copyrighted content. This device uses
PlayReady technology to access PlayReady-protected
content and/or WMDRM-protected content. If the device
fails to properly enforce restrictions on content usage,
content owners may require Microsoft to revoke the
device’s ability to consume PlayReady-protected content.
Revocation should not aect unprotected content or
content protected by other content access technologies.
Content owners may require you to upgrade PlayReady to
access their content. If you decline an upgrade, you will
not be able to access content that requires the upgrade.
The “CI Plus” Logo is a trademark of CI Plus LLP.
This product is protected by certain intellectual property
rights of Microsoft Corporation. Use or distribution of such
technology outside of this product is prohibited without
a licence from Microsoft or an authorised Microsoft
subsidiary.
Antenna Connection
Connect the aerial TV plug to the AERIAL INPUT (ANT-TV)
socket located on the rear side of the TV.
Rear side of the TV
ANT-TV
If you want to connect a device to the TV, make
sure that both the TV and the device are turned
o before making any connection. After the
connection is done, you can turn on the units and use
them.
Inserting the Batteries into the Remote
Remove the back cover to reveal the battery compartment.
You need to do the followings in order to do that:
•Place the tip of a pen or some other pointed object in
the hole above the cover and press it down.
•Then press firmly on the cover and slide in the direction
of the arrow.
Insert two size AAA batteries. Make sure the (+) and (-)
signs match (observe correct polarity). Do not mix old
and new batteries. Replace only with same or equivalent
type. Place the cover back on.
A message will be displayed on the screen when the
batteries are low and must be replaced. Note that when
the batteries are low, the performance of the remote
control may be impaired.
Batteries should not be exposed to excessive heat such
as sunshine, fire or the like.
Getting to know your TV
You’ll be up and running in no time
Getting to know your TV
11
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.

Power Connection
IMPORTANT: The TV set is designed to operate on a
220-240V AC, 50 Hz supply. After unpacking, allow the
TV set to reach the ambient room temperature before
you connect the set to the mains. Plug the power cord
to the mains socket outlet.
Switching On/O
To Switch the TV On
Connect the power cord to a power source such as a
wall socket (220-240V AC, 50 Hz).
To switch on the TV from standby mode either:
•Press the Standby button, Programme +/-, a numeric
button or Netflix button the remote control.
•Press the control button on the TV.
To Switch the TV O
•Press the Standby button on the remote control.
•Press the control button on the TV, the function options
menu will be displayed. The focus will be on the Standby
option. Press and hold the button for about 2 seconds
to activate this option. The icon colour of the option will
change. Then press the button once again, the TV will
switch into standby mode.
To power down the TV completely, unplug the power
cord from the mains socket.
Note: When the TV is switched into standby mode, the
standby LED can blink to indicate that features such as
Standby Mode Search, Timer is active. The LED can also
blink when you switch on the TV from standby mode.
Getting to know your TV
You’ll be up and running in no time
Getting to know your TV
12
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.

Remote Control 1. Standby: Switches On / O the TV
2. Numeric buttons: Switches the channel, enters a number or a
letter in the text box on the screen.
3. Language: Displays and changes audio/subtitle language and
turns subtitles on or o (digital TV, where available)
4. Mute: Completely turns o the volume of the TV
5. Volume +/-
6. Guide: Displays the electronic programme guide
7. Directional buttons: Helps navigate menus, content, etc. and
displays the subpages in TXT mode when pressed Right or Left
8. OK: Confirms user selections, holds the page (in TXT mode),
views Channels menu (DTV mode)
9. Back/Return: Returns to previous screen, previous menu, opens
index page (in TXT mode). Quickly cycles between previous and
current channels or sources
10. Netflix: Launches the Netflix application
11. Freeview Play: Connects to the Freeview Play platform where
you can access available catch-up TV services
12. Coloured Buttons: Follow the on-screen instructions for
coloured button functions
13. Rewind: Moves frames backwards in media such as movies
14. No function
15. Play: Starts to play selected media
16. Pause: Pauses the media being played
17. Stop: Stops the media being played
18. Fast Forward: Moves frames forward in media such as movies
19. Prime Video: Launches the Amazon Prime Video application
20. YouTube: Launches the YouTube application
21. Exit: Closes and exits from displayed menus or returns to
previous screen
22. Info: Displays information about on-screen content, shows
hidden information (reveal - in TXT mode)
23. Home: Displays TV menu
24. Programme +/-
25. Text: Displays teletext (where available), press again to
superimpose the teletext over a normal broadcast picture (mix)
26. Source: Shows available broadcast and content sources
Getting to know your TV
You’ll be up and running in no time
Getting to know your TV
13
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.

Connections
3

Connections
Connector Type Cables Device
VGA
Connection
(back)
AUDIO IN
YPbPr/PC
Audio
Connection
(back) YPbPr/PC Audio Cable
HDMI
Connection
(side&back)
SPDIF SPDIF
(Optical Out)
Connection
(back)
BACK AV
Back AV
(Audio/Video)
Connection
(back) Audio Video Cable
HEADPHONE Headphone
Connection
(side)
YPBPR YPbPr Video
Connection
(back) YPbPr to VGA Connection Cable
USB
Connection
(side)
CI
Connection
(side)
CAM
module
LAN
Ethernet
Connection
(back) LAN / Ethernet Cable
See the illustrations on the left side.
You can use YPbPr to VGA cable to
enable YPbPr signal via VGA input.
You cannot use VGA and YPbPr at the
same time. To enable YPbPr/PC audio,
you will need to use the back audio
inputs with a YPbPr/PC audio cable
for audio connection. When using the
wall mounting kit (available from a third
party in the market, if not supplied),
we recommend that you plug all your
cables into the back of the TV before
mounting on the wall. Insert or remove
the CI module only when the TV is
SWITCHED OFF. You should refer to
the module instruction manual for
details of the settings. The/Each USB
input of your TV supports devices up
to 500mA. Connecting devices that
have current value above 500mA may
damage your TV. When connecting
equipment using a HDMI cable to your
TV, to guarantee sucient immunity
against parasitic frequency radiation
and trouble-free transmission of high
definition signals, such as 4K content,
you have to use a high speed shielded
(high grade) HDMI cable with ferrites.
If you want to connect a device
to the TV, make sure that both
the TV and the device are turned o
before making any connection. After
the connection is done, you can turn
on the units and use them.
Connections
Bringing it all together
Connections
16
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.

First Time Installation
When turned on for the first time, the language selection
screen is displayed. Select the desired language and press
OK. In the following steps of the installation guide, set
your preferences using the directional buttons and OK
button.
On the second screen set your country preference.
Depending on the country selection you may be asked
to set and confirm a PIN at this point. The selected PIN
cannot be 0000. You have to enter it if you are asked to
enter a PIN for any menu operation later.
You can activate Store Mode option in the next step.
This option will configure your TV’s settings for store
environment and depending on the TV model being
used, the supported features of it may be displayed on
the side of the screen as an info banner. This option is
intended only for store use. It is recommended to select
Home Mode for home use. This option will be available
in Settings>System>More menu and can be turned o/
on later. Make your selection and press OK to continue.
Depending on the model of your TV and the country
selection Privacy Settings menu may appear at this
point. Using this menu you can set your privacy privileges.
Highlight a feature and use Left and Right directional
buttons to enable or disable. Read the related explanations
displayed on the screen for each highlighted feature
before making any changes. You can use Programme
+/- buttons to scroll up and down to read the entire
text. You will be able to change your preferences at any
time later from the Settings>System>Privacy Settings
menu. If the Internet Connection option is disabled
Network/Internet Settings screen will be skipped and
not displayed. If you have any questions, complaints
or comments regarding this privacy policy or its
enforcement, please contact by email at smarttvsecurity@
vosshub.com.
Highlight Next and press OK button on the remote
control to continue and the Network/Internet Settings
menu will be displayed. Please refer to Connectivity
section to configure a wired or a wireless connection.
If you want your TV to consume less power in standby
mode, you can disable the Networked Standby Mode
option by setting it as O. After the settings are completed
highlight Next and press OK button to continue.
On the next screen you need to agree to the terms and
conditions of Freeview Play to make use of the related
services. Scroll the page to read the entire text using the
up/down directional buttons or Programme +/- buttons.
Highlight Yes and press OK on the remote to confirm and
proceed. Highlight No and press OK to proceed without
confirmation. For further requirements for Freeview Play
services refer to the Freeview Play Platform section.
On next screen you can set broadcast types to be
searched, set your encrypted channel searching and time
zone (depending on the country selection) preferences.
Additionally you can set a broadcast type as your favourite
one. Priority will be given to the selected broadcast type
during the search process and the channels of it will
be listed on the top of the channel list. When finished,
highlight Next and press OK to continue.
About Selecting Broadcast Type
To turn a search option for a broadcast type highlight it
and press OK. The checkbox next to the selected option
will be checked. To turn the search option o clear the
checkbox by pressing OK after moving the focus on the
desired broadcast type option.
Digital Aerial: If D. Aerial broadcast search option
is turned on, the TV will search for digital terrestrial
broadcasts after other initial settings are completed.
After the initial settings are completed TV will start to
search for available broadcasts of the selected broadcast
types.
While the search continues current scan results will
be displayed at the bottom of the screen. After all the
available stations are stored, Channels menu will be
displayed. You can edit the channel list according to your
preferences using the Edit tab options or press the Home
button to quit and watch TV.
While the search continues a message may appear, asking
whether you want to sort channels according to the
LCN(*). Select Yes and press OK to confirm.
(*) LCN is the Logical Channel Number system that
organises available broadcasts in accordance with a
recognisable channel number sequence (if available).
Note: Do not turn o the TV while initialising first time
installation. Note that, some options may not be available
depending on the country selection.
Connections
Bringing it all together
Connections
17
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
or online at www.bush-support.co.uk. If you still require further assistance, call one of our experts on 0345 604 0105, a Bush enquiry line.
