Calorex I-PAC Series Quick start guide

I-PAC inverter heat pump
IPT 8, 12, 16, 22, 28.
Owner Installation Manual 1005494 iss 1

21005494 ISS 1
OWNER/INSTALLATION MANUAL
HEALTH AND SAFETY WARNING
This product contains electrical and rotational
equipment. ONLY competent trained people
should work on is device, and must be
isolated electrically before removing access
panels.
This appliance can be used by children from
8 years and above and persons wi reduced
physical, sensory or mental capabilities or
lack of experience and knowledge if ey
have been given supervision or instruction
concerning use of e appliance in a safe way
and understand e hazards involved. Children
should not play wi e appliance. Cleaning
and user maintenance shall not be made by
children wiout supervision.
HEALTH AND SAFETY WARNING

3
1005494 ISS 1
CONTENTS
HEALTH AND SAFETY WARNING ���������������������������2
1�0 FOREWORD ���������������������������������������������������������4
1�1 SAFETY PRECAUTIONS���������������������������������4
1�2� ATTENTION�����������������������������������������������������5
1�3� SAFETY �����������������������������������������������������������5
2�0 ABOUT YOUR HEAT PUMP �������������������������������6
2�1� TRANSPORTATION ���������������������������������������6
2�2� ACCESSORIES������������������������������������������������6
2�3 OPTIONAL ACCESSORIES�����������������������������7
2�3� FEATURES�������������������������������������������������������8
2�4� OPERATING CONDITIONS AND RANGE ����8
2�5� OPERATING MODES �������������������������������������8
3�0 INSTALLATION ����������������������������������������������������9
3�1� INSTALLATION REMINDER ������������������������10
3�2� POOL WATER CIRCUIT��������������������������������11
3�3� PLUMBING����������������������������������������������������12
4�0 ELECTROLYTIC CORROSION IN SWIMMING
POOLS�����������������������������������������������������������������������13
4�1 ELECTRIC WIRING AND SUPPLY ���������������13
4�2 CONNECTING THE MACHINE TO THE
POWER SUPPLY ��������������������������������������������������14
5�0 USING YOUR HEAT PUMP�������������������������������16
5�1� THE KEY PAD �����������������������������������������������16
5�2� OPERATING INSTRUCTIONS����������������������17
6�0� TESTING ������������������������������������������������������������18
6�1� REFRIGERANT LEAKAGE DETECTION
NOTES AND METHOD ����������������������������������������19
6�2� INITIAL CHECKS ������������������������������������������19
7�0� MAINTENANCE ������������������������������������������������20
8�0� TROUBLE SHOOTING COMMON FAULTS ����20
8�1 HEAT PUMP MALFUNCTION ����������������������21
8�2 PROTECTION CODES�����������������������������������21
8�3 FAULT CODES������������������������������������������������22
9�0� DATASHEETS ����������������������������������������������������23
10�0� DIMENSIONS��������������������������������������������������25
11�0 WINTERISATION PROCEDURE ���������������������26
11�1 START UP PROCEDURE AFTER
WINTERISATION ������������������������������������������������������26
12�0 WARRANTY CONDITIONS�����������������������������27

41005494 ISS 1
OWNER/INSTALLATION MANUAL
1�0 FOREWORD
Thank you for choosing is product, which is designed
for quiet and energy ecient operation. It is e ideal
way to heat your pool in an environmentally friendly
way.
1�1 SAFETY PRECAUTIONS
Important safety information is contained in is manual
and on your heater.
Please read and follow all safety advice.
The refrigerant used in is heat pump is R32. This
refrigerant is environmentally friendly, but safety
instructions must be strictly adhered to.
The WARNING sign denotes a hazard. It calls
attention to a procedure or practice, which if not
adhered to could result in injury. Warning signs
and procedures must be complied wi.
The heat pump must be kept
away from sources of fire or
naked flames.
The heat pump must be
installed in well ventilated
area. Closed areas are not
permitted.
Repair and disposal must
be carried out by F-Gas
registered engineers.
Completely de-gas e
refrigerant before any brazing
is performed. Brazing can only
be carried out by technicians
trained to EU 517/2014.

5
1005494 ISS 1
1�2� ATTENTION
Please read e following instructions before installation,
use and maintenance.
• Installation must be carried out by competent
people, in accordance wi is manual.
• A refrigerant leak test must be performed aer
installation.
• Only manufacturers recommended procedures may
be used to defrost, or to accelerate e defrost of
e heat pump, to avoid damage.
• If a repair is required, please contact e nearest
aer-sales service centre.
• To avoid over heating or over cooling set e
desired temperature on e control panel.
• Do not place obstructions at will block air flow
near e inlet or outlet.
• Do not use or store combustible gas or liquids near
e heat pump.
• The heating performance can be improved
by insulating e flow and return pipework. it
is recommended at a cover is used on e
swimming pool to reduce heat losses.
1�3� SAFETY
• Mains power isolator should be out of reach of
children.
• Aer a power cut, when e power supply is
restored, e heat pump will start up.
• Electric storms can damage electronic equipment.
Ideally e heat pump should be switched off at
e mains.
• Risk assessments must be carried out before
maintenance or repairs are started.
• If R32 gas leaks during e installation process, stop
e installation immediately and call e service
centre.

61005494 ISS 1
OWNER/INSTALLATION MANUAL
2�0 ABOUT YOUR HEAT PUMP
2�1� TRANSPORTATION
Always keep e heat pump upright.
Do not li e heat pump by e water inlet or outlet
connections.
(If is is done e titanium heat exchanger inside e
heat pump could be damaged).
2�2� ACCESSORIES
These accessories are provided wi e heat pump.
Water union
2 x 1½
2 x 50mm
Drainage kit
x

7
1005494 ISS 1
2�3 OPTIONAL ACCESSORIES
The following items are additional accessories available
for purchase.
Rubber mounting kit.
(pack of 4 mounts).
Remote LED control kit for indoor installation.
(10m extension cable).
Winter cover.

81005494 ISS 1
OWNER/INSTALLATION MANUAL
2�3� FEATURES
• Stepless DC inverter compressor
• EEV Technology (Electronic Equalisation Valve)
• Quick hot gas defrosting wi Saginomiya 4-way
valve
• High-eciency twisted titanium heat exchanger
• High pressure and low pressure protection
• So start and wide voltage application
• Stable inverter control system
2�4� OPERATING CONDITIONS AND RANGE
Air temperature operating range:
-5-43°C (X) -10-43°C (Y)
Heating temperature setting range: 18°C-40°C
Cooling temperature setting range: 12°C-30°C
2�5� OPERATING MODES
The heat pump has two modes: Boost mode and
Whisper mode.
Mode Modes Characteristics
Boost mode
Heating capacity: 20% to 100% capacity
Intelligent optimization
Fast heating
Whisper mode
Heating capacity: 20% to 80% capacity
Sound level: 3dB (A) lower an Boost mode

9
1005494 ISS 1
3�0 INSTALLATION
> 50 cm
Plant room
Calorex*
Wall
Calorex
Possible positions of a Calorex heat pump
Wall
Suitable opening
Calorex* >70 cm
Calorex
>70 cm
>250 cm
Calorex
The red lines represent e air inlet area
Swimming pool or spa
* Controls are obscured by e wall� Connect to
Remote control panel or Wi-Fi before installing
e heat pump in position�
Required free areas to provide air flow to and from heat
pumps when installed in an enclosed area or where
required to pass air rough a wall etc.
Free area is e available area rough which air can
pass rough a grille or louvres.
Minimum free areas m2
Model Discharge area
IPT 8 0.169
IPT 12 0.169
IPT 16ALX 0.169
IPT 16ALY 0.229
IPT 22 0.301
IPT 28 0.301

10 1005494 ISS 1
OWNER/INSTALLATION MANUAL
3�1� INSTALLATION REMINDER
Installation must only be attempted by competent
personnel.
Location and dimensions.
The heat pump must be positioned in a well
ventilated area. Minimum distances between e heat
pump and any obstructions are shown below.
• The heat pump must be fixed by M10 bolts to a
concrete base or mounting brackets. These must be
solid and fixed securely. Brackets must be corrosion
proof.
• Do not block inlet or outlet grilles.
>70 cm
>250 cm
Calorex
>70 cm
>50 cm
Swimming pool or spa
Fan grille
Wall

11
1005494 ISS 1
3�2� POOL WATER CIRCUIT
Anti return loop
to be incorporated,
minimum height
100mm above
heat pump
outlet port
(If sanitiser fitted)
Non return
valve
Sanitiser or
chemical dosing
device,
(If fitted)
Aux heater
(If fitted)
Filter Pump
To waste
for
winterising
drain down
100mm
Condensate
water to
waste
Spare port
for winterising
flushing
connection
To waste
Calorex
Heat pump
Pool
Bypass
valve
(Normally
closed)
KEY
Isolation valve
Breakable coupling
Three way valve

12 1005494 ISS 1
OWNER/INSTALLATION MANUAL
3�3� PLUMBING
Hose. Condensate adaptor.
Fit in hole in base of unit.
Approximate position shown.
Water
out
Note: Fittings shown at larger scale for clarity.
Water
in
x

x

IMPORTANT
Before installing e heat pump ensure e
blanking disks are removed from e pool water
in/out connections� These should drop out when
e adaptors are unscrewed�
1. Ensure at bypass is installed and set to achieve
e recommended flow rates stated in e data
sheet.
2. Ensure at e condensate drain kit supplied is
fixed and is drained to a drain or soak-away.
(It is best to do is first before e heat pump
is fixed to pipework or e ground)�
3. Inlet and outlet pipework must be supported to
avoid excessive strain on e connections.

13
1005494 ISS 1
Electrolytic corrosion will occur when dissimilar metals
at are in contact wi each oer create a potential
difference between emselves. Sometimes separated
by a conductive substance known as an electrolyte, e
dissimilar metals will create a small voltage (potential
difference) at allows e ions of one material to pass
to e oer.
Just like a battery, ions will pass from e most positive
material to e more negative material.
Anying more an 0.3 volts can cause e most
positive material to degrade.
A swimming pool wi its associated equipment
can create is effect. The pool water being an ideal
electrolyte and components of e filtration circuit,
heating system, steps, lights etc providing e dissimilar
metals needed to complete e circuit.
Whilst ese small voltages are rarely a safety reat,
ey can create premature failure rough corrosion.
Not dissimilar to corrosion rough oxidation, electrolytic
corrosion can cause complete failure of a metallic
material in a very short period of time.
In order to prevent is type of corrosion all metallic
components in contact wi swimming pool water
should be bonded togeer using 10mm² bonding
cable. This includes non-electrical items such as metal
filters, pump strainer boxes, heat exchangers, steps
and handrails. It is highly recommended at bonding
be retrofitted to existing pools, which may not be
protected by is system.
All electrical work to be carried out in accordance wi
l.E.E. regulations, latest issue, or local codes of practice
as applicable.
The machine should be installed in accordance wi
EMC2004/108/EC.
Protected supply fuses or motor type circuit breakers
(Type GU, FAZC) to specified rating, (see below). H.R.C.
fuses are recommended. An isolator which disconnects
all poles must be fitted wiin 2m and in line of sight of
e heat pump.†
All units must be correctly eared- Grounded and an
ear leakage trip installed.
Inconsistent electrical supply
The following voltage limits must not be exceeded.
Failure to achieve e necessary voltages will invalidate
e warranty.
Minimum Maximum
Voltage
Single phase machines 207V 253V
Three-phase machines 360V 440V
Cycle frequency (50Hz) 47.5Hz 52.5Hz
The voltage must not drop below e above figures
when starting e machine.
Note. This voltage must be available at e heat pump
whilst running.
† Note. The isolator must have a minimum of 3mm air
gap when turned off.
4�0 ELECTROLYTIC CORROSION IN SWIMMING
POOLS
4�1 ELECTRIC WIRING AND SUPPLY

14 1005494 ISS 1
OWNER/INSTALLATION MANUAL
4�2 CONNECTING THE MACHINE TO THE
POWER SUPPLY
L N
Fuse/MCB
Eared Power
Supply 230V 50Hz
Supply
cord
Distribution box
L N
RCD/
Circuit
Breaker
Remove ese
two screws
Li lower
panel away
P1 P2
Power
terminals
Pump
terminals
Secure cables
using cable
clamps and feed
rough cable
entry points in
machine
Cable clamp
L3
N
Fuses/MCB
Eared Power
Supply 400V 50Hz
L3 N P1 P2
Power
terminals
Pump
terminals
Single phase
Terminals in Heat Pump Electrics enclosure
L2
L1
L2
L1
1
Remove ese
four screws and
remove cover
Two cable
entry points
2
Three phase
Terminals in Heat Pump Electrics enclosure
Cable clamp
Secure cables
using cable
clamps and feed
rough cable
entry points in
machine
Supply
cord
RCD/
Circuit
Breaker
Distribution box

15
1005494 ISS 1
Recommended electrical installation for Calorex heat pump
(Single or Three phase) wi single phase water pump
L
N
L N
N
N L
L
N
P1
P2
CALOREX
Heat pump
Single phase
N L
Single phase
Switched fuse isolator wiin 2m
of heat pump and sized in
accordance wi datasheet
Single phase supply
to suit capacity
Water pump
more an 3/4 HP
Single Phase
Minimum 2 Pole N/O starter
wi overload
and 230V 50Hz coil
rated to suit water pump
L1
N
P1
P2
CALOREX
Heat pump
Three phase
N L1
Three phase
Switched fuse isolator wiin 2m
of heat pump and sized in
accordance wi datasheet
L2
L3
L3
L2
L

16 1005494 ISS 1
OWNER/INSTALLATION MANUAL
For installations where a time clock controls e filter
pump, which also provides water for e heat pump,
your heat pump can over-ride “pump off “ periods.
By doing so, your filter pump will only run when
a) a block period of pump “running” has been set on
e time clock for filtration purposes.
b) e pool requires heating
This feature operated by over-riding e time clock for
five minutes each hour. This allows pool water to be
circulated rough e heat pump
During is sampling period if e heat pump detects a
need for water heating, it will continue to over-ride e
time clock until e pool water temperature is satisfied.
If water heating is not required, e over-ride will stop,
and e filter pump will turn off, and not restart until e
next hourly sampling period, or pre-set run time.
This feature will reduce e filter pump run time, and
consequently save energy as well as unnecessary filter
pump wear and tear.
4�3 POOL PUMP SYNCHRONISATION
Water pump
Power Supply
230V ~N 50Hz
Customer’s circuit
breaker or fuse for
water pump
Ear
L
N
Supply lead
Power supply
230V ~N 50Hz
Customer’s circuit breaker or
fuse for heat pump
Ear
L
N
Terminals in heat pump
LNP1 P2
GR/Y
Contactor
Water Pump

17
1005494 ISS 1
5�0 USING YOUR HEAT PUMP
5�1� THE KEY PAD
Symbol Designation Function
On/Off
Power On/Off
Wi-Fi Setting
Unlock Heat Mode
Lock/Unlock Screen
Mode switching for heating, cooling or automatic heat/
cool.
Speed Mode Two mode for switching, Boost or Whisper
Up/Down Temperature Setting and Display
Attention:
a. Standby mode or Screen lock: Only lights
up, screen and oer buttons turn dark.
b. Power off: Only lights up, No display on
screen.
c. The controller has a power-saving function.

18 1005494 ISS 1
OWNER/INSTALLATION MANUAL
a� Screen lock
1) Press for 3 seconds to lock or unlock e
screen.
2) Automatic lock period: 30 seconds if no operation.
b� Power on
Press for 3 seconds to unlock screen.
Press to power on machine.
c� Temperature setting
Press and to display and adjust e set
temperature.
d� Heat Mode selection
Press to switch between
Heating mode
Cooling mode
Automatic heat cool mode
e� Speed Mode selection
Press to switch between Boost mode and
Whisper mode.
Default mode: Boost.
Please choose Boost mode for initial heating.
f� Wi-Fi
When e screen is on, press for 3 seconds,
aer flashes, enter Wi-Fi connection.
Connect Wi-Fi on mobile phone and input password,
en control equipment by Wi-FIi. When APP connects
Wi-Fi successfully light is on. When setting by
APP, flashes.
Clear Wi-Fi setting history:
When screen is on, press for 10 seconds, aer
flashing for 10 seconds, lights off.
g� Defrosting
1. Automatic defrosting: When machine is defrosting,
e lamp flashes; aer defrosting e
lamp stops flashing.
2. Forced defrosting: When machine is heating and
e compressor has been running continuously for
10 minutes, press and simultaneously for
5 seconds to start forced defrosting.
The lamp flashes and defrost starts,
when e lamp stops flashing defrosting stops.
Note: The minimum interval between periods of forced
defrosting should be more an 30 minutes.
Attention: The controller has power-down memory
function.
5�2� OPERATING INSTRUCTIONS

19
1005494 ISS 1
6�1� REFRIGERANT LEAKAGE DETECTION
NOTES AND METHOD
Refrigerant leak detection is prohibited in closed area.
An ignition source must not be used during leak
detection.
Leak detection fluids can be used but e use of
detergents containing chlorine must be avoided as
e chlorine may react wi e refrigerant and cause
corrosion.
Completely de-gas e refrigerant from e heat pump
before any brazing is carried out. Brazing must only be
carried out by trained technicians in accordance wi
EU517/2014.
If a refrigerant leak is suspected stop using e heat
pump and contact Danerm Group UK service,
service.department@danerm.com
6�2� INITIAL CHECKS
Start e filtration pump before e heat pump is
switched on, and turn off e heat pump before e
filtration pump.
Note. Heat pump must be turned off prior to
backwashing.
Before staring e heat pump, please check for any
leakage of water; and set e required temperature on
e ermostat, and en switch on power supply.
In order to protect e swimming pool heater, e
machine is equipped wi a time lag starting function.
When starting, e fan will run for one minute before
e compressor starts, and when power to e
machine is turned off it will stop running one minute
aer e compressor stops.
Aer starting up, please check for any abnormal noise
from e machine.
6�0� TESTING
Inspect heat pump before use
• Check at e fan, air inlets and outlets are not
obstructed.
• It is prohibited to install refrigeration pipe or
components in corrosive environment.
• Check at e electric wiring conforms to e
electric wiring diagram and at e machine is
eared.
• Double check at e main power switch is off.
• Check e temperature setting.

20 1005494 ISS 1
OWNER/INSTALLATION MANUAL
7�0� MAINTENANCE
Cover e machine body when not in use.
Please clean is machine wi household detergents
or clean water, NEVER use gasoline, inners or any
similar fuel.
Check bolts, cables and connections regularly.
Repair, service and disposal of redundant heat pumps
must be completed by auorised technicians. It is
illegal to allow refrigerant gases to escape to air.
Do not attempt to work on e equipment by yourself.
Improper operation may cause danger.
8�0� TROUBLE SHOOTING COMMON FAULTS
Requirements for service personnel
Any person who is involved wi working on or
breaking into a refrigerant circuit should hold a current
valid certificate from an industry-accredited assessment
auority, F-Gas registered.
Do not attempt to work on e equipment by
yourself.
Strictly comply wi e manufacturer’s requirements
when charging R32 gas. This chapter focuses on
special maintenance requirements for swimming pool
heat pump wi R32 gas. Please refer to e technical
service manual for detailed maintenance operation.
The heat pump must be completely de-gassed before
any brazing. Brazing must only be carried out by
trained personnel.
Isolate e
power supply
of e heater
before cleaning,
examination or
repair.
