cadenbach HARMONIA User manual

HARMONIA Manual volume: E 0.1

HARMONIA 12 inch FIR point source loudspeaker
Safety precautions
YOU ART. WE SOUND.
Potential risk of personal injury
Never stand in the direct sound beam close to a loudspeakers driven at a high level.
Professional loudspeaker systems can cause sound pressure levels that could harm
human health. Noncritical sound levels at about 90 dB can cause hearing damage if
people are exposed to it over a longer period.
In order to prevent accidents when deploying loudspeakers on the ground or when
own, please take note of the following:
• When setting up the loudspeakers or loudspeaker stands, make sure they are
standing on a rm surface. If you place several systems on top of one another, use
straps to secure them against movement.
• Only use accessories which have been tested and approved by Cadenbach Acous-
tics for assembly and mobile applications. Pay attention to the correct application
and maximum load capacity of the accessories.
• Ensure that all additional hardware, xings and fasteners used for installation or
mobile use are of an appropriate size and load safety factor. Pay attention to the
manufacturers instructions and to the relevant safety guidelines.
• Regularly check the loudspeaker housings and accessories for visible signs of
wear and tear, and replace them when necessary.
• Regularly check all load bearing bolts in the mounting devices.
Potential risk of material damage
Loudspeakers produce a static magnetic eld even if they are not connected or not
in use. Therefore make sure when erecting and transporting loudspeakers that they
are not near equipment and objects which may be impaired or damaged by an ex-
ternal magnetic eld.
WARNINGS ON THE SPEAKERS BACK PLATE:
THIS EQUIPMENT CAN GENERATE EXTREME SOUND PRESSURE LEVELS THAT CAN LEAD TO
PERMANENT HEARING DAMAGE.
THIS SURFACE MAY REACH HIGH TEMPERATURES WHILE IN USE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE.
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
ONLY PERSONAL CERTIFIED TO BE TRAINED BY CADENBACH ACOUSTICS, HAVING PASSED
S1 COURSE SHOULD SETUP THIS SYSTEM, OTHERWISE ANY WARRANTY IS VOID. SEE COR-
RESPONDING MANUAL.
MADE IN GERMANY / EU
www.cadenbach.eu

HARMONIA 12 inch FIR point source loudspeaker
Product description
YOU ART. WE SOUND.
Overview
HARMONIA is an extreme versatile point source loudspeaker with rotatable and interchange
able Horn in a multi- shape design with integrated standard truss mounting bar. It also pro-
vides quick lock pin side plates for easy and precise Cradle attachment and precise angling.
Even full active equipped HARMONIA is still light wight and offers in all version more than 136
dB SPL at 1 meter. This enables the system to be used as main Loudspeaker system either as
single speaker or in multiple horizontal and also vertical speaker array arrangement.
HARMONIA was designed for exibility, whether using the speaker vertically or horizontally
the Mid to High frequency 60° by 40° (90° x 50° when ordering HARMONIA9) CD horn deliv-
ers constant directivity and dispersion control and can be rotated into either the horizontal
or vertical plane.
The construction of the 12 inch Low frequency neodymium cone with it’s 3 inch voice coil and
Mid To High 1.5 inch exit driver section offers phase coherence between both chassis around
crossover point of more than 5 octaves, creating a remarkable point source behaviour. The
ring radiator design of the Mid to High compression driver has got a 1.75 inch voice coil deliv-
ering extra high excursion possibilities and radiates distortion free sound also above 16 kHz.
TEUTAES is the dedicated low frequency extension, anyway all cadenbach acoustic sub woof-
ers can be chosen to run with HARMONIA.
On order HARMONIA incorporates a very power full two channel frequency modulated oat-
ing modulator amplier. Due to it’s advanced high efciency power technology it runs at any
moment at very low temperature and needs no fan cooling at all.
Operation
The frequency and phase response of HARMONIA is smooth at very low THD. HARMONIA can
run full passive without the need of a controller and it can run in linear phase mode by us-
ing cadenbach acoustics FIR lter of the HEIMDALL D1 digital controller. It’s rotatable and
interchange able horn offers full CD dispersion control in horizontal and vertical point source
mode.
Applications
• Small concert halls, theatres and houses of worship, AV applications.
• Stage monitor, small to medium main system sound reinforcement.
• Side or front ll system, under balcony or distributed system.
Features
• Multi- shape design with high output level, with optional integrated amplier
• Left and Right Horn one cabinet Monitor shape. Optimal integration with TEUTATES sub woofer.
• Very exible CD coverage via rotatable, replace able Horn and cadenbach acoustics FIR lters.
• Easy quick lock system and Truss bar integration for various fast own congurations
www.cadenbach.eu

Technical Specications
Transducers
• Low frequency: 12 inches
(320 mm) Neodymium
• High frequency: 1.5 inches
(38 mm) Neodymium
Voice coil size and impedance
• Low frequency: 3 inches
(76 mm) Al, 8 ohms
• High frequency: 1.75 inches
(44.4 mm) Cu, 16 ohms
Diaphragm size
• High frequency: 1.75 inches
(44.4 mm) Polyester
Exit size
• High frequency: 1.5 inches
(38 mm) port
Nominal Impedance
• Low frequency: 8 ohms
• High frequency: 16 ohms
• Passive: 8 ohms
Z = 8 ohms
Output at 1m
• 138.5 dB SPL ( 3 )
driven with PAX P16 137 dB
driven with internal amps 138 dB
• HARMONIA9: 137.5 dB SPL ( 3 )
driven with PAX P16 136 dB
driven with internal amps 137 dB
Sensitivity (SPL at 1m)
• Low frequency: 104 (300 Hz) dB / 130 dB
cont. at 400 watts
• High frequency: 115 (1.5 kHz) dB / 134 dB
cont. at 80 watts
• Passive: 103 (300 Hz) dB / 129 dB
cont. at 400 watts
Power Handling
• Low frequency: 1500 watts peak
400 watts AES
800 watts program
rec. amp power on 4 ohms
2800 watts
• High frequency: 450 watts peak
80 watts AES
240 watts program
rec. amp power on 4 ohms
2800 watts
• Passive: 1500 watts peak
400 watts AES
800 watts program
rec. amp power on 4 ohms
2800 watts
Crossover type and frequency
• Filter type active: FIR zero phase
Low to Mid High: 1.1 - 1.6 kHz
• Filter type passive: None / FIR zero phase
Low to Mid High: 1.5 kHz
• Sub to Low: 70 Hz - 130 Hz
Data
Frequency and Phase response
• Usable frequency range: 52 Hz - 22 kHz ( 1 )
• Free eld frequency response: 75 Hz - 19.5 kHz
(-5 dB) linearity (+/- 0.5 dB)
passive no lter(+/- 2.5 dB)
• Phase response: 0° +/- 2°
from 280 Hz to 21.5 kHz
passive: 180° to - 180° from 77 Hz to 17.5 kHz
Size and weight
• Height: 26.47 inches (672 mm)
• Width: 16.38 inches (416 mm)
• Depth: 15.98 inches (406 mm)
• Weight:
52.91 lbs (24 kg) passive model
57.32 lbs (26 kg) active model
Coverage
• Horizontal coverage:
55° - 65° rotatable
HARMONIA9: 85° - 95° rotatable
• Vertical coverage:
40° rotatable
HARMONIA9: 50° rotatable
Speakers per PAX P16 channel
• For passive model:
2 / 3 ( 2 ) parallel via link
Connection
• For passive model:
2 x NL4 (1+/1- passive, 2+/2- link)
( 1 ) Full-range mode, pro-
viding 115 dB @ 52 Hz
( 2 ) possible only with short
length cables.
( 3 ) SPL max peak, test
signal: pink noise with crest
factor 6 dB.
www.cadenbach.eu
HARMONIA 12 inch FIR point source loudspeaker
436 mm
(17.17 inch)
406 mm
(15.98 inch)
672 mm
(26.47 inch)
416 mm
(16.38 inch)
415 mm
(16.34 inch)
406 mm
(15.98 inch)

Data
HARMONIA 12 inch FIR point source loudspeaker
www.cadenbach.eu
Technical Specications
Internal Amp module
• Type of output stage: free oating
modulator FM out put power stage
• Total output Power and Volts:
into 8 ohms
Music: 2 x 2800 watts at 150 Vpk
RMS: 2 x 1400 watts at 106 V
• Low frequency:
2800 watts peak / 1400 watts rms
• High frequency:
1400 watts peak / 700 watts rms
Audio specications
• IM: 0,05% (SMPTE)
• DIM: 0,005% (DIM 100)
• THD: 0,02% (+N 20 Hz – 20 kHz)
Audio input Connection
• XLR 5 pin, (with internal Controller XLR 3 pin)
female in and male link out
5pin: 1g, 2 LF+, 3 LF-, 4 HF+, 5 HF-,
3pin: 1g, 2 +, 3 -
Audio input Impedance
• 20 kOhms symmetric (between + and -),
• 10 kOhms non symmetric (- grounded).
Ac Power connection
• Powercon 25 A blue in and white link
(max 12,6 A link)
Ac Power specications
• 180 – 265 V AC 50 Hz / 2200 VA
Mechanical specications
• Mounting: 2 Aluminum side plates
with 4 point quick lock
• Working load: 144 x Speaker-weight
• Construction: 15 - 27 mm Plywood
steal grill with foam, aluminum angle
adjustment plates all powder coated,
50 mm truss bar, inside acoustic carpet,
foam and glue damping.
Internal amp module mounted on 7 mm
aluminum back plate with total passive fan
free cooling.
• Flying frame: Quick lock U-type Cradle
CSR-12U

Data
Measurements
Frequency response with FIR Filter of HARMONIA
Phase response FIR linear phase Filter of HARMONIA
www.cadenbach.eu
HARMONIA 12 inch FIR point source loudspeaker

Systems
HARMONIA 12 inch FIR point source loudspeaker
System setups: HARMONIA-S2
Typical starter system using 2 x HARMONIA-12UP passive per side with
2 x TEUTAES sub on the ground with 2 x PAX-P16 Amp + 1 x HEIMDALL
D05 FIR Controller. Same Amping can double the speakers to run.
www.cadenbach.eu
