Solimar™
CF-TO-V7002-9
In-Wall Vessel Lavatory Faucet
Installation Instructions
1
IMPORTANT: Read all instructions prior to installation and provide copy of instructions to consumer.
Operating Specifications:
Recommended Supply Pressure: 20 to 70 psi *†
Maximum Flow Rate: 1.2 gpm
*Operating pressures between hot and cold supplies should vary no more than 30 psi.
†If water pressure exceeds 70 psi, install a Pressure-Reducing Valve (RPV).
INSTALLING SPOUT TO IN-WALL VALVE
Prior to installing faucet trim in-wall vessel rough
VALVE (1), CF-VL-R, must be properly installed
and wall surface must be completely finished
Recommended through-hole size shall be Ø1-1/4”
Apply thread sealant to both threaded ends of
NIPPLE (2), not supplied, and tighten into center
outlet of VALVE (1)
Securely tighten QUICK CONNECT (3) onto end
of NIPPLE (2) using I/2” open-end wrench
Place O-RING (4) into ESCUTCHEON (5) & slide
ESCUTCHEON (5) onto QUICK CONNECT (3)
IMPORTANT: To prevent damage to internal o-ring on SPOUT
(6), QUICK CONNECT (3) MUST be free of any dirt and/or debris
Slide SPOUT (6) onto QUICK CONNECT (3),
align ESCUTCHEON (5) & SPOUT (6) and tighten
SETSCREW (7) on bottom side of SPOUT (6)
CALIFORNIA FAUCETS RECOMMENDS THAT ALL PLUMBING PRODUCTS BE INSTALLED
BY A LICENSED PROFESSIONAL
Ø1-1/4”
(3 holes)

CF-TO-V7002-9_ii_160720 Pg 2
2
3
4
v ALIGN & TRIM VALVE STEM
Remove MUDGUARD (1b) from VALVE (1)
To obtain proper HANDLE (11) alignment it may
be necessary to re-align cartridge STEM (1a); to
align STEM (1a), slightly loosen the cartridge NUT
(1c), place HANDLE (11) on STEM (1a) and
TIGHTEN in CW direction until desired
alignment is achieved; retighten cartridge NUT (1c)
to factory torque setting of 14 ft-lbs.
WARNING: Cartridge NUT (1c) MUST be properly torqued to
prevent possible failure and/or water damage
Unscrew ALL-THREAD (9) from valve STEM (1a)
Cut STEM (1a)1-3/8” from finished wall surface
Reattach ALL-THREAD (9) onto valve STEM (1a),
using a marking device (e.g. pencil or marker)
indicate a distance of ¾” from finished wall on ALL-
THREAD (9); remove ALL-THREAD (9) and cut off
excess ALL-THREAD (9) at indicated mark &
reattach ALL-THREAD (9)onto valve STEM (1a)–
repeat on other side
IMPORTANT: To prevent HANDLE (11) rotation during operation
of faucet set LOCK-NUT (8) MUST be placed on both ALL-
THREAD (9) of VALVE (1)
Place LOCK-NUT (8) onto ALL-THREAD (9) and
tighten against cartridge NUT (1c) to prevent ALL-
THREAD (9) from rotating while operating
HANDLE (11) –repeat on other side
INSTALLING ESCUTCHEON
Insert O-RING (4) into ESCUTCHEON (5) and
place onto ALL-THREAD (9)
Secure ESCUTCHEON (5) onto wall by tightening
lock NUT (10)
To align ESCUTCHEONS (5), use a ruler or
straight edge to align the spout and handle
escutcheons of the faucet as shown; after alignment
retighten lock NUTS (10)
INSTALLING HANDLE
Loosen SETSCREW (11a) from POST (11c)
IMPORTANT: Handle BLADE (11b) shall be aligned with wider
portion of handle POST (11c)
Slide HANDLE (11) down onto and engage valve
STEM (1a)
Handle POST (11c) shall completely cover lock
NUT (10) and seat against ESCUTCHEON (5)
Tighten SETSCREW (11a) and rotate handle
BLADE (11b) to check operation, open position is
when BLADE (11b) is rotated upward –repeat on
other side
1-3/8”
californiafaucets.com 5271 Argosy Ave. Huntington Beach, CA 92649 800-822-8855
13/16”
hex
3/4”
11/16”
hex
