NX216-E ZONE EXPANDER 2
GENERAL DESCRIPTION
The NX216-E is a microprocessor-controlled 16-zone expander for the NX8/NX8-E control panels. Up to 5
NX216-E expanders can be added to the NetworX NX8 control panel with a maximum zone count of 48 zones.
Up to twenty-three NX216-E expanders can be added to the NX8-E control with a maximum zone count of 192
zones. Each expander has an optional tamper switch and power isolator making it ideal for use in a remote
location.
6-POSITION DIP SWITCH SETTINGS
The first thing that must be decided is the starting zone of this particular zone expander. The starting zone must
be on a boundary of eight (8) zones. The sixteen (16) zones for this module will move out from this starting
position. To set the starting zone, set the dip switch according to the table below:
NOTE: THE POSITION OF ALL SWITCHES IS ONLY UPDATED WHEN THE NX216-E IS POWERED UP.
BEFORE YOU CHANGE THE POSITION OF THESE SWITCHES YOU MUST POWER DOWN THE EXPANDER.
Starting Zone # Expander # Switch 1 Switch 2 Switch 3 Switch 4 Switch 5
1 22 OFF OFF OFF OFF OFF
9 23 ON OFF OFF
OFF OFF
17 16 OFF ON OFF
OFF OFF
25 17 ON ON OFF
OFF OFF
33 18 OFF OFF ON OFF OFF
41 19 ON OFF ON OFF OFF
49 20 OFF ON ON OFF OFF
57 21 ON ON ON
OFF OFF
65 96 OFF OFF OFF ON OFF
73 97 ON OFF OFF ON OFF
81 98 OFF ON OFF ON OFF
89 99 ON ON OFF
ON OFF
97 100 OFF OFF ON ON OFF
105 101 ON OFF ON ON OFF
113 102 OFF ON ON ON OFF
121 103 ON ON ON ON OFF
129 104 OFF OFF OFF OFF ON
137 105 ON OFF OFF
OFF ON
145 106 OFF ON OFF
OFF ON
153 107 ON ON OFF
OFF ON
161 108 OFF OFF ON OFF ON
169 109 ON OFF ON OFF ON
177 110 OFF ON ON OFF ON
185 111 ON ON ON
OFF ON
Dip switch 6 - Dip switch 6 is used to disable the second block of eight (8) zones on this zone expander. This
can be done if only an eight- (8) zone expander is required in a particular expander location. To disable the
second group of eight (8) zones on this expander, turn dip switch 6 on.
ENROLLING THE NX216-E EXPANDER
The NX8/NX8-E has the ability to automatically find and store in its memory the presence of all keypads, zone
expanders,wireless receiversandanyother module connected to the dataterminal. Thisallows these modules
tobe supervised by the control panel. Toenroll the modules enter the ProgramMode of the NX8/NX8-E control,
andwhen the Program Mode is exited,itwill automatically enroll the devices. The enrollingprocess takes about
12 seconds, during which time the “Service” LED will illuminate. User codes will not be accepted during the
enrollingprocess. Once a module is enrolled, ifit is not detected by thecontrol, the “Service” LED will illuminate.

NX216-E ZONE EXPANDER 3
WIRING THE NX216-E
Wire the zones according to the wiring diagram. NOTE: Any unused zones must have the EOL resistor
across it (unless all eight are disabled by dip switch 6).
TERMINAL DESCRIPTION
TERMINAL DESCRIPTION
POS Connect to the KP POS terminal of the NX8/NX8-E. Current draw is 30 mA.
COM Connect to the KP COM terminal of the NX8/NX8-E.
DATA Connect to the KP DATA terminal of the NX8/NX8-E. (See the wiring diagram for wire
specifications)
TAM Connect as shown below. IF NOT USED, CONNECT TO A COM TERMINAL.
AUX Canbe used to power devicesdirectlyfrom the NX216-E. Poweriscoming fromthe NX8/NX8-
E, therefore the current draw of these devices must be added to the total current draw of the
NX216-E. This output is current limited to 100 mA.
Z9 Connect to one side of zone 9 loop. Connect the other side to COM terminal. Open or short
causes alarm. (See the wiring diagram for examples)
COM Common (-) terminal for zones 9 & 10.
Z10 Connect to one side of zone 10 loop. Connect the other side to COM terminal. Open or short
causes alarm. (See the wiring diagram for examples).
Z11-Z24 Connect as described for Z9 & Z10.
WIRING DIAGRAM

NX216-E ZONE EXPANDER 4
DEFAULT ZONE CONFIGURATIONS
Zones can be programmed to be one of thirty different zone configurations (zone types). Configurations # 17
through 20 can be used for wireless or hardwired zones using European double EOL configuration. The default
zone configurations are listed below. These zone configurations can be customized by programming locations
110 to 169. NOTE #1: Zone Types 21-30 are applicable to the NX8-E control panel ONLY. NOTE #2: The
expander zones will not follow the Fast Loop Response.
DATA DESCRIPTION OF DEFAULT CONFIGURATION
“1” DAY ZONE - Instant when system is armed trouble zone when system is disarmed.
“2” 24-HOUR AUDIBLE - Creates an instant yelping siren alarm regardless of the armed state of the panel.
“3” ENTRY/EXIT DELAY 1 - A trip will start entry delay 1. The lack of a trip during exit delay will enable the
Automatic Bypass or Instant mode if so programmed.
“4” FOLLOWER WITH AUTO-BYPASS DISABLED - This zone will be instant when the system is armed and
no entry or exit delays are being timed. It is delayed during entry and exit delay times. This zone will not
bypass in Stay Mode, nor automatically bypass even if enabled in Segment 1 / Location 23.
“5” INTERIOR FOLLOWER WITH AUTO- BYPASS ENABLED - This zone will be instant when the system is
armed and no entry or exit delay is being timed. It is delayed during entry and exit delay times. This zone
will bypass in Stay Mode, and automatically bypass if enabled in Segment 1 of Location 23.
“6” INSTANT - This zone creates an instant alarm whenever it is tripped and the Armed LED is on.
“7” 24-HOUR SILENT - Creates an instantsilentalarm regardlessof the armed stateof the control panel.Itwill
not display on the keypad.
“8” FIRE - This zone will illuminatetheFireLEDandsoundthetemporalsireneachtime the zone is shorted. It
will also rapidly flash the Fire LED indicating a trouble if the zone is open.
“9” ENTRY/EXIT DELAY 2 - A trip will start entry delay 2. The lack of a trip during exit delay will enable the
Automatic Bypass or Instant mode if so programmed.
“10” 24-HOUR SILENT SUPERVISED - Creates an instant silent alarm regardless of the armed state of the
control panel. It will display on the keypad.
“11” KEYSWITCH ZONE - This zone type will arm and disarm the partition or partitions of the control panel that
resides in each time the zone is shorted. Keyswitch arming will report as user #99.
“12”
INTERIOR FOLLOWER WITH "CROSS ZONE" ENABLED -Thiszone will be Instant when the system is
armed and no entry or exit delay is being timed. It is delayed during entry and exit delay times. If a "Cross
Zone" is not being timed it will start a "Cross Zone" timer. If a "Cross Zone" is being timed it will create an
Instantalarm. This zone will bypass inStay Mode and automatically bypass whenenabled in Segment 1 of
Location 23.
“13” INSTANT ENTRY GUARD - This zone creates an instant alarm whenever it is tripped and the Stay LED is
off. It will start an entry delay time 2 if it is tripped and the system is armed and the Stay LED is on.
“14” ENTRY/EXIT DELAY 1 WITH GROUP BYPASS ENABLED - A trip will start entry delay 1. This zone will
bypass when the "Group Bypass" command is entered at the keypad. The lack of a trip during exit delay
will enable the Automatic Bypass or Instant mode if so programmed.
"15
INTERIOR FOLLOWER WITH GROUP BYPASS ENABLED - Thiszone will beinstant when thesystemis
armedandnoentry or exit delays are being timed. It is delayed during entry/exit delay times. This zone will
bypass when the "Group Bypass" command is entered at the keypad. This zone will bypass in Stay Mode
and automatically bypass even if enabled in Segment 1 / Location 23.
"16" INSTANT WITH GROUP BYPASS ENABLED - This zone creates an instant alarm whenever it is tripped
and the Armed LED is on. This zone will bypass when the "Group Bypass" command is entered at the
keypad.
"17" ENTRY/EXIT DELAY 1 WITH TAMPER ENABLED - A trip will start entry delay 1. The lack of a trip during
exit delay will enable the Automatic Bypass or Instant mode if so programmed. This configuration group
can be used to enable tamper on a wireless transmitter.
"18"
INTERIOR FOLLOWER WITH TAMPER AND AUTO-BYPASS ENABLED - Thiszonewill beinstantwhen
the system is armed and no entry or exit delay is being timed. It is delayed during entry and exit delay
times. This zone will bypass in Stay Mode and automatically bypass if enabled in Segment 1 / Location 23.
This configuration group can be used to enable tamper on a wireless transmitter.
"19" INSTANT WITH TAMPER ENABLED - This zone creates an instant alarm whenever it is tripped and the
Armed LED is on. This configuration group can be used to enable tamper on a wireless transmitter.
"20" ENTRY/EXIT DELAY 2 WITH TAMPER ENABLED - A trip will start entry delay 2. The lack of a trip during
exit delay will enable the Automatic Bypass or Instant mode if so programmed. This configuration group
can be used to enable tamper on a wireless transmitter.

NX216-E ZONE EXPANDER 5
DATA DESCRIPTION OF DEFAULT CONFIGURATION
Zone Types 21-30 are applicable to the NX8-E control panel ONLY
21 GAS DETECTION- Creates an instant alarm regardless of the armed state of the control panel. It will
display on the keypad and activate the keypad sounder.
22 LOW TEMP DETECTION- Creates an instant silent alarm regardless of the armed state of the control
panel. It will display on the keypad and activate the keypad sounder.
23 HIGH TEMP DETECTION- Creates an instant silent alarm regardless of the armed state of the control
panel. It will display on the keypad and activate the keypad sounder.
24 MANUAL FIRE - This zone will illuminate the Fire LED and sound the temporal siren each time the zone is
shorted. It will also rapidly flash the Fire LED indicating a trouble if the zone is open.
25 CHIME ONLY - Creates no alarm regardless of the armed state of the control panel. It will chime anytime it
is faulted and will display on the keypad. Local only.
26 INTERIOR FOLLOWER DELAY 2 - Thiszone will be instantwhen the system isarmedand no entry orexit
delay is being timed. It is delayed during entry and exit delay 2 times. This zone will automatically bypass if
enabled in Segment 1 of Location 23.
27 INTERIOR FOLLOWER FORCE ARMABLE - This zone will be instant when the system is armed and no
entry or exit delay is being timed. It is delayed during entry and exit delay 1 times. This zone will
automatically bypass if enabled in Segment 1 of Location 23.
28 ENTRY/EXIT FORCE ARMABLE DELAY 2 - A trip will start entry delay 2. The lack of a trip during exit
delay will enable the Automatic Bypass or Instant mode if so programmed.
29
INTERIOR FOLLOWER WITH ACTIVITY SUPERVISION ENABLED - This zone will be instant when the
system is armed and no entry or exit delay is being timed. It is delayed during entry and exit delay times. It
will send a report if the zone activity time is reached without a change of state. Refer to Location 40 /
Segment 11. This zone will automatically bypass if enabled in Segment 1 of Location 23.
30 ENTRY/EXIT WITH ACTIVITY SUPERVISION ENABLED- Atrip willstartentry delay 1.It will send areport
if the zone activity time is reached without a change of state. Refer to Location 40 / Segment 11. The lack
of a trip during exit delay will enable the Automatic Bypass or Instant mode if so programmed.
PROGRAMMING THE ZONE CONFIGURATION AND PARTITION FOR EACH ZONE
The programming for all zone information is performed in the NX8/NX8-E control panel. For instructions on
accessing and programming the NX8/NX8-E, as well as changing the characteristics of a configuration group,
referto theNX8/NX8-EInstallation Manual.Thefollowing programminginformationistaken fromtheNX8/NX8-E
Installation Manual.
LOCATION 25 CONFIGURATION GROUP ZONES 1-8 (8 segments, numerical data)
Location 25 contains the Configuration Group (Zone type) for zones 1-9. Segment 1 is for zone 1; Segment 8 is
for zone 8. Default configurations are found in the table on page 4.
LOCATION 26 PARTITION SELECT ZONES 1-8 (8 segments, feature selection data)
Location 26 is used to select the partition(s) that zones 1-8 reside in. A zone may reside in any combination of
the8 partitions. If a burglary zone resides in more than 1 partition, it will only be active when all partitions
are armed. A zone that resides in more than 1 partition will be reported to its lowest partition. Location
28 has 8 segments. Segment 1 corresponds to zone 1 and Segment 8 corresponds to zone 8.
Segments 1 - 8: 1 = Partition #1
2 = Partition #2
3 = Partition #3
4 = Partition #4
5 = Partition #5
6 = Partition #6
7 = Partition #7
8 = Partition #8

NX216-E ZONE EXPANDER 6
LOCATIONS 27 –36 and 170 - 205
These locations contain the Configuration Group and Partition Select for Zones 9 –192. Use the instructions
associated with Location 25 and 26 to program the remaining locations. Worksheets for these locations are
included for your convenience.
LOC DESCRIPTION DEFAULT DATA
27 ZONES 9 - 16 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
28 ZONES 9 - 16 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 9 10 11 12 13 14 15 16
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
29 ZONES 17 –24 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
30 ZONES 17 –24 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 17 18 19 20 21 22 23 24
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
31 ZONES 25 –32 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
32 ZONES 25 –32 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 25 26 27 28 29 30 31 32
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
33 ZONES 33 –40 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
34 ZONES 33 –40 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 33 34 35 36 37 38 39 40
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8

NX216-E ZONE EXPANDER 7
LOC DESCRIPTION DEFAULT DATA
35 ZONES 41 –48 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
36 ZONES 41 –48 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 41 42 43 44 45 46 47 48
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
NOTE: THE FOLLOWING LOCATIONS ARE ONLY AVAILABLE ON THE NX8-E PANEL
170 ZONES 49 –56 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
171 ZONES 49 –56 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 49 50 51 52 53 54 55 56
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
172 ZONES 57 –64 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
173 ZONES 57 –64 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 57 58 59 60 61 62 63 64
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
174 ZONES 65 –72 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
175 ZONES 65 –72 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 65 66 67 68 69 70 71 72
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8

NX216-E ZONE EXPANDER 8
LOC DESCRIPTION DEFAULT DATA
176 ZONES 73 –80 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
177 ZONES 73 –80 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 73 74 75 76 77 78 79 80
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
178 ZONES 81 –88 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
179 ZONES 81 –88 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 81 82 83 84 85 86 87 88
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
180 ZONES 89 –96 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
181 ZONES 89 –96 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 89 90 91 92 93 94 95 96
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
182 ZONES 97 –104 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
183 ZONES 97 –104 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 97 98 99 100 101 102 103 104
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8

NX216-E ZONE EXPANDER 9
LOC DESCRIPTION DEFAULT DATA
184 ZONES 105 –112 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
185 ZONES 105 –112 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 105 106 107 108 109 110 111 112
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
186 ZONES 113 –120 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
187 ZONES 113 –120 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 113 114 115 116 117 118 119 120
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
188 ZONES 121 –128 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
189 ZONES 121 –128 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 121 122 123 124 125 126 127 128
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
190 ZONES 129 –136 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
191 ZONES 129 –136 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 129 130 131 132 133 134 135 136
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8

NX216-E ZONE EXPANDER 10
LOC DESCRIPTION DEFAULT DATA
192 ZONES 137 –144 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
193 ZONES 137 –144 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 137 138 139 140 141 142 143 144
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
194 ZONES 145 –152 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
195 ZONES 145 –152 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 145 146 147 148 149 150 151 152
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
196 ZONES 153 –160 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
197 ZONES 153 –160 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 153 154 155 156 157 158 159 160
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
198 ZONES 161 –168 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
199 ZONES 161 –168 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 161 162 163 164 165 166 167 168
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8

NX216-E ZONE EXPANDER 11
LOC DESCRIPTION DEFAULT DATA
200 ZONES 169 –176 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
201 ZONES 169 –176 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 169 170 171 172 173 174 175 176
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
202 ZONES 177 –184 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
203 ZONES 177 –184 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 177 178 179 180 181 182 183 184
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
204 ZONES 185 –192 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
205 ZONES 185 –192 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 185 186 187 188 189 190 191 192
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
NOTES

SPECIFICATIONS
OPERATING POWER 12VDC Supplied from NX8/NX8-E or NX-320
AUXILIARY POWER Supplied from NX8/NX8-E or NX-320
Current limited to 100mA
CURRENT DRAW 30mA
LOOP RESISTANCE 300 Ohms Maximum
LOOP RESPONSE Selectable 50mS or 500mS
OPERATING TEMPERATURE 32 to 120 degrees F
DIMENSIONS 6.0" Wide
2.125" High
1.0" Deep
SHIPPING WEIGHT 2 lbs.
CADDX CONTROLS, INC.
1420 NORTH MAIN STREET
GLADEWATER, TEXAS 75647
TOLL FREE 800-727-2339
FAX [phone]
www.caddx.com
NX216-E INSTALLATION MANUAL
NX216EIB00 REV. B (04-03-01)
