Cabletron Systems WPIM-DDS Programming manual

WPIM-DDS
LOCAL MANAGEMENT GUIDE

WPIM-DDS Local Management Guide i
NOTICE
Cabletron Systems reserves the right to make changes in specifications and other information
contained in this document without prior notice. The reader should in all cases consult Cabletron
Systems to determine whether any such changes have been made.
The hardware, firmware, or software described in this manual is subject to change without notice.
IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FORANY INCIDENTAL,
INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT
NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR
THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN
ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH
DAMAGES.
 Copyright 1996 by Cabletron Systems, Inc., P.O. Box 5005, Rochester, NH 03866-5005
All Rights Reserved
Printed in the United States of America
Order Number: 9031710 September 1996
SPECTRUM , LANVIEW , MicroMMAC , and BRIM are registered trademarks, and Element
Manager , EPIM , EPIM-A , EPIM-F1 , EPIM-F2 , EPIM-F3 , EPIM-T , EPIM-X , FOT-F , FOT-F3 ,
HubSTACK , SEH , SEHI , TMS-3, and WPIM are trademarks of Cabletron Systems, Inc.
All other product names mentioned in this manual may be trademarks or registered trademarks of
their respective companies.
Printed on Recycled Paper

Notice
ii WPIM-DDS Local Management Guide
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment.
This equipment uses, generates, and can radiate radio frequency energy and if not installed in
accordance with the operator’s manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause interference in which case the user
will be required to correct the interference at his own expense.
WARNING: Changes or modifications made to this device which are not expressly approved by the
party responsible for compliance could void the user’s authority to operate the equipment.
DOC NOTICE
This digital apparatus does not exceed the ClassA limits for radio noise emissions from digital
apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique
édicté par le ministère des Communications du Canada.
VCCI NOTICE
This equipment is in the 1st Class Category (information equipment to be used in commercial and/or
industrial areas) and conforms to the standards set by the Voluntary Control Council for Interference
by Information Technology Equipment (VCCI) aimed at preventing radio interference in commercial
and/or industrial areas.
Consequently, when used in a residential area or in an adjacent area thereto, radio interference may be
caused to radios and TV receivers, etc.
Read the instructions for correct handling.

Notice
WPIM-DDS Local Management Guide iii
CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT
IMPORTANT: Before utilizing this product, carefully read this License Agreement.
This document is an agreement between you, the end user, and Cabletron Systems, Inc. (“Cabletron”)
that sets forth your rights and obligations with respect to the Cabletron software program (the
“Program”) contained in this package. The Program may be contained in firmware, chips or other
media. BY UTILIZING THE ENCLOSED PRODUCT,YOU ARE AGREEING TO BECOME
BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES THE LICENSE AND
THE LIMITATION OF WARRANTYAND DISCLAIMER OF LIABILITY. IFYOU DO NOT
AGREE TO THE TERMS OF THIS AGREEMENT, PROMPTLY RETURN THE UNUSED
PRODUCT TO THE PLACE OF PURCHASE FOR A FULL REFUND.
CABLETRON SOFTWARE PROGRAM LICENSE
1. LICENSE. You have the right to use only the one (1) copy of the Program provided in this
package subject to the terms and conditions of this License Agreement.
You may not copy, reproduce or transmit any part of the Program except as permitted by the
Copyright Act of the United States or as authorized in writing by Cabletron.
2. OTHER RESTRICTIONS. You may not reverse engineer, decompile, or disassemble the
Program.
3. APPLICABLE LAW. This License Agreement shall be interpreted and governed under the laws
and in the state and federal courts of New Hampshire. You accept the personal jurisdiction and
venue of the New Hampshire courts.
EXCLUSION OF WARRANTY AND DISCLAIMER OF LIABILITY
1. EXCLUSION OF WARRANTY. Except as may be specifically provided by Cabletron in
writing, Cabletron makes no warranty, expressed or implied, concerning the Program (including
its documentation and media).
CABLETRON DISCLAIMS ALL WARRANTIES, OTHER THAN THOSE SUPPLIED TO
YOU BY CABLETRON IN WRITING, EITHER EXPRESSED OR IMPLIED, INCLUDING
BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, WITH RESPECT TO THE PROGRAM, THE
ACCOMPANYING WRITTEN MATERIALS, AND ANY ACCOMPANYING HARDWARE.
2. NO LIABILITY FOR CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL
CABLETRON OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER
(INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS,
PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, SPECIAL,
INCIDENTAL, CONSEQUENTIAL, OR RELIANCE DAMAGES, OR OTHER LOSS)
ARISING OUT OF THE USE OR INABILITY TO USE THIS CABLETRON PRODUCT,
EVEN IF CABLETRON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, OR
ON THE DURATION OR LIMITATION OF IMPLIED WARRANTIES, IN SOME
INSTANCES THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO
YOU.

Notice
iv WPIM-DDS Local Management Guide
UNITED STATES GOVERNMENT RESTRICTED RIGHTS
The enclosed product (a) was developed solely at private expense; (b) contains “restricted computer
software” submitted with restricted rights in accordance with Section 52227-19 (a) through (d) of the
Commercial Computer Software - Restricted Rights Clause and its successors, and (c) in all respects
is proprietary data belonging to Cabletron and/or its suppliers.
For Department of Defense units, the product is licensed with “Restricted Rights” as defined in the
DoD Supplement to the Federal Acquisition Regulations, Section 52.227-7013 (c) (1) (ii) and its
successors, and use, duplication, disclosure by the Government is subject to restrictions as set forth in
subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at
252.227-7013. Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03867-0505.

WPIM-DDS Local Management Guide v
CONTENTS
CHAPTER 1 INTRODUCTION
1.1 Using This Manual.......................................................................1-1
1.2 Document Conventions...............................................................1-2
1.3 WPIM-DDS Features...................................................................1-3
1.4 WPIM-DDS Port Assignment.......................................................1-3
1.5 WPIM-DDS Specifications...........................................................1-4
1.6 Getting Help.................................................................................1-5
1.7 Related Manuals..........................................................................1-6
CHAPTER 2 LOCAL MANAGEMENT
2.1 The WAN Physical Configuration Screen....................................2-1
2.1.1 WAN Physical Configuration Screen Fields....................2-2
2.1.2 WPIM-DDS Configuration Fields ....................................2-3
2.2 The WAN Interface Configuration Screen...................................2-5
2.2.1 WAN Interface Configuration Screen Fields...................2-5
2.3 WPIM-DDS Configuration............................................................2-7
2.3.1 WPIM-DDS Physical Configuration ................................2-8
2.3.2 WPIM-DDS Interface Configuration................................2-9
APPENDIX A WANTERMS AND ACRONYMS

Contents
vi WPIM-DDS Local Management Guide

WPIM-DDS Local Management Guide 1-1
CHAPTER 1
INTRODUCTION
Welcome to the Cabletron Systems WPIM-DDS Local Management
Guide
. This manual explains how to use Local Management to control
and manage the Cabletron Systems WPIM-DDS. This manual also
provides a summary of the most widely used WAN terms and acronyms.
The WPIM-DDS resides in and provides connectivity/functionality to
Cabletron Systems Wide Area Network (WAN) modules such as the
BRIM-W6.
Before using this manual you must perform the following procedures:
• Install the WPIM-DDS in a Wide Area Network module. Refer to the
appropriate manual (e.g., the
BRIM-W6 User’s Guide ) for installation
and troubleshooting procedures.
• Set up and access Local Management. Refer to the appropriate MIM,
standalone hub, or module User’s Guide for instructions on setting up
and accessing local management.
1.1 USINGTHIS MANUAL
Read through this manual completely to familiarize yourself with its
content and to gain an understanding of the features and capabilities of
the WPIM-DDS.You should have a general working knowledge of the
following data communications networks and their physical layer
components before using the WPIM-DDS.
•WAN
• Ethernet and IEEE 802.3

Chapter 1: Introduction
1-2 WPIM-DDS Local Management Guide
The following list briefly explains each chapter of the WPIM-DDS
manual:
Chapter 1, Introduction , outlines the contents of this manual, describes
WPIM-DDS features, lists specifications, and concludes with a list of
related manuals.
Chapter 2,
Local Management , describes how to use Local Management
to set up the WPIM-DDS.
Appendix A, WAN Terms and Acronyms , contains a brief glossary of
the terms used in this book.
1.2 DOCUMENT CONVENTIONS
The following conventions are used throughout this document:
Navigate through the WPIM Local Management Screens by using the
following keyboard commands:
• SPACE bar to toggle between selections in a field.
• ENTER (RETURN) to implement a selection.
• Arrow keys to move up, down or sideways within the screen.
NOTE
Note symbol. Calls the reader’s attention to any item of
information that may be of special importance.
TIP
Tip symbol. Conveys helpful hints concerning procedures or
actions.
!
CAUTION
Caution symbol. Contains information essential to avoid
damage to the equipment.
Warning symbol.Warns against an action that could result in
equipment damage, personal injury or death.

WPIM-DDS Features
WPIM-DDS Local Management Guide 1-3
1.3 WPIM-DDS FEATURES
The WPIM-DDS extends the functionality of the Wide Area Network
module to allow remote connectivity using Digital Data Service (DDS).
The WPIM-DDS provides a DDS interface that includes a built-in
Channel Service Unit/Digital Service Unit (CSU/DSU) for direct
connection to a DDS line.
Diagnostic Loopback
The WPIM-DDS supports remote CSU diagnostic loopback and
Non-Latching remote DSU diagnostic loopback.
WAN Protocols
As of this printing, the module in which the WPIM-DDS is installed
supports the following WAN protocols (refer to the Release Notes
included with the host MIM or standalone hub for a list of current
protocols):
• Point to Point Protocol (LCP) as defined by RFC 1661
• Point to Point Protocol (BNCP) as defined by RFC 1638
• Point to Point Protocol LAN Extender (PPP/LEX)
• Frame Relay as defined by RFC 1490
MIB Support
Refer to the Release Notes included with the host MIM or standalone hub
for a list of all MIBs supported by theWPIM-DDS. For information about
how to extract and compile individual MIBs, contact Cabletron Systems
Technical Support (refer to the section
Getting Help in this chapter).
1.4 WPIM-DDS PORT ASSIGNMENT
The WPIM-DDS features one RJ45 port to enable any Cabletron product
supporting the WPIM architecture to connect directly to a single Digital
Data Service (DDS) circuit. The pinout information for the port is shown
in Table 1-1, below. Table 1-2 lists the Cabletron Systems part number for
the interface cable for the WPIM-DDS.

Chapter 1: Introduction
1-4 WPIM-DDS Local Management Guide
1.5 WPIM-DDS SPECIFICATIONS
This section describes the environmental specifications and safety and
approval requirements for the WPIM-DDS. Cabletron Systems reserves
the right to change these specifications at any time without notice.
Environmental Requirements
Operating Temperature: 5 ° to 40 ° C (41 ° to 104 ° F)
Non-operating Temperature: -30
° to +90 ° C (-22 ° to 194 ° F)
Operating Humidity: 5% to 95% (non-condensing)
Safety
This unit meets the safety requirements of UL1950, CSA C22.2 No. 950,
EN 60950, and 73/23/EEC.
EMC
This unit meets the EMC requirements of FCC Part 15 ClassA, EN 55022
Class A, VCCI Class I, EN 50082-1, and 89/336/EEC.
Table 1-1 Network Pinout Assignments
PIN SIGNAL PIN SIGNAL
1 Transmit Ring 5 Not Used
2 Transmit Tip 6 Not Used
3 Not Used 7 Receive Tip
4 Not Used 8 Receive Ring
Table 1-2 DDS Interface Cable Part Number
Interface Cable Cabletron Part Number
DDS Line Interface Cable 9360119-x

Getting Help
WPIM-DDS Local Management Guide 1-5
1.6 GETTING HELP
If you need additional support related to this device, or if you have any
questions, comments, or suggestions concerning this manual, contact
Cabletron Systems Technical Support:
Before calling Cabletron Systems Technical Support, have the following
information ready:
• A description of the failure
• A description of any action(s) already taken to resolve the problem
(e.g., changing mode switches, rebooting the unit, etc.)
• A description of your network environment (layout, cable type, etc.)
• Network load and frame size at the time of trouble (if known)
• The serial and revision numbers of all Cabletron Systems products in
the network
• The device history (i.e., have you returned the device before, is this a
recurring problem, etc.)
• Any previous Return Material Authorization (RMA) numbers
Phone [phone]
Monday – Friday; 8 A . M . – 8 P . M . Eastern Time
CompuServe GO CTRON from any ! prompt
Internet mail [email protected]
FTP ctron.com (134.141.197.25)
Login
anonymous
Password your email address
BBS [phone]
Modem setting 8N1: 8 data bits, 1 stop bit, No parity
For additional information about Cabletron Systems products, visit our
World Wide Web site: http://www.cabletron.com/

Chapter 1: Introduction
1-6 WPIM-DDS Local Management Guide
1.7 RELATED MANUALS
Refer to the manual included with the host Wide Area Network module
(e.g., the
BRIM-W6 User’s Guide ) to supplement the procedures and
other technical data provided in this manual. Refer to the MIM,
standalone hub or module User’s Guides and/or Local Management
Guides for local management setup information. This manual references
procedures in these manuals, where appropriate, but does not repeat them.

WPIM-DDS Local Management Guide 2-1
CHAPTER 2
LOCAL MANAGEMENT
This chapter explains how to configure the WPIM-DDS through Local
Management. The WAN Physical Configuration screen and the WAN
Interface Configuration screen appear as Local Management menu
selections after you install the WPIM-DDS into a WAN module such as
the BRIM-W6 and then install the BRIM into a MIM or standalone hub.
Refer to the MIM or standalone hub User’s Guide for instructions about
how to set up and access Local Management.
Sections of this chapter include the following:
• The WAN Physical Configuration Screen 2.1
• The WAN Interface Configuration Screen 2.2
• WPIM-DDS Configuration 2.3
Read Sections 2.1 and 2.2 to gain an understanding of the WPIM-DDS
Local Management screens. Section 2.3 provides examples for setting up
the WPIM-DDS in a PPP (LEX or BNCP) or Frame Relay environment.
2.1 THEWAN PHYSICAL CONFIGURATION SCREEN
To access the WAN Physical Configuration screen from the Setup screen,
use the arrow keys to highlight the
WAN BRIM Setup option, then press
ENTER. The screen shown in Figure 2-1 appears.

Chapter 2: Local Management
2-2 WPIM-DDS Local Management Guide
Figure 2-1 WAN Physical Configuration Screen
2.1.1 WAN Physical Configuration Screen Fields
The following sections describe WAN Physical Configuration screen
fields and instructions for setting them. The WAN Physical Configuration
screen lets you configure the WPIM or “Physical Interface.”
Cabletron Systems offers a variety of WPIMs. Select the WPIM you wish
to configure by using the arrow keys to highlight the
WPIM command
field at the bottom of the screen. Use the SPACE bar to select the
appropriate WPIM, then press ENTER. The WAN Configuration screen
automatically displays unique configuration fields for each WPIM as
shown in Figure 2-1.
SAVE WAN INT CONFIG RETURN
Type: DDS
BRIM #: 1
Mode: [Primary]
Active: Yes
Ifaces: 002
Type: T1
BRIM #: 1
Mode: [Secondary]
Active: No
Ifaces: 003-026
WAN PHYSICAL CONFIGURATION
DDS Line Mode:
DDS Tx Clock Source:
DDS Loopback:
WPIM 1 Line Configuration
148201
<host name> Local Management Flash Image Version: xx.xx.xx
[WPIM 1]
WPIM 1 WPIM 2
[DDS-PRI]
[Loop-Timing]
[NONE]
DDS In-Speed:
DDS Out-Speed: [56000] [56000]

TheWAN Physical Configuration Screen
WPIM-DDS Local Management Guide 2-3
The WAN Physical Configuration screen displays the following
information for each WPIM.
WPIM 1-4
Displays configuration information for as many as four WPIMs.
TYPE
Displays the WPIM type.
BRIM #
Displays the BRIM slot in which the WPIM resides.
MODE
Displays the WPIM mode. Toggles between PRIMARY and
SECONDARY. In a device such as the BRIM-W6 where two WPIMs are
utilized, but only one can be active at a given time, the second WPIM
installed or recognized defaults to
SECONDARY .
ACTIVE
Displays the status of the WPIM,Yes (active) or No.
INTERFACES
Displays the interfaces available to each WPIM.
2.1.2 WPIM-DDS Configuration Fields
The configuration fields displayed on the Physical Configuration screen
shown in Figure 2-1 vary depending on the type of WPIM. The examples
in this Guide cover the WPIM-DDS. Each Cabletron Systems WPIM has
a Local Management Guide that provides specific configuration
guidelines.
NOTE
Each BRIM-W6 supports two WPIMs.Some of Cabletron
Systems products (e.g., the NBR-620 or the EMM-E6) support
two BRIM-W6 modules, providing connectivity for up to four
WPIMs. Only oneWPIM per BRIM-W6 can be active .

Chapter 2: Local Management
2-4 WPIM-DDS Local Management Guide
DDS Line Mode
Displays the DDS Line Mode. The selections toggle between DDS-PRI
(primary) and DDS-CC (clear channel). This field should be set according
to the instruction of your service provider. The default setting for this field
is DDS-PRI.
DDSTx Clock Source
Displays the clock source as either Loop or Local. The Loop setting
allows the WPIM-DDS to receive its timing information from the service
provider and the Local setting allows the WPIM-DDS to receive its
timing information internally. If DDS-CC is chosen for the DDS Line
Mode then this field must be set to Loop. The default setting is Loop.
DDS Loopback
Displays the internal Loopback as either Line or None. Line loopback is
reserved for network diagnostics only. The default is None.
DDS In-Speed
Informational purposes only. Displays 56000 (bps) for Primary DDS Line
Mode and 64000 (bps) for Clear Channel DDS Line Mode upon startup.
DDS Out-Speed
Informational purposes only. Displays 56000 (bps) for Primary DDS Line
Mode and 64000 (bps) for Clear Channel DDS Line Mode upon startup.

TheWAN Interface Configuration Screen
WPIM-DDS Local Management Guide 2-5
2.2 THEWAN INTERFACE CONFIGURATION SCREEN
This section describes the features of the WAN Interface Configuration
screen. Access the screen by using the arrow keys to highlight the WAN
INT CONFIG command field at the bottom of the Physical
Configuration screen, then press ENTER. The WAN Interface
Configuration screen shown in Figure 2-2 appears.
Figure 2-2 WAN Interface Configuration Screen
2.2.1 WAN Interface Configuration Screen Fields
The following sections describe WAN Interface Configuration screen
fields.
Interface Number
Displays active Interface Number. Use this field to configure the Interface
Number assigned to the WPIM on the WAN Physical Configuration
screen.
WAN INTERFACE CONFIGURATION
RETURN
SAVE
Interface Number: [002]
Data Compression: [NO]
Max Xmit Unit: [0]
Line Coding: [NONE]
Active Protocol: [NONE]
148204
<host name> Local Management Flash Image Version: xx.xx.xx
001
002
003
004
005
006
007
008
009
010
011
012
013
014
015
PT# IF# LID STATE
018
019
020
021
022
023
024
025
026
027
028
029
030
031
032
PT# IF# LID STATE
016
017
001 Enet UP

Chapter 2: Local Management
2-6 WPIM-DDS Local Management Guide
Data Compression
Displays the status of Data Compression. This field displaysYES or NO.
The default setting is NO.
Max Xmit Unit
User configured field that displays the maximum packet size that can be
transmitted on the selected interface. The default settings for this field are
8191 for PPP and 4095 for Frame Relay.
Line Coding
Displays the Line Coding for timeslots associated with this interface. This
field displays JBZS, INV-HDLC, or NONE. The default setting for this
field is NONE.
Active Protocol
Displays the active OSI Layer protocol. This field displays NONE,
FR (Frame Relay), or PPP (Point-to-Point). The default setting is NONE.
If you select PPP, the following field appears:
PPPType: This field displays BNCP or LEX. The default
setting is BNCP.
If you select FR, the following field appears:
FR LMP: This field displays the Link Management
Protocol NO LMI, Q.933-A or T1.617-D. The
default setting is TL617-D.
If NO LMI is selected, the following fields are displayed:
DLCI Address: Thisfield can be set to valuesfrom0–1023.The
values 0–15 and 1008–1022 are reserved DLCI
(Data Link Connection Identifiers) addresses.
Thevalues 16–991 are typicallyusedforvirtual
circuits.
Circuit State: Toggles between Active, Inactive and Invalid.
