Calypso Davis Compatible User manual

c a l y p s o i n s t r u m e n t s . c o m
Davis Compatible
Ultrasonic wind sensor
User manual
English version 1.0
18.03.2021
0809
If you want to know more about our new Davis Compatible Ultrasonic wind sensor, please keep reading
or visit our website www.calypsoinstruments.com

0. Index 1. Product overview 3. Technical specifications
0. Product overview
1. Package content
2. Technical specifications
Dimensions wind sensor
Weight wind sensor
Dimensions box
Mechanical data
Power
Attached cable
Connections
Internal connections
Sensors
Wind information
Easy mount
Limitations
Quality control
3. Installation
Battery placement
Wind sensor and box connection
Console configuration
4. General information
General recommendations
Maintenance and repair
Warranty
Thank you for choosing the Davis Compatible
Ultrasonic wind sensor from Calypso Instruments.
· Both shape and firmware have been enhanced
for an improved rain performance, being this
point key for static applications such as weather
stations.
· Mechanical design has been revamped making
the unit more robust and dependable.
· Powered by two lithium batteries, with a duration
of 3 years.
Applications for the Davis Compatible Ultrasonic
are the following:
Weather Stations | Air Quality
Gardening | Agriculture
2. Package content
The package contains the following:
· Ultrasonic Wired Wind Instrument connected to
the Box with a 12m cable + cable 50cm to
connect to Davis Station.
· Two lithium batteries.
· Serial number reference in the back of the
packaging.
· Quality control reference in the same place as
the previous one.
(Both shown in the Image 1)
· User Quick guide at the back of the packaging
and some more information useful for the
customer.
· Connection instructions picture including at the
box package.
· M4 headless screw (x6)
· M4 screw (x3)
Davis Compatible Ultrasonic wind sensor is made up
of the wind sensor and the Davis compatible box.
Image 2. Main dimensions of the wind sensor.
N o t h m a rk p o s i t i o n
Make sure the north mark
is perfectly aligned.
Image 3. Davis compatible box.
M4x0,5
Q u a l i t y c on t r o l p a ss e d
MAC address /serial
Image 1. Serial number/Control quality label
Davis Compatible
User manual
Image 4. North Mark
Davis Compatible
User manual
Image 5. Screw Holes positon.
3.3 BOX
Dimensions
· 127 x 70 x 38 mm
3.2 Wind sensor
Weight
· Weight: 210 grams
3.1 Wind sensor
Dimensions
· Diameter: 68 mm
· Height: 65mm
3.5 Mechanical data

Mounting accessories
Yellow
DATA Rx
Brown
VCC (Power +)
3. Technical specifications
(continuation)
The Davis compatible ultrasonic wind sensor
incorporates 12m of cable between the wind sensor
and the box.
50cm of cable terminated in RJ-11 comes out of the
box.
The wind sensor has been designed to avoid any
mechanical parts to maximize reliability and
minimize maintenance.
The transducers communicate between themselves
two by two using ultrasonic range waves. Each
couple of transductors calculates the signal delay
and gets information about both, wind direction and
wind speed.
The wind sensor has lateral and inferior female thread. It can be mounted either on a plate (inferior
screws) or on a tube (lateral screws).
North mark position
Make sure the north mark is perfectly aligned
M4x0,5 M4x0,5
Inside the box there are two connectors, one where
is connected the wind sensor and other where is
connected the cable for the Davis Station.
Pole mount up to 52 mm
Image 6. Wire connections.
Davis compatible unit connections:
Aluminio and Carbon Fiber poles
Wind sensor connections:
The box can be attached to the pole with cable ties or similar.
Davis Compatible
User manual
Davis Compatible
User manual
White
GND (Power -)
Green
DATA Tx
3.11 Wind · Speed Range: 0-40 m/s
information · Direction Range: 0-360 º
3.8 Connections · Modular Connector (RJ-11)
3.7 Attached cable
3.12 Easy mount
- 3 x M4 lateral female thread
- 3 x M4 inferior female thread
3.10 Sensors · Ultrasonic transducter (4x)
· 2xAA, 3.6V Lithium primary
batteries (duration 6 years)
3.6 Power
Adapter to Poles up to 39mm
Flat mount
Yellow
VCC (Power +)
Green
WIND Direction
Red
GND (Power -)
Black
WIND Speed
3.9 Internal Connections

3.13 Limitations
3.14 Quality control
4.1 Battery placement
4.3 Console configuration
3. Technical specifications
(continuation)
Wind sensor is engineered to be a robust device
with minimal downtime. This new shape has been
designed for optimum water spillage which implies
lower probability of ice formation. Frost might
affect measurements if it blocks the wave path.
The box has IP68 rating (outdoors & underwater).
The input wires are protected by Transient Voltage
Suppression (TVS) diodes. Also, the instrument
body is built in Polyamide.
Every single unit is automatically calibrated on a
wind tunnel. A Q/C report for both module and
angle is generated and kept in our files. Standard
deviation is checked to warranty that each unit has
been calibrated to the highest standards.
4. Installation
The installation of Davis Compatible Ultrasonic
wind sensor is very easy.
When you receive the Davis compatible ultrasonic
wind sensor, you have to put the included batteries
inside the box.
Remove the screws to open the box and insert them
in the battery holder in the correct position, after
that close the box with the screws.
Image 7. Battery placement.
2. Press DONE repeatedly to scroll through the
screens until you come to the Wind Cup Size
screen.
3. Press the + and - keys to toggle the sizes until
OTHER appears.
4. Press and hold the DONE key to exit Setup
Mode and return to the Current Weather Screen.
Image 9. Davis Console.
Once you have mounted the wind sensor and box
in a suitable location, insert the RJ-11 end into the
cable access port of the ‘Sensor Interface’ and
firmly insert the RJ connector into the socket labeled
WIND.
Image 8. Connection to Sensor Interface.
To configure the console:
1. Enter the Setup Mode by pressing DONE and
the –key at the same time.
Davis Compatible
User manual
Davis Compatible
User manual
4.2 Wind sensor and box connection
-
+

ULTRASONIC ULP 485
5. General information
5.1 General recommendations
As described previously is important to understand
that the unit can be mounted directly on a pole or
using a flat bracket. In either case make sure the
north mark is perfectly aligned.
Then install the sensor in a location free from wind
perturbation.
Other important aspects
· Do not try to modify by any case the unit.
· Avoid touching the transducers
· Do not modify/customizethe surfaceof the unit.
If you have any questions or doubts, please contact
directly with us. We will be glad to assist you in
any time.
5.2 Maintenance and repair
Thanks to the mechanical simplicity the ultrasonic
does not require mechanical maintenance.
Transducers must be kept clean and aligned.
Impacts or incorrect impulsive handling may lead to
transducers misalignment.
The space in between the transducers and its
reflection surface must be empty and clean. Dust,
frost, water, etc… will make the unit stop
working. Rinse with fresh water and let it dry.
The batteries have a duration of about three years,
after this time they must be replaced.
5.3 Warranty
Warranty is void in case of non-following the
instruct ions of use, repair or maintenance without
written authorization. Every Calypso product offers
a 2-Year Performance Warranty.
Calypso Instruments shall not be liable for any
damages arising out of:
- Exposition of the Ultrasonic at temperatures out of
the range stated above.
- Transducers misalignment or damage duet to
external impact.
- Geometry changes on the flow channel due to
external actions.
- Use inappropriate voltages.
- Do not install the Davis compatible ultrasonic wind
sensor as stated above which causes damage on
the ultrasonic.
You can return unopened items in the original
packaging within 30 days of your purchase with
proof of purchase. Upon receipt of the returned
item, we will fully examine it and notify you via
email, within a reasonable period of time on the
status. If we decide a return is appropriate, we will
refund your purchase price and a credit will be
applied to your original method of payment.
For further information please contact Calypso
Technical Support through
[e-mail]
or visit www.calypsoinstruments.com
Calypso Instruments team thanks you for your
confidence.
