Califone DVD-110 User manual

DVD-110
Portable DVD Player
User Manual
DVD-110 User Manual - JH 2009.11.23.indd 1 11/23/2009 10:59:31 AM

califone.com
1
DVD-110 Portable DVD Player
Thank you for purchasing the Califone® Model DVD-110 Portable DVD
Player.
We encourage you to visit our website www.califone.com to register your
product for its warranty coverage, to sign up to receive our
newsletter, download our catalog, and learn more about the complete
line of Califone audio visual products, including portable and installed
wireless PA systems, multimedia players and recorders, headphones
and headsets, computer peripheral equipment, visual presentation
products and language learning materials.
1. Important Safety Instructions
2. Package Contents
3. Part Names & Functions
4. Key Functions
5. Setup & Installation
5.1 Remote Control Battery Installation
5.2 Connect to Television / Sound System
6. System Settings
6.1 Menu Operation
6.2 System Settings Page
6.3 Language Settings Page
6.4 Audio Settings Page
6.5 Video Settings Page
6.6 Speaker Settings Page
6.7 Digital Settings Page
7. Playback
7.1 Read and Play Discs
7.2 Playing MP3/MPEG4 Discs
8. Handling DVDs & Compact Discs
9. Specications & Features
10. Troubleshooting
11. Warranty
Table of Contents
2
4
4
6
9
9
9
10
10
10
11
11
11
11
11
12
12
12
13
14
15
16
DVD-110 User Manual - JH 2009.11.23.indd 2-1 11/23/2009 10:59:31 AM

califone.com
2
califone.com
3
1. IMPORTANT SAFETY INSTRUCTIONS
Before using this product, read the instruction manual for important safety
information. Please retain this manual for future reference and warranty
information.
Troubleshooting & Servicing
Do not attempt to service or repair the device yourself. Refer all servicing
to qualied service personnel. Do not attempt to modify the device in any
way. Doing so could invalidate your warranty.
Moisture and heat sources
Do not use this apparatus near water (for example, sinks, baths, pools) or
expose it to rain, moisture, dripping or splashing liquids. Do not expose
the unit to high temperatures, high humidity or direct sunlight.
Cleaning
When cleaning the device, please use a soft, dry cloth. Never use
benzene, paint-thinner, or other chemicals on the device.
Location
Place the device in stable location, so it will not fall causing damage to
the device or bodily harm.
Intended use
The product may only be used with the original parts intended for it. The
product may only be used in closed and dry rooms. The intended use
includes adherence to the specied installation instructions. The
manufacturer accepts no liability for damage arising due to improper use.
WARNING: Changes or modications to this unit not expressly approved
by the party responsible for compliance could void the user’s authority to
operate the equipment.
IMPORTANT
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
The unit’s circuitry may cause interference to nearby radios. To prevent
interference, either switch the unit off or move away from the affected
radio.
NOTE: This equipment has been tested and found to comply within the
limits for a class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for
help.
NOTE: Shielded cables may be required to be used with this unit to en-
sure compliance with the Class B FCC limits.
SAFETY CERTIFICATION
This Compact Disc Player is made and tested to meet safety standards
of the FCC, requirements and compliance with safety performance of
the U.S. Department of Health and Human Services, and also with FDA
Radiation Performance Standards 21 CFR Subchapter J.
LASER SAFETY
This unit employs an optical laser beam system in the CD mechanism,
designed with built-in safeguards. Do not attempt to disassemble; refer to
qualied service personnel. Exposure to this invisible laser light beam may be
harmful to the human eye.
THIS IS A CLASS-1 LASER PRODUCT. USE OF CONTROLS, OR ADJUST-
MENTS OR PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN,
MAY RESULT IN HAZARDOUS LASER LIGHT BEAM EXPOSURE.
INVISIBLE LASER
RADIATION WHEN
OPEN AND INTERLOCK
FAILED OR DEFEATED.
AVOID DIRECT EXPO-
SURE TO LASER BEAM.
DVD-110 User Manual - JH 2009.11.23.indd 2-3 11/23/2009 10:59:31 AM

califone.com
4
califone.com
5
2. PACKAGE CONTENTS
The following materials are included.
• DVD-110 DVD Player
• Remote control
• 2pcs AAA batteries
• RCA A/V cable
• User Manual
Unpacking the Unit
Inspect the unit once the packaging has been opened for any damage
that occurred during shipping and contact us immediately. Please keep
the packing material for further use.
3. PART NAMES & FUNCTIONS
1. Open/ Close
2. Play/ Pause
3. Stop
1. STANDBY/ ON
2. NUMBER BUTTONS
3. AUDIO
4. SUBTITLE
5. SETUP
6. TITLE
7. UP ARROW
8. LEFT ARROW
9. DOWN ARROW
10. PBC
11. PLAY
12. REPEAT
13. A-B
14. REWIND
15. FORWARD
16. STEP
17. SLOW
18. R/L
19. N/ P
20. VOLUME -
21. VIDEO
22. OPEN/ CLOSE
23. GOTO
24. CLEAR
25. ANGLE
26. ENTER
27. MENU
28. RIGHT ARROW
29. ZOOM
30. PAUSE
31. OSD
32. PROGRAM
33. NEXT
34. PREVIOUS
35. MUTE
36. STOP
37. DVD/ USB
38. REST
39. VOLUME +
1. S-Video Output
2. RCA Video Output
3. Coaxial Digital Audio Output
1
4
6
1 2 3 4 5 6
BACK PANEL
4. Analog Audio Left/Right (ML/
MR) Outputs
5. Component Video Outputs (Y,
Pr/Cb, Pr/Cr)
6. USB Port
4. Previous
5. Next
6. Power
DVD-110
1
2
23
22
3
4
5
6
8
9
11
13
15
17
10
12
14
16
18
25
26
27
28
29
30
31
32
33
34
35
36
37
7
20
21
19
24
38
39
2
3
5
FRONT PANEL
DVD-110 User Manual - JH 2009.11.23.indd 4-5 11/23/2009 10:59:32 AM

califone.comcalifone.com
6
4. KEY FUNCTIONS
Note: Some of the following buttons are on the remote control, and some
are only on the machine. The button may also function differently on the
machine or remote control.
STANDBY / ON
Press this key to turn on the dvd player and to bring it to standby.
OPEN / CLOSE
Press this key to open and close the disc tray
GOTO
Press this key and then use the direction keys or number keys to select
a specic title, chapter, song, title time, chapter time or song time to play.
AUDIO
Press this key to select the audio settings.
SUBTITLE
Press this key to switch between any available subtitles on the DVD.
ANGLE
Press this key to switch between different video angles available on the
DVD.
CLEAR
Press this key to clear an entry or exit a mode.
SETUP
Press this key to setup the system.
TITLE
Press this key to return to display the DVD title content.
MENU
Press this key to return to the DVD menu.
PBC
Plays DVDs interactively by following the menu on the TV screen.
califone.com
7
PLAY
Press this key to begin playback or to resume normal playback from
pause, fast forward, or fast reverse states.
PAUSE
Press this key to pause playback, and then press this key or press
[ ] to resume normal playback.
ZOOM
Press this key to zoom. Three different levels of zoom are available.
REPEAT
Press this key to change the repeat mode.
A-B
Press this key to set the starting point (A) and then press again to set
the ending point (B). The machine will repeat the content from point A
to point B. Press the A-B key a third time and it will cancel and resume
normal playback.
PROGRAM
Press this key to program specic song/chapters to play.
OSD
Press once to enter the system settings main menu, and then press
again to withdraw from the system settings menu. In the menu, the
number keys can be used to enter the corresponding options or select
the appropriate chapters or tracks.
FAST REVERSE (REV)
Press this key for fast backward search. You can select the speed of
2X, 4X, 8X, 20X.
FAST FORWARD (FWD)
Press this key for fast forward search. You can select the speed of 2X,
4X, 8X, 16X, and 32X.
SKIP BACKWARD (PREV)
Press this key to skip to the previous chapter or song.
DVD-110 User Manual - JH 2009.11.23.indd 6-7 11/23/2009 10:59:32 AM
