Camplex CMX-12GSDI-CTRL User manual

12G-SDI over LC Fiber Converter set with RS-485 Function
CMX-12GSDI-CTRL
User Manual and Specifications

The CMX-12GSDI-CTRL is a 12G-SDI UHD audio and video optical converter that offers seamless
transmission of 12G-SDI video and RS485 Data signals through a single optical fiber up to 20km. It
supports various SDI standards, is energy-efficient (less than 1.5W), and features a robust, aluminum
shell. Easily integrated Type-C power supplies and included SFP modules make the CMX-12GSDI-
CTRL a reliable choice for your audio and video needs.
DESCRIPTION
Format Compatibility: Supports a wide range of video formats, including HD and SD standards
Precise Clock Management: Advanced clock recovery function ensures stable data regeneration with
low jitter
Signal Optimization: Automatic signal equalization for optimal quality and signal integrity
Long-Distance Transmission: Reliable transmission up to 20km using included simplex LC-based SFP
modules
Intuitive Status Indicators: Clear status lights provide quick device feedback
USB Power Supply: Conveniently powered via USB for added flexibility
Plug-and-Play: No need for complicated setup or debugging
Supports RS-485 transmission compliant with the EIA RS-485 standard
Single Mode Simplex LC fiber-based SFP modules included
FEATURES
CMX-12GSDI-CTRL

Fiber Type: 9/125um Single Mode
Rate: 12Gbps
Tx Power: 0~-3dB
Rx Sensitivity: -12dB
Fiber Connector: LC
Transmission Distance: Single Mode: 20km /
Multimode: 550m
Impedance: 75Ω
Input Level Range: 3.3V - 12V
Output Level Parameters: 0V or 3.3V
Input Current: ≤ 300MA
Input Voltage: 5V
Power Supply Physical Interface: Type C
Power Consumption: < 1.5W
Operating Temperature: -4°F - 167°F (-20°C -
75°C)
Storage Temperature: -40°F - 185°F (-40°C -
85°C)
Dimensions (LxWxH): 2.74 x 2.16 x 1.04 in (both
units)
Weight: 6 oz (both units)
Protocol Standard: SMPTE ST-2082
SMPTE Rate:
270Mbit/s, 1.48Gbit/s, 2.97Gbit/s, 5.94Gbit/s,
11.88Gbit/s
SMPTE 259M, SD-SDI 480i, 576i
SMPTE 344M, ED-SDI 480P, 576P
SMPTE 292M, HD-SDI 720P, 1080i
CMX-12GSDI-CTRL
SPECIFICATIONS
PACKAGE CONTENTS
1 x CMX-12GSDI-CTRL Converter Set
2 x Power Supplies
2 x USB to Type-C Power Cables
2 x Single Mode Simplex LC Fiber-based SFP Modules
Supported Standards (Digital Video Formats):
SMPTE 424M, 3G-SDI, 1080p@60Hz
SMPTE ST-2081, 6G-SDI, 2160p@30Hz
SMPTE ST-2082, 12G-SDI, 2160p@60Hz
Cable Equalization:
75m at 11.88Gbps
120m at 5.94Gbps
200m at 2.97Gbps
RS-485 Data Index:
Compliant with the EIA RS-485 Standard
Baud Rate: 50bps to 420kbps (supports non-
standard baud rates)
RS485: 2 wire (A, B), half-duplex, point-to-
multipoint communication
Interface: Industrial terminal/3.81mm Phoenix
Connector

CMX-12GSDI-CTRL
PRODUCT LAYOUT
CMX-12GSDI-CTRL (TX)
SDI In
RS485 Option
SDI Out

CONNECTION DIAGRAM:
CMX-12GSDI-CTRL
CMX-12GSDI-CTRL (TX)
CMX-12GSDI-CTRL (RX)
12G-SDI Cable
12G-SDI Cable
Mixed Video Matrix
Fiber Optic Cable
Broadcasting Station
12G-SDI Cable
12G-SDI Cable
HDMI Cable
4K Display
Computer
USB 3.0 Cable
12G-SDI Acquisition Card
4K Camera

The unit should be serviced by qualified service personnel if:
(a) The DC power supply cord or AC adaptor has been damaged
(b) Objects or liquids have gotten into the unit
(c) The unit has been exposed to rain
(d) The unit does not operate normally or exhibits a marked change in performance; The unit has been
dropped or the cabinet is damaged.
Servicing Personnel: Do not attempt to service the unit beyond that described in these operating
instructions. Refer all other servicing to authorized servicing personnel.
Replacement parts: When parts need replacing ensure the servicer uses parts specified by the
manufacturer. Unauthorized substitutes may result in fire, electric shock, or other hazards.
Safety check: After repairs or service, ask the servicer to perform safety checks to confirm that the unit is in
proper working condition.
If your product needs service please contact us at [email protected] or call us at 1.800.445.7568
DAMAGE REQUIRING SERVICE:
PRODUCT SERVICE
Please read all instructions before attempting to unpack, install or operate this equipment and before
connecting the power supply.
Please keep the following in mind as you unpack and install the unit:
Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this product near water.
Never spill liquid of any kind on or into this product.
Never push an object of any kind into this product through any openings or empty slots in the unit, as you
may damage parts inside the unit.
Do not attach the power supply cabling to building surfaces.
Use only the supplied power supply unit (PSU). Do not use the PSU if it is damaged.
Do not allow anything to rest on the power cabling or allow any weight to be placed upon it or any person
walk on it.
To protect the unit from overheating, do not block any vents or openings in the unit housing that provide
ventilation and allow for sufficient space for air to circulate around the unit
SAFETY PRECAUTIONS
WARRANTY
1 Year
CMX-12GSDI-CTRL
812 Kings Highway, Saugerties, NY 12477 | 1.800.445.7568 | [email protected]
