HEBE 6.5 inch FIR point source loudspeaker
Safety precautions
YOU ART. WE SOUND.
Potential risk of personal injury
Never stand in the direct sound beam close to a loudspeakers driven at a high level.
Professional loudspeaker systems can cause sound pressure levels that could harm
human health. Noncritical sound levels at about 90 dB can cause hearing damage if
people are exposed to it over a longer period.
In order to prevent accidents when deploying loudspeakers on the ground or when
own, please take note of the following:
• When setting up the loudspeakers or loudspeaker stands, make sure they are
standing on a rm surface. If you place several systems on top of one another, use
straps to secure them against movement.
• Only use accessories which have been tested and approved by Cadenbach Acous-
tics for assembly and mobile applications. Pay attention to the correct application
and maximum load capacity of the accessories.
• Ensure that all additional hardware, xings and fasteners used for installation or
mobile use are of an appropriate size and load safety factor. Pay attention to the
manufacturers instructions and to the relevant safety guidelines.
• Regularly check the loudspeaker housings and accessories for visible signs of
wear and tear, and replace them when necessary.
• Regularly check all load bearing bolts in the mounting devices.
Potential risk of material damage
Loudspeakers produce a static magnetic eld even if they are not connected or not
in use. Therefore make sure when erecting and transporting loudspeakers that they
are not near equipment and objects which may be impaired or damaged by an ex-
ternal magnetic eld.
WARNINGS ON THE SPEAKERS BACK PLATE:
THIS EQUIPMENT CAN GENERATE EXTREME SOUND PRESSURE LEVELS THAT CAN LEAD TO
PERMANENT HEARING DAMAGE.
THIS SURFACE MAY REACH HIGH TEMPERATURES WHILE IN USE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE.
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
ONLY PERSONAL CERTIFIED TO BE TRAINED BY CADENBACH ACOUSTICS, HAVING PASSED
S1 COURSE SHOULD SETUP THIS SYSTEM, OTHERWISE ANY WARRANTY IS VOID. SEE COR-
RESPONDING MANUAL.
MADE IN GERMANY / EU
www.cadenbach.eu

HEBE 6.5 inch FIR point source loudspeaker
Product description
YOU ART. WE SOUND.
Overview
HEBE is versatile point source loudspeaker with rotatable able Horn in an extreme compact
multi- shape design. It also provides mounting points for easy horizontal and vertical cradle
attachment. Even full active equipped HEBE is still light wight and offers up to 128 dB SPL
at 1 meter. This enables the system to be used as main Loudspeaker system for small ap-
plications either as single speaker or in multiple horizontal and also vertical speaker array
arrangement.
HEBE was designed for exibility, whether using the speaker vertically or horizontally the Mid
to High frequency 95° by 55° (55° x 95° when rotated by 90°) CD horn delivers constant di-
rectivity and dispersion control and can be rotated into either the horizontal or vertical plane.
The construction of the 6.5 inch Low frequency cone with it’s 1.5 inch voice coil and Mid To
High 1 inch exit driver section offers phase coherence between both chassis around crossover
point of more than 3 octaves. The ring radiator design of the Mid to High compression driver
has got a 1.75 inch voice coil delivering extra high excursion possibilities and radiates distor-
tion free sound also above 16 kHz.
TETHRA is the dedicated low frequency extension, anyway all cadenbach acoustic sub woof-
ers can be chosen to run with HEBE.
On order HEBE incorporates a very power full two channel frequency modulated oating
modulator amplier. Due to it’s advanced high efciency power technology it runs at any mo-
ment at very low temperature and needs no fan cooling at all.
Operation
The frequency and phase response of HEBE is smooth at very low THD. HEBE can run full
passive and on order without the need a controller and it can run in linear phase mode by us-
ing cadenbach acoustics FIR lter of the HEIMDALL D1 digital controller. It’s rotatable horn
offers full CD dispersion control in horizontal and vertical point source mode.
Applications
• Small concert halls, theatres and houses of worship, AV applications.
• Small stage monitor, small main system sound reinforcement.
• Side or front ll system also for large Systems, under balcony or distributed system.
Features
• Multi- shape design with high output level, with optional integrated amplier
• Optimal integration with TETHRA sub woofer.
• CD coverage via rotatable horn and Cadenbach Acoustics FIR lters.
• Integration mounting points for horizontal and vertical cradle.
www.cadenbach.eu

Technical Specications
Transducers
• Low frequency: 6.5 inches
(170 mm) Neodymium
• High frequency: 1 inches
(25.4 mm) Neodymium
Voice coil size and impedance
• Low frequency: 1.5 inches
(38 mm) Cu, 16 ohms
• High frequency: 1.75 inches
(44.4 mm) Cu, 16 ohms
Diaphragm size
• High frequency: 1.75 inches
(44.4 mm) Polyester
Exit size
• High frequency: 1 inches
(25.4 mm) port
Nominal Impedance
• Low frequency: 16 ohms
• High frequency: 16 ohms
• Passive: 16 ohms
Z = 16 ohms
Output at 1m
• 128 dB SPL ( 3 )
driven with PAX P16 124 dB
driven with internal amps 124.5 dB
Sensitivity (SPL at 1m)
• Low frequency: 94 (300 kHz) dB / 115 dB
cont. at 130 watts
• High frequency: 112 (3 kHz) dB / 133 dB
cont. at 80 watts
• Passive: 98 (1.4 Hz) dB / 119 dB
cont. at 150 watts
Power Handling
• Low frequency: 600 watts peak
130 watts AES
260 watts program
rec. amp power on 4 ohms
2800 watts
• High frequency: 450 watts peak
80 watts AES
240 watts program
rec. amp power on 4 ohms
2800 watts
• Passive: 600 watts peak
150 watts AES
300 watts program
rec. amp power on 4 ohms
2800 watts
Crossover type and frequency
• Filter type active: FIR zero phase
Low to Mid High: 1.2 - 1.6 kHz
• Filter type passive: None / FIR zero phase
Low to Mid High: 1.2 kHz
• Sub to Low: 90 Hz - 120 Hz
Data
Frequency and Phase response
• Usable frequency range: 53 Hz - 21.5 kHz ( 1 )
• Free eld frequency response: 78 Hz - 21 kHz
(-5 dB) linearity (+/- 0.5 dB)
passive no lter(+/- 2.5 dB)
• Phase response: 0° +/- 2°
from 280 Hz to 21.5 kHz
passive: 180° to - 50° from 77 Hz to 17.5 kHz
Size and weight
• Height: 14.33 inches (364 mm)
• Width: 8.9 inches (226 mm)
• Depth: 8.98 inches (228 mm)
• Weight:
18.74 lbs (7.5 kg) passive model
16.53 lbs (8.5 kg) active model
Coverage
• Horizontal coverage:
95° rotatable
• Vertical coverage:
55° rotatable
Speakers per PAX P16 channel
• For passive model:
4 / 6 ( 2 ) parallel via link
Connection
• For passive model:
4 x NL4 (1+/1- passive, 2+/2- link)
( 1 ) Full-range mode, pro-
viding 105 dB @ 53 Hz
( 2 ) possible only with short
length cables.
( 3 ) SPL max peak, test
signal: pink noise with crest
factor 6 dB.
www.cadenbach.eu
HEBE 6.5 inch FIR point source loudspeaker
229
226
226
364

Data
HEBE 6.5 inch FIR point source loudspeaker
www.cadenbach.eu
Technical Specications
Internal Amp module
• Type of output stage: free oating
modulator FM out put power stage
• Total output Power and Volts:
into 16 ohms
Music: 2 x 475 watts at 87 V peak
RMS: 2 x 230 watts at 61 V rms
• Low frequency:
475 watts peak / 230 watts rms
• High frequency:
475 watts peak / 230 watts rms
Audio specications
• IM: 0,05% (SMPTE)
• DIM: 0,005% (DIM 100)
• THD: 0,02% (+N 20 Hz – 20 kHz)
Audio input Connection
• XLR 3 pin
female in and male link out
3pin: 1g, 2 +, 3 -
Audio input Impedance
• 20 kOhms symmetric (between + and -),
• 10 kOhms non symmetric (- grounded).
Ac Power connection
• Powercon 25 A blue in and white link
(max 12,6 A link)
Ac Power specications
• 180 – 265 V AC 50 Hz / 300 VA
on order 110 V AC 60 Hz / 300 VA
Mechanical specications
• Mounting: 4 x M5 inserts
• Working load: 12 x Speaker-weight
• Construction: 15 - 27 mm Plywood
steal grill with foam, powder coated,
inside acoustic carpet,
foam and glue damping.
Internal amp module mounted on 2 mm
aluminum internal plate with total passive fan
free cooling.
• Flying frame: U-type Cradle
CSR-7 and CSR-7H (for horizontal mounting)

Data
Measurements
Frequency response with FIR Filter of HEBE
Phase response FIR linear phase Filter of HEBE
www.cadenbach.eu
HEBE 6.5 inch FIR point source loudspeaker

Systems
HEBE 6.5 inch FIR point source loudspeaker
www.cadenbach.eu
System setups: HEBE-S1
Typical starter system using 4 x HEBE-7P passive per side with
1 x TETHRA sub on the ground with 2 x PAX-P16 Amp + 1 x HEIMDALL
D05 FIR Controller, same Amping can double the speakers to run.
READY/PROTECT
SIGNAL
BRIDGEBRIDGE
CLIP/NLR
CH2-dB CH1-dB
TEMPLIMIT/TCL
SUPPLYOVL
0
oo
2
4
6
8
10
12
14
18
24
0
oo
2
4
6
8
10
12
14
18
24
POWER ON
cadenbachacoustics
P16 die-seriessystemamplier
READY/PROTECT
SIGNAL
BRIDGEBRIDGE
CLIP/NLR
CH2-dB CH1-dB
TEMPLIMIT/TCL
SUPPLYOVL
0
oo
2
4
6
8
10
12
14
18
24
0
oo
2
4
6
8
10
12
14
18
24
POWER ON
cadenbachacoustics
P16 die-seriessystemamplier
cadenbachacoustics
TCP/IP-ACT
TCP/IP-LINK
POWER
D1
die-seriessystemcontroller
cadenbachacoustics
TCP/IP-ACT
TCP/IP-LINK
POWER
D1
die-seriessystemcontroller
READY/PROTECT
SIGNAL
BRIDGEBRIDGE
CLIP/NLR
CH2-dBCH1-dB
TEMPLIMIT/TCL
SUPPLYOVL
0
oo
2
4
6
8
10
12
14
18
24
0
oo
2
4
6
8
10
12
14
18
24
POWER ON
cadenbachacoustics
P16 die-seriessystemamplier
System setups: HEBE-S2
Typical starter system using 2 x HEBE active per side with
1 x TETHRA active sub on the ground.

Save operating
Protecting your speaker
HEBE 6.5 inch FIR point source loudspeaker
HEBE speakers may be used in combination with Cadenbach Acoustics
PAX Ampliers and Cadenbach Acoustics HEIMDALL controller.
In general, audio signals must not be over driven. This may be caused by
mixing consoles, equalizers, effect equipment, etc. and should be indi-
cated on this equipment. When a power amplier is over- loaded at the
output (clipping), then the amplier activates a clipping warning signal.
In any case, the signal must be reduced as soon as it sounds unnaturally
distorted.
Damage caused by overloading the speakers or using the speakers with-
out Cadenbach Acoustics PAX and HEIMDALL we do not assume warranty
and excludes liability for possible consequential damage.
Permanent high-level signals with high frequency and continuous noise
from feedback or permanently distorted high-level signals or noises,
which occur when the amplier is on while equipment is being connected,
disconnected or switched on could damage the loudspeakers.
Do not install loudspeakers at places where they are permanently ex-
posed to direct sunlight, high moisture, direct rain or strong vibrations
and dust.
www.cadenbach.eu

HEBE 6.5 inch FIR point source loudspeaker
Manufacturer’s Declarations
YOU ART. WE SOUND.
EU conformity of loudspeakers (CE symbol)
This declaration applies to:
Cadenbach Acoustics loudspeaker, HEBE-7
Cadenbach Acoustics loudspeaker, HEBE-7P
Cadenbach Acoustics loudspeaker, iHEBE-7
Cadenbach Acoustics loudspeaker, iHEBE-7P
All production versions of these types are included, provided they correspond to the
original technical version and have not been subject to any later design or electro-
mechanical modications.
We herewith declare that said products are in conformity with the provisions of the
respective EC directives including all applicable amendments.
A detailed declaration is available on request and can be ordered from Cadenbach
Acoustics.
WEEE Declaration (Disposal)
Electrical and electronic equipment must be disposed of separately from normal
waste at the end of its operational lifetime.
Please dispose of this product according to the respective national regulations or
contractual agreements. If there are any further questions concerning the disposal
of this product, please contact Cadenbach Acoustics.
[email protected]
www.cadenbach.eu
Cadenbach Acoustics
Germany
