Caminetti Montegrappa TECH 3 Quick start guide

DIRECTIONS FOR INSTALLATION
USE AND MAINTENANCE
EN
TECH 3
CLOSED FIREPLACES
WITH A SYSTEM OF NATURAL CONVECTION
THESE INSTRUCTIONS ARE INTEGRAL PART OF THE PRODUCT
PLEASE READ CAREFULLY AND SAVE FOR FUTURE REFERENCE
Serial number
UET 0920100550_04 010618 Copy translated from the original



Foreword

Congratulations on your purchase of a Caminetti
Montegrappa product, one of the best available on the
market!
●
Before installing and operating your appliance, read this
instruction manual carefully and save it for future reference.
●
All installation, water and electrical connection, inspection,
maintenance and repair work must be performed by
authorized and qualified technicians only.
●
It is recommended that the first-time lighting of your
appliance should be done by the appliance installer who
may check and ensure proper appliance operation and
draught.
●
The technician must present a certificate verifying proper
installation.
●
This appliance is not suitable for people (children included)
with reduced physical, sensorial and mental capacities, or
unpractised people, unless they are supervised and trained
to use the appliance by someone who is responsible for
their safety.
●
Never let your appliance unattended in the presence of
children. Do no let the children touch any hot surface areas
of the appliance nor let them operate it.
●
For any further information or requests always contact an
authorized dealer who will be pleased to assist you.
●

Symbols used in this manual

In the present instruction manual some indications are pointed
out by the following symbols:
Safety precautions.
Prohibited operation.
Important information.
Caminetti Montegrappa assumes no responsibility for any
incidental or consequential damage to people, things or pets
resulting from the inobservance of the prescriptions given in
this manual, particularly of those marked with following
symbols.

ENGLISH
TECH 3 3

SUMMARY 4
1 GENERAL INFORMATION 4
1.1 Warranty 4
1.1.1 Warranty conditions 4
1.1.2 CE label and product serial number 5
1.1.3 Remarks on materials 5
1.1.4 null 6
1.2 Certifications and patents 7
1.2.1 CE marking information 7
1.2.2 Further certifications and patents 8
1.3 Technical dimensions and features 9
1.3.1 Technical drawings 9
1.3.2 Technical features 10
1.4 Firewood 11
1.4.1 Characteristics of firewood 11
1.4.2 Preparing firewood 12
1.4.3 Purchasing firewood 12
1.4.4 Combustion 13
1.5 Recommendations 14
1.5.1 Safety precautions 14
1.5.2 General recommendations 14
1.5.3 Warnings for correct appliance disposal 15
1.6 Safety requirements and devices 16
1.7 Environment requirements 16
1.8 Equipment 17
1.8.1 Checking of the accessories included 17
1.8.2 Natural air convection channelling kit 18
1.8.3 Forced air convection channelling kit 19
1.8.4 Primary air channelling kit 20
1.9 Functioning principle 21
2 INSTALLATION 22
2.1 Packaging dismantling and disposal 22
2.2 Installation requirements 22
2.3 Appliance installation 22
2.3.1 Making appliance lighter in order to facilitate handling 22
2.3.2 Vertical sliding door check 23
2.3.3 Appliance Positioning 23
2.3.4 Force convection pre-arrangement 24
2.3.5 Outside air intakes 25
2.3.6 Connection to the chimney flue 26
2.3.7 Chimney flue 26
2.3.8 Chimney cap 27
2.3.9 Insulation 28
2.3.10 Electrical connection 29
2.3.11 Cladding Installation 30
ENGLISH
TECH 3

2.3.12 Finishing mantle 30
2.3.13 Warm air distribution 31
3 OPERATION 33
3.1 Pre- and first-lighting instructions 33
3.2 Following lightings 33
3.3 Combustion control and operation 35
3.4 Radio control 36
3.4.1 Description and use 36
3.4.2 Configuration 37
3.4.3 Battery replacement 38
4 CARE AND MAINTENANCE 39
4.1 Recurrent maintenance 39
4.1.1 Cleaning of metal parts 39
4.1.2 Cleaning of ceramic glass 39
4.1.3 Hearth cleaning 40
4.2 Routine maintenance 41
4.2.1 General cleaning 41
4.2.2 Gasket control 42
4.2.3 Cleaning of chimney flue 42
4.3 Failures/ Causes / Trouble-shooting 43
5 FOR THE AUTHORIZED SERVICE TECHNICIAN 44
5.1 Wiring-diagram 44
5.2 Servicing record 45
ENGLISH
TECH 3

1 GENERAL INFORMATION

1.1 Warranty

1.1.1 Warranty conditions
1. Caminetti Montegrappa s.p.a. acknowledges and adopts the "guarantee of conformity with the contract" of Directive
1999/44/CE.
2. As to benefit from the guarantee in compliance with the provisions of national law adopted in order to comply with Directive
1999/44/CE, the consumer shall refer to his dealer only (the seller).



ENGLISH
TECH 3 4

●
●
●
●
1.1.2 CE label and product serial number

1.1.3 Remarks on materials
The components below are subject to common wear and tear (corrosion or progressive decay) that cannot constitute grounds for
objection due to the type and features of the materials used in the construction of the parts and due to the product operational
conditions.
The internal movable or fix parts in steel or cast iron: are made of high temperature resistant materials but could distort and
settle if using the wrong fuel or exceeding the fuel amount suggested in this manual. However they can eventually present
rusty or oxidized parts.

Electric and electronic components: are all tried in place when assembling the product. The use over a long period of time of
an unsuitable fuel, or of an amount of fuel exceeding that indicated in this manual may cause overheating of the above
components, which may result in a higher sound level of the fan or breakage of the temperature sensor and the electronic
control.

Gaskets: are necessary to make the firebox airtight and to hold the ceramic glass panel in place; their distortion absorbency
and elasticity will be guaranteed only by following the instructions under section 4.1.2 regarding the ceramic glass cleaning;
mind that if the glass detergent trickles down the glass, the gaskets could harden letting the glass panel loose.

Misuse of the following components could result in their breakage.

The ceramic glass panels: are thoroughly factory-checked. Please note that with the techniques currently available, the
manufacturing of glass ceramic panels totally free from any kind of defects cannot be guaranteed and therefore any
The serial number (an alphanumeric code) is printed on the
cover of the appliance "installation, use and maintenance"
manual. It is highly recommended that the serial number be
quoted for any request.
This number is also printed at the bottom of the CE label
located on the cover plate of the air intake compartment of the
air to be heated (under the fireplace hearth).

Example of CE label with serial number
The materials used to manufacture this product have been thoroughly checked and are guaranteed to be free from
defects.
ENGLISH
TECH 3 5

●
irregularities that might be noticed have to be considered within the specifications of this material and are not prejudicial to its
strength nor to the correct functioning of the firebox. Note: Please refer to section 4.1.2 for directions on cleaning.

CMtech®: is an exclusive mixture of refractory materials and is designed to withstand very high temperatures and thermal
shocks. Such a high performance is made possible thanks to the thickness and physical structure of the CMtech® material,
which may only become damaged in very exceptional cases (cracks and/or erosion) if subjected to high impact stress. It is
therefore highly recommended to load the wood logs into the combustion chamber with the utmost care, leaning the logs
instead of throwing them against the walls in CMtech®. The same care must be used while handling the CMtech® parts during
the maintenance works. Also note that any fissures and crackles on the CMtech® lining surface do not negatively affect the
efficiency of the material and are not prejudicial to the performance and correct functioning of the appliance.



Ceramic glass thermal shock resistance 750°C. It is important not to light the fire close to the glass to avoid its
damage (white residue) in the long run.
ENGLISH
TECH 3 6

1.2 Certifications and patents

1.2.1 CE marking information

ENGLISH
TECH 3 7

●
●
●
●
1.2.2 Further certifications and patents
We declare that the appliance
TECH 3

complies with legislative provisions that implement the following directives and regulations:
Directive 2011/65/EU (RoHS Directive on the restriction of the use of certain hazardous substances in electrical and
electronic equipment).
Directive 2014/30/EU (EMCD Electromagnetic Compatibility) and subsequent amendments.
Directive 2014/35/EU (LVD Low Voltage) and subsequent amendments.
Regulation (UE) 305/2011 (Building Products).
CMtech®
CMtech® is a material resulting from research activities of Caminetti Montegrappa to obtain the best performance from your
appliance; it is a refractory mix of material that withstands very high temperatures and thermal shocks and can absorb and store
heat, radiating it for hours after the fire has gone out. The material turns a light colour at the working temperature, giving the
hearth a clean and pleasant appearance.

meets the requirements of the
15a B-VG
(strict Austrian local regulation)

is type-approved in Switzerland by VKF

The Declaration of Performance and the Declaration of Conformity CE can be downloaded from our website
www.caminettimontegrappa.it.
ENGLISH
TECH 3 8

1.3 Technical dimensions and features

1.3.1 Technical drawings

TECH 3

ENGLISH
TECH 3 9

1.3.2 Technical features

Readings in accordance with standard
EN 13229:2001 + A2:2004 + AC:2006 Tech 3
CN = appliance with natural convection CN
max. Output - min. Output 16,9 - 8,4 kW
Thermal Output nominal 13,0 kW
CO emission at 13% oxygen ≤ 0,10 %
efficiency ≥ 80,0 %
nominal electrical power - W
nominal voltage - V
nominal frequency - Hz
fuel firewood logs
fuel consumption per hour 3,7 kg/h
total capacity of flue gases 12,1 g/s
flue gas temperature 262 °C
flue draught pressure 12,0 Pa
flue gases outlet Ø 250 mm
interior section of chimney flue Ø 25 cm
minimum height of chimney flue (from connecting joint) 4 m
outside air inlet ducts 2 x Ø 15 cm
height of hearth 25 cm
net weight 232 kg
weight with packaging 257 kg
.
ENGLISH
TECH 3 10

●
●
●
●
●
●
●
●
●
●
●
●
1.4 Firewood
The following paragraphs provide technical and practical information regarding the fuel used, so that the user will understand the
importance that Caminetti Montegrappa gives to the selection and preparation of the fuel, and the correct use of the appliance, which
will have a significant impact on proper functioning as well as minimizing fuel consumption and pollution.
Renewable, coming from trees and plants, which grow under the action of sun light.
Organic, being produced by living organisms.
Neutral as regards carbon dioxide released into the atmosphere ("neutral CO₂"), since the CO₂ produced after the combustion
is that absorbed during photosynthesis.
Clean since burning wood efficiently and completely produces only natural substances that are abundantly present
everywhere in our environment in non-toxic concentrations for the living organisms.


1.4.1 Characteristics of firewood
Firewood is usually classified into softwood (poor or fair quality) and hardwood (good quality) depending upon its specific weight;
hardwood, which weighs more than softwood, allows to reduce the amount of wood needed.

Softwood weighs about 300-350 kg/cu.m (with 15/20% moisture content):
it is easy to ignite, it burns rapidly and provides a lively fire.
Softwood includes the following species: fir, ailanthus, locust, chestnut, cypress, cornelian cherry, mulberry, larch, alder, pine,
poplar, willow, elder and lime.
Hardwood weighs about 350-400 kg/cu.m (with 15/20% moisture content):
it has a higher density and is less resinous than softwood, it burns slowly and keeps a low flame (suitable for home heating).
Hardwood includes the following species: maple, white birch, hornbeam, bitter oak, cherry, beech, ash, holm-oak, walnut, olive,
elm, pear, plane, oak and false acacia (those highlighted are among the best wood types).
As seen above, firewood for heating has different features according to the tree species it comes from. There are different types of
wood and their properties in terms of heat value vary from species to species. The heating value of wood fuel (kcal/kg) is the
quantity of heat produced after the complete combustion of 1 kg of wood.
The heating value of the different wood types is not only affected by the density, but also by their moisture content; as a
consequence the output and the efficiency of the appliance is strictly dependent upon the type of wood burned (normally the
heating value of a well seasoned wood is 3200 kcal/kg).
Here find some comparative data:
SOFTWOOD = kcal/kg 2800 - 3400.
HARDWOOD = kcal/kg 3400 - 3900.
WOOD BRIQUETTES = kcal/kg 3850 - 4200.
WOOD PELLET = kcal/kg 4200 - 4600.
Firewood is:
Corticated timber at a natural state, in pieces or not (logs, or briquettes free of any binders or additives, kindling, shavings from
processing trees), deadwood like branches and pine cones.
Wood residues created by the furniture manufacturing or the construction industry, provided they are not painted or treated.
Firewood is not:
Any wood scrap coming from house demolition, restoration or renovation, or coming from packing material (pallets), wooden
furniture, Formica, even if mixed with natural wood.
Any other wood material such as painted, varnished and treated wood scraps even if mixed with natural firewood.
Wood is the only source of energy that is:
Softwood produces more creosote with consequential need for more frequent cleaning of your chimney flue.
The only fuel admitted for the appliance use is firewood and its by-products.
The use of any other type of solid fuel (e.g. coal) is FORBIDDEN.
If possible, avoid the use of resinous wood as it can produce obstructions, which damage the inner parts of the
appliance firebox and the chimney flue.
ENGLISH
TECH 3 11

●
●
●
●
●
●
●
●
❍
❍
●
●
●

1.4.2 Preparing firewood
The firewood manufacturing processes vary greatly depending upon the final type of fuel to produce: wood pieces, briquettes or
pellets.
Wood pellets or briquettes are produced only in big sawmills that have large quantities of shavings and sawdust at disposal, which
become valuable products for an appealing market.
Individuals who are landowners can easily obtain the amount of wood that will be needed for their home heating.
Those who are not landowners can address dealers experienced in firewood combustion, who can advise about quality and wood
species locally available.
The most important steps in producing firewood are the following:
Cutting of trees or suckers (usually on waning moon or in winter).
Trimming of the smaller branches from the trunk (usually when they are less than 4 cm in diameter).
Cutting of trunks and branches into 1 m long logs.
Cutting of the bigger logs in half along their length (quartering).
Piling of the sawn logs in a dry, ventilated location favouring preliminary wood drying.
Covering the upper part of wood piles with clothes as shelf from the rain.
Cutting of the wood logs into small pieces whose length will vary to suit the user's needs. Final wood stacking in a dry,
ventilated location away from rain and humidity.
Air-drying for at least:
2 years (outdoor).
1 year (indoor, in an adequate place).

1.4.3 Purchasing firewood
The units of measurement commonly used in selling firewood are mainly three:
Cubic metre (cu.m): unit of measurement referring to any type of wood and corresponding to 1cu m of solid wood (the weight
of 1cu m of wood varies greatly depending upon species and humidity).
Stere (metre) (sm): unit of measurement referring to the stacked wood pieces and corresponding to 1 cu.m including the air
space between the pieces of stacked wood. The amount of wood contained in a space of 1 stere depends upon species,
relative moisture content, diametre and shape of the wood pieces, and the way in which they have been stacked (one stere of
wood logs 1 m long corresponds to approximately 0,7 cu.m of wood).
Quintal (q): officially suppressed, this unit of measurement (100 kg; 0,1 t) is still the most widely used in selling firewood.
"Deadwood" does not necessarily mean "dry wood": the dryness of wood is greatly determined by the time it takes
to dry but also by the place where wood is stored for seasoning. Should the wood be stacked for a long amount of
time without providing any protection or be kept in a humid, unsufficiently aerated place, it will rot and decay
easily under the action of mildew with consequential lost of its heating value.
Knowing the type of firewood and its moisture content, if it is sold on a space basis, allows you to get an idea of its heating
value, whereas it is not necessary to know the species of wood if it is sold on a weight basis as with an equal moisture
content the heat value differs slightly.
The heating value of wood varies greatly depending upon its moisture content, thus when you buy wood as a source of
energy it would be better knowing its moisture content.
If we compare as a way of example a piece of beech having a moisture content of 30% with a well seasoned piece of the
same wood type having a moisture content of 15%, the latter will release 25% more heat. When the moisture content is
50% the heat value is reduced by the half.
Purchase of green, damp or wet wood, could mean that you are also buying the water inside. To be sure the firewood you
have purchased has been seasoned for about one year, you should always buy your firewood in the summertime (June-
July) since trees are mostly cut in autumn.
Be careful with any painted or treated wood whose combustion can give off harmful fumes, and whose use is only allowed
in authorized combustion plants.
ENGLISH
TECH 3 12

●
●
●
●
●
❍
❍
❍
1.4.4 Combustion
When wood burns there are three stages of combustion:
DRYING: Moisture in wood is removed by evaporation by means of the surrounding fire. Any type of wood contains a
percentage of moisture. Since part of the heat produced by the fire is used for evaporation, it is more convenient and less
polluting to burn well-seasoned wood (max. 20% moisture) rather than green wood freshly cut (with 50% moisture or more).
This stage is over when the wood temperature reaches 100°C (water boiling point).
PYROLYSIS: At a higher temperature wood breaks down chemically and volatile gases and char are formed. When temperature
is between 260°C and 315°C this char and a small amount of these gases break into flames and wood burns. Most of these
gases will then be expelled through the chimney unless the temperature of the appliance is high enough to burn them. As
soon as these gases pass through the chimney they will mix with moisture to form creosote.
GASIFICATION AND COMBUSTION: Gases (smoke) and charcoal (wood residues) burn. Charcoal start burning and releases heat
between 540°C and 705°C, then become ash. Most of the usable heat is produced during this stage. Volatile gases, when mixed
with the proper amount of oxygen, ignite when temperature is between 600°C and 650°C. But gases rarely reach the above
temperature, unless they are conveyed towards flames or towards an area inside the firebox where this temperature has been
reached.

In practice the three stages are interwoven in a complex way during the combustion of every single piece of wood.
The incomplete combustion of wood results in toxic emissions. Note that the worst is the emission level the lower the heat
produced by the combustion process (e.g.: the use of big wood pieces results in slow combustion and low temperatures within the
fireplace, which affects negatively both the appliance and the chimney; the use of green, damp wood, which cannot burn
completely, results in soot and creosote formation collecting rapidly on the chimney walls).
On the contrary, in case of complete combustion (with well-seasoned wood and pieces of appropriate size) we reach a higher
temperature thus reducing the overall amount of the wood needed.
To ensure complete combustion and high efficiency the following conditions must be met:
The wood used must be dry and well-seasoned (with about 15/20% moisture content).
Your wood-burning appliance must be designed in such a way as to ensure that:
High temperatures are reached into the firebox.
Gases emitted in the combustion process are kept at very high temperatures for long time.
There is a sufficient amount of oxygen the gases emitted in the combustion process.
Compared with the past, new wood-burning appliances have been ameliorated with the aim of reducing emissions and increasing
efficiency.
This appliance has a fumes baffle at the top of the hearth, which ensures a higher and steadier temperature inside the combustion
chamber, which maximizes combustion and reduces wood consumption and the release of pollutant emissions.
On the fire bed remain the ashes, which are organic residues that may be used in gardening as soil fertilizer (about 2-3 litres once a
year every 10 sq.m).
ENGLISH
TECH 3 13

1.5 Recommendations

1.5.1 Safety precautions

1.5.2 General recommendations
IMPORTANT!!! For the proper and safe operation of this appliance and the electrical components in it, and in order
to prevent any possibility of causing serious injury, the instructions given in this manual must always be followed.
CAUTION: The installation, electrical connection, operation control, repair and maintenance works, must be
executed by qualified staff only.
CAUTION: If there has been a fire in the flue it is necessary to turn the appliance off and call the fire department and
check whether the chimney stack and flue pipe have been visibly damaged. Make any repairs before any further use
of the combustion system.
CAUTION: All local, national and European Norms must be met during installation and use of the appliance.
CAUTION: The accident-prevention and safety requirements stated in this manual must be followed carefully.
CAUTION: This manual must be read and understood in every part, and the use of the controls must be clear before
operating the appliance or executing any works on it.
WARNING: Do not modify or replace any parts in the unit by yourself; not-authorized works may cause injuries and will
relieve Caminetti Montegrappa of any public or criminal liability.
WARNING: During operation, some of the appliance surface areas may become very hot; we highly recommend not
to leave the unit unattended in the presence of children, elderly and disabled people.
ATTENTION: To avoid yielding and breakages (or feasible bursting or explosion in exceptional cases) of the CMtech®
parts, you are recommended to strictly follow the indications given for first-time starting.
WARNING: Never use flammable liquids (alcohol or petrol) to speed up the lighting of a wood fire: it is extremely
dangerous. Alcohol and petrol release highly flammable vapours, which could provoke the risk of burns.
CAUTION: This appliance is intended for the use it has been designed and manufactured for only.
CAUTION: This appliance in not intended to be used as a cooker so as to avoid that vapours and grease cause incrustations
on the combustion chamber's components and in the exhaust venting system.
ATTENTION: Don't use the appliance as an incinerator.
WARNING: Do not use the appliance in case of breakdown or malfunction.
In case of a model with forced convention (that is, fan-assisted) disconnect the bipolar switch (to provide on site).
In order to avoid releasing smoke in the room, it is FORBIDDEN to operate the appliance with the door open,
without the glass panel or with broken glass.
Always open the door slowly, first holding it open only slightly for a few seconds before opening it completely. Should
some smoke blow back, there is no danger, just aerate the room temporarily.
Ceramic glass thermal shock resistance 750°C. It is important not to light the fire close to the glass to avoid its
damage (white residue) in the long run.
Inspect and clean the exhaust venting system periodically.
ENGLISH
TECH 3 14


1.5.3 Warnings for correct appliance disposal
Warnings for correct appliance disposal in accordance with European Directive 2002/96/EC.
Do NOT spray the appliance with water to clean any of its parts.
For repairing, refer to authorized professionals and ask for original replacement parts only.
Keep this instruction manual as an integral part of the product for future reference.
It must be supplied together with the unit if this is resold or moved to another place, so as to allow the next user and
installer to get acquainted with its operating instructions and requirements.
Should the manual be lost or become unreadable, call Caminetti Montegrappa for a new copy.
Responsibility for the demolition and the disposal of the appliance lies exclusively with the owner who will have to act in
compliance with the regulations in force in his own Country regarding safety, respect and protection of the environment.
At the end of his useful life the appliance cannot be disposed of together with urban refuse.
It can be taken to special waste collection centers provided by local government, or to a dealer providing this service.
The separate disposal of the appliance (taking it to authorized recycling centres) avoids the possible negative
consequences for the environment and human health resulting from inappropriate disposal and allows to recover the
materials it is made of, in order to obtain significant energy and resources savings.
WARNING: Improper disposal of the appliance by the user implies the application of administrative sanctions
provided by law.
The abandonment of the appliance in accessible areas is a serious danger to humans and animals. The responsibility for any
damage to people and animals always lies with the owner.
Upon demolition, CE marking, this manual, the declaration of disposal, the manual for installation and other documents
relating to this appliance must be preserved. Remember that any registration with the regional land registry should be
annulled.
ENGLISH
TECH 3 15

●
1.6 Safety requirements and devices
The appliance is provided with the following safety devices:
Snap closure: the snap closure of the door folding into the frame when it stops and the special gaskets the door incorporates
make the firebox totally air-tight if compared to one without this device.

1.7 Environment requirements
WARNING: The installation of a "bipolar switch" is mandatory when providing the electrical connection of the fan-
assisted version; the bipolar switch acts as a safety device when the appliance is not operated or during
maintenance works as it enables to break the circuit and totally disconnect the appliance.
It is FORBIDDEN to disconnect the safety devices.
Note: This section has been drawn up considering the appliance as being operated in accordance with the
requirements and directions on the appliance use indicated under section 3.
Since Caminetti Montegrappa has no control over the conditions in which the appliance is being operated we
assume no responsibility for any injury or damage to people, properties or pets resulting from the non-observance
of these instructions and of the following recommendations:
A) During any maintenance, adjusting, cleaning and servicing works, the appliance must not be left unattended in
order to avoid incidental starting by third party.
B) Do not mishandle and/or remove any safety devices in the appliance.
C) Provide an efficient connection to the exhaust venting system.
D) Check that the room where the appliance is installed is aerated as prescribed.
IMPORTANT: To ensure its proper operation, the appliance shall be located in a ventilated room where an air flow allowing
the complete combustion of wood can be admitted according to the installation requirements under the local standards
currently in force.
The air supply must be sufficient for both proper combustion and to provide ventilation of the room, that is, no less than
15-20 sq.m.
The natural admission of air must be provided directly through two permanent openings made on the exterior walls of the
room of installation (for the section minimum dimension see section 2.3.5); the openings must be made in such a way they
can never be obstructed (check regularly).
Air entering the room where the appliance is installed from contiguous room(s) is permitted provided it is admitted from a
space which is aired directly from outside, a space which is not used as a bedroom or a bathroom and where fire ignition
could never occur, as in a garage or in a combustible warehouse, in compliance with the requirements under the local
standards currently in force.
80 cu.m/h of air is required in order to ensure proper fuel combustion.
(This pertains to operation with door closed).
Do NOT install the appliance in a bedroom or a bathroom, or in any other room where an existing heating appliance
(fireplace, stove, etc.) is not provided with its own outside air source.
It is FORBIDDEN to install the appliance near objects made of combustible materials (curtains, pieces of furniture,
carpets,...).
The appliance is not designed to be operated in environments where materials may explode. Therefore, it is
FORBIDDEN the use of the appliance in an explosive atmosphere or in a space where materials or machineries may
produce gas or dust emissions in such a quantity they may cause an explosion.
The minimum clearance to combustible side walls is 80 cm; a 150 cm clearance must be maintained to any objects or pieces
of furniture in front of the unit.
It is recommended that particularly delicate objects or pieces of furniture be installed at higher distances than those
previously recommended, if you assume they could be damaged by the changes in temperature produced during the
appliance operation.
The positioning of the appliance must be implemented in scrupulous compliance with the directions found in sections 2.3.
ENGLISH
TECH 3 16

1.8 Equipment

1.8.1 Checking of the accessories included

ENGLISH
TECH 3 17

1.8.2 Natural air convection channelling kit
(code 1530200100 OPTIONAL AVAILABLE ON PRICE LIST)

X = PARTS TO BE REMOVED AND ELIMINATED
ENGLISH
TECH 3 18
