Cadillac 2006 Escalade User manual

Seats and Restraint Systems ........................... 1-1
Front Seats ............................................... 1-2
Rear Seats ............................................... 1-7
Safety Belts .............................................. 1-8
Child Restraints ....................................... 1-26
Airbag System ......................................... 1-48
Restraint System Check ............................ 1-63
Features and Controls ..................................... 2-1
Keys ........................................................ 2-3
Doors and Locks ...................................... 2-12
Windows ................................................. 2-17
Theft-Deterrent Systems ............................ 2-20
Starting and Operating Your Vehicle ........... 2-24
Mirrors .................................................... 2-41
OnStar
®
System ...................................... 2-45
Universal Home Remote System ................ 2-47
Storage Areas ......................................... 2-51
Sunroof .................................................. 2-52
Vehicle Personalization ............................. 2-53
Instrument Panel ............................................. 3-1
Instrument Panel Overview .......................... 3-4
Climate Controls ...................................... 3-48
Warning Lights, Gages, and Indicators ........ 3-57
Driver Information Center (DIC) .................. 3-73
Audio System(s) ....................................... 3-94
Driving Your Vehicle ....................................... 4-1
Your Driving, the Road, and Your Vehicle ..... 4-2
Towing ................................................... 4-37
Service and Appearance Care .......................... 5-1
Service ..................................................... 5-3
Fuel ......................................................... 5-5
Checking Things Under the Hood ............... 5-10
All-Wheel Drive ........................................ 5-51
Rear Axle ............................................... 5-52
Front Axle ............................................... 5-53
Bulb Replacement .................................... 5-54
Windshield Replacement ........................... 5-56
Windshield Wiper Blade Replacement ......... 5-56
Tires ...................................................... 5-57
Appearance Care ..................................... 5-94
Vehicle Identification ............................... 5-103
Electrical System .................................... 5-104
Capacities and Specifications ................... 5-116
Maintenance Schedule ..................................... 6-1
Maintenance Schedule ................................ 6-2
Customer Assistance and Information .............. 7-1
Customer Assistance and Information ........... 7-2
Reporting Safety Defects ........................... 7-13
Index ................................................................ 1
2006 Cadillac STS/STS-V Owner Manual M

GENERAL MOTORS, GM, the GM Emblem, CADILLAC,
the CADILLAC Crest & Wreath, and the name STS
are registered trademarks of General Motors
Corporation.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes in
the product after that time without notice. For vehicles
first sold in Canada, substitute the name “General
Motors of Canada Limited” for Cadillac Motor Car
Division whenever it appears in this manual.
Keep this manual in the vehicle, so it will be there if it is
needed while you are on the road. If the vehicle is
sold, leave this manual in the vehicle.
Canadian Owners
A French language copy of this manual can be obtained
from your dealer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
How to Use This Manual
Many people read the owner manual from beginning to
end when they first receive their new vehicle. If this
is done, it can help you learn about the features
and controls for the vehicle. Pictures and words work
together in the owner manual to explain things.
Index
A good place to quickly locate information about the
vehicle is the Index in the back of the manual. It is an
alphabetical list of what is in the manual and the
page number where it can be found.
Litho in U.S.A.
Part No. 06STS A First Printing
©
2005 General Motors Corporation. All Rights Reserved.
ii

Safety Warnings and Symbols
There are a number of safety cautions in this book. We
use a box and the word CAUTION to tell about things
that could hurt you if you were to ignore the warning.
{CAUTION:
These mean there is something that could hurt
you or other people.
In the caution area, we tell you what the hazard is.
Then we tell you what to do to help avoid or reduce the
hazard. Please read these cautions. If you do not,
you or others could be hurt.
You will also find a circle
with a slash through it in
this book. This safety
symbol means “Do Not,”
“Do Not do this” or “Do Not
let this happen.”
iii

Vehicle Damage Warnings
Also, in this manual you will find these notices:
Notice: These mean there is something that could
damage your vehicle.
A notice tells about something that can damage the
vehicle. Many times, this damage would not be covered
by your vehicle’s warranty, and it could be costly. But
the notice will tell what to do to help avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors
or in different words.
There are also warning labels on the vehicle. They use
the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along with
the text describing the operation or information
relating to a specific component, control, message,
gage, or indicator.
If you need help figuring out a specific name of a
component, gage, or indicator, reference the
following topics:
•Seats and Restraint Systems in Section 1
•Features and Controls in Section 2
•Instrument Panel Overview in Section 3
•Climate Controls in Section 3
•Warning Lights, Gages, and Indicators in Section 3
•Audio System(s) in Section 3
•Engine Compartment Overview in Section 5
iv

These are some examples of symbols that may be found on the vehicle:
v

✍NOTES
vi

Front Seats ......................................................1-2
Power Seats ..................................................1-2
Power Lumbar ...............................................1-2
Heated Seats .................................................1-3
Heated and Ventilated Seats ............................1-4
Power Reclining Seatback ...............................1-5
Head Restraints .............................................1-6
Rear Seats .......................................................1-7
Heated Seats .................................................1-7
Rear Seat Pass-Through Door .........................1-7
Safety Belts .....................................................1-8
Safety Belts: They Are for Everyone .................1-8
Questions and Answers About Safety Belts ......1-12
How to Wear Safety Belts Properly .................1-13
Driver Position ..............................................1-13
Shoulder Belt Height Adjustment .....................1-20
Safety Belt Use During Pregnancy ..................1-20
Right Front Passenger Position .......................1-21
Rear Seat Passengers ..................................1-21
Rear Safety Belt Comfort Guides ....................1-23
Safety Belt Pretensioners ...............................1-25
Safety Belt Extender .....................................1-26
Child Restraints .............................................1-26
Older Children ..............................................1-26
Infants and Young Children ............................1-29
Child Restraint Systems .................................1-32
Where to Put the Restraint .............................1-36
Lower Anchors and Tethers for
Children (LATCH) ......................................1-37
Securing a Child Restraint in a
Rear Seat Position ....................................1-43
Securing a Child Restraint in the Right
Front Seat Position ....................................1-45
Airbag System ...............................................1-48
Where Are the Airbags? ................................1-51
When Should an Airbag Inflate? .....................1-55
What Makes an Airbag Inflate? .......................1-56
How Does an Airbag Restrain? .......................1-56
What Will You See After an Airbag Inflates? .....1-57
Passenger Sensing System ............................1-58
Servicing Your Airbag-Equipped Vehicle ...........1-62
Adding Equipment to Your Airbag-Equipped
Vehicle ....................................................1-62
Restraint System Check ..................................1-63
Checking the Restraint Systems ......................1-63
Replacing Restraint System
Parts After a Crash ...................................1-64
Section 1 Seats and Restraint Systems
1-1

Front Seats
Power Seats
The power seat controls
are located on the
outboard sides of the
front seat cushions.
•Move the front of the horizontal control up or down
to adjust the front portion of the cushion.
•Move the rear of the horizontal control up or down
to adjust the rear portion of the cushion.
•Slide the horizontal control forward or rearward to
move the entire seat forward or rearward.
•Press the vertical control rearward to recline the
seatback. Press the vertical control forward to raise
the seatback. See Power Reclining Seatback
on page 1-5.
If your vehicle has the memory feature, you can
program and recall memory settings for seat positions.
See Memory Seat, Mirrors and Steering Wheel on
page 2-70.
Power Lumbar
Your vehicle’s seats may be equipped with power
lumbar.
You can increase or
decrease lumbar support
in an area of the lower
seatback with this control,
located on the outboard
sides of the front seat(s).
To increase support, press and hold the front of the
control. To decrease support, press and hold the rear
of the control. Let go of the control when the lower
seatback reaches the desired level of support.
1-2

To raise the position of the lumbar support, press and
hold the top of the control. To lower the position of
lumbar support, press and hold the bottom of the control.
Let go of the control when the lower seatback reaches
the desired level of support.
Your vehicle may have a memory function which allows
seat settings to be saved and recalled. See Memory
Seat, Mirrors and Steering Wheel on page 2-70 for
more information.
Heated Seats
Your vehicle may have
heated front seats. The
buttons are located on the
climate control panel.
z(Heated Seat and Seatback): This button is for the
heated seat and seatback. Press the up arrow once
to turn on the heated seat at the highest setting. Press
the down arrow once to turn on the heated seat at
the lowest setting.
Pressing the up or down arrows a second time will raise
or lower the setting. To turn off the heated seat keep
pressing the down arrow until the indicator for heated
seat on the climate control display is off.
A light bar in the climate control display shows the
setting: high, medium, or low. The longest bar shows
the high range and the shortest bar shows the low
range.
The heated seat will automatically shut off when the
vehicle is turned off.
1-3

Heated and Ventilated Seats
Your vehicle may have
heated and ventilated
front seats. The buttons
are located on the climate
control panel.
z(Heated Seat and Seatback): This part of the
button is for the heated seat and seatback.
{(Ventilated Seat): This part of the button is for
the ventilated seat.
There are three settings for each feature. A light bar
in the climate control display shows the setting;
high, medium or low. The longest bar shows the high
range and the shortest bar shows the low range.
Pressing either the heated seat or ventilated part of
the seat button will start that feature at the highest
setting. Each time you press the button, the feature
will decrease one setting.
To turn the feature off, keep pressing the button until
the display lights turn off.
The heated or ventilated seats will automatically shut
off when the vehicle is turned off.
1-4

Power Reclining Seatback
The vertical power seat control described earlier allows
the seatback to recline. See Power Seats on page 1-2
for more information.
Do no have a seatback reclined if your vehicle is
moving.
{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts cannot do their
job when you are reclined like this.
The shoulder belt cannot do its job because it
will not be against your body. Instead, it will be
in front of you. In a crash, you could go into it,
receiving neck or other injuries.
The lap belt cannot do its job either. In a crash,
the belt could go up over your abdomen. The
belt forces would be there, not at your pelvic
bones. This could cause serious internal
injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety belt
properly.
1-5

Head Restraints
The front and rear head
restraints lock into place
when raised. To release
the head restraint and
lower it, press the
tab located at the base
of the restraint.
The front head restraints also tilt forward and rearward.
Adjust your head restraint so that the top of the restraint
is closest to the top of your head. This position reduces
the chance of a neck injury in a crash.
1-6

Rear Seats
Heated Seats
Your vehicle may have this feature. The buttons used to
control the heated rear seats are located on the back
of the center console. The engine must be running
for the heated seat feature to work.
z(Heated Seat and Seatback): Press this button to
turn the heated seat feature on. When you press the
button, the feature will turn on at the highest setting.
Each time you press the button, the feature will go down
one temperature setting. A light next to the button will
indicate the setting; 3 is the highest, 1 is the lowest.
To turn the feature off, keep pressing the button until
the indicator light goes off.
The heated rear seats will shut off automatically when
the ignition is turned off.
Rear Seat Pass-Through Door
Your vehicle has a pass-through door that provides
access to the trunk from the rear seats. See “Rear Seat
Pass-Through Door” under Trunk on page 2-14.
1-7

Safety Belts
Safety Belts: They Are for Everyone
This part of the manual tells you how to use safety
belts properly. It also tells you some things you should
not do with safety belts.
{CAUTION:
Do not let anyone ride where he or she cannot
wear a safety belt properly. If you are in a
crash and you are not wearing a safety belt,
your injuries can be much worse. You can hit
things inside the vehicle or be ejected from it.
You can be seriously injured or killed. In the
same crash, you might not be, if you are
buckled up. Always fasten your safety belt,
and check that your passengers’ belts are
fastened properly too.
{CAUTION:
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a
collision, people riding in these areas are more
likely to be seriously injured or killed. Do not
allow people to ride in any area of your vehicle
that is not equipped with seats and safety
belts. Be sure everyone in your vehicle is in a
seat and using a safety belt properly.
Your vehicle has indicators to remind you and your
passengers to buckle your safety belts. See Safety Belt
Reminder Light on page 3-59 and Passenger Safety
Belt Reminder Light on page 3-60.
In most states and in all Canadian provinces, the law
says to wear safety belts. Here is why: They work.
1-8

You never know if you will be in a crash. If you do
have a crash, you do not know if it will be a bad one.
A few crashes are mild, and some crashes can be
so serious that even buckled up, a person would not
survive. But most crashes are in between. In many
of them, people who buckle up can survive and
sometimes walk away. Without belts they could have
been badly hurt or killed.
After more than 30 years of safety belts in vehicles,
the facts are clear. In most crashes buckling up
does matter...a lot!
Why Safety Belts Work
When you ride in or on anything, you go as fast as
it goes.
Take the simplest vehicle. Suppose it is just a seat
on wheels.
1-9

Put someone on it. Get it up to speed. Then stop the vehicle.
The rider does not stop.
1-10

The person keeps going until stopped by something.
In a real vehicle, it could be the windshield... or the instrument panel...
1-11

or the safety belts!
With safety belts, you slow down as the vehicle does.
You get more time to stop. You stop over more distance,
and your strongest bones take the forces. That is why
safety belts make such good sense.
Questions and Answers About
Safety Belts
Q: Will I be trapped in the vehicle after an accident
if I am wearing a safety belt?
A: You could be — whether you are wearing a safety
belt or not. But you can unbuckle a safety belt,
even if you are upside down. And your chance of
being conscious during and after an accident,
so you can unbuckle and get out, is much greater
if you are belted.
Q: If my vehicle has airbags, why should I have to
wear safety belts?
A: Airbags are in many vehicles today and will
be in most of them in the future. But they are
supplemental systems only; so they work with
safety belts — not instead of them. Every airbag
system ever offered for sale has required the use of
safety belts. Even if you are in a vehicle that has
airbags, you still have to buckle up to get the most
protection. That is true not only in frontal collisions,
but especially in side and other collisions.
1-12

Q: If I am a good driver, and I never drive far from
home, why should I wear safety belts?
A: You may be an excellent driver, but if you are in an
accident — even one that is not your fault — you
and your passengers can be hurt. Being a good
driver does not protect you from things beyond your
control, such as bad drivers.
Most accidents occur within 25 miles (40 km)
of home. And the greatest number of serious
injuries and deaths occur at speeds of less
than 40 mph (65 km/h).
Safety belts are for everyone.
How to Wear Safety Belts Properly
This part is only for people of adult size.
Be aware that there are special things to know about
safety belts and children. And there are different
rules for smaller children and babies. If a child will be
riding in your vehicle, see Older Children on page 1-26
or Infants and Young Children on page 1-29. Follow
those rules for everyone’s protection.
First, you will want to know which restraint systems
your vehicle has.
We will start with the driver position.
Driver Position
Lap-Shoulder Belt
The driver has a lap-shoulder belt. Here is how to
wear it properly.
1. Close and lock the door.
2. Adjust the seat so you can sit up straight.
To see how, see “Seats” in the Index.
1-13

3. Pick up the latch plate and pull the belt across you.
Do not let it get twisted.
The shoulder belt may lock if you pull the belt
across you very quickly. If this happens, let the belt
go back slightly to unlock it. Then pull the belt
across you more slowly.
4. Push the latch plate into the buckle until it clicks.
Pull up on the latch plate to make sure it is secure.
If the belt is not long enough, see Safety Belt
Extender on page 1-26.
Make sure the release button on the buckle is
positioned so you would be able to unbuckle the
safety belt quickly if you ever had to.
5. Move the shoulder belt height adjuster to the height
that is right for you. See Shoulder Belt Height
Adjustment on page 1-20.
6. To make the lap part tight, pull up on the
shoulder belt.
7. This safety belt has a feature that will reduce the
tension of the safety belt on the occupant’s
shoulder if the vehicle is on. To set this feature,
gently pull on the belt, or lean forward and then sit
back. The belt will retract and rest lightly against
the occupant.
1-14
