Calorex I-PAC Series Quick start guide

I-PAC inverter heat pumps
I-PAC 50/100BLY, I-PAC 50/100BHC
Owner Installation Manual 1007929 Issue 1

21007929 ISSUE 1
OWNER/INSTALLATION MANUAL
HEALTH AND SAFETY WARNING
This product contains electrical and rotational
equipment and must be isolated electrically
before removing access panels. ONLY
competent trained people should work on is
device.
This appliance can be used by children from
8 years and above and persons wi reduced
physical, sensory or mental capabilities or
lack of experience and knowledge if ey
have been given supervision or instruction
concerning use of e appliance in a safe way
and understand e hazards involved. Children
should not play wi e appliance. Cleaning
and user maintenance shall not be made by
children wiout supervision.
HEALTH AND SAFETY WARNING

3
1007929 ISSUE 1
HEALTH AND SAFETY WARNING ���������������������������2
1�0 INTRODUCTION ��������������������������������������������������4
1�1 FOREWORD�����������������������������������������������������4
1�2 WARNINGS ������������������������������������������������������4
2�0 ABOUT YOUR HEAT PUMP �������������������������������7
2�1 TRANSPORTATION ����������������������������������������7
2�2 ACCESSORIES�������������������������������������������������8
2�3 OPTIONAL ACCESSORIES�����������������������������8
2�4 FEATURES��������������������������������������������������������9
2�5 OPERATING CONDITIONS AND RANGE �����9
2�6 OPERATING MODES ��������������������������������������9
3�0 INSTALLATION ��������������������������������������������������10
3�1 POSITIONING AND AIRFLOW���������������������10
3�2 POOL WATER CIRCUIT���������������������������������13
3�3 PLUMBING�����������������������������������������������������14
3�4 INITIAL CHECKS �������������������������������������������14
3�5 ELECTROLYTIC CORROSION IN SWIMMING
POOLS�������������������������������������������������������������������15
3�6 ELECTRIC WIRING AND SUPPLY ���������������15
3�7 CONNECTING THE HEAT PUMP TO THE
POWER SUPPLY ��������������������������������������������������16
3�8 POOL PUMP SYNCHRONISATION
TERMINALS P1 AND P2�������������������������������������18
3�9 INSTALLING THE OPTIONAL REMOTE
CONTROLLER ������������������������������������������������������19
3�10 REMOTE ON / OFF TERMINALS 5 AND 6
�������������������������������������������������������������������������������20
4�0 USING YOUR HEAT PUMP�������������������������������21
4�1 THE KEY PAD ������������������������������������������������21
4�2 OPERATING INSTRUCTIONS�����������������������22
4�3 USING THE APP��������������������������������������������23
4�4 USING THE OPTIONAL REMOTE
CONTROLLER ������������������������������������������������������29
4�5 THE KEY PAD ������������������������������������������������29
4�6 OPERATING INSTRUCTIONS�����������������������30
5�0 TESTING �������������������������������������������������������������31
5�1 HEAT PUMP MALFUNCTION ����������������������31
5�2 PROTECTION CODES ����������������������������������32
5�3 FAULT CODES������������������������������������������������33
6�0 MAINTENANCE �������������������������������������������������34
7�0 TROUBLE SHOOTING COMMON FAULTS �����34
8�0 I-PAC 50/100BLY, I-PAC 50/100BHC
DATASHEET ��������������������������������������������������������������35
9�0 I-PAC 50/100BLY, PERFORMANCE GRAPHS
������������������������������������������������������������������������������������36
10�0 PRODUCT DRAWINGS �����������������������������������37
11�0 WINTERISATION PROCEDURE ���������������������41
11�1 START UP PROCEDURE AFTER
WINTERISATION ������������������������������������������������������41
12�0 WARRANTY CONDITIONS�����������������������������42
13�0 HEAT PUMP RECORD LOG����������������������������43
14�0 DECLARATION OF CONFORMITY����������������45
CONTENTS

41007929 ISSUE 1
OWNER/INSTALLATION MANUAL
Thank you for choosing is product, which is designed
for quiet and energy ecient operation. It is e ideal
way to heat your pool in an environmentally friendly
way.
This guide provides information needed to install and
operate e heat pump effectively. Please ensure you
read is manual and use e correct installation and
operating procedures.
This manual is intended for installers and users�
Read e entire manual before using e heat
pump� Awareness of e correct operating
procedure for e machine and any safety devices
is important, to avoid damage or injury�
The appliance can be used by children aged from 8
years and above and persons wi reduced, physical,
sensory or mental capabilities or lack of experience
and knowledge if ey have been given supervision
or instruction concerning use of e appliance in a safe
way and understand e hazards involved. Children
shall not play wi e appliance. Cleaning and user
maintenance shall not be made by children wiout
supervision.
1�2 WARNINGS
Important safety information is contained in is manual
and marked on e heat pump.
Please read and follow all safety advice�
The WARNING sign denotes a hazard� It calls
attention to a procedure or practice, which if not
adhered to could result in injury� Warning signs
and procedures must be complied wi�
If a refrigerant leak is suspected stop using e
heat pump and contact Danerm Group UK
service�
service�department@danerm�com or
[phone] (option 4)�
Take e following precautions in order to avoid
any danger:
REFRIGERANT SAFETY:
Repair, service and disposal must be carried out by
F-Gas registered engineers.
Completely evacuate e refrigerant before any brazing
is performed. Brazing can only be carried out by
technicians trained to EU 517/2014.
Risk assessments must be carried out before
maintenance or repairs are started.
Appropriate safety measures and risk assessments
must be taken before work commences.
Do not attempt to work on e equipment by
yourself�
Consult e qualified engineer undertaking e work to
establish all requirements before work commences.
1�1 FOREWORD
1�0 INTRODUCTION

5
1007929 ISSUE 1
ACTIONS TO AVOID (OPERATION AND
HANDLING):
Be especially careful when handling e heat pump,
not to cause any damage at may result in leakage of
e cooling circuit.
Do not use means to accelerate e defrosting process
or to clean, oer an ose recommended by e
manufacturer.
Do not pierce or burn.
IN CASE OF FIRE:
Toxic fumes may occur in e event of fire. You must
leave e room as quickly as possible in e event of
fire.
Check if ere are any local regulations, which
you must comply to, when installing or storing
e heat pump�
Be aware at refrigerants may not contain an
odour�

61007929 ISSUE 1
OWNER/INSTALLATION MANUAL
Installation must be carried out by competent people,
in accordance wi is manual.
INSTALLATION:
Read e instructions before installation, use and
maintenance.
If a repair is required, please contact e nearest aer-
sales service centre.
To avoid over heating or over cooling of pool water
check and set e temperature on e control panel.
The performance can be improved by insulating e
flow and return pipework.
It is recommended at a cover is used on e
swimming pool to reduce heat losses.
AIRFLOW:
The heat pump must have access to adequate airflow.
See section 3.1.
Do not place obstructions at will block air flow near
e inlet or outlet.
ELECTRICAL SAFETY:
Mains power isolator should be out of reach of children.
Aer a power cut, when e power supply is restored,
e heat pump may start up wiout warning.
Electric storms can damage electronic equipment.
Ideally e heat pump should be switched off at e
mains.
HEAT PUMP MALFUNCTION:
WARNING: Isolate heat pump electrically and wait
3 minutes before removing panels or entering heat
pump.
Refer to e user check list in section 5.2 and e error
codes listed in section 5.3 before initiating a service call.
Do not attempt to interfere wi any internal control
settings as ese have been factory calibrated and
sealed.
Any sign of abnormal operation such as water dripping
should be reported immediately to e installer. If
in doubt or if advice is required contact e Service
support team on telephone [phone]
(option 4).
MAINTENANCE:
Isolate e power supply of e heat pump and wait 3
minutes before cleaning examination or repair.
Please clean is machine wi household detergents
or clean water. NEVER use petroleum spirit, inners or
any similar fuel.
Check bolts, cables and connections regularly.
BACKWASH:
When performing a routine backwash care should be
taken to prevent water passing rough e heat pump
in e reverse direction or at a rate which exceeds e
maximum recommended water flow rates indicated in
e data sheet [section 8] as is may cause damage to
e heat pump water condenser or flow switch.
DISPOSAL:
Repair, service and disposal of redundant heat pumps
must be completed by auorised technicians. It is
illegal to allow refrigerant gases to escape to air.
Do not attempt to work on e equipment by yourself.
Improper operation may cause danger.

7
1007929 ISSUE 1
2�0 ABOUT YOUR HEAT PUMP
2�1 TRANSPORTATION
Always keep e heat pump upright.
Undo e fixing screws on e pallet.
Use a forkli to move e heat pump to e location.
Do not li e heat pump by e water inlet or outlet
connections�
(If is is done e titanium heat exchanger inside e heat
pump could be damaged).

81007929 ISSUE 1
OWNER/INSTALLATION MANUAL
2�2 ACCESSORIES
These accessories are provided wi e heat pump.
2�3 OPTIONAL ACCESSORIES
The following items are additional accessories available
for purchase.
Remote controller kit for indoor installation.
(10m extension cable).
Supplied wi a module to allow e Wi-Fi connectivity
function to operate wi e remote control.
i

9
1007929 ISSUE 1
2�4 FEATURES
• Stepless DC inverter compressor
• Brushless fan motor
• EEV Technology (Electronic Equalisation Valve)
• Reverse cycle defrosting wi 4-way valve
• High-eciency twisted titanium heat exchanger
• High pressure and low pressure protection
• So start and wide voltage application
• Stable inverter control system
2�5 OPERATING CONDITIONS AND RANGE
Air temperature operating range:
I-PAC 50 / 100BLY models: -7°C to 43°C
I-PAC 50 / 100BHC models: 10°C to 55°C
Water temperature setting range:
Heating: 18°C-35°C
Cooling: 12°C-30°C
2�6 OPERATING MODES
The heat pump has two modes: Boost mode and
Whisper mode.
Mode Modes Characteristics
Boost mode
Heating capacity: 20% to 100% capacity
Intelligent optimization
Fastest heating
Whisper mode
Heating capacity: 20% to 80% capacity
Sound level: 3dB(A) lower an Boost mode

10 1007929 ISSUE 1
OWNER/INSTALLATION MANUAL
3�0 INSTALLATION
Installation must only be attempted by competent
personnel.
3�1 POSITIONING AND AIRFLOW
The heat pump should be located in an open
space wi e maximum possible distance in all
directions to any obstructions. The heat pump should
not be covered by any structure or awning.
The heat pump works by absorbing energy from air
passing rough it so any restriction in e air flow will
reduce performance.
An obstruction is an object such as a wall, fence,
hedge or anying similar which may restrict e free
movement of air.
Obstructions can also cause exhaust air leaving e
heat pump to be sucked back into e heat pump
which will reduce performance.
Locating e heat pump near any obstructions should
be avoided if possible however if it is enclosed on up
to two sides by obstructions at e minimum distances
en e heat pump should perform as expected.
If e heat pump is enclosed on more an two sides
by obstructions at e minimum distances en e
performance will be reduced.
If ere are obstructions closer to e heat pump an
e minimum distances en e performance will be
significantly reduced.
A reduction in performance will result in longer pool
heat up times, e pool not reaching e desired
temperture and excess energy costs.
The diagrams show e minimum allowable mandatary
distances between e heat pump and any potential
obstuctions.
The heat pump should be fixed by M10 bolts to a level
concrete base or to solid mounting brackets which are
securely fixed. Fixings [including any brackets] must be
corrosion proof. Ensure e condensate connection is
made prior to securing e heat pump.
Airflow - general principles
• The heat pump absorbs energy from e air drawn
rough it. To function effectively e heat pump
must have access to e fresh air it needs.
• Air must not recirculate. The air leaving e heat
pump must not be sucked back into e inlet.
• Air must not be restricted. The air volume must not
be reduced.
• The minimum required distances shown must be
provided to minimise e risk of air recirculation or
restriction and reduction in performance. Examples
are shown on e following page.

11
1007929 ISSUE 1
>120cm
>100cm >100cm
Obstruction
>100cm >100 cm
Wall
Typical inside or plant room installation.
(Not recommended for long duct runs).
The plant room must not be used
as an occupied space.
>300cm
Typical outside installation.
>100cm
Obstruction
>300cm
Typical outside installation.
>100cm >100 cm
Plantroom
Typical inside or plant room installation.
(Not recommended for long duct runs).
The plant room must not be used
as an occupied space.
>120cm
>100cm >100cm
Obstruction
Obstruction
>100cm
I-PAC 50BLY / I-PAC 50BHC
I-PAC 100BLY / I-PAC 100BHC

12 1007929 ISSUE 1
OWNER/INSTALLATION MANUAL
>350 cm
Swimming pool or spa
To comply wi safety regulations regarding electrical
installations in wet areas e heat pump must be
installed at least 350cm away from e edge of e
pool or spa.

13
1007929 ISSUE 1
3�2 POOL WATER CIRCUIT
Anti return loop
to be incorporated,
minimum height
100mm above
heat pump
outlet port
(If sanitiser fitted)
Non return
valve
Sanitiser or
chemical dosing
device,
(If fitted)
Aux heater
(If fitted)
Filter Pump
To waste
for
winterising
drain down
100mm
Condensate
water to
waste
Spare port
for winterising
flushing
connection
To waste
Calorex
Heat pump
Pool
Bypass
valve
(adjusted to
achieve
recommended
flow)
KEY
Isolation valve
Breakable coupling
Three way valve

14 1007929 ISSUE 1
OWNER/INSTALLATION MANUAL
3�3 PLUMBING
IMPORTANT
Before installing e heat pump ensure e
blanking disks are removed from e pool water
in/out connections� These should drop out when
e adaptors are unscrewed�
1. Ensure at bypass is installed and set to achieve
e recommended flow rates stated in e data
sheet.
2. Ensure at e condensate drain kit supplied is
fixed and is drained to a drain or soak-away.
(It is best to do is first before e heat pump
is fixed to pipework or e ground)�
3. Inlet and outlet pipework must be supported to
avoid excessive strain on e connections.
4. Water quality must be maintained. See warranty
conditions.
3�4 INITIAL CHECKS
Start e filtration pump before e heat pump is
turned on, and turn off e heat pump before e
filtration pump. It is recommended to turn off e heat
pump prior to backwashing.
Before starting e heat pump, please check for
any leakage of water; and check/set e required
temperature on e controller, and en turn on.
In order to protect e components, e heat pump
incorporates time delays. When starting heating/cooling
e fan will run for one minute before e compressor
starts. When e heat pump stops heating/cooling, or
is turned off by e user, e fan will continue to run for
one minute.
Aer starting up, check for any error codes or abnormal
noise from e heat pump.

x
Water
out
Water
in
Condensate
drain position

15
1007929 ISSUE 1
Electrolytic corrosion will occur when dissimilar metals
at are in contact wi each oer create a potential
difference between emselves. Sometimes separated
by a conductive substance known as an electrolyte, e
dissimilar metals will create a small voltage (potential
difference) at allows e ions of one material to pass
to e oer.
Just like a battery, ions will pass from e most positive
material to e more negative material.
Anying more an 0.3 volts can cause e most
positive material to degrade.
A swimming pool wi its associated equipment
can create is effect. The pool water being an ideal
electrolyte and components of e filtration circuit,
heating system, steps, lights etc providing e dissimilar
metals needed to complete e circuit.
Whilst ese small voltages are rarely a safety reat,
ey can create premature failure rough corrosion.
Not dissimilar to corrosion rough oxidation, electrolytic
corrosion can cause complete failure of a metallic
material in a very short period of time.
In order to prevent is type of corrosion all metallic
components in contact wi swimming pool water
should be bonded togeer using 10mm² bonding
cable. This includes non-electrical items such as metal
filters, pump strainer boxes, heat exchangers, steps
and handrails. It is highly recommended at bonding
be retrofitted to existing pools, which may not be
protected by is system.
All electrical work to be carried out in accordance wi
l.E.E. regulations, latest issue, or local codes of practice
as applicable.
The machine should be installed in accordance wi
EMC2004/108/EC.
Always isolate e main power supply before removing
machine covers.
The machine power supply must incorporate e
following. Fuses or motor type circuit breakers (aM
Fuse / MCB type C) to specified rating (see datasheet).
When using a fuse, H.R.C. fuses are recommended. An
isolator which disconnects all poles must be must fitted
wiin 2m and in line of sight of e heat pump. The
isolator must have a minimum of 3mm air gap when
turned off.
All units must be correctly eared/grounded and its
own separate type RCD ear leakage trip installed
which protects e machine only. See data sheet for
e correct type.
The following limits of operation must not be exceeded.
Failure to provide e necessary voltages will invalidate
e warranty. This voltage must be available at e heat
pump whilst running. The voltage must not drop below
e above figures when starting e compressor.
Minimum Maximum
Voltage
Three-phase machines 360V 440V
Cycle frequency (50Hz) 47.5Hz 52.5Hz
3�5 ELECTROLYTIC CORROSION IN SWIMMING
POOLS
3�6 ELECTRIC WIRING AND SUPPLY

16 1007929 ISSUE 1
OWNER/INSTALLATION MANUAL
Remove ese
two screws
Li lower
panel away
1
Remove screws
and remove cover
Two cable
entry points
2
CAUTION
Remove screws -2
and remove cover
3
Ensure cable runs
rough all ree
holes
4Replace all covers wi retained screws.
5
P1 P2 R S T N
POWER
380~415V
50Hz
Note:
The illustrations show e IPT 50 heat
pump. The instructions are e same
for e IPT 100 heat pumps.
3�7 CONNECTING THE HEAT PUMP TO THE POWER
SUPPLY

17
1007929 ISSUE 1
Isolator which
disconnects all poles
fitted wiin 2m and in line
of sight of e heat pump
L3
N
Fuses/MCB
Eared Power
Supply 400V 50Hz
T
N
P1 P2
Power
terminals
Pump
terminals
S
R
L2
L1
Three phase
Terminals in Heat Pump Electrics enclosure
Cable clamp
Supply
cord
RCD/
Circuit
Breaker
Distribution box
Secure cables
using cable
clamps and feed
rough cable
entry points in
machine

18 1007929 ISSUE 1
OWNER/INSTALLATION MANUAL
L
Terminals in
heat pump
(volt free)
Customer’s external pump/
filter time clock
P1
P2
N
Pool pump
starter
L
N
Single phase
water pump
L N
Separate supply
E
Fuse
Contact rating
2A max
For installations where e pool filter pump runs
continuously, ese terminals do not need to be used.
For installations where a timeclock controls e pool
filter pump, and e same pump provides water flow
to e heat pump, e heat pump can override “pump
off” periods to ensure e pool is heated/cooled. To
activate is setting please speak to your installer.
When installed in parallel wi e timeclock, e pool
filter pump will run when:
a) a block period of “pump on” has been set on e
time clock for filtration purposes.
b) e heat pump runs e pool filter pump for
temperature sampling and if e pool subsequently
requires heating/cooling.
This feature operates by over-riding e timeclock for
3 minutes to circulate e pool water rough e heat
pump to sample e water temperature. The default
sampling time interval is 1 hour.
If e measured temperature is more an 1°C
from e set temperature, e point heat pump will
continue to run e filter pump and heat/cool e pool.
If e measured temperature is wiin 1°C of e set
temperature, e filter pump will turned off until e
next sampling period, or e next timeclock “pump on”
period.
When e pool pump is already running, and e
heat pump is not heating/cooling, e heat pump will
sample e water temperature once per hour and will
start heating/cooling if needed. The heat pump will
ignore a demand to heat/cool e pool until e
sampling timer (default 1 hour) has elapsed*.
This feature will reduce e pool filter pump run time to
minimise pump energy usage.
*If e pool filter pump is later changed to run
continuously, it is recommended to de-activate is
setting so e heat pump will respond to a heating/
cooling demand wiout waiting for e sampling time
interval to elapse. To deactivate is setting please
speak to your installer.
3�8 POOL PUMP SYNCHRONISATION
TERMINALS P1 AND P2
*The installer will need to adjust parameter P0 when using is feature�

19
1007929 ISSUE 1
3�9 INSTALLING THE OPTIONAL REMOTE CONTROLLER
This optional accessory replaces e integral controller
and can be installed up to10m away.
Take e lid off e IPT to gain access to e existing
controller. Remove e upper and lower front covers.
Disconnect e plug from e socket (inside sleeving)
on e back of e controller as shown.
Feed e cable from e remote controller rough e
upper cable access point.
This hole.
Connect e lead. and slide e sleeving back over e
connectors. Secure e sleeving wi a cable tie.
Route e cable inside e IPT securing it where
necessary. Make sure ere is a drip loop and at e
connector is above e lowest point in e cabling.

20 1007929 ISSUE 1
OWNER/INSTALLATION MANUAL
If e cable is concealed, fit e grommet in e hole to
protect e cable from rubbing.
Secure e cable from e controller in e IPT
Refit e front covers and e top cover.
To check at e installation is correct, set e
temperature on e remote controller to slightly higher
an e pool water. The IPT should run to heat e
pool, immediately if e pump synchronisation is
not in use, or at e next sampling period if pump
synchronisation is in use.
Inlet for
exposed cable.
Inlet for
concealed cable.
Connect e lead. Remove e two screws from e back of e Remote
Controller.
Remove e appropriate knock out and fit e back of
e box to e wall.
3�10 REMOTE ON / OFF TERMINALS 5 AND 6
Terminals in
heat pump
5V DC
Customer’s external
remote switch
5
6
For installations where a remote On / Off function is
required an external switch can be used to over ride
e main On / Off switch and power e heat
pump on or off.
The machine is supplied wi a link installed between
terminals 5 and 6 which should be removed and
replaced wi an external switching device as indicated.
When e external switch contacts are closed e heat
pump will power on and remain operational until e
external contacts are broken.
