CAMBRIDGE Topaz SR20 User manual

CXR120/200
AV RECEIVER

2
Contents
Make sure you register your purchase.
Visit: www.cambridgeaudio.com/vip
By registering, you'll be the rst to know about:
•Future product releases
•Software upgrades
• News, events and exclusive oers plus
competitions!
This guide is designed to make installing and using this product
as easy as possible. Information in this document has been
carefully checked for accuracy at the time of printing; however,
Cambridge Audio’s policy is one of continuous improvement,
therefore design and specications are subject to change without
prior notice.
© Copyright Cambridge Audio Ltd 2016.
For DTS patents, see http://patents.dts.com. Manufactured under
license from DTS Licensing Limited. DTS, DTS-HD, the Symbol,
& DTS and the Symbol together are registered trademarks, and
DTS-HD Master Audio is a trademark of DTS, Inc. © DTS, Inc. All
Rights Reserved.
Manufactured under license from Dolby Laboratories. Dolby,
Pro Logic, and the double-D symbol are trademarks of Dolby
Laboratories.
"HDMI","HDMI logo" and "High-Denition Multimedia Interface"
are trademarks or registered trademarks of HDMI Licensing LLC.
The Spotify software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses.
Important safety instructions .................................................................. 3
Limited warranty...................................................................................... 4
Front panel controls ................................................................................ 5
Rear panel connections........................................................................... 5
Main remote control ................................................................................ 6
Loudspeaker connections....................................................................... 7
Analogue audio connections................................................................... 7
Digital audio connections........................................................................ 8
5.1/7.1 direct in ....................................................................................... 8
HDMI connections................................................................................... 9
4K video resolution.................................................................................. 9
Aerial connections................................................................................. 10
Using the tuner...................................................................................... 10
Presets .................................................................................................. 10
StreamMagic ...................................................................................... 10
Operating instructions........................................................................... 10
Selecting the source........................................................................... 10
Selecting the desired listening mode ................................................. 10
Surround sound modes......................................................................... 10
DSP modes ........................................................................................... 11
Stereo/Stereo + Sub........................................................................... 11
Direct .................................................................................................. 11
All channels ........................................................................................ 11
Setup menu ........................................................................................... 12
Speaker setup .................................................................................... 12
Speaker conguration ........................................................................ 12
Auto Setup ......................................................................................... 12
Manual Setup ........................................................................................ 13
Input Setup............................................................................................ 13
Lip sync .............................................................................................. 14
Zone 2 (CXR200 only)............................................................................ 14
Network Setup....................................................................................... 14
Connecting to a wired network .......................................................... 14
Network Setup.................................................................................... 14
Wireless Setup ................................................................................... 14
General Settings.................................................................................... 15
HDMI Output Setup............................................................................... 15
DTS-HD speaker re-map.................................................................... 16
Trigger outputs ................................................................................... 16
SW Version ......................................................................................... 16
Update Via USB ................................................................................. 16
Save Current Settings ........................................................................ 16
Load Current Settings ........................................................................ 16
Factory Reset ..................................................................................... 16
Network software update...................................................................... 16
Web administration interface.............................................................. 16
Wired connection ............................................................................... 16
Wireless connection ........................................................................... 16
The process of setting up the CXR is rst to make all the connections to your
speakers and source equipment and then set the unit up via its On-Screen
Display (OSD). There are various settings and adjustments that need to be
made before the CXR can be used.
However before you actually decide which connections to make or perform
any adjustments it is strongly advised that you read through the 'Setup menu'
section of this manual rst, starting on page 12.
For more detailed information, please visit our website
www.cambridgeaudio.com for the product reference
manual and FAQ.
Before connecting

3
CXR120/200
For your own safety please read the following important safety instructions
carefully before attempting to connect this unit to the mains power supply.
They will also enable you to get the best performance from and prolong the
life of the unit:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding-type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for replacement
of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at
plugs, convenience receptacles and the point where they exit from the
apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long
periods of time.
13. Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as the power-
supply cord or plug having been damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has been dropped.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE AND OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED ON
THIS APPARATUS.
Batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, re or the like.
TO COMPLETELY DISCONNECT THIS APPARATUS FROM THE AC
MAINS, DISCONNECT THE POWER SUPPLY CORD PLUG FROM THE AC
RECEPTACLE. POUR DECONNECTER COMPLETEMENT L’APPAREIL DU
RESEAU D’ALIMENTATION, DECONNECTER LE CORDON D’ALIMENTATION
DE LA PRISE MURALE.
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN
READILY ACCESSIBLE. LA PRISE DU RESEAU D’ALIMENTATION DOIT
DEMEURER AISEMENT ACCESSIBLE”
Only use the mains cord supplied with this unit.
Important safety instructions
The lightning ash with the arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of un-insulated ‘dangerous
voltage’ within the product’s enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance instructions in
the service literature relevant to this appliance.
The symbol on this product indicates that it is of CLASS II (double
insulated) construction.
WEEE symbol
The crossed-out wheeled bin is the European Union symbol
for indicating separate collection for electrical and electronic
equipment. This product contains electrical and electronic
equipment which should be reused, recycled or recovered and
should not be disposed of with unsorted regular waste. Please
return the unit or contact the authorised dealer from whom you purchased
this product for more information.
CE mark
This product complies with European Low Voltage (2014/35/
EU), Electromagnetic Compatibility (2014/30/EU) and
Environmentally-friendly design of Energy-related Products (2009/125/EC)
Directives when used and installed according to this instruction manual.
For continued compliance only Cambridge Audio accessories should be
used with this product and servicing must be referred to qualied service
personnel.
RCM (Regulatory Compliance Mark)
This product meets the Safety, EMC and Radio Communications
requirements of the ERAC and ACMA.
CU-TR Mark
This product meets Russia, Byelorussia and Kazakhstan electronic
safety approvals.
Caution: Hot Surface. Do Not Touch
The top surface over the internal heat sink may become hot when
operating this product continuously. Do not touch hot areas,
especially around the "Hot surface mark" and the top panel.
FCC regulations
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO
OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS
TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER
AUTHORITY TO OPERATE THE EQUIPMENT.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
- Re-orient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.

4
Cambridge Audio warrants this product to be free from defects in materials
and workmanship (subject to the terms set forth below). Cambridge Audio will
repair or replace (at Cambridge Audio's option) this product or any defective
parts in this product. Warranty periods may vary from country to country. If
in doubt consult your dealer and ensure that you retain proof of purchase.
To obtain warranty service, please contact the Cambridge Audio authorised
dealer from which you purchased this product. If your dealer is not equipped
to perform the repair of your Cambridge Audio product, it can be returned by
your dealer to Cambridge Audio or an authorised Cambridge Audio service
agent. You will need to ship this product in either its original packaging or
packaging aording an equal degree of protection.
Proof of purchase in the form of a bill of sale or receipted invoice, which is
evidence that this product is within the warranty period, must be presented
to obtain warranty service.
This Warranty is invalid if (a) the factory-applied serial number has been
altered or removed from this product or (b) this product was not purchased
from a Cambridge Audio authorised dealer. You may call Cambridge Audio
or your local country Cambridge Audio distributor to conrm that you have
an unaltered serial number and/or you purchased from a Cambridge Audio
authorised dealer.
This Warranty does not cover cosmetic damage or damage due to acts of
God, accident, misuse, abuse, negligence, commercial use, or modication
of, or to any part of, the product. This Warranty does not cover damage
due to improper operation, maintenance or installation, or attempted repair
by anyone other than Cambridge Audio or a Cambridge Audio dealer, or
authorised service agent which is authorised to do Cambridge Audio warranty
work. Any unauthorised repairs will void this Warranty. This Warranty does not
cover products sold AS IS or WITH ALL FAULTS.
REPAIRS OR REPLACEMENTS AS PROVIDED UNDER THIS WARRANTY
ARE THE EXCLUSIVE REMEDY OF THE CONSUMER. CAMBRIDGE AUDIO
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY IN
THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY LAW, THIS
WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND
IMPLIED WARRANTIES WHATSOEVER INCLUDING, BUT NOT LIMITED TO,
THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PRACTICAL
PURPOSE.
Some countries and US states do not allow the exclusion or limitation of
incidental or consequential damages or implied warranties so the above
exclusions may not apply to you. This Warranty gives you specic legal rights,
and you may have other statutory rights, which vary from state to state or
country to country.
For any service, in or out of warranty, please contact your dealer.
Limited warranty
Ventilation
IMPORTANT – The unit will become hot when in use. Do not stack multiple
units on top of each other. Do not place in an enclosed area such as a
bookcase or in a cabinet without sucient ventilation.
Ensure that small objects do not fall through any ventilation grille. If this
happens, switch o immediately, disconnect from the mains supply and
contact your dealer for advice.
Please ensure there is ample ventilation (at least 20cm clearance on the top,
side and rear). Do not put any objects on top of this unit. Do not situate it on a
rug or other soft surface and do not obstruct any air inlets or outlet grilles. Do
not cover the ventilation grilles with items such as newspapers, tablecloths,
curtains, etc.
Positioning
Choose the installation location carefully. Avoid placing it in direct sunlight or
close to a source of heat. No naked ame sources, such as lighted candles,
should be placed on the unit. Also avoid locations subject to vibration and
excessive dust, cold or moisture. The unit can be used in a moderate climate.
This unit must be installed on a sturdy, level surface. Do not place in a sealed
area such as a bookcase or in a cabinet. Any space open at the back (such
as a dedicated equipment rack) is ne, however. Do not place the unit on an
unstable surface or shelf. The unit may fall, causing serious injury to a child or
adult as well as serious damage to the product. Do not place other equipment
on top of the unit.
Due to stray magnetic elds, turntables or CRT TVs should not be located
nearby due to possible interference.
Electronic audio components have a running in period of around a week (if
used several hours per day). This will allow the new components to settle
down and the sonic properties will improve over this time.
Power sources
The unit should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power-supply to your
home, consult your product dealer or local power company.
This unit can be left in Standby mode when not in use and will draw <0.5W in
this state. To turn the unit o, switch o at the rear panel. If you do not intend
to use this unit for a long period of time, unplug it from the mains socket.
Overloading
Do not overload wall outlets or extension cords as this can result in a risk of
re or electric shock. Overloaded AC outlets, extension cords, frayed power
cords, damaged or cracked wire insulation and broken plugs are dangerous.
They may result in a shock or re hazard.
Be sure to insert each power cord securely. To prevent hum and noise, do not
bundle the interconnect leads with the power cord or speaker leads.
Cleaning
To clean the unit, wipe its case with a dry, lint-free cloth. Do not use any
cleaning uids containing alcohol, ammonia or abrasives. Do not spray an
aerosol at or near the unit.
Battery disposal
Batteries may contain substances harmful to the environment. Please dispose
of any discharged batteries with due consideration and in accordance with
local environmental/electronic recycling guidelines.
Loudspeakers
Before making any connections to loudspeakers, make sure all power is
turned o and only use suitable cables.
Servicing
These units are not user serviceable. Never attempt to repair, disassemble or
reconstruct the unit if there seems to be a problem. A serious electric shock
could result if this precautionary measure is ignored. In the event of a problem
or failure, please contact your dealer.

5
CXR120/200
ENGLISH
Front panel controls
1. Standby/On
2. Phones
For suitable headphones – connection
will mute the main zone speakers.
3. Tuning +/-
Used to tune FM/AM frequencies and
presets for the built-in Tuner.
4. Direct
Disables any audio processing on the
current source.
5. Zone (CXR200 only)
Press this button followed by
Standby/On or Source +/- to change
Zone 2. When illuminated, indicates
that Zone 2 is On.
6. Display
Status window.
7. Source +/-
Also used for character entry. +/-
button to move between character
entry.
8. Menu
9. Back
In the Setup menu, press to return to
the previous item.
10. USB / MP3 / HDMI/
MHL Inputs
USB - For playback of audio on USB
Media from USB Flash-disks or USB
hard-drives.
MP3 ( ) – For connection to a
portable audio device.
HDMI 8/MHL – For connection to a
HDMI source or MHL compatible
device.
11. Volume
Volume and 'select' button. Also used
for character entry. Rotate to browse
through the characters.
CX R200
HDMI 8/ MHL
1
2
3
8
9
10
11
4
57
6
1. FM / AM aerials
2. Analogue inputs
(CXR120 3 inputs only)
3. 7.1 Direct in
4. Pre out / Sub out
5. Rec out
6. Zone 2 out (CXR200 only)
7. HDMI 2.0 compatible
inputs
8. Vent grille
DO NOT OBSTRUCT!
9. Digital in
(CXR120 2 optical only)
10. Zone 2 speaker
outputs (CXR200 only)
11. Bi-amp speaker
terminals (CXR200 only)
12. Ethernet
13. HDMI 2.0 outputs
CXR120 – Outputs mirrored.
CXR200 – Output 2 can display a
dierent source in Zone 2.
14. USB
For connection to the supplied wi
antenna or optional BT100 Bluetooth
audio receiver.
15. Speaker terminals
16. IR receiver In
17. Emitter in
18. IR out
19. Trigger out
20. AC power socket
21. RS232C
Custom install control - a full protocol
is available for the CXR on our
website.
22. Power on/o
Rear panel connections
1
4
10 11
3
2 5 6
7
9
22
20
8
15
13
12 14
17 18 21
16 19
