BUTURE BR400 User manual
Language
01-07
08-14
15-21
22-28
29-35
English
Deutsch
Français
Italiano
Español
日本語36-42
Package Content
1 x Jump Starter 1 x Smart Jumper Cables
1 x Type C Charging Cable 1 x EC5 Cigarette Lighter
1 x Storage Box1 x User Manual
User Manual
Car Battery Jump Starter
EN 01
Introduction
Key Features
Thank you for purchasing BUTURE BR400 car jump starter. Please read the user
manual carefully before you start to use the product.
★APowerful Jump Starter: Car Jump Starter with 1600 amps peak current can jump
starts 12V cars, SUV, truck or van (8L petrol or 7L diesel engine) in seconds up to 25
times.
★Dual USB Charger with QC3.0 & 5V 2.4A: Ensures the fastest charging efficiency,
4x faster than conventional charger. Backward compatible with QC 1.0 and 2.0
★Safety Protection: Premium cells, circuitry and safety features protect you and
your device from surge or short circuits.
★LifeSaver Kits: 4 modes LED light: flashlight, strobe light, SOS signal light, and
warning light, built-in safety hammer for emergency.
EN 02
Know Your Product
Powerful Circuit Protection System - Smart Clamps
① Jump Starting Port
② LED Light
③ QC3.0 USB Output
④ 5V/2.4A USB Output
①Red Jumper Cable (+)
②Black Jumper Cable (-) ⑤TYPE-C Input
⑥ Power Switch
⑦Battery Indicator
⑧Safety Hammer
①②③④⑤⑥⑦①②③START
③ Smart Clamp Plug
EN 03
Getting Started
Charging your Jump Starter
1. Please use the provided Type C Cable to charge the product.(Charging adapter is
not included, 5V/2A or 9V/2A adapter is recommended )
2. Using a 9V/2A adaptor, it will take approximately 4 hours to fully charge the unit. In
order to extend the battery life it is recommended to fully charge the unit every 3 months.
Turn On your Jump Starter
Short press the power switch to boot the system, the battery indicator lights will turn
on. For energy saving, the system will turn to standby mode if there is no operation
within 20 seconds.
4 Modes LED Light
Long press the power switch more than 3 seconds to turn on the light mode. There
are 4 modes which are ON, SOS, Strobe, and Warning, simply short press the
power switch button to change the 4 modes or turn off the light mode. And you can
also press the power switch button for more than 3 seconds to turn off the light mode.
QC3.0 & 5V 2.4A Dual USB Output
This portable jump starter is also equipped with two smart USB outputs that provide
the fastest charging speed(USB1 - QC3.0:5V3A/9V2A/12V1.5A; USB2 - 5V2.4A) for
your portable electronic devices, such as phones,tablets, bluetooth earphones, etc
12V/10A EC5 Cigarette Lighter
Power your devices such as Air Compressor Pump, Car Vacuum Cleaner,etc. Just
plug the adapter into the EC5 Output port and connect the other end with the
device(up to 12V/10A)
EN 04
Start your Car
1.Insert the plug of the smart clip completely
into the jump starter, the green and red lights
flash alternately.
2.Correctly clip the red and black clamps to the
electrodes of the car battery (red to positive and
black to negative)(The green light stays on)
3.Start the vehicle.
4.When the vehicle is started, remove the jumper
cable from the vehicle battery immediately.
EN 05
Security Indication
In any of the following situations, the smart clamp turns on protection mode:
1. Use the original smart clamp to start the car.
2. DO NOT use this unit if any cable clamp or cord is damaged.
3. Start only for 12V vehicles,or it will cause serious damages to the unit.
4. Do not jump start your car when the battery capacity of BR400 is lower than 30%.
5. Do not connect two clamps together when the starter is powered on. And do not
connect both cable clamps to the same piece of metal.
6. If the engine does not start on the first try, disconnect it from the car battery and wait
for at least 20 seconds before reconnecting. Maximize three attempts in two minutes.
7. Once the engine is successfully started, disconnect the clamps within 30 seconds.
LED Indicator
The red/green led will flash
The green light is always on
The red light is always on
The red light flashes slowly
The red LED flashes quickly
The green light flashes slowly
Situations
Ready to work
Work status
1.battery clamp is reversely connected
--- check whether the clip is reversely connected
2.The clamp is short-circuited
---check whether two clamps together connect or
connect both cable clamps to the same piece of metal
Back charge protection, the voltage of the car battery is
higher than 12.6V
-No jump starter needed, the car battery is enough to
start your car
The temperature of the clamp exceeds 65(+/-5)degrees
--- remove the clamp until the red-green led flash
The voltage of the starter is too low
--try to replace the startup power supply or change it in
time
EN 06
Warranty
Our company provides customers with warranty of 24 months from the date of
purchase.
Contact US
For additional assistance or warranty cover claim, please contact us:
E-Mail: support@ibuture.com
FAQ & Trouble Shooting
Q: Why the indicator is always flashing in red and green? Why the indicator does not
turn into green light? Why I can not start my car?
A: Please note this product only works with a dead/drained battery(12V).
Q: How to turn off this power pack?
A: This power pack will power off automatically when no load or charging is complete.
Q: What kind of adapter should I use?
A: You can use the charger of your phone or tablet
Q: How many times can this product start the vehicle with full capacity?
A: Up to 25 times at 25℃/ 77℉.(The times may vary based on working temperature )
Q: What is the working temperature range ?
A: -20℃~60℃/ -4℉~140℉Care and Maintenance
1. DO NOT put the product under direct sunlight or hot areas.
2. DO NOT drop or knock your car jump starter.
3. DO NOT disassemble the equipment, it may cause damage.
4. DO NOT use chemicals or detergents to clean the product.
5. DO NOT place the products in high temperature environment for long. The
operating temperature: -20℃~60℃/ -4℉~140℉.
6. Check the power of the product at least every three months, and charge the
product in time.
EN 07
DE 08
Lieferumfang
1 x Tragbare StarthilfePowerbank
（Multifunktional）
1 x Smart Clamps (Starthilfekabel)
1 x USB TYP C / USB A alles
in einem Kabel 1 x EC5 Zigarettenanzünder
1 x Aufbewahrungskiste1 x Bedienungsanleitung
