Calphalon TSCLTRDG3 User manual

1
INSTRUCTION MANUAL
COUNTERTOP OVEN
PRECISION CONTROL
MODEL: TSCLTRDG3

TABLE OF CONTENTS
IMPORTANT SAFEGUARDS 3
POLARIZED PLUG 5
PRODUCT DIAGRAM 6
USAGE INSTRUCTIONS 7
PREPARING YOUR COUNTERTOP OVEN 7
OVEN FUNCTIONS OVERVIEW 7
HOW TO USE YOUR COUNTERTOP OVEN 8
COOKING FUNCTIONS DETAILS 9
CLEANING & MAINTENANCE 14
TROUBLESHOOTING 15
WARRANTY 16

3
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed, including the
following:
1. Read all instructions, product labels and warnings before using your Precision Control countertop oven.
2. This appliance generates heat during use. Do not touch hot surfaces. Use handles or knobs. Always
protect your hands with non-slip oven mitts or similar.
3. To protect against electric shock, do not place or immerse cord, plugs, or appliance in water or other
liquid.
4. This appliance is not to be used by children or by persons with reduced physical, sensory or mental
capabilities.
5. Close supervision is necessary when any appliance is used near children. Children should not play with
the appliance.
6. Unplug from outlet when not in use, before putting on or taking o parts and before cleaning. Allow to
cool before putting on or taking o parts, and before cleaning. To disconnect, turn any control to OFF,
then unplug power cord from outlet. Do not disconnect by pulling on cord. Always grasp the plug and
pull to disconnect.
7. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has
been damaged in any manner. Do not attempt to replace or splice a damaged cord. Return appliance to
the manufacturer (see warranty) for examination, repair or adjustment.
8. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
9. Do not use outdoors or for commercial purposes.
10. Do not let cord hang over edge of table or counter, or touch hot surfaces.
11. Do not place on or near wet surfaces, or heat sources such as a hot gas or electric burner, or in a heated
oven.
12. Extreme caution must be used when moving an appliance or removing a pan, containing hot oil or other
hot liquids. Always protect your hands with non-slip oven mitts or similar.
13. Do not use appliance for other than intended use. Misuse can cause injuries. Intended for household
countertop use only. Keep 6 inches (152 mm) clear from the wall and on all sides. Always use appliance
on a dry, stable, level surface.
14. Oversize foods or metal utensils must not be inserted in the countertop oven as they may create a fire or
risk of electric shock.
15. A fire may occur if the countertop oven is covered, touching or near flammable materials, including
curtains, draperies, towels, walls, and the like, when in operation. Do not store any item on top of the
appliance when in operation.
16. Do not clean with metal scouring pads. Pieces can break o the pad and touch electrical parts, creating
a risk of electric shock.

4
17. Extreme caution should be exercised when using containers constructed of materials other than metal or
glass.
18. Do not store any materials, other than manufacturers recommended accessories, in this oven when not
in use.
19. Do not place any of the following materials in the oven: paper, cardboard, plastic, or any materials that
may catch fire or melt.
20. Do not cover crumb tray or any part of the oven with metal foil. This will cause overheating of the oven.
21. Empty the crumb tray after each use.
22. The glass door is made of tempered glass. Always inspect the glass door for chips, cracks or any other
damage. Do not use the countertop oven if the glass door is damaged, as the glass may shatter during
use.
23. If your toaster oven is equipped with a STAY-ON feature, toaster oven will stay ON if knob is turned
counter-clockwise past zero. Exercise caution when using this feature and do not operate unattended for
long periods.
24. Do not use with a programmer, timer, wireless plug adapter or outlet that allows control remotely, or
connect to a circuit that is regularly switched on and o by the utility.
SAVE THESE INSTRUCTIONS –
HOUSEHOLD USE ONLY

5
POWER CORD INSTRUCTIONS
A short power-supply cord or detachable power-supply cord is provided to reduce risks resulting
from becoming entangled in or tripping over a longer cord. Longer detachable power-supply cords or
extension cords are available and may be used if care is exercised in their use. If a long detachable
power-supply cord or extension cord is used:
• The marked electrical rating of the cord set or extension cord should be at least as great as the
electrical rating of the appliance;
• The cord should be arranged so that it will not drape over the countertop or tabletop where it can be
pulled on by children or tripped over unintentionally; and
• If the appliance is of the grounded type, the cord set or extension cord should be a grounding-type
3-wire cord. Do not pull, twist or otherwise abuse the power cord.
NOTICES
• Some countertop and table surfaces are not designed to withstand the prolonged heat generated by
certain appliances. Do not set the heated unit on a finished wood table. We recommend placing a hot
pad or trivet under your countertop oven to prevent possible damage to the surface.
• During initial use of this appliance, some slight smoke and/or odor may be detected. This is normal
with many heating appliances and will not recur after a few uses.
POLARIZED PLUG
This appliance has a polarized plug, (one blade is wider than the
other). As a safety feature to reduce the risk of electrical shock,
this plug is intended to fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature
or modify the plug in any way. If the plug fits loosely into the AC outlet or if the AC outlet
feels warm do not use that outlet.
POLARIZED PLUG

6
PRODUCT DIAGRAM
1. LCD Screen Display
2. Start, Turbo Convect, and Cancel/OFF Buttons
3. Function Selector Dial
4. Time/ Temperature Selector Button
5. Time/ Temperature Control Dial
6. Two Rack Positions
7. *Baking Pan
8. *Removable Wire Rack
9. *Removable Crumb Tray
*These parts can be replaced on Calphalon.com or at 1-800-809-7267
1
2
3
4
5
78 9
6

7
PREPARING YOUR COUNTERTOP OVEN
• Remove all packaging before using the Calphalon® Precision Control Countertop Oven.
• Wipe Countertop Oven with a damp cloth. DO NOT IMMERSE IN WATER. Make sure to only use mild,
soapy water. Abrasive cleaners, scrubbing brushes and chemical cleaners will damage the coating
on this unit. Dry the unit thoroughly before using.
NOTE: Do not immerse the cord, plug or body of the unit in water.
• Clean accessories. Remove them from packaging and immerse in warm, soapy water and wipe with
soft cloth or sponge. These accessories may also be washed in the top rack of the dishwasher. Dry
thoroughly.
• Select a location for the countertop oven. The location should be in an open area, on a dry, stable,
level surface where the plug will reach an outlet.
• Plug the Countertop Oven into the electrical outlet.
OVEN FUNCTIONS OVERVIEW
Function Rack Position Preheat Range
Toast Upper No Shade 1-7
1:35 mins. – 12:30 mins.
Bagel Upper No Shade 1-7
1:35 mins. - 11:00 mins.
Bake Lower Yes 150°F -450°F
Up to 1 hour
Roast Lower Yes 150°F -450°F
Up to 2 hours
Broil Upper No 350°F -450°F
Up to 2 hours
Pizza Upper Yes 150°F -450°F
Up to 1 hour
Reheat Upper/Lower No 150°F -450°F
Up to 1 hour
Defrost Upper/Lower Yes 150°F -450°F
Up to 1 hour

8
HOW TO USE YOUR COUNTERTOP OVEN
• Once the Calphalon® Precision Control Countertop Oven is plugged in, the START Button LED light
will flash. Set Temperature or Set Shade will flash on the screen, with a default time displayed.
• Turn the Function Selector Dial to one of the following 8 options: Toast (Default), Bagel Bake, Roast,
Broil, Pizza, Reheat, and Defrost.
• Once the desired function has been selected, use the Time/Temperature Control Dial to select the
desired cooking temperature or shade (for TOAST and BAGEL functions). Turn clockwise to increase
and counter-clockwise to decrease.
• Press the START button to begin preheating. PREHEATING will display on the LCD screen. Ensure the
Oven door is closed for preheating. Oven does not preheat for BAGEL and TOAST functions. For these
functions, food items may be placed inside the Oven immediately after pressing the START button.
• Once the Countertop Oven is preheated, it will beep and PREHEATING will disappear from the LCD
screen.
• You may set the timer before the oven begins preheating, during preheating, or once preheating is
complete. Press the Time/ Temperature Selector Button to change the Time/ Temperature Selector
Dial to time selection. Turn dial clockwise to increase cooking time and counter-clockwise to
decrease cooking time. The maximum time setting is 2 hours.
NOTE: TOAST and BAGEL functions automatically select time based on shade setting.
• Once preheating is complete and timer is set, put food into the Countertop Oven using the Wire
Rack or Baking Pan. When using the Baking Pan, always place it on top of the Wire Rack.
NOTE: Never place food or accessories directly on the Quartz Heating elements.
• Once food is inside, close the door and press the START button again. The Timer will begin counting
down.
• Press the Turbo Convect Button for better air circulation and crispier food if needed.
• Once the allotted time has expired, the Countertop Oven will beep, and it will stop heating, but the
display will remain lit for a period of time and then it will time out. You may press Cancel/OFF to
turn o the display before it times out.
• Use pot holders to carefully remove food from the Countertop Oven.
• The LCD screen light will turn o after 90 seconds of inactivity. Press any button to wake up the
appliance.
• Press the Cancel/OFF Button to turn o the Countertop Oven.

9
COOKING FUNCTIONS DETAILS
Toast
For best TOAST results, place wire rack in the upper rack position. This function is ideal for toasting
sliced bread, English muns, and frozen waes.
NOTE: For darker toast results, use a higher shade setting.
1. Insert the wire rack into the upper rack position.
2. Place food in the center of the wire rack for more even toasting.
3. Close the countertop oven door.
4. Turn the Function Selector Dial to select the TOAST function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired shade. Turn the Time/Temperature
Control Dial clockwise to increase shade selection and counter-clockwise to decrease.
5. Press the START button to begin toasting.
6. When toasting cycle is complete, an audible alert will sound.
7. Open countertop oven door fully and remove food carefully with oven mitt.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Bagel
For optimal results, place wire rack in the upper rack position.
1. Insert the wire rack into the upper rack position.
2. Place food in the center of the wire rack for more even cooking.
3. Close the countertop oven door.
4. Turn the Function Selector Dial to select the BAGEL function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired shade. Turn the Time/Temperature
Control Dial clockwise to increase shade selection and counter-clockwise to decrease.
5. Press the START button to begin the bagel cycle.
6. When bagel cycle is complete, an audible alert will sound.
7. Open countertop oven door fully and remove food carefully with oven mitt.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.

10
Bake
For optimal results, place wire rack in the lower rack position.
1. Insert the wire rack into the lower rack position. Note that certain baked goods call for upper rack
placement.
2. Ensure the countertop oven door is closed for preheating.
3. Turn the Function Selector Dial to select the BAKE function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
4. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.
5. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
6. Once preheating is complete, an audible alert will sound. The START button will flash.
7. Carefully place food in the center of the wire rack for more even cooking.
8. Close the countertop oven door.
9. Press the START button to begin the baking cycle.
Note: The timer will not begin until the START button is pressed.
10. When baking cycle is complete, an audible alert will sound.
11. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Roast
For optimal results, place wire rack in the lower rack position.
1. Insert the wire rack into the lower rack position.
2. Ensure the countertop oven door is closed for preheating.
3. Turn the Function Selector Dial to select the ROAST function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
4. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.
5. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
6. Once preheating is complete, an audible alert will sound. The START button will flash.
7. Carefully place food in the center of the wire rack for more even roasting.
8. Close the countertop oven door.

11
9. Press the START button to begin the roasting cycle.
Note: The timer will not begin until the START button is pressed.
10. When roasting cycle is complete, an audible alert will sound.
11. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Broil
For optimal results, place wire rack in the lower rack position.
1. Insert the wire rack into the lower rack position.
2. Ensure the countertop oven door is closed for preheating.
3. Turn the Function Selector Dial to select the BROIL function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
4. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.
5. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
6. Once preheating is complete, an audible alert will sound. The START button will flash.
7. Carefully place food in the center of the wire rack for more even roasting.
8. Close the countertop oven door.
9. Press the START button to begin the broiling cycle.
Note: The timer will not begin until the START button is pressed.
10. When BROILING cycle is complete, an audible alert will sound.
11. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.

12
Pizza
For optimal results, place wire rack in the lower rack position.
1. Insert the wire rack into the lower rack position.
2. Ensure the countertop oven door is closed for preheating.
3. Turn the Function Selector Dial to select the PIZZA function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
4. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.
5. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
6. Once preheating is complete, an audible alert will sound. The START button will flash.
7. Carefully place pizza on the pizza pan and place in the center of the wire rack for more even
cooking.
8. Close the countertop oven door.
9. Press the START button to begin the pizza cycle.
Note: The timer will not begin until the START button is pressed.
10. When pizza cycle is complete, an audible alert will sound.
11. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Reheat
For optimal results, place wire rack in the desired rack position.
1. Insert the wire rack in desired rack position.
2. Place food on an oven-safe accessory. Then, carefully place accessory in the center of the wire rack
for even heating.
3. Close countertop oven door.
4. Turn the Function Selector Dial to select the REHEAT function. Once the function has been selected,
use the Time/Temperature Control Dial to select the desired cooking temperature and time. Turn the
Time/Temperature Control Dial clockwise to increase temperature and time and counter-clockwise
to decrease.
5. Press the TURBO CONVECT button for better air circulation and crispier food if needed. The turbo
convection fan will appear on the LCD screen to indicate that Turbo Convection is on. To cancel
convection setting, press the TURBO CONVECT button once more.

13
6. Press the START button to begin the reheat cycle.
Note: The timer will not begin until the START button is pressed.
7. When reheat cycle is complete, an audible alert will sound.
8. Open countertop oven door fully and remove food carefully. We recommend using oven mitts or pot
holders when removing food from the countertop oven.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.
Defrost
For optimal results, place wire rack in the upper rack position.
1. Insert the wire rack into the upper rack position.
2. Ensure the countertop oven door is closed for preheating.
3. Turn the Function Selector Dial to select the DEFROST function. Once the function has been
selected, use the Time/Temperature Control Dial to select the desired cooking temperature and
time. Turn the Time/Temperature Control Dial clockwise to increase temperature and time and
counter-clockwise to decrease.
4. Press the START button to begin preheating. PREHEATING will appear on the LCD screen.
5. Once preheating is complete, an audible alert will sound. The START button will flash.
6. Carefully place food in the center of the wire rack.
7. Close the countertop oven door.
8. Press the START button to begin the defrost cycle.
Note: The timer will not begin until the START button is pressed.
9. When defrost cycle is complete, an audible alert will sound.
10. Open countertop oven door fully and remove food carefully. If food requires more time to defrost,
place it back inside the countertop oven and repeat steps 3, 4, 7 & 8. If food is suciently
defrosted, place it back into the oven and choose the appropriate Cooking Function and Cooking
Time to complete food preparation.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop oven unattended.

14
CLEANING & MAINTENANCE
• Clean oven and any accessory after each use.
• Before cleaning your Calphalon® Precision Control Countertop Oven, press the CANCEL/OFF button
to turn OFF the countertop oven. Unplug the cord and allow it to cool before cleaning.
• To clean exterior of oven, wipe with a damp cloth. DO NOT IMMERSE IN WATER. Make sure to only
use mild, soapy water. Abrasive cleaners, scrubbing brushes and chemical cleaners will damage
the coating on this unit.
• To clean Wire Rack or Baking Pan remove from the Oven and immerse in warm, soapy water and
wipe with soft cloth or sponge. These accessories may also be washed in the top rack of the
dishwasher. Dry thoroughly.
• Remove the Removable Crumb Tray and shake o crumbs. Wash with soapy water, and dry
thoroughly. Cleaning the Crumb Tray often will avoid any accumulations.
• This appliance has no user serviceable parts. Any servicing beyond that described in the Cleaning
Section should be performed by an Authorized Service Representative only. See Warranty Section.

15
TROUBLESHOOTING
Possible Problem Easy Solution
Oven does not turn ON • Plug the Countertop into the electrical outlet.
• Check that the power plug is securely inserted into the outlet.
• Insert the power plug into a dierent outlet.
• Press the START button.
Smoke odor • During initial use of this appliance, some slight smoke and/or odor
may be detected. This is normal with many heating appliances and
will not recur after a few uses.
Heating elements do not
stay ON
• Be certain that function is as desired. Heating elements will cycle ON
and OFF to maintain proper heat.
Overcooked/
undercooked foods
• You may have to adjust the time and temperature to desired taste.
• Because your countertop oven is smaller than your regular oven, it
will heat up faster and generally cook in shorter periods of time.
• Rack may need to be adjusted to accommodate food type.
Burnt smell • Refer to “Cleaning & Maintenance.” Food build-up inside the
countertop oven, on heating elements, in crumb tray can sometimes
cause burnt smell.
LCD display turns OFF • Press any button to wake up the appliance. The LCD screen light turns
o after 90 seconds of inactivity.

16
WARRANTY
1 YEAR LIMITED WARRANTY
Calphalon (“Calphalon”) warrants that for a period of one year from the date of purchase, this product
will be free from defects in material and workmanship. Calphalon, at its option, will repair or replace
this product or any component of the product found to be defective during the guarantee period.
Replacement will be made with a new or remanufactured product or component. If the product is no
longer available, replacement may be made with a similar product of equal or greater value. This is
your exclusive guarantee. Do NOT attempt to repair or adjust any electrical or mechanical functions on
this product. Doing so will void this guarantee. This guarantee is valid for the original retail purchaser
from the date of initial retail purchase and is not transferable. Keep the original sales receipt. Proof of
purchase is required to obtain satisfaction guarantee performance. Calphalon dealers, service centers,
or retail stores selling Calphalon, do not have the right to alter, modify or any way change the terms
and conditions of this guarantee. This guarantee does not cover damage resulting from any of the
following: negligent use or misuse of the product, use on improper voltage or current, use contrary
to the operating instructions, disassembly, repair or alteration by anyone other than Calphalon or an
authorized Calphalon service center. Further, the guarantee does not cover: Acts of God, such as fire,
flood, hurricanes and tornadoes.
What are the limits on Calphalon’s Liability? Calphalon shall not be liable for any incidental or
consequential damages caused by the breach of any express, implied or statutory guarantee or
condition. Except to the extent prohibited by applicable law, any implied guarantee or condition of
merchantability or fitness for a particular purpose is limited in duration to the duration of the above
guarantee. Calphalon disclaims all other guarantees, conditions or representations, express, implied,
statutory or otherwise. Calphalon shall not be liable for any damages of any kind resulting from the
purchase, use or misuse of, or inability to use the product including incidental, special, consequential
or similar damages or loss of profits, or for any breach of contract, fundamental or otherwise, or for
any claim brought against purchaser by any other party. Some provinces, states or jurisdictions do not
allow the exclusion or limitation of incidental or consequential damages or limitations on how long
an implied guarantee lasts, so the above limitations or exclusion may not apply to you. This guarantee
gives you specific legal rights, and you may also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction
If you have any questions regarding the limited warranty, please call 1-800-809-7267.
