CAI 600 Series User manual

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
6 0 0
S E R I E S
MHFID
Total Hydrocarbon Analyzer
USER’S MANUAL
Note: For Serial Numbers After
June 2007, Please See Addendum on
Page 113 of This Manual

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
Standards
The 600 series instruments meet or exceed the following directives and standards. (CE)
Application of Council Directive(s):
Electrical Safety:
Low Voltage Directive 73/23/EEC
Electromagnetic Compatibility:
EMC Directive 89/336/EEC
Standard(s) to which Conformity is Declared:
Electrical Safety:
Standard for Electrical Equipment for Measurement, Control, and Laboratory Use [EN
61010-1:2001 (2nd Edition)
Electromagnetic Compatibility:
EN 61326:1997 Electrical equipment for measurement, control and laboratory use -
EMC requirements (Amendment A1: 1998 to EN 61326:1997; Amendment A2:2001 to EN
61326:1997)
(This analyzer was tested by ETL to confirm that it is in complete compliance to CE,CSA.
and the equivalent UL specifications, in accordance with the above directives and standards )

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
600 Series HFID Quick Start Guide
Note: DO NOT energize the sample pump or introduce any moisture-containing
sample until the oven has reached an operating temperature of at least 100°C.
1. Connect analyzer to AC power (115 VAC 60 Hz OR 230 VAC 50 Hz , ±10%) and turn
on main power switch that is located on the back panel.
2. Connect combustion air, combustion fuel, zero gas and span gas through the back
panel. Set supply pressures to 20-25 psig.
This analyzer uses a fuel that contains a FLAMMABLE LEVEL OF HYDROGEN.
Any leakage from this fuel can result in an explosion. Carefully check the fuel
supply system, to the analyzer for leaks upon installation, before initial start-up. The
operating technician should be properly trained for work with hazardous materials.
Note: The analyzer uses pure H2 OR a H2/He mixture as indicated on the back
panel and identified as combustion fuel. Serious damage may occur if the incorrect
fuel is used.
Note: Purge fuel line at the analyzer to remove any residual air in the line to aid
in flame ignition.
3. Press and release F8 IGNITE on the main menu to initiate the ignition sequence.
Note: If the Burner fails to ignite a Burner Temp Failure message displays at the
bottom of the screen.
4. Use at least an Extended User Operator Level-3 password for access to the screen
needed to define the value of the span gas that will be used for calibration (See
Section 5.)
5. From the Main Menu, press F5, Setup.
6. Press F1, Range Select.
7. Select the appropriate range for the span gas that is connected to the analyzer and
enter the concentration value of the gas.
Note: The four ranges are specified by the customers order. When not otherwise
defined, the factory default ranges are, 30, 300, 3,000, and 30,000 ppm.
8. Press BACK to return to the SETUP screen.
9. Press F2, Calibration Settings.
10. Press F3 if calibrating using the optional internal solenoids or F5 if calibrating with an
internal or system supplied sample pump.
11. Press Main to return to the Main Menu
12. Press F4, Calibrations, and then press F2, Manual Calibrations.
13. Press F1 to Flow Zero or F2 to Flow Span Gas and observe the displayed results.
14. Press F1 to save the appropriate zero and span calibration values.

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
QUICK MANUAL CALIBRATION
SETUP
1. Define span gas concentration for each range press, F5, F1.
2. Define Calibration path using SOLENOIDS F5, F2, F4, or PROBE (pump) F5, F2, F5.
CALIBRATION
1. Select range (MEASUREMENT screen)
2. Select ZERO GAS press F4, F1, F1.
3. Save Value press F1.
4. Select SPAN GAS press F4, F2, F2.
5. Save Value press F1.
QUICK AUTO CALIBRATION
SETUP
1. Single range
a) Define span gas concentration for each range press F5, F1.
b) Define Calibration path using SOLENOIDS press F5, F2, F4, or PROBE (pump)
press F5, F2, F5.
c) Define Gas flow windows TIMES press F5, F2, F2, (Purge, Calibrating, Verifying,
Purge After).
d) Define Measuring Deviation press F5, F2, F2.
e) Define Deviations press F5, F2, F3 (% Absolute ((CAI Ideal CAL Curve,
m=1.b=0)) (% Relative ((Last & New ABS Curve)).
2. All Ranges All Channels**
a) Define span gas concentration for each range press F5, F1.
b) Define Calibration path.
c) SOLENOIDS press F5, F2, F4.
d) PROBE (pump) press F5, F2, F5.
e) Define Gas flow windows: TIMES press F5, F2, F2, (Purge, Calibrating, Verifying,
Purge After).
f)Define Measuring Deviation press F5, F2, F2.
g) Define Deviations press F5, F2, F3: (% Absolute ((CAI Ideal CAL Curve,
m=1.b=0)) % Relative (Last Cal Curve).
h) Define Auto Cal Start Time press F5, F7, F1, F1 (Date, Hour, Frequency).
CALIBRATION
1. Single range
a) Select /range (MEASUREMENT screen)
b) AUTOMATIC CALIBRATION press F4, F1: (Instrument flows zero & span gas
and saves value if operator defined deviation requirements are realized)
2. All ranges.
a) AUTO CAL ENABLED press F5, F7, F1, F4.
b) Calibration per real-time clock F5, F7, F1, F3.

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
FILTER HOUSING MAINTENANCE
1) Whenever the Filter Element is replace ALWAYS apply a fairly liberal
coating of silicone lubricant to the threads of the Filter Housing before re-assembly to
prevent galling and seizing of the threads.
NOTE: Use a silicone lubricant that is free of Hydrocarbons to eliminate
measurement errors and contaminate the analyzer
2) ALWAYS, use a second wrench on the body of the Filter Housing when attempting to
Inspect or replace the filter.
3) NEVER attempt to disassemble the Filter Housing while it is hot. Always allow it to
cool to room temperature before attempting any maintenance.
4) NEVER attempt to re-assemble the Filter housing when it is hot. Re-assembly
must ONLY be performed when the analyzer is at room temperature.
5) DO NOT over-tighten. The sealing of the Filter Housing is
accomplished by the o-ring. Re-assembly should be made 'just past finger tight' and only when
the Filter Housing is at room temperature.

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
TABLE OF CONTENTS
1. Introduction................................................................................................................... 1
1.1. Overview.................................................................................................................. 1
1.2. Unpacking Instructions ............................................................................................ 1
1.3. Reporting Damage .................................................................................................. 1
1.4. Contact Information ................................................................................................. 1
1.5. Warranty Certificate................................................................................................. 2
1.6. Possible Explosion Hazard ...................................................................................... 4
1.7. Electrical Shock Hazard........................................................................................... 4
1.8. Fuel Requirements .................................................................................................. 4
1.9. Potential Sample Pump Damage............................................................................. 4
1.10. Removing Protective Caps ...................................................................................... 5
2. Features......................................................................................................................... 6
2.1. Description............................................................................................................... 6
2.2. Features-General .................................................................................................... 6
2.2.1. Ranges.......................................................................................................................7
2.2.2. Calibration ..................................................................................................................7
2.2.2.1 Manual Calibration......................................................................................................7
2.2.2.2 Auto Calibration..........................................................................................................8
2.3. Model 600 MHFID Specifications............................................................................. 9
3. Installation....................................................................................................................10
3.1. General...................................................................................................................10
3.2. Site and Mounting...................................................................................................10
3.3. Electrical.................................................................................................................11
3.4. Sampling System....................................................................................................13
3.5. Required Gases and Gas Handling Equipment ......................................................13
3.6. Gas Connections....................................................................................................13
3.7. Sampling Requirements .........................................................................................14
3.7.1. Filtration....................................................................................................................14
3.7.2. Condensation ...........................................................................................................14
3.7.3. Presence of Corrosive Gases ..................................................................................14
3.7.4. Gas Temperature.....................................................................................................14
3.7.5. Pressure and Flow Rates.........................................................................................14
3.7.6. Sample Gas Bypass Outlet Vent (1) and Exhaust Port (2) ...................................... 16

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
4. Basic Operation...........................................................................................................17
4.1. Applied AC Power...................................................................................................17
4.2. Menu Overview.......................................................................................................17
4.3. ALARMS.................................................................................................................18
4.4. DEVIATIONS..........................................................................................................19
4.5. CALIBRATION........................................................................................................19
4.6. Display (Measurement Screen)...............................................................................19
4.7. Keypad...................................................................................................................21
4.7.1. Operation with the Selector Bar and the Arrow Keys...............................................21
4.7.2. Operation with the Function Keys.............................................................................21
4.7.3. Enter Key.................................................................................................................21
5. Password and Operating Level Menu Structure........................................................22
5.1. Operating levels......................................................................................................22
5.1.1. Password Level Menu..............................................................................................22
5.2. User Functions (Level 1).........................................................................................23
5.3. Advanced User Functions (Level 2)........................................................................23
5.4. Maintenance Functions (Level 3)............................................................................23
5.5. System User Functions (Level 4)............................................................................23
5.6. Selection of an Operation Level and Entering a Password .....................................24
5.6.1. F1 Enter Password..................................................................................................25
5.6.2. F2 Change Password..............................................................................................26
5.6.3. F3 Reset Passwords...............................................................................................26
5.7. Available Menus with Access levels........................................................................27
5.7.1. Main Menu................................................................................................................27
5.7.2. F4 Calibrations ........................................................................................................28
5.7.3. F5 Setup Menu........................................................................................................ 30
6. Menus...........................................................................................................................32
6.1. Main Menu Tree......................................................................................................33
6.2. F1 Measurement Menu Tree ..................................................................................34
6.3. F4 Calibrations Menu Tree ....................................................................................36
6.4. F5 Setup Menu Tree..............................................................................................37
6.5. F5 Password Menu Tree (sub menu of F5 Setup) ..................................................39
7. Menu Function Descriptions.......................................................................................41

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
7.1. F1 Measurements Menu........................................................................................41
7.1.1. (Measurement) F3 Diagnostics...............................................................................42
7.1.2. (Measurement) F4 C1/C3 ....................................................................................... 43
7.1.3. (Measurement) F5 Toggle Zero..............................................................................43
7.1.4. (Measurement) F6 Toggle Span.............................................................................43
7.1.5. (Measurement) F7 Standby.....................................................................................44
7.1.6. (Measurement) Select Range .................................................................................. 44
7.2. F3 Diagnostics.......................................................................................................46
7.3. F4 Calibrations Set Up...........................................................................................46
7.3.1. Entering the Span Gas Concentration...................................................................... 46
7.3.2. Selecting the Path for Calibration Gas Introduction. ................................................47
7.3.3. Selecting the Range to be Calibrated....................................................................... 47
7.3.4. F2 Automatic Calibration.........................................................................................47
7.3.4.1 Setting the Analyzer’s Internal Clock and Calendar. ................................................47
7.3.4.2 Defining the Calibration Schedule............................................................................49
7.3.4.3 Defining the Ranges to be Calibrated. .....................................................................49
7.3.4.4 Enabling the Autocalibration Sequence....................................................................49
7.3.4.5 Entering the Automatic Calibration Span Gas Concentration. .................................50
7.3.4.6 Calibration Gas Introduction/Automatic Calibration Sequence. ...............................50
7.3.4.7 Setting of Automatic Calibration Times....................................................................51
7.3.4.8 Measuring Deviations...............................................................................................51
7.3.4.9 Deviations.................................................................................................................52
7.4. Manual Calibration..................................................................................................52
7.4.1. Zero Calibration........................................................................................................52
7.4.2. Span Calibration.......................................................................................................52
7.4.3. Calibration Verification (Manual Mode). ...................................................................52
7.4.4. (Calibrations) F4 Check Calibration ........................................................................53
7.4.5. (Calibrations) F5 Reset Calibration Values.............................................................54
7.4.6. (Calibrations) F6 Calibration Range Selection........................................................55
7.5. F3 Display Deviations............................................................................................57
7.5.1. Zero Gas Deviations.................................................................................................58
7.5.2. Span Gas Deviations................................................................................................59
7.5.3. Verifying Deviations Zero. ........................................................................................59
7.5.4. Verifying Deviations Span. .......................................................................................60
7.6. F5 Setup................................................................................................................61
7.6.1. Entering the Span Gas Concentration......................................................................61
7.6.2. F2 Calibration Settings............................................................................................62
7.6.2.1 F1 Times .................................................................................................................62

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
7.6.2.2 F2 Measuring Deviations.........................................................................................62
7.6.2.3 F3 Deviations ..........................................................................................................64
7.6.2.4 F4 Calibrations via Valves/Probe ............................................................................65
7.6.3. F3 Range Limits......................................................................................................66
7.6.3.1 Setting Full Scale Range Values..............................................................................66
7.6.3.2 Auto Range Switching Levels...................................................................................66
7.6.4. Alarms ...................................................................................................................... 67
7.6.4.1 F1 Temperatures and Concentration Alarms (T/C Alarms) ....................................67
7.6.4.2 F2 Pressure Alarms ................................................................................................67
7.6.4.3 F3 EPC Coil Alarms ................................................................................................69
7.6.5. F5 Password ...........................................................................................................69
7.6.6. F6 Linearization....................................................................................................... 70
7.6.6.1 Change Linearization Coefficients............................................................................70
7.6.6.2 Display Raw Value ...................................................................................................71
7.6.7. F7 System Settings .................................................................................................71
7.6.7.1 Real Time Clock.......................................................................................................72
7.6.7.2 System Setup F1 Real Time Clock .........................................................................72
7.6.7.3 F2 TCP/IP Settings..................................................................................................73
7.6.7.4 F3 Output Assignment.............................................................................................73
7.6.7.5 F4 Output Range.....................................................................................................74
7.6.7.6 F5 Status Line ON/OFF...........................................................................................74
7.6.7.7 F7 Autostart.............................................................................................................74
7.6.8. F8 Measure Settings...............................................................................................75
7.6.9. F10 Version.............................................................................................................76
7.6.10. F6 Remote / Manual Control...................................................................................77
7.6.11. F7 Standby..............................................................................................................77
7.6.12. F8 Ignition................................................................................................................78
8. Functional Description................................................................................................79
8.1. Operating Principle.................................................................................................79
8.2. Burner Assembly....................................................................................................79
8.3. Flow System...........................................................................................................79
8.4. Sample Supply .......................................................................................................80
9. Analyzer Components.................................................................................................81
9.1. Rear Panel..............................................................................................................81
9.2. Internal Component Locations................................................................................82
9.2.1. Model 600 MHFID Interior Layout ............................................................................82
9.2.2. Model 600 MHFID Electronics Section.....................................................................83
9.2.3. Model 600 MHFID Solenoid Layout.......................................................................... 84

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
9.2.4. Oven Compartment Layout......................................................................................86
10. Operation......................................................................................................................88
10.1. Startup....................................................................................................................88
10.2. Shutdown Procedure..............................................................................................89
11. Troubleshooting ..........................................................................................................90
11.1. Troubleshooting-Disassembly Procedures..............................................................90
11.1.1. Oven Burner Assembly Filter Unit/Filter Removal....................................................90
11.1.2. Flow System/Fuel and Burner Air Supply.................................................................90
11.2. Troubleshooting Guide ...........................................................................................91
11.3. Error Messages......................................................................................................92
12. GLOSSARY...................................................................................................................93
12.1. ABS DEVIATIONS..................................................................................................93
12.1.1. Calibration Via Probe................................................................................................93
12.1.2. Calibration Via Solenoid Valves ...............................................................................93
12.1.3. Change Linear Coefficients......................................................................................93
12.2. Linear Curve: Standard FACTORY.........................................................................93
12.3. Lin. Value ...............................................................................................................93
12.4. Measured Curve.....................................................................................................93
12.5. MEASURING DEVIATION......................................................................................93
12.6. Measured Value......................................................................................................93
12.7. Physical Range (AKA Linear Curve).......................................................................94
12.8. Purge / Calibration / Verifying Purge After..............................................................94
12.9. Purge: (MAIN MENU) .............................................................................................94
12.10. Real Time...............................................................................................................94
12.11. Raw Value..............................................................................................................94
12.12. RELATIVE DEVIATIONS........................................................................................94
12.13. Reset Calibration Values ........................................................................................94
12.14. Software Range (AKA Measurement Curve) ..........................................................94
12.15. Status Line .............................................................................................................94
13. AK Protocol Format.....................................................................................................95
13.1. Serial Interface and AK-Commands .......................................................................95
13.2. Interface Parameters..............................................................................................95
13.3. General AK Requirements......................................................................................96
13.4. Scans .....................................................................................................................96

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
13.4.1. AKON: Measured concentration value.....................................................................96
13.4.2. AEMB: Set measuring range....................................................................................96
13.4.3. AMBE: Measuring range limit...................................................................................96
13.4.4. AKAK: Calibration gas concentrations .....................................................................97
13.4.5. AMBU: Upper and lower range switchover values for auto range............................97
13.4.6. ASTZ: Normal device status.....................................................................................97
13.4.6.1 Possible states:........................................................................................................97
13.4.7. ASTF: Error status....................................................................................................98
13.4.8. AKEN: Device identification......................................................................................98
13.4.9. ARMU: Raw value.................................................................................................... 98
13.4.10. ATEM: Temperatures...............................................................................................98
13.4.11. ADRU: Pressures.....................................................................................................98
13.4.12. ADUF: Flows ............................................................................................................99
13.4.13. AGRD: Polynom coefficients....................................................................................99
13.4.14. AANG: Deviation from zero point after autocalibration............................................. 99
13.4.15. AAEG: Deviation from end point after autocalibration.............................................. 99
13.4.16. AFDA: Purge and Autocalibration times...................................................................99
13.4.17. APAR: Request Autocalibration tolerance values ....................................................99
13.4.18. AKAL: Deviations from calibration..........................................................................100
13.4.19. ASYZ: Respond System Time................................................................................100
13.4.20. AT90: Respond Lowpass filter time........................................................................100
13.4.21. ADAL: Diagnostic alarm limits................................................................................100
13.4.22. ACXB: Respond Display Factor .............................................................................100
13.5. Control commands ...............................................................................................101
13.5.1. SRES: Reset ..........................................................................................................101
13.5.2. SPAU: Pause..........................................................................................................101
13.5.3. STBY: Standby.......................................................................................................101
13.5.4. SNGA: Open valve for zero gas calibration............................................................101
13.5.5. SEGA: Open valve for end gas calibration.............................................................101
13.5.6. SSPL: Purge Analyzer with zero gas...................................................................... 101
13.5.7. SLIN: Linearization mode.......................................................................................101
13.5.8. SATK: Start automatic calibration ..........................................................................101
13.5.9. SEMB: Set measuring range..................................................................................101
13.5.10. SARE: Auto range on.............................................................................................102
13.5.11. SARA: Auto range off.............................................................................................102
13.5.12. SREM: Remote mode for AK-commands..............................................................102
13.5.13. SMAN: Manual control to control device manually.................................................102
13.5.14. SMGA: Start measuring .........................................................................................102
13.5.15. SNKA: Saves measured value as new offset.........................................................102

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
13.5.16. SEKA: Saves measured value as new span value ................................................102
13.5.17. SHCG: Cutter off....................................................................................................102
13.5.18. SCH4: Cutter on.....................................................................................................102
13.5.19. S---: Enable dual measure mode ...........................................................................102
13.6. Settings ................................................................................................................103
13.6.1. EKAK: The four span gas concentration values are set.........................................103
13.6.2. EMBE: The four measuring range end values are set ...........................................103
13.6.3. EMBU: The upper and the lower range switchover for autorange are set .............103
13.6.4. EKEN: Set new device identification ......................................................................103
13.6.5. EGRD: Set polynom coefficients............................................................................103
13.6.6. EFDA: Set autocalibration and purge times...........................................................103
13.6.7. EPAR: Set autocalibration tolerance values...........................................................103
13.6.8. ESYZ: Set System Time......................................................................................... 104
13.6.9. ET90: Set Lowpass Filter Time..............................................................................104
13.6.10. EDAL: Diagnostic alarm limits................................................................................104
13.6.11. ECXB: Set Display Factor ......................................................................................104
13.7. Abbreviations used...............................................................................................104
14. Appendix ....................................................................................................................105
14.1. Connectors...........................................................................................................105
14.1.1. Main Connector (Standard 28 Pin Connector) ....................................................... 105
14.1.2. Auxiliary Connector (Standard 28 Pin Connector)..................................................105
14.1.3. Digital Outputs –RS-232 (Standard 9 Pin DIN Connector).................................... 106
14.1.4. Digital Outputs –TCP/IP (8 Pin RJ-47 Connector) ................................................106
14.2. Model 600 MHFID Flow Diagrams........................................................................107
14.3. Electrical Block Diagram.......................................................................................111
14.4. AC Power 600 HCLD/MHFID................................................................................112

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
Table of Figures
Figure 3-1 AC Power Switch, Connector, and Fuse........................................................................................11
Figure 3-2 EMI Suppressor.............................................................................................................................12
Figure 3-3 Sample Gas Bypass Outlet Vent (1) and Exhaust Port (2)............................................................16
Figure 4-1 Measurement Screen.....................................................................................................................20
Figure 4-2 Keypad...........................................................................................................................................21
Figure 5-1 Enter / Change Password..............................................................................................................24
Figure 5-2 Access Level Screens....................................................................................................................25
Figure 5-3 Enter password..............................................................................................................................25
Figure 5-4 Passwords .....................................................................................................................................26
Figure 5-5 Reset Passwords to Factory Defaults............................................................................................26
Figure 6-1 Main Menu on Power Up Screen...................................................................................................32
Figure 6-2 Main User Menu (Level 4)..............................................................................................................32
Figure 6-3 Main Menu.....................................................................................................................................33
Figure 6-4 Measurement Menu Tree ..............................................................................................................34
Figure 6-5 Changing the Ranges ....................................................................................................................35
Figure 6-6 Calibration Menu............................................................................................................................36
Figure 6-7 Setup Menu (Page 1).....................................................................................................................37
Figure 6-8 Setup Menu Tree (Page 2) ............................................................................................................38
Figure 6-9 Password Menu Tree.....................................................................................................................40
Figure 7-1 Main Menu Screen to Measurement Screen .................................................................................41
Figure 7-2 Dual F2 Screen..............................................................................................................................41
Figure 7-3 Main Menu Screen to Measurement Screen .................................................................................42
Figure 7-4 First Diagnostics Screen................................................................................................................42
Figure 7-5 Second Diagnostics Screen...........................................................................................................42
Figure 7-6 F4 C1/C3 Selection.......................................................................................................................43
Figure 7-7 F5 Toggle Zero Selection...............................................................................................................43
Figure 7-8 Toggle Span Selection...................................................................................................................44
Figure 7-9 F7 Go To Standby.........................................................................................................................44
Figure 7-10 Analyzer set to Range 1...............................................................................................................45
Figure 7-11 Analyzer set to Range 2...............................................................................................................45
Figure 7-12 Analyzer set to Range 3...............................................................................................................45
Figure 7-13 Analyzer set to Range 4...............................................................................................................45
Figure 7-14 Set to Auto-Range .......................................................................................................................45
Figure 7-15 Diagnostic screens.......................................................................................................................46

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
Figure 7-16 Auto Calibration Cycle..................................................................................................................51
Figure 7-17 F4 Check calibration....................................................................................................................53
Figure 7-18 F5 Reset calibration values..........................................................................................................54
Figure 7-19 Reset calibration values...............................................................................................................54
Figure 7-20 Reset calibration values confirmation..........................................................................................54
Figure 7-21 Range 1 selection from Calibrations Menu..................................................................................55
Figure 7-22 Range 2 selection from Calibrations Menu..................................................................................55
Figure 7-23 Range 3 selection from Calibrations Menu..................................................................................55
Figure 7-24 Range 4 selection from Calibrations Menu..................................................................................56
Figure 7-25 Auto Range selection from Calibrations Menu.............................................................................56
Figure 7-26 F3 Display deviations..................................................................................................................58
Figure 7-27 Zero gas deviations......................................................................................................................58
Figure 7-28 Span gas deviations.....................................................................................................................59
Figure 7-29 Verifying Zero Gas Deviations .....................................................................................................59
Figure 7-30 Verifying Span Gas Deviations ....................................................................................................60
Figure 7-31 Main menu (User level 4).............................................................................................................61
Figure 7-32 Setup menu 1...............................................................................................................................61
Figure 7-33 Span gas concentrations .............................................................................................................61
Figure 7-34 Change span gas settings ...........................................................................................................61
Figure 7-35 Change Auto Calibration Settings...............................................................................................62
Figure 7-36 Setup-times..................................................................................................................................62
Figure 7-37 Measuring deviations...................................................................................................................63
Figure 7-38 Absolute versus relative deviations..............................................................................................65
Figure 7-39 Calibrations via internal solenoid valves......................................................................................65
Figure 7-40 Calibration via probe....................................................................................................................65
Figure 7-41 Change Range Limits ..................................................................................................................66
Figure 7-42 Change Upper Range Limits........................................................................................................66
Figure 7-43 Change Auto Range Limits..........................................................................................................66
Figure 7-44 Setup Alarms ...............................................................................................................................67
Figure 7-45 Set Temperature Alarms..............................................................................................................67
Figure 7-46 Select Set Pressure Alarms.........................................................................................................68
Figure 7-47 Select Set EPC Coil Alarms.........................................................................................................69
Figure 7-48 Change Linearization Coefficients Screen...................................................................................70
Figure 7-49 Select Range/Linear Coefficients.................................................................................................70
Figure 7-50 F2 Display Raw............................................................................................................................71
Figure 7-51 F7 System Setup Screen.............................................................................................................71

Model 600 MHFID Analyzer
C-ETC-US/CE Manual Rev 1.0
Figure 7-52 Setup RTC...................................................................................................................................72
Figure 7-53 Set Autocalibration Cal Timing.....................................................................................................72
Figure 7-54 F4 Autocalibration status .............................................................................................................72
Figure 7-55 TCP/IP Address...........................................................................................................................73
Figure 7-56 Status Line On/Off .......................................................................................................................74
Figure 7-57 Autostart.......................................................................................................................................74
Figure 7-58 Menu Settings Screen..................................................................................................................75
Figure 7-59 Set Time Constant.......................................................................................................................75
Figure 7-60 Analyzer Information/Version.......................................................................................................76
Figure 7-61 Device/Software Version..............................................................................................................76
Figure 7-62 Remote manual control................................................................................................................77
Figure 7-63 Standby selection.........................................................................................................................77
Figure 7-64 Standby screen............................................................................................................................77
Figure 7-65 Ignition..........................................................................................................................................78
Figure 9-1 Rear Panel.....................................................................................................................................81
Figure 9-2 Interior Layout by Section ..............................................................................................................82
Figure 9-3 Model 600 MHFID Interior Layout..................................................................................................84
Figure 9-4 Model 600 MHFID Oven Compartment (Full View)......................................................................86
Figure 9-5 Oven Compartment (Close up)......................................................................................................87
Figure 14-1: 600M-HFID Standard Analyzer/Without Pump.........................................................................107
Figure 14-2: 600M-HFID Standard Analyzer with Pump...............................................................................108
Figure 14-3: 600M-MHFID with Non-Methane Cutter Assembly without Pump............................................109
Figure 14-4: 600M-HFID with Non-Methane Cutter Assembly with Pump....................................................110
Figure 14-5 Electrical Block Diagram............................................................................................................111
Figure 14-6 AC Power...................................................................................................................................112

Section 1 Model 600 MHFID Analyzer
Page 1 of 105 Manual Rev 1.0
1. Introduction
1.1. Overview
Congratulations and thank you! You have just purchased one of the most reliable gas
analyzers in the world. Before using the analyzer, please familiarize yourself with its operation
by reading this manual. If you have any questions, please do not hesitate to call California
Analytical Instruments for assistance. We want you to be a member of our thousands of
satisfied customers.
1.2. Unpacking Instructions
Open the shipping container and carefully remove the analyzer from the packing materials.
Inspect the instrument for any sign of damage. Remove the Top Cover retaining screws.
Visually check for loose parts or connectors that are not properly seated. Verify all circuit
boards and circuit board connections are secure. If all internal components look normal, re-
install the cover.
1.3. Reporting Damage
Should there be any apparent damage either to the inside or outside of the instrument due
to shipping or handling, immediately notify the shipper. The shipping container or packing
materials should be retained for inspection by the shipper.
1.4. Contact Information
California Analytical Instruments, Inc.
1312 West Grove Avenue
Orange, CA 92865
714 974-5560
Fax [phone]
Website: www.gasanalyzers.com

Section 1 Model 600 MHFID Analyzer
Page 2 of 105 Manual Rev 1.0
1.5. Warranty Certificate
Subject to the exceptions and upon the conditions stated below, California Analytical
Instruments (CAI) warrants that the products sold under this sales order shall be free from
defects in workmanship and materials for one year after delivery of the product to the original
Buyer by CAI and if any such product should prove to be defective within such one year
period, CAI agrees, at its option, either (i) to correct by repair or, at CAI’s election, by
replacement with equivalent product any such defective product, provided that investigation
and factory inspection discloses that such defect developed under normal and proper uses, or
(ii) to refund the purchase price. The exceptions and conditions mentioned above are as
follows:
a. components or accessories manufactured by CAI which by their nature are not intended to and will
not function for one year are warranted only to give reasonable service for a reasonable time; which
constitutes reasonable time and reasonable services shall be determined solely by CAl. A complete
list of such components and accessories is maintained at the factory;
b. CAI makes no warranty with respect to components or accessories not manufactured by it; in the
event of defect in any such component or accessory CAI will give reasonable assistance to Buyer in
obtaining from the respective manufacturer whatever adjustment is authorized by the manufacturer’s
warranty;
c. any product claimed to be defective must be returned to the factory transportation charges prepaid
and CAI will return the repaired or replaced product freight collect;
d. if the product claimed to be defective requires on-site repair, such warranty labor will be provided at
no charge; however, transportation and living expenses will be charged to Buyer;
e. if the product is a consumable or the like, it is warranted only to conform to the quantity and content
and for the period (but not in excess of one year) stated on the label at the time of delivery or 90
days;
f. CAI may from time to time provide a special printed warranty with respect to a certain product, and
where applicable, such warranty shall be deemed incorporated herein by reference;
g. CAI shall be released from all obligations under all warranties, either expressed or implied, if any
product covered hereby is repaired or modified by persons other than its own authorized service
personnel unless such repair by others is made with the written consent of CAl.
IT IS EXPRESSLY AGREED THAT THE ABOVE WARRANTY SHALL BE IN LIEU OF ALL
WARRANTIES OF FITNESS AND OF THE WARRANTY OF MERCHANTABILITY AND
THAT CAI SHALL HAVE NO LIABILITY FOR SPECIAL OR CONSEQUENTIAL DAMAGES
OF ANY KIND OR FROM ANY CAUSE WHATSOEVER ARISING OUT OF THE
MANUFACTURE USE, SALE, HANDLING, REPAIR, MAINTENANCE OR REPLACEMENT
OF ANY OF THE PRODUCTS SOLD UNDER THIS SALES ORDER. SOME STATES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THAT THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE
OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
Representations and warranties made by any person, including dealers and representatives of
CAI, which are inconsistent, or in conflict with the terms of this warranty, shall not be binding
upon CAI unless reduced to writing and approved by an expressly authorized officer of CAl.

Section 1 Model 600 MHFID Analyzer
Page 3 of 105 Manual Rev 1.0

Section 1 Model 600 MHFID Analyzer
Page 4 of 105 Manual Rev 1.0
1.6. Possible Explosion Hazard
This analyzer uses a fuel that contains a FLAMMABLE LEVEL OF HYDROGEN. Any
leakage from this fuel can result in an explosion. Carefully check the fuel supply system, to the
analyzer for leaks upon installation, before initial start-up, during any maintenance or after the
integrity of the system is broken.
Do not apply power to the analyzer or attempt to ignite the burner until performing ALL
leak checks and until determining the analyzer environment to be non-hazardous.
Use this analyzer in a NON-HAZARDOUS environment.
This analyzer has not been designed for use with a hazardous sample.
Tampering or use of substitute components may cause a safety hazard. Use only factory
authorized replacement parts.
1.7. Electrical Shock Hazard
Do not operate without the cover secured. Servicing requires access to live electrical
circuits that can cause death or serious injury. Refer servicing to qualified service personnel.
For safety and proper performance, connect this instrument to a properly grounded three-wire
receptacle.
1.8. Fuel Requirements
The CAI factory configures the Model 600 MHFID for either 100% Hydrogen or 40%/60%
Hydrogen/Helium Fuel. Please make sure to use the CORRECT fuel (as specified on the fuel
label affixed on the back panel of the analyzer.)
Use of incorrect fuel WILL damage the instrument and COULD cause an explosion.
1.9. Potential Sample Pump Damage
The analyzer can be calibrated using the optional zero and span gas ports located on the
back panel. It can also be calibrated using the internal sample pump; HOWEVER, care must
be taken to assure that the sample pump is not exposed to excessive pressure using this
calibration method. Any pressure exceeding 2.0 psig can result in a NON-WARRANTY failure.

Section 1 Model 600 MHFID Analyzer
Page 5 of 105 Manual Rev 1.0
1.10. Removing Protective Caps
Do not apply AC power to this analyzer until removing the plastic ¼-inch caps from the
sample/zero/span/fuel fittings on the rear panel. Failure to remove these caps will result in
analyzer contamination.
