cadenbach MINERVA User manual

MINERVA Manual volume: E 0.0

MINERVA 10 inch FIR point source loudspeaker
Safety precautions
YOU ART. WE SOUND.
Potential risk of personal injury
Never stand in the direct sound beam close to a loudspeakers driven at a high level.
Professional loudspeaker systems can cause sound pressure levels that could harm
human health. Noncritical sound levels at about 90 dB can cause hearing damage if
people are exposed to it over a longer period.
In order to prevent accidents when deploying loudspeakers on the ground or when
own, please take note of the following:
• When setting up the loudspeakers or loudspeaker stands, make sure they are
standing on a rm surface. If you place several systems on top of one another, use
straps to secure them against movement.
• Only use accessories which have been tested and approved by Cadenbach Acous-
tics for assembly and mobile applications. Pay attention to the correct application
and maximum load capacity of the accessories.
• Ensure that all additional hardware, xings and fasteners used for installation or
mobile use are of an appropriate size and load safety factor. Pay attention to the
manufacturers instructions and to the relevant safety guidelines.
• Regularly check the loudspeaker housings and accessories for visible signs of
wear and tear, and replace them when necessary.
• Regularly check all load bearing bolts in the mounting devices.
Potential risk of material damage
Loudspeakers produce a static magnetic eld even if they are not connected or not
in use. Therefore make sure when erecting and transporting loudspeakers that they
are not near equipment and objects which may be impaired or damaged by an ex-
ternal magnetic eld.
WARNINGS ON THE SPEAKERS BACK PLATE:
THIS EQUIPMENT CAN GENERATE EXTREME SOUND PRESSURE LEVELS THAT CAN LEAD TO
PERMANENT HEARING DAMAGE.
THIS SURFACE MAY REACH HIGH TEMPERATURES WHILE IN USE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE.
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
ONLY PERSONAL CERTIFIED TO BE TRAINED BY CADENBACH ACOUSTICS, HAVING PASSED
S1 COURSE SHOULD SETUP THIS SYSTEM, OTHERWISE ANY WARRANTY IS VOID. SEE COR-
RESPONDING MANUAL.
MADE IN GERMANY / EU
www.cadenbach.eu

MINERVA 10 inch FIR point source loudspeaker
Product description
YOU ART. WE SOUND.
Overview
MINERVA is a point source loudspeaker with rotatable and interchange able Horn in a trap-
ezoid design. MINERVA offers four 8 mm inserts for mounting. Even full active equipped
MINERVA is still light wight and offers in all version more than 133 dB SPL at 1 meter. This
enables the system to be used as main Loudspeaker system either as single speaker or in
multiple horizontal and also vertical speaker array arrangement.
MINERVA was designed for wide range natural sound reproduction, whether using the speak-
er vertically or horizontally the Mid to High frequency 65° by 40° (95° x 55° when ordering
MINERVA9) CD horn delivers constant directivity and dispersion control and can be rotated
into either the horizontal or vertical plane.
The construction of the 10 inch Low frequency neodymium cone with it’s 2.5 inch voice coil
and Mid To High 1.5 inch exit driver section offers phase coherence between both chassis
around crossover point of more than 4 octaves, creating a remarkable point source behav-
iour. The ring radiator design of the Mid to High compression driver has got a 1.75 inch voice
coil delivering extra high excursion possibilities and radiates distortion free sound also above
16 kHz.
TEUTATES is the dedicated low frequency extension, anyway all cadenbach acoustic sub
woofers can be chosen to run with MINERVA.
On order MINERVA incorporates a very power full frequency modulated oating modulator
amplier. Due to it’s advanced high efciency power technology it runs at any moment at
very low temperature and needs no fan cooling at all.
Operation
The frequency and phase response of MINERVA is exceptional smooth at very low THD.
MAGNA can run passive but needs some frequency correction of a controller and it can run in
linear phase mode by using Cadenbach Acoustics FIR lter of the HEIMDALL D1 digital con-
troller. It’s rotatable and interchange able horn offers full CD dispersion control in horizontal
and vertical point source mode.
Applications
• Small concert halls, theatres and houses of worship, AV applications.
• Small to medium main system sound reinforcement.
• Side or front ll system, under balcony or distributed system.
Features
• Trapezoid design with wide range output, with optional integrated amplier
• Optimal integration with TEUTATES sub woofer.
• Very exible CD coverage via rotatable, replace able Horn and Cadenbach Acoustics FIR lters.
• Four 6 mm inserts for various own congurations
www.cadenbach.eu

Technical Specications
Transducers
• Low frequency: 10 inches
(254 mm) Neodymium
• High frequency: 1.5 inches
(38 mm) Neodymium
Voice coil size and impedance
• Low frequency: 2.5 inches
(64 mm) Al, 8 ohms
• High frequency: 1.75 inches
(44.4 mm) Cu, 16 ohms
Diaphragm size
• High frequency: 1.75 inches
(44.4 mm) Polyester
Exit size
• High frequency: 1.5 inches
(38 mm) port
Nominal Impedance
• Low frequency: 8 ohms
• High frequency: 16 ohms
• Passive: 8 ohms
Z = 8 ohms
Output at 1m
• 135 dB SPL ( 3 )
driven with PAX P16 134 dB
driven with internal amps 134 dB
• MINERVA9: 134 dB SPL ( 3 )
driven with PAX P16 133 dB
driven with internal amps 133 dB
Sensitivity (SPL at 1m)
• Low frequency: 106 (300 Hz) dB / 131 dB
cont. at 400 watts
• High frequency: 115 (1.5 kHz) dB / 134 dB
cont. at 80 watts
• Passive: 106 (300 Hz) dB / 128 dB
cont. at 400 watts
Power Handling
• Low frequency: 1500 watts peak
400 watts AES
800 watts program
rec. amp power on 4 ohms
2800 watts
• High frequency: 450 watts peak
80 watts AES
240 watts program
rec. amp power on 4 ohms
2800 watts
• Passive: 1200 watts peak
600 watts AES
900 watts program
rec. amp power on 4 ohms
2800 watts
Data
Crossover type and frequency
• Filter type active: FIR zero phase
Low to Mid High: 1.1 - 1.6 kHz
• Filter type passive: NONE / IIR / FIR zero phase
Low to Mid High: 1.5 kHz
• Sub to Low: 70 Hz - 130 Hz
Frequency and Phase response
• Usable frequency range: 58 Hz - 22 kHz ( 1 )
• Free eld frequency response: 78 Hz - 19.5 kHz
(-5 dB) linearity (+/- 0.5 dB)
passive with IIR lter (+/- 2 dB)
• Phase response: 0° +/- 2°
from 280 Hz to 21.5 kHz
passive with IIR:
180° to - 180° from 77 Hz to 17 kHz
Size and weight
• Height: 23.58 inches (599 mm)
• Width: 14.65 inches (372 mm)
• Depth: 12.20 inches (310 mm)
• Weight:
44.09 lbs (20 kg) passive model
52.91 lbs (24 kg) active model
Coverage
• Horizontal coverage:
65° rotatable
MINERVA9: 95° rotatable
• Vertical coverage:
40° rotatable
MINERVA9: 55° rotatable
Speakers per PAX P16 channel
• For passive model:
2 / 3 ( 2 ) parallel via link
Connection
• For passive model:
2 x NL4 (1+/1- passive, 2+/2- link)
( 1 ) Full-range mode, pro-
viding 113 dB @ 52 Hz
( 2 ) possible only with short
length cables.
( 3 ) SPL max peak, test
signal: pink noise with crest
factor 6 dB.
www.cadenbach.eu
MINERVA 10 inch FIR point source loudspeaker
372 mm
310 mm
310 mm
599 mm
241 mm

Data
MINERVA 10 inch FIR point source loudspeaker
www.cadenbach.eu
Technical Specications
Internal Amp module
• Type of output stage: free oating
modulator FM out put power stage
• Total output Power and Volts:
into 8 ohms
Music: 2 x 2800 watts at 150 Vpk
RMS: 2 x 1400 watts at 106 V
iMINERVA
into 6 ohms
Music: 1 x 1200 watts at 87 V peak
RMS: 1 x 620 watts at 61 V rms
• Low frequency:
2800 watts peak / 1400 watts rms
• High frequency:
1400 watts peak / 700 watts rms
• iMinerva:
1200 watts peak / 620 watts rms
Audio specications
• IM: 0,05% (SMPTE)
• DIM: 0,005% (DIM 100)
• THD: 0,02% (+N 20 Hz – 20 kHz)
Audio input Connection
• XLR 5 pin, (iMINERVA XLR 3 pin)
female in and male link out
5pin: 1g, 2 LF+, 3 LF-, 4 HF+, 5 HF-,
3pin: 1g, 2 +, 3 -
Audio input Impedance
• 20 kOhms symmetric (between + and -),
• 10 kOhms non symmetric (- grounded).
Ac Power connection
• Powercon 25 A blue in and white link
(max 12,6 A link)
Ac Power specications
• 180 – 265 V AC 50 Hz / 2200 VA
iMinerva 110 V AC 60 Hz / 300 VA
Mechanical specications
• Mounting: four 8 mm inserts
• Working load: 12 x Speaker-weight
• Construction: 15 - 27 mm Plywood
steal grill with foam, powder coated,
inside acoustic carpet,
foam and glue damping.
Internal amp module mounted on 7 mm
(2 mm) for iMINERVA
aluminum back plate with total passive fan
free cooling.
• Flying frame: CSR-10

Data
Measurements
Frequency response with FIR Filter of MINERVA
Phase response FIR linear phase Filter of MINERVA
www.cadenbach.eu
MINERVA 10 inch FIR point source loudspeaker

Systems
MINERVA 10 inch FIR point source loudspeaker
System setups: MINERVA S2
Typical starter system using 2 x iMINERVA-10 active per side with
2 x TETHRA sub and 1 x HEIMDALL D05 controller.
www.cadenbach.eu
System setups: MINERVA S1
System for Main or side, stage ll system use, with 4 x MINERVA-10P with 4 x TE-
THRA subwoofer, 2 x PAX-P16 Amp + 1 x HEIMDALL D05 FIR Controller.
cadenbachacoustics
TCP/IP-ACT
TCP/IP-LINK
POWER
D1
die-seriessystemcontroller
cadenbachacoustics
TCP/IP-ACT
TCP/IP-LINK
POWER
D1
die-seriessystemcontroller
READY/PROTECT
SIGNAL
BRIDGEBRIDGE
CLIP/NLR
CH2-dBCH1-dB
TEMPLIMIT/TCL
SUPPLYOVL
0
oo
2
4
6
8
10
12
14
18
24
0
oo
2
4
6
8
10
12
14
18
24
POWER ON
cadenbachacoustics
P16 die-seriessystemamplier
READY/PROTECT
SIGNAL
BRIDGEBRIDGE
CLIP/NLR
CH2-dBCH1-dB
TEMPLIMIT/TCL
SUPPLYOVL
0
oo
2
4
6
8
10
12
14
18
24
0
oo
2
4
6
8
10
12
14
18
24
POWER ON
cadenbachacoustics
P16 die-seriessystemamplier
READY/PROTECT
SIGNAL
BRIDGEBRIDGE
CLIP/NLR
CH2-dBCH1-dB
TEMPLIMIT/TCL
SUPPLYOVL
0
oo
2
4
6
8
10
12
14
18
24
0
oo
2
4
6
8
10
12
14
18
24
POWER ON
cadenbachacoustics
P16 die-seriessystemamplier
cadenbachacoustics
TCP/IP-ACT
TCP/IP-LINK
POWER
D1
die-seriessystemcontroller
cadenbachacoustics
TCP/IP-ACT
TCP/IP-LINK
POWER
D1
die-seriessystemcontroller
READY/PROTECT
SIGNAL
BRIDGEBRIDGE
CLIP/NLR
CH2-dBCH1-dB
TEMPLIMIT/TCL
SUPPLYOVL
0
oo
2
4
6
8
10
12
14
18
24
0
oo
2
4
6
8
10
12
14
18
24
POWER ON
cadenbachacoustics
P16 die-seriessystemamplier

Save operating
Protecting your speaker
MINERVA 10 inch FIR point source loudspeaker
MINERVA speakers may be used in combination with Cadenbach Acoustics
PAX Ampliers and Cadenbach Acoustics HEIMDALL controller.
In general, audio signals must not be over driven. This may be caused by
mixing consoles, equalizers, effect equipment, etc. and should be indi-
cated on this equipment. When a power amplier is over- loaded at the
output (clipping), then the amplier activates a clipping warning signal.
In any case, the signal must be reduced as soon as it sounds unnaturally
distorted.
Damage caused by overloading the speakers or using the speakers with-
out Cadenbach Acoustics PAX and HEIMDALL we do not assume warranty
and excludes liability for possible consequential damage.
Permanent high-level signals with high frequency and continuous noise
from feedback or permanently distorted high-level signals or noises,
which occur when the amplier is on while equipment is being connected,
disconnected or switched on could damage the loudspeakers.
Do not install loudspeakers at places where they are permanently ex-
posed to direct sunlight, high moisture, direct rain or strong vibrations
and dust.
www.cadenbach.eu

MINERVA 10 inch FIR point source loudspeaker
Manufacturer’s Declarations
YOU ART. WE SOUND.
EU conformity of loudspeakers (CE symbol)
This declaration applies to:
Cadenbach Acoustics loudspeaker, MINERVA-10
Cadenbach Acoustics loudspeaker, MINERVA-10P
Cadenbach Acoustics loudspeaker, iMINERVA-10
Cadenbach Acoustics loudspeaker, MINERVA9-10
Cadenbach Acoustics loudspeaker, MINERVA9-10P
Cadenbach Acoustics loudspeaker, iMINERVA9-10
All production versions of these types are included, provided they correspond to the
original technical version and have not been subject to any later design or electro-
mechanical modications.
We herewith declare that said products are in conformity with the provisions of the
respective EC directives including all applicable amendments.
A detailed declaration is available on request and can be ordered from Cadenbach
Acoustics.
WEEE Declaration (Disposal)
Electrical and electronic equipment must be disposed of separately from normal
waste at the end of its operational lifetime.
Please dispose of this product according to the respective national regulations or
contractual agreements. If there are any further questions concerning the disposal
of this product, please contact Cadenbach Acoustics.
[email protected]
www.cadenbach.eu
Cadenbach Acoustics
Germany
