Cadac 5431 User manual

503-0667 LEV4
MODEL No: 5431
USER INSTRUCTIONS
LIVE THE BRAAI LIFE
POWER COOKER
NOTE! PRODUCT MAY VARY FROM ILLUSTRATIONS
GB
PERMIT 1002-149/2-RSA-17-A

11
CAUTION
Provide ample ventilation. This gas appliance consumes air (oxygen). Do not use this appliance in an unventilated space to
avoid endangering your life. If still more gas appliances and/or occupants using gas are added to the space, additional ventilation
must be provided.
IMPORTANT
Read these instructions carefully so as to familiarise yourself with the appliance before connecting it to a gas cylinder.
Retain these instructions for future reference.
GB
1. Introduction
• This appliance complies with SANS 1539:2017.
• This appliance shall be used exclusively on CADAC domestic gas cylinders.
• It may be hazardous to attempt to t the appliance to other types of gas cylinders.
• Appliance category: Cylinder Vapour Pressure propane / butane mixture (LPG).
• Nominal consumption: 168 g/hr
• Nominal Heat Input: 2.3kW
• This appliance uses a No.21 CADAC jet.
• Maximum pot size: Diameter 300mm.
2. Safety information
• Check that the seal (H)(Fig. 2) is in place and in good condition before connecting the
appliance to the gas cylinder (K).
• DO NOT USE THE APPLIANCE IF IT HAS A DAMAGED OR WORN SEAL. REPLACE IT.
• Do not use an appliance that is leaking, damaged or that does not operate properly.
• The appliance shall only be used in a well-ventilated location, if used in-doors.
• Always operate the appliance on a rm level surface.
• Ensure the appliance is used away from ammable materials. Minimum safe distances
are: above the appliance 1.2m. At the rear and sides 600mm (See Fig.1).
• Gas cylinders must be tted or changed outdoors, away from any source of ignition
such as naked ames, electric res and away from other people.
• If there is a leak on your appliance (smell of gas), immediately close the cylinder valve
and take it outside into a well-ventilated ame free location where the leak may be
detected and stopped. Do not try to detect leaks using a ame. Soapy water should be
used.
• Never leave the appliance unattended when lit.
• In the event of light back (ignition inside the burner (A) or mixing tube), immediately
turn off the gas supply by • closing the control valve on the cylinder. After the ame is extinguished, re-light
the appliance as described below. Should the ame persistently light back, return the product to your authorised CADAC repair agent.
• Do not modify the appliance. Do not use it for anything for which it has not been designed.
• During use, parts of the appliance will become hot. Avoid touching hot parts with bare hands. The use of oven gloves is
recommended.
• Keep young children away from the appliance at all times.
3. Fitting and changing the gas cylinder
• Check that the seal (H)(Fig.2) is in place and in good condition before connecting the appliance to the gas cylinder (M).
• DO NOT USE THE APPLIANCE IF IT HAS A DAMAGED OR WORN SEAL. REPLACE IT.
• Do not use an appliance that is leaking, damaged or that does not operate properly.
• The appliance shall only be used in a well-ventilated location, if used in-doors.
• Always operate the appliance on a rm level surface.
• Ensure the appliance is used away from ammable materials. Minimum safe distances are: above the appliance 1.2m. At the rear and
sides 600mm (See Fig. 1).
• Gas cylinders must be tted or changed outdoors, away from any source of ignition such as naked ames, electric res and away from
other people.
• If there is a leak on your appliance (smell of gas), immediately close the cylinder valve and take it outside into a well-ventilated ame
free location where the leak may be detected and stopped. Do not try to detect leaks using a ame. Soapy water should be used.
• Never leave the appliance unattended when lit.
• In the event of light back (ignition inside the burner (A) or mixing tube), immediately turn off the gas supply by closing the control
valve on the cylinder. After the ame is extinguished, re-light the appliance as described below. Should the ame persistently light
back, return the product to your authorised CADAC repair agent.
• Do not modify the appliance. Do not use it for anything for which it has not been designed.
• During use, parts of the appliance will become hot. Avoid touching hot parts with bare hands. The use of oven gloves is
recommended.
• Keep young children away from the appliance at all times.
Fig. 1

22
Fig. 2
4. Operating the Appliance
• Always operate the appliance on a rm level surface.
• To light the appliance, hold a ame to the burner, turn the gas control knob (N) (Fig. 2) slowly in the direction of the “+” arrow
(anti-clockwise) until gas ignites.
• After lighting, do not move the appliance around as liquid gas may enter the appliance from the gas cylinder, causing large yellow
ames.
• Adjust the size of the ame by turning the control knob (N)(Fig. 2). To increase the size of the ame, turn the knob anti-clockwise
and to decrease turn the knob clockwise.
• After use, always ensure that the control knob is turned to the “off” position (turn fully clockwise).
• In the event of light-back (ignition inside the burner (A) or mixing tube), do not move the cylinder but simply turn the gas control
knob fully clockwise. Wait until all the ames are extinguished. Follow the safety instructions given in sections 2, 3 and 6. Re-light
the appliance.
PARTS LIST
A BURNER
B SECURING SCREWS
C COOKER PLATE
D POT STAND
E WASHER
FADAPTOR
G AIR HOLES
H RUBBER SEAL
I BRASS INSERT
J MESH
K JET
LFILTER
M CYLINDER (not supplied)
N CONTROL KNOB (not supplied)
GB

33
5. General Maintenance
REPLACING A BLOCKED JET
• Should the hole in the jet become blocked, this may result in a small ame or no ame at all. Do not attempt to clean the jet with a
pin or other such device as this may damage the orice, which could make the appliance unsafe.
• Ensure the cylinder valve is closed.
• If the appliance was in use, it will be hot. Allow to cool before attempting any maintenance.
• Unscrew the appliance from the gas cylinder.
• Remove the Mesh and Filter using a very thin at screwdriver. The Jet is now visible to remove. Unscrew the jet from the adaptor using
a suitable size at screw driver. Do not use pliers to remove the jet as this may damage the jet, making it unusable or impossible to
remove.
• Screw a new CADAC No. 21 jet into the CADAC Cooker and ensure a gas tight seal. Do not over tighten the jet.
REPLACEMENT OF SEALS
• Remove the rubber seal (G) without damaging the seat, replace it with a new seal making sure it is well seated.
• Connect to a gas cylinder following the directions in section 3 and the safety information in section 2.
6. Troubleshooting
• A normal ame is blue and may have an orange or yellow tip. If the ame is completely yellow, it may be that the jet is not securely
tted. Re-tighten to give a gas tight seal. An overlled gas cylinder can also cause large yellow ames. Cylinder should be returned to
lling station and checked by weight.
• Check that the air holes (G) in the adaptor are clear and free of obstructions (Fig.2).
• If the ame power drops or the gas will not light, check that the gas cylinder still contains gas (shake to hear the noise made by the
liquid). If there is still gas, the jet might have become blocked or partially blocked.
7. Cleaning and Storage
• To clean the appliance, simply wipe with a damp cloth using a little dishwashing liquid, if necessary.
• DO NOT immerse in water as this will allow water to get into the burner and primary air holes, causing the appliance to malfunction.
• Do not use abrasive cleaners as this will cause permanent damage to the surface.
• After cleaning, unscrew the appliance from the gas cylinder and store both in a cool dry place away from heat.
8. Spares and Accessories
• Always use genuine CADAC spares and accessories as they have been designed to give optimum performance.
9. Returning the Appliance for Repair or Service
• Do not modify the appliance. This may cause the appliance to become unsafe.
• If you cannot rectify any fault by following these instructions, please return the appliance to your local CADAC distributor for
inspection / repair.
GB

44
