Logik L32HE23 User manual

Connecting the Aerial
44Connecting to the Mains Socket 55
Target Region Setting
77
Turning the TV On for the First Time
66
Unpacking
11
Installing the Base Stand
33
Operating Your Remote Control
22
Connect one end of the RF coaxial cable to the aerial socket on
the wall and the other end of the cable to the RF (75Ω) socket at
the rear right side of your TV.
Do not connect the TV to the mains supply until you
have completed all the connections.
1. Connect the mains cable to the mains socket after you have
completed all the connections.
2. At this stage, the TV switches to standby mode. The red LED
indicator will illuminate on the front panel of the TV.
3. In standby mode, press the button on the right side bottom
panel of the TV or on the remote control to turn the TV on. The
red LED indicator will turn blue.
Target Region Setting
Country Code GBR
Primary Region England
Secondary Region
Tertiary Region
London
During tuning your TV may have received signals
from more than one transmitter. If this has occurred
the Target Region Setting screen will be displayed.
This will enable you to select the correct regional
transmission for the local news service that you
require.
Press the buttons to adjust each option's setting
and then press the OK button to confirm.
Well done, your new TV is now ready to use. You will find that there are many exciting features available. To get to know all these
features, please take some time to read the instruction manual provided with your TV.
If after reading the instruction manual you have additional questions related to the use of your TV please call our UK Call Centre on 0844 561 1234.
Our UK Customer Contact Centre is open Monday-Saturday 8am-8pm or Sunday 8am-6pm.
RF Coxial Cable
(not included)
OR
USB HDMI2 HDMI1(ARC) PC IN RF
COMMON INTERFACE (CI)
HEADPHONE PC AUDIO
To mains
socket
Quick Start Guide
Thank you for purchasing your new Logik TV.
Your new TV incorporates the latest technology to enhance your viewing experience. We would suggest that you allow about 20 mins for initial setup.
Please follow this guide for a successful rst time installation.
32” LED TV
L32HE23
This will be shown as GBR for the UK.
This will show the regional country
(e.g. England, Wales, Scotland, NI).
This will allow you to set the region for
your local news service on BBC and ITV
(e.g. London, Beds and Cambs etc).
You may receive signals from more than
one transmitter within the Secondary
Region, (e.g Beds and Cambs may have
Luton or Sandy Heath).
(QSG-L32HE23-131213V2)
The first time you turn the TV on, it will go straight into First Time Installation menu.
First Time Installation
Please ensure aerial is plugged in!
Then press OK button.
OK
Portugal
Rumania
Russian
Serbia
Slovenia
Spain
Switzerland
UK
Sweden
Country
TV : 0 Channel(s)
Channel Tuning
DTV : 3 Channel(s)
Radio : 0 Channel(s)
Data : 0 Channel(s)
36%... 668.75MHz (DTV)
Press MENU to skip.
OK
English
Svenska
Dansk
ýesky
Slovak
Norsk
Suomi
Please select an OSD Language
OK
Home Mode
Shop Mode
Mode Select
1. Press the OK button to start
First Time Installation menu.
2. Press the buttons to
select your desired language to
be displayed on the menu. The
default on-screen menu
language is set as English.
Press the OK button to confirm.
3. Press the buttons to select
your desired mode and then
press the OK button. Press the
button to select Yes to confirm
or the button to select No to
cancel and return to the Mode
Select menu.
4. Press the buttons to
select the country where you
will operate the TV. Press the
OK button to confirm.
5. DTV channel tuning will
commence. This operation may
take up to 3 minutes. The
display will show the progress of
the tuning and the number of
channels found.
The latest eco-friendly power-saving technology will switch off the TV if
device is left on and idle for 4 hours. Please refer to “Auto Standby” under
the “Time Settings” section of the instruction manual for more detail.
Remove all packaging from the TV. Retain the packaging.
If you dispose of it please do so according to any local
regulations.
Make sure the (+) and ( – ) ends
of the batteries match the (+)
and ( – ) ends indicated in the
battery compartment.
1. Press and lift the back cover to open the
battery compartment of the remote
control.
2. Insert two AAA size batteries. Close the
battery compartment cover.
1. Lay the TV down on a flat surface with the back side facing up, and ideally at the edge of a table so that the base of the TV slightly overhangs on it. Please
make sure a soft cushioned material (such as a pillow or thick piece of foam) is placed beneath the screen.
2. To install the TV stand, first attach the stand support to the TV by using 3 screw A. Align with the screw hole then use screws to fix the stand support to the TV.
3. To install the base stand, align the screw holes, then secure with a screw driver (not included) using the 3 screw B provided.
screw in
screw in
Screw A x 3
Screw B x 3
TV Front Base Stand
Front
TV
TV Stand Support
Quick Start Guide
TV Base
Remote Control /
AAA Batteries x 2
Instruction Manual
Screw A x 3
Screw B x 3
Component Adapter Cable
