Bush MEBI55177F User manual

Instruction manual
Built-In Larder
MEBI55177F

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions.
2
You’ll soon be enjoying your new Built-In Larder.
It all begins here, with your instructions. Don’t worry,
there’s nothing too technical coming up. Just simple,
step-by-step guidance to get you up and running quickly.
Sound good? Then let’s get started.
Help and Guidance
We’re here to help you get the most from your Built-In Larder. Should you require any guidance, a
simple solution can often be found online at:
www.bush-support.com
If you still require further assistance, call one of our experts on 0345 257 7271.

3
Contents
22
22
26
27
28
29
30
Care and maintenance
Cleaning and Maintenance
Defrosting
Replacing LED Lighting
Technical Specification
Product support
Before Calling After-Sales Service
Tips for Energy Saving
Help and assistance
Disposal
Guarantee
5
6
6
10
11
14
14
15
16
18
18
19
Safety information
Safety information
Getting to know your
Built-in Larder
Ready? Let’s begin
Product features
Installing your Built-in
Larder
Installation Warnings
Electrical Information (for UK Type
Plug)
During Usage
Shipment and Repositioning
Transport and Changing Position
Using your Built-in Larder
Display and Control Panel
Operating your Fridge
Temperature Adjustment Warnings
Food Storage
1
2
3
4
16
20
23
24
or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions.
4
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of fire / flammable materials
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly

Safety Information 1

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions.
6
Safety information
Important - Please read these instructions fully before installing or
operating
Safety Instructions
General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings,
in the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING: Do not use mechanical
devices or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
WARNING: Do not use electrical
appliances inside the food storage
compartments of the appliance, unless
they are of the type recommended by the
manufacturer.
WARNING: Do not damage the
refrigerant circuit.
WARNING: When positioning the
appliance, ensure the supply cord is not
trapped or damaged.
WARNING: Do not locate multiple
portable socket-outlets or portable power
supplies at the
rear of the appliance.
WARNING: In order to avoid any
hazards resulting from the instability of the
appliance, it must be fixed in accordance
with the following instructions:
If your appliance uses R600a as a
refrigerant (this information will be
provided on the label of the cooler) you
should take care during transportation and
installation to prevent the cooler elements
from being damaged. R600a is an
environmentally friendly and natural gas,
but it is explosive. In the event of a leak due
to damage of the cooler elements, move
your larder away from open flames or heat
sources and ventilate the room where the
appliance is located for a few minutes.
•While carrying and positioning the larder,
do not damage the cooler gas circuit.
•Do not store explosive substances such
as aerosol cans with a flammable
propellant in this appliance.
•This appliance is intended to be
used in household and domestic
applications such as:
-staff kitchen areas in shops, offices and
other working environments.
-farm houses and by clients in hotels,
motels and other residential type
environments.
-bed and breakfast type
environments;
-catering and similar non-retail
applications.
•If the socket does not match the
refrigerator plug, it must be replaced
by the manufacturer, a service agent or
similarly qualified persons in order to
avoid a hazard.
•A specially grounded plug has been
connected to the power cable of your
refrigerator. This plug should be used
with a specially grounded socket of 13
amperes. If there is no such socket in
your house, please have one installed
by an authorised electrician.
Safety information

7
or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.
•This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
•Children aged from 3 to 8 years
are allowed to load and unload
refrigerating appliances. Children are
not expected to perform cleaning or
user maintenance of the appliance,
very young children (0-3 years old)
are not expected to use appliances,
young children (3-8 years old) are
not expected to use appliances safely
unless continuous supervision is given,
older children (8-14 years old) and
vulnerable people can use appliances
safely after they have been given
appropriate supervision or instruction
concerning use of the appliance. Very
vulnerable people are not expected
to use appliances safely unless
continuous supervision is given.
•If the supply cord is damaged, it must
be replaced by the manufacturer, an
authorised service agent or similar
qualified persons, in order to avoid a
hazard.
•This appliance is not intended for use
at altitudes exceeding 2000 m.
To avoid contamination of food, please
respect the following instructions:
•Opening the door for long periods can
cause a significant increase of the
temperature in the compartments of
the appliance.
•Clean regularly surfaces that can come
in contact with food and accessible
drainage systems.
•Store raw meat and fish in suitable
containers in the refrigerator, so that it
is not in contact with or drip onto other
food.
•If the refrigerating appliance is left
empty for long periods, switch off,
defrost, clean, dry, and leave the door
open to prevent mould developing
within the appliance.
Safety information
Important - Please read these instructions fully before installing or
operating

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions.
8

Getting to know your Built-In Larder 2

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions.
10
Getting to know your Built-In Larder
You’ll be up and running in no time
Ready? Let’s begin...
Please read these instructions carefully. They
contain important information which will help you
get the best from your Built-In Larder and ensure
safe and correct installation and operation.
If you require any further assistance, our technical
experts are happy to help. For full details, refer to
the product support section at the end of these
instructions.
Getting to know your Built-In Larder

11
or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.
Getting to know your Built-In Larder
You’ll be up and running in no time
Getting to know your Built-In Larder
1
2
3
4
5
4
5
6
7
8
1. Control panel
2. Turbo fan
3. Refrigerator shelves x 4
4. Crisper covers x 2
5. Crispers x 2
6. Left & Right stays
7. Bottle shelf x 1
8. Door shelves x 4
9. Egg holder x 1
9
This presentation is only for information
about the parts of the appliance. Parts may
vary according to the appliance model.
General notes:
Fresh Food Compartment (Fridge):
Most e󰀩cient use of energy is ensured
in the conguration with the drawers in
the bottom part of the appliance, and
shelves evenly distributed, position
of door bins does not a󰀨ect energy
consumption.

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions.
12
1.1 Dimensions
560 - 570 mm
560 mm
(recommended)
min. 550 mm
1770 - 1790 mm
max 2100 mm
min 200 cm
2
min 40 mm
545 mm
540 mm
1770 mm
* 1770 - 1778 for metal top
cover

Installing your Built-In Larder 3

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions.
14
Installation warnings
Before using your fridge for the first time, please
pay attention to the following points:
• The operating voltage for your fridge is 220-
240 V at 50Hz.
• The plug must be accessible after installation.
• Your fridge may have an odour when it is
operated for the first time. This is normal and
the odour will fade when your fridge starts to
cool.
• Before connecting your fridge, ensure that
the information on the data plate (voltage
and connected load) matches that of the
mains electricity supply. If in doubt, consult a
qualified electrician.
• Insert the plug into a socket with an efficient
ground connection. If the socket has no
ground contact or the plug does not match,
we recommend you consult a qualified
electrician for assistance.
• The appliance must be connected with a
properly installed fused socket. The power
supply (AC) and voltage at the operating point
must match with the details on the name
plate of the appliance (the name plate is
located on the inside left of the appliance).
• We do not accept responsibility for any
damages that occur due to ungrounded
usage.
• Place your fridge where it will not be exposed
to direct sunlight.
• Your fridge must never be used outdoors or
exposed to rain.
• Your appliance must be at least 50 cm away
from stoves, gas ovens and heater cores, and
at least 5 cm away from electrical ovens.
• If your fridge is placed next to a deep freezer,
there must be at least 2 cm between them
to prevent humidity forming on the outer
surface.
• Do not cover the body or top of fridge with
lace. This will affect the performance of your
fridge.
• Clearance of at least 150 mm is required
at the top of your appliance. Do not place
anything on top of your appliance.
• Do not place heavy items on the appliance.
• Clean the appliance thoroughly before use
(see Cleaning and Maintenance).
• Before using your fridge, wipe all parts with
a solution of warm water and a teaspoon of
sodium bicarbonate. Then, rinse with clean
water and dry. Return all parts to the fridge
after cleaning.
• The installation procedure into a kitchen
unit is given in the installation manual. This
product is intended to be used in proper
kitchen units only.
Electrical information (For UK type
plug)
Warning! This appliance must be earthed.
The mains lead of this appliance has been fitted
with a specially earthed plug.
Important: Do not use the appliance
without the fuse cover in position. Should the fuse
need to be replaced, it must be replaced with a
13A fuse, ASTA approved to BS1362.
The plug must be used with a specially earthed
socket of 13 amperes. If there is no such socket
in your house, please have one installed by an
authorised electrician.
The mains lead of this
appliance has been fitted
with a BS 1363A 13A fused
plug. To change a fuse in
this type of plug, follow
the steps below:
1. Remove the fuse cover
and fuse.
2. Fit replacement 13A fuse, ASTA approved to BS
1362 type, into the fuse cover.
3. Replace fuse cover.
Installing your Built-In Larder
Installing your Built-In Larder
Bringing it all together

15
or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.
Installing your Built-In Larder
Bringing it all together
During Usage
•Do not connect your fridge to the mains
electricity supply using an extension lead.
•Do not use damaged, torn or old plugs.
•Do not pull, bend or damage the cord.
•Do not use plug adapter.
•This appliance is designed for use by adults.
Do not allow children to play with the
appliance or hang off the door.
•Never touch the power cord/plug with wet
hands. This may cause a short circuit or
electric shock.
•Do not place explosive or flammable material
in your fridge. Place drinks with high alcohol
content vertically in the fridge compartment
and make sure their tops are tightly closed.
Old and Out-of-order Fridges
•If your old fridge or freezer has a lock, break
or remove the lock before discarding it,
because children may get trapped inside it
and may cause an accident.
•Old fridges and freezers contain isolation
material and refrigerant with CFC. Therefore,
take care not to harm environment when you
are discarding your old fridges.
CE Declaration of conformity
We declare that our products meet the applicable
European Directives, Decisions and Regulations
and the requirements listed in the standards
referenced.
Disposal of your old appliance
The symbol on the product or on its
packaging indicates that this product
may not be treated as household waste.
Instead it shall be handed over to the
applicable collection point for the recycling of
electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will
help prevent potential negative consequences
for the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. For more detailed
information about recycling of this product, please
contact your local city offi ce, your household
waste disposal service or the shop where you
purchased the product.
Packaging and the Environment
Packaging materials protect your machine
from damage that may occur during
transportation. The packaging materials
are environmentally friendly as they are recyclable.
The use of recycled material reduces raw material
consumption and therefore decreases waste
production.
Notes:
•Please read the instruction manual carefully
before installing and using your appliance. We
are not responsible for the damage occurred
due to misuse.
•Follow all instructions on your appliance and
instruction manual, and keep this manual in a
safe place to resolve the problems that may
occur in the future.
•This appliance is produced to be used in
homes and it can only be used in domestic
environments and for the specified purposes.
It is not suitable for commercial or common
use. Such use will cause the guarantee of the
appliance to be cancelled and our company
will not be responsible for any losses incurred.
•This appliance is produced to be used in
houses and it is only suitable for cooling /
storing foods. It is not suitable for freezing
foodstuffs, for commercial or common use
and/or for storing substances except for food.
•Our company is not responsible for any losses
incurred by inappropriate usage of the
appliance.
Installing your Built-In Larder

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions.
16
Shipment and Repositioning
Transportation and Changing
Positioning
• The original packaging and foam may be kept
for re-transportation (optional).
• Fasten your appliance with thick packaging,
bands or strong cords and follow the
instructions for transportation on the
packaging.
• Remove all movable parts (shelves,
accessories, vegetable bins, and so on) or fix
them into the appliance against shocks using
bands when re-positioning or transporting.
Always carry your appliance in the upright
position.
Installing your Built-In Larder
Bringing it all together
Installing your Built-In Larder

Using your Built-In Fridge 4

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions.
18 Functions
Display and Control Panel
1 2 3 4
If your product has lighting
When the product is plugged in for the first
time, the interior lights may turn on 1 minute
late due to opening tests.
Using the Control Panel
1. Fridge temperature set button
2. Super cooling symbol (Super cooling LED)
3. Alarm symbol (Alarm LED)
4. Fridge adjusted temperature indicator
Operating your Fridge
Fridge Temperature Set Button
This button allows setting temperature of the
fridge. In order to set values for fridge partition,
press this button. Use this button also to activate
super cooling mode.
Alarm symbol (Alarm LED)
In case of a problem within the fridge, the alarm
led will release red light.
Super Cooling Mode
When would it be used?
• To cooling huge quantities of food.
• To cooling fast food.
• To cooling food quickly.
• To store seasonal food for a long time.
How to use?
• Press temperature set button until super
cooling light comes on.
• Super cooling led will light during this mode.
• For optimal appliance performance in
maximum cooling capacity, set the appliance
to active super cooling mode 6 hours before
you put the fresh food into the fridge.
During this mode:
If you press temperature set button, the mode will
be cancelled and the setting will be restored from
2.
The super cooling mode will be cancel
automatically after 6 hours or when cooling
sensor temperature falls below 2°C.
Fridge Temperature Settings
• The initial temperature of the setting display is
5°C.
• Press fridge setting button once.
• Every time you press the button, the setting
temperature will increase. (2°C, 4°C, 5°C,
6°C, 8°C, Super cooling)
• If you press fridge setting button until super
cooling symbol is displayed on your fridge.
• Settings display and you do not press any
button within the following 3 seconds.
• Super cooling will blink.
• If you keep on pressing, it will restart from last
value.
Using your Built-In Larder
Getting the most from your appliance

19
or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.
Temperature Adjustment Warnings
• It is not recommended that you operate your
fridge in environments colder than 10°C in
terms of its efficiency.
• Do not start another adjustment before
completing one adjustment.
• Temperature adjustments should be made
according to the frequency of door openings
and the quantity of food kept inside the fridge.
• When you first switch on the appliance, allow
it to operate for 24 hours in order to reach
normal operating temperature. During this
time, do not open the door or place a lot of
food inside the appliance.
• If the appliance is switched off or unplugged,
wait at least 5 minutes before plugging the
appliance in or restarting it in order to prevent
damage to the compressor.
• Your fridge is designed to operate within
specific ambient temperature ranges,
according to the climate class stated on the
information label. We do not recommend
operating your fridge outside the stated
temperatures value limits.
• Your appliance is designed to operate in the
ambient temperature (ST/SN = 10°C - 38°C)
intervals stated in the standards, according to
the climate class displayed on the information
label. We do not recommend operating your
appliance out of the stated temperature limits
in terms of cooling effectiveness.
Climate class and meaning:
T (tropical): This refrigerating appliance is intended
to be used at ambient temperatures ranging from
16°C to 43°C.
ST (subtropical): This refrigerating appliance is
intended to be used at ambient temperatures
ranging from 16°C to 38°C.
N (temperate): This refrigerating appliance is
intended to be used at ambient temperatures
ranging from 16°C to 32°C.
SN (extended temperate): This refrigerating
appliance is intended to be used at ambient
temperatures ranging from 10°C to 32°C.
The Turbo Fan
Do not block the air inlet and outlet openings
when storing food, otherwise air circulation
provided by the turbo fan will be impaired.
Turbo fan
The Fresh Dial
If the crisper is full, the fresh dial located in front of
the crisper should be opened. This allows the air in
the crisper and the humidity rate to be controlled,
to increase the life of food within.
Fresh dial
The dial, located behind the shelf, must be
opened if any condensation is seen on the
glass shelf.
Visual and text descriptions in the accessories
section may vary according to the model of
your appliance.
Using your Built-In Larder
Getting the most from your appliance
Functions

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions.
20
Using your Built-In Larder
Getting the most from your appliance
Food Storage
• To reduce humidity and avoid the
consequent formation of frost, always store
liquids in sealed containers in the refrigerator.
Frost tends to concentrate in the coldest
parts of the evaporating liquid and, in time,
your appliance will require more frequent
defrosting.
• Never place warm food in the refrigerator.
Warm food should be allowed to cool at
room temperature and should be arranged
to ensure adequate air circulation in the
refrigerator compartment.
• Make sure no items are in direct contact with
the rear wall of the appliance as frost will
develop and packaging will stick to it. Do not
open the refrigerator door frequently.
• We recommend that meat and clean fish
are loosely wrapped and stored on the glass
shelf just above the vegetable bin where the
air is cooler, as this provides the best storage
conditions.
• Store loose fruit and vegetable items in the
crisper containers.
• Store loose fruit and vegetables in the crisper.
• Storing fruit and vegetables separately helps
prevent ethylene-sensitive vegetables (green
leaves, broccoli, carrot, etc.) being affected
by ethylene-releaser fruits (banana, peach,
apricot, fig etc.).
• Do not put wet vegetables into the
refrigerator.
• Storage time for all food products depends
on the initial quality of the food and an
uninterrupted refrigeration cycle before
refrigerator storage.
• To avoid cross-contamination do not store
meat products with fruit and vegetables.
Water leaking from meat may contaminate
other products in the refrigerator. You should
package meat products and clean any
leakages on the shelves.
• Do not put food in front of the air flow
passage.
• Consume packaged foods before the
recommended expiry date.
• For normal working conditions, it will be
sufficient to adjust the temperature setting of
your refrigerator to +4°C.
• The temperature of the fridge compartment
should be in the range of 0-8°C, fresh foods
below 0°C are iced and rotted, bacterial load
increases above 8°C, and spoils.
• Do not put hot food in the refrigerator
immediately, wait for the temperature to pass
outside. Hot foods increase the degree of
your refrigerator and cause food poisoning
and unnecessary spoiling of the food.
• Meat, fish, etc. should be store in the chiller
compartment of the food, and the vegetable
compartment is preferred for vegetables. (if
available)
• To prevent cross contamination, meat
products and fruit vegetables are not stored
together.
• Foods should be placed in the refrigerator
in closed containers or covered to prevent
moisture and odors.
NOTE: Potatoes, onions and garlic should not
be stored in the refrigerator.
The table below is a quick guide to show you the
most efficient way to store the major food groups
in your refrigerator compartment.
Food Maximum
storage time
How and where to
store
Vegetables and
fruits 1 week Vegetable bin
Meat and fish 2 - 3 Days
Wrap in plastic foil,
bags, or in a meat
container and store
on the glass shelf
Fresh cheese 3 - 4 Days On the designated
door shelf
Butter and
margarine 1 week On the designated door shelf
Bottled products
e.g. milk and
yoghurt
Until the
expiry date
recommended
by the producer
On the designated
door shelf
Eggs 1 month On the designated
egg shelf
Cooked food All shelves
Using your Built-In Larder
