C & K Systems SN914-SZR User manual

1
Mounting Procedure
To mount the SN914-SZR, orient
theunitasshowninFigure2.Loosen
the cover retaining screw on the
front of the Receiver and open the
front panel. The front and rear
housingsmaybeseparatedforeasier
installation.Removetheknock-outs
for wiring the Receiver to the con-
trol panel.
Use the rear cover as a template
to mark the mounting holes (see
Figure 2). Drill the holes as neces-
sary. The hole at the top center of
the rear housing is designed for
mounting the Receiver to the wall.
The tab also serves as a removable
stand-off when mounting the Re-
ceivertothetopoftheControlPanel
housing (see Figure 1). The plastic
tab should be removed as it will
interfere with the proper closing of
the control panel door.
Receiver Wall Tamper
Both a cover and a wall tamper are
providedwithasingletamperswitch.
To
activate the wall tamper , remove
the knock-out in the rear housing
and install a screw in the wall, leav-
ing enough of the screw head exposed to depress the tamper switch
when the cover is closed.
Wiring the Receiver
Pullthe6-wirecable(common,
power,alarm,and trouble) and
the 2-wire cable (tamper)
through the rear cover. Mount
the Receiver in the desired lo-
cation as shown in Figure 1.
Connect the SN914-SZR Re-
ceiver to the Control Panel as
shown in Figure 3. Be sure to
observe polarity. The SN914-
SZR derives its power from
the Control Panel via the V+
(to panel AUX+) and V- (to
panelCorGND)terminals.The
SN914-SZR Receiver is elec-
tronicallyprotectedagainstre-
verse polarity.
500 ft. max.
(152.4 m)
Control Panel
Door
Removable
Mounting
Tab (Stand-
off)
RF Receiver
Figure 1 - Mounting Location
Cover Retaining Screw
SpreadNet®
Model SN914-SZR
RF Single Zone Receiver
Installation Instructions
The SpreadNet®Model SN914-SZR is a Single Zone Receiver in
the C&K family of Spread Spectrum RF products. The SN914-SZR
is a stand-alone product which supports up to 32 SpreadNet trans-
mitters. The SN914-SZR provides both a Form "C" Alarm Relay
output and a Form "A" Trouble Relay output. The SN914-SZR is not
suitable for use with smoke detectors.
Special features include an alarm and trouble event memory. The
SN914-SZR Single Zone Receiver detects alarms, tamper, low bat-
tery, and no check-in from the various transmitters (sensors).
Features
• Easy Installation • Up to 32 Devices
• Form "C" Alarm Relay • Individual Device Alarm/
Form "A" Trouble Relay Trouble Indication Using
SN900 Programmer
• EEPROM Memory • Alarm/Trouble Memory
• Uses Spacial Diversity
Antennas for Improved • No Check-In and Low Battery
Reception Supervision
• 900 MHz Spread Spectrum • Wall/Cover Tamper
• Noise & RF Immunity • Suitable for UL Grade B
Service
Mounting Location
The RF Receiver may either be mounted on the wall or on the control
panel housing. For optimum performance, the Receiver should be
mounted on the wall. The distance between the Receiver and Control
Panel
must not exceed 500 ft. (152.4 m).
Receiver orientation is not a problem, as the unique antenna design
of the SpreadNet RF Receiver automatically compensates for vari-
ations in signal direction. Two antennas orientated at right angles
virtually eliminate problems associated with noise and signal fading.
When choosing a location to install the SN914-SZR RF Receiver,
you should avoid areas near screens, metal window frames, circuit
breaker boxes, metal air conditioner and heater ducts. These areas
interfere with the receiver's ability to pick up signals or are sources
of high noise and radio frequency interference.
Figure 2 - Receiver
Housing
Mounting Holes
Mounting Wall
Rear Cover
Knock-outs
Wall Tamper
Knock-out
Front Cover
Form "A"
Trouble Relay
Form "C"
Alarm Relay
Figure 3 - Wiring the Receiver
Programming
Connector P1
Tamper
Switch
Common (Panel)
AUX+ (Panel)
Relay Configuration
Whenwiringthe SN914-SZR, a number ofconfigurationsareavailable
for connecting and monitoring for Alarm, Tamper, and Trouble con-
ditions. The diagrams below illustrate the proper method of connect-
ing the Receiver to the Control Panel. In each diagram, R represents
the End of Line Resistor.
R
R
Zone Input (Panel)
Legend:
Short = Alarm
Open = Trouble
R
Legend:
Short = Tamper
Open = Alarm
Zone Input (Panel)
Zone Input (Panel)
Legend:
Short = Alarm or
Tamper
Open = Trouble
R
Zone Input (Panel)
Legend:
Open = Alarm
Tamper (Form "B" Relay)
AUX+ Com
(Control Panel) AUX+ Com
(Control Panel)
AUX+ Com
(Control Panel)
AUX+ Com
(Control Panel)

-2-
Specifications
Power Requirements: Operating Frequency:
210 mA at 9.5 - 14 VDC 902 - 928 MHz Spread Spectrum
Dimensions: Operating Environment:
7.875" x 4.125" x 1.75" 32° to 140° F (0° to 60° C)
(20 cm x 10.5 cm x 4.5 cm) Up to 95% relative humidity
(non-condensing)
Weight:
11 oz. (311 g) Alarm Relay:
Form C, Energized (NC/C/NO)
Trouble Relay: 125 mA, 24 VDC
Form A, Energized (NC)
250 mA, 24 VDC Tamper Relay:
Form B, Energized (NO)
Approvals: 50 mA, 30 VDC
FCC certified
UL listed
IC
C&K is a registered trademark of C&K Components, Inc.
SpreadNet is a registered trademark of C&K Systems, Inc.
Copyright 1995 C&K Systems, Inc.
All Rights Reserved
Printed in Hong Kong
P/N 5-051-337-00 Rev A
FCC NOTICE
The Model SN914-SZR generates and uses radio frequency energy. If not installed and used in
accordance with the manufacturer's instructions, it may cause interference to radio and television
reception.TheReceiverhasbeentestedandfound tocomplywiththespecificationsinPart15ofFCC
Rules for Class B Computing Devices and FCC Part 15 Subpart C, Specifications for Intentional
Spread Spectrum Radiators.
If this equipment causes interference to radio or television reception - which can be determined by
turningtheequipmentonandoff-theinstallerisencouragedtocorrecttheinterferencebyoneormore
of the following measures: 1) Reorient the antenna of the radio/television. 2) Connect the AC
transformer to a different outlet so the control panel and radio/television are on different branch
circuits. 3) Relocate the control panel with respect to the radio/television.
If necessary, the installer should consult an experienced radio/television technician for additional
suggestions, or send for the "Interference Handbook" prepared by the Federal Communications
Commission. This booklet is available from the U.S. Government Printing Office, Washington D.C.,
20402, stock number 004-000-00450-7.
CAUTION: C&K does not support field changes or modifications to any of the SpreadNet RF
equipment unless they are specifically covered in this manual. All adjustments must be made at the
factoryunderthe specificguidelinesset forth inourmanufacturing processes.Anymodification to the
equipment could void the user's authority to operate the equipment and render the equipment in
violation of FCC Part 15, Subpart C, 15.247.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
INDUSTRY CANADA
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the Radio Interference Regulations of the Canadian Department of
Communications.
Leprésentappareilnumérquen'émetpasdebruitsradioélectriquesdépassantleslimitesapplicables
aux appareils numérique de Classe B prescrites dans le règlement sur le brouillage radioélectrique
edicte par le Ministere des Communications du Canada.
LIMITED WARRANTY
Seller warrants its products to be in conformance with its own plans and specifications and to be free
fromdefectsinmaterialsandworkmanship under normaluseandservicefor18monthsfrom the date
stamp control on the product or for products not having a C&K Systems date stamp, for 12 months
fromthedate oforiginalpurchase, unlesstheinstallation instructionsorcatalogue setsfortha shorter
period, in which case the shorter period shall apply. Seller's obligation shall be limited to repairing or
replacing,atitsoption,freeofchargeformaterialsorlabor,anypartwhichisprovednotincompliance
with Seller's specifications or proves defective in materials or workmanship under normal use and
service. This warranty is void if the product is altered or improperly repaired or serviced by anyone
other than C&K Systems factory service. For warranty service, return the product transportation
prepaid to C&K Factory Service, 107 Woodmere Road, Folsom, CA, 95630.
THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR OTHERWISE, WHICH EXTEND BEYOND THE DESCRIP-
TION ON THE FACE HEREOF. In no case shall Seller be liable to anyone for any consequential or
incidental damages for breach of this or any other warranty, express or implied, or upon any other
basisof liability whatsoever,even if theloss or damageis caused bySeller's own negligenceor fault.
Seller does not represent that its product may not be compromised or circumvented; that the product
will prevent any personal injury or property loss by burglary, robbery, fire or otherwise; or that the
product will in all cases provide adequate warning or protection. Buyer understands that a properly
installed and maintained alarm may only reduce the risk of burglary, robbery, or fire without warning,
but it is not insurance or a guarantee that such will not occur or that there will be no personal injury
or property loss as a result. CONSEQUENTLY, SELLER SHALL HAVE NO LIABILITY FOR ANY
PERSONAL INJURY, PROPERTY DAMAGE, OR OTHER LOSS BASED ON A CLAIM THAT THE
PRODUCT FAILED TO GIVE WARNING. However, if Seller be held liable, whether directly or
indirectly, for any loss or damage arising under this Limited Warranty or otherwise, regardless of
cause or origin, Seller's maximum liability shall not in any case exceed the purchase price of the
product, which shall be fixed as liquidated damages and not as a penalty, and shall be the complete
and exclusive remedy against Seller.
Thiswarrantyreplacesall previouswarrantiesandis theonlywarrantymade by C&KSystemson this
product. No increase or alteration, written or verbal, of the obligation of this warranty is authorized.
Figure 4 - Connecting the RF Programmer
Programming and Set-Up
The SN914-SZR Receiver is programmed using the SN900-PROG
Handheld Programmer. Connect the SN900-PROG Programmer to
connector P1 on the Receiver, as shown above, using the intercon-
nect cable supplied with the Programmer. In order to determine the
Channel # and Property Code to be used, the Programmer must be
connected to the Receiver prior to programming any of the system's
transmitters.
When selection of the Channel and Property Codes has been suc-
cessfully completed, the system transmitters may be programmed.
Refer to the Installation Instructions included with each Transmitter
for proper setup.
Programming the Receiver
Program the SN914-SZR Receiver following the instructions out-
lined in the SN900-PROG RF Programmer Programming Manual.
Testing the Transmitter and Receiver
Aftertheindividualtransmittershavebeeninstalledandprogrammed,
the RF Programmer can be used with the RF Receiver to measure
transmitter reception characteristics. For additional details, refer to
the SN900-PROG RF Programmer Programming Manual (P/N 5-051-
136-00).
Termination Summary Label
After the system has been installed, programmed and tested, the
installer should complete the Termination Summary Label, included
with the installation kit. A partial sample of the Termination Label is
shown below with an assortment of zones filled out.
Property Code: Identifies the Transmitter and Receiver as belonging
to a particular system.
Transmitter Location:
Thephysicallocationofthe
Transmitter within the pre-
mises.
TX (Transmitter) Type:
Which of the various
SpreadNet Transmitters is
usedinthatparticularloca-
tion.(i.e.Door,PIR,Smoke,
etc.)
Check-InInterval:TheSu-
pervisory Rate for all Transmitters (in seconds). May range from 30 to
300 seconds in 10 second intervals, or 0 for unsupervised.
SNR: The Signal-to-Noise Ratio of the Transmitter showing Signal
strength and Noise level in decibels (dB).
Battery Date: The date the batteries were installed or last replaced.
Upon completion, the label may then be placed inside the rear cover of the
RF Receiver or inside the Control Panel for future reference.
NOTE: The SN914-SZR Receiver is suitable for UL Grade B service.
