COMPONENTS
PVS4100C and PVS4100D
Portable Automatic Liquid Samplers
Biggest,
Fastest Pump
Vacuum technology
for better samples
Overview
The PVS4100C and PVS4100D are deluxe, portable water samplers
that use ac power with a backup battery. The PVS4100C is a com-
posite sampler that deposits its water samples into a 9 L bottle;
the PVS4100D is a discrete sampler that deposits its water samples
into up to 24 containers. These samplers have a bigger pump than
our other portable water samplers allowing them to support the
fastest sampling rates and longest sampling distances.
campbellsci.com/water-samplers
Benets and Features
Rapid transport velocities of samples (horizontal draws 76.2 m
(250 ft) at 0.8 m s-1 (2.5 ft s-1), meaning more accurate samples,
even of solids
Controller housed in an environmentally sealed enclosure for
corrosion protection, and all information is easily controlled
and viewable on a 2 by 16 character backlit LCD
Composite or discrete models available
Side handles for easy lifting (increases diameter)
Interfaces with Campbell Scientic dataloggers for more
measurement and control capabilities
Stainless-steel suspension harness* available for sampling
in sewer systems
Handcart* available for easy transport
PVS4100C
PVS4100D
*For a complete list of options and accessories, refer to: www.campbellsci.com/pvs4100c-ordering or www.campbellsci.com/pvs4100d-ordering
Options*
Quick connect terminals
Power supply options: 80 to 264 Vac with a 17 A h battery or
80 to 264 Vac without a battery
Water Detection Probe
Warranty options: three or ve year
Sample container options: no bottles, 9 L bottle (PVS4100C
only), 24 0.5 L bottles (PVS4100D only), or 24 1 L bottles
(PVS4100D only)
PVS4100C size options: 3/8 in. ID system or 5/8 in. ID system
(the PVS4100D Discrete Sampler is a 3/8 in. ID system only)
questions & quotes: 435.227.9000

© 2011, 2013
Campbell Scientic, Inc.
September 25, 2013
Campbell Scientic, Inc.
|
815 W 1800 N
|
Logan, UT 84321-1784
|
[phone]
|
www.campbellsci.com
USA |AUSTRALIA |BRAZIL |CANADA | CHINA | COSTA RICA |ENGLAND |FRANCE |GERMANY |SOUTH AFRICA |SPAIN
Specications
Enclosure: Molded medium density linear polyethylene, three
piece construction and stainless-steel ttings
Cooling System: Insulated container wall cavity space for ice
Height: 80.9 cm (31.875 in.)
Height with extended base: 96.2 cm (37.875 in.)
Body Case Diameter: 42.8 cm (16.85 in.)
Sampler Weight, no battery: 11.8 kg (26 lb)
Battery Weight: 6.8 kg (15 lb)
Vacuum System
Pinch Valve: Fixed – normally open
Purge Cycle: Adjustable from 1 to 99 s
Suction Cycle: Variable (adjusts automatically to double the
input value of the purge time setting or until liquid contacts
level electrode in metering chamber
Metering Chamber Cover: Nylon
Volume Control Tube: 316 stainless steel
Metering Chamber Level Electrode: 316 stainless steel
Intake Hose: ordered as a common accessory. Campbell Scientic
oers PVC hose with 25 ft and user-specied lengths. Intake end
can have a lead sinker or stainless-steel strainer. Sampler end can
have a clamp or quick connect termination.
Discharge Hose Material: Latex
Controller
LCD: 2 x 16 character backlit LCD
Touchpad: 16 key with multi-level menu
Start Delay: Disabled; Time/Day; Pulse Count; 4 to 20 mA
(0 to 100 pulses/min.); External Contact; Level Control
Sample Initiation: Disabled; Time/Day; Pulse Count; 4 to 20 mA
(0 to 100 pulses/min.); External Contact
Program Type: Composite; Multi-Composite; Consecutive; Daily
Cycle; Timed Step
Clock: Real-time clock and operating system
Direct Function Keys: Manual sample; Manual purge; Manual
bottle advance; Restart
Switches: Controller on/o (SPST toggle)
Available Displays: Real-time clock; process timing; process
totals; pulse counting; event response; multilevel descriptions;
ashing prompts; diagnostics
Automatic Displays: Container Full; Fault; Power Interrupt (pro-
gram resumed); Alternating Time Stamp; Cycle(s) abandoned
Backup Power Source: Internal lithium battery to maintain
program settings and information in case of power failure
Power Requirements
DC Output: 13.6 Vdc, 10 A
AC Input: 88 to 264 Vac, 50/60 Hz, 2.5 A (nominal), 3 A (maximum)
Backup Battery: 12 Vdc
Quiescent Current Drain: 61 mA
Vacuum Pump
The PVS4100C and PVS4100D samplers use an external vacuum
pump to draw water through intake tubing, instead of the tra-
ditional peristaltic pump that induce ow by squeezing exible
tubing. Because the vacuum method disturbs the water samples
less, they better represent the original water solution, especially
if the solution has high concentrations of suspended solids. To
prevent cross contamination, the samplers use air pressure (up
to 28 psi) to purge the tubing of excess water. See our vacuum
pump water samplers in action at:
www.youtube.com/watch?v=wi4dxFTw-ks
Controller/Interfacing with a Datalogger
The PVS4100C and PVS4100D include a programmable controller
with 16-key intuitive touch pad. The controller can accept a pulse
input (e.g., rain gage), a 4 to 20 mA signal (e.g., ow meter), or
initiate a sample on a timed basis. See a demonstration of the
programmable controller at:
www.youtube.com/watch?v=yRr80Lm-5Hs
The sampler can also be interfaced with our dataloggers. Our
dataloggers can measure nearly any turbidity, water level, or
hydrometeorologic sensor, as well as control the sampler based
on time, event, or measured conditions.
Technical Details
Horizontal Velocity
System Size Distance
7.6 m (25 ft) 15.2 m (50 ft) 22.9 m (75 ft) 30.5 m (100 ft) 53.3 m (175 ft) 61 m (200 ft) 76.2 m (250 ft)
3/8 in. system 2.2 m s-1
(7.1 ft s-1)
1.9 m s-1
(6.2 ft s-1)
1.7 m s-1
(5.6 ft s-1)
1.5 m s-1
(5 ft s-1)
1.2 m s-1
(4 ft s-1)
1.1 m s-1
(3.7 ft s-1)
0.8 m s-1
(2.6 ft s-1)
5/8 in. system
(PVS4100C only)
1.5 m s-1
(5 ft s-1)
1.4 m s-1
(4.7 ft s-1)
1.3 m s-1
(4.3 ft s-1)
1.28 m s-1
(4.2 ft s-1)
1.1 m s-1
(3.7 ft s-1)
1 m s-1
(3.3 ft s-1)
0.7 m s-1
(2.4 ft s-1)
