Callaway Eclipse User manual

INTRODUCTION
The Callaway ECLIPSE Golf GPS delivers
elite performance on the course in a versatile
and unique design. Hit more greens and limit
penalty strokes by knowing precise distances
to the front, center, and back of the green,
along with distances to hazards & doglegs.
SPECIFICATIONS
2INTRODUCTION
Product Callaway ECLIPSE GPS
# of Courses 30,000+
Dimensions 4.25” x 3” x 1.75“ (w/Clip)
Weight 2.08 oz.
Battery 220mAh Lithium Ion Polymer
Battery Life Golf: 9 hours / Time: 90 Days
Display Size 1.28” (128 x128 pixels)
Water Resistant Yes 1ATM Designation

CHARGING
1. Power GPS unit Off. Hold [POWER ] until
screen goes blank. (See unit diagram page 4)
2. Connect Charger Pins on the charger to
the Charging Ports on the unit.
Note: Charger Pins and Charging Ports
must be aligned properly (Easiest to align
while looking at back of unit).
3. Secure Charger Clamp on the charger to
Charger Socket located on opposite side
of unit.
4. Plug USB cord end into USB port.
5. When connection is
made, unit will power
on and Battery Icon
bars will pulsate
to indicate charging.
Note: Battery Icon bars will stop pulsating
when charging is complete. (2-3 hours)
ENGLISH 3
CHARGING PINS
CHARGER CLAMP
CHARGING PORTS

DESCRIPTION OF TERMS
• PRESS - Press & Release button quickly.
• HOLD - Press & Hold button until desired
screen appears or change happens.
ECLIPSE DIAGRAM
A. [POWER ]- Power On/Off / Backlight On/Off
B. Charging Ports
C. [UP ]- Scroll Up
D. [OK ]- Toggle Screens and Select Options,
Hold to access Main Menu.
E. [DOWN ]- Scroll Down
F. Removable Clip
4HOW TO USE

ENGLISH 5
DISPLAY DIAGRAM
A. Distance to the Center of Green
B. Distance to the Back of Green
C. Distance to the Front of Green
D. Distance to front and back of Dogleg
E. Distance to layup or carry Water
F. Distance to layup or carry Bunker
PLAY MODE
HAZARD MODE

REVERSING CLIP
1. To remove Clip, PRESS and HOLD down
Tab (on back of clip) then PULL Clip away
from device.
2. Rotate unit 180 degrees.
3. To Attach Clip, PRESS and HOLD down
tab and insert Clip into Clip Socket until it
clicks and locks into place.
6HOW TO USE
CLIP SOCKET
(Arial View)
CLIP TAB
BACK VIEW
CLIP SOCKET
CLIP SOCKET
BACK VIEW

ENGLISH 7
TIME MODE
1. PRESS [OK ]button to toggle between
Analog or Digital Time Display.
2. PRESS [POWER ]button to turn Backlight
On/Off.
3. To set time and date, see Settings. (Pg. 14)
4. HOLD [OK ]button to access Main Menu.
AT GOLF COURSE
1. From Time Screen, HOLD [OK ]button to
access Main Menu.
2. PRESS [OK ]button to select Play Golf.
3. Device will begin searching for satellite
signal (HOLD [OK ]button to cancel).
4. Once satellite connection is established,
the nearest golf courses will be listed. Use
[UP/DOWN ]buttons to scroll to desired
course, PRESS [OK ]button to select course.

8HOW TO USE
PLAY MODE
1. PRESS [OK ]button to toggle between
Hazard, Scorecard, and
Shot Distance Screens.
2. To exit Play Mode at any time,
HOLD [OK ]button.
HAZARD VIEW
Note: If no hazards are
present, screen will be blank.
1. PRESS [OK ]button to access the
Hazard Screen.
2. Only 3 hazards will show at a time. If a hole
has more than 3 hazards, scroll by using
[UP/DOWN ]buttons. (Hazards that are
behind you will not be displayed).
3. PRESS [OK ]button to view next/previous
screen.

ENGLISH 9
SHOT DISTANCE
Note: Shot Distance must be turned On
in Settings.
1. PRESS [OK ]button to access Shot
Distance.
2. To start measuring Shot Distance, PRESS
the [DOWN ]button.
3. As you travel to your ball, the distance will
begin calculating.
4. Once you arrive at your ball, the distance
displayed is the distance of your previous
shot (the distance you traveled).
5. To reset, PRESS the [DOWN ]button.
6. PRESS [OK ]button to view next/previous
screen.

10 HOW TO USE
SCORECARD
Note: Scorecard must be turned On in
Settings.
1. PRESS [OK ]button to access Scorecard.
2. Use [UP/DOWN ]buttons until number of
total strokes for that hole is displayed.
3. HOLD the [DOWN ]button to scroll to Putts,
use [UP/DOWN ]buttons until correct
number of putts is displayed.
4. HOLD the [DOWN ]button to scroll to GIR
(Greens in Regulation). Use [UP/DOWN ]
buttons to select Y/N (Yes or No).
5. PRESS [OK ]button to view next/previous
screen.
AUTO-HOLE ADVANCE
1. While traveling from the green to the next
tee box, the device will automatically
advance to the next hole.
2. To manually advance to the next hole,
PRESS [UP ]button. To return to the
previous hole, PRESS the [DOWN ]button.

ENGLISH 11
END ROUND
1. When nished with round, HOLD [OK ]
button to return to Main Menu.
ODOMETER
1. From Time Screen, HOLD [OK ]button to
access Main Menu.
2. Use [UP/DOWN ]buttons to scroll to
Odometer, PRESS [OK ]button to select.
3. Circle will ash while connecting to satellite.
4. Once satellite connection is established,
circle will stop ashing.
5. To start, PRESS [UP ]button. The
Odometer will begin calculating the
distance you will travel.
6. To reset, PRESS [DOWN ]button. The
distance will return to zero (0).
7. To exit and return to Main Menu,
HOLD [OK ]button.

12 HOW TO USE
SETTINGS
1. From Time Screen, HOLD [OK ]button to
access Main Menu.
2. Use [UP/DOWN ]buttons to scroll to Settings.
3. PRESS [OK ]button to access
Settings Menu.
4. Use [UP/DOWN ]buttons to scroll through
Settings Menu.
5. PRESS [OK ]button to select desired setting.
6. HOLD [OK ]button to return to Main Menu.
ALARM
1. Use [UP/DOWN ]buttons to select Alarm 1,
Alarm 2, or Alarm 3.
2. PRESS [OK ]button to scroll down. PRESS
[UP/DOWN ]buttons to Enable/Disable Alarm.

ENGLISH 13
3. PRESS [OK ]button to scroll down. Use
[UP/DOWN ]buttons to set the Hour.
4. PRESS [OK ]button to scroll to Minutes.
Use [UP/DOWN ]buttons to set the Minutes
then PRESS [OK ]button.
5. PRESS [OK ]button to scroll through days
of the week. Use [UP/DOWN ]buttons to
Enable/Disable Alarm for that day.
(Enabled is represented by a circle.)
6. HOLD [OK ]button to save and return to
Settings Menu.
DATE/TIME
1. Use [UP/DOWN ]buttons to select Auto
or Manual.
• Auto: The Watch will start searching for
satellite connection, once connected; the
time and date will appear according to your
location. (Note: Must be outside)
• Manual: PRESS [OK ]button to scroll up
or down the list of time/date settings, Use
[UP/DOWN ]buttons to change/edit setting.

14 HOW TO USE
2. Use [UP/DOWN ]button to change the Date
Format (MM-DD-YYYY, DD-MM-YYYY,
YYYY-MM-DD).
3. PRESS [OK ]button to scroll down. Use
[UP/DOWN ]button to select 12 hour or 24
hour clock.
4. PRESS [OK ]button to scroll down. Use
[UP/DOWN ]button to select Month.
5. PRESS [OK ]button then use [UP/DOWN ]
button to select Day.
6. PRESS [OK ]button then use [UP/DOWN ]
button to select Year.
7. PRESS [OK ]button then use [UP/DOWN ]
button to select Hour.
8. PRESS [OK ]button then use [UP/DOWN ]
button to select Minutes.

ENGLISH 15
9. HOLD [OK ]button to save and return to
Settings Menu.
10. HOLD [OK ]button again to return to
Time Screen.
UNIT
1. Use [UP/DOWN ]buttons to change unit of
measure to Yards or Meters.
2. PRESS [OK ]button to save and return to
Settings Menu.
LANGUAGE
1. Use [UP/DOWN ]buttons to scroll
through Languages (English, Espanol,
Francais, Deutsch).
2. PRESS [OK ]button to select Language
and return to Settings Menu.
BACKLIGHT
1. Use [UP/DOWN ]buttons to scroll through
the amount of time the Backlight stays on
(5s, 10s, 30s, off).
2. PRESS [OK ]button to save and return to
Settings Menu.

16 HOW TO USE
SOUND
1. Use [UP/DOWN ]buttons to toggle
Sound (On/Off).
2. PRESS [OK ]button to save and return
to Settings Menu.
DAYLIGHT SAVINGS TIME (DST)
1. Use [UP/DOWN ]buttons to toggle
DST (On/Off).
2. PRESS [OK ]button to save and return
to Settings Menu.
SCORECARD
1. Use [UP/DOWN ]buttons to toggle
Scorecard (On/Off).
2. PRESS [OK ]button to save and return
to Settings Menu.
SHOT DISTANCE
1. Use [UP/DOWN ]buttons to toggle
Shot Distance (On/Off).
2. PRESS [OK ]button to save and return
to Settings Menu.
MODEL INFO
1. PRESS [OK ]button to return
to Settings Menu.

ENGLISH 17
WARRANTY POLICY
This product is warranted to be free from
defects for up to (1) year from the original
purchase date. IZZO Golf cannot refund your
purchase unless purchased directly from IZZO
Golf. IZZO Golf will replace or repair any unit
that is determined defective under normal
use within the warranty period. Please call
Customer Service at 888-606-4634 to request
a Return Authorization. All defective products
must be returned to:
IZZO Golf
Attn: Returns Dept.
1635 Commons Parkway
Macedon, NY 14502
Please include a note with your Name,
Address, Phone # and Return Authorization #.
Your replacement will be shipped once we
diagnose the returned unit.
To register your product visit:
www.callawaydmd.com/registration
If you have any other questions or
concerns, please call 1-888-606-4634 or
go to www.callawaydmd.com

18 CAUTION
CAUTION
Global Position System (GPS) was developed
and is managed by the United States
Department of Defense (DOD) which is
responsible for its normal operation and
position precision control; the U.S. is entitled
to affect function or position precision of
the whole system without prior notication
or announcement based on its political
considerations or safety of national defense.
In order to use the device correctly and safely,
you must be aware of the following information
prior to operating the device:
• The device was only designed for the
purpose of leisure and recreation and
is not applicable for industrial or
special measurement.
• The device is only an auxiliary device.
IZZO Golf will not accept any legal liability
for accidents due to mistaken operation, or
any use of the device for measurement.
• Please do not try to dissemble the device
or repair any part of the device discreetly.
• Please do not store the device in places
exposed to direct sunlight or in extremely
high temperatures.
© 2015 CALLAWAY GOLF COMPANY.
Callaway Golf and the Chevron device are trademarks
of Callaway Golf Company. IZZO Golf is an ofcial
licensee of Callaway Golf Company.

INTRODUCTION
Le GPS pour le golf ECLIPSE de Callaway offre
une performance d'élite sur le parcours et un design
unique. Atteignez plus souvent les verts et limitez les
coups de pénalité en connaissant les distances précis-
es, à l'avant, au centre et à l'arrière du vert, de même
que la distance des obstacles et des & doglegs.
CARACTÉRISTIQUES
2INTRODUCTION
Produit GPS Callaway ECLIPSE
# de Parcours 30,000+
Dimensions 4.25” x 3” x 1.75“ (w/Clip)
Poids 2,08 oz.
Pile Polymère lithium-ion 220mAh
Durée de la pile Golf : 9 heures / Durée : 45 jours
Taille de l'afchage 1,28 po (128 x 128 pixels)
Résistance à l'eau Oui Désignation 1 ATM
